HP Compaq Presario Manual

3-44 Volume Two
Presario 3000
System Board Assembly Spare Part System
System Board 005492-001 240906-001 All
Configuration Jumper Settings (005492)
Jumper Pins Function
P7 Replacement Battery Connector
P8 Processor
75MHz
90MHz, 120MHz, 150MHz
100MHz, 133MHz, 166MHz, 200MHz
1 - 2
2 - 3
3 - 4
Clock Speed Select
50MHz
60MHz
66MHz
P9 Processor
75MHz, 90MHz, 100MHz
120MHz, 133MHz
150MHz, 166MHz
200MHz
A1-A2
B1-B2
A2-A3
B1-B2
A2-A3
B2-B3
A1-A2
B2-B3
CPU Clock Multiplier
1.5x
2.0X
2.5X
3.0X
P11 CMOS Erase/Password Clear
Configuration
Code Assembly System Board Spare Part Model
GZC5 005492-001 240906-001 3060
GZF2 005492-001 240906-001 3020
GZF3 005492-001 240906-001 3020
GZF4 005492-001 240906-001 3020
GZF5 005492-001 240906-001 3020
GZF6 005492-001 240906-001 3020
GZF9 005492-001 240906-001 3020
Microprocessor Assembly Spare Part System
P54C/166, 66MHz 251591-003 243134-001 All
P55C/166MMX, 66MHz 240167-001 240181-001 3060 (JPN)
P55C/200, 66MHz 240167-002 240181-002 3060
P54C Heat Sink 172944-001 214097-001 3020
P55C Heat Sink 240167-001 238247-001 3060
Memory Assembly Spare Part System
4 MB SIMM, EDO, 60ns, Tin/Lead
Contacts1185173-002 236512-001 All
8 MB SIMM, EDO, 60ns, Tin/Lead
Contacts 185172-002 236513-001 All
1 MB Video Memory 004827-001 213859-001 All
Cache, 256K, 16OP 237716-001 243117-001 All
1Two each shipped in each model.

Volume Two 3-45
Presario 3000
Miscellaneous Assembly Spare Part System
Keyboard, NA English 237743-401 240992-401 All
Speaker Kit 239511-001 240989-001 All
Riser Board 005556-001 240908-001 All
Mouse Remote 241015-001 241028-001 All
Mouse Remote Receiver 241016-001 241029-001 All
Display Panel 240925-001 241195-001 All
Display Enclosure * 241196-001 All
Display Bezel, Front 240929-001 241197-001 All
Microphone w/ Cable 241525-004 241068-001 All
* Complete assembly (except display).
Controller Boards Assembly Spare Part System
Graphics 240907-001 All
Wavetable 004824-001 213858-001 All
Hard Drives Spare Part System
3.8 GB, IDE 238475-001 3060
2.0 GB, IDE 241174-001 3020
CD-ROM Drive Assembly Spare Part System
CD-ROM, IDE, 6-spd, Multiplatter,
Ivory 185679-406 185680-406 All
Diskette Drives Spare Part System
1.44 MB, 3.5,” Gray 160788-301 All
33.6k-bps Modem
(+FDSP+TAM ISA) Assembly Spare Part Cable Spare Part System
APD 221500-001 221506-371 137256-001 All
Australia 005671-103 225259-011 165224-012 All
France 005671-102 225259-051 165224-051 All
Germany 005671-103 225259-041 165224-041 All
Italy 005671-102 225259-061 165224-061 All
JPN/LTNA 221500-001 221506-191 137256-001 All
NA 221500-001 221506-001 165224-001 All
Netherlands 005671-104 225259-331 165224-331 All
Sweden 005671-103 225259-101 165224-101 All
Switzerland 005671-103 225259-111 165224-111 All
U Kingdom 005671-101 225259-031 165221-032 All
Cables Spare Part System
Diskette Drive Cable, 15” 241097-001 All
Cable Kit: CD-Audio, CD, HD, Diskette, Serial Port, Mic
Intermediate, RF Module, RF Antenna, Button Board 241095-001 All
Hard Drive Cable, 10” 241096-001 All
Audio Cable 241176-001 All
Mic Intermediate 241094-001 All
Serial Port 171141-002 All
CD-ROM Drive 241177-001 All
RF Module Cable 241180-001 All
RF Antenna Cable 241179-001 All
Button Board Cable 241178-001 All

3-46 Volume Two
Presario 3000
ROM Information Spare Part System
System ROMPaq 148218-001 All
Power Supply/Battery Spare Part System
Power Supply, 230 VAC PCF 241071-001 All
Real-Time Clock Battery (4.5 v alkaline) 160274-001 All

Volume Two 3-47
Presario 3000
MEMORY UPGRADE CHART
I/O BOARD
005492
(8 MB)
MAXIMUM SYSTEM MEMORY IS 128 MB
8-MB EDO 60ns - OPTION PN 236548-001
Memory upgrade SIMMs must be installed in pairs.
Use SIMMs with tin/lead contacts only. EDO Simms
are recommended for all system boards.
