HP C4742A User manual

C4742A
HP Multimedia Keyboard
User’s Guide
HP Multimedia-Tastatur
Benutzerhandbuch
Clavier HP Multimédia
Guide d’utilisation
Teclado multimedia HP
Guía del usuario
Léase esto primero
Tastiera multimediale HP
Guida d’uso
English
Deutsch
Français
Español
Italiano
keyb.book Page i Friday, May 28, 1999 10:30 AM

Notice
The information contained in this document is subject to change without notice.
Hewlett-Packard makes no warranty of any kind withregard to this material, including, but not limited to,
the implied warranties of merchantability and fitness fora particular purpose. Hewlett-Packard shall not
be liable for errors contained herein or for incidental or consequential damages in connection with the
furnishing, performance, or use of this material. Hewlett-Packard assumes no responsibilityfor the use or
reliability of itshardware or softwareon equipment that isnot furnished byHewlett-Packard or equipmentfor
whichitisnot intended. This document contains proprietary information that is protected by copyright.
All rights are reserved. No part of this document may be photocopied, reproduced, or translated to
another language without the prior written consent of Hewlett-Packard Company.
Hinweis
Inhaltliche Änderungen vorbehalten.
Hewlett-Packard übernimmt keine Garantie welcher Art auch immer für diese Ausrüstung, einschließlich
der (doch nicht begrenzt auf die) Qualitätsgarantie und die Garantie bezüglich Eignung für einen
bestimmten Zweck. Hewlett-Packard haftet nicht für in dieser Dokumentation enthaltene Fehler oder für
unbeabsichtigte oder indirekte Schäden in Verbindung mit der Lieferung, der Leistung oder der
Benutzung der Ausrüstung. Hewlett-Packard übernimmt keine Haftung fur den Betrieb oder die
Zuverlässigkeit seiner Software, wenn diese auf Hardware benutzt wird, die nicht von Hewlett-Packard
geliefert wurde. Dieses Dokument enthalt proprietäre Informationen, die durch das Copyright geschützt
sind. Alle Rechte vorbehalten. Dieses Dokument darf ohne vorherige schriftliche Genehmigung der
Hewlett-Packard Company weder ganz noch teilweise fotokopiert, reproduziert oder übersetzt werden.
Avertissement
Les informations contenues dans ce document peuvent être modifiées sans préavis.
Hewlett-Packard ne donne aucune garantie de quelque sorte que ce soit concernant, sans que ce soit
limitatif, les garanties implicites de qualité commerciale de ce matériel, ou la bonne adaptation de celui-
ci à un usage particulier. Hewlett-Packard n’est pas responsable des erreurs pouvant apparaître dans ce
manuel et n’est pas non plus responsable des dommages directs ou indirects résultant de l’équipement,
desperformances et de l’utilisation de cematériel.Hewlett-Packard nesauraitêtre tenu pour responsable
de l’utilisation et de la fiabilité de son logiciel sur des matériels non fournis par Hewlett-Packard. Les
informations contenues dans ce document sont originales et protégées par copyright. Tous droits
réservés. L’acheteur s’interdit en conséquence de les photocopier, de les reproduire ou de les traduire
dans toute autre langue, sauf accord préalable et écrit de Hewlett-Packard.
Aviso
La información contenida en este documento está sujeta a cambios sin previo aviso.
Hewlett-Packard no ofrece ningún tipo de garantía con respecto a este material, incluyendo, pero sin
limitarse a, las garantías implícitas de comerciabilidad e idoneidad para un fin determinado. Hewlett-
Packard no asume responsabilidad alguna por los posibles errores contenidos o por los daños casuales o
emergentes relacionados con el suministro, funcionamiento o uso de este material. Hewlett-Packard no
asume responsabilidad alguna por el uso o fiabilidad de su software en equipos que no hayan sido
fabricadospor Hewlett-Packard.Este documento contiene información patentada, protegida porlasleyes
del copyright. Reservados todos los derechos. Ninguna parte de este documento puede ser fotocopiada,
reproducida o traducida a otro idioma sin la autorización previa y por escrito de Hewlett-Packard
Company.
Avviso
Le informazioni contenute in questo documento sono soggette a cambiamento senza preavviso.
Hewlett-Packard non rilascia garanzie di alcun tipo riguardo a questo materiale, comprese le garanzie
implicite di commerciabilità e di idoneità per uno scopo particolare. Hewlett-Packard non sarà ritenuta
responsabile per errori contenuti in questo documento, né per danni accidentali o conseguenti alla
fornitura, alle prestazioni o all’uso di questo materiale. Hewlett-Packard non si assume alcuna
responsabilità riguardo all’uso o all’affidabilità del proprio software su apparecchiature di altri produttori.
Questo documento contiene informazioni di proprietà protette da copyright. Tutti i diritti sono riservati.
Nessuna parte di questo documento può essere fotocopiata, riprodotta o tradotta in un’altra lingua senza
un precedente consenso scritto di Hewlett-Packard Company.
Hewlett-Packard France, 38053 Grenoble, Cedex 9 France
© 1999 Hewlett-Packard Company
keyb.book Page ii Friday, May 28, 1999 10:30 AM

DraftFrancais
English . . . . . . . . . . . . . . . . Chapter 1
Deutsch. . . . . . . . . . . . . . . . Kapitel 2
Français . . . . . . . . . . . . . . . Chapitre 3
Español. . . . . . . . . . . . . . . . Capítulo 4
Italiano. . . . . . . . . . . . . . . . Capitolo 5
keyb.book Page iii Friday, May 28, 1999 10:30 AM

keyb.book Page iv Friday, May 28, 1999 10:30 AM

English 1
Chapter 1 - Your HP Multimedia Keyboard
Supported Platforms
This manual describes how to set up the HP multimedia keyboard and
configure the following operating systems supported by HP:
•Windows 95
•Windows 98
•Windows NT 4.0
To find out on which HP Business PCs you can install the HP multimedia
keyboard go to the following HP Web site:
Setting Up Your HP Multimedia Keyboard
1ShutdownyourPCthenconnecttheHPmultimediakeyboardtothePC.
Your PC’s audio connection panel may differ from the own shown here.
Color-coding is used on some PC’s to aid connection. Refer to your PC’s
User’s Guide for more information.
NOTE When you connect the keyboard jack to the rear of the PC, the PC’s internal
speaker, where fitted, is deactivated. You can then connect headphones or
speakers to the rear of the keyboard to have sound (go to the next step).
www.hp.com/go/pcaccessories
Microphone
Speakers/headphones
keyb.book Page 1 Friday, May 28, 1999 10:30 AM

2 English
NOTE To avoid discomfort from unexpected noise, always turn the volume down
before connecting headphones or speakers.
Listening to loud sounds for prolonged periods may permanently damage
your hearing. Before putting on headphones, place them around your neck
and turn the volume down. When you put on the headphones, slowly
increase the volume until you find a comfortable listening level, and leave
the volume control in that position.
2Connect the microphone and headphones/speakers to the keyboard.
The speakers and microphone shown here are not supplied with your PC.
NOTE Your PC may have a CD-ROM or DVD drive. Although these drives may have
a headphones socket and a volume control, use the keyboard sockets as
described in this section. This will ensure that you use all your PC’s
multimedia features.
Installing the Keyboard Support Software
Windows 95,
Windows 98 &
Windows NT 4.0
1Insert the first HP Extended Keyboard support software disk in your
floppy drive.
2From WindowsExplorer (or WindowsNTExplorerfor NT 4.0) double click on
3½ Floppy (A:).
3Double click on Setup.exe to begin installation.
4Follow the on screen instructions and insert other disks as prompted.
keyb.book Page 2 Friday, May 28, 1999 10:30 AM

English 3
Using Your HP Multimedia Keyboard
The HP multimedia keyboard includes soft keys you can use to:
•Display and configure the actions assigned to keys.
•Perform one-touch shortcuts to start applications, open files, or open
sites on the WWW.
•Launch the Internet browser supplied with your system.
•Lock your PC or PC Workstation.
•Access HP TopTools and customer information.
•Mute or adjust the volume of the audio system.
WindowsKey You can display the Windows 95 Start menu by pressing either of the two
Windows keys, positioned to the left and right of the space bar.
Application Key You can access all right-mouse button functions used to copy and move
files, display shortcut menus, and get Help information, by pressing the
Application key. The Application key can also be programmed by your
software.
“Power-on”
Function Note that the “Power-on” function only works on HP PCs that support this
function.
You can switch on your PC by pressing the space bar. You can enable and
disable the “Power-on” function from your PC’s Setup program (the default
is enabled). Please refer to the description of the Setup program in your
PC’s documentation.
Mail Key You can launch your default mail client by pressing this key. For MAPI-
based mail clients like Microsoft Outlook, the LED above this key blinks
when new mail is received. When the LED blinks, simply press the mail key
to view the newly arrived mail.
HP TopTools
Mail key
Menu key
Internet key Lock key
HPCustomer
Information
Mute Key
Volume Keys
Shortcut keys
keyb.book Page 3 Friday, May 28, 1999 10:30 AM

4 English
Shortcut Keys The shortcut soft keys can be used to start an application, open a
document, or open a site on the Internet. Actions can be assigned to the
shortcut keys by pressing the Menu key and clicking the key you want to
configure in the keyboard displayed on your screen.
HP TopTools Pressing this soft key opens HP TopTools on PCs that come with this
application. HP TopTools helps you manage your PC, reduce overall
ownership costs, and provides advanced PC management tools. For
example, it can be used for remote BIOS updates and security
management.
NOTE Before using HP TopTools for the first time on HP preloaded systems, you
must install it as follows: From the Start menu, select Programs, then
HP DMI, then Setup. TheHP TopTools application is installed automatically.
Internet Key This soft key is used to start the Web browser configured on your computer.
Menu Key Pressing the ?Menu soft key displays the soft key section of the HP
multimedia keyboard on your screen. Click any of the keys on the screen to
display the action assigned to an individual key or to change or assign an
action to a key. Shortcut keys are provided specifically for user-defined
actions.
Lock Key The action of the Lock key is configured by pressing the Menu Key, and
then clicking on Configure,the Extended Keys tab and the onscreen Lock
button. With HP Lock installed, the actions you canspecify for the Lock key
are:
•Lock the front panel.
•Launch screen saver
HP Customer
Information This soft key accesses HP Customer Information, which includes:
•Information on product features
•The preloaded software on the system
•Details on how to configure the HP multimedia keyboard
•Information on how to configure the WWW browser
•Detailed HP support information
•Links to the HP PC and PC Workstation Web sites.
Mute and Volume
Keys Pressing the Mute key mutes the audio, or restores the audio if it has been
muted. The Volume keys can be used to control the volume level.
keyb.book Page 4 Friday, May 28, 1999 10:30 AM

English 5
The Euro Symbol
The Euro Symbol
This section only applies if your keyboard comes with the Euro symbol key
(only available with certain language models).
Your keyboard’s Euro symbol key can only be used with Operating Systems
and applications that support this feature.
•Only the latest operating systems, such as Windows 98, provide
integrated support for the Euro symbol (in certain languages only).
•Not all applications support the Euro symbol.
•Not all fonts contain the Euro character.
WindowsNT4.0&
Windows95 Windows NT 4.0 and Windows 95 do not provide integrated support. For
more information on how to enable support of the Euro symbol, refer to
Microsoft’s web site at:
www.microsoft.com/windows/euro.asp
Windows98 Windows 98 has all the necessary fonts and built-in drivers to use the euro
symbol, provided that the user's peripherals (such as printers) were
designed to work with the euro. Printer fonts that support the euro symbol
include Times New Roman, Arial, and Courier New.
Configuring Your
Keyboard To configure your keyboard, go toSettings > Control Panel in the Start menu.
Double-click on Keyboard and select the Language or Input Locales tab in the
Keyboard Properties window. Click on Add and select the country that
corresponds with your keyboard, and click OK. Click OK to exit the Control
Panel.
HP Support Services
You can get help with solving problems with HP accessories from the
following HP support Web sites:
www.hp.com/go/vectrasupport
www.hp.com/go/kayaksupport
www.hp.com/go/briosupport
keyb.book Page 5 Friday, May 28, 1999 10:30 AM

HP Support Services
6 English
keyb.book Page 6 Friday, May 28, 1999 10:30 AM

keyb.book Page xxiii Friday, May 28, 1999 10:30 AM

Part Number
Printed in 5969-1956 06/99
Paper not bleached with chlorine
keyb.book Page xxiv Friday, May 28, 1999 10:30 AM
