HP Chromebook x360 14 Assembly instructions

EL-MF877-00 Page 1
Template Revision B
PSG instructions for this template are available at EL-MF877-01
Product End-of-Life Disassembly Instructions
Product Category: Notebooks and Tablet PCs
Marketing Name / Model
[List multiple models if applicable.]
HP Chromebook x360 14;
HP Chromebook x360 14X*
HP Chromebook x360 14 G1
HP Chromebook Enterprise x360 14E G1
Name / Model #5
Purpose: The document is intended for use by end-of-life recyclers or treatment facilities. It provides the basic instructions
for the disassembly of HP products to remove components and materials requiring selective treatment, as defined by EU
directive 2002/96/EC, Waste Electrical and Electronic Equipment (WEEE).
1.0 Items Requiring Selective Treatment
1.1 Items listed below are classified as requiring selective treatment.
1.2 Enter the quantity of items contained within the product which require selective treatment in the right column, as
applicable.
Item Description
Notes
Quantity
of items
included
in product
Printed Circuit Boards (PCB) or Printed Circuit
Assemblies (PCA)
With a surface greater than 10 sq cm
MB & IO PCB
2
Batteries
All types including standard alkaline and lithium
coin or button style batteries battery
1
Mercury-containing components
For example, mercury in lamps, display backlights,
scanner lamps, switches, batteries
Liquid Crystal Displays (LCD) with a surface
greater than 100 sq cm
Includes background illuminated displays with gas
discharge lamps LCD
1
Cathode Ray Tubes (CRT)
Capacitors / condensers (Containing PCB/PCT)
Electrolytic Capacitors / Condensers measuring
greater than 2.5 cm in diameter or height
External electrical cables and cords
Power cords,Adapter
2
Gas Discharge Lamps
Plastics containing Brominated Flame Retardants
weighing > 25 grams (not including PCBs or PCAs
already listed as a separate item above)

EL-MF877-00 Page 2
Template Revision B
PSG instructions for this template are available at EL-MF877-01
Components and parts containing toner and ink,
including liquids, semi-liquids (gel/paste) and toner
Include the cartridges, print heads, tubes, vent
chambers, and service stations.
Components and waste containing asbestos
Components, parts and materials containing
refractory ceramic fibers
Components, parts and materials containing
radioactive substances
2.0 Tools Required
List the type and size of the tools that would typically be used to disassemble the product to a point where components
and materials requiring selective treatment can be removed.
Tool Description
Tool Size (if
applicable)
Description #1
Philip #1 /
TORX T
Description #2
Philip #0 /
TORX T
Description #3
Description #4
Description #5
3.0 Product Disassembly Process
3.1 List the basic steps that should typically be followed to remove components and materials requiring selective treatment:
1. Remove Log Low
2. Remove Battery pack
3. Remove FAN & HEAT PIPE
4. Remove Hinge up
5. Remove Motherboard
6. Remove IO PCB
7. Remove Speaker module & K-lock bracket
8. Remove LCD Cover
9. Remove EDP cable / TS / Camera trans / G sensor PCB
10. Remove Antenna
11. Remove Hinge
12. Remove Hinge Cap
3.2 Optional Graphic. If the disassembly process is complex, insert a graphic illustration below to identify the items
contained in the product that require selective treatment (with descriptions and arrows identifying locations).

EL-MF877-00 Page 3
Template Revision B
PSG instructions for this template are available at EL-MF877-01
Step1 Remove Log Low Step2 Remove Battery pack
Step3 Remove FAN & HEAT PIPE Step4 Remove Hinge up
Step5 Remove Motherboard Step6 Remove IO PCB

EL-MF877-00 Page 4
Template Revision B
PSG instructions for this template are available at EL-MF877-01
Step7 Remove Speaker module & K-lock bracket Step8 Remove LCD Cover
Step9 Remove EDP cable / TS / Camera trans / G sensor PCB Step10 Remove Antenna
Step11 Remove Hinge Step12 Remove Hinge Cap
