HP EliteBook 820 G2 Installation instructions

Product End-of-Life Disassembly Instructions
Product Category: Notebooks and Tablet PCs
Marketing Name / Model
[List multiple models if applicable.]
HP Elitebook 820 G2 Notebook PC
Purpose: The document is intended for use by end-of-life recyclers or treatment facilities. It provides the basic instructions
for the disassembly of HP products to remove components and materials requiring selective treatment, as defined by EU
directive 2002/96/EC, Waste Electrical and Electronic Equipment (WEEE).
1.0 Items Requiring Selective Treatment
1.1 Items listed below are classified as requiring selective treatment.
1.2 Enter the quantity of items contained within the product which require selective treatment in the right column, as
applicable.
Item Description Notes
Quantity
of items
included
in product
Printed Circuit Boards (PCB) or Printed Circuit
Assemblies (PCA)
With a surface greater than 10 sq cm
1
Batteries
All types including standard alkaline and lithium coin
or button style batteries
2
Mercury-containing components
For example, mercury in lamps, display backlights,
scanner lamps, switches, batteries
0
Liquid Crystal Displays (LCD) with a surface greater
than 100 sq cm
Includes background illuminated displays with gas
discharge lamps
1
Cathode Ray Tubes (CRT)
0
Capacitors / condensers (Containing PCB/PCT)
0
Electrolytic Capacitors / Condensers measuring
greater than 2.5 cm in diameter or height
0
External electrical cables and cords
0
Gas Discharge Lamps
0
Plastics containing Brominated Flame Retardants
weighing > 25 grams (not including PCBs or PCAs
already listed as a separate item above)
0
Components and parts containing toner and ink,
including liquids, semi-liquids (gel/paste) and toner
Include the cartridges, print heads, tubes, vent
chambers, and service stations.
0
Components and waste containing asbestos
0
Components, parts and materials containing
refractory ceramic fibers
0
EL-MF877-00 Page 1
Template Revision B
PSG instructions for this template are available at EL-MF877-01

Components, parts and materials containing
radioactive substances
0
2.0 Tools Required
List the type and size of the tools that would typically be used to disassemble the product to a point where components
and materials requiring selective treatment can be removed.
Tool Description
Tool Size (if
applicable)
Screwdriver #1
Cross head
of screwdriver
Support fixture
NA
Description #3
Description #4
Description #5
3.0 Product Disassembly Process
3.1 List the basic steps that should typically be followed to remove components and materials requiring selective treatment:
1. Follow steps described in Disassembly instruction (file attached)
2. If parts can be removed without using a tool, remove it first.
3. Use correct screwdriver and torque value before unlock the screw.
4.
5.
6.
7.
8.
3.2 Optional Graphic. If the disassembly process is complex, insert a graphic illustration below to identify the items
contained in the product that require selective treatment (with descriptions and arrows identifying locations).
EL-MF877-00 Page 2
Template Revision B
PSG instructions for this template are available at EL-MF877-01

MANUFACTURING PROCESS INSTRUCTIONS
MECHANICAL ASSEMBLY
MODEL :Snicker
Auditor ：AliciaChien
Tabulator：
A. Current station version list
B. Version Modify list
Revision Date Station Content Ver. Design
0.1 2014/11/12 ALL FIRST VERSION 0.1 Nydia Lee
Sub-assembly name: FA DIS ASS‘Y
Document No.: Snicker FA DIS ASS'Y SOP
Written by: Nydia Lee Revision: 0.1
Date: 2014/11/12 Page: 1
Station Ver. Station Ver. Station Ver. Station Ver.
1 0.1 10 0.1
2 0.1 11 0.1
3 0.1 12 0.1
4 0.1 13 0.1
5 0.1 14 0.1
6 0.1 15 0.1
7 0.1 16 0.1
8 0.1
9 0.1
Nydia Lee

Notes : If finding anything uncommon, notice foreman or assistant at once.
Standard Operation Procedure
Document No. : Snicker FA DIS ASS’Y SOP Station :
Name : Ver. : Date :
Holding fixture list (holding fixture standard) Qty Holding fixture list (holding fixture standard) Qty
Step：
Tabulator：Issue department：
AliciaChien NPSU-PPE
Auditor ：Nydia Lee
Disassemble Service Door
1. Press and slide the release button to left, at
the same time, slide the service door
downward. (Fig.1)
2. Disassemble the service door. (Fig.2)
1(1/1)
0.1 2014/11/12
Fig.2
Fig.1

Notes : If finding anything uncommon, notice foreman or assistant at once.
Standard Operation Procedure
Document No. : Snicker FA DIS ASS’Y SOP Station :
Name : Ver. : Date :
Holding fixture list (holding fixture standard) Qty Holding fixture list (holding fixture standard) Qty
Step：
Tabulator：Issue department：
AliciaChien NPSU-PPE
Auditor ：Nydia Lee
Disassemble Battery
1. Slide the two knobs to the unlocked position.
(Fig.1)
2. Disassemble the battery. (Fig.2)
2(1/1)
Fig.1
“Unlocked”
Fig.1
Fig.2
0.1 2014/11/12

Notes : If finding anything uncommon, notice foreman or assistant at once.
Standard Operation Procedure
Document No. : Snicker FA DIS ASS’Y SOP Station :
Name : Ver. : Date :
Holding fixture list (holding fixture standard) Qty Holding fixture list (holding fixture standard) Qty
Step：
Tabulator：Issue department：
AliciaChien NPSU-PPE
Auditor ：Nydia Lee
Disassemble HDD
3(1/1)
Electric cross screwdriver(#1) 1
1. Loosen HDD bracket set screw * 4.
2. Disassemble the HDD.
1
4
3
2
Fig.1
0.1 2014/11/12

Notes : If finding anything uncommon, notice foreman or assistant at once.
Standard Operation Procedure
Document No. : Snicker FA DIS ASS’Y SOP Station :
Name : Ver. : Date :
Holding fixture list (holding fixture standard) Qty Holding fixture list (holding fixture standard) Qty
Step：
Tabulator：Issue department：
AliciaChien NPSU-PPE
Auditor ：Nydia Lee
Disassemble SSD Card & DDR
4(1/1)
Electric cross screwdriver(#1) 1
1. Loosen screw * 1, then disassemble SSD
card. (Fig.1)
2. Disassemble DDR. (Fig.2)
Fig.1
Fig.2
0.1 2014/11/12

Notes : If finding anything uncommon, notice foreman or assistant at once.
Standard Operation Procedure
Document No. : Snicker FA DIS ASS’Y SOP Station :
Name : Ver. : Date :
Holding fixture list (holding fixture standard) Qty Holding fixture list (holding fixture standard) Qty
Step：
Tabulator：Issue department：
AliciaChien NPSU-PPE
Auditor ：Nydia Lee
Disassemble WWANcard
5(1/1)
Electric cross screwdriver(#1) 1
1. Disassemble WWANcable. (Fig.1)
2. Loosen screw * 1. (Fig.2)
3. Disassemble the WWAN.(Fig.3)
Fig.1
Fig.3
Fig.2
0.1 2014/11/12

Notes : If finding anything uncommon, notice foreman or assistant at once.
Standard Operation Procedure
Document No. : Snicker FA DIS ASS’Y SOP Station :
Name : Ver. : Date :
Holding fixture list (holding fixture standard) Qty Holding fixture list (holding fixture standard) Qty
Step：
Tabulator：Issue department：
AliciaChien NPSU-PPE
Auditor ：Nydia Lee
1. Loosen screw * 3. (Fig.1)
2. Loosen KB set screw * 2. (Fig.2)
Loosen Bottom Case Screws
6(1/1)
Electric cross screwdriver(#1) 1
1
Fig.1
Fig.1
Fig.2
0.1 2014/11/12

Notes : If finding anything uncommon, notice foreman or assistant at once.
Standard Operation Procedure
Document No. : Snicker FA DIS ASS’Y SOP Station :
Name : Ver. : Date :
Holding fixture list (holding fixture standard) Qty Holding fixture list (holding fixture standard) Qty
Step：
Tabulator：Issue department：
AliciaChien NPSU-PPE
Auditor ：Nydia Lee
Disassemble WLAN Card & CNTR
7(1/1)
Electric cross screwdriver(#1) 1
1. Disassemble WLAN cable, loosen screw * 1,
disassemble the WLAN. (Fig.1/Fig.2)
2. Disassemble e-DP CNTR. (Fig.3)
Fig.1
Fig.2
Fig.3
0.1 2014/11/12

Notes : If finding anything uncommon, notice foreman or assistant at once.
Standard Operation Procedure
Document No. : Snicker FA DIS ASS’Y SOP Station :
Name : Ver. : Date :
Holding fixture list (holding fixture standard) Qty Holding fixture list (holding fixture standard) Qty
Step：
Tabulator：Issue department：
AliciaChien NPSU-PPE
Auditor ：Nydia Lee
1. Loosen bottom case screw * 4 (M2.5*4).
(Fig.1)
Loosen Bottom Case Screws
8(1/1)
Fig.1
Electric cross screwdriver(#1) 1
Fig.1
Fig.2
0.1 2014/11/12
Fig.1

Notes : If finding anything uncommon, notice foreman or assistant at once.
Standard Operation Procedure
Document No. : Snicker FA DIS ASS’Y SOP Station :
Name : Ver. : Date :
Holding fixture list (holding fixture standard) Qty Holding fixture list (holding fixture standard) Qty
Step：
Tabulator：Issue department：
AliciaChien NPSU-PPE
Auditor ：Nydia Lee
1. Loosen bottom case screw * 10. (Fig.1)
Loosen Bottom Case Screws
9(1/1)
Fig.1
Electric cross screwdriver(#1) 1
Fig.1
Fig.2
1
2
4
10
3
9
8
6
7 5
0.1 2014/11/12
Fig.1

Notes : If finding anything uncommon, notice foreman or assistant at once.
Standard Operation Procedure
Document No. : Snicker FA DIS ASS’Y SOP Station :
Name : Ver. : Date :
Holding fixture list (holding fixture standard) Qty Holding fixture list (holding fixture standard) Qty
Step：
Tabulator：Issue department：
AliciaChien NPSU-PPE
Auditor ：Nydia Lee
Disassemble Keyboard
1. Open BASE unit (30 °)(Fig.1), poke the
position (marked in red circle) by T8
screwdriver. (Fig.2)
2. Open the machine and disassemble keyboard.
(Fig.3)
10(1/1)
Fig.1
Fig.2
Fig.3
0.1 2014/11/12

Notes : If finding anything uncommon, notice foreman or assistant at once.
Standard Operation Procedure
Document No. : Snicker FA DIS ASS’Y SOP Station :
Name : Ver. : Date :
Holding fixture list (holding fixture standard) Qty Holding fixture list (holding fixture standard) Qty
Step：
Tabulator：Issue department：
AliciaChien NPSU-PPE
Auditor ：Nydia Lee
ReleaseCNTR and FFC
1. Disassemble backlight FFC, KB FFC,
Stickpoint FFC CNTR. (Fig.1)
2. Disassemble power FFC, smart card FFC,
finger/B FFC CNTR. (Fig.2)
11(1/1)
Fig.3
Backlight FFC
KB FFC
Stickpoint FFC
Fig.1
Fig.2 Power FFC
Smart Card FFC
Finger/B FFC
0.1 2014/11/12

Notes : If finding anything uncommon, notice foreman or assistant at once.
Standard Operation Procedure
Document No. : Snicker FA DIS ASS’Y SOP Station :
Name : Ver. : Date :
Holding fixture list (holding fixture standard) Qty Holding fixture list (holding fixture standard) Qty
Step：
Tabulator：Issue department：
AliciaChien NPSU-PPE
Auditor ：Nydia Lee
Loosen Screws and Disassemble Top Case
12(1/1)
1. Loosen TOP CASE screw (M2.5*4) * 2. (Fig.1)
2. Disassemble TOP CASE. (Fig.2)
Fig.1
Fig.2
Electric cross screwdriver(#1) 1
0.1 2014/11/12

Notes : If finding anything uncommon, notice foreman or assistant at once.
Standard Operation Procedure
Document No. : Snicker FA DIS ASS’Y SOP Station :
Name : Ver. : Date :
Holding fixture list (holding fixture standard) Qty Holding fixture list (holding fixture standard) Qty
Step：
Tabulator：Issue department：
AliciaChien NPSU-PPE
Auditor ：Nydia Lee
Loosen M/B Screws
13(1/1)
1. Loosen MB screw * 3 (M2*3). (Fig.1)
2. Loosen thermal module screw *4 & FAN SET
screw * 2. (Fig.2/Fig.3)
Fig.1
Fig.2
Fig.3
1
2
4
3
Electric cross screwdriver(#1) 1
0.1 2014/11/12

Notes : If finding anything uncommon, notice foreman or assistant at once.
Standard Operation Procedure
Document No. : Snicker FA DIS ASS’Y SOP Station :
Name : Ver. : Date :
Holding fixture list (holding fixture standard) Qty Holding fixture list (holding fixture standard) Qty
Step：
Tabulator：Issue department：
AliciaChien NPSU-PPE
Auditor ：Nydia Lee
Disassemble Speaker & Fan CNTR 14(1/1)
1. Disassemble speaker CNTR & FAN CNTR.
(Fig.1)
2. Put the MB/TOP module in the bag.
0.1 2014/11/12
Fig.1
Speaker cable CNTR
FAN cable CNTR
Fig.2

Notes : If finding anything uncommon, notice foreman or assistant at once.
Standard Operation Procedure
Document No. : Snicker FA DIS ASS’Y SOP Station :
Name : Ver. : Date :
Holding fixture list (holding fixture standard) Qty Holding fixture list (holding fixture standard) Qty
Step：
Tabulator：Issue department：
AliciaChien NPSU-PPE
Auditor ：Nydia Lee
1. Put the machine on support fixture. (Fig.1)
2. Disassemble WLAN/WWANcable. (Fig.2)
Disassemble Cable Routing on Base
15(1/1)
Fig.1
Support Fixture 1
3
1
2
4 Mylar
Fig.2
0.1 2014/11/12

Notes : If finding anything uncommon, notice foreman or assistant at once.
Standard Operation Procedure
Document No. : Snicker FA DIS ASS’Y SOP Station :
Name : Ver. : Date :
Holding fixture list (holding fixture standard) Qty Holding fixture list (holding fixture standard) Qty
Step：
Tabulator：Issue department：
AliciaChien NPSU-PPE
Auditor ：Nydia Lee
1. Put the machine on support fixture. (Fig.1)
2. Loosen screw * 4, separate LCM and BU.
(Fig.2)
Loosen Hinge Screws
16(1/1)
Fig.1
Support Fixture 1
Fig.2
Electric cross screwdriver(#1) 1
0.1 2014/11/12
