HP Elite 7100 User instructions

Microtower
1. 300 watt non-PFC power supply 6. Front I/O: (3) USB 2.0 ports, (1) MIC - (1) audio out
(Headphone), (1) 1394
2. (2) external 5.25” drive bays for optional optical drives 7. (2) internal 3.5” hard drive drive bays
3. (1) external 3.5” drive bay for optional media reader 8. USB Scroll Mouse
4. (3) PCIe x1 slots, (1) PCIe x16 2.0 slot 9. HP Standard USB Keyboard
5. Rear I/O: (6) USB 2.0 ports, (1) RJ-45, (1) 1394, (1) Optical Out,
(1) audio in – (1) audio out – (1) MIC – (1) Surround center, – (1)
Surround LS – (1) Surround RS, (1) VGA port, (1) DVI-D port
10. Monitor (sold separately)
At A Glance
Intel® Core™ i7, Core i5, Core i3, and Pentium processors
Intel H57 PCH chipset
Intel® HD Graphics integrated with Intel Pentium processor, Intel Core i3 processors,
and select Intel Core i5 processors
NVIDIA and ATI graphics cards also available
PCI Express I/O bus
Serial ATA controller
Integrated Realtek RTL 8111DL Gigabit Ethernet Controller
Integrated 1394 port
Choice of hard drives and optical drives
Can be configured with multiple hard drives in a RAID array
DDR3 SDRAM system memory
QuickSpecs
HP Elite 7100 Microtower PC
Overview
DA - 13571 North America — Version 3 — June 8, 2010 Page 1

Processor and Speed
One of the following
Intel Core i7-870 Processor * (2.93 GHz, 1 MB L2 and 8 MB L3 shared cache)
Up to 3.6 GHz with Intel Turbo Boost Technology **
Intel Core i7-860 Processor * (2.8 GHz, 1 MB L2 and 8 MB L3 shared cache)
Up to 3.46 GHz with Intel Turbo Boost Technology **
Intel Core i5-750 Processor * (2.66 GHz, 1 MB L2 and 8 MB L3 shared cache)
Up to 3.2 GHz with Intel Turbo Boost Technology **
Intel Core i5-670 Processor (3.46 GHz), 512 KB L2 and 4 MB L3 shared cache)
Up to 3.73 GHz with Intel Turbo Boost Technology **
Intel Core i5-660 Processor (3.33 GHz), 512 KB L2 and 4 MB L3 shared cache)
Up to 3.60 GHz with Intel Turbo Boost Technology **
Intel Core i5-650 Processor (3.2 GHz), 512 KB L2 and 4 MB L3 shared cache)
Up to 3.46 GHz with Intel Turbo Boost Technology **
Intel Core i3-540 Processor (3.06 GHz, 512 KB L2 and 4 MB L3 shared cache)
Intel Core i3-530 Processor (2.93 GHz, 512 KB L2 and 4 MB L3 shared cache)
Intel Pentium G6950 Processor (2.8GHz, 3MB L2 cache)
* Requires one of the discrete graphics cards listed in Graphics section below.
** Under some configurations and workloads, Intel Turbo Boost technology enables higher
performance through the availability of increased core frequency.
NOTE: Intel processor numbers are not a measure of performance. Processor numbers differentiate
features within each processor family, not across different processor families.
Operating Systems and
Application Software
(availability varies by
region)
Genuine Windows 7 Professional Edition 32 *
Genuine Windows 7 Professional Edition 64 *
Genuine Windows XP Professional available through downgrade rights from Windows 7
Professional *+
Genuine Windows 7 Home Premium Edition 32 *
Genuine Windows 7 Home Basic Edition 32 *
Genuine Windows Vista Business 32 **
Novell SUSE Linux Enterprise Desktop 11 †
FreeDOS
Certified :
Red Hat Enterprise Linux †
Novell SUSE Linux Enterprise Desktop †
NOTE: Windows XP Mode, available as a separate download for Windows 7 Professional, works with
virtualization software such as Windows Virtual PC to run older Windows XP business software on the
Windows 7 desktop.
* System may require upgraded and/or separately purchased hardware and/or a DVD drive to install the
Windows 7 software and take full advantage of Windows 7 functionality. See:
http://www.microsoft.com/windows/windows-7/ for details.
** Certain Windows Vista product features require advanced or additional hardware. See:
http://www.microsoft.com/windowsvista/getready/hardwarereqs.mspx and
http://www.microsoft.com/windowsvista/getready/capable.mspx for details. Windows Vista Upgrade
QuickSpecs
HP Elite 7100 Microtower PC
Standard Features and Configurable Components (availability may vary by country)
DA - 13571 North America — Version 3 — June 8, 2010 Page 2

Advisor can help you determine which features of Windows Vista will run on your computer. To download
the tool, visit: http://www.windowsvista.com/upgradeadvisor .
+ Windows XP Professional is preinstalled on this system and includes end user rights and media for
Windows 7 Professional. You may only use one version at a time. You must back up all data (files, photos,
etc.) before uninstalling and installing operating systems to avoid loss of your data.
† The following features are not supported by Linux:
Integrated 1394 port
Intel Gigabit CT Desktop NIC
LSI PCIe x1 56K International SoftModem
HP Wireless 802.11 b/g/n PCIe x1 Card
NVIDIA GeForce G210 HDMI PCIe x16 graphics card
ATI Radeon HD 4550 (512MB DH) PCIe x16 graphics card
ATI Radeon HD 4650 (1GB DH ) PCIe x16 graphics card
Belkin USB to serial adapter
22-in-1 Media Reader
Microsoft Office 2007 Basic
Microsoft Office 2007 Small Business
Microsoft Office 2007 Professional
HP Backup and Recovery Manager
Intel Matrix Storage Manager
Mozilla Firefox for HP Virtual Solutions
Roxio Easy Media Creator 10 *
Intervideo WinDVD 8 *
McAfee Total Protection Anti-Virus **
PDF Complete
* Supporting software available with certain optical drive configurations
** 60 day trial period for McAfee Total Protection for Small Business software. Internet access required to
receive updates. First update included. Subscription required for updates thereafter.
Internal Storage
(3.5-inch SATA)
Hard Drives
160 GB Hard Drive
8MB cache, 7200 RPM, 3.0 GB/s, NCQ, Smart IV
250 GB Hard Drive
8MB cache, 7200 RPM, 3.0 GB/s, NCQ, Smart IV
320 GB Hard Drive
8MB cache, 7200 RPM, 3.0 GB/s, NCQ, Smart IV
500 GB Hard Drive
16MB cache, 7200 RPM, 3.0 GB/s, NCQ, Smart IV
1 TB Hard Drive
16MB cache, 7200 RPM, 3.0 GB/s, NCQ, Smart IV
Solid State Drive
64-GB Solid State Drive
QuickSpecs
HP Elite 7100 Microtower PC
Standard Features and Configurable Components (availability may vary by country)
DA - 13571 North America — Version 3 — June 8, 2010 Page 3

System Memory 1-GB DDR3 Synch DRAM PC3-10600 (1333-MHz) Non-ECC (1 x 1GB)
2-GB DDR3 Synch DRAM PC3-10600 (1333-MHz) Non-ECC (2 x 1GB)
2-GB DDR3 Synch DRAM PC3-10600 (1333-MHz) Non-ECC (1 x 2GB)
3-GB DDR3 Synch DRAM PC3-10600 (1333-MHz) Non-ECC (3 x 1GB)
4-GB DDR3 Synch DRAM PC3-10600 (1333-MHz) Non-ECC (4 x 1GB)
4-GB DDR3 Synch DRAM PC3-10600 (1333-MHz) Non-ECC (1 x 4GB)
4-GB DDR3 Synch DRAM PC3-10600 (1333-MHz) Non-ECC (2 x 2GB)
6-GB DDR3 Synch DRAM PC3-10600 (1333-MHz) Non-ECC (3 x 2GB)
8-GB DDR3 Synch DRAM PC3-10600 (1333-MHz) Non-ECC (4 x 2GB)
8-GB DDR3 Synch DRAM PC3-10600 (1333-MHz) Non-ECC (2 x 4GB)
NOTE: For systems configured with more than 3 GB of memory and a 32-bit operating system, all memory
may not be available due to system resource requirements. Addressing memory above 4 GB requires a 64-
bit operating system.
Removable Storage
One or more of the
following (see Storage
section below)
Media Reader
HP 22-in-1 Media Reader and additional USB 2.0 port
Optical Drives (Serial ATA)
SATA DVD-ROM Drive
SATA SuperMulti LightScribe DVD Writer Drive
HP SATA Blu-ray Writer
Input Devices Keyboard – One of the following
HP USB Standard Keyboard
HP USB Mini Keyboard
HP Washable Keyboard
HP USB Smartcard Keyboard
HP 2.4 GHz Wireless Keyboard and Mouse
Mouse – One of the following
USB 2-Button Optical Scroll Mouse
USB 2-Button Laser Mouse
Audio/Visual Realtek ALC888S High Definition audio codec
3D audio compliant with AC'97 Rev. 2.3 and HD Audio compatible
HP Thin USB Powered Speakers
HP USB 2.0MP Business Webcam
QuickSpecs
HP Elite 7100 Microtower PC
Standard Features and Configurable Components (availability may vary by country)
DA - 13571 North America — Version 3 — June 8, 2010 Page 4

Communication Integrated Realtek RTL8111DL Gigabit Ethernet Controller
Intel Gigabit CT Desktop NIC
LSI PCIe x1 56K International SoftModem
HP Wireless 802.11 b/g/n PCIe x1 Card (full height)
Graphics Integrated graphics with Intel Pentium processor, Intel Core i3 processors,
and select Intel Core i5 processors:
Intel® Graphics Media Accelerator HD
Available discrete graphics cards:
NVIDIA GeForce G210 HDMI PCIe x16 Graphics Card
ATI Radeon HD 4550 Dual Head PCIe x16 Graphics Card
ATI Radeon HD 4650 1GB PCIe x16 Graphics Card
ATI Radeon HD 5450 1GB PCIe x16 Graphics Card
Miscellaneous Belkin USB to serial adapter
QuickSpecs
HP Elite 7100 Microtower PC
Standard Features and Configurable Components (availability may vary by country)
DA - 13571 North America — Version 3 — June 8, 2010 Page 5

Base Unit MT: Micro ATX Microtower chassis, including power supply and front bezel; five (5) drive bays and
four expansion slots
Active type heatsink
92 x 92 x 25 mm chassis fan for Microtower chassis
System board with Intel H57 PCH chipset, RTL8111DL Gigabit Ethernet controller and Realtek audio,
(3) PCI Express x1 slots, (1) PCI Express x16 slot, (4) DDR3 DIMM memory slots, (4) Serial ATA data
connectors, (10) USB Ports (see USB support below), 1394 Firewire, Optical Out, VGA port, DVI-D
port
Power cord
Slots PCI PCI Express x1 slots
(3) full-height (4.34”), length (6.6”), Max power per slot 10W
PCI Express x16 2.0 slot (for graphic cards)
(1) full-height (4.34”), length (9.5”), Max power per slot 75W
Memory Expansion Four (4) DDR3 SDRAM DIMM slots (16 GB maximum memory support)
NOTE: For systems configured with more than 3 GB of memory and a 32-bit operating system, all memory
may not be available due to system resource requirements. Addressing memory above 4 GB requires a 64-
bit operating system.
Bays Internal Two (2) 3.5-inch
External Two (2) 5.25-inch; One (1) 3.5-inch
USB Support EHCI high-speed USB 2.0 controller
Three (3) front ports; six (6) rear ports, five (5) internal ports on system board
Other Ports Front :
(1) audio out; (1) microphone in, (1) 1394 port
Rear :
(1) Digital Out
(1) audio in, (1) audio out; (1) microphone in, (1) surround rear, (1) surround side,
(1) center/sub
(1) RJ-45 network port
(1) 1394 port
(6) USB ports
(1) VGA port
(1) DVI-D port
QuickSpecs
HP Elite 7100 Microtower PC
System Details
DA - 13571 North America — Version 3 — June 8, 2010 Page 6

Weight & Dimensions Chassis Dimensions
(H x W x D)
15.14 x 7.27 x 16.36 in
385 x 185 x 416 mm
Packaged Dimensions
(L x W x H)
19.13 x 21.875 x 10.13 in
490 x 556 x 257 mm
System Weight 22.4 lb (10.2 kg)
Shipping Weight 30.8 lb (14.0 kg)
Technology and Features Memory Type PC3-10600 DDR3 (1333 MHz) non-ECC
Up to 16 GB system memory standard
NOTE: For systems configured with more than 3 GB of memory and a 32-bit operating system, all memory
may not be available due to system resource requirements. Addressing memory above 4 GB requires a 64-
bit operating system.
Hard Drive Interfaces
Supported
Serial ATA
RAID Redundant Array of Independent Drives
RAID 0,1 are the RAID configurations that HP Elite 7100 Microtower PC products offer as factory
configurations. The pre-configured systems:
Are complete RAID systems and have both drives installed.
Have the necessary Option ROM configuration.
Are pre-loaded and pre-installed with all required Intel software.
Include a preinstalled operating system that is in mirrored mode out of the box.
SMART Technology *
(Self-Monitoring, Analysis
and Reporting Technology)
Allows hard drives to monitor their own health and to raise flags if imminent failures were predicted
Predicts failures before they occur. Tracks fault prediction and failure indication parameters such as
re-allocated sector count, spin retry count, calibration retry count
By avoiding actual hard drive failures, SMART hard drives act as "insurance" against unplanned user
downtime and potential data loss from hard drive failure
IOEDC: I/O Error Detection Circuitry
Detects errors in Read/Write buffers on HDD cache RAM
Interface in F10 setup provides confirmation of SMART support.
* This feature is inoperable when a RAID configuration is enabled.
QuickSpecs
HP Elite 7100 Microtower PC
System Details
DA - 13571 North America — Version 3 — June 8, 2010 Page 7

Chassis Front Panel Power button
Power On LED
HDD Activity LED
Cooling Solutions
Supported
Power Supply Fan (variable speed)
Active heatsink (variable speed)
Chassis fan (variable speed) (MT only)
Slots Supported (3) PCI Express x1 slots, (1) PCI Express x16 slot
Front I/O Three (3) USB 2.0 ports, 1394, Headphone, Mic
Rear I/O Standard Micro ATX I/O connectors, including six (6) USB 2.0 ports
Drive Bays (MT) Two (2) 5.25-inch (13.335 cm) half height external
One (1) 3.5-inch (8.89 cm) half height external
Two (2) 3.5-inch (8.89 cm) half height internal
Internal Speaker Not supported
Security Padlock loop
Support for chassis padlocks and cable lock devices
Kensington Lock Support
Power Supply MT: 300-watt ATX Power Supply – non-PFC with a 115v/230v line switch
(varies by country/region)
Unit Environment and
Operating Conditions
General Unit Operating Guidelines
Keep the computer away from excessive moisture, direct moisture and the extremes of heat and
cold, to ensure that unit is operated within the specified operating range.
Leave a 4 in (10.2 cm) clearance on all vented sides of the computer to permit the required airflow.
Never restrict airflow into the computer by blocking any vents or air intakes.
Do not stack computers on top of each other or place computers so near each other that they are
subject to each other's re-circulated or preheated air.
Occasionally clean the air vents on the front, back, and any other vented side of the computer. Lint,
dust and other foreign matter can block the vents and limit the airflow.
If the computer is to be operated within a separate enclosure, intake and exhaust ventilation must
be provided on the enclosure, and the same operating guidelines listed above will still apply.
Temperature Range Operating 41° to 95° F (5° to 35° C)
Non-operating –22° to 140° F (–30° to 60° C)
Relative Humidity Operating 15% to 80% (non-condensing at ambient)
Non-operating 90% (non-condensing at ambient)
Maximum Altitude
(unpressurized)
Operating 7500 ft (2286 m)
Non-operating 15,000 ft (4572 m)
NOTE: Operating temperature is de-rated 1.0 deg C per 1000 ft (300 m) to 7500 ft (2286 m) for MT and
10000 ft (3000m) for SFF above sea level, no direct sustained sunlight. Maximum rate of change is 7.5 deg
C/Hr for MT and 10 deg C/Hr for SFF. The upper limit may be limited by the type and number of options
installed.
System Board Processor Socket LGA1156 industry standard Micro ATX form factor
QuickSpecs
HP Elite 7100 Microtower PC
System Details
DA - 13571 North America — Version 3 — June 8, 2010 Page 8

Intel Core i3, Core i5, or Core i7 processor
PWM Intersil ISL6338 – 3 phase
Chipset Intel H57 PCH Chipset
Super I/O N/A
Memory Bus Frequency 1333 MHz
Memory DDR3 SDRAM
4 x DIMM slots
Clock Generator N/A
Audio Realtek ALC888S HD Audio compatible codec with two channel audio 3D audio
compliant with AC'97 rev. 2.3
LOM Realtek RTL8111DL Gigabit Ethernet
Storage Four Serial ATA interfaces
Expansion Slots 3 x PCI Express x1 slots
1 x PCI Express x16 slot
BIOS SPI FLASH ROM
Industrial Standard PCIe compliant
USB 2.0
Rear Side I/O Ports 6 x USB 2.0 ports
1 x RJ-45 10/100 port
1 x 1394 port
1 x Digital Out
6 x audio ports
1 VGA port
1 DVI-D port
On Board I/O Interfaces 1 x ATX power connector
1 x +12V power connector
1 x Front panel connector, Switch, LED (ON/Flash/OFF)
2 x Fan headers for CPU, chassis, with voltage/fan speed control
2 x header (1 -2x5, 1-1x5) to support 3 USB 2.0 ports at front side
1 x header (1 - 2x5) to support USB Card Media Reader
3 x headers (1 -1x5) to support additional USB devices
1 x header 2x5 to support 2 front (Headphone/Mic) audio ports
1 x header 2x5 to support 1 front IEEE 1394
Board Size Micro-ATX, PCB Size: 9.6 x 9.6 in (24.38 x 24.38 cm)
4-layer PCB with green color
Additional Features Bootable without keyboard, mouse or monitor
Keyboard/mouse/USB wake up
Support S3, S4 and S5
ACPI status
Hardware monitor capability
CPU fan speed control
QuickSpecs
HP Elite 7100 Microtower PC
System Details
DA - 13571 North America — Version 3 — June 8, 2010 Page 9

Network Interface Integrated Realtek RTL8111DL Gigabit NIC
Intel Gigabit CT Desktop NIC (optional)
Wireless Wireless 802.11b/g/n PCIe Card (full height bracket)
Power Supply ATX Power Supply – Passive PFC
ATX Power Supply – High Voltage (HV)
ATX Power Supply – High Efficiency (85%)
Passive Power Factor Correction (PFC/NPFC) - with line switch set to 230V – No PFC in 115V line
switch position
90 to 140VAC, or 180 to 264VAC operating voltage range
100 to 127VAC, or 200 to 240VAC rated voltage range
50-60 Hz rated line frequency
47-63 Hz operating line frequency range
300 watt maximum rated power
80-mm power supply fan – variable speed for optimum acoustics
Power Conservation
'Energy Saver'
APM 1.2 support
Screen blanking
Hard drive 'Idle' mode
System Idle mode
~2 watt power consumption in ES mode – suspend to RAM (S3) (instantly available PC)
Processor/Cache memory power-down (S3)
S5 Max Power Savings (<1W) for Eup Lot 6 compliance
System Environmental
Specs
Values are subject to change without notification and are for reference only.
Performance of system, options, and ancillary equipment will vary depending on the system
configuration.
Levels presented do not account for non-HP/Compaq installed hardware.
Ambient Air Temperature Operating MT: Operating 41° to 95°F (5 to 35°C) (Test 0 to
104°F (40°C));
SFF: 50° to 95°F (10° to 35°C) at sea level with an
altitude de-rating of 1.0°C per every 1000 ft (300
m) above sea level to a maximum of 10,000 ft
(3000 m), no direct sustained sunlight. Maximum
rate of change is 77°F/Hr (25°C/Hr). The upper
limit may be limited by the type and number of
options installed.
Storage MT: Storage: 90% RH @ 60°C for 12 hours (Non-
condensing)
SFF: -22° to 140°F (-30° to 60°C) – Maximum rate
of change: 410°F/Hr (210°C/Hr).
QuickSpecs
HP Elite 7100 Microtower PC
System Details
DA - 13571 North America — Version 3 — June 8, 2010 Page 10

Humidity Operating 15% to 80% relative humidity (Rh), 35°C non-
condensing.
Storage 90% relative humidity (Rh), 60°C for
12 hours, non-condensing).
Altitude Operating 0 to 7,500 feet (0 to 2286 meters) – This value
may be limited by the type and number of options
installed.
Non-Operating 0 to 15,000 feet (0 to 4572 meters)
Shock Listed are the levels of shock the product can withstand with No damage
being incurred. The values represent peak input acceleration during an 2~3 ms
half-sine shock pulse, 11 ms trapezoidal shock pulse.
Non-Operating 35G's (Half-sine Shock)
35G's (Trapezoidal Shock)
Vibration Listed are the levels of vibration the product can withstand with No damage
being incurred. The values represent a flat random vibration input
acceleration profile across the given frequency range.
Operating MT: Random Operating: ~0.21Grms (5-500 Hz)
Swept Sine: 0.5g (5-500Hz) 5 min. dwell at 4
resonance's 5Hz to 300Hz, (0.25G's nominal).
SFF: Random vibration at [email protected]²/Hz,
[email protected]²/Hz, [email protected]²/Hz,
[email protected]²/Hz
5Hz to 300Hz, (0.25G's nominal).
Non-Operating MT: ~2.09Grms (5-500Hz), Non-Operational
SFF: Random vibration at 0.008G²/Hz,
10Hz to 500Hz, (2 Grms nominal).
Service and Support On-site Warranty
Note 1
: One-year (1-1-1) limited warranty delivers one year of on-site, next business-
day
Note 2
service for parts and labor and includes free telephone support
Note 3
24 x 7. Global coverage
Note
2
ensures that any product purchased in one country and transferred to another non-restricted country will
remain fully covered under the original warranty and service offering. One-year onsite and labor are not
available in all countries.
NOTE 1: Terms and conditions may vary by country. Certain restrictions and exclusions apply. Other
warranty variations may be offered in your region.
NOTE 2: On-site service may be provided pursuant to a service contract between HP and an authorized HP
third-party provider, and is not available in certain countries. Global service response times are based on
commercially reasonable best effort and may vary by country.
NOTE 3: Technical telephone support applies only to HP-configured Compaq and third-party HP-qualified
hardware and software. Toll-free calling and 24 x 7 support may not be available in some countries.
QuickSpecs
HP Elite 7100 Microtower PC
System Details
DA - 13571 North America — Version 3 — June 8, 2010 Page 11

Communications NICs
Intel Gigabit CT Desktop NIC PCIe x1 FH969AA
Wireless LAN
HP Wireless 802.11/b/g/n PCIe x1 FH971AA
Modems
LSI PCIe x1 56K International SoftModem FH970AA
Hard Disk Drives HP 500-GB SATA 3.0-Gb/s Hard Drive KW347AA
HP 250-GB SATA 3.0-Gb/s Hard Drive PY278AA
HP 160-GB SATA 3.0-Gb/s Hard Drive PY277AA
HP 1-TB SATA 3.0-Gb/s Hard Drive TBD
External Storage Devices HP 250-GB Pocket Media Drive FE477AA
Removable Storage
Devices
22-in-1 Media Reader FX273AA
Input Devices HP USB Standard Keyboard DT528A
HP Washable Keyboard VF097AA
HP Mini Keyboard AS601AA
HP 2.4 GHz Wireless Keyboard and Mouse NB896AA#xxx
HP USB 2-Button Optical Scroll Mouse DC172B
HP USB 2-Button Laser Mouse GW405AA
Memory HP 1-GB PC3-10600 (DDR3 1333-MHz) DIMM AT023AA
HP 2-GB PC3-10600 (DDR3 1333-MHz) DIMM AT024AA
HP 4-GB PC3-10600 (DDR3 1333-MHz) DIMM VH638AA
Audio/Visual HP Thin USB Powered Speakers KK912AA
HP USB 2.0M Business Webcam NX252AA
Graphics ATI Radeon HD 4650 PCIe x16 Graphics Card AR956AA
NVIDIA GeForce G210 HDMI SH PCIe x16 Graphics Card VN565AA
QuickSpecs
HP Elite 7100 Microtower PC
After-Market Options (availability may vary by country)
DA - 13571 North America — Version 3 — June 8, 2010 Page 12

Optical Drives HP SATA DVD-ROM Drive AH047AA
HP SATA SuperMulti LightScribe DVD Writer Drive GF343AA
HP SATA Blu-ray Writer (black) AR482AA
Security HP Business PC Security Lock Kit PV606AA
Security Cable with Kensington Lock PC766A
HP USB Smartcard Keyboard ED707AA
Miscellaneous
Accessories
Belkin Serial to USB adapter EM449AA
QuickSpecs
HP Elite 7100 Microtower PC
After-Market Options (availability may vary by country)
DA - 13571 North America — Version 3 — June 8, 2010 Page 13

DDR3 SYNCH DRAM NON-ECC MEMORY
The Intel H57 chipset supports non-ECC DDR3 memory up to PC3-16000 (1333-MHz). Memory upgrades are accomplished by adding
single or multiple DIMMs of the same or varied sizes. This chart does not represent all possible memory configurations.
CAUTION: You must shut down the computer and disconnect the power cord before adding or removing memory modules. Regardless of
the power-on state, voltage is always supplied to the memory modules as long as the computer is plugged in to an active AC outlet.
Adding or removing memory modules while voltage is present may cause irreparable damage to the memory modules or system board.
HP recommends dual-channel symmetric configurations for maximum performance.
For best performance, add the same amount of total memory to each channel and do not mix speeds. For dual-channel symmetric
performance, the total amount of memory in each channel must be equal. If speeds are mixed, speed will default to the slowest DIMM.
STANDARD MEMORY
1-GB, 2-GB or 4GB DDR3 SYNCH DRAM
OPTIONAL MEMORY UPGRADES
Supports up to 16-GB of DDR3 SYNCH DRAM. Not all memory configurations possible are represented below.
NOTE: For systems configured with more than 3 GB of memory and a 32-bit operating system, all memory may not be available due to
system resource requirements. Addressing memory above 4 GB requires a 64-bit operating system.
DIMM Size Slot 1 (Black) Slot 2 (Blue) Slot 3 (Black) Slot 4 (Blue)
1-GB 1-GB
2-GB (dual-channel symmetric) 1-GB 1-GB
4-GB (dual-channel symmetric) 1-GB 1-GB 1-GB 1-GB
4-GB (dual-channel symmetric) 2-GB 2-GB
8-GB (dual-channel symmetric) 2-GB 2-GB 2-GB 2-GB
16-GB (dual-channel symmetric) 4-GB 4-GB 4-GB 4-GB
QuickSpecs
HP Elite 7100 Microtower PC
Memory
DA - 13571 North America — Version 3 — June 8, 2010 Page 14

HP Elite 7100 Microtower PC
Maximum Quantity Supported Position Supported Controller
Drive Support
Media Reader 1 3 Internal USB 2.0 port
CD-ROM Drives 2 1, 2 SATA
DVD-ROM Drives 2 1, 2 SATA
DVD+/-RW Drives 2 1, 2 SATA
3.5” Serial ATA Devices 2 4, 5 SATA
QuickSpecs
HP Elite 7100 Microtower PC
Storage
DA - 13571 North America — Version 3 — June 8, 2010 Page 15

Integrated Realtek
ALC888S Audio
Type Integrated 2-channel
HD Audio compatible
codec
Yes
Sampling Supports 48/96 KHz
Audio Jacks Mic-In
Line-In
Line-Out / Headphone Out
Center/Sub
Surround Side
Surround Rear
Power Support Digital: 3.3V
Analog: 5V
Other Meets performance requirements for audio on PC99/2001 systems
High-performance DACs with 97dB SNR(A-Weighting)
ADCs with 90dB NR(A-Weighting)
QuickSpecs
HP Elite 7100 Microtower PC
Technical Specifications - Audio
DA - 13571 North America — Version 3 — June 8, 2010 Page 16

Integrated Realtek
RTL8111DL Gigabit
Ethernet Controller
Connector RJ-45
Controller RTL 8111DL
Memory N/A
Data rates supported 10/100/1000 Mbps
Compliance IEEE 802.3 compliant, 802.3x flow control
Bus architecture PCI Express 1.1
Data transfer mode Bus-master DMA
Hardware certifications FCC, B, CE, TUV- cTUVus Mark Canada and United States, TUV- GS Mark for
European Union
Power requirement 588.5mW - 1000mbps
322.3mW - 100mbps
278.3mW - 10mbps
S3 - 195.8mW
Boot ROM support Yes
Network transfer rate 10BASE-T (half-duplex) 10 Mbps
10BASE-T (full-duplex) 20 Mbps
100BASE-TX (half-duplex) 100 Mbps
100BASE-TX (full-duplex) 200 Mbps
1000BASE-T (full-duplex) 2000 Mbps (actual rate limited by PCI Bus)
Environmental Operating temperature 32° to 120°F (0° to 48.89° C)
Operating humidity 85% at 120°F (48.89° C)
Dimensions 68Pin QFN (9mm x 9mm x 0.85mm)
Management capabilities WOL, PXE, (WOL supported from S1, S3, S4 states only. Not supported from
S5 state).
Intel Gigabit CT Desktop
NIC
Connector RJ-45
Controller Intel WG82574L Gigabit Ethernet Controller
Memory Integrated Dual 48K configurable transmit receive FIFO Buffers
Data rates supported 10/100/1000 Mbps
Compliance IEEE 802.1P, 802,1Q, 802.2, 802.3, 802.3AB and 802.3u compliant, 802.3x
flow control
Bus architecture PCI-E 1.0a
Data path width X1, 250 MB/s, Bi-directional interface
Data transfer mode Bus-master DMA
Hardware certifications FCC, B, CE, TUV- cTUVus Mark Canada and United States, TUV- GS Mark for
European Union
Power requirement Aux 3.3V, 3.0 Watts in 1000base-T and 2.0 Watts in 100Base-T
Boot ROM support Yes
QuickSpecs
HP Elite 7100 Microtower PC
Technical Specifications - Communications
DA - 13571 North America — Version 3 — June 8, 2010 Page 17

Network transfer rate 10BASE-T (half-duplex) 10 Mbps
10BASE-T (full-duplex) 20 Mbps
100BASE-TX (half-duplex) 100 Mbps
100BASE-TX (full-duplex) 200 Mbps
1000BASE-T (full-duplex) 2000 Mbps (actual rate limited by PCI Bus)
Environmental Operating temperature 32° to 131°F (0° to 55° C)
Operating humidity 85% at 131° F (55° C)
Dimensions 4.75 x 2.25 x 0.8 in (12.1 x 5.7 x 2.0 cm)
Management capabilities WOL, PXE, DMI, WFM 2.0
HP Wireless 802.11b/g/n
PCIe
Dimensions (L x H) 3.3 x 4.7 inches (8.5 x 12 cm)
Weight 0.08 pounds (40 g)
Controller Ralink RT2790
System interface PCIExpress x1
Network standard 802.11 b/g/n
Frequency band 2.400 - 2.497 GHz
Operating temperature 14° to 149°F, operating (-10° to 65°C, operating)
Storage temperature -40° to 176°F, non-operating (-40° to 80°C, non-operating)
Humidity 10-90% operating
5-95% non-operating
Operating voltage 3.3V +/- 9%
12V +/- 8%
Power consumption Platform/WLAN Mode Power Consumption
Maximum Power
Consumption
10 Watts
Transmit Only 4 Watts maximum averaged power over 1 second
Transmit Packet or Active
Scanning
1000 mA peak current for 100 microseconds or
longer
Receive Only Mode or Idle
without IEEE PSP mode
enabled
3 Watts maximum averaged over 1 second
Idle, with IEEE PSP mode
enabled
1.0 Watts maximum averaged over 1 second
Transmit Disabled (turned
off in software)
50 mW maximum, averaged over 1 second
Platform in S3 or S4
(power removed from Low
Profile PCI Express Card)
5 mW maximum, averaged over 1 second
Output power
(approximately)
802.11b modes 802.11g modes EWC modes
+19 dBm +/- 1.0 dB
maximum
+17 dBm +/- 1.0 dB
maximum
+17 dBm +/- 1.0 dB
maximum (total power
in all transmit chains)
QuickSpecs
HP Elite 7100 Microtower PC
Technical Specifications - Communications
DA - 13571 North America — Version 3 — June 8, 2010 Page 18

Receive sensitivity Mode Data rate Sensitivity
802.11b 1 Mbps -94 dBm
802.11b 11 Mbps -85 dBm
802.11g 6 Mbps -91 dBm
802.11g 18 Mbps -85 dBm
802.11g 48 Mbps -75 dBm
802.11g 54 Mbps -72 dBm
EWC (2.4 GHz) 6.5 Mbps -87 dBm
EWC (2.4 GHz) 54 Mbps -82 dBm
EWC (2.4 GHz) 81 Mbps -78 dBm
EWC (2.4 GHz) 162 Mbps -74 dBm
EWC (2.4 GHz) 270 Mbps -68 dBm
EWC (2.4 GHz) 300 Mbps -64 dBm
Data transfer rate Data Rate (MCS) Minimum Throughput
1 Mbps (802.11 b) 700 kbps
2 Mbps (802.11 b) 1.4 Mbps
5.5 Mbps (802.11 b) 3.5 Mbps
11 Mbps (802.11 b) 5.9 Mbps
12 Mbps (802.11 g) 6 Mbps
18 Mbps (802.11 g) 9 Mbps
24 Mbps (802.11 g) 12 Mbps
36 Mbps (802.11 g) 18 Mbps
48 Mbps (802.11 g) 21 Mbps
54 Mbps (802.11 g) 22.5 Mbps
6.5 Mbps (20 MHz EWC) 4.5 Mbps
13 Mbps (20 MHz EWC) 9 Mbps
19.5 Mbps (20 MHz EWC) 13.5 Mbps
26 Mbps (20 MHz EWC) 18 Mbps
39 Mbps (20 MHz EWC) 27 Mbps
52 Mbps (20 MHz EWC) 36 Mbps
58.5 Mbps (20 MHz EWC) 40 Mbps
65 Mbps (20 MHz EWC) 45 Mbps
78 Mbps (20 MHz EWC) 54 Mbps
104 Mbps (20 MHz EWC) 72 Mbps
117 Mbps (20 MHz EWC) 81 Mbps
130 Mbps (20 MHz EWC) 91 Mbps
13.5 Mbps (40 MHz EWC) 8 Mbps
27 Mbps (40 MHz EWC) 16 Mbps
40.5 Mbps (40 MHz EWC) 24 Mbps
54 Mbps (40 MHz EWC) 32 Mbps
81 Mbps (40 MHz EWC) 48 Mbps
QuickSpecs
HP Elite 7100 Microtower PC
Technical Specifications - Communications
DA - 13571 North America — Version 3 — June 8, 2010 Page 19

108 Mbps (40 MHz EWC) 64 Mbps
121.5 Mbps (40 MHz EWC) 72 Mbps
135 Mbps (40 MHz EWC) 81 Mbps
Security IEEE and WiFi compliant 64 / 128 bit WEP encryption
AES: CCM
802.1x authentication
WPA: 802.1x. WPA-PSK and TKIP
WPA2 certification
IEEE 802.11i
Cisco Certified Extensions, all versions through V5
Antenna HP part number 497792-001
Certifications Wi-Fi certified
Certifications for use by
country
United States, Canada, Peru, Taiwan
LSI PCIe x1 56K
International SoftModem
Data Transmission Technology speeds: 56,000 Kbps maximum downstream data, controllerless
NOTE: 56 Kbps technology refers to download speeds only and requires
compatible modems at server sites. Other conditions may limit modem speed.
FCC limitations allow a maximum of 53 Kbps during download transmissions.
Data Speeds (Upload only) 33,600/31,200/28,800/26,400/21,600/19,200/
16,800/14,400/12,000/9,600/7,200/4,800/2,400/1,200/300
Data Standards ITU-T V.90, ITU-T, ITU-T V.34, V.44, V.42, V.42bis21, V.32bis, Bell 212A, and
Bell 103
Fax Speeds 14,400/12,000/9,600/7,200/4,800/2,400/1,200/300 b/s
Fax Mode Capabilities ITU-T T.31 class 1 FAX, V. 17, V.29, V.27ter, and V.21 Channel 2
Error Correction and Data
Compression
V.44, 42bis, V.42 and MNP2-5
Power Management PCI Bus Power Management Interface Specification (PCI-PM) Revision 1.2,
Appendix A. D0, D3hot, and D3cold. Wake on Ring state when in D3cold. If the
power management event (PME) feature is enabled in D3cold, a modem can
wake the system via WAKE# (WAKEN) or beacon. Meets PCI Express 1.1
standard.
Upgradeability Driver upgradeable for future enhancements
Video ITU-T V.80 video ready interface
Other TIA/EIA 602 standard AT command set
Integrated DTE interface with speeds of up to 115.2 Kbps, parallel 16550a
UART-compatible interface
Optional ring wakeup signal
Operating Temperature 32° to 158° F (0° to 70° C)
Operating Humidity 20% to 90%, non-condensing
Power Requires a 3.3-V auxiliary power rail on PCI express bus
Uses only one PCI express load (i.e., one grant/request pair), one shared IRQ,
one electrical load
QuickSpecs
HP Elite 7100 Microtower PC
Technical Specifications - Communications
DA - 13571 North America — Version 3 — June 8, 2010 Page 20
