HP C4742B User manual

C4742B
HP Multimedia Keyboard
User’s Guide
HP Multimedia-Tastatur
Benutzerhandbuch
Clavier HP Multimédia
Guide d’utilisation
TecladomultimediaHP
Guía del usuario
Léase esto primero
Tastiera multimediale HP
Guida d’uso
English
Deutsch
Français
Español
Italiano
keyb.book Page i Thursday, May 25, 2000 4:36 PM

Notice
The information contained in this document is subject to change without notice.
Hewlett-Packard makes no warranty of any kind with regard to this material, including, but not
limited to, the implied warranties of merchantability and fitness for a particular purpose. Hewlett-
Packard shall not be liable for errors contained herein or for incidental or consequential damages
in connection with the furnishing, performance, or use of this material. Hewlett-Packard assumes
no responsibility for the use or reliability of its hardware or software on equipment that is not furnished
by Hewlett-Packard or equipment for which it is not intended. This document contains proprietary
information that is protected by copyright. All rights are reserved. No part of this document may
be photocopied, reproduced, or translated to another language without the prior written consent
of Hewlett-Packard Company.
Hinweis
Inhaltliche Änderungen vorbehalten.
Hewlett-Packard übernimmt keine Garantie welcher Art auch immer für diese Ausrüstung,
einschließlich der (doch nicht begrenzt auf die) Qualitätsgarantie und die Garantie bezüglich
Eignung für einen bestimmten Zweck. Hewlett-Packard haftet nicht für in dieser Dokumentation
enthaltene Fehler oder für unbeabsichtigte oder indirekte Schäden in Verbindung mit der
Lieferung, der Leistung oder der Benutzung der Ausrüstung. Hewlett-Packard übernimmt keine
Haftung fur den Betrieb oder die Zuverlässigkeit seiner Software, wenn diese auf Hardware
benutzt wird, die nicht von Hewlett-Packard geliefert wurde. Dieses Dokument enthalt proprietäre
Informationen, die durch das Copyright geschützt sind. Alle Rechte vorbehalten. Dieses
Dokument darf ohne vorherige schriftliche Genehmigung der Hewlett-Packard Company weder
ganz noch teilweise fotokopiert, reproduziert oder übersetzt werden.
Avertissement
Lesinformationscontenuesdanscedocumentpeuventêtremodifiéessanspréavis.
Hewlett-Packard ne donne aucune garantie de quelque sorte que ce soit concernant, sans que ce
soit limitatif, les garanties implicites de qualité commerciale de ce matériel, ou la bonne adaptation
de celui-ci à un usage particulier. Hewlett-Packard n’est pas responsable des erreurs pouvant
apparaître dans ce manuel et n’est pas non plus responsable des dommages directs ou indirects
résultant de l’équipement, des performances et de l’utilisation de ce matériel. Hewlett-Packard ne
saurait être tenu pour responsable de l’utilisation et de la fiabilité de son logiciel sur des matériels
non fournis par Hewlett-Packard. Les informations contenues dans ce document sont originales et
protégées par copyright. Tous droits réservés. L’acheteur s’interdit en conséquence de les
photocopier, de les reproduire ou de les traduire dans toute autre langue, sauf accord préalable et
écrit de Hewlett-Packard.
Aviso
La información contenida en este documento está sujeta a cambios sin previo aviso.
Hewlett-Packard no ofrece ningún tipo de garantía con respecto a este material, incluyendo, pero
sin limitarse a, las garantías implícitas de comerciabilidad e idoneidad para un fin determinado.
Hewlett-Packard no asume responsabilidad alguna por los posibles errores contenidos o por los
daños casuales o emergentes relacionados con el suministro, funcionamiento o uso de este
material. Hewlett-Packard no asume responsabilidad alguna por el uso o fiabilidad de su software
en equipos que no hayan sido fabricados por Hewlett-Packard. Este documento contiene
información patentada, protegida por las leyes del copyright. Reservados todos los derechos.
Ninguna parte de este documento puede ser fotocopiada, reproducida o traducida a otro idioma
sin la autorización previa y por escrito de Hewlett-Packard Company.
Avviso
Le informazioni contenute in questo documento sono soggette a cambiamento senza preavviso.
Hewlett-Packard non rilascia garanzie di alcun tipo riguardo a questo materiale, comprese le
garanzie implicite di commerciabilità e di idoneità per uno scopo particolare. Hewlett-Packard non
sarà ritenuta responsabile per errori contenuti in questo documento, né per danni accidentali o
conseguenti alla fornitura, alle prestazioni o all’uso di questo materiale. Hewlett-Packard non si
assume alcuna responsabilità riguardo all’uso o all’affidabilità del proprio software su
apparecchiature di altri produttori. Questo documento contiene informazioni di proprietà protette
da copyright. Tutti i diritti sono riservati. Nessuna parte di questo documento può essere
fotocopiata, riprodotta o tradotta in un’altra lingua senza un precedente consenso scritto di
Hewlett-Packard Company.
Hewlett-Packard France, 38053 Grenoble, Cedex 9 France
© 2000 Hewlett-Packard Company
keyb.book Page ii Thursday, May 25, 2000 4:36 PM

English 1
Chapter 1 - Your HP Multimedia Keyboard
Supported Platforms
This manual describes how to set up the HP multimedia keyboard and
configure the following operating systems supported by HP:
•Windows 95
•Windows 98
•Windows NT 4.0
•Windows 2000
To find out on which HP Business PCs you can install the HP multimedia
keyboard go to the following HP Web site:
Setting Up Your HP Multimedia Keyboard
1Shut down your PC and connect the HP multimedia keyboard to the PC.
Your PC’s audio connection panel may differ from the own shown here.
Color-coding is used on some PC’s to aid connection. Refer to your PC’s
User’s Guide for more information.
NOTE When you connect the keyboard jack to the rear of the PC, the PC’s internal
speaker, where fitted, is deactivated. You can then connect headphones or
speakers to the rear of the keyboard to have sound (go to the next step).
www.hp.com/go/pcaccessories
Microphone
Speakers/headphones
keyb.book Page 1 Thursday, May 25, 2000 4:36 PM

2 English
NOTE To avoid discomfort from unexpected noise, always turn the volume down
before connecting headphones or speakers.
Listening to loud sounds for prolonged periods may permanently damage
your hearing. Before putting on headphones, place them around your neck
and turn the volume down. When you put on the headphones, slowly
increase the volume until you find a comfortable listening level, and leave
the volume control in that position.
2Connect the microphone and headphones/speakers to the keyboard.
The speakers and microphone shown here are not supplied with your PC.
NOTE Your PC may have a CD-ROM or DVD drive. Although these drives may have
a headphones socket and a volume control, use the keyboard sockets as
described in this section. This will ensure that you use all your PC’s
multimedia features.
Installing the Keyboard Support Software
Windows 95,
Windows 98,
Windows NT 4.0
& Windows 2000
1Insert the first HP Multimedia Keyboard software CD-ROM that
corresponds to your operating system, into your CD-ROM drive.
2From Windows Explorer (or Windows NT Explorer for NT 4.0) double click on
the CD-ROM Drive (typically the D:).
3Double click on Setup.exe to begin installation.
4Follow the on screen instructions and insert other disks as prompted.
keyb.book Page 2 Thursday, May 25, 2000 4:36 PM

English 3
Using Your HP Multimedia Keyboard
WARNING Important Ergonomic Information
Improper and prolonged use of keyboards and input devices are among
those tasks associated with repetitive strain injury (RSI) to soft tissue in the
hands and arms. If you do experience discomfort or pains while using any
computing equipment, discontinue use immediately and consult your
physician as soon as possible.
Your comfort and safety are our primary concern. Consequently, we
recommend you read HP’s ergonomic information before using your PC.
For detailed information, refer to HP’s online version of “Working in
Comfort” which is preloaded on your PC’s hard disk or visit HP’s Working
in Comfort Web site at: www.hp.com/ergo.A summary is provided in the
Comfort and Safety Checklist on page 6.
The HP multimedia keyboard includes soft keys you can use to:
•Display and configure the actions assigned to keys.
•Perform one-touch shortcuts to start applications, open files, or open
sites on the WWW.
•Launch the Internet browser supplied with your system.
•Lock your PC or PC Workstation.
•Access HP TopTools and customer information.
•Mute or adjust the volume of the audio system.
Windows Key You can display the Windows 95 Start menu by pressing either of the two
Windows keys, positioned to the left and right of the space bar.
Application Key You can access all right-mouse button functions used to copy and move files,
display shortcut menus, and get Help information, by pressing the Application
key. The Application key can also be programmed by your software.
HP TopTools
Mail key
Menu key
Internet key
Lock key
HP Customer
Information
Mute Key
Volume Keys
Shortcut keys
keyb.book Page 3 Thursday, May 25, 2000 4:36 PM

4 English
“Power-on”
Function
Note that the “Power-on” function only works on HP PCs that support this
function.
You can switch on your PC by pressing the space bar. You can enable and
disable the “Power-on” function from your PC’s Setup program (the default
is enabled). Please refer to the description of the Setup program in your
PC’s documentation.
Mail Key You can launch your default mail client by pressing this key. For MAPI-
based mail clients like Microsoft Outlook, the LED above this key blinks
when new mail is received. When the LED blinks, simply press the mail key
to view the newly arrived mail.
Shortcut Keys The shortcut soft keys can be used to start an application, open a
document, or open a site on the Internet. Actions can be assigned to the
shortcut keys by pressing the Menu key and clicking the key you want to
configure in the keyboard displayed on your screen.
HP TopTools Pressing this soft key opens HPTopTools on PCs that come with this
application. HP TopTools helps you manage your PC, reduce overall
ownership costs, and provides advanced PC management tools. For
example, it can be used for remote BIOS updates and security
management.
NOTE Before using HP TopTools for the first time on HP preloaded systems, you
must install it as follows: From the Start menu, select Programs, then
HP DMI, then Setup. The HP TopTools application is installed automatically.
Internet Key This soft key is used to start the Web browser configured on your computer.
Menu Key Pressing the ?Menu soft key displays the soft key section of the HP
multimedia keyboard on your screen. Click any of the keys on the screen to
display the action assigned to an individual key or to change or assign an
action to a key. Shortcut keys are provided specifically for user-defined
actions.
Lock Key The action of the Lock key is configured by pressing the Menu Key, and
then clicking on Configure,the Extended Keys tab and the onscreen Lock
button. With HP Lock installed, the actions you can specify for the Lock key
are:
•Lock the front panel.
•Launch screen saver
HP Customer
Information
This soft key accesses HP Customer Information, which includes:
•Information on product features
•The preloaded software on the system
•Details on how to configure the HP multimedia keyboard
•Information on how to configure the WWW browser
•Detailed HP support information
•Links to the HP PC and PC Workstation Web sites.
keyb.book Page 4 Thursday, May 25, 2000 4:36 PM

English 5
The Euro Symbol
Mute and Volume
Keys
Pressing the Mute key mutes the audio, or restores the audio if it has been
muted. The Volume keys can be used to control the volume level.
The Euro Symbol
This section only applies if your keyboard comes with the Euro symbol key
(only available with certain language models).
Your keyboard’s Euro symbol key can only be used with Operating Systems
and applications that support this feature.
•Only the latest operating systems, such as Windows 98, provide
integrated support for the Euro symbol (in certain languages only).
•Not all applications support the Euro symbol.
•Not all fonts contain the Euro character.
Windows NT 4.0 &
Windows 95
Windows NT 4.0 and Windows 95 do not provide integrated support. For
more information on how to enable support of the Euro symbol, refer to
Microsoft’s web site at:
www.microsoft.com/windows/euro.asp
Windows 98 Windows 98 has all the necessary fonts and built-in drivers to use the euro
symbol, provided that the user's peripherals (such as printers) were
designed to work with the euro. Printer fonts that support the euro symbol
include Times New Roman, Arial, and Courier New.
Windows 2000 Windows 2000 provides integrated support.
Configuring Your
Keyboard
To configure your keyboard, go to Settings >Control Panel in the Start menu.
Double-click on Keyboard and select the Language or Input Locales tab in the
Keyboard Properties window. Click on Add and select the country that
corresponds with your keyboard, and click OK. Click OK to exit the Control
Panel.
HP Support Services
You can get help with solving problems with HP accessories from the
following HP support Web sites:
www.hp.com/go/vectrasupport
www.hp.com/go/kayaksupport
www.hp.com/go/briosupport
keyb.book Page 5 Thursday, May 25, 2000 4:36 PM

HP Support Services
6 English
keyb.book Page 6 Thursday, May 25, 2000 4:36 PM

keyb.book Page xxiii Thursday, May 25, 2000 4:36 PM

Part Number
Printed in
C4742-90027
France
Paper not bleached with chlorine
05/00
keyb.book Page xxiv Thursday, May 25, 2000 4:36 PM
