HP 4510s - ProBook - Celeron 1.8 GHz User manual

An impressive combination of mobile office
features makes the newly-designed HP
ProBook 4510s Notebook PC an excellent
price-for-performance package.
Technology to get the job done
The HP ProBook 4510s Notebook PC boasts
a sleek design that packs an array of
features normally reserved for more
expensive notebooks. Available in a new
Merlot or glossy Noir finish with a more
spacious keyboard layout and separate
numeric keypad, it delivers refined simplicity
with a clean design and the latest Intel®
Core™2 Duo processors.3
The low-profile 15.6-inch diagonal, 16:9
LED-backlit HD6 display, gives you improved
brightness, contrast and clarity with a screen
that is more power-efficient than regular LCD
screens. Choose between high-performance
ATI discrete graphics, featuring dedicated
video memory, or integrated Intel UMA
graphics3 that balances memory usage
between graphics and the system.
Whether you’re across the street or across
the country, integrated HP Mobile
Broadband powered by Gobi,19 Wi-Fi
CERTIFIED™ WLAN7and Bluetooth® help
you stay connected.
HP Professional Innovations help you
focus on your business
Built to protect. Integrated, customizable
security solutions help defend your
network, your applications, and your data.
File Sanitizer for HP ProtectTools10 can
permanently delete individual files, folders
and personally identifiable information
from your notebook.
Built to simplify. HP QuickLook 211
provides read capability of email,
calendar, task and contact information in
seconds at the touch of a button, without
having to boot up.
Built to last. HP 3D DriveGuard helps
protect your notebook’s hard drive against
impact, bumps, or drops using a three-axis
accelerometer which detects any sudden
movement and initiates protective action,
so your critical information is protected
while you are on the move.
Built to conserve. HP Business Notebook
PCs are designed to reduce their impact
on the environment by eliminating or
reducing substances of concern, using
fewer resources, reducing energy
consumption, and designing for
recyclability.
HP recommends Windows Vista®Business
HP ProBook 4510s Notebook PC
Stylish
affordability.
15.6-inch
diagonal
high-definition6
display,
Intel processors

HP ProBook 4510s Notebook PC
HP recommends Windows Vista®Business
Operating system Preinstalled:
Genuine Windows Vista®Business 321
Genuine Windows Vista®Home Basic 321
Genuine Windows Vista®Home Premium 321
Genuine Windows Vista®with downgrade
to Genuine Windows®XP Professional custom installed1,2
SUSE Linux
FreeDOS
Red Flag Linux (PRC only)
Supported:
Genuine Windows Vista®Business 641
Certified:
SuSE Linux Enterprise Desktop 10
Processor Intel®CoreTM2 Duo3 (up to 2.8 GHz, 6 MB L2 cache), Intel®Celeron®Dual-Core (up to 1.83 GHz, 1 MB L2
cache), Intel®Celeron®(up to 2.20 GHz, 1 MB L2 cache)
Chipset Mobile Intel PM45 Express Chipset, Mobile Intel GM45 Express Chipset, Mobile Intel GL40 Express Chipset
Memory DDR2 SDRAM, 800 MHz, two slots supporting dual channel memory, 1024/2048/4096 MB SODIMMs, up to
8192 MB total (Up to 4096 MB max on GL40 Chipset)13
Internal Storage14 160/250/320/500 GB 5400 rpm SATA HDD, 160/250 GB 7200 rpm SATA HDD; (with HP 3D DriveGuard)
Removable
Storage
Fixed 12.7-mm SATA optical drive: Blu-ray ROM DVD+/-RW SuperMulti DL LightScribe Drive,5DVD+/–RW
SuperMulti DL LightScribe Drive, DVD-ROM Drive4
Display 15.6-inch diagonal LED-backlit HD6(1366 x 768), 15.6-inch diagonal LED-backlit HD6(1366 x 768)
BrightView
Graphics9Mobile Intel GMA 4500MHD,ATI Mobility RadeonTM HD 4330, with 512 MB dedicated video memory (1024
MB HyperMemory*)
*Indicates dedicated video memory and shared system memory. 512 MB dedicated video memory.
Audio/Visual High Definition Audio, stereo speakers, stereo headphone/line out, stereo microphone in, integrated
microphone; optional integrated 2 MP webcam
Wireless
support7,8,19
Optional HP un2400 EV-DO/HSPA Mobile Broadband Module (requires mobile network operator service) with
HP Connection Manager; Intel 802.11 a/b/g/n draft 2.0, a/b/g; Broadcom 802.11 a/b/g/n draft 2.0, b/g;
Bluetooth™ 2.0, HP Wireless Assistant
Communications15 Marvell Ethernet (10/100/1000 NIC), optional 56K v.92 modem
Expansion slots (1) ExpressCard/34 slot, Media Card Reader
Ports and
connectors
(4) USB 2.0 ports, VGA, HDMI, stereo microphone in, stereo headphone/line out, power connector,
RJ-11/modem, RJ-45/ethernet
Input device Full-sized keyboard with separate numeric keypad, touchpad with scroll zone
Software HP Recovery Manager, HP QuickLook 2,11 HP SoftPaq Download Manager, Roxio Creator Business (for optional
DVD+/-RW and DVD/CDRW drives)
Security HP ProtectTools, Device Access Manager, Enhanced Pre-Boot Security, HP Spare Key, HP Disk Sanitizer,14 Drive
Encryption for HP ProtectTools, Credential Manager for HP ProtectTools, File Sanitizer for HP ProtectTools,14
Kensington Lock slot, McAfee Security Solution18
Dimensions 1.24 (at front) x 14.6 x 9.83 in / 31.5 (at front) x 371.8 x 249.6 mm
Weight Starting at: 5.7 lb / 2.59 kg (or 5.2 lb / 2.36 kg with no optical drive; weight will vary by configuration)
Power 8-cell (63 WHr) Lithium-Ion battery, 6-cell (47 WHr) Lithium-Ion battery, 90W HP Smart AC Adapter (Discrete),
65W HP Smart AC Adapter, HP Fast Charge16
Expansion
Solutions17 HP USB 2.0 Docking Station, HP Essential USB Port Replicator, HP Basic Adjustable Stand
Warranty Limited 1-year and 90-day warranty options available, depending on country, 1-year limited warranty on
primary battery. Optional HP Care Pack Services are extended service contracts which go beyond your standard
warranties.
For more details visit: http://www.hp.com/go/lookuptool.

2 MP Webcam (optional)
Inte
g
rated numeric keypad
HDMI port
Media card reader
ExpressCard/34 slot
Full-size, user-friendly
QWERTY keyboard
Low-profile 15.6-inch
diagonal, LED-backlit HD6
display
HP ProBook 4510s Notebook PC
HP recommends Windows Vista®Business

HP ProBook 4510s Notebook PC
HP recommends Windows Vista®Business
© 2009 Hewlett-Packard Development Company, L.P. The information contained herein is subject to change without notice. The
only warranties for HP products and services are set forth in the express warranty statements accompanying such products and
services. Nothing herein should be construed as constituting an additional warranty. HP shall not be liable for technical or
editorial errors or omissions contained herein. Bluetooth is a trademark of its proprietor and used by Hewlett-Packard Company
under license. Microsoft, Windows and Vista are trademarks of the Microsoft group of companies. Intel and Core are trademarks
or registered trademarks of Intel Corporation or its subsidiaries in the U.S. and other countries. To learn more, visit www.hp.com
March 2009
1. Certain Windows Vista product features require advanced or additional hardware. See
www.microsoft.com/windowsvista/getready/hardwarereqs.mspx and
www.microsoft.com/windowsvista/getready/capable.mspx for details. Windows Vista Upgrade Advisor can help you determine
which features of Windows Vista will run on your computer. To download the tool, visit www.windowsvista.com/upgradeadvisor.
2. Windows Vista Business disk may be included for future upgrade if desired. To qualify for this downgrade an end user must be a
business (including governmental or educational institutions) and is expected to order at least 25 customer systems with the same
custom image.
3. Dual Core is a technology designed to improve performance of certain software products. Not all customers or software
applications will necessarily benefit from use of this technology 64-bit computing on Intel architecture requires a computer system
with a processor, chipset, BIOS, operating system, device drivers and applications enabled for Intel® 64 architecture. Processors
will not operate (including 32-bit operation) without an Intel 64 architecture-enabled BIOS. Performance will vary depending on
your hardware and software configurations.
4. Double-layer discs can store more data than single layer discs. However, double-layer discs burned with this drive may not be
compatible with many existing single-layer DVD drives and players. LightScribe media required and sold separately. LightScribe
creates a monochrome image. Note that DVD-RAM cannot read or write to 2.6GB single-sided/5.2 GB double-sided – version
1.0 media. Don’t copy copy-right protected materials.
5. As Blu-Ray is a new format containing new technologies, certain disc, digital connection, compatibility and/or performance issues
may arise, and do not constitute defects in the product. Flawless playback on all systems is not guaranteed. HD-DVD movies cannot
be played on this device. Models with integrated graphics require Mobile Intel GM45 Express chipset and Windows Vista to
support the Blu-Ray DVD drive; models with discrete graphics support it with either Windows Vista or Windows XP.
6. HD content required to view HD images
7. Wireless access point and Internet service is required and is not included. Availability of public wireless access points limited
8. The specifications for the 802.11n WLAN are draft specifications and are not final. If the final specifications differ from the draft
specifications, it may affect the ability of the notebook to communicate with other 802.11n WLAN devices.
9. Shared video memory (UMA) uses part of the total system memory for video performance. System memory dedicated to video
performance is not available for other use by programs.
10. For the use cases outlined in the DOD 5220.22-M Supplement.
11. HP QuickLook 2 is accessible when the notebook is off or in hibernation from Windows XP or Vista. Timings may vary
depending on the system configuration.
12. Dual Channel is only supported when the system is configured with DDR2 symmetric memory (i.e. 2x256).
13. 32-bit operating systems can only address ~3.2 GB. To fully utilizing memory configurations of 4GB or more, a 64-bit operating
system is required.
14. For hard drives, GB = 1 billion bytes. Actual formatted capacity is less. Up to 8 GB (for XP) and 10 GB (for Vista) of system disk is
reserved for the system recovery software.
15. The term "10/100/1000" or "Gigabit" Ethernet indicates compliance with IEEE standard 802.3ab for Gigabit Ethernet, and does
not connote actual operating speed of 1 Gb/sec. For high speed transmission, connection to a Gigabit Ethernet server and
network infrastructure is required.
16. HP Fast Charge recharges your primary battery up to 90% within 90 minutes when the system is off.
17. Sold separately or purchased as an optional feature.
18. 60 day trial period. Internet access required to receive updates. First update included. Subscription required for updates.
19. Gobi wireless technology requires separately purchased wireless data service contracts. Check with local service provider for
coverage and availability in your area. . Connection speeds will vary due to location, environment, network conditions, and other
factors.
