HP Kayak
PC Workstation
Service Handbook
PC Workstations and
Accessories
4th Edition
June 2000
Ka_sh_1.bk Page 1 Thursday, June 15, 2000 7:27 PM

Mini-Tower
PC Workstations
HP Kayak XU Series 04xx and HP Kayak XW Series
04xx 2-1
2
2
HP Kayak XU Series 04xx and
HP Kayak XW Series 04xx
Models and Accessories
Product
Number
Processors Std.
RAM
Hard
Drive
Video Controller Multi-
media
LAN
Kayak XU 6/xxx PC Workstation
HP Kayak XU 6/400 MHz - 512 KB (Series 0441) (CPL: 8/98 )
D6331N
and
D6331T
Single
Pentium®
II Xeon™
processor
with 512 KB
of L2 cache
memory
128 MB
SDRAM
ECC
4.5 GB
10k rpm
SCSI
ELSA GLoria
Synergy AGP,
8 MB on board,
not upgradable.
32XIDE
CD-ROM.
Audio chip
(AD1816) is
integrated
on the
system
board.
10BT/
100TX
HP Kayak XU 6/450 MHz - 512 KB (Series 0441) (CPL: 10/98 )
D6333N
and
D6333T
Single
Pentium
II Xeon
processor
with 512 KB
of L2 cache
memory
128 MB
SDRAM
ECC
4.5 GB
10k rpm
SCSI
ELSA GLoria
Synergy AGP,
8 MB on board,
not upgradable.
32XIDE
CD-ROM.
Audio chip
(AD1816) is
integrated
on the
system
board
10BT/
100TX
D6334N
and
D6334T
CD-RW
CD-ROM.
Audio chip
(AD1816) is
integrated
on the
system
board
Ka_sh_1.bk Page 1 Thursday, June 15, 2000 7:27 PM

HP Kayak XU Series 04xx and HP Kayak XW Series 04xx
2-2 HP Kayak XU Series 04xx and HP Kayak
XW Series 04xx
Mini-Tower
PC Workstations
2HP Kayak XU 6/450 MHz - 1 MB (Series 0441) (CPL: 03/99 )
D6335N
and
D6335T
Single
Pentium
II Xeon
processor
with 1 MB of
L2 cache
memory
128 MB
SDRAM
ECC
9.1 GB
10k rpm
SCSI
ELSA GLoria
Synergy AGP,
8 MB on board,
not upgradable.
CD-RW.
Audio chip
(AD1816) is
integrated
on the
system
board
10BT/
100TX
HP Kayak XU 6/450 MHz - 512 KB (Series 0403) (CPL: 12/98 )
D6336N
and
D6336T
Single
Pentium
II Xeon
processor
with 512 KB
of L2 cache
memory
128 MB
SDRAM
ECC
9.1 GB
10k rpm
SCSI
Matrox
Millennium G200
8 MB video
memory fitted.
Upgradable to
16 MB of memory.
32✕Max
IDE
CD-ROM.
Audio chip
(AD1816) is
integrated
on the
system
board
10BT/
100TX
HP Kayak XU 6/450 MHz - 512 KB (Series 0462) (CPL: 11/99 )
D6337N
and
D6337T
Single
Pentium
II Xeon
processor
with 512 KB
of L2 cache
memory
128 MB
SDRAM
ECC
9.1 GB
10k rpm
SCSI
AccelGalaxy AGP.
31 MB of video
memory. Not
upgradable.
CD-RW.
Audio chip
(AD1816) is
integrated
on the
system
board
10BT/
100TX
Product
Number
Processors Std.
RAM
Hard
Drive
Video Controller Multi-
media
LAN
Kayak XU 7/xxx PC Workstation
HP Kayak XU 7/500 MHz - 512 KB (Series 0403) (CPL: 03/99 )
D6340N
and
D6340T
Single
Pentium
III Xeon
processor
with 512 KB
of L2 cache
memory
128 MB
SDRAM
ECC
9.1 GB
10k rpm
SCSI
Matrox
Millennium G200
8 MB video
memory fitted.
Upgradable to
16 MB of memory.
32✕Max
IDE
CD-ROM.
Audio chip
(AD1816) is
integrated
on the
system
board
10BT/
100TX
Product
Number
Processors Std.
RAM
Hard
Drive
Video Controller Multi-
media
LAN
Ka_sh_1.bk Page 2 Thursday, June 15, 2000 7:27 PM

HP Kayak XU Series 04xx and HP Kayak XW Series 04xx
Mini-Tower
PC Workstations
HP Kayak XU Series 04xx and HP Kayak XW
Series 04xx 2-3
2
HP Kayak XU 7/500 MHz - 512 KB (Series 0441) (CPL: 03/99 )
D6341N
and
D6341T
Single
Pentium
III Xeon
processor
with 512 KB
of L2 cache
memory
128 MB
SDRAM
ECC
9.1 GB
10k rpm
SCSI
ELSA GLoria
Synergy AGP,
8 MB on board,
not upgradable
CD-RW.
Audio chip
(AD1816) is
integrated
on the
system
board
10BT/
100TX
HP Kayak XU 7/500 MHz - 512 KB (Series 0462) (CPL: 03/99 )
D6342N
and
D6342T
Single
Pentium
III Xeon
processor
with 512 KB
of L2 cache
memory
256 MB
SDRAM
ECC
9.1 GB
10k rpm
SCSI
AccelGalaxy AGP.
31 MB of video
memory. Not
upgradable
CD-RW.
Audio chip
(AD1816) is
integrated
on the
system
board
10BT/
100TX
HP Kayak XU 7/500 MHz - 512 KB (Series 0490) (CPL: 03/99 )
D6343N
and
D6343T
Single
Pentium
III Xeon
processor
with 512 KB
of L2 cache
memory
256 MB
SDRAM
ECC
9.1 GB
10k rpm
SCSI
Matrox
Productiva
G100-Quad
32X IDE
CD-ROM.
Audio chip
(AD1816) is
integrated
on the
system
board
10BT/
100TX
HP Kayak XU 7/550 MHz - 512 KB (Series 0441) (CPL: 05/99 )
D6345N
and
D6345T
Single
Pentium
III Xeon
processor
with 512 KB
of L2 cache
memory
128 MB
SDRAM
ECC
9.1 GB
10k rpm
SCSI
ELSA GLoria
Synergy AGP,
8 MB on board,
not upgradable
32X IDE
CD-ROM.
Audio chip
(AD1816) is
integrated
on the
system
board
10BT/
100TX
Product
Number
Processors Std.
RAM
Hard
Drive
Video Controller Multi-
media
LAN
Ka_sh_1.bk Page 3 Thursday, June 15, 2000 7:27 PM

HP Kayak XU Series 04xx and HP Kayak XW Series 04xx
2-4 HP Kayak XU Series 04xx and HP Kayak
XW Series 04xx
Mini-Tower
PC Workstations
2HP Kayak XU 7/550 MHz - 512 KB (Series 0462) (CPL: 05/99 )
D6346N
and
D6346T
Single
Pentium
III Xeon
processor
with 512 KB
of L2 cache
memory
256 MB
SDRAM
ECC
9.1 GB
10k rpm
SCSI
AccelGalaxy AGP.
31 MB of video
memory. Not
upgradable
CD-RW.
Audio chip
(AD1816) is
integrated
on the
system
board
10BT/
100TX
HP Kayak XU 7/550 MHz - 512 KB (Series 0490) (CPL: 05/99 )
D6347N
and
D6347T
Single
Pentium
III Xeon
processor
with 512 KB
of L2 cache
memory
256 MB
SDRAM
ECC
9.1 GB
10k rpm
SCSI
Matrox
Productiva
G100-Quad
32X IDE
CD-ROM.
Audio chip
(AD1816) is
integrated
on the
system
board
10BT/
100TX
HP Kayak XU 7/550 MHz - 512 KB (Series 0403) (CPL: 05/99 )
D6348N
and
D6348T
Single
Pentium
III Xeon
processor
with 512 KB
of L2 cache
memory
128 MB
SDRAM
ECC
9.1 GB
10k rpm
SCSI
Matrox
Millennium G200
8 MB video
memory fitted.
Upgradable to
16 MB of memory
32X IDE
CD-ROM.
Audio chip
(AD1816) is
integrated
on the
system
board
10BT/
100TX
Product
Number
Processors Std.
RAM
Hard
Drive
Video Controller Multi-
media
LAN
Ka_sh_1.bk Page 4 Thursday, June 15, 2000 7:27 PM

HP Kayak XU Series 04xx and HP Kayak XW Series 04xx
Mini-Tower
PC Workstations
HP Kayak XU Series 04xx and HP Kayak XW
Series 04xx 2-5
2
NOTE: All models are supplied with a 1.44 MB Flexible Disk
Drive, an integrated Ultra Wide 16-bit SCSI controller,
and an integrated IDE controller.
Kayak XW 6/xxx PC Workstation
HP Kayak XW 6/400 MHz - 512 KB (Series 0480) (CPL: 07/98 )
D6796N
and
D6796T
Single
Pentium II
Xeon
processor
with 512 KB
of L2 cache
memory
128 MB
SDRAM
ECC
4.5 GB,
10k rpm,
SCSI
HP VISUALIZE
fx6 hardware
accelerator
32X IDE
CD-ROM.
Audio chip
(AD1816) is
integrated
on the
system
board.
10BT/
100TX
HP Kayak XW 6/450 MHz - 512 KB (Series 0480) (CPL: 09/98 )
D6797N
and
D6797T
Single
Pentium II
Xeon
processor
with 512 KB
of L2 cache
memory
128 MB
SDRAM
ECC
9.1 GB,
10k rpm,
SCSI
HP VISUALIZE
fx6 hardware
accelerator
CD-RW.
Audio chip
(AD1816) is
integrated
on the
system
board.
10BT/
100TX
HP Kayak XW 6/450 MHz - 512 KB (Series 0475) (CPL: 01/99 )
D6799N
and
D6799T
Single
Pentium II
Xeon
processor
with 512 KB
of L2 cache
memory
128 MB
SDRAM
ECC
9.1 GB,
10k rpm,
SCSI
HP VISUALIZE
fx4+ hardware
accelerator
CD-RW.
Audio chip
(AD1816) is
integrated
on the
system
board.
10BT/
100TX
Product
Number
Processors Std.
RAM
Hard
Drive
Video Controller Multi-
media
LAN
Ka_sh_1.bk Page 5 Thursday, June 15, 2000 7:27 PM

HP Kayak XU Series 04xx and HP Kayak XW Series 04xx
2-6 HP Kayak XU Series 04xx and HP Kayak
XW Series 04xx
Mini-Tower
PC Workstations
2
Supported Accessories
Memory Upgrades
SDRAM 64 MB 72bit 100MHz main memory (unbuffered ECC) D6522A
SDRAM 128 MB 72bit 100MHz main memory (unbuffered ECC) D6523A
SDRAM 256 MB 72bit 100MHz main memory (unbuffered ECC) D6743A
SDRAM 512 MB 72bit 100MHz main memory (registered ECC)1
1. Not compatible with non-registered ECC DIMMs. Available from December 1998 (to be
confirmed).
D6742A
16 MB Hardware texture module for HP VISUALIZE fx4+ graphics board D5511B
32 MB Hardware texture module for HP VISUALIZE fx6 graphics board D6795A
Dual Processor Kits2
2. Dual Processor Kits include: processor, voltage regulator module and heatsink.
Intel Pentium II Xeon 400 MHz containing 512 KB internal L2 cache D6740A
Intel Pentium II Xeon 450 MHz containing 512 KB internal L2 cache D6741A
Intel Pentium II Xeon 450 MHz containing 1 MB internal L2 cache D6939A
Intel Pentium III Xeon 500 MHz containing 512 KB internal L2 cache D7513A
Intel Pentium III Xeon 550 MHz containing 512 KB internal L2 cache D7514A
Input Devices
HP mouse C3751B
Video Displays
All current HP Displays (see the HP Kayak Accessory Service Handbook)
Mass Storage—Hard disk drives
4.5 GB UW-SCSI hard disk 7.2k rpm (Low Profile) D5368B
4.5 GB UW-SCSI hard disk 10k rpm3(Low Profile)
3. 10k rpm hard disk drives can only be installed in the two upper internal disk drive shelves.
They must not be installed in the lower front-access shelves.
D5481B
9.1 GB UW-SCSI hard disk 10k rpm3 (Low Profile) D6520A
18.1 GB UW-SCSI hard disk 10k rpm3 (Low Profile) D7515A
9.1 GB UW-SCSI hard disk 7.2k rpm (Low Profile) D6938A
Removable Mass Storage
Flexible disk 3.5-inch 1.44 MB (1-inch high) D2035B
IDE 32✕CD-ROM drive D4384A
CD-RW drive C4400A
Miscellaneous
User’s Guide Manual D6339A
HP FastRAID2 Accessory Kit D6690A
Ka_sh_1.bk Page 6 Thursday, June 15, 2000 7:27 PM

HP Kayak XU Series 04xx and HP Kayak XW Series 04xx
Mini-Tower
PC Workstations
HP Kayak XU Series 04xx and HP Kayak XW
Series 04xx 2-7
2
System Board, BIOS and Memory
I/O Cards Fan
Multimedia Panel
16-bit SCSI
Processor 1 Slot
Processor 2 Slot
AGP Slot
Four PCI Slots RAIDport
Status Panel
Power Supply
Disk Drive Fan
Switches1
FDD
VRM 2
VRM 1
Memory Modules
Combo PCI/ISASlot
Processor Fan
External Battery
LCD Panel
CD In Audio
Aux In Audio
Wake On LAN
HP External Start
Mem 4
Mem 3
Mem 2
Mem 1
VRM 3
Internal speaker
IDE 1
Mic In
BOOT PROC [1] DUAL PROC [2]
PCI 1
PCI 2
PCI 3
PCI 4
PCI 5
1. There are two types of system board switch boxes.
OFF = UP ON = DOWN
or
OFF = OPEN ON = CLOSE
Ka_sh_1.bk Page 7 Thursday, June 15, 2000 7:27 PM

HP Kayak XU Series 04xx and HP Kayak XW Series 04xx
2-8 HP Kayak XU Series 04xx and HP Kayak
XW Series 04xx
Mini-Tower
PC Workstations
2
System Board Switches
Setup and BIOS History
For the latest BIOS, the flasher utility program, and the BIOS history refer to the
HP World Wide Web site. The BIOS is in the form HO11xxx.FUL, where xx is the
version number.
Installing a Dual Processor / Replacing a Processor
HP Kayak XU Series 04xx PC Workstations are supplied with either a
Pentium®II Xeon or Pentium III Xeon™processor.
Switch Function Default
1-5 — Processor frequency, see following table —
6OFF
1
1. Refer to the diagrams on the previous page to determine their ON/OFF position on the system
board switch box.
Retain configuration in EEPROM, normal position OFF
ON Clears EEPROM
7 OFF Enables User and Administrator passwords OFF
ON Clears User and Administrator passwords
8OFF Disables power on using keyboard ON
ON Enables keyboard power on
9OFF Reserved ON
ON
10 OFF Normal operation OFF
ON Recovery boot active (force BIOS flashing)2
2. Refer to “Recovery Boot Active Procedure” in Appendix B for the detailed recovery procedure.
Processor
Frequency1
1. PCI Bus Frequency is 33 MHz
ISA Bus Frequency is 8.25 MHz
Local Bus
(FSB)
Frequency
Switch
12345
400 MHz 100 MHz OFF OFF ON OFF OFF
450 MHz 100 MHz OFF OFF ON OFF ON
500 MHz 100 MHz OFF OFF ON ON OFF
550 MHz 100 MHz OFF OFF ON ON ON
600 MHz 100 MHz OFF ON OFF OFF OFF
http://www.hp.com/go/kayaksupport
Ka_sh_1.bk Page 8 Thursday, June 15, 2000 7:27 PM

HP Kayak XU Series 04xx and HP Kayak XW Series 04xx
Mini-Tower
PC Workstations
HP Kayak XU Series 04xx and HP Kayak XW
Series 04xx 2-9
2
A single Xeon processor must always be accompanied with two Voltage
Regulator Modules (VRM) inserted in the VRM sockets 1 and 2 (refer to the
diagram on page 7 for the VRM sockets position on the system board).
Single processor models can be upgraded to dual processor systems by
installing the second processor accessory in the vacant slot.
The second processor must be a Xeon processor of the same type, speed and
level-2 cache memory capacity as the first. It is installed by gently inserting the
processor into the vacant processor connector slot (labeled DUAL PROC [2])
until it clicks into place. Insert the VRM1that was supplied with the second
processor into the vacant third VRM socket. The following table explains how
to perform supported processor upgrades.
NOTE: After installation of a second processor, the operating
system must be reinstalled.
1. Each VRM is specific to the processor with which it was supplied, and should only be used
with that processor.
Dual Processor Upgrade
Upgrade
to
2X
400 MHz
(D6740A)
2X
450 MHz
(D6741A)
2X
450 MHz
(D6939A)
2X
500 MHz
(D7513A)
2X
550 MHz
(D7514A)
1X400 MHz
(D6740A)
Add 2nd
D6740A1.
1. Insert VRM that was supplied with the second processor into the VRM socket 3.
Remove
D6740A2.
Add two
D6741A.
2. Supplied processor must be removed.
Remove
D6740A 2.
Add two
D6741A.
Remove
D6740A2.
Add two
D7513A.
Remove
D6740A2.
Add two
D7514A.
1X450 MHz
(D6741A)
N/A Add 2nd
D6741A1.
Remove
D6741A 2.
Add two
D6939A.
Remove
D6741A2.
Add two
D7513A.
Remove
D6741A2.
Add two
D7514A.
1 x 450 MHz
(D6939A)
N/A N/A Add 2nd
D6939A1.
Remove
D6939A2.
Add two
D7513A.
Remove
D6939A2.
Add two
D7514A.
1X500 MHz
(D7513A)
N/A N/A N/A Add 2nd
D7513A1.
Remove
D7513A2.
Add two
D7514A.
1X550 MHz
(D7514A)
N/A N/A N/A N/A Add 2nd
D7514A1.
Ka_sh_1.bk Page 9 Thursday, June 15, 2000 7:27 PM
