HP Nc6400 - Compaq Business Notebook User instructions

HP recommends
Windows Vista
®
Business
1. Volume Mute Button with LED 15. Power/Standby LED
2. Volume Down Button 16. Wireless On/Off LED
3. Volume Up Button 17. PC Card Eject Button
4. Integrated Microphone 18. PC Card Slot
5. Biometric Fingerprint Sensor 19. Headphone Jack
6. Pointstick 20. Microphone Jack
7. Pointstick Buttons 21. 2 USB 2.0 Ports
8. Stereo Speakers 22. Power Button with LED
9. SD Media Slot 23. HP Info Center Button
10. Fast Infrared Port 24. Wireless On/Off Button with LED
11. Touchpad with scroll zone 25. Presentation Mode Button
12. Touchpad Buttons 26. Ambient Light Sensor
13. Hard Drive Activity LED 27. Dual-band Wireless LAN Antennas
14. Battery Charging LED 28. 5-Band Wireless WAN Antennas (enabled with WWAN option)
QuickSpecs
HP Compaq nc6400 Notebook PC
Overview
DA - 12446 North America — Version 18 — August 10, 2007 Page 1

1. Integrated Smart Card Reader 6. RJ-11 Port (Modem)
2. MultiBay II Drive with Easy Release 7. VGA/External Monitor Port
3. Optical Drive Button 8. S-Video TV Out
4. USB 2.0 Port 9. Power Connector
5. RJ-45 Port (NIC) 10. Kensington Lock Slot
At A Glance
Genuine Windows Vista Business 32,
Genuine Windows Vista Home Basic 32,
Genuine Windows XP Professional,
Genuine Windows XP Home Edition, or
FreeDOS
Sleek light-weight design starting at under 4.6 lb (2.1 kg) and 1.1 inch (29.2 mm) thin at front
14.1-inch wide screen display
Intel® Core™ 2 Duo processors and Intel Core Duo processors
Mobile Intel 945GM Express Chipset or Mobil Intel 945PM Express Chipset
Up to 4GB* of 533- or 667-MHz DDR2 SDRAM, dual channel memory support
ATI Mobility Radeon X1300 or Intel Graphics Media Accelerator 950
Up to 100-GB 7200 rpm, user-removable hard drive
Optional integrated HP ev2200 1xEV-DO or HP hs2300 HSDPA Broadband Wireless module
Optional integrated 802.11 a/b/g or 802.11 b/g wireless LAN module and Bluetooth®
Support for optional Intel Centrino™ Duo mobile technology
Protected by three-year standard parts and labor warranty – certain restrictions and exclusions apply
* Above 3-GB, all memory may not be available due to system resource requirements.
QuickSpecs
HP Compaq nc6400 Notebook PC
Overview
DA - 12446 North America — Version 18 — August 10, 2007 Page 2

Processors Intel Core 2 Duo Processor T7600 (2.33-GHz, 667-FSB, 4-MB L2 cache)*
Intel Core 2 Duo Processor T7400 (2.16-GHz, 667-FSB, 4-MB L2 cache)*
Intel Core 2 Duo Processor T7200 (2.0-GHz, 667-FSB, 4-MB L2 cache)*
Intel Core 2 Duo Processor T5600 (1.83-GHz, 667-FSB, 2-MB L2 cache)*
Intel Core 2 Duo Processor T5500 (1.66-GHz, 667-FSB, 2-MB L2 cache)*
Intel Core Duo Processor T2600* (2.16-GHz, 667-MHz FSB, 2-MB L2 cache)
Intel Core Duo Processor T2500* (2.00-GHz, 667-MHz FSB, 2-MB L2 cache)
Intel Core Duo Processor T2400* (1.83-GHz, 667-MHz FSB, 2-MB L2 cache)
* Intel's numbering is not a measurement of higher performance.
NOTE: Processor speed denotes maximum performance mode; processors will run at lower speeds n
battery optimization mode.
Operating System Preinstalled Genuine Windows Vista Business 32*
Genuine Windows Vista Home Basic 32*
Genuine Windows XP Professional SP2
Genuine Windows XP Home Edition SP2
FreeDOS
Supported
(select drivers available on
http://www.hp.com )
Genuine Windows Vista Business 64*
†
Genuine Windows Vista Enterprise*
†
Genuine Windows 2000
Certified SUSE Linux Enterprise Desktop 10
* Certain Windows Vista product features require advanced or additional hardware.
See http://www.microsoft.com/windowsvista/getready/hardwarereqs.mspx and
http://www.microsoft.com/windowsvista/getready/capable.mspx for details. Windows Vista Upgrade
Advisor can help you determine which features of Windows Vista will run on your computer. To download
the tool, visit http://www.windowsvista.com/upgradeadvisor .
†
At initial boot, either 32- or 64-bit can be selected. This is a one time selection and the other version will
be deleted.
Chipset Mobile Intel 945PM Express Chipset with 667-MHz front side bus (models with discrete graphics)
or
Mobile Intel 945GM Express Chipset with 667-MHz front side bus (models with integrated graphics)
QuickSpecs
HP Compaq nc6400 Notebook PC
Standard Features
DA - 12446 North America — Version 18 — August 10, 2007 Page 3

Graphics For discrete graphics models with 512MB of system memory:
ATI Mobility Radeon X1300 256MB HyperMemory*
Microsoft DirectX 9 capable
For discrete graphics models with 1024MB or more of system memory:
ATI Mobility Radeon X1300 512MB HyperMemory*
Microsoft DirectX 9 capable
For integrated graphics models:
Intel Graphics Media Accelerator 950 with up to 224MB shared system memory,
depending on model
Microsoft DirectX 9 capable
* Indicates dedicated video memory and shared system memory. Either 64MB or 128MB dedicated video
memory, depending on model.
Display Internal 14.1-inch WXGA (1280 x 800 resolution)
14.1-inch WXGA+ (1440 x 900 resolution)
Ambient Light Sensor
External Up to 32-bit per pixel color depth
VGA port supports resolutions up to 2048 x 1536 at 75 Hz, and lower
resolutions at up to 100 Hz
DVI port in optional HP Docking Station (sold separately)
supports resolutions up to 1600 x 1200 at both full and reduced
blanking, and 1920 x 1200 at reduced blanking
NOTE: Resolutions are dependent upon monitor capability, and resolution and
color depth settings.
Memory Standard 512-MB, 1024-MB or 2048-MB 533-MHz or 667-MHz DDR2 SDRAM; two
SODIMM slots supporting dual channel memory
Maximum Upgradeable to 4096-MB maximum (2048-MB SODIMM in slots 1 and 2)
Dual-channel Maximized dual-channel performance requires SODIMMs of the same size and
speed in both memory slots.
NOTE: Due to the non-industry standard nature of some third-party memory modules, we recommend HP
branded memory to ensure compatibility. If you mix memory speeds, the system will perform at the lower
memory speed. Above 3-GB, all memory may not be available due to system resource requirements.
Communications Integrated Broadcom NetXtreme Gigabit Ethernet PCI Express Controller (10/100/1000 NIC)*
56K V.92 modem** with digital line guard
* The term "10/100/1000" or "Gigabit" Ethernet indicates compliance with IEEE standard 802.3ab for
Gigabit Ethernet, and does not connote actual operating speed of 1 Gb/s. For high-speed transmission,
connection to a Gigabit Ethernet server and network infrastructure is required.
** Designed for downloads from 56K modem compliant sources. Maximum achievable download
transmission rates currently do not reach 56 KB/s, and will vary with line conditions. Modem availability is
subject to country regulatory approval.
QuickSpecs
HP Compaq nc6400 Notebook PC
Standard Features
DA - 12446 North America — Version 18 — August 10, 2007 Page 4

Wireless Devices Support for a broad range of secure, integrated wireless LAN and wireless WAN options featuring support
for the latest industry standards. Integrated Bluetooth is also an option (factory configurable only) and
can be combined with any of the supported wireless LAN and wireless WAN options.
HP ev2200 1xEV-DO
Broadband Wireless
Module*
Integrated dual band 800-MHz (cellular) and 1900-MHz (PCS) WWAN module
connects to the Verizon Wireless BroadbandAccess and NationalAccess
networks (US only)
Supports CDMA 1xEV-DO, 1xRTT connections
NOTE: Separately purchased Verizon Wireless service is required. For details,
go to http://www.hp.com/go/broadbandwireless .
Upgradeable design and two 800/900/1800/1900/2100-MHz antennas
integrated in the top of the display panel support current and future WWAN
technologies
HP hs2300 HSDPA
Broadband Wireless
Module*
Integrated WWAN module that provides connection to GSM, GPRS, EDGE,
UMTS, and HSDPA mobile networks in many countries. Currently supported by
the Cingular network in the U.S.
NOTE: Separately purchased mobile network operator service is required.
Upgradeable design and two 800/900/1800/1900/2100-MHz antennas
integrated in the top of the display panel support current and future WWAN
technologies.
All integrated wireless
LAN options
Wi-Fi certified
Cisco Compatible Extensions support (Version 3.0)
Wired Equivalent Privacy (WEP) support up to 128-bit keys
Wi-Fi Protected Access (WPA) and WPA2 support
802.1x authentication support, including EAP-TLS, EAP-TTLS, PEAP-GTC,
PEAP-MSCHAPv2, and LEAP
Advanced Encryption Standard (AES) support
WiFi certified for WPA2, WMM
Dual antennas integrated in the display enclosure
Intel PRO/Wireless
3945ABG Network
Connection
Intel Centrino mobile technology
Integrated support for 802.11a, b and g
Up to 54-mbps data rate
Broadcom 4311AG WiFi
Adapter
Integrated support for 802.11a, b and g
Up to 54-mbps data rate
Broadcom 4311BG WiFi
Adapter
Integrated support for 802.11 b and g
Up to 54-mbps data rate
HP Integrated Module
with Bluetooth 2.0
Wireless Technology
Bluetooth Specification v2.0 compliant
Works with a wide range of Bluetooth devices
* Broadband Wireless Module (WWAN) requires Microsoft Windows XP Professional and is available as a
standard feature or as an option to be added later.
QuickSpecs
HP Compaq nc6400 Notebook PC
Standard Features
DA - 12446 North America — Version 18 — August 10, 2007 Page 5

Keyboard The 101/102-key compatible keyboard features an industry standard, full-pitch key layout with desktop
keyboard features, such as the isolated inverted-T cursor control keys, editing keys, both left and right
control and alt keys, and 12 function keys. US and International key layouts are available. Other features
include an integrated numeric keypad, hotkeys for instant access to power conservation, brightness, and
other features, 19-mm x 19-mm key pitch (center-to-center spacing), 2.5-mm stroke, comfort-dished
keycaps, and bright key legends for improved visibility in low light conditions.
One-Touch Productivity
Buttons
Provide one-touch access to the following features: HP Info Center, Wireless On/Off, Presentation Mode,
Volume Up, Volume Down, and Volume Mute
Pointing Device Dual pointing devices:
Touchpad with scroll zone, two soft-touch buttons
and
Pointstick, two soft-touch buttons
Expansion Card Slots
One Type I/II PC Card slot Supports 32-bit CardBus and 16-bit PC Cards
Integrated Smart Card
Reader
Compatible with ISO 7816 compliant Smart Cards
PC/SC interface support
Media Slots Secure Digital slot Supports SD (Secure Digital), MultiMedia Card
Storage Hard Drives 60-, 80-, 100-GB 7200 rpm SMART SATA
60-, 80-, 100-GB 5400 rpm SMART SATA
NOTE: These hard drives are customer removable and will withstand multiple insertion/removal cycles. Up
to 8 GB is reserved for the system recovery software.
HP Mobile Data
Protection System 3D
Hard drive is mounted directly to the notebook frame, reducing the
transmission of shock to the hard drive. Uses three-axis digital motion
detection with intelligent sensitivity to help protect the hard drive during
normal use from shock and vibration.
Optical Drives MultiBay II (9.5-mm) DVD-ROM MultiBay II Drive
DVD/CD-RW Combo MultiBay II Drive
DVD+/-RW SuperMulti MultiBay II Drive with
Double Layer
QuickSpecs
HP Compaq nc6400 Notebook PC
Standard Features
DA - 12446 North America — Version 18 — August 10, 2007 Page 6

Interfaces PC Card Slot One Type I/II
Smart Card Reader One
External Monitor One – VGA
External Microphone One
Headphone/Line out One
Power Connector One
RJ-11 (Modem) One
RJ-45 (NIC) One
Fast Infrared Port One (4-Mb/s support)
IrDA 4-MB compliant; IR performance will vary depending on performance of
IR peripherals and application used.
S-Video TV Out One (Support for NTSC/PAL)
USB 2.0 Three
Docking Connector One
Travel Battery Connector One
LED Status Indicators Eleven
Audio PremierSound audio/speaker subsystem
ADI1981HD High Definition CODEC
Integrated 16-bit Sound Blaster Pro compatible audio
24-bit DAC
Integrated stereo speakers
Integrated microphone
External volume up, volume down, and mute buttons
Stereo headphone/line out
Stereo microphone in
Software Preinstalled Software
with Windows Vista or
Windows XP
Adobe Acrobat Reader*
HP Backup and Recovery Manager
HP Help and Support Center*
HP Mobile Print Driver* (Windows XP models)
HP ProtectTools Security Manager*:
BIOS Configuration for HP ProtectTools
Embedded Security for HP ProtectTools
Credential Manager for HP ProtectTools
HP Quick Launch Buttons
HP Wireless Assistant
HP OpenView Radia Management Solutions*
Sonic Digital Media Plus* (Windows XP models):
RecordNow! (for optional DVD+/-RW and DVD/CDRW drives)
MyDVD (DVD Authoring for optional DVD+/-RW drives)
Roxio Creator 9 (Window Vista models with optional DVD+/-RW or
DVD/CDRW drives)
Synaptics Touchpad Driver
Symantec Norton Internet Security* with complimentary 60-day live update
QuickSpecs
HP Compaq nc6400 Notebook PC
Standard Features
DA - 12446 North America — Version 18 — August 10, 2007 Page 7

Intervideo WinDVD* – DVD Player (for optional DVD+/-RW, DVD/CDRW and
DVD drives)
* NOTE: Software marked with an asterisk is loaded on the hard drive and can be installed by running the
Software Setup utility.
Additional software
available from the Web
HP Client Manager Software
Smart Card Security for HP ProtectTools
Device Access Manager for HP ProtectTools
HP Backup and Recovery
Manager
Each unit is shipped with HP Backup and Recovery Manager. HP Backup and Recovery Manager can provide
data and system file protection for HP business PCs to enable fast recovery if the system becomes
corrupted or if important information is accidentally deleted. HP Backup and Recovery Manager can
perform scheduled or manual backups of the entire drive or individual files and folders. Up to 8 GB of the
hard drive is reserved for the system recovery software. HP Backup and Recovery Manager can also create
software recovery CDs or DVDs (requires optional hardware).
HP OpenView Radia
Management Solutions
HP OpenView Radia Management Solutions automate the management of software such as operating
systems, software, software updates, content, and configuration settings to ensure that each computer is
maintained in the correct configuration.
HP Client Management
Interface
HP Client Management Interface is based on industry standards that include Microsoft Windows
Management Interface (MS WMI), Web Based Enterprise Management (WBEM), System Management BIOS
(SMBIOS), and Advanced Configuration and Power Interface (ACPI). HP CMI is a foundation technology
utilized in HP Client Management Solutions.
SMBIOS Version 2.4 System Management BIOS, previously known as DMI BIOS, is used to store system management
information.
HP ProtectTools Security
Manager
HP ProtectTools Security Manager is the security platform for business notebooks and desktops. The HP
ProtectTools Security Manager is an extensible client security console that delivers enhanced security
capabilities through add-on software modules. Modules currently available are:
- Smart Card Security for HP ProtectTools
- BIOS Configuration for HP ProtectTools
- Credential Manager for HP ProtectTools
- Embedded Security for HP ProtectTools
- Device Access Manager for HP ProtectTools
QuickSpecs
HP Compaq nc6400 Notebook PC
Standard Features
DA - 12446 North America — Version 18 — August 10, 2007 Page 8

Security Standard Features HP ProtectTools Security Manager
HP Biometric Fingerprint Sensor
Integrated Smart Card Reader
TPM 1.2 Embedded Security Chip*
Configuration Control Hardware
Memory Change Alert
Ownership Tag
Setup Password
Power-On Password
DriveLock
TPM Enhanced DriveLock*
HP Disk Sanitizer
Kensington Lock Slot
Support for Computrace / LoJack for Laptops (must be purchased separately)
Optional Features HP Privacy Filter Narrows viewing area so that screen data is
visible only to persons directly in front of the
monitor
* NOTE: TPM module disabled where use is restricted by law; for example, Russia.
For more information on HP security solutions refer to http://www.hp.com/go/security .
Power Supply External Smart AC Adapter (65-watt standard with integrated graphics; 90-watt standard with discrete
graphics), 6-foot (1.8-meter) power cord included.
Total length including External AC adapter is 12 feet (3.66 meter).
HP Fast Charge Technology*
*Fast Charge Technology recharges your battery up to 90% within 90 minutes when the system is off. Fast Charge Technology does
not apply to 12-cell Ultra Capacity batteries.
Battery Primary Battery 55Wh 6-cell Lithium-Ion
Optional HP 8-Cell
Extended Life Battery
52Wh 8-cell high capacity Lithium-Ion
Optional HP 12-Cell Ultra-
Capacity Battery
95Wh 12-cell high capacity Lithium-Ion
QuickSpecs
HP Compaq nc6400 Notebook PC
Standard Features
DA - 12446 North America — Version 18 — August 10, 2007 Page 9

Battery Life 6-cell Primary with integrated
graphics
6-cell Primary with discrete graphics
Primary Battery Up to 6 hours Up to 4 hours
and 30 minutes
Primary Battery and
optional HP 8-Cell
Extended Life Battery
Up to 12 hours
and 15 minutes
Up to 8 hours
and 30 minutes
Primary Battery and
optional HP 12-Cell Ultra-
Capacity Battery
Up to 16 hours
and 15 minutes
Up to 13 hours
NOTE: Battery life will vary depending on the product configuration, product model, applications loaded
on the product, power management settings of the product, and the product features used by the
customer. As with all batteries, the maximum capacity of this battery will decrease with time and usage.
System Standby Time Up to 1 week
Power Conservation Supports enhanced Intel SpeedStep technology with Intel Core Duo and Intel Core Solo processors (allows
Battery Optimized Mode, Maximum Performance Mode, or Automatic mode)
Intel Display Power Saving technology (models with integrated graphics)
ATI PowerPlay technology (models with discrete graphics)
Hibernation
Standby
ACPI compliance
Docking HP Docking Station
HP Advanced Docking Station
HP External MultiBay II
HP Adjustable Notebook Stand
HP's shared docking solutions provide simple and convenient port replication and cable management.
Features include Gigabit NIC pass through, modem pass through, legacy parallel and serial ports, S-video
TV out, USB 2.0 ports, integrated security mechanism*, integrated MultiBay II and ExpressCard** slots.
These docking solutions are compatible across multiple Business Notebook platforms enabling a lower
total cost of ownership.
* HP/Kensington Cable Lock required (purchased separately)
** HP Advanced Docking Station only
Service and Support HP Services includes a three-year standard parts and labor warranty, pick-up or carry-in, and toll-free 7 x
24 hardware technical phone support. On-site service and warranty upgrades are also available.
NOTE: Certain restrictions and exclusions apply. Consult the HP Customer Support Center for details.
http://h20000.www2.hp.com/bizsupport/TechSupport/ProductRoot.jsp .
Select Model(s)
QuickSpecs
HP Compaq nc6400 Notebook PC
Standard Features
DA - 12446 North America — Version 18 — August 10, 2007 Page 10

nc6400
RC454AW#ABA
Processor Intel Core Duo Processor T2400*
Operating System Genuine Windows XP Professional
System Memory 1024 MB 667-MHz DDR2 (1 DIMM)
Hard Drive 60-GB 5400 rpm SATA
Display 14.1-inch WXGA
Graphics Intel Graphics Media Accelerator 950
Audio ADI High Definition CODEC
line out/headphone and microphone jacks
integrated microphone
Communications 56K V.92 modem
Integrated Broadcom NetXtreme Gigabit Ethernet PCI Express Controller
(10/100/1000 NIC)
Integrated Wireless Intel PRO/Wireless 3945ABG Network Connection
Bluetooth 2.0
Integrated Security TPM 1.2 Embedded Security Chip
HP Biometric Fingerprint Sensor
Smart Card Reader
Pointing Device Dual pointing devices (both Pointstick and Touchpad)
MultiBay II Drive DVD/CD-RW Combo MultiBay II Drive
Battery 6-cell (55 WHr) Lithium-Ion
Power External 65W adapter
Warranty 3/3/0
* Intel's numbering system is not a measurement of higher performance.
nc6400
RA252AW#ABA
Processor Intel Core Duo Processor T2400*
Operating System Genuine Windows XP Professional
System Memory 512 MB 667-MHz DDR2 (1 DIMM)
Hard Drive 60-GB 5400 rpm SATA
Display 14.1-inch WXGA
Graphics Intel Graphics Media Accelerator 950
Audio ADI High Definition CODEC
line out/headphone and microphone jacks
integrated microphone
Communications 56K V.92 modem
Integrated Broadcom NetXtreme Gigabit Ethernet PCI Express Controller
(10/100/1000 NIC)
Integrated Wireless Intel PRO/Wireless 3945ABG Network Connection
Bluetooth 2.0
Integrated Security TPM 1.2 Embedded Security Chip
HP Biometric Fingerprint Sensor
Smart Card Reader
Pointing Device Dual pointing devices (both Pointstick and Touchpad)
QuickSpecs
HP Compaq nc6400 Notebook PC
Standard Features
DA - 12446 North America — Version 18 — August 10, 2007 Page 11

MultiBay II Drive DVD/CD-RW Combo MultiBay II Drive
Battery 6-cell (55 WHr) Lithium-Ion
Power External 65W adapter
Warranty 3/3/0
* Intel's numbering system is not a measurement of higher performance.
nc6400
RA253AW#ABA
Processor Intel Core Duo Processor T2500*
Operating System Genuine Windows XP Professional
System Memory 512 MB 667-MHz DDR2 (1 DIMM)
Hard Drive 60-GB 5400 rpm SATA
Display 14.1-inch WXGA
Graphics ATI Mobility Radeon 256MB HyperMemory**
Audio ADI High Definition CODEC
line out/headphone and microphone jacks
integrated microphone
Communications 56K V.92 modem
Integrated Broadcom NetXtreme Gigabit Ethernet PCI Express Controller
(10/100/1000 NIC)
Integrated Wireless Intel PRO/Wireless 3945ABG Network Connection
Bluetooth 2.0
Integrated Security TPM 1.2 Embedded Security Chip
HP Biometric Fingerprint Sensor
Smart Card Reader
Pointing Device Dual pointing devices (both Pointstick and Touchpad)
MultiBay II Drive DVD/CD-RW Combo MultiBay II Drive
Battery 6-cell (55 WHr) Lithium-Ion
Power External 90W adapter
Warranty 3/3/0
* Intel's numbering system is not a measurement of higher performance.
** 256MB HyperMemory is a total of 64MB dedicated video memory and 192MB shared system memory.
QuickSpecs
HP Compaq nc6400 Notebook PC
Standard Features
DA - 12446 North America — Version 18 — August 10, 2007 Page 12

nc6400
EN362UT#ABA
Smart Buy
Processor Intel Core 2 Duo Processor T5500*
Operating System Genuine Windows XP Professional
System Memory 512 MB 667-MHz DDR2 (1 DIMM)
Hard Drive 60-GB 5400 rpm SATA
Display 14.1-inch WXGA
Graphics Intel Graphics Media Accelerator 950
Audio ADI High Definition CODEC
line out/headphone and microphone jacks
integrated microphone
Communications 56K V.92 modem
Integrated Broadcom NetXtreme Gigabit Ethernet PCI Express Controller
(10/100/1000 NIC)
Integrated Wireless Intel PRO/Wireless 3945ABG Network Connection, Bluetooth
Integrated Security TPM 1.2 Embedded Security Chip
HP Biometric Fingerprint Sensor
Smart Card Reader
Pointing Device Dual pointing devices (both Pointstick and Touchpad)
MultiBay II Drive DVD/CD-RW Combo MultiBay II Drive
Battery 6-cell (55 WHr) Lithium-Ion
Power External 65W adapter
Warranty 3/3/0
* Intel's numbering system is not a measurement of higher performance.
nc6400
RB515UA#ABA
Processor Intel Core 2 Duo Processor T5600*
Operating System Genuine Windows XP Professional
System Memory 1024 MB 667-MHz DDR2 (2 DIMM)
Hard Drive 80-GB 5400 rpm SATA
Display 14.1-inch WXGA
Graphics Intel Graphics Media Accelerator 950
Audio ADI High Definition CODEC
line out/headphone and microphone jacks
integrated microphone
Communications 56K V.92 modem
Integrated Broadcom NetXtreme Gigabit Ethernet PCI Express Controller
(10/100/1000 NIC)
Integrated Wireless Intel PRO/Wireless 3945ABG Network Connection, Bluetooth
Integrated Security TPM 1.2 Embedded Security Chip
HP Biometric Fingerprint Sensor
Smart Card Reader
Pointing Device Dual pointing devices (both Pointstick and Touchpad)
MultiBay II Drive DVD/CD-RW Combo MultiBay II Drive
Battery 6-cell (55 WHr) Lithium-Ion
QuickSpecs
HP Compaq nc6400 Notebook PC
Standard Features
DA - 12446 North America — Version 18 — August 10, 2007 Page 13

Power External 65W adapter
Warranty 3/3/0
* Intel's numbering system is not a measurement of higher performance.
nc6400
RB516UT#ABA
Smart Buy
Processor Intel Core 2 Duo Processor T5600*
Operating System Genuine Windows XP Professional
System Memory 1024 MB 667-MHz DDR2 (2 DIMM)
Hard Drive 80-GB 5400 rpm SATA
Display 14.1-inch WXGA
Graphics Intel Graphics Media Accelerator 950
Audio ADI High Definition CODEC
line out/headphone and microphone jacks
integrated microphone
Communications 56K V.92 modem
Integrated Broadcom NetXtreme Gigabit Ethernet PCI Express Controller
(10/100/1000 NIC)
Integrated Wireless Intel PRO/Wireless 3945ABG Network Connection, Bluetooth
Integrated Security TPM 1.2 Embedded Security Chip
HP Biometric Fingerprint Sensor
Smart Card Reader
Pointing Device Dual pointing devices (both Pointstick and Touchpad)
MultiBay II Drive DVD+RW DL MultiBay II Drive
Battery 6-cell (55 WHr) Lithium-Ion
Power External 65W adapter
Warranty 3/3/0
* Intel's numbering system is not a measurement of higher performance.
nc6400
RB524UT#ABA
Smart Buy
Processor Intel Core 2 Duo Processor T5600*
Operating System Genuine Windows XP Professional
System Memory 1024 MB 667-MHz DDR2 (2 DIMM)
Hard Drive 80-GB 5400 rpm SATA
Display 14.1-inch WXGA
Graphics Intel Graphics Media Accelerator 950
Audio ADI High Definition CODEC
line out/headphone and microphone jacks
integrated microphone
Communications 56K V.92 modem
Integrated Broadcom NetXtreme Gigabit Ethernet PCI Express Controller
(10/100/1000 NIC)
QuickSpecs
HP Compaq nc6400 Notebook PC
Standard Features
DA - 12446 North America — Version 18 — August 10, 2007 Page 14

Integrated Wireless Intel PRO/Wireless 3945ABG Network Connection, Bluetooth, HP ev2200
1xEV-DO Broadband Wireless Module (requires Verizon Wireless Service sold
separately)
Integrated Security TPM 1.2 Embedded Security Chip
HP Biometric Fingerprint Sensor
Smart Card Reader
Pointing Device Dual pointing devices (both Pointstick and Touchpad)
MultiBay II Drive DVD/CD-RW Combo MultiBay II Drive
Battery 6-cell (55 WHr) Lithium-Ion
Power External 65W adapter
Warranty 3/3/0
* Intel's numbering system is not a measurement of higher performance.
nc6400
RB522UA#ABA
Processor Intel Core 2 Duo Processor T5600*
Operating System Genuine Windows XP Professional
System Memory 1024 MB 533-MHz DDR2 (2 DIMM)
Hard Drive 80-GB 5400 rpm SATA
Display 14.1-inch WXGA
Graphics Intel Graphics Media Accelerator 950
Audio ADI High Definition CODEC
line out/headphone and microphone jacks
integrated microphone
Communications 56K V.92 modem
Integrated Broadcom NetXtreme Gigabit Ethernet PCI Express Controller
(10/100/1000 NIC)
Integrated Wireless Intel PRO/Wireless 3945ABG Network Connection, Bluetooth, HP ev2200
1xEV-DO Broadband Wireless Module (requires Verizon Wireless Service sold
separately)
Integrated Security TPM 1.2 Embedded Security Chip
HP Biometric Fingerprint Sensor
Smart Card Reader
Pointing Device Dual pointing devices (both Pointstick and Touchpad)
MultiBay II Drive DVD+RW DL MultiBay II Drive
Battery 6-cell (55 WHr) Lithium-Ion
Power External 65W adapter
Warranty 3/3/0
* Intel's numbering system is not a measurement of higher performance.
QuickSpecs
HP Compaq nc6400 Notebook PC
Standard Features
DA - 12446 North America — Version 18 — August 10, 2007 Page 15

nc6400
RB523UA#ABA
Processor Intel Core 2 Duo Processor T5600*
Operating System Genuine Windows XP Professional
System Memory 1024 MB 667-MHz DDR2 (1 DIMM)
Hard Drive 80-GB 7200 rpm SATA
Display 14.1-inch WXGA
Graphics ATI Mobility Radeon 512MB HyperMemory**
Audio ADI High Definition CODEC
line out/headphone and microphone jacks
integrated microphone
Communications 56K V.92 modem
Integrated Broadcom NetXtreme Gigabit Ethernet PCI Express Controller
(10/100/1000 NIC)
Integrated Wireless Intel PRO/Wireless 3945ABG Network Connection, Bluetooth, HP ev2200
1xEV-DO Broadband Wireless Module (requires Verizon Wireless Service sold
separately)
Integrated Security TPM 1.2 Embedded Security Chip
HP Biometric Fingerprint Sensor
Smart Card Reader
Pointing Device Dual pointing devices (both Pointstick and Touchpad)
MultiBay II Drive DVD+RW DL MultiBay II Drive
Battery 6-cell (55 WHr) Lithium-Ion
Power External 65W adapter
Warranty 3/3/0
* Intel's numbering system is not a measurement of higher performance.
** 512MB HyperMemory is a total of 64MB dedicated video memory and 448MB shared system memory.
nc6400
RB517UT#ABA
Smart Buy
Processor Intel Core 2 Duo Processor T5600*
Operating System Genuine Windows XP Professional
System Memory 1024 MB 667-MHz DDR2 (1 DIMM)
Hard Drive 60-GB 5400 rpm SATA
Display 14.1-inch WXGA
Graphics ATI Mobility Radeon 512MB HyperMemory**
Audio ADI High Definition CODEC
line out/headphone and microphone jacks
integrated microphone
Communications 56K V.92 modem
Integrated Broadcom NetXtreme Gigabit Ethernet PCI Express Controller
(10/100/1000 NIC)
Integrated Wireless Intel PRO/Wireless 3945ABG Network Connection, Bluetooth
Integrated Security TPM 1.2 Embedded Security Chip
HP Biometric Fingerprint Sensor
Smart Card Reader
QuickSpecs
HP Compaq nc6400 Notebook PC
Standard Features
DA - 12446 North America — Version 18 — August 10, 2007 Page 16

Pointing Device Dual pointing devices (both Pointstick and Touchpad)
MultiBay II Drive DVD/CD-RW Combo MultiBay II Drive
Battery 6-cell (55 WHr) Lithium-Ion
Power External 90W adapter
Warranty 3/3/0
* Intel's numbering system is not a measurement of higher performance.
** 512MB HyperMemory is a total of 64MB dedicated video memory and 448MB shared system memory.
nc6400
RB518UT#ABA
Smart Buy
Processor Intel Core 2 Duo Processor T7200*
Operating System Genuine Windows XP Professional
System Memory 1024 MB 667-MHz DDR2 (1 DIMM)
Hard Drive 80-GB 7200 rpm SATA
Display 14.1-inch WXGA
Graphics ATI Mobility Radeon 512MB HyperMemory**
Audio ADI High Definition CODEC
line out/headphone and microphone jacks
integrated microphone
Communications 56K V.92 modem
Integrated Broadcom NetXtreme Gigabit Ethernet PCI Express Controller
(10/100/1000 NIC)
Integrated Wireless Intel PRO/Wireless 3945ABG Network Connection, Bluetooth
Integrated Security TPM 1.2 Embedded Security Chip
HP Biometric Fingerprint Sensor
Smart Card Reader
Pointing Device Dual pointing devices (both Pointstick and Touchpad)
MultiBay II Drive DVD+RW DL MultiBay II Drive
Battery 6-cell (55 WHr) Lithium-Ion
Power External 90W adapter
Warranty 3/3/0
* Intel's numbering system is not a measurement of higher performance.
** 512MB HyperMemory is a total of 64MB dedicated video memory and 448MB shared system memory.
QuickSpecs
HP Compaq nc6400 Notebook PC
Standard Features
DA - 12446 North America — Version 18 — August 10, 2007 Page 17

nc6400
RB519UA#ABA
Processor Intel Core 2 Duo Processor T7200*
Operating System Genuine Windows XP Professional
System Memory 1024 MB 667-MHz DDR2 (1 DIMM)
Hard Drive 80-GB 7200 rpm SATA
Display 14.1-inch WXGA
Graphics ATI Mobility Radeon 512MB HyperMemory**
Audio ADI High Definition CODEC
line out/headphone and microphone jacks
integrated microphone
Communications 56K V.92 modem
Integrated Broadcom NetXtreme Gigabit Ethernet PCI Express Controller
(10/100/1000 NIC)
Integrated Wireless Intel PRO/Wireless 3945ABG Network Connection, Bluetooth
Integrated Security TPM 1.2 Embedded Security Chip
HP Biometric Fingerprint Sensor
Smart Card Reader
Pointing Device Dual pointing devices (both Pointstick and Touchpad)
MultiBay II Drive DVD+RW DL MultiBay II Drive
Battery 6-cell (55 WHr) Lithium-Ion
Power External 90W adapter
Warranty 3/3/0
* Intel's numbering system is not a measurement of higher performance.
** 512MB HyperMemory is a total of 128MB dedicated video memory and 384MB shared system memory.
nc6400
RM100AW#ABA
Global
Processor Intel Core 2 Duo Processor T5600*
Operating System Genuine Windows XP Professional
System Memory 1024 MB 667-MHz DDR2 (1 DIMM)
Hard Drive 80-GB 5400 rpm SATA
Display 14.1-inch WXGA
Graphics Intel Graphics Media Accelerator 950
Audio ADI High Definition CODEC
line out/headphone and microphone jacks
integrated microphone
Communications 56K V.92 modem
Integrated Broadcom NetXtreme Gigabit Ethernet PCI Express Controller
(10/100/1000 NIC)
Integrated Wireless Intel PRO/Wireless 3945ABG Network Connection
Bluetooth 2.0
Integrated Security TPM 1.2 Embedded Security Chip
HP Biometric Fingerprint Sensor
Smart Card Reader
Pointing Device Dual pointing devices (both Pointstick and Touchpad)
QuickSpecs
HP Compaq nc6400 Notebook PC
Standard Features
DA - 12446 North America — Version 18 — August 10, 2007 Page 18

MultiBay II Drive DVD/CD-RW Combo MultiBay II Drive
Battery 6-cell (55 WHr) Lithium-Ion
Power External 65W adapter
Warranty 3/3/0
* Intel's numbering system is not a measurement of higher performance.
nc6400
RM106AW#ABA
Global
Processor Intel Core 2 Duo Processor T7200*
Operating System Genuine Windows XP Professional
System Memory 1024 MB 667-MHz DDR2 (1 DIMM)
Hard Drive 80-GB 5400 rpm SATA
Display 14.1-inch WXGA
Graphics ATI Mobility Radeon 512MB HyperMemory**
Audio ADI High Definition CODEC
line out/headphone and microphone jacks
integrated microphone
Communications 56K V.92 modem
Integrated Broadcom NetXtreme Gigabit Ethernet PCI Express Controller
(10/100/1000 NIC)
Integrated Wireless Intel PRO/Wireless 3945ABG Network Connection
Bluetooth 2.0
Integrated Security TPM 1.2 Embedded Security Chip
HP Biometric Fingerprint Sensor
Smart Card Reader
Pointing Device Dual pointing devices (both Pointstick and Touchpad)
MultiBay II Drive DVD/CD-RW Combo MultiBay II Drive
Battery 6-cell (55 WHr) Lithium-Ion
Power External 90W adapter
Warranty 3/3/0
* Intel's numbering system is not a measurement of higher performance.
** 512MB HyperMemory is a total of 64MB dedicated video memory and 448MB shared system memory.
QuickSpecs
HP Compaq nc6400 Notebook PC
Standard Features
DA - 12446 North America — Version 18 — August 10, 2007 Page 19

nc6400
RM130UT#ABA
Smart Buy
Processor Intel Core 2 Duo Processor T5600*
Operating System Genuine Windows XP Professional
System Memory 1024 MB 667-MHz DDR2 (2 DIMM)
Hard Drive 80-GB 5400 rpm SATA
Display 14.1-inch WXGA
Graphics ATI Mobility Radeon 512MB HyperMemory**
Audio ADI High Definition CODEC
line out/headphone and microphone jacks
integrated microphone
Communications 56K V.92 modem
Integrated Broadcom NetXtreme Gigabit Ethernet PCI Express Controller
(10/100/1000 NIC)
Integrated Wireless Intel PRO/Wireless 3945ABG Network Connection, Bluetooth\
HP hs2300 HSDPA Broadband Wireless Module
Integrated Security TPM 1.2 Embedded Security Chip
HP Biometric Fingerprint Sensor
Smart Card Reader
Pointing Device Dual pointing devices (both Pointstick and Touchpad)
MultiBay II Drive DVD/CD-RW Combo MultiBay II Drive
Battery 6-cell (55 WHr) Lithium-Ion
Power External 65W adapter
Warranty 3/3/0
* Intel's numbering system is not a measurement of higher performance.
** 512MB HyperMemory is a total of 128MB dedicated video memory and 384MB shared system memory.
QuickSpecs
HP Compaq nc6400 Notebook PC
Standard Features
DA - 12446 North America — Version 18 — August 10, 2007 Page 20
