Portable Powerhouse.
Create masterful designs and jaw-dropping animations with
workstation-caliber graphics by either AMD or NVIDIA. The HP EliteBook
8570w is ISV-certied so your mobile workstation runs smoothly and
reliably no matter what the project is.
Keep up with large les and daunting projects with the incredible
performance and responsiveness of an Intel®Core™ i7 quad-core
processor or an i7 or i5 dual-core processor.1Gain improved
performance and speed with up to four SODIMMS supporting up to
32 GB of memory.2,3
Multi-task on multiple screens at once or view enlarged content across
up to ve additional displays.4,5
Color remains consistent and accurate. HP DreamColor Technology2
and HP Mobile Display Assistant allow you to control color attributes
throughout your development environments.
Creativity with business acumen.
Save time by quickly accessing your favorite les with Intel Smart
Response Technology.6You’ll also gain fast response times for things
like system boot and application startup. Engage in video conferences,7
web-based trainings8or streaming videos with smooth audio quality
that’ll surprise you. SRS Premium Sound PRO also allows you to share
crisp, powerful sound directly from your notebook. Forget the extra
speakers during your presentations.
Access the Internet and email in more places than ever, thanks to
various wireless technologies9that keep you connected—from Wi-Fi
CERTIFIED™ WLAN9to HP Mobile Broadband featuring 3G and 4G LTE2,10 and
optional Bluetooth connectivity.2
Business on the run.
Work eciently in dimly lit rooms or on red eye ights. The full-size,
backlit keyboard2 doesn’t sacrice comfort.
When design projects require travel, you’ll condently take the
portable HP EliteBook 8570w with you. This mobile workstation meets
tough military standards (MIL-STD-810G) for drop, vibration, dust,
temperature and altitude.11
HP recommends Windows® 7.
HP EliteBook 8570w Mobile Workstation
HP’s most versatile mobile workstation oers high-end professional graphics,
robust processing power, a 15.6-inch diagonal display and a chiseled design that radiates performance.
hp.com/zworkstations

EliteBook 8570w Mobile Workstation HP recommends Windows®7.
Form Factor Mobile
Operating system Preinstalled:
Genuine® Windows 7 Professional 3212
Genuine Windows 7 Professional 6412,13
Genuine Windows 7 Home Premium 3212 (select countries)
Genuine Windows 7 Home Premium 6412,13 (select countries)
Supported:
Genuine Windows 7 Enterprise 3212
Genuine Windows 7 Enterprise 6412,13
Genuine Windows 7 Ultimate 3212
Genuine Windows 7 Ultimate 6412,13
SUSE Linux Enterprise Desktop
Red Hat Enterprise Linux (RHEL)
Certied:
SUSE Linux Enterprise Desktop
Red Hat Enterprise Linux (RHEL)
FreeDOS
Processor 3rd Generation Intel® CoreTM i7 Quad-Core1with Turbo Boost Technology;14 3rd Generation Intel® CoreTM i7 and i5 Dual-Core1with Turbo Boost Technology14
Chipset Mobile Intel® QM77 Express Chipset (vPro™ support15)
Memory DDR3 SDRAM PC3-12800, 1600 MHz, dual-core processors support 2 memory slots, 2/4/8 GB16 SODIMMs, up to 16 GB total, quad-core processors
support 4 memory slots, 2/4/8 GB16 SODIMMs, up to 32 GB total3
Internal Storage17 320/500/750 GB 7200 rpm HDD, 500 GB 7200 rpm SED (Self Encrypting Drive), SATA 6 Gb/s, 128/180 GB SSD, SATA 6 Gb/s, 256 GB SED SSD
Flash Cache Intel®24 GB SLC mSATA cache module; Support Intel Smart Response Technology (available with non-SED HDD only)
Upgrade Bay 12.7 mm SATA optical drive or secondary hard drive: DVD-ROM Drive,2 DVD+/-RW Drive,2 Blu-ray ROM DVD+/-RW Drive,2,18 Blu-ray R/RE DVD+/-RW
Drive,2,18 500 GB 7200 rpm HDD,2,17 256 GB SATA 6 Gb/s SED SSD,2,17 or weight saver
Display 15.6" diagonal LED-backlit WVA anti-glare, HD+19 (1600 x 900); 15.6" diagonal LED-backlit WVA anti-glare, FHD19 (1920 x 1080); 15.6" diagonal
LED-backlit UWVA anti-glare, FHD9,19 DreamColor2(1920 x 1080)
Graphics AMD FireProTM M4000, with 1 GB dedicated GDDR5 video memory (AMD Eyenity Technology for advanced multi-monitor support),4NVIDIA Quadro
K1000M, with 2 GB dedicated DDR3 video memory, NVIDIA Quadro K2000M, with 2 GB dedicated DDR3 video memory
Audio/Visual High Denition Audio (SRS Premier Sound PRO), stereo speakers, stereo headphone/line out, stereo microphone in, integrated dual-microphone array,
optional 720p HD19 Webcam2
Wireless Support2,10,11 Optional HP hs2350 HSPA+ Mobile Broadband;2 Optional HP un2430 EV-DO/HSPA Mobile Broadband;2 Broadcom 802.11a/b/g/n 2x2;9Intel®Centrino
Advanced-N 6205 802.11a/b/g/n 2x2;9Intel® Centrino Ultimate-N 6300 802.11a/b/g/n 3x39
Communications Integrated Intel®82579LM Gigabit Network Connection (vPro™ support14), 56K v.92 modem2
Ports and Connectors 2 USB 3.0 ports, 2 USB 2.0 ports (1 charging), 1 eSATA/USB 2.0 combo port, 1 VGA, 1 DisplayPort, 1 stereo microphone in, 1 stereo headphone/line out,
1 1394a, 1 RJ-11(optional modem), 1 RJ-45(Ethernet), 1 docking connector, 1 secondary battery connector,power connector
Expansion Slots 1 ExpressCard/54 slot, 1 SD/MMC slot supports SD (Secure Digital), SDHC (Secure Digital High Capacity), SDXC (Secure Digital Extended Capacity),
MMC (MultiMedia Card), MMC+
Input Devices Full-sized spill-resistant keyboard with numeric keypad, bottom case drain, backlit keyboard,2 touchpad with scroll zone and gestures support, point
stick, discrete launch buttons (Web browser, WLAN on/o, mute, calculator)
Software (Windows OS only) HP Power Assistant,20 HP Recovery Manager, HP Support Assistant, Microsoft® Oce Starter: reduced-functionality Word and Excel® only, with advertising.
No PowerPoint® or Outlook®. Buy Oce 2010 to use the full-featured software.21 Intervideo WinDVD (select models), Roxio Secure Burn22 (select models),
Roxio MyDVDE 10 SE (select models), HP Performance Advisor. Custom Integration Services provides tailor-made, turnkey solutions for Business Ready PCs
Security Standard: Microsoft Security Essentials, HP ProtectTools,23 TPM Embedded Security Chip 1.2, HP Fingerprint Sensor, Pre-Boot Security, HP SpareKey
(requires initial user setup), HP Disk Sanitizer,24 Drive Encryption for HP ProtectTools, Credential Manager for HP ProtectTools, Face Recognition for
HP ProtectTools,25 File Sanitizer for HP ProtectTools,24 Smart Card Reader, security lock slot. Optional: HP Privacy Filter,2HP Notebook Combo Lock,2
HP Keyed Lock,2Central Management for HP ProtectTools,26 Computrace2,27
Dimensions (w x d x h) Standard panel: 15.0 x 10.1 x 1.36 in (at front)/38.2 x 25.8 x 3.5 cm (at front); DreamColor panel: 15.0 x 10.1 x 1.44 in (at front)/38.2 x 25.8 x 3.7 cm
(at front)
Weight Starting at 6.69 lb (3.0 kg) with weight saver (weight will vary by conguration)
Power20 8-cell (83 WHr) Lithium-Ion battery,28 8-cell (75 WHr) HP Long Life Battery,28 optional HP ST09 Extended Life Notebook Battery (73 WHr),2,28 optional
HP BB09 Ultra Extended Life Notebook Battery (100 WHr),2,28 120W HP Smart AC Adapter, 150W HP Smart AC Adapter, 200W HP Smart AC Adapter,
HP Fast Charge29
Expansion Solutions2HP 230W Docking Station, HP 90W Docking Station, HP 230W Advanced Docking Station, HP 120W Advanced Docking Station, HP Dual Hinge Notebook
Stand, HP Display & Notebook Stand, HP Adjustable Display Stand
Warranty Limited 3-year and 1-year warranty options available, depending on country,1-year limited warranty on primary battery. Optional HP Care Pack
Services2,30 are extended service contracts which go beyond your standard warranties. For more details, visit hp.com/go/lookuptool.
2

EliteBook 8570w Mobile Workstation HP recommends Windows®7.
1. Genuine Windows®7 Professional12
2. Optional 720p HD Webcam2,19
3. 15.6" diagonal display
4. Full-size keyboard with numeric keypad
5. Touchpad with scroll zone
4
5
1
2
3
3

Screen image courtesy of Autodesk
1. Multi-Core is designed to improve performance of certain software products. Not all customers or software applications will necessarily benet from use of this technology. 64-bit computing on Intel®
architecture requires a computer system with a processor, chipset, BIOS, operating system, device drivers, and applications enabled for Intel®64 architecture. Processors will not operate (including
32-bit operation) without an Intel® 64 architecture-enabled BIOS. Performance will vary depending on your hardware and software congurations. Intel’s numbering is not a measurement of higher
performance.
2. Sold separately or as an optional feature.
3. Four SODIMMS for a total of 32 GB of memory is available only on quad-core systems. Maximum memory capacities assume Windows 64-bit operating systems or Linux. With Windows 32-bit
operating systems, memory above 3 GB may not all be available due to system resource requirements.
4. Support for 5 monitors requires separately purchased HP Advance Docking Station.
5. HP oers discrete graphics congurations supporting up to ve total displays through the advanced docking station. The advanced docking station is sold separately. AMD graphics supports ve total
displays, including the native notebook display. NVIDIA graphics supports up to four total displays, including the native notebook display.
6. Requires a compatible Intel®Core processor, enabled chipset, Intel® Rapid Storage technology software and non-SED HDD + optional mSATA SSD ash cache module. Intel®Smart Response
Technology is only available on select 2012 HP systems. Depending on system conguration, results may vary.
7. Video conferencing is available on congurations with the optional 720p HD webcam.
8. Internet access required.
9. Wireless access point and Internet service required. Availability of public wireless access points limited.
10. Wireless use requires separately purchased service contract. Check with your local vendor for coverage area and availability in your area. Connection and speeds will vary due to location,
environment, network conditions, and other factors. 4G compatibility with HSPA+ and LTE. 4G LTE is only available in the United States. LTE is expected to be available in June 2012.
11. Testing was not intended to demonstrate tness for DOD contracts requirements or for military use. Test results are not a guarantee of future performance under these test conditions.
12. This system may require upgraded and/or separately purchased hardware to take full advantage of Windows 7 functionality. Not all features are available in all editions of Windows 7.
See microsoft.com/windows/windows-7 for details.
13. 64-bit computing on Intel architecture requires a computer system with a processor, chipset, BIOS, operating system, device drivers and applications enabled for Intel® 64 architecture. Processors
will not operate (including 32-bit operation) without an Intel 64 architecture-enabled BIOS. Performance will vary depending on your hardware and software congurations. See intel.com/info/em64t
for more information. Quad Core is designed to improve performance of multithreaded software products and hardware-aware multitasking operating systems and may require appropriate operating
system software for full benet. Not all customers or software applications will necessarily benet from use of this technology. Intel’s numbering is not a measurement of higher performance.
14. Intel®Turbo Boost 2.0 technology requires a PC with a processor with Intel Turbo Boost 2.0 capability. Intel Turbo Boost 2.0 performance varies depending on hardware, software and overall system
conguration. See intel.com/technology/turboboost for more information.
15. Some functionality of this technology, such as Intel® Active management technology and Intel Virtualization technology, requires additional 3rd party software in order to run. Availability of future
“virtual appliances” applications for Intel vPro technology is dependent on 3rd party software providers. Microsoft Windows required.
16. Maximum memory capacities assume Windows 64-bit operating systems or Linux. With Windows 32-bit operating systems, memory above 3 GB may not all be available due to system
resource requirements.
17. For hard drives, GB = 1 billion bytes. Actual formatted capacity is less. Up to 15 GB (for Windows 7) of system disk is reserved for the system recovery software.
18. Blu-ray contains new technologies, certain disc, digital connection, compatibility and/or performance issues may arise, and do not constitute defects in the product. Flawless playback on all systems
is not guaranteed. In order for some Blu-ray titles to play, they may require an HDMI digital connection and your display may require HDCP support. HD DVD disks cannot be played on this drive. Note
that DVD-ROM cannot read or write to 2.6 GB Single Sided/5.2 GB Double Sided – Version 1.0 media. Actual speeds may vary. Don’t copy copyright-protected materials. Double Layer discs can store
more data than single layer discs; discs burned with this drive may not be compatible with many existing single-layer DVD drives and players.
19. HD content required to view HD images.
20. Power calculations and cost calculations are estimates. Results will vary based on variables, which include information provided by the user, time PC is in dierent power states (on, standby, hibernate,
o), time PC is on battery or AC, hardware conguration, variable electricity rates and utilities provider. HP advises customers to use information reported by HP Power Assistant for reference only
and to validate impact in their environment. Environmental calculations were based on U.S. EPA eGrid 2007 data found at epa.gov/egrid/. Regional results will vary. Microsoft Windows required.
Requires discrete graphics conguration.
21. Includes reduced functionality versions of Word and Excel. Purchase of Product Key required to activate full Oce 2010 suite available at participating resellers/retailers and oce.com.
22. Do not copy copyright-protected materials.
23. Microsoft Windows required.
24. For the use cases outlined in the DOD 5220.22-M Supplement. Does not support Solid State Drives (SSDs). Initial setup required. Web history deleted only in Internet Explorer and Firefox browsers
and must be user enabled.
25. Microsoft Windows and webcam required.
26. In order to deploy policies the client needs to be connected to the network. Requires connectivity to the DigitalPersona server to receive updated policies. System access may not prevent users from
logging into the system on the rst attempt if policy updates haven’t yet been received and applied. This functionality blocks network access from the user’s PC.
27. The Computrace agent is shipped turned o, and must be activated by customers when they purchase a subscription. Subscriptions can be purchased for terms ranging multiple years. Service is
limited, check with Absolute for availability outside the U.S.
28. Battery life will vary depending on the product model, conguration, loaded applications, features, use, wireless functionality and power management settings. The maximum capacity of the battery
will naturally decrease with time and usage. See MobileMark07 battery benchmark bapco.com/products/mobilemark2007 for additional details.
29. Fast Charge Technology recharges your battery up to 90% within 90 minutes when the system is o. Fast Charge Technology does not apply to the HP Ultra-Capacity or 9-cell batteries. When the PC is
powered on, charge time may increase and will vary based on the workload of the notebook PC.
30. Service levels and response times for HP Care Packs may vary depending on your geographic location. Service starts on date of hardware purchase. Restrictions and limitations apply. For details, visit
hp.com/go/lookuptool.
EliteBook 8570w Mobile Workstation HP recommends Windows®7.
Learn more
hp.com/zworkstations
© 2012 Hewlett-Packard Development Company, L.P. The information contained herein is subject to change without notice.
The only warranties for HP products and services are set forth in the express warranty statements accompanying such products
and services. Nothing herein should be construed as constituting an additional warranty. HP shall not be liable for technical or
editorial errors or omissions contained herein.
Bluetooth is a trademark of its proprietor and used by Hewlett-Packard Company under license. Microsoft and Windows are
U.S. registered trademarks of Microsoft Corporation. Intel and Core and are trademarks or registered trademarks of Intel Corporation
or its subsidiaries in the United States and other countries. AMD is a trademark of Advanced Micro Devices, Inc.
4AA4-1807ENW, June 2012
