HP Compaq Notebook series User guide

Compaq Notebook Series
Startup Guide

ii Startup Guide
Notice
© 2002 Hewlett-Packard Company.
Microsoft, MS-DOS, and Windows are trademarks of Microsoft Corporation in the
U.S. and/or other countries.
All other product names mentioned herein may be trademarks of their respective
companies.
This product incorporates copyright protection technology that is protected by
method claims of certain U.S. patents and other intellectual property rights owned by
Macrovision Corporation and other rights owners. Use of this copyright protection
technology must be authorized by Macrovision Corporation and is intended for home
and other limited viewing uses only unless otherwise authorized by Macrovision
Corporation. Reverse engineering or disassembly is prohibited.
HP shall not be liable for technical or editorial errors or omissions contained herein.
The information is provided “as is” without warranty of any kind, and is subject to
change without notice. The warranties for HP products are set forth in the express
limited warranty statements accompanying such products. Nothing herein should be
construed as constituting an additional warranty.
Compaq Notebook Series Startup Guide
First Edition (December 2002)
Reference Number: 2100/2500/N1050v
Part Number: 311027-001

Startup Guide iii
Important Safety Information
CAUTION To reduce the risk of fire, use only No. 26 AWG or larger telecommunications
line cord to connect a modem to the telephone wall jack. In Australia, the
notebook must be connected to the Telecommunication Network through a line
cord that meets the requirements of ACA Technical Standard TS008.
When using your notebook with a telephone connection, always follow basic safety
precautions to reduce the risk of fire, electric shock, and injury to persons.
• Do not use this product with a telephone connection near water (for example,
near a bathtub, sink, swimming pool, or in a wet basement).
• Avoid using a telephone connection (other than a cordless type) during an
electrical storm. There may be a remote risk of electric shock from lightning.
• Do not use a telephone connection to report a gas leak in the vicinity of the leak.
• Use only the power cord and batteries indicated in this manual. Do not dispose of
batteries in a fire. They may explode. Check with local codes for possible special
disposal instructions.
• Disconnect the modem cable before opening the notebook case or touching an
uninsulated modem cable, jack, or internal component.
• Do not plug a modem cable or telephone cable into the network (LAN)
receptacle.
WARNING This is a Class B digital device, pursuant to Part 15 of the FCC Rules. For
more Class B information, refer to the Reference Guide on the Documentation
Library CD.

iv Startup Guide
Software Product License Agreement
Your HP product contains software programs. CAREFULLY READ THIS
LICENSE AGREEMENT BEFORE PROCEEDING TO OPERATE THIS
EQUIPMENT. RIGHTS IN THE SOFTWARE ARE OFFERED ONLY ON THE
CONDITION THAT THE CUSTOMER AGREES TO ALL TERMS AND
CONDITIONS OF THE LICENSE AGREEMENT. PROCEEDING TO OPERATE
THE EQUIPMENT INDICATES YOUR ACCEPTANCE OF THESE TERMS
AND CONDITIONS. IF YOU DO NOT AGREE WITH THE TERMS OF THE
LICENSE AGREEMENT, YOU MUST NOW EITHER REMOVE THE
SOFTWARE FROM YOUR HARD DISK DRIVE AND DESTROY THE
MASTER DISKETTES, OR RETURN THE COMPLETE HP PRODUCT AND
SOFTWARE FOR A FULL REFUND. PROCEEDING WITH CONFIGURATION
SIGNIFIES YOUR ACCEPTANCE OF THE LICENSE TERMS.
UNLESS OTHERWISE STATED BELOW, THIS HP SOFTWARE LICENSE
AGREEMENT SHALL GOVERN THE USE OF ALL SOFTWARE THAT IS
PROVIDED TO YOU AS PART OF THE HP PRODUCT AND SHALL
SUPERSEDE ANY OTHER SOFTWARE WARRANTY STATEMENT THAT
MAY BE INCLUDED IN THIS HP PRODUCT OR MAY BE FOUND ONLINE.
Operating system and software applications by Microsoft are licensed to you under
the Microsoft License Agreement contained in the Microsoft documentation or
displayed on your screen when Microsoft Software Products are launched.
For a PC supplied with a Microsoft operating system: When you start the PC and
accept the Microsoft End-user License Agreement (“EULA”), your license rights are
valid only if a Certificate of Authenticity (“COA”) label corresponding to your
Microsoft operating system is provided with your PC. The COA label can usually be
found on the bottom of the notebook. If the COA label does not correspond to your
Microsoft operating system or is missing, contact your HP reseller for details.
Other non-HP Software and Operating Systems are covered by the appropriate
vendor license. The following License Terms govern the use of the HP software:
USE. Customer may use the software on any one HP product. Customer may not
network the software or otherwise use it on more than one HP product. Customer
may not reverse assemble or decompile the software unless authorized by law.
COPIES AND ADAPTATIONS. Customer may make copies or adaptations of the
software (a) for archival purposes or (b) when copying or adaptation is an essential
step in the use of the software with an HP product so long as the copies and
adaptations are used in no other manner.

Startup Guide v
OWNERSHIP. Customer agrees that he/she does not have any title or ownership of
the software, other than ownership of the physical media. Customer acknowledges
and agrees that the software is copyrighted and protected under the copyright laws.
Customer acknowledges and agrees that the software may have been developed by a
third party software supplier named in the copyright notices included with the
software, who shall be authorized to hold the Customer responsible for any copyright
infringement or violation of this Agreement.
PRODUCT RECOVERY CD-ROM or DVD. If your HP product was shipped with a
product recovery CD-ROM or DVD: (i) The product recovery CD-ROM or DVD
and/or support utility software may only be used for restoring the hard disk of the HP
product with which the product recovery CD-ROM or DVD was originally provided.
(ii) The use of any operating system software by Microsoft contained in any such
product recovery CD-ROM or DVD shall be governed by the Microsoft License
Agreement.
TRANSFER OF RIGHTS IN SOFTWARE. Customer may transfer rights in the
software to a third party only as part of the transfer of all rights and only if Customer
obtains the prior agreement of the third party to be bound by the terms of this
License Agreement. Upon such a transfer, Customer agrees that his/her rights in the
software are terminated and that he/she will either destroy his/her copies and
adaptations or deliver them to the third party.
SUBLICENSING AND DISTRIBUTION. Customer may not lease, sublicense
the software or distribute copies or adaptations of the software to the public in
physical media or by telecommunication without the prior written consent of
Hewlett-Packard.
TERMINATION. Hewlett-Packard may terminate this software license for failure to
comply with any of these terms provided Hewlett-Packard has requested Customer to
cure the failure and Customer has failed to do so within thirty (30) days of such
notice.
UPDATES AND UPGRADES. Customer agrees that the software does not include
updates and upgrades which may be available from Hewlett-Packard under a
separate support agreement.
EXPORT CLAUSE. Customer agrees not to export or re-export the software or any
copy or adaptation in violation of the U.S. Export Administration regulations or
other applicable regulation.

vi Startup Guide
U.S. GOVERNMENT RESTRICTED RIGHTS. Use, duplication, or disclosure is
subject to HP standard commercial license terms and for non-DOD Departments and
Agencies of the U.S. Government, the restrictions set forth in FAR 52.227-19(c)(1-2)
(June 1987) Hewlett-Packard Company, 3000 Hanover Street, Palo Alto, CA 94304
U.S.A. Copyright (c) 2000 Hewlett-Packard Company. All Rights Reserved.
Customer further agrees that Software is delivered and licensed as “Commercial
notebook software” as defined in DFARS 252-227-7014 (June 1995) or as a
“commercial item” as defined in FAR 2.101(a), or as “Restricted notebook software”
as defined in FAR 52.227-19 (or any equivalent agency regulation or contract
clause), whichever is applicable. The Customer agrees that it has only those rights
provided for such Software by the applicable FAR or DFARS clause or the HP
standard software agreement for the product involved.
SUPPORT POLICY FOR MICROSOFT OPERATING SYSTEMS SERVICE
PACK. HP will provide end user support for HP PCs that use Microsoft Operating
Systems, including its latest service packs. This support will be available 30 days
after the service pack being released by Microsoft.

Startup Guide vii
Contents
Getting Started with Your Notebook..........................................................................1
Identifying Parts of the Notebook .........................................................................2
Series 2100 and N1050v..................................................................................2
Series 2500 ......................................................................................................5
Status Lights ....................................................................................................8
Setting Up Your Notebook..................................................................................10
Step 1: Insert the battery................................................................................10
Step 2: Connect AC power ............................................................................11
Step 3: Connect a phone line .........................................................................12
Step 4: Turn on the notebook.........................................................................13
Step 5: Set up Windows.................................................................................13
Using the Documentation Library CD ................................................................14
Basic Operation........................................................................................................15
Operating Your Notebook...................................................................................16
Default power settings ...................................................................................17
To reset the notebook ....................................................................................18
To change the boot device .............................................................................18
To use the TouchPad .....................................................................................19
To use the function hot keys..........................................................................20
Using CDs or DVDs............................................................................................21
To play DVD movies.....................................................................................21
Batteries and Power Management...........................................................................23
Using Battery Power ...........................................................................................24
To check battery status ..................................................................................24
To respond to a low-battery warning.............................................................25
To recharge the battery ..................................................................................25

viii Startup Guide
Troubleshooting and Maintenance .........................................................................27
Troubleshooting Your Notebook.........................................................................28
Display problems...........................................................................................28
Hard disk drive problems ..............................................................................29
Keyboard and pointing device problems .......................................................29
Performance problems...................................................................................30
Power and battery problems ..........................................................................30
Startup problems............................................................................................31
Configuring Your Notebook ...............................................................................32
To run the BIOS Setup utility........................................................................32
Reinstalling and Updating Software....................................................................33
Index.........................................................................................................................35

Startup Guide 1
Getting Started with Your Notebook

Getting Started with Your Notebook
Identifying Parts of the Notebook
2 Startup Guide
Identifying Parts of the Notebook
Series 2100 and N1050v
NOTE Components included with the notebook may vary by geographical region and the
features you selected. The following illustrations identify the standard external
components included with most notebook models.
1 Notebook open/close latch.
2 One-Touch buttons.
3 Keyboard status lights.
4 Power button. Turns the notebook on and off.
5 TouchPad, scroll pad, Click buttons, and
on-off button.
6 Main status lights (left to right): power mode,
hard disk activity, and battery.
7 Hard disk drive.
8 Infrared port (select models only).
9 Wireless on-off button and indicator light
(select models only).
10 Battery.
11 CD-ROM, DVD, or other drive.
12 PS/2 port.

Getting Started with Your Notebook
Identifying Parts of the Notebook
Startup Guide 3
13 AC adapter jack.
14 Universal serial bus ports (USB).
15 RJ-45 jack. Connects a network cable.
16 S-video out jack.
17 Parallel port (LPT1). Use this port for a
parallel printer or other parallel device.
18 Serial port (COM1). Use this port for a serial
mouse, modem, printer, or other serial
device.
19 External monitor port.
20 Kensington lock slot (security connector).
21 RJ-11 jack. Connects the modem cable.
22 PC Card and CardBus slot and button.
23 IEEE 1394 port (select models only).
24 Audio jacks (left to right): external
microphone, audio out (headphones).
25 Volume control.
26 Audio mute button and audio mute light.
27 Floppy disk drive (select models only).

Getting Started with Your Notebook
Identifying Parts of the Notebook
4 Startup Guide
28 Hard disk drive.
29 Battery latch.
30 RAM (memory) cover.
31 Reset button.
32 Docking port (select models only).
33 Mini-PCI cover (no user parts inside).

Getting Started with Your Notebook
Identifying Parts of the Notebook
Startup Guide 5
Series 2500
1 Notebook open/close latch.
2 One-Touch buttons.
3 Keyboard status lights.
4 Power button. Turns the computer on and off.
5 TouchPad, scroll pad, Click buttons, plus on-off
button.
6 Main status lights (left to right): power mode,
hard disk activity, and battery.
7 Infrared port (select models only).
8 Wireless on-off button and indicator light
(select models only).
9 Battery.
10 Audio mute button, audio mute light, and
volume control.
11 Audio jacks (left to right): audio out
(headphones), external microphone.
12 CD-ROM, DVD, or other drive.
13 Universal serial bus port (USB).

Getting Started with Your Notebook
Identifying Parts of the Notebook
6 Startup Guide
14 AC adapter jack.
15 Two USB ports.
16 RJ-45 network jack. Connects a network
cable.
17 PS/2 port.
18 Parallel port (LPT1). Use this port for a
parallel printer or other parallel device.
19 External monitor port.
20 S-video out jack.
21 Kensington lock slot (security
connector).
22 RJ-11 jack. Connects a modem cable.
23 IEEE 1394 port (select models only).
24 PC Card and CardBus slot and buttons.
25 Floppy disk drive (select models only).

Getting Started with Your Notebook
Identifying Parts of the Notebook
Startup Guide 7
26 Hard disk drive.
27 Battery latch.
28 Mini-PCI cover (no user parts inside).
29 RAM (memory) cover.
30 Docking port (select models only).
31 Reset button.

Getting Started with Your Notebook
Identifying Parts of the Notebook
8 Startup Guide
Status Lights
The notebook includes a number of status lights that report power and battery status,
drive activity, and keyboard functions such as Caps Lock and Num Lock.
The following diagram shows the main status lights on the front of the notebook.
1 Power mode.
• On: the notebook is on (even if the display is off).
• Blinking: the notebook is in Standby.
• Off: the notebook is off or in Hibernation.
2 Hard disk drive activity.
On: notebook is accessing the hard disk drive.
3 Battery status.
• Green: the AC adapter is connected and the battery is fully charged.
• Amber: the AC adapter is connected and the battery is charging.
• Blinking: the AC adapter is connected and the battery is missing or has a
fault.
• Off: the AC adapter is not connected.

Getting Started with Your Notebook
Identifying Parts of the Notebook
Startup Guide 9
The keyboard status lights, located above the keyboard, indicate the states of the
keyboard locks.
1 Caps Lock On: Caps Lock is active.
2 Num Lock On: Num Lock is active. (The Keypad Lock must also be on to use
the embedded keypad.)
3 Keypad Lock On: The embedded keypad is active (Fn+F8). Num Lock must
also be on for the numeric keys. Otherwise, cursor control is active (as marked
on an external keyboard).

Getting Started with Your Notebook
Setting Up Your Notebook
10 Startup Guide
Setting Up Your Notebook
WARNING Improper use of keyboards and other input devices has been associated with
ergonomic injury.
If you are using your notebook as your primary computer, or using it for
extended periods, you should use it with a full-sized keyboard, monitor, and
mouse. Docking accessories offer quick, easy connections to these devices. This
can reduce the risk of ergonomic injury.
For information about setting up a safe and comfortable work environment,
see the Safety & Comfort Guide on this CD.
When you set up your notebook for the first time, you’ll charge the battery, connect
the AC adapter, turn on the notebook, and run the Windows setup program.
Step 1: Insert the battery
WARNING Do not mutilate or puncture batteries. Do not dispose of batteries in fire, or
they can burst or explode, releasing hazardous chemicals. Rechargeable
batteries must be recycled or disposed of properly.
Your notebook is shipped with the battery installed. If the battery has been removed,
you should install it:
1. Turn the notebook upside down.
2. Insert the connector end of the battery into the battery compartment and slide it in
until it latches.

Getting Started with Your Notebook
Setting Up Your Notebook
Startup Guide 11
Step 2: Connect AC power
CAUTION Use only the AC adapter included with your notebook (or other approved
adapter that meets the power requirements of the notebook).
Using the wrong AC adapter could damage the notebook or adapter, cause
data loss, and may void your warranty. (See the printed document Worldwide
Limited Warranty and Technical Support that came with the notebook.)
1. Plug the AC adapter into the notebook.
2. Connect the power cord to the AC adapter.
3. Plug the power cord into a wall outlet.
The notebook battery then starts charging.
Important When unplugging the power cord, unplug it from the outlet before unplugging it
from the AC adapter.
While the battery is charging, you can continue with step 3.

Getting Started with Your Notebook
Setting Up Your Notebook
12 Startup Guide
Step 3: Connect a phone line
1. Make sure the telephone line is an analog line, sometimes called a data line. (You
must not use a digital line.)
2. Connect the telephone cord (RJ-11) into a telephone jack
3. Plug the other end of the phone cord into the RJ-11 modem jack in the side of the
notebook.
For details about using the modem, including AT commands, see the Reference
Guide on the Documentation Library CD included with your notebook.
