HP Vectra VL800 User manual

hp business pcs
www.hp.com/go/vectrasupport
service
handbook
chapter
hp vectra
vl800
minitower

notice
Information contained in this document is subject to change without notice.
Hewlett-Packard makes no warranty of any kind with regard to this material,
including, but not limited to, the implied warranties of merchantability and
fitness for a particular purpose. Hewlett-Packard shall not be liable for errors
contained herein or for incidental or consequential damages in connection with
the furnishing, performance, or use of this material.
Hewlett-Packard assumes no responsibility for the use or reliability of its
software on equipment that is not furnished by Hewlett-Packard.
This document contains proprietary information that is protected by copyright.
ll rights are reserved. No part of this document may be photocopied,
reproduced, or translated into another language without the prior written
consent of Hewlett-Packard Company.
3Com® and EtherLink® are registered trademarks of 3Com Corporation.
NVIDI , GeForce2 GTS and GeForce2 MX are registered trademarks or trademarks
of NVIDI Corporation.
Matrox® is a registered trademark of Matrox Electronic Systems Ltd.
Microsoft®, Windows®, Windows NT® and MS-DOS® are registered trademarks of the
Microsoft Corporation.
Pentium® and GPset are trademarks of Intel Corporation.
Rambus® and RDR M® are registered trademarks of Rambus Inc.
Direct Rambus, Direct RDR M and RIMM are trademarks of Rambus Inc.
Sound Blaster® is a registered trademark of Creative Technology Limited.
© 2001 Hewlett-Packard Company
contents
This chapter provides:
❒ Product model numbers
❒ Supported ccessories
❒ System Board, BIOS, and memory information
❒ Part numbers.
replacement and exchange parts
The difference between a replacement and an exchange part is that when using
an exchange part you should return the replaced part to HP.
Replacement and exchange parts listed in this manual are subject to change.
However, updated part numbers are automatically cross-referenced to the old
number. This means that you will receive the correct part using the numbers
listed in this manual (even if the parts actual number has been updated).
ordering parts
Contact your local HP Customer Care Center or an HP uthorized support
provider to get parts. Diagnostic is required in both cases, prior to any shipments.
For HP Customer Care Centers connect to www.hp.com/go/vectrasupport and
select contact hp.


HP Vectra vl800 Minitower PC
Models and Accessories
1
Product
umber1Cache Memory Std. RAM Hard Drive Video Controller Multi-media LA
HP ectra vl800 PC
HP Vectra vl800 1.3 GHz (CPL: 03/2001 )
P2078A
and
P2078T
Pentium® 4
with 256KB
cache
memory
128 MB
PC800
RDRAM®
non-ECC
20 GB
Ultra
ATA/100
7.2krpm
Matrox
Millennium
G450 16MB
Dual
48✕ IDE
CD-ROM 3COM
PCI
HP ectra vl800 PC
HP Vectra vl800 1.4 GHz (CPL: 03/2001 )
P2080A
and
P2080T
Pentium® 4
with 256KB
cache
memory
128 MB
PC800
RDRAM®
non-ECC
18 GB
U160
SCSI
7.2krpm
Matrox
Millennium
G450 16MB
Dual
48✕ IDE
CD-ROM 3COM
PCI
P3632A Pentium® 4
with 256KB
cache
memory
256 MB
PC800
RDRAM®
non-ECC
40 GB
Ultra
ATA/100
7.2krpm
n IDIA
GeForce2
GTS 32MB
12✕40✕ IDE
D D-ROM 3COM
PCI
HP ectra vl800 PC
HP Vectra vl800 1.5 GHz (CPL: 03/2001 )
P2079A
and
P2079T
Pentium® 4
with 256KB
cache
memory
128 MB
PC800
RDRAM®
non-ECC
40 GB
Ultra
ATA/100
7.2krpm
n IDIA
GeForce2
GTS 32MB
12✕40✕IDE
D D-ROM 3COM
PCI
HP ectra vl800 PC
HP Vectra vl800 1.7 GHz (CPL: 03/2001 )
P3633A Pentium® 4
with 256KB
cache
memory
256 MB
PC800
RDRAM®
non-ECC
40 GB
Ultra
ATA/100
7.2krpm
n IDIA
GeForce2
GTS 32MB
12✕40✕IDE
D D-ROM
and
8✕4✕32✕IDE
CD-Writer
3COM
PCI
All models are supplied with a 1.44 MB Floppy Disk Drive, an integrated IDE
ontroller, and an integrated audio hip on the system board.
1. Unless otherwise mentioned, the operating system for the HP ectra vl800 Minitower PC is
Windows® 2000.
minitower vectras HP Vectra vl800 Minitower PC 1-4

HP Vectra vl800 Minitower PC
Supported Accessories
Memory Upgrades
2 x 128 MB kit, PC800 non-ECC RDRAM main memory
2 x 256 MB kit, PC800 non-ECC RDRAM main memory
2 x 512 MB kit, PC800 non-ECC RDRAM main memory
2 x 64 MB kit, PC800 ECC RDRAM main memory
2 x 128 MB kit, PC800 ECC RDRAM main memory
2 x 256 MB kit, PC800 ECC RDRAM main memory
2 x 512 MB kit, PC800 ECC RDRAM main memory
Mass StorageHard Disk Drives
40 GB Ultra ATA/100 hard disk, 7.2k rpm
9.1 GB Ultra3 SCSI hard disk, 10k rpm
18 GB Ultra3 SCSI hard disk, 10k rpm
Removable Mass Storage
48X max-speed IDE CD-ROM drive (single)
48X max-speed IDE CD-ROM drive (pack of 10)
P2277A
P2278A
P2279A
D9518A
D9519A
D9520A
P2272A
P2813A
D8608B
D8609B
D9444A
D9445A
12X40X max-speed (D D read, CD-ROM read) IDE D D-ROM drive P1547A
18X4X32X max-speed (write, rewrite, read) IDE CD-Writer drive
USB CD-Writer
HP USB CompactFlash reader
Input Devices
HP multimedia keyboard
HP USB smart card keyboard
HP mouse with scrolling wheel
HP USB optical mouse with scrolling wheel
HP cordless scrolling mouse
HP USB CompactFlash reader
HP USB Web camera
LA Interfaces
HP 3COM FastEtherlink XL 3C905C-TX PCI NIC1 (single)
HP 3COM FastEtherlink XL 3C905C-TX PCI NIC1 (pack of 10)
HP 802.11b Wireless LAN access point for corporations
HP 802.11b Wireless LAN PCI card
HP 802.11b Wireless LAN USB
HP 802.11b Wireless LAN access point for small business
1-5 HP Vectra vl800 Minitower PC minitower vectras
P1982A
C4504A
P1977A
C4742B
C4764B
C4736B
C4766A
C4740B
P1977A
P1978A
D7522B
D7523B
F2135A
F2137A
P1980A
P1981A

HP Vectra vl800 Minitower PC
Audio
HP Standard headset
HP External amplified speakers (9.6 WRMS)
Interface Cards
HP Ultra 160 SCSI adapter
Modems
HP 56K 90 external USB e-Modem
HP 56K 90 PCI internal modem
Graphics Cards
Matrox Millennium G450 dual 16MB graphics card
n idia GeForce2 GTS 32MB graphics card
Security
HP Kensington lock security cable
HP Spare master pass key
HP Master pass key system kit
HP Kit of 50 locks for master pass key
HP ProtectTools 2000 smart card kit
1. NIC = Network Internet Connector
D8387A
P1534A
P1969A
P1979A
D7519A
D7518A
P1971A
F1645A
D6658B
D6655C
D9528A
D8436B 1
minitower vectras HP Vectra vl800 Minitower PC 1-6

HP Vectra vl800 Minitower PC
System Board Connectors, BIOS, and Memory
1
Pentium 4
processor
(socket 423)
Main Power
Supply
Secondary IDE
*
*
)
)
Primary IDE
Floppy
GP Slot
PCI slots
Battery socket
Wake On L N
DT chassis intrusion
CD-ROM
audio in
Processor fan
DT status panel
DT Internal Speaker
TX12V power
Main chassis fan
Memory slots
System
board
switches
i850 MCH
i850 ICH2
SCSI LED
MT internal
MT chassis
intrusion
MT status panel
speaker
1-7 HP Vectra vl800 Minitower PC minitower vectras

HP Vectra vl800 Minitower PC
System Board Switches
Switch Default Function
1FF
Reserved 1-5. Do ot Change Default Settings.
2FF
3FF
4FF
5FF
6Disables keyboard power-on
O Enables keyboard power-on
7OFF Enables normal mode
Enables the BIOS recovery mode at next boot
8FF Retains CMOS memory
Clears CMOS memory at next boot
9OFF Enables User and System Administrator passwords
Clears the passwords at next boot
10 OFF
O
O
O
O
O
O
BIOS History
For the latest BIOS, the flasher utility program, and the BIOS history refer to the
HP World Wide Web site. The BIOS is in the form IQ.01.yy.zz
yy= BIOS version number
zz = is the selected language to be downloaded
1
http://www.hp.com/go/vectrasupport
Main Memory
The HP ectra vl800 has two pairs of memory sockets for installing either two
or four RAMBUS Direct RAM (RDRAM) memory modules.
Each pair of memory sockets must contain identical memory modules
(identical in size, speed and type). That is, sockets A1 and B1 must contain
identical modules, and sockets A2 and B2 must contain identical modules (or
continuity modules).
If only two RDR M modules are installed, use the sockets marked A1 and B1.
The other two sockets (A2 and B2) must contain continuity modules.
minitower vectras HP Vectra vl800 Minitower PC 1-8

HP Vectra vl800 Minitower PC
Replacing the Heatsink Thermal Interface
Follow these instructions when replacing the heatsink, processor or system
board.
Removing the Heatsink
1Remove the screws.
2 Remove the heatsink by
twisting and lifting it.
Replacing the Thermal Interface
3 Carefully remove all old thermal bonding
material from the processor and the underside of
the heatsink.
4 Remove the two paper protectors from the
thermal interface material then affix it to the top
of the processor.
Reattaching the Heatsink
5 Attach the heatsink to the
processor.
6 Secure the heatsink using the
springs and screws.
1
1-9 HP Vectra vl800 Minitower PC minitower vectras

1
HP Vectra vl800 Minitower PC
Parts and Part umbers
1
1b
1e
1c
1d
1f
1a
5
3
2b
3d
3c
2a
4
1g
minitower vectras HP Vectra vl800 Minitower PC 1-10

HP Vectra vl800 Minitower PC
Parts List
Item Description Replacement
Part umber Exchange Part umber
1Chassis assembly for vl800 Minitower:
aHard disk drive cage
bPower-on kit (anti-intrusion, front LED,
power-on switch).
cFront bezel filler kit
dRear fan assembly (with 4 pushpins)
eLock assembly
fPower supply PFC
gFloppy disk drive (1.44)
Not shown in graphi :-
6x32 screws for power supply
5065-4227
5002-6283
5065-0446
5065-0449
5065-4254
5064-9154
5065-4261
D2035-60293
2360-0565








2Cables:
aIDE cable kit (FDD, HDD, CD-ROM)
bSCSI cable, U160, 4-point
cSCSI LED cable for U160 SCSI card
dCD-ROM audio cable
CD-ROM audio cable for Sound Blaster
5065-4255
5184-4906
5184-3868
5182-1857
5184-4907





3System board:
Manufacturing Part Number P2074-60001/2
Manufacturing Part Number P2074-60003/4
P2074-63001
P2074-63003
P2074-69001
P2074-69003
4RDRAM Continuity Module D8660-63001 
5Minitower internal Speaker 5184-3847 
1
1-11 HP Vectra vl800 Minitower PC minitower vectras

HP Vectra vl800 Minitower PC
Parts List
1
Available Parts that are not shown in the graphic on page 10.
Ultra160 SCSI card (Symbios 8955U) 5184-3856 
Internal SCSI wide to narrow converter 5184-3872 
Standard hard disk drives1
20 GB IDE Ultra ATA/100 7.2k rpm
IBM Telesto LP
Maxtor Rigel P1640-63001 P2833-63001P1640-69001 P2833-69001
40 GB IDE Ultra ATA/100 7.2k rpm
IBM Telesto LP
Maxtor Rigel P1641-63001
P3624-63001P1641-69001 P3624-69101
60 GB IDE Ultra ATA/100 7.2k rpm
Maxtor Rigel P3726-63001P3726-69001
9GB SCSI U160 10k rpm P1575-63001P1575-63001
18 GB SCSI U160 10k rpm P1576-63001P1576-69001
36 GB SCSI U160 10k rpmP1577-63001P1577-69001
Optical drives:
CD-ROM 48X IDE drive D4389-60081 D4389-63081
D D-ROM 12X IDE drive D4388-61004 D4388-69004
CD-Writer 8X4X24X IDE drive D4398-63051 D4398-69051
ZIP Drive 100 MB D9794-63001 
Graphics cards & cables:
Matrox Millennium G450 AGP 16MB Dual
n idia GeForce2 GTS AGP 32MB
n idia GeForce2 MX AGP
D I- GA converter for n idia GeForce2MX
Appian Jeronimo Pro Quad P2A I
Cable P2A P2 for Jeronimo Pro
5065-3897
5065-2543
5065-4231
5184-3854
5065-4208
5184-3831
P2062-69501
P1546-69001
P2075-69501



Sound Blaster Live audio card 5065-4246 
PCI Modem Kit:
For USA
For Europe D7519-60001 D7519-60002  
Intel LAN card
3COM LAN card 3C905 5065-1210 5064-7429  
Item Description Replacement
Part umber Exchange Part umber
minitower vectras HP Vectra vl800 Minitower PC 1-12

HP Vectra vl800 Minitower PC
Parts List
Item Description Replacement
Part umber Exchange Part umber
Input Devices:
Cordless mouse
USB & PS2 Optical wheel mouse
Enhanced mouse with scroll/zoom wheel
Multimedia keyboard
Standard keyboard
C4740-63001
C4767-60001
C4736-60101
C4742-601xx
C4393-601xx





Audio headset 5183-9500 
Power cord 8120-xxxx 
CR2032 battery (3) 1420-0356 
Screws 6x32 2680-0311 
1. For optional disk drive information, refer to the A essory Servi e Handbook.
System Board Parts List
1
Description Repl.
Part
umber
Exchange
Part
umber
Processors (Socket):
Intel Pentium 4, 1.3 GHz
Intel Pentium 4, 1.4 GHz
Intel Pentium 4, 1.5 GHz
Intel Pentium 4, 1.7 GHz
Pentium 4 heatsink
Pentium 4 heatsink springs & screws kit
Pentium 4 thermal interface
P2135-63001
P2136-63001
P2137-63001
P2138-63001
P2136-63101
5065-4230
P2136-65001
P2135-69001
P2136-69001
P2137-69001
P2138-69001



Main memory modules
2 x 64 MB kit, PC800 non-ECC RDRAM
2 x 128 MB kit, PC800 non-ECC RDRAM
2 x 256 MB kit, PC800 non-ECC RDRAM
2 x 512 MB kit, PC800 non-ECC RDRAM
2 x 64 MB kit, PC800 ECC RDRAM
2 x 128 MB kit, PC800 ECC RDRAM
2 x 256 MB kit, PC800 ECC RDRAM
2 x 512 MB kit, PC800 ECC RDRAM
P2144-63001
P2145-63001
P2146-63001
P2147-63001
D9518-63010
D9519-63010
D9520-63010
P2143-63001
P2144-69001
P2145-69001
P2146-69001
P2147-69001
D9518-69001
D9519-69001
D9520-69001
P2143-69001
1-13 HP Vectra vl800 Minitower PC minitower vectras

HP Vectra vl800 Minitower PC
Manuals and Documentation
Description Available
Qui k Users Guide
(Minitower and Desktop) Paper document and
electronic file
Desktop Users Guide electronic file only
Desktop Troubleshooting Guide electronic file only
Te hni al Referen e Manual (Minitower and Desktop) electronic file only
Online documentation (electronic files) can be downloaded from:
www.hp.com/go/vectrasupport
Software
Description Repl.
Part umber Exchange Part umber
Image Creation and Re overy CD-ROM for
Windows NT and Windows 2000 5970-0451-xx1
Image Creation and Re overy CD-ROM for
Windows NT and Windows 2000 - Spanish 5970-0452-SP 
1. xx = Language code except Spanish
1
minitower vectras HP Vectra vl800 Minitower PC 1-14

HP Vectra vl800 Minitower PC
1
Notes: _____________________________________________________________
___________________________________________________________________
___________________________________________________________________
___________________________________________________________________
___________________________________________________________________
___________________________________________________________________
___________________________________________________________________
___________________________________________________________________
___________________________________________________________________
___________________________________________________________________
___________________________________________________________________
___________________________________________________________________
___________________________________________________________________
___________________________________________________________________
___________________________________________________________________
1-15 HP Vectra vl800 Minitower PC minitower vectras
