HP Pavilion N5415 Quick start guide

HP Notes
02 April 2001
This file contains up-to-date information for your HP notebook PC on these topics:
¾Software bundled on your computer
¾DVD and video file playback
¾Switching to a TV display
¾Fn hot keys on an external keyboard
¾Hibernate mode
¾Pad Lock button
¾TV set after resume
¾Windows 2000 – Running the Tour of Windows 2000
¾Problems resuming from standby or hibernate
¾Easy Internet Access issue
¾Battery life
¾Additional CPU and display specifications
¾To recover the factory installation of your hard disk
¾SXGA+ Resolution on 15-Inch Displays
You can find additional current information about your computer on the HP notebook Web site,
www.hp.com/notebooks.
Software bundled on your computer
Your HP notebook PC comes with preinstalled software, and various models are configured with
different combinations of software.
Among the applications included are:
> Adobe Acrobat Reader, which allows you to read documents in Acrobat format, used
frequently on the Web
> MusicMatch Jukebox, which controls play of MP3 music files
> McAfee VirusScan, which protects your computer from files that can be harmful
If the computer has a DVD drive or a CD-RW/DVD combo drive, also included is:
> a DVD movie player, which controls DVD operation
If the computer has a CD-RW drive or a CD-RW/DVD combo drive, also included is:
> Adaptec Easy CD Creator software, which allows you to read, write, and rewrite CDs
If the computer has Windows 98 or Windows ME, you also have:
> Quicklink III, which permits fax transfer and data transfer
If the computer is an HP Omnibook Notebook PC, you also have:
> HP TopTools for Notebooks, which allows administrators to manage networked systems

DVD and video file playback
While you are playing a DVD disc—or while you are playing any video file in the AVI (Audio
Video Interleave) or MPEG (Moving Picture Experts Group) format—these functions are not
supported:
> Switching among built-in display, external display, and simultaneous displays using Fn+F5.
Select the display before starting the DVD player.
> Modifying the resolution or color depth of your display. If you want to change these settings,
do it before starting the DVD player.
> Dragging the DVD/AVI playback window to the secondary display when using dual monitors
in Windows 98. DVD/AVI playback is supported only on the primary display.
Some combinations of color depth and resolution are not supported in DVD/AVI playback. If
you receive an error message with a DVD, reduce color depth or display resolution.
If your hp notebook has a DVD drive, you may have to manually install the DVD movie player.
To do this, run c:\hp\programs\dvd\setup.exe.
Switching to a TV display
To switch to a TV display connected to the TV output port, use the TV icon in the system tray
(to the right of the taskbar).
The shortcut key sequence Fn+F5 switches between the internal LCD and an external display
connected to the VGA port only. It does not switch to a TV display connected to the TV output
port.
Fn hot keys on an external keyboard
When using combination hot keys (shortcut key sequences) on an external keyboard—which is
equivalent to using the Fn key on the HP notebook keyboard—use the Ctrl and Alt keys on the
left side of the external keyboard. For example, Left Ctrl+Left Alt+F1 on an external keyboard
decreases the display’s brightness.
These features are not functional when using an external USB keyboard.
Hibernate mode
In Windows 2000 and Windows ME you can set a timeout to automatically enter hibernate mode.
For Windows 2000, Windows 98 and Windows ME, the hibernate mode occurs automatically
when battery power reaches a critically low level. It is possible to lower the critical low battery
setting, however, HP does not recommend that you lower the defaults. Lowering the default
values could cause your unit to not hibernate properly and could result in loss of unsaved data.

Pad Lock button
When you disable (or reenable) the touch pad by pressing the Pad Lock button, avoid contact
with the touch pad itself at the same time you are pressing the Pad Lock button. Simultaneous
contact will not allow the Pad Lock button to work properly until a delay occurs.
TV set after resume
If you are using a TV set as the monitor for your computer and it does not work properly after
standby and resume, check to see that the BIOS setting for Video Display Device is Auto (which
is the default setting):
1. Shut down Windows and restart the computer (Click Start, Shut Down, Restart).
2. When you see the HP logo, press F2 to enter the BIOS Setup utility.
3. In the Main Menu, select Video Display Device and set it to Auto.
4. After you have finished making changes, press F10. Press Enter, then Enter again, to confirm
and reboot the computer.
Running the Tour of Windows 2000
In the Getting Started window, you can click Discover Windows for a tour of Windows 2000. If
you’re prompted for a location, type c:\tour to start the tour.
Problems resuming from standby or hibernate
If you experience problems, resuming your notebook from standby or hibernate, try the
following:
1. close all applications before going into standby or hibernate
2. uninstall applications you installed before having the problems
3. uninstall drivers (for example printer drivers) you installed before having the problems
If recently installed applications or drivers cause the problems, try contacting the software
application or device vendor for additional support.
Known issues using WIN 98SE and WIN ME
When using the “Easy Internet Signup”, the tab and arrow keys do not work. Use the Mouse to
navigate.
Battery life
To maintain maximum battery capacity and accuracy of the battery gauge, we recommend that
the user perform the following procedure about once a month:
1. Charge the battery to 100%.
2. Discharge the battery fully: use the computer without ac power until the battery is fully
discharged and the computer goes into the hibernate mode (suspends to disk).
3. Connect ac power and charge the battery to 100% with no power interruptions.

Additional CPU and display specifications
Certain models in this product line will have an Intel PIII CPU with 1GHz FSB. (This is a higher
speed than specified in the user’s guides.)
Certain models in this product line will have SXGA+ displays.
To recover the factory installation of your hard disk
The following procedure describes how to recover the original Windows software and operating
system that came with your computer.
CAUTION: This procedure will format the hard disk drive. After the hard disk drive is
formatted, you’ll need to reinstall any applications. Reformatting the hard disk drive will
erase all data on the disk.
1. Back up all data from your hard disk.
2. Connect the AC adapter to the computer.
3. Insert the bootable Recovery CD in the CD-ROM drive.
If the computer is turned off, you must insert a straightened paper clip into the hole on the
front of the drive in order to open it.
4. Reboot and, when you see the HP logo, press Esc.
5. Select the CD-ROM drive as the first boot device and reboot.
The recovery process can take about 10 or 15 minutes. Do not interrupt the process or unplug the
AC adapter until the process is completed.
You can find more details about recovering the factory installation of Windows on the Recovery
CD: the file readme.txt is in the CD’s root directory.
Note: Windows 98 supports the FAT16 and FAT32 file systems. Windows 2000 supports the
FAT16, FAT32, and NTFS file systems. Windows ME supports the FAT32 file system.
SXGA+ Resolution on 15-Inch Displays
Some models with 15-inch displays have SXGA+ resolution (1400x1050) instead of XGA
resolution (1024x768).
If items on the screen seem too small for viewing comfortably, you can adjust certain display
settings while maintaining the SXGA+ resolution. In Control Panel, open Display and try the
following suggested settings on the Appearance tab.
Item Suggested Default
Active Title Bar - Size 21 18
Active Title Bar - Font Size 12 8
Active Window Border - Size 2 1
Caption Buttons - Size 21 18
Icon - Size 42 32
Icon - Font Size 12 8
Icon Spacing (Horizontal) - Size 60 43

Icon Spacing (Vertical) - Size 54 43
Inactive Title Bar - Size 21 18
Inactive Title Bar - Font Size 12 8
Inactive Windows Border - Size 2 1
Menu - Size 21 18
Menu - Font Size 12 8
Message Box - Font Size 12 8
Pallette Title - Size 21 15
Pallette Title - Font Size 12 8
Scrollbar - Size 20 16
Selected Items - Size 21 18
Selected Items - Font Size 12 8
ToolTip - Font Size 12 8
