HP Compaq Microtower Business PC dx2300 User instructions

HP recommends
Windows Vista
®
Business
Microtower
1. Monitor (sold separately) 7. (4) USB 2.0 ports, (1) serial port, (1) optional second serial
port, (1) parallel port, (2) PS/2, (1) RJ-45, (1) VGA, (1) audio in –
(1) audio out – (1) MIC
2. PS/2 Scroll Mouse
3. HP Standard Keyboard
4. (2) USB 2.0 ports, audio ports 8. 250-watt max power supply
5. (2) internal 3.5" drive bays 9. (2) external 5.25" drive bays for optional optical drives; (1)
external 3.5" drive bay for optional media reader or diskette
drive
6. (1) full-height PCI 2.3 slot, (2) PCIe x1 slots,
(1) PCIe x16 slot
QuickSpecs
HP Compaq dx2300 Microtower Business PC
Overview
DA - 12668 North America — Version 17 — May 21, 2008 Page 1

At A Glance
Intel® Core™ 2 Duo processors, Intel Pentium® D processors, Intel Pentium 4 processors, or Intel Celeron® D processors
Choice of operating systems:
Genuine Windows Vista Business 32
Genuine Windows Vista Home Basic 32
Genuine Windows XP Professional
Genuine Windows XP Home
Intel 946GZ Express Chipset
Intel I/O Controller Hub 7 (ICH7)
Intel Graphics Media Accelerator 3000
PCI Express I/O bus
Serial ATA controller
Serial ATA optical and hard drives
Intel PRO/100 VE Network Connection
Choice of hard drives and optical drives
DDR2 SDRAM system memory
Protected by HP Services. Certain restrictions and exclusions apply.
QuickSpecs
HP Compaq dx2300 Microtower Business PC
Overview
DA - 12668 North America — Version 17 — May 21, 2008 Page 2

Model Key and Example
NOTE: This diagram is an example that illustrates how to read the model number. It is not intended to give every available configuration
choice specified in the body of this document and may include references to modules that are out of date and no longer available.
QuickSpecs
HP Compaq dx2300 Microtower Business PC
Configurable Components - Select Models
DA - 12668 North America — Version 17 — May 21, 2008 Page 3

Processor and Speed
One of the following
Intel Celeron D Processors
Intel Celeron D 331 Processor (2.66-GHz, 256-KB L2 cache, 533-MHz FSB)
Intel Celeron D 336 Processor (2.80-GHz, 256-KB L2 cache, 533-MHz FSB)
Intel Celeron D 347 Processor (3.06-GHz, 512-KB L2 cache, 533-MHz FSB)
Intel Celeron D 352 Processor (3.20-GHz, 512-KB L2 cache, 533-MHz FSB)
Intel Celeron D 356 Processor (3.33-GHz, 512-KB L2 cache, 533-MHz FSB)
Intel Celeron D 360 Processor (3.46-GHz, 512-KB L2 cache, 533-MHz FSB)
Intel Celeron D 420 Processor (1.60-GHz, 512-KB L2 cache, 800-MHz FSB)
Intel Celeron D 430 Processor (1.80-GHz, 512-KB L2 cache, 800-MHz FSB)
Intel Celeron D 440 Processor (2.00-GHz, 512-KB L2 cache, 800-MHz FSB)
Intel Pentium 4 Processors
Intel Pentium 4 631 Processor (3.00-GHz, 2-MB L2 cache, 800-MHz FSB)
Intel Pentium 4 641 Processor (3.20-GHz, 2-MB L2 cache, 800-MHz FSB)
Intel Pentium 4 651 Processor (3.40-GHz, 2-MB L2 cache, 800-MHz FSB)
Intel Pentium D Processors
Intel Pentium D 915 Processor (2.80-GHz, 4-MB L2 cache, 800-MHz FSB)
Intel Pentium D 925 Processor (3.00-GHz, 4-MB L2 cache, 800-MHz FSB)
Intel Pentium D 935 Processor (3.20-GHz, 4-MB L2 cache, 800-MHz FSB)
Intel Pentium D 945 Processor (3.40-GHz, 4-MB L2 cache, 800-MHz FSB)
Intel Pentium dual-core Processors
Intel Pentium Dual-Core E2140 Processor (1.60-GHz, 1-MB L2 cache, 800-MHz FSB)
Intel Pentium Dual-Core E2160 Processor (1.80-GHz, 1-MB L2 cache, 800-MHz FSB)
Intel Pentium Dual-Core E2180 Processor (2.00-GHz, 1-MB L2 cache, 800-MHz FSB)
Intel Core 2 Duo Processors
Intel Core 2 Duo E4300 Processor (1.80-GHz, 2-MB L2 cache, 800-MHz FSB)
Intel Core 2 Duo E4500 Processor (2.20-GHz, 2-MB L2 cache, 800-MHz FSB)
Intel Core 2 Duo E6300 Processor (1.86-GHz, 2-MB L2 cache, 1066-MHz FSB)
Intel Core 2 Duo E6320 Processor (1.86-GHz, 4-MB L2 cache, 1066-MHz FSB)
Intel Core 2 Duo E6400 Processor (2.13-GHz, 2-MB L2 cache, 1066-MHz FSB)
Intel Core 2 Duo E6420 Processor (2.13-GHz, 4-MB L2 cache, 1066-MHz FSB)
Intel Core 2 Duo E6600 Processor (2.40-GHz, 4-MB L2 cache, 1066-MHz FSB)
Intel Core 2 Duo E6700 Processor (2.66-GHz, 4-MB L2 cache, 1066-MHz FSB)
NOTE: Intel processor numbers are not a measure of performance. Processor numbers differentiate
features within each processor family, not across different processor families.
QuickSpecs
HP Compaq dx2300 Microtower Business PC
Standard Features and Configurable Components
DA - 12668 North America — Version 17 — May 21, 2008 Page 4

Operating Systems and
Application Software
(availability varies by
region)
Genuine Windows Vista Business 32*
Genuine Windows Vista Home Basic 32*
Genuine Windows XP Professional SP2
Genuine Windows XP Home SP2
SUSE Linux Enterprise Desktop 10 (certified)
Microsoft Office 2007 Basic
Microsoft Office 2007 Small Business
Microsoft Office 2007 Professional
Microsoft Works 8.5
HP Backup and Recovery Manager
Roxio Easy Media Creator 9.1**
Intervideo WinDVD Player**
Symantec AntiVirus 10
Sun Java Runtime Environment
Google Toolbar
HP Backup and Recovery Manager Software
* Certain Windows Vista product features require advanced or additional hardware. See
http://www.microsoft.com/windowsvista/getready/hardwarereqs.mspx and
http://www.microsoft.com/windowsvista/getready/capable.mspx for details. Windows Vista Upgrade
Advisor can help you determine which features of Windows Vista will run on your computer. To download
the tool, visit http://www.windowsvista.com/upgradeadvisor .
** Supporting software available with certain optical drive configurations
Hard Drives 80-GB Serial ATA 3.0-Gb/s Hard Drive (7200 rpm)
160-GB Serial ATA 3.0-Gb/s Hard Drive (7200 rpm)
250-GB Serial ATA 3.0-Gb/s Hard Drive (7200 rpm)
System Memory 256-MB DDR2 Synch DRAM PC2-5300 (667-MHz) Non-ECC (1 x 256-MB)
NOTE: 256-MB configurations not supported by Windows Vista
512-MB DDR2 Synch DRAM PC2-5300 (667-MHz) Non-ECC (1 x 512-MB)
1-GB DDR2 Synch DRAM PC2-5300 (667-MHz) Non-ECC (2 x 512-MB)
1-GB DDR2 Synch DRAM PC2-5300 (667-MHz) Non-ECC (1 x 1-GB)
2-GB DDR2 Synch DRAM PC2-5300 (667-MHz) Non-ECC (2 x 1-GB)
QuickSpecs
HP Compaq dx2300 Microtower Business PC
Standard Features and Configurable Components
DA - 12668 North America — Version 17 — May 21, 2008 Page 5

Storage –
One or more of the
following (see Storage
section below)
Diskette Drive
1.44-MB Diskette Drive
Media Reader
HP 16-in-1 Media Reader and additional USB 2.0 port
Optical Drives (Serial ATA)
SATA CD-ROM Drive (not supported by Windows Vista)
SATA DVD-ROM Drive
SATA CD-RW/DVD-ROM Combo Drive
SATA DVD+/-RW (DL/DF) LightScribe Drive
Input Devices Keyboard – One of the following
HP PS/2 Standard Keyboard
HP USB Standard Keyboard
Mouse – One of the following
PS/2 2-Button Scroll Mouse
PS/2 2-Button Optical Scroll Mouse
USB 2-Button Optical Scroll Mouse
Audio Realtek ALC888 High Definition audio codec
3D audio compliant with AC'97 Rev. 2.3 and HD Audio compatible
Internal PC speaker
Communication Intel PRO/1000 PT Gigabit PCIe Adapter (full height)
Intel PRO/100 VE Network Connection
Agere 56K PCI Modem
Graphics Intel Graphics Media Accelerator 3000
ATI Radeon X1300 (256MB SH) PCIe Graphics
ATI Radeon X1300 Pro (256MB DH) PCIe Graphics
Miscellaneous HP FireWire / IEEE 1394 PCI Card (full height)
QuickSpecs
HP Compaq dx2300 Microtower Business PC
Standard Features and Configurable Components
DA - 12668 North America — Version 17 — May 21, 2008 Page 6

Base Unit Micro ATX microtower chassis, including power supply and front bezel
Five (5) drive bays and four expansion slots
Microsoft operating system CD
Active type heatsink
92 x 92 x 25 mm chassis fan
System board with Intel 946GZ Express chipset, Intel I/O Controller Hub 7 (ICH7), Intel PRO/100 VE
Network Connection, Intel GMA 3000 graphics, and Realtek audio, 1 full-height PCI 2.3 slot, 2 PCI
Express x1 slots, 1 PCI Express x16 slot, 2 DDR2 DIMM memory slots
(4) Serial ATA data connectors
Product documentation on CD
Power cord
Slots PCI One (1) full-height PCI 2.3 slot on PCA
Two (2) full-height PCI Express x1 slots on PCA
One (1) full-height PCI Express x16 slot on PCA (for graphic cards)
Memory Expansion Two (2) DDR2 SDRAM DIMM slots (4 GB maximum memory support)
Bays Internal Two (2) 3.5”
External Two (2) 5.25”
One (1) 3.5”
USB Support EHCI high-speed USB 2.0 controller
Two (2) front ports; Four (4) rear ports, Two (2) internal ports on motherboard
Interfaces (Legacy) One (1) parallel port
One (1) serial port
One (1) optional second serial port
One (1) PS/2 keyboard port
One (1) PS/2 mouse port
One (1) analog VGA video port
One (1) line in; one (1) line out; one (1) mic in
One (1) RJ45 network port
One (1) microphone (front); one (1) headphone (front)
Weight & Dimensions Chassis Dimensions
(H x W x D)
13.90 x 6.89 x 16.38 in (353 x 175 x 416 mm)
Packaged Dimensions
(L x W x H)
22.25 x 19.63 x 16.31 in (565.15 x 498.5 x 414.3 mm)
System Weight 21.16 lb (9.6 kg)
Shipping Weight 30.86 lb (14.0 kg)
QuickSpecs
HP Compaq dx2300 Microtower Business PC
System Details
DA - 12668 North America — Version 17 — May 21, 2008 Page 7

Technology and Features Memory Type PC2-5300 DDR2 SDRAM (667-MHz) non-ECC
Up to 2-GB system memory standard
Up to 4-GB system memory supported
Hard Drive Interfaces
Supported
Serial ATA
Chassis Front Panel Power button
Power On LED
HDD Activity LED
Cooling Solutions
Supported
Power Supply Fan (variable speed)
Active heatsink (variable speed)
Chassis fan (variable speed)
Slots Supported Four (4) full-height expansion slots
Front I/O Two (2) USB 2.0 ports
Rear I/O Standard Micro ATX I/O connectors, including four (4 ) USB 2.0 ports
Drive Bays Two (2) 5-1/4” external
One (1) 3-1/2” external
Two (2) 3-1/2” internal
Internal Speaker Standard
Security Padlock loop
Kensington Lock Support
Power Supply 250-watt ATX Power Supply – PFC/non-PFC with a 115v/230v line switch
Unit Environment and
Operating Conditions
General Unit Operating Guidelines
Keep the computer away from excessive moisture, direct moisture and the extremes of heat and
cold, to ensure that unit is operated within the specified operating range.
Leave a 4 in (10.2 cm) clearance on all vented sides of the computer to permit the required airflow.
Never restrict airflow into the computer by blocking any vents or air intakes.
Do not stack computers on top of each other or place computers so near each other that they are
subject to each other's re-circulated or preheated air.
Occasionally clean the air vents on the front, back, and any other vented side of the computer. Lint,
dust and other foreign matter can block the vents and limit the airflow.
If the computer is to be operated within a separate enclosure, intake and exhaust ventilation must
be provided on the enclosure, and the same operating guidelines listed above will still apply.
Temperature Range Operating 50° to 95° F (10° to 35° C)
Non-operating -22° to 140° F( -30° to 60° C)
Relative Humidity Operating 10% to 90% (non-condensing at ambient)
Non-operating 5% to 95% (non-condensing at ambient)
Maximum Altitude
(unpressurized)
Operating 10,000 ft (3048 m)
Non-operating 30,000 ft (9000 m)
NOTE: Operating temperature is de-rated 1.0 deg C per 1000 ft (300 m) to 10,000 ft (3000 m) above sea
level, no direct sustained sunlight. Maximum rate of change is 10 deg C/Hr. The upper limit may be limited
by the type and number of options installed.
QuickSpecs
HP Compaq dx2300 Microtower Business PC
System Details
DA - 12668 North America — Version 17 — May 21, 2008 Page 8

System Board Processor Socket T; LGA775 industry standard Micro ATX form factor
Support single Intel Core 2 Duo, Pentium D, Pentium 4 or Celeron D
PWM Intersil 6312 3 phase
Chipset Intel 946GZ Express
Intel I/O Controller Hub 7 (ICH7)
Super I/O W83627DHG
Front Side Bus Frequency 533/800 MHz
Memory DDR2 SDRAM
2 x DIMM slots
Clock Generator CY505YC56DT
Integrated Graphics Intel Graphics Media Accelerator (GMA) 3000
Audio Realtek ALC888 HD Audio compatible codec with two channel audio 3D audio
compliant with AC'97 rev. 2.3
LOM Intel PRO/100 VE Network Connection
Serial Four Serial ATA interfaces
Expansion Slots 1 x PCI 2.3 slot
2 x PCI Express x1 slots
1 x PCI Express x16 slot
BIOS LPC EEPROM
Industrial Standard PCI 2.3 compliant
USB 2.0
Rear Side I/O Ports 1 x PS/2 keyboard port
1 x PS/2 mouse port
4 x USB 2.0 ports
1 x RJ-45 10/100 port
1 x serial port
1 x optional second serial port
1 x parallel port
1 x DB 15 pin analog VGA port
3 x audio ports
On Board I/O Interfaces 1 x ATX power connector
1 x +12V power connector
1 x Floppy connector
1 x Front panel connector, Switch, LED (ON/Flash/OFF)
2 x Fan headers for CPU, chassis, with voltage/fan speed control
1 x header to support 2 USB 2.0 ports at front side
1 x header to support USB media reader
1 x serial header to support optional second serial port
Board Size Micro-ATX, PCB Size: 9.6 x 9.0 in (24.38 x 22.86 cm)
4-layer PCB with green color
QuickSpecs
HP Compaq dx2300 Microtower Business PC
System Details
DA - 12668 North America — Version 17 — May 21, 2008 Page 9

Additional Features Bootable without keyboard, mouse or monitor
Keyboard/mouse/USB wake up
Support S1, S3, S4 and S5
ACPI status
Hardware monitor capability
CPU fan speed control
Network Interface Intel PRO/100 VE Network
Connection
Hardware Highlights PCI interfaces
Features 10-Mbps and 100-Mbps operation
Intel PRO/1000 PT Gigabit
PCIe Adapter
Hardware Highlights PCI Express interface
Features 10-Mbps, 100-Mbps and 1000-Mbps operation
Wireless Wireless A+G PCI Card (full height bracket)
Power Supply ATX Power Supply – Passive PFC/non-PFC with a 115v/230v line switch
Passive Power Factor Correction (PFC) – with line switch set to 230V – No PFC in 115V line switch
position
90 to 140VAC, or 180 to 264VAC operating voltage range
100 to 127VAC, or 200 to 240VAC rated voltage range
50–60 Hz rated line frequency
47–63 Hz operating line frequency range
250 watt maximum rated power
80-mm power supply fan – variable speed for optimum acoustics
Power Conservation
‘Energy Saver‘
APM 1.2 support
Screen blanking
Hard drive 'Idle' mode
System Idle mode
~2 watt power consumption in ES mode – suspend to RAM (S3) (instantly available PC)
Processor/Cache memory power-down (S3)
QuickSpecs
HP Compaq dx2300 Microtower Business PC
System Details
DA - 12668 North America — Version 17 — May 21, 2008 Page 10

System Environmental
Specs
Values are subject to change without notification and are for reference only.
Performance of system, options, and ancillary equipment will vary depending on the system
configuration.
Levels presented do not account for non-HP/Compaq installed hardware.
Ambient Air Temperature Operating 50° to 95°F (10° to 35°C) at sea level with an
altitude de-rating of 1.0°C per every 1000 ft (300
m) above sea level to a maximum of 8000 ft
(2500 m), no direct sustained sunlight. Maximum
rate of change is 77°F/Hr (25°C/Hr). The upper
limit may be limited by the type and number of
options installed.
Storage -22° to 140°F (-30° to 60°C) –
Maximum rate of change: 410°F/Hr (210°C/Hr).
Humidity Operating 10% to 90% relative humidity (Rh), 86°F (30°C)
maximum wet bulb temperature, non-condensing
Storage 10% to 95% relative humidity (Rh), 101.66°F
(38.7°C) maximum wet bulb temperature, non-
condensing
Altitude Operating 0 to 10,000 feet (0 to 3048 meters) – This value
may be limited by the type and number of options
installed. Maximum allowable altitude change
rate is 1,000 ft/min (304.8 m/min).
Non-Operating 0 to 30,000 feet (0 to 9,144 meters) – Maximum
allowable altitude change rate is 1200 ft/min
(365.76 m/min).
Shock Listed are the levels of shock the product can withstand with NO damage
being incurred. The values represent peak input acceleration during an 2~3 ms
half-sine shock pulse, 11 ms trapezoidal shock pulse.
Non-Operating 35G's (Half-sine Shock)
35G's (Trapezoidal Shock)
Vibration Listed are the levels of vibration the product can withstand with NO damage
being incurred. The values represent a flat random vibration input
acceleration profile across the given frequency range.
Operating Random vibration at [email protected]
2
/Hz,
[email protected]
2
/Hz, [email protected]
2
/Hz,
[email protected]
2
/Hz
5Hz to 300Hz, (0.25G's nominal).
Non-Operating Random vibration at 0.008G²/Hz,
10Hz to 500Hz, (2 Grms nominal).
QuickSpecs
HP Compaq dx2300 Microtower Business PC
System Details
DA - 12668 North America — Version 17 — May 21, 2008 Page 11

Acoustic Noise Listed are the declared A-WEIGHTED SOUND POWER LEVELS (LWAd) and
declared average desktop seated operator position A-WEIGHTED SOUND
PRESSURE LEVELS (LpAm) when the product is operating in a 73.4°F (23°C)
ambient environment. Noise emissions were measured in accordance with ISO
7779 (ECMA 74) and declared in accordance with ISO 9296 (ECMA 109).
IDLE (Fixed disk drive
spinning)
LWAd = 4.3 Bels,
Desktop Average LpAm = 32 dBA
FIXED DISK (Random write) LWAd = 4.8 Bels,
Desktop Average LpAm = 37dBA
CD-ROM (Sequential
Reads)
LWAd = 5.0 Bels,
Deskside Average LpAm = 39dBA
Service and Support On-site Warranty
1
: One-year (1-1-1) limited warranty delivers one year of on-site, next business-day
2
service for parts and labor and includes free telephone support
3
24 x 7. Global coverage
2
ensures that any
product purchased in one country and transferred to another non-restricted country will remain fully
covered under the original warranty and service offering.
1
Terms and conditions may vary by country. Certain restrictions and exclusions apply.
2
On-site service may be provided pursuant to a service contract between HP and an authorized HP third-
party provider, and is not available in certain countries. Global service response times are based on
commercially reasonable best effort and may vary by country.
3
Technical telephone support applies only to HP-configured Compaq and third-party HP-qualified
hardware and software. Toll-free calling and 24 x 7 support may not be available in some countries.
QuickSpecs
HP Compaq dx2300 Microtower Business PC
System Details
DA - 12668 North America — Version 17 — May 21, 2008 Page 12

Communications NICs
Intel PRO/1000 PT PCIe Gigabit NIC Card EH352AA
Wireless LAN
HP Wireless A+G PCI Card EA118AA
Modems
Agere 2006 PCI High-Speed 56K International SoftModem EK694AA
Connectivity
Bundle Connectivity Starter Kit – Surge Protector/LAN cable/Printer cable RT174AA
Office 2007 Media-less
License Kits (MLKs)
MS Office Basic Edition 2007 – Media-less License Kit RZ361A#ABA
MS Office Small Business Edition 2007 – Media-less License Kit RZ365A#ABA
MS Office Professional Edition 2007 – Media-less License Kit RZ363A#ABA
Hard Disk Drives HP 250-GB SATA 3.0-Gb/s Hard Drive PY278AA
HP 160-GB SATA 3.0-Gb/s Hard Drive PY277AA
HP 80-GB SATA 3.0-Gb/s Hard Drive PY276AA
Removable Storage
Devices
Diskette Drive
HP 1.44-MB Internal Diskette Drive AG295AA
HP 1.44-MB USB Diskette Drive – External DC141B
16-in-1 Media Reader EM718AA
Input Devices Keyboards
HP PS/2 Standard Keyboard DT527A#ABA
HP USB Standard Keyboard DT528A#ABA
Mice
HP PS/2 2-Button Scroll Mouse DD440B
HP PS/2 2-Button Optical Scroll Mouse EY703AA
HP USB 2-Button Optical Scroll Mouse DC172B
HP USB 2-Button Laser Mouse GW405AA
Memory HP 1-GB PC2-5300 (DDR2-667 MHz) DIMM PX976AA
HP 512-MB PC2-5300 (DDR2-667 MHz) DIMM PX975AA
HP 256-MB PC2-5300 (DDR2-667 MHz) DIMM PX974AA
QuickSpecs
HP Compaq dx2300 Microtower Business PC
After-Market Options
DA - 12668 North America — Version 17 — May 21, 2008 Page 13

Audio HP USB Powered Speakers RD628AA
Thin USB Powered Speakers KK912AA
(launching
4/14/08)
Graphics ATI RADEON X1300 (256MB DH) PCIe Graphics Card AH050AA
ATI RADEON X1300 (256MB SH) PCIe Graphics Card AG392AA
HP DMS59 DVI Dual-head Connector Cable DL139A
Optical Drives HP SATA CD-RW/DVD-ROM Combo Drive AH046AA
HP SATA DVD-ROM Drive AH047AA
HP PATA DVD+/-RW SuperMulti LightScribe Drive GF343AA
Security HP Business PC Security Lock Kit TBD
Kensington Compaq Security Lock – Single PC766A
HP Smart Data Protection Service BB731UT
Cables and Adapters HP USB to Serial Adapter, 3ft EM449AA
HP DVI to DVI Cable DC198A
Local Area Network (LAN) cable AH122AA
HP Firewire (1394) Cable AH123AA
HP 7-outlet Surge Protector AG290AA#ABA
HP DMS59 DVI Dual-head Connector Cable (supports AH050AA) DL139A
Chassis Enhancements HP 5.25" Blank Bezel Kit (Carbonite 50/Bulk Pack) DC177B
Miscellaneous
Accessories
HP FireWire / IEEE 1394 PCI Card PA997A
QuickSpecs
HP Compaq dx2300 Microtower Business PC
After-Market Options
DA - 12668 North America — Version 17 — May 21, 2008 Page 14

Monitors CRTs 3PO Offering
Business LCD Monitors
HP L1506 15-inch LCD Monitor PX848AA#ABA
HP L1710 17-inch LCD Monitor GS917AA#ABA
HP L1750 17-inch LCD Monitor GF904AA#ABA
HP L1745 17-inch LCD Monitor GE178AA#ABA
HP L1910 19-inch LCD Monitor GS918AA#ABA
HP L1950 19-inch LCD Monitor GG458AA#ABA
HP LP1965 19-inch LCD Monitor RA373AA#ABA
HP LP2065 20-inch LCD Monitor EF227A4#ABA
Business Widescreen LCD Monitors GX007AA#ABA
HP L1908w 19-inch Widescreen LCD Monitor GP536AA#ABA
HP L2045w 20-inch Widescreen LCD Monitor RD125AA#ABA
HP L2208w 22-inch Widescreen LCD Monitor GX007AA#ABA
HP L2245w 22-inch Widescreen LCD Monitor GX008AA#ABA
HP LP2465 24-inch Widescreen LCD Monitor EF224A4#ABA
HP LP3065 30-inch Widescreen LCD Monitor EZ320A4#ABA
Business Widescreen LCD Monitor with Integrated Speakers
HP L1908wm 19-inch Widescreen LCD Monitor with Built in Integrated Speakers KA214AA#ABA
Business GSA Monitors 3PO Offering
Business Touchscreen LCD Monitor
HP L5006tm 15-inch Touch Screen LCD Monitor RB146AA#ABA
Business LCD Monitor with Integrated Work Stand
HP L1908wi 19-inch Widescreen LCD Monitor plus Integrated Work Stand GP537AA#ABA
HP L1910i 19-inch LCD Monitor plus Integrated Work Stand GS581AA#ABA
Options
HP Flat Panel Speaker Bar EE418AA
HP Quick Release Kit EM870AA
HP Integrated Work Stand (stand alone) GN783AA
QuickSpecs
HP Compaq dx2300 Microtower Business PC
After-Market Options
DA - 12668 North America — Version 17 — May 21, 2008 Page 15

DDR SYNCH DRAM NON-ECC MEMORY
The Intel 946GZ Express chipset supports non-ECC DDR2 memory up to PC2-5300 (667-MHz). Memory upgrades are accomplished by
adding single or multiple DIMMs of the same or varied sizes. This chart does not represent all possible memory configurations.
CAUTION: You must shut down the computer and disconnect the power cord before adding or removing memory modules. Regardless
of the power-on state, voltage is always supplied to the memory modules as long as the computer is plugged in to an active AC outlet.
Adding or removing memory modules while voltage is present may cause irreparable damage to the memory modules or system
board.
HP recommends dual-channel symmetric configurations for maximum performance.
For best performance, add the same amount of total memory to each channel and do not mix speeds. For dual-channel symmetric
performance, the total amount of memory in each channel must be equal. If speeds are mixed, speed will default to the slowest DIMM.
STANDARD MEMORY
256-MB, 512-MB, 1-GB, or 2-GB DDR2 SYNCH DRAM
OPTIONAL MEMORY UPGRADES
Supports up to 4-GB of DDR2 SYNCH DRAM. Not all memory configurations possible are represented below.
DIMM Size Slot 1 Slot 2
256-MB 256-MB
512-MB 512-MB
512-MB (dual-channel symmetric) 256-MB 256-MB
1-GB 1-GB
1-GB (dual-channel symmetric) 512-MB 512-MB
2-GB (dual-channel symmetric) 1-GB 1-GB
4-GB (dual-channel symmetric) 2-GB 2-GB
QuickSpecs
HP Compaq dx2300 Microtower Business PC
Memory
DA - 12668 North America — Version 17 — May 21, 2008 Page 16

HP Compaq dx2300 Microtower Business PC
Maximum Quantity
Supported
Position Supported Controller
Drive Support
Diskette Drives 1 3 SIO
Media Reader 1 3 Internal USB 2.0 port
CD-ROM Drives 2 1, 2 SATA
DVD-ROM Drives 2 1, 2 SATA
CD-RW/Combo Drives 2 1, 2 SATA
DVD+/-RW Drives 2 1, 2 SATA
3.5” Serial ATA Hard Drives 2 4,5 SATA
QuickSpecs
HP Compaq dx2300 Microtower Business PC
Storage
DA - 12668 North America — Version 17 — May 21, 2008 Page 17

Integrated Realtek
ALC888 Audio
Type Integrated
HD Audio compatible
codec
Yes
Sampling Supports 48/96 KHz
Audio Jacks Mic-In
Line-In
Line-Out / Headphone Out
Power Support Digital: 3.3V
Analog: 5V
Other Meets performance requirements for audio on PC99/2001 systems
High-performance DACs with 97dB SNR(A-Weighting)
ADCs with 90dB NR(A-Weighting)
QuickSpecs
HP Compaq dx2300 Microtower Business PC
Technical Specifications - Audio
DA - 12668 North America — Version 17 — May 21, 2008 Page 18

Intel PRO/1000 PT PCIe
Gigabit NIC
Connector RJ-45
Controller Intel 82572EI Gigabit Ethernet Controller
Memory Integrated Dual 48K configurable transmit receive FIFO Buffers
Data rates supported 10/100/1000 Mbps
Compliance IEEE 802.1P, 802,1Q, 802.2, 802.3, 802.3AB and 802.3u compliant, 802.3x
flow control
Bus architecture PCI Express 1.0a
Data transfer mode Bus-master DMA
Hardware certifications FCC, B, CE, TUV- cTUVus Mark Canada and United States, TUV- GS Mark for
European Union
Power requirement Aux 3.3V, 3.0 Watts in 1000base-T and 2.0 Watts in 100Base-T
Boot ROM support Yes
Network transfer rate 10BASE-T (half-duplex) 10 Mbps
10BASE-T (full-duplex) 20 Mbps
100BASE-TX (half-duplex) 100 Mbps
100BASE-TX (full-duplex) 200 Mbps
1000BASE-T (full-duplex) 2000 Mbps (actual rate limited by PCI Bus)
Environmental Operating temperature 32° to 131°F (0° to 55° C)
Operating humidity 85% at 131° F (55° C)
Dimensions 6.4 x 2.6 x 0.8 in (16.3 x 6.6 x 1.9 cm)
Management capabilities ASF, WOL, PXE, DMI, WFM 2.0.
HP Wireless A+G PCI Dimensions 4.99 x 2.54 x 0.71 in (126.8 x 64.4 x 18.0 mm)
Weight 0.268 lb (65 g)
Controller
system interface
Atheros AR5414X chipset
PCI Spec 2.2
Network standard IEEE 802.11a/b/g
Frequency band 5.1500 to 5.8500 GHz
2.4000 to 2.4835 GHz
Operating temperature 32° to 140° F (0° to 60° C), operating
Storage temperature -4° to 176° F (-20° to 80° C), non-operating
Humidity 10% to 85% non-condensing
Operating voltage 5V ± 5%
Power consumption Tx/Rx peak 560/250mA @ 3.3V (max.)
Output power
(approximately)
15 dBM ±2dB
Receive sensitivity -90dBm at 11 Mbps (typical)
Data transfer rate Standard rates of 1, 2, 5.5, 11, 6, 9, 12, 18, 24, 48, 54 and Super AG Mode108-
Mbps
QuickSpecs
HP Compaq dx2300 Microtower Business PC
Technical Specifications - Communications
DA - 12668 North America — Version 17 — May 21, 2008 Page 19

Spreading DSSS (Direct Sequence Spread Spectrum)
Security 64(40h) bit, 128(104h) bit, WPA, IEEE802.1X, AES-OCB, AES-CCM, Microsoft
PEAP,TKIP, WEP
Antenna External 5dBi antenna
Throughput 108 Mbps (only with Belkin
54G or above router that
supports 108 Mbps speed)
200 ft (60.96 m) – Indoor
54 Mbps 200 ft (60.96 m) – Indoor
11 Mbps 200 ft (60.96 m) – Indoor
Certifications Wi-Fi certified
Certifications for use by
country
North America: United States, Canada
Agere 56K PCI Modem Data Transmission 56,000 Kbps maximum downstream data
NOTE: 56 Kbps technology refers to download speeds only and requires
compatible modems at server sites. Other conditions may limit modem speed.
FCC limitations allow a maximum of 53 Kbps during download transmissions.
Data Speeds (Upload only) 33,600/31,200/28,800/26,400/21,600/19,200/16,800/14,400/
12,000/9,600/7,200/4,800/2,400/1,200/300
Data Standards ITU-T V.90, ITU-T, ITU-T V.34, V.44, V.42, V.42bis21, V.32bis, Bell 212A, and
Bell 103
Fax Speeds 14,400/12,000/9,600/7,200/4,800/2,400/300 b/s
Fax Mode Capabilities ITU-T T.31 class 1 FAX, V. 17, V.29, V.27ter, and V.21 Channel 2
Error Correction and Data
Compression
V.44, 42bis, V.42 and MNP2-5
Power Management ACPI; PPMI 1.1 and wake support with PME and Vaux; meets PCI 2.3
requirements and PC 2001 requirements
Upgradeability Driver upgradeable for future enhancements
Video ITU-T V.80 video ready interface
Other TIA/EIA 602 standard AT command set
Integrated DTE interface with speeds of up to 115.2 Kbps, parallel 16550a
UART-compatible interface
Optional ring wakeup signal
Operating Temperature 32° to 158° F (0° to 70° C)
Operating Humidity 20% to 90%, non-condensing
Power Requires a 3.3-V auxiliary power rail on PCI bus
Uses only one PCI load (i.e., one grant/request pair), one shared IRQ, one
electrical load
Chipset Agere Systems SV92PL – Integrated PCI interface with 5-V tolerant buffers
and CardBus support
Dimensions (L X H) Complies with PCI low profile specifications-6.7 x 2.3 in (17.0 x 5.8 cm) and
supports high- and low-profile brackets
QuickSpecs
HP Compaq dx2300 Microtower Business PC
Technical Specifications - Communications
DA - 12668 North America — Version 17 — May 21, 2008 Page 20
