HP PRO 3500 MICROTOWER BUSINESS PC
1. (1) external 5.25" drive bay
2. 300 W power supply
3. Rear I/O includes: (4) USB 2.0 ports, RJ-45 Ethernet Port, DVI-D and VGA video ports, audio in/out jacks (5.1 channel audio out)
4. Front I/O includes: (2) USB 2.0 ports, dedicated headphone port, microphone jack
5. (1) internal 3.5" hard drive bay
6. (3) PCIe x1 slots, (1) PCIe x16 slot, (1) MiniPCIe slot
7. USB Scroll Mouse
8. HP USB Standard Value Keyboard
9. HP Monitor (sold separately)
QuickSpecs
HP Pro 3500 Microtower Desktop PC
Overview
DA - 14349 North America — Version 10 — August 8, 2013 Page 1

At A Glance
Windows 8 Pro (64-bit), Windows 8 (64-bit), Windows® 7 Professional Edition (32- and 64-bit), FreeDOS, Freelnx
Choice of 3rd Gerneration Intel Core i5 and i7 or 2nd Generation Intel Core i3, Intel® Pentium, Intel Celeron® processors
Choice of integrated graphics: Intel HD Graphics, Intel HD 2000/2500/4000 Graphics Intel H61 Express Chipset
Up to 8 GB DDR3 1600 MHz SDRAM (running at1333 MHz) system memory available standard (depending on model)
Up to 1 TB 6.0 Gb/s SATA hard drive
SuperMulti DVD+/-RW Drive or DVD ROM Drive
Integrated Realtek RTL8171E Gigabit Ethernet Controller
(6) USB 2.0 ports, including (2) Front, (4) rear
DVI-D and VGA video ports support independent dual displays
HP Wireless NIC 802.11b/g/n MiniPCIe Card (1x1) (optional)
5.1 audio channels
Protected by HP Services. Terms and conditions vary by country. Certain restrictions and exclusions apply.
QuickSpecs
HP Pro 3500 Microtower Desktop PC
Overview
DA - 14349 North America — Version 10 — August 8, 2013 Page 2

OPERATING SYSTEMS
Preinstalled
Windows 8 Pro (64-bit)*
Windows 8 (64-bit)*
Windows® 7 Professional (32-bit or 64-bit) **
FreeDOS 2.0
FreeLnx
*Not all features are available in all editions of Windows 8. Systems may require upgraded and/or separately purchased
hardware, drivers and/or software http://www.microsoft.com/windows/windows-7/ for details. to take full advantage of
Windows 8 functionality. See http://www.microsoft.com .
**Not all features are available in all editions of Windows 7. This system may require upgraded and/or separately purchased
hardware to take full advantage of Windows 7 functionality. See http://www.microsoft.com/windows/windows-7/ for details.
*** Restrictions exist for this operating system. It is not available in some countries and is not compatible with some CPUs.
Please check for availability.
PROCESSOR
Intel® 3rd Generation Core™ i7 Processors
Intel® Core™ i7-3770 with Intel HD Graphics 4000 (3.40 GHz, 8 MB cache, 4 cores)
8 threads. Intel Stable Image Platform Program (SIPP)
Intel® 3rd Generation Core™ i5 Processors
Intel® Core™ i5-3470 with Intel HD Graphics 2500 (3.20 GHz, 6 MB cache, 4 cores)
4 threads. Intel Stable Image Platform Program (SIPP)
Intel® 2nd Generation Core™ i3 Processors
Intel® Core™ i3-2130 with Intel HD Graphics 2000 (3.40 GHz, 3 MB cache, 2 cores)
4 threads
Intel® Core™ i3-2120 with Intel HD Graphics 2000 (3.30 GHz, 3 MB cache, 2 cores)
4 threads
Intel® Pentium® Processors
Intel® Pentium® G870 with Intel HD Graphics (3.10 GHz, 3 MB cache, 2 cores)
2 threads
Intel® Pentium® G860 with Intel HD Graphics (3.00 GHz, 3 MB cache, 2 cores)
2 threads
Intel® Pentium® G840 with Intel HD Graphics (2.80 GHz, 3 MB cache, 2 cores)
2 threads
Intel® Celeron® Processors
Intel® Celeron® G540 with Intel HD Graphics (2.50 GHz, 2 MB cache, 2 cores)
2 threads
QuickSpecs
HP Pro 3500 Microtower Desktop PC
Standard Features and Configurable Modules
DA - 14349 North America — Version 10 — August 8, 2013 Page 3

CHIPSET
Intel® H61 Express
GRAPHICS
Integrated (depends on processor)
Intel HD Graphics: Basic, 2000,2500, 4000
STORAGE
SATA Hard Drive
250 GB, 7200 rpm, SATA 6.0 Gb/s, SMART IV, 3.5"
500 GB, 7200 rpm, SATA 6.0 Gb/s, SMART IV, 3.5"
1 TB, 7200 rpm, SATA 6.0 Gb/s, SMART IV, 3.5"
Optical Disc Drive
SATA DVD-ROM
SATA SuperMulti DVD+/-RW
QuickSpecs
HP Pro 3500 Microtower Desktop PC
Standard Features and Configurable Modules
DA - 14349 North America — Version 10 — August 8, 2013 Page 4

DRIVE SUPPORT
Maximum Quantity Supported Position Supported Controller
SuperMulti DVD Drive 1 1 SATA
3.5" SATA Hard Drive 1 2 SATA
MEMORY
Type
Non-ECC, DDR3 1600 MHz SDRAM UDIMM
NOTE: Memory will run at 1333 MHz due to processor/chipset limitations
Maximum
8 GB
# of Slots
2 DIMM
NOTE: For systems configured with more than 3 GB of memory and a 32-bit operating system, all memory may not be available
due to system resource requirements. Addressing memory above 4 GB requires a 64-bit operating system.
QuickSpecs
HP Pro 3500 Microtower Desktop PC
Standard Features and Configurable Modules
DA - 14349 North America — Version 10 — August 8, 2013 Page 5

NETWORKING/COMMUNICATIONS
Ethernet (RJ-45)
Realtek RTL8171E Gigabit Ethernet Controller (standard)
Wireless
802.11b/g/n Mini Card (optional)
AUDIO/MULTIMEDIA
Realtek ALC656
KEYBOARDS AND POINTING DEVICES
Keyboard
HP USB Value Keyboard
Mice
HP USB Optical Mouse
SECURITY
HP Business PC Security Lock Kit (optional)
HP Keyed Cable Lock Kit (optional)
SOFTWARE
Preinstalled (varies by country, list below with Windows 8, certain items not included with other operating systems)
(Buy Office)
Browser and Toolbars
Internet Explorer 10
Norton Toolbar
Security and Protection
HP Client Security
Productivity
Buy Office
Optical Disc Drive Playback and TV Tuners
QuickSpecs
HP Pro 3500 Microtower Desktop PC
Standard Features and Configurable Modules
DA - 14349 North America — Version 10 — August 8, 2013 Page 6

CyberLink PowerDVD
Avermedia TV app
Hauppauge TV app
Windows® Live™
Movie Maker
Writer
Photo Gallery
Windows 8 applications
Mail
Calendar
People
SkyDrive
Photos
Messaging
Photos and Videos
CyberLink YouCam
CyberLink Media Suite
CyberLink Power2Go
CyberLink Label Print
A/V Integration
HP Connected Remote
Audio Post Processing
Beats Audio™
Games
HP Games by WildTangent
Communication
Broadband connection utility
HP MyRoom
Utilities and Support
HP Online User Guide
HP Recovery Manager
HP Support Assistant
HP MyDisplay
HP ePrint (driver)
QuickSpecs
HP Pro 3500 Microtower Desktop PC
Standard Features and Configurable Modules
DA - 14349 North America — Version 10 — August 8, 2013 Page 7

POWER
Power Supply
300 W, active PFC
300 W, regular
PORTS
I/O Ports - Standard
6 - USB 2.0 (2 front, 4 rear)
1 - RJ-45 (rear)
1 - DVI-D (rear)
1 - VGA (rear)
1 - Headphone (front)
1 - Microphone (front)
1 - Audio-in (rear)
1 - Audio out (rear)
BAYS
1 -- 5.25" external
1 -- 3.5" internal
SLOTS
1 - PCIe x16
3 - PCIe x1
1 - miniPCIe
FORM FACTOR AVAILABLE
Form Factor
Microtower
QuickSpecs
HP Pro 3500 Microtower Desktop PC
Standard Features and Configurable Modules
DA - 14349 North America — Version 10 — August 8, 2013 Page 8

SERVICE AND SUPPORT
On-site Warranty
Note 1
: 1-1-1, limited warranty delivers on-site, next business-day
Note 2
service for parts and labor and includes
free telephone support
Note 3
24 x 7. Global coverage
Note 2
ensures that any product purchased in one country and transferred to
another non-restricted country will remain fully covered under the original warranty and service offering. One-year onsite and
labor are not available in all countries.
NOTE 1 : Terms and conditions may vary by country. Certain restrictions and exclusions apply. Other warranty variations may be
offered in your region.
NOTE 2 : On-site service may be provided pursuant to a service contract between HP and an authorized HP third-party provider, and
is not available in certain countries. Global service response times are based on commercially reasonable best effort and may vary
by country.
NOTE 3 : Technical telephone support applies only to HP-configured Compaq and third-party HP-qualified hardware and software.
Toll-free calling and 24 x 7 support may not be available in some countries.
QuickSpecs
HP Pro 3500 Microtower Desktop PC
Standard Features and Configurable Modules
DA - 14349 North America — Version 10 — August 8, 2013 Page 9

Monitors
Part Number
HP LV1911 18.5-inch LED Backlit LCD Monitor A5V72AA
HP LV2011 20-inch LED Backlit LCD Monitor A3R82AA
HP LV2311 23-inch LED Backlit LCD Monitor A6B85AA
QuickSpecs
HP Pro 3500 Microtower Desktop PC
After-Market Options (availability may vary by region)
DA - 14349 North America — Version 10 — August 8, 2013 Page 10

SYSTEM UNIT
Dimensions (WxDxH) 6.50 x 15.31 x 14.49 in
16.5 x 38.9 x 36.8 cm
Weight 15.28 lbs to 15.83 lbs (approximate)
6.932 kg to 7.18 kg (approximate)
Packaging Dimensions (LxWxH) 19.52 x 9.45 x 20.39 in
496x 240 x 518 mm
Shipping Weight 1.94 lb ~22.49 lb
9.952 kg ~10.2 kg
Temperature Operating 32° to 104° F (0 to 40° C)
Non-operating -22° to 149° F (-30° to 65° C)
Relative Humidity Operating 10% to 90% (non-condensing at ambient)
Non-operating 5% to 95% (non-condensing at ambient)
Shock Operating 40 G, half-sine
Non-operating 35G, T-Shock, 165 cm/sec half sine, 2-3 ms
Maximum Altitude
(unpressurized)
Operating 10,000 ft (3048 m)
Non-operating 30,000 ft (9144 m)
Environmental TAA Compliant Yes
For accessibility information on HP products, please visit: http://www.hp.com/accessibility .
INTEL HD GRAPHICS
VGA Controller Integrated
DVI-D Integrated
Bus Type PCI Express x16
RAMDAC Integrated, 350 MHz
Memory
Intel graphics do not have dedicated memory but utilizes some of the computer's system
memory The amount of memory used for graphics depending on the amount of system
memory installed, BIOS settings, operating system, and system load. 32 MB is pre-allocated
for graphics use at system boot time. Additional memory can be allocated at boot time by the
BIOS for PAVP (Protected Audio Video Playback) support for playback of protected video
content.
Additional memory is allocated for graphics as needed using Intel's Dynamic Video Memory
Technology (DVMT), to provide an optimal balance between graphics and system memory use.
Maximum Graphics Memory
Microsoft Windows XP Microsoft Windows 7
Up to 1GB Up to 1.7GB
NOTE: the actual amount of maximum graphics memory can be less than the amounts listed
above depending upon your computer's configuration.
HW Video Decode AVC/VC1/MPEG2/JPEG/MJPEG/PAVP
Maximum Color Depth 32 bits/pixel
3rd Generation Core processors :
QuickSpecs
HP Pro 3500 Microtower Desktop PC
System Unit Specifications and Environmental Data
DA - 14349 North America — Version 10 — August 8, 2013 Page 11

Graphics/Video API Support
The Processor Graphics contains a refresh of the seventh generation graphics core
enabling substantial gains in performance and lower power consumption. Up to 16 EU
support.
Next Generation Intel Clear Video Technology HD Support is a collection of video
playback and enhancement features that improve the end user's viewing experience
Encode/transcode HD content
Playback of high definition content including Blu-ray Disc
Superior image quality with sharper, more colorful images
Playback of Blu-ray disc S3D content using HDMI (V.1.4 with 3D)
DirectX Video Acceleration (DXVA) support for accelerating video processing
Full AVC/VC1/MPEG2 HW Decode
Advanced Scheduler 2.0, 1.0, XPDM support
Windows 7, Windows XP, OSX, Linux OS Support
DirectX 11, DirectX 10.1, DirectX 10, DirectX 9 support
OpenGL 3.3 support
2nd Generation Core processors:
The Processor Graphics contains a refresh of the sixth generation graphics core
enabling substantial gains in performance and lower power consumption.
Next Generation Intel Clear Video Technology HD support is a collection of video
playback and enhancement features that improve the end user's viewing experience.
Encode/transcode HD content
Playback of high definition content including Blu-ray Disc
Superior image quality with sharper, more colorful images
Playback of Blu-ray disc S3D content using HDMI (V.1.4 with 3D)
DirectX Video Acceleration (DXVA) support for accelerating video processing
Full AVC/VC1/MPEG2 HW Decode
Advanced Scheduler 2.0, 1.0, XPDM support
Windows 7, XP, Windows Vista, OSX, Linux OS Support
DirectX 10.1, DirectX 10, DirectX 9 support
OpenGL 3.0 support
Supported Display Resolutions and Refresh Rates
NOTE: other resolutions may be available but are not recommended as they may not have been tested and qualified by HP
Resolution Analog Digital
640x480 85 60
800x600 85 60
1024x768 85 60
1280x720 85 60
1280x1024 85 60
1440x900 75 60
1600x1200 85 60
1680x1050 75 60
1920x1080 85 60-R
1920x1200 85 60-R
1920x1440 85 N/A
2048x1536 75 N/A
QuickSpecs
HP Pro 3500 Microtower Desktop PC
System Unit Specifications and Environmental Data
DA - 14349 North America — Version 10 — August 8, 2013 Page 12

2560x1600 N/A 60*
NOTE: Other resolutions may be available but are not recommended as the may not have been tested and qualified by HP
NOTE: 60-R denotes reduced blanking timings are used on single-link DVI connections and may be used with other digital connections
ENVIRONMENTAL INFORMATION
Unit Environment and
Operating Conditions
General Unit Operating Guidelines
Keep the computer away from excessive moisture, direct moisture and the extremes of heat and
cold, to ensure that unit is operated within the specified operating range.
Leave a 4 in (10.2 cm) clearance on all vented sides of the computer to permit the required airflow.
Never restrict airflow into the computer by blocking any vents or air intakes.
Do not stack computers on top of each other or place computers so near each other that they are
subject to each other's re-circulated or preheated air.
Occasionally clean the air vents on the front, back, and any other vented side of the computer. Lint,
dust and other foreign matter can block the vents and limit the airflow.
If the computer is to be operated within a separate enclosure, intake and exhaust ventilation must be
provided on the enclosure, and the same operating guidelines listed above will still apply.
Eco-Label Certifications &
declarations
This product has received or is in the process of being certified to the following approvals and may be
labeled with one or more of these marks:
IT ECO declaration This product conforms to the examination standards (2003 version) under JEITA's Label
System.
System Configuration The configuration used for the Energy Consumption and Declared Noise Emissions data for the Microtower
model is based on a typically configured product
Energy Consumption Normal Operation 55.63 W
Sleep (low power mode) 1.80W
Off 0.90 W
Heat Dissipation * Normal Operation 189.9BTU/Hr
Sleep 6.0BTU/Hr
Off 3.07BTU/Hr
* Heat dissipation is calculated based on the measured watts, assuming the service level is attained for
one hour.
Declared Noise Emissions
(in accordance with ISO
7779 and ISO 9296)
System Fan on with active
graphic card
Sound Power (LWAd, bels) Sound Pressure (LpAm, decibels)
Idle 4.1 30
HDD random seek 4.4 32
Batteries This product is in compliance with the Restrictions of Hazardous Substances (RoHS) directive -
2002/95/EC.
This HP product is designed to comply with the Waste Electrical and Electronic Equipment (WEEE)
Directive - 2002/96/EC.
This product is in compliance with California Proposition 65 (State of California; Safe Drinking Water
and Toxic Enforcement Act of 1986).
Plastics parts weighing over 25 grams used in the product are marked per ISO 11469 and ISO1043.
This product contains 0% post-consumer recycled plastic (by wt.)
This product is at least 65% recyclable when properly disposed of at end of life.
QuickSpecs
HP Pro 3500 Microtower Desktop PC
System Unit Specifications and Environmental Data
DA - 14349 North America — Version 10 — August 8, 2013 Page 13

Packaging Materials
External: (Carton)
1145g
Internal: (Cushion)
192g
Internal: (Bag for Chassis)
35g
Internal: (Accessory Bag)
19g
Internal: (Insert)
39g
RoHS2 Compliance Hewlett-Packard is committed to compliance with all applicable environmental laws and regulations,
including the European Union Restriction of Hazardous Substances (RoHS) Directive. HP's goal is to exceed
compliance obligations by meeting the requirements of the RoHS Directive on a worldwide basis. By July 1,
2006, RoHS substances will be virtually eliminated (virtually = to levels below legal limits) for all HP
electronic products subject to the RoHS Directive, except where it is widely recognized that there is no
technically feasible alternative (as indicated by an exemption under the EU RoHS Directive).
Material Usage This product does not contain any of the following substances in excess of regulatory limits (refer to the
HP General Specification for the Environment at:
http://www.hp.com/hpinfo/globalcitizenship/environment/supplychain/gen_specifications.html )
Asbestos
Certain Azo Colorants
Certain Brominated Flame Retardants - may not be used as flame retardants in plastics
Cadmium
Chlorinated Hydrocarbons
Chlorinated Paraffins
Formaldehyde
Halogenated Diphenyl Methanes
Lead carbonates and sulfates
Lead and Lead compounds
Mercuric Oxide Batteries
Ozone Depleting Substances
Polybrominated Biphenyls (PBBs)
Polybrominated Biphenyl Ethers (PBBEs)
Polybrominated Biphenyl Oxides (PBBOs)
Polychlorinated Biphenyl (PCB)
Polychlorinated Terphenyls (PCT)
Polyvinyl Chloride (PVC) - except for wires and cables, and certain retail packaging has been
voluntarily removed from most applications.
Radioactive Substances
Tributyl Tin (TBT), Triphenyl Tin (TPT), Tributyl Tin Oxide (TBTO)
Nickel finishes that release greater than 0.5 micro-grams/cm2/week, measured according to EN
1811:1998, are not used on any product surface designed to be frequently handled or touched by
users.
Packaging HP follows these guidelines to decrease the environmental impact of product packaging:
Eliminate the use of heavy metals such as lead, chromium, mercury and cadmium in packaging
materials.
QuickSpecs
HP Pro 3500 Microtower Desktop PC
System Unit Specifications and Environmental Data
DA - 14349 North America — Version 10 — August 8, 2013 Page 14

Eliminate the use of ozone-depleting substances (ODS) in packaging materials.
Design packaging materials for ease of disassembly.
Maximize the use of post-consumer recycled content materials in packaging materials.
Use readily recyclable packaging materials such as paper and corrugated materials.
Reduce size and weight of packages to improve transportation fuel efficiency.
Plastic packaging materials are marked according to ISO 11469 and DIN 6120 standards.
End-of-life Management
and Recycling
Hewlett-Packard offers end-of-life HP product return and recycling programs in many geographic areas.
To recycle your product, please go to: http://www.hp.com/go/reuse-recycle or contact your nearest HP
sales office. Products returned to HP will be recycled, recovered or disposed of in a responsible manner.
The EU WEEE directive (2002/95/EC) requires manufacturers to provide treatment information for each
product type for use by treatment facilities. This information (product disassembly instructions) is posted
on the Hewlett Packard web site at: http://www.hp.com/go/recyclers . These instructions may be used by
recyclers and other WEEE treatment facilities as well as HP OEM customers who integrate and re-sell HP
equipment.
Hewlett-Packard
Corporate Environmental
Information
For more information about HP's commitment to the environment:
Global Citizenship Report
http://www.hp.com/hpinfo/globalcitizenship/gcreport/index.html
Eco-label certifications
http://www.hp.com/hpinfo/globalcitizenship/environment/productdesign/ecolabels.html
ISO 14001 certificates:
http://www.hp.com/hpinfo/globalcitizenship/environment/operations/envmanagement.html
All rights reserved. AMD is a trademark of Advanced Micro Devices, Inc. Microsoft and Windows are U. S. registered trademarks of
Microsoft Corporation. Intel, Intel Core, Celeron, and Pentium are trademarks of Intel Corporation in the U.S. and/or other countries.
Bluetooth is a registered trademark of Bluetooth SIG, Inc., in the U.S. and other countries. All other product names mentioned herein
may be trademarks of their respective companies.
The information contained herein is subject to change without notice and is provided "as is" without warranty of any kind. The
warranties for HP products are set forth in the express limited warranty statements accompanying such products. Nothing herein
should be construed as constituting an additional warranty. HP shall not be liable for technical or editorial errors or omissions
contained herein.
June 2012
QuickSpecs
HP Pro 3500 Microtower Desktop PC
System Unit Specifications and Environmental Data
DA - 14349 North America — Version 10 — August 8, 2013 Page 15
