Welcome to Your HP Vectra PC
Congratulations on the purchase of your new Hewlett-Packard
Personal Computer. Your high-performance HP Vectra PC provides:
•a PentiumTM Pro processor in a Zero Insertion Force (ZIF) socket for
easy processor upgrades
•processor-integrated level-two cache for improved performance
•32 MB of ECC (error correcting code) memory, upgradeable
to 512 MB
•an Ultra VGA PCI (Peripheral Component Interconnect) video
controller with 2 MB of video memory (upgradeable to 8 MB)
•an integrated Enhanced IDE (Integrated Drive Electronics)
controller on the PCI bus supporting Fast IDE and Standard IDE
•an integrated Ultra SCSI controller on the PCI bus supporting
Fast-20 SCSI-2 (up to 20 MB-per-second data transfer rate) and
SCSI Plug and Play (SCAM) compliant devices
•a 32-bit PCI 100VG/10BaseT Ethernet LAN controller or
a 32-bit PCI 100/10BaseT Ethernet LAN controller
•seven mass storage shelves:
❒five front-access shelves
❒two internal shelves
•six slots for accessory boards:
❒three 32-bit PCI (Peripheral Component Interconnect) slots
❒two 16-bit ISA (Industry Standard Architecture) slots
❒one combination ISA or PCI slot
•a CD-ROM drive

English v
•an integrated SoundBlasterTM 16 audio interface on the ISA bus
•headphones jack, microphone jack, and volume control on
the front panel
•MIDI/joystick interface connector, audio Stereo In jack, and audio
Stereo Out jack on the rear panel
•one SCSI connector, one parallel port, and two serial ports on the
rear panel
•System BIOS and Video BIOS stored in Flash ROMs (for easy
upgradeability)
•BIOS support for ISA “Plug and Play” accessory board configuration
•Optimized for 32-bit operating systems.
NOTE The PentiumTM Pro processor installed in your HP Vectra PC provides
the best performance when used with 32-bit operating systems and
applications.

vi English
Important Safety Information
If you have any doubt that you can lift the PC or display safely, do not
try to move it without help.
For your safety, always connect the equipment to a grounded wall
outlet. Always use a power cord with a properly grounded plug, such as
the one provided with this equipment, or one in compliance with your
national regulations. This PC is disconnected from the power by
removing the power cord from the power outlet. This means the PC
must be located close to a power outlet that is easily accessible.
For your safety, never remove the PC’s cover without first removing the
power cord from the power outlet, and any connection to a
telecommunications network. Always replace the cover on the PC
before switching it on again.
WARNING To avoid electric shock, do not open the power supply.
This HP PC is a class 1 laser product. Do not attempt to make any
adjustment of the laser units.
Important Ergonomic Information
It is strongly recommended that you read the ergonomic information
before using your PC. See “Working in Comfort” on page 16.

Contents
English vii
1 Setting Up Your PC
Unpacking Your PC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Connecting the Display, Mouse, and Keyboard . . . . . . . . . . . . . . . . . . 4
Connecting to a Network . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Connecting a Printer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
