HP dx2200 - Microtower PC Operating and maintenance manual

Hardware Reference Guide
HP Compaq dx2200 Microtower Business
PC
Document Part Number: 413758-001
January 2006
This guide provides basic information about upgrading this computer
model.

© Copyright 2006 Hewlett-Packard Development Company, L.P.
The information contained herein is subject to change without notice.
Microsoft and Windows are trademarks of Microsoft Corporation in the U.S.
and other countries.
The only warranties for HP products and services are set forth in the express
warranty statements accompanying such products and services. Nothing herein
should be construed as constituting an additional warranty. HP shall not be liable
for technical or editorial errors or omissions contained herein.
This document contains proprietary information that is protected by copyright.
No part of this document may be photocopied, reproduced, or translated to
another language without the prior written consent of Hewlett-Packard
Company.
ÅWARNING: Text set off in this manner indicates that failure to follow
directions could result in bodily harm or loss of life.
ÄCAUTION: Text set off in this manner indicates that failure to follow
directions could result in damage to equipment or loss of information.
Hardware Reference Guide
HP Compaq dx2200 Microtower Business PC
First Edition (January 2006)
Document Part Number: 413758-001

Hardware Reference Guide www.hp.com iii
Contents
1 Hardware Upgrades
Serviceability Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1–2
Warnings and Cautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1–2
Removing the Access Panel and Front Bezel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1–3
Removing a 5.25" Drive Bezel Blank . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1–5
Removing a 3.5" Drive Bezel Blank . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1–6
Installing Additional Memory . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1–7
DIMMs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1–7
DDR2-SDRAM DIMMs. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1–7
Installing DIMMs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1–8
Installing an Expansion Card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1–10
Replacing or Upgrading a Drive . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1–12
Locating Drive Positions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1–13
Removing a 5.25" Optical Drive . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1–14
Removing a 3.5" Media Card Reader or Diskette Drive . . . . . . . . . . . . . . . . . . . 1–16
Removing a 3.5" Hard Drive . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1–18
2 Battery Replacement
Replacing the Battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2–1
3 Computer Operating Guidelines, Routine Care and
Shipping Preparation
Computer Operating Guidelines and Routine Care. . . . . . . . . . . . . . . . . . . . . . . . . . . . 3–1
Optical Drive Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3–2
Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3–2
Cleaning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3–2
Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3–2
Shipping Preparation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3–3

iv www.hp.com Hardware Reference Guide
Contents
4 Electrostatic Discharge
Preventing Electrostatic Damage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4–1
Grounding Methods. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4–1

Hardware Reference Guide www.hp.com 1-1
1
Hardware Upgrades
HP Compaq dx2200 Microtower
✎The drive configuration shown above may be different than your
computer model.

1-2 www.hp.com Hardware Reference Guide
Hardware Upgrades
Serviceability Features
The Microtower computer includes features that make it easy to
upgrade and service. A Torx T-15 screwdriver is needed for many of
the installation procedures described in this chapter.
Warnings and Cautions
Before performing upgrades be sure to carefully read all of the
applicable instructions, cautions, and warnings in this guide.
ÅWARNING: To reduce the risk of personal injury from electrical shock
and/or hot surfaces, be sure to disconnect the power cord from the wall
outlet and allow the internal system components to cool before touching.
ÅWARNING: To reduce the risk of electrical shock, fire, or damage to the
equipment, do not plug telecommunications/telephone connectors into the
network interface controller (NIC) receptacles.
ÄCAUTION: Static electricity can damage the electrical components of the
computer or optional equipment. Before beginning these procedures,
ensure that you are discharged of static electricity by briefly touching a
grounded metal object. See Chapter 4, “Electrostatic Discharge” for more
information.
ÄCAUTION: When the computer is plugged into an AC power source,
voltage is always applied to the system board. You must disconnect the
power cord from the power source before opening the computer to
prevent system board damage.

Hardware Reference Guide www.hp.com 1-3
Hardware Upgrades
Removing the Access Panel and Front Bezel
ÄCAUTION: Before removing the computer access panel, ensure that the
computer is turned off and that the power cord is disconnected from the
electrical outlet.
1. Turn off the computer properly through the operating system and
turn off any external devices.
2. Disconnect the power cord from the power outlet and the
computer 1, and disconnect any external devices.
3. Remove the two screws that secure the access panel to the
computer chassis 2.
4. Slide the access panel back about 1.25 cm (1/2 inch), then lift it
away from and off the unit 3.
Removing the Power Cord and Access Panel
✎To replace the access panel, reverse the removal steps.

1-4 www.hp.com Hardware Reference Guide
Hardware Upgrades
5. To remove the front bezel, pull outward on all three tabs on the
left side of the bezel 1then rotate the bezel off the chassis 2,
beginning with the left side then the right side.
Removing the Front Bezel
✎To replace the front bezel, insert the three hooks on the right side of
the bezel into the rectangular holes on the chassis then rotate the bezel
into place so that the catches on the three tabs on the left side of the
bezel snap into place on the chassis.

Hardware Reference Guide www.hp.com 1-5
Hardware Upgrades
Removing a 5.25" Drive Bezel Blank
If the computer was not shipped with a drive in the 5.25" option bay,
the bay will be covered by a bezel blank. If you add a drive to the
option bay, you must first remove the bezel blank.
1. Turn off the computer properly through the operating system and
turn off any external devices.
2. Disconnect the power cord from the power outlet and the
computer, and disconnect any external devices.
3. Remove the access panel and front bezel. Refer to “Removing the
Access Panel and Front Bezel.”
4. While facing the inside of the front bezel, press the two retaining
tabs on the right towards the outer edge of the bezel 1and pull
the bezel blank inwards to remove it 2.
Removing a 5.25" Bezel Blank
✎To install a 5.25" bezel blank, slide the left side of the blank into the
two retainer slots on the left side of the front bezel then snap the right
side of the blank into place.

1-6 www.hp.com Hardware Reference Guide
Hardware Upgrades
Removing a 3.5" Drive Bezel Blank
If the computer was not shipped with a device in the 3.5" bay, the bay
will be covered by a bezel blank. If you install a device in the 3.5"
bay, you must first remove the bezel blank.
1. Turn off the computer properly through the operating system and
turn off any external devices.
2. Disconnect the power cord from the power outlet and the
computer, and disconnect any external devices.
3. Remove the access panel and front bezel. Refer to “Removing the
Access Panel and Front Bezel.”
4. While facing the inside of the front bezel, press outward on the
two retaining tabs on each side of the bezel blank 1and pull the
bezel blank inwards to remove it 2.
Removing a 3.5" Bezel Blank
✎To install a 3.5" bezel blank, press the blank inward from inside the
front bezel so that it snaps into place.

Hardware Reference Guide www.hp.com 1-7
Hardware Upgrades
Installing Additional Memory
The computer comes with double data rate 2 synchronous dynamic
random access memory (DDR2-SDRAM) dual inline memory
modules (DIMMs).
DIMMs
The memory sockets on the system board can be populated with up to
two industry-standard DIMMs. These memory sockets are populated
with at least one preinstalled DIMM. The sockets are labeled DIMM1
and DIMM2. To achieve the maximum memory support, you can
populate the system board with up to 2GB (2 x 1GB) of memory.
DDR2-SDRAM DIMMs
For proper system operation, the DDR2-SDRAM DIMMs must be:
■industry-standard 240-pin
■unbuffered PC2-5300 667 MHz-compliant
■1.9 volt DDR2-SDRAM DIMMs
The DDR2-SDRAM DIMMs must also:
■support CAS latency 4 (CL = 4) for PC2-5300 667 MHz
■contain the mandatory JEDEC SPD information
In addition, the computer supports:
■256Mbit, 512Mbit, and 1Gbit non-ECC memory technologies
■single-sided and double-sided DIMMS
■DIMMs constructed with x8 and x16 DDR devices; DIMMs
constructed with x4 SDRAM are not supported
✎The system will not start if you install unsupported DIMMs.

1-8 www.hp.com Hardware Reference Guide
Hardware Upgrades
Installing DIMMs
ÄCAUTION: The memory module sockets have gold metal contacts. When
upgrading the memory, it is important to use memory modules with gold
metal contacts to prevent corrosion and/or oxidation resulting from having
incompatible metals in contact with each other.
ÄCAUTION: Static electricity can damage the electronic components of
the computer or optional cards. Before beginning these procedures,
ensure that you are discharged of static electricity by briefly touching a
grounded metal object. For more information, refer to Chapter 4,
“Electrostatic Discharge.”
ÄCAUTION: When handling a memory module, be careful not to touch
any of the contacts. Doing so may damage the module.
1. Turn off the computer properly through the operating system and
turn off any external devices.
2. Disconnect the power cord from the power outlet and the
computer, and disconnect any external devices.
3. Remove the computer access panel.
4. Locate the memory module sockets on the system board.
ÅWARNING: To reduce risk of personal injury from hot surfaces, allow
the internal system components to cool before touching.

Hardware Reference Guide www.hp.com 1-9
Hardware Upgrades
5. Open both latches of the memory module socket 1, and insert the
memory module into the socket 2.
Installing a DIMM
✎A memory module can be installed in only one way. Match the notch
on the module with the tab on the memory socket.
6. Push the module down into the socket, ensuring that the module
is fully inserted and properly seated. Make sure the latches are in
the closed position 3.
7. Replace the computer access panel and reconnect the power
cable.
The computer should automatically recognize the additional memory
the next time you turn on the computer.

1-10 www.hp.com Hardware Reference Guide
Hardware Upgrades
Installing an Expansion Card
The computer has two PCI expansion slots that can accommodate
expansion cards up to 17.46 cm (6.875 inches) in length, one PCI
Express x1 expansion slot, and one PCI Express x16 expansion slot.
1. Turn off the computer properly through the operating system and
turn off any external devices.
2. Disconnect the power cord from the power outlet and the
computer, and disconnect any external devices.
3. Remove the access panel and lay the computer on its side with the
opening to internal parts facing up.
4. On the rear panel of the computer, remove the screw that secures
the slot cover lock in place 1and slide the slot cover lock up and
away from the slots to remove it from the computer 2.
Releasing the Slot Cover Lock

Hardware Reference Guide www.hp.com 1-11
Hardware Upgrades
5. If you are installing an expansion card for the first time, you must
use a flatblade screwdriver to pry out the metal shield on the rear
panel that covers the expansion slot. Be sure to remove the
appropriate shield for the expansion card you are installing.
6. Hold the expansion card just above the expansion slot on the
system board then move the card toward the rear of the chassis so
that the bottom of the bracket on the card slides into the small slot
on the chassis. Gently press the card straight down into the
expansion slot on the system board.
Adding an Expansion Card
Removable Shield Expansion Card Type
Top shield PCI Express x16
Second shield PCI Express x1
Third shield PCI
Bottom shield PCI

1-12 www.hp.com Hardware Reference Guide
Hardware Upgrades
✎When installing an expansion card, press firmly on the card so that
the whole connector seats properly in the expansion card slot.
7. While holding the expansion card bracket against the chassis,
slide the slot cover lock down toward the expansion card bracket
to secure it in place and replace the screw that secures the slot
cover lock.
8. Connect external cables to the installed card, if needed. Connect
internal cables to the system board, if needed.
9. Replace the computer access panel and reconnect the power
cable.
✎To remove an expansion card, reverse the installation procedure.
ÄCAUTION: After removing an expansion card, you must replace it with
a new card or expansion slot cover for proper cooling of internal
components during operation.
Replacing or Upgrading a Drive
The computer supports up to five drives that may be installed in
various configurations.
This section describes the procedure for replacing or upgrading the
storage drives. A Torx T-15 screwdriver is needed to remove and
install the guide screws and retainer screws on a drive.
ÄCAUTION: Make sure you back up your personal files on the hard drive
to an external storage device, such as a CD, before removing the hard
drive. Failure to do so will result in data loss. After replacing the primary
hard drive, you will need to run the Restore Plus! CD to load the HP
factory-installed files.

Hardware Reference Guide www.hp.com 1-13
Hardware Upgrades
Locating Drive Positions
✎The drive configuration shown below may be different than your
computer model.
Drive Positions
1External 5.25" full-height optical drive bay
2External 5.25" full-height option drive bay
3External 3.5" option drive bay (media card reader shown)*
4Internal 3.5" one-third height bay for optional secondary
hard drive
5Internal 3.5" one-third height bay for primary hard drive
*The external 3.5" option drive bay accommodates a diskette
drive or a media card reader.

1-14 www.hp.com Hardware Reference Guide
Hardware Upgrades
Removing a 5.25" Optical Drive
1. Turn off the computer properly through the operating system and
turn off any external devices.
2. Disconnect the power cord from the power outlet and the
computer, and disconnect any external devices.
3. Remove the access panel and front bezel. Refer to “Removing the
Access Panel and Front Bezel.”
4. Disconnect the power and data cables from the back of the drive.
5. Remove the two retainer screws that secure the drive to the bay 1
then slide the drive forward and out of the bay 2.
Removing a 5.25” External Drive
To install a drive, reverse the removal procedure. Be sure to install a
guide screw on the front right side of a new drive. The guide screw
helps secure the drive in place.

Hardware Reference Guide www.hp.com 1-15
Hardware Upgrades
✎If you are installing a drive in the bottom 5.25" drive bay, remove the
metal shield that covers the bay by pressing inward on the silver tab
on the left side of the chassis then pulling the shield out from the front
of the chassis.
✎There are a total of eight extra guide/retainer screws on the front of
the chassis behind the bezel. Four have 6-32 standard threads and four
have M3 metric threads. Standard screws are used for hard drives and
have a silver finish. Metric screws are used for all other drives and
have a black finish. Be sure to install the appropriate guide screws
into the drive.

1-16 www.hp.com Hardware Reference Guide
Hardware Upgrades
Removing a 3.5" Media Card Reader or Diskette Drive
The 3.5" external drive bay may be populated with a diskette drive or
a media card reader. The removal procedure is the same for both
devices.
1. Turn off the computer properly through the operating system and
turn off any external devices.
2. Disconnect the power cord from the power outlet and the
computer, and disconnect any external devices.
3. Remove the access panel and front bezel. Refer to “Removing the
Access Panel and Front Bezel.”
4. If the device is a media card reader, disconnect the internal USB
cable from the system board. If the device is a diskette drive,
disconnect the power and data cables from the back of the drive.
5. Remove the retainer screws that secure the drive to the bay 1
then slide the drive forward and out of the bay 2.
Removing a 3.5” Device (Media Card Reader Shown)
