HP ProBook 5330m User instructions

1. WLAN and WWAN antennas (select models) 10. Touchpad buttons
2. Dual-microphone array 11. Hard drive activity / HP 3D DriveGuard LED
3. Integrated 2 MP webcam 12. VGA connector
4. Wireless on/off button 13. RJ-45/Ethernet port
5. QuickLook button 14. DisplayPort
6. QuickWeb button 15. Power connector
7. HP Fingerprint Sensor (optional) 16. Battery charging LED
8. Stereo speakers 17. Power button
9. Touchpad with scroll zone
1. Secure Digital (SD)/MMC slot 4. (2) USB 2.0 Ports
2. USB 2.0 Port (powered) 5. Lock slot
3. Combo stereo headphone/mic jack
QuickSpecs
HP ProBook 5320m Notebook PC
Overview
DA - 13671 Worldwide QuickSpecs — Version 6 — 12.29.2010 Page 1

1. Battery bay 4. Battery release latch
2. SIM slot for WWAN (select models) – inside battery bay 5. Wireless/memory/hard drive access door
3. Vents
At A Glance
Genuine Windows 7 versions, Genuine Windows Vista Home Basic, SUSE Linux Enterprise Desktop 11, Red Flag Linux
(PRC only), or FreeDOS
Sleek, lightweight design starting at 3.79 lb/1.72 kg and 0.93-inch/23.5 mm thin
Durable anodized aluminum display enclosure and palm rest in espresso color; magnesium alloy bottom case
Two external monitor ports: DisplayPort for latest display technology, plus VGA for legacy displays and projectors
HP DayStarter displays your calendar and battery charge while Windows starts up
13.3-inch diagonal LED-backlit HD 16:9 display (anti-glare or optional BrightView); HP Privacy Filter support
Choice of Intel® Celeron® ultra-low voltage processor or standard voltage Intel Core™ i5 or i3 processor
Enhanced security features including optional HP Fingerprint Sensor, HP ProtectTools with Central Management, Face
Recognition for HP ProtectTools, HP SpareKey, and HP Disk Sanitizer
HP QuickSync for synchronizing data between two PCs or a PC and portable storage devices
Secure Digital (SD/MMC) slot
Flexible wireless connectivity options:
Integrated HP un2420 EV-DO/HSDPA Mobile Broadband Module provides worldwide Gobi mobile Internet
technology with GPS
Integrated 802.11 a/b/g/n or b/g/n wireless LAN module
Bluetooth® 2.1
BFR/PVC-free *
Choice of 250/320/500-GB 2.5-inch SMART SATA II hard drive protected by HP 3D DriveGuard;
or 80/128 GB 2.5-inch Solid State Drive
Optional HP External USB 2.0 CD/DVD R/RW Drive and HP USB 2.0 Docking Station
Integrated 2 MP Webcam and dual-microphone array
HP QuickLook 3 for instant access to email, calendar, and contact information; HP QuickWeb for convenient internet
access
HP Power Assistant to conserve power, stretch battery run-time, accurately monitor your reported power need, and report
QuickSpecs
HP ProBook 5320m Notebook PC
Overview
DA - 13671 Worldwide QuickSpecs — Version 6 — 12.29.2010 Page 2

workforce power consumption
* HP ProBook 5320m is brominated flame retardant and polyvinyl chloride-free (BFR/PVC-free); meeting the evolving definition of
'BFR/PVC-free' as set forth in the "iNEMI Position Statement on the 'Definition of Low-Halogen' Electronics (BFR/CFR/PVC-Free)'".
Plastic parts contain < 1000 ppm (0.1%) of bromine [if the Br source is from BFRs] and < 1000 ppm (0.1%) of chlorine [if the Cl
source is from CFRs or PVC or PVC copolymers]. Power supply and power cords are not BFR/PVC-free. Service parts after
purchase may not be BFR/PVC-free.
QuickSpecs
HP ProBook 5320m Notebook PC
Overview
DA - 13671 Worldwide QuickSpecs — Version 6 — 12.29.2010 Page 3

Processors Intel Core i5-450M Processor (2.40 GHz, 35W, 3 MB L3 cache) *
Up to 2.53 GHz with Intel Turbo Boost Technology
Intel Core i3-370M Processor (2.40 GHz, 35W, 3 MB L3 cache) *
Intel Core i3-350M Processor (2.26 GHz, 35W, 3 MB L3 cache) *
Intel Celeron Processor U3400 (1.06 GHz, 18W ultra-low voltage, 2 MB L3 cache) *
* Intel's numbering is not a measurement of higher performance.
NOTE: Processor speed denotes maximum performance mode; processors will run at lower speeds in
battery optimization mode.
Operating System Preinstalled Genuine Windows 7 Professional Edition 32 *
Genuine Windows 7 Professional Edition 64 *
Genuine Windows 7 Home Premium Edition 32 *
Genuine Windows 7 Home Premium Edition 64 *
Genuine Windows 7 Home Basic * (select countries)
Genuine Windows Vista Home Basic 32 **
SUSE Linux Enterprise Desktop 11
Red Flag Linux (PRC only)
FreeDOS
Supported Genuine Windows Vista Business **
Genuine Windows Vista Enterprise **
Certified SUSE Linux Enterprise Desktop 11
* System may require upgraded and/or separately purchased hardware and/or a DVD drive to
install the Windows 7 software and take full advantage of Windows 7 functionality.
See http://www.microsoft.com/windows/windows-7/ for details.
** Certain Windows Vista product features require advanced or additional hardware. See:
http://www.microsoft.com/windowsvista/getready/hardwarereqs.mspx and
http://www.microsoft.com/windowsvista/getready/capable.mspx for details. Windows Vista
Upgrade Advisor can help you determine which features of Windows Vista will run on your computer.
To download the tool, visit: http://www.windowsvista.com/upgradeadvisor .
Chipset Mobile Intel HM57 Express Chipset
Graphics Intel HD Graphics
Microsoft DirectX 10 (Shader 4.0) and OpenGL 2.0 capable
QuickSpecs
HP ProBook 5320m Notebook PC
Standard Features
DA - 13671 Worldwide QuickSpecs — Version 6 — 12.29.2010 Page 4

Display Internal 13.3-inch diagonal LED-backlit HD anti-glare (1366 × 768 resolution)
13.3-inch diagonal LED-backlit HD BrightView (1366 × 768 resolution)
HP Privacy Filter support
External Up to 32-bit per pixel color depth
VGA port supports resolutions up to 1600 x 1200 at 75 Hz, and lower
resolutions at up to 100 Hz
DisplayPort supports resolutions up to 2560 x 1600, 30-bit color depth at
60 Hz with full HD (1920 x 1080) monitors, 24-bit color depth at 120
Hz
NOTE: Resolutions are dependent upon monitor capability, and resolution
and color depth settings.
Memory Standard 1 GB, 2 GB, or 4 GB DDR3 1333 MHz SDRAM SODIMM *
one SODIMM slot
Maximum Supports up to 4 GB maximum
* All memory modules operate at the maximum system supported speed of 1066 MHz, except in the
case of the Intel Celeron U3400 Processor ULV processor, which limits memory speed to 800 MHz.
NOTE: Due to the non-industry standard nature of some third-party memory modules, we recommend
HP branded memory to ensure compatibility. Availability of 4 GB of memory requires a Windows 64-
bit operating system or Linux. With Windows 32-bit operating systems, memory above 3 GB may not
all be available due to system resource requirements.
Communications Integrated Realtek Ethernet (10/100/1000 NIC) *
* The term "10/100/1000" or "Gigabit" Ethernet indicates compliance with IEEE standard 802.3ab
for Gigabit Ethernet, and does not connote actual operating speed of 1 Gb/s. For high-speed
transmission, connection to a Gigabit Ethernet server and network infrastructure is required.
Wireless Devices Support for a broad range of secure, integrated wireless LAN and wireless WAN options featuring
support for the latest industry standards. Mobile Broadband (WWAN) requires a Windows operating
system and is available in select countries as a standard, factory configurable feature or as an option
to be added later. Integrated Bluetooth is also available (factory configurable only) and can be
combined with any of the supported wireless LAN and wireless WAN options.
HP un2420
EV-DO/HSPA Mobile
Broadband Module
Integrated mobile broadband module with Gobi global mobile Internet
technology that provides connectivity to both CDMA (EVDO) and UMTS
(HSPA) networks. It also provides GPS functionality for various mapping
applications and security applications.
NOTE: Separately purchased mobile network operator service is required.
Two 850/900/1575/1800/1900/2100 MHz antennas integrated in
the top of the display panel support current and future WWAN
technologies.
All 802.11 integrated
wireless LAN options
Wi-Fi CERTIFIED *
Cisco Compatible Extensions support
Wired Equivalent Privacy (WEP) support up to 128-bit keys
Wi-Fi Protected Access (WPA) and WPA2 support
802.1x authentication support, including EAP-TLS, EAP-TTLS, PEAP-GTC,
PEAP-MSCHAPv2, and LEAP
Advanced Encryption Standard (AES) support
Two antennas integrated in the display enclosure
QuickSpecs
HP ProBook 5320m Notebook PC
Standard Features
DA - 13671 Worldwide QuickSpecs — Version 6 — 12.29.2010 Page 5

Broadcom 43224AGN
802.11a/b/g/n
Wi-Fi Adapter
Integrated support for 802.11a, b, g, and n
Up to 300 mbps data rate
Broadcom 4313GN
802.11b/g/n
WiFi Adapter
Integrated support for 802.11 b, g, and n
Up to 72 mbps data rate
HP Integrated Module
with Bluetooth 2.1+EDR
Wireless Technology
Bluetooth Specification v2.1 compliant
Works with a wide range of Bluetooth devices
Keyboard The HP spill-resistant keyboard design minimizes the risk of damage to sensitive components. The
101/102-key compatible keyboard features an industry standard, full-pitch key layout with desktop
keyboard features, such as the isolated inverted-T cursor control keys, editing keys, both left and right
control and alt keys, and 12 function keys. US and International key layouts are available. Other
features include an integrated numeric keypad, hotkeys for instant access to power conservation,
brightness, and other features, 19 mm x 19 mm key pitch (center-to-center spacing), 2.0 mm stroke,
and comfort-dished keycaps.
HP DuraKeys is a clear coating applied over the notebook keyboard that helps protect the finish and
the printed characters on the keys.
Pointing device Touchpad with scroll zone, two pick buttons
Gestures support: two-finger scroll, zoom, pinch
Expansion card slots Secure Digital slot Supports SD (Secure Digital), MMC (MultiMedia Card)
Storage Internal Storage Device 250/320/500 GB 7200 rpm 2.5-inch SMART SATA II Hard Drive
or
80/128 GB 2.5-inch Solid State Drive*
NOTE: Hard drives are customer removable and will withstand multiple insertion/removal cycles. Up
to 10 GB is reserved for the system recovery software.
HP 3D DriveGuard
(Windows models only)
The hard drive is mounted to the notebook frame, reducing the transmission
of shock away from the hard drive. Uses three-axis digital motion detection
with intelligent sensitivity to help protect the hard drive during normal use
from shock and vibration. The digital accelerometer temporarily halts all
data transfer and parks the hard drive when abrupt motion is detected.
Optical drive Optional HP External USB 2.0 CD/DVD R/RW Drive
* Installation of a Solid State Drive on systems with Windows 7 requires system memory of 2 GB or
more.
QuickSpecs
HP ProBook 5320m Notebook PC
Standard Features
DA - 13671 Worldwide QuickSpecs — Version 6 — 12.29.2010 Page 6

Interfaces External monitor Two – DisplayPort and VGA
Combo stereo
headphone/
mic jack
One
Power connector One
RJ-45/Ethernet One
USB 2.0 Three (including one powered USB 2.0 port)
LED status indicators Nine
Audio/Visual HD audio (HP Premier Sound)
Stereo speakers
Integrated dual-microphone array
Combo stereo headphone/mic jack
2 MP Webcam
Supports videoconferencing and still image capture
Large image sensor for excellent color matching and good low light sensitivity
Up to 30 frames/sec
Fixed focus lens
Video capture at VGA, 1.3 Mpixel, and 2 Mpixel resolutions
16-bit true color (camera sensors output YCrCb format among others)
Software Preinstalled software with
Windows operating
system
HP Recovery Manager (available with Windows 7 or Vista only)
HP Support Assistant (available with Windows 7 or Vista only)
HP ProtectTools Security Manager
HP ProtectTools for Central Management
Face Recognition for HP ProtectTools
HP QuickLaunch Buttons Software
HP QuickLook 3
HP QuickWeb
HP QuickSync
HP Power Assistant
HP Connection Manager 3.1
HP Wireless Assistant
HP DayStarter
HP Webcam Software (select models)
Roxio Creator 10 (select models)
Microsoft Office 2010 preloaded (purchase of a Product
Key required to activate a full Office 2010 suite)*
Corel Home Office 60-day trial
McAfee Total Protection **
Skype
WinZip 14.5 trial
Additional software
available from the web
HP SoftPaq Download Manager
QuickSpecs
HP ProBook 5320m Notebook PC
Standard Features
DA - 13671 Worldwide QuickSpecs — Version 6 — 12.29.2010 Page 7

* Microsoft Office 2010 Preloaded includes reduced functionality versions of Word and Excel.
Purchase of Product Key required to activate full Office 2010 suite available at participating
resellers/retailers and http://www.office.com .
* 60 day trial period for McAfee Total Protection for Small Business software. Internet access required
to receive updates. First update included. Subscription required for updates thereafter.
HP Recovery Manager Models shipped with Windows 7 or Windows Vista include HP Recovery Manager. HP Recovery
Manager enables fast recovery of the factory preinstalled image if the system becomes corrupted or if
important system files are accidentally deleted. Up to 10 GB of the hard drive is reserved for the
system recovery software.
Security Standard Features HP ProtectTools Security Manager
Face Recognition for HP ProtectTools
One-Step Logon
Enhanced Pre-Boot Security
HP SpareKey
HP Disk Sanitizer
Setup Password
Lock Slot
Support for Computrace ** LoJack Pro for HP ProtectTools
HP Privacy Filter (must be purchased separately)
Optional Features HP Fingerprint Sensor Enhanced sensor scans the fingerprint to
uniquely identify and authenticate a person.
HP Privacy Filter Narrows viewing area so that screen data is
visible only to persons directly in front of the
monitor.
Computrace ** LoJack
Pro Premium for HP
ProtectTools with GPS
Tracking
Subscription based security solution providing
the ability to track, initiate physical recovery,
conduct asset management, and perform
remote data delete by utilizing GPS technology.
GPS functionality requires HP un2420 EV-
DO/HSPA Mobile Broadband Module.
For more information on HP security solutions refer to: http://www.hp.com/go/security .
QuickSpecs
HP ProBook 5320m Notebook PC
Standard Features
DA - 13671 Worldwide QuickSpecs — Version 6 — 12.29.2010 Page 8

HP ProtectTools Security
Manager with Central
Management
HP ProtectTools Security Manager is the security platform for business notebooks and desktops. The HP
ProtectTools Security Manager is an extensible client security console that delivers enhanced security
capabilities through add-on software modules. The following modules are available on the hard drive
(also downloadable from the web) and can be configured in Software Setup:
Credential Manager for HP ProtectTools
Device Access Manager for HP ProtectTools
Drive Encryption for HP ProtectTools
File Sanitizer for HP ProtectTools
Privacy Manager for HP ProtectTools (Chat & Sign)
Computrace LoJack Pro for HP ProtectTools
HP ProtectTools is now capable of being centrally managed from a single control point. HP
ProtectTools is management ready out of the box, in partnership with Digital Persona, and provides
features that customers expect from a centrally managed security solution, such as user provisioning,
credential reset, and system and network revocation . Central Management is available in two feature
levels:
Digital Persona Pro Enterprise: Designed for environments with Active Directory. For large
businesses, as well as smaller businesses utilizing an active directory based infrastructure. Gives
IT Managers the ability to create role based security policies, provision users, and create login
policies based on passwords, biometrics or smart cards. Management features also include
remote credential recovery in case the user forgets the password, loses the smart card, or
cannot use the fingerprint reader for any reason. In addition, advanced auditing capabilities
are also built in.
Digital Persona Workgroup Manager: Designed for environments without Active Directory. This
option can be used by smaller businesses as well as workgroups within large organizations.
Workgroup Manager offers features similar to Digital Persona Pro Enterprise, but without active
directory integration. Workgroup activation is built into HP ProtectTools, and activation of up to
5 seats is completely free.
Power Supply External 65-watt Smart AC adapter, 6-foot (1.8-meter) power cord included.
Total length including external AC adapter:
Regular: 12 feet (3.66 meter);
Travel Adapter: 10.2 feet (3.12 meter)
HP Fast Charge*
*HP Fast Charge recharges the 6-cell battery up to 90% within 90 minutes when the system is off.
Fast Charge Technology does not apply to the 4-cell primary battery.
Battery Primary Battery 6-cell (62 WHr) high capacity Lithium-Ion
4-cell (41 WHr) high capacity Lithium-Ion
QuickSpecs
HP ProBook 5320m Notebook PC
Standard Features
DA - 13671 Worldwide QuickSpecs — Version 6 — 12.29.2010 Page 9

Battery Life With Solid State Drive With Hard Drive
Ultra-low voltage
processor
Standard voltage
processor
Ultra-low voltage
processor
Standard voltage
processor
6-cell Primary Battery Up to 9 hours and
30 minutes
Up to 9 hours Up to 8 hours and
15 minutes
Up to 8 hours
4-cell Primary Battery Up to 6 hours and
30 minutes
Up to 6 hours and
15 minutes
Up to 5 hours and
45 minutes
Up to 5 hours and
30 minutes
NOTE: Battery life will vary depending on the product model, configuration, loaded applications,
features, use, wireless functionality and power management settings. The maximum capacity of the
battery will naturally decrease with time and usage. See MobileMark07 battery benchmark
www.bapco.com/products/mobilemark2007 for additional details.
System Standby Time Up to 1 week
Power Conservation Supports enhanced Intel SpeedStep technology (allows Battery Optimized Mode, Maximum
Performance Mode, or Automatic mode)
Intel Display Power Saving technology
Hibernation
Standby
ACPI compliance
Service and Support HP Services includes a one-year standard parts and labor warranty, pick-up or carry-in, and toll-free 7
x 24 hardware technical phone support (depending on model). On-site service and warranty
upgrades are also available (depending on model). HP Care Pack Services extend service contracts
beyond the standard warranties. To choose the right level of service for your HP product, use the HP
Care Pack Services Lookup Tool at: http://www.hp.com/go/lookuptool . Additional HP Care Pack
Services information by product is available at: http://www.hp.com/hps/carepack .
NOTE: Certain restrictions and exclusions apply. Consult the HP Customer Support Center for details.
http://h20000.www2.hp.com/bizsupport/TechSupport/ProductRoot.jsp .
QuickSpecs
HP ProBook 5320m Notebook PC
Standard Features
DA - 13671 Worldwide QuickSpecs — Version 6 — 12.29.2010 Page 10

Memory HP 1 GB (DDR3 1333 MHz) * SODIMM AT911AA
HP 2 GB (DDR3 1333 MHz) * SODIMM AT912AA
HP 4 GB (DDR3 1333 MHz) * SODIMM AT913AA
* All memory modules operate at the maximum system supported speed of 1066
MHz.
Storage HP External USB 2.0 CD/DVD R/RW Drive FS943AA
HP 250GB Pocket Media Drive FE477AA
HP 320GB 7200 rpm Primary SATA HDD AS282AA
Expansion Solutions HP USB 2.0 Docking Station FQ834AA
HP Essential USB 2.0 Port Replicator AQ731AA
HP Basic Adjustable Stand AL549AA
HP Adjustable Dual Monitor Stand AW664AA
HP Adjustable Display Stand AW663AA
HP Display & Notebook Stand AW662AA
HP Dual Hinge Notebook Stand AW661AA
Power HP 65W Smart AC Adapter ED494AA
HP 90W Smart AC/Auto/Air Combo Adapter AJ652AA
HP 90W Smart Auto/Truck Adapter ED493AA
HP Smart 65W Travel AC Adapter AU155AA
HP 65W Slim Adapter AX727AA
HP 4-Cell Li-Ion Primary Battery AT907AA
HP 6-Cell Li-Ion Primary Battery TBD
Carrying Cases HP Basic Carrying Case AJ078AA
HP Basic Backpack AM863AA
HP Basic Messenger Carrying Case AP355AA
HP Deluxe Roller Case GD405AA
HP Value Nylon Case RR314AA
HP Universal Nylon Case RR315AA
HP Deluxe Nylon Backpack RR317AA
Compaq Top Load Carrying Case AX338AA
HP Elite Leather Top Load Case AX675AA
HP Elite Leather Messenger AX676AA
HP Executive Top Load Case AX677AA
HP Executive Messenger AX678AA
HP Elite Top Load Case AX679AA
HP Elite Slim Top Load Case AX680AA
QuickSpecs
HP ProBook 5320m Notebook PC
Options
DA - 13671 Worldwide QuickSpecs — Version 6 — 12.29.2010 Page 11

HP Elite 13.3 Slip Case AX682AA
HP Professional Slim Top Load Case AY530AA
Security HP Notebook Combo Lock AY475AA
HP Privacy Filter for 13.3-inch AU649AA
Input/Output Devices HP USB Keyboard & Mouse Bundle RC465AA
HP USB/PS2 Optical 2-Button Scroll Mouse DC369A
HP USB Optical Travel Mouse RH304AA
HP Mobile USB 2.0 Speakers FS944AA
HP Bluetooth Stereo Headphones AR084AA
HP Wireless Optical Mouse AR085AA
HP Mobile Audio Speakers FS944AA
HP Mobile Productivity Bundle AQ729AA
HP Notebook Companion Projector AX325AA
HP Digital Premium Stereo Headset KJ270AA
HP Premium Autofocus Webcam KQ245AA
HP Migration Cable for Windows 7 AY493AA
Notebook Multi-Purpose Cleaning Kit (North America) BL528AA
Wireless HP un2420 EV-DO/HSDPA Mobile Broadband Module WD301AA
QuickSpecs
HP ProBook 5320m Notebook PC
Options
DA - 13671 Worldwide QuickSpecs — Version 6 — 12.29.2010 Page 12

Supports 1333 MHz * DDR3 SDRAM
One DIMM slot
Standard Memory 1 GB (1 GB x 1)
2 GB (2 GB x 1)
4 GB (4 GB x 1)
Optional Memory
Upgrades
Memory slot is user accessible. Please refer to the Hardware and Software Guide for installation
procedures.
NOTE: Due to the non-industry standard nature of some third-party memory modules, we strongly recommend using only HP
branded memory modules to ensure compatibility. Availability of 4 GB of memory requires a Windows 64-bit operating system or
Linux. With Windows 32-bit operating systems, memory above 3 GB may not all be available due to system resource
requirements.
Memory Upgrades HP 2 GB (DDR3 1333 MHz) * SODIMM AT912AA
HP 4 GB (DDR3 1333 MHz) * SODIMM AT913AA
* All memory modules operate at the maximum system supported speed of 1066
MHz.
QuickSpecs
HP ProBook 5320m Notebook PC
Memory
DA - 13671 Worldwide QuickSpecs — Version 6 — 12.29.2010 Page 13

Internal Storage Device
Hard Drives (2.5-inch SMART SATA II) Quantity Supported Drive Bay
250 GB 7200 rpm One Dedicated hard drive bay
320 GB 7200 rpm One Dedicated hard drive bay
500 GB 7200 rpm One Dedicated hard drive bay
Solid State (2.5-inch)*
80 GB Solid State Drive One Dedicated hard drive bay
128 GB Solid State Drive One Dedicated hard drive bay
* Installation of a Solid State Drive on systems with Windows 7 requires system memory of 2 GB or more.
QuickSpecs
HP ProBook 5320m Notebook PC
Storage
DA - 13671 Worldwide QuickSpecs — Version 6 — 12.29.2010 Page 14

System Unit Dimensions (HxWxD) 0.93 in x 12.9 in x 8.7 in
23.5 mm x 328 mm x 221 mm
Weight Starting from 3.79 lb (1.72 kg)
NOTE: Starting weight includes 4-cell battery, hard drive, 1 GB memory. Weight varies by configuration
and components.
Stand-Alone Power
Requirements
(AC Power)
Nominal Operating
Voltage
18.5 V
Average Operating Power TBD W
Max Operating Power < 65 W
Temperature Operating 32° to 95° F (0° to 35° C) (not writing optical)
41° to 95° F (5° to 35° C) (writing optical)
Non-operating -4° to 140° F (-20° to 60° C)
Relative Humidity Operating 10% to 90%, non-condensing
Non-operating 5% to 95%, 101.6° F (38.7° C) maximum wet
bulb temperature
Shock Operating 125 G, 2 ms, half-sine
Non-operating 200 G, 2 ms, half-sine
Random Vibration Operating 0.75 grms
Non-operating 1.50 grms
Altitude
(unpressurized)
Operating –50 to 10,000 ft (–15.24 to 3,048 m)
Non-operating –50 to 40,000 ft (–15.24 to 12,192 m)
Industry Standard
Certifications
UL Yes
CSA Yes
FCC Compliance Yes
EPEAT TBD (Silver target) *
ICES Yes
Australia / NZ A-Tick
Compliance
Yes
CCC Yes
Japan VCCI Compliance Yes
MIC Yes
BSMI Yes
CE Marking Compliance Yes
BNCI or BELLIS Yes
CIT Yes
GOST Yes
Saudi Arabian
Compliance (ICCP)
Yes
SABS Yes
UKRSERTCOMPUTER Yes
QuickSpecs
HP ProBook 5320m Notebook PC
Technical Specifications
DA - 13671 Worldwide QuickSpecs — Version 6 — 12.29.2010 Page 15

* EPEAT Registered TBD in U.S. (requires Microsoft Windows). EPEAT registration varies by country. See
www.epeat.net for registration status by country.
For accessibility information on HP products, please visit: http://www.hp.com/accessibility .
HP 65W Smart AC
Adapter
Dimensions 4.17 x 1.85 x 1.1 in (10.6 x 4.7 x 2.8 cm)
Weight 0.62 lb (280 g)
Input 100 to 240 VAC
Input Efficiency 83% min at 115 VAC
Input frequency range 47 to 63 Hz
Input AC current 1.7 A at 90 VAC, 0.85 A at 180 VAC
Output Output power 65W
DC output 18.5V
Hold-up time 5 msec at 115 VAC inputOutput current limit
Output current limit <11A, Over voltage protection- 29V max
automatic shutdown
Connector 3 pin/grounded, mates with interchangeable cords
Environmental Design Operating temperature 32° to 104° F (0° to 40° C)
Non-operating (storage)
temperature
–4° to 149° F (–20° to 65° C)
Altitude 0 to 10,000 ft (0 to 3,048 m)
Humidity 20% to 80%
Storage Humidity 10% to 90%
EMI and Safety
Certifications
CE Mark – full compliance with LVD and EMC directives; Worldwide safety
standards – IEC60950, EN60950, UL60950, Class1, SELV; Agency
approvals – C-UL-US, NORDICS, DENAN, EN55022 Class B, FCC Class
B, CISPR22 Class B, CCC, NOM-1 NYCE; MTBF – over 200,000 hours at
25°C ambient condition.
NOTE: Unless otherwise noted, temperature limits listed in the following component specifications relate to the internal temperatures
of these components and not to the environment in which the PC is operating.
QuickSpecs
HP ProBook 5320m Notebook PC
Technical Specifications
DA - 13671 Worldwide QuickSpecs — Version 6 — 12.29.2010 Page 16

6-Cell (62 WHr) Lithium-
on battery
Dimensions (HxWxL) 0.8 x 2.0 x 8.3 in (2.0 x 5.1 x 21.1 cm)
Weight 0.72 lb (0.325 kg)
Cells/Type 6-cell Lithium-Ion
Energy Watt-hour Capacity 62Wh
Temperature Operating (Charging) 32° to 113° F (0° to 45° C)
Operating (Discharging) 14° to 140° F (–10° to 60° C)
Non-operating –4° to 140° F (–20° to 60° C)
Battery Re-Charge Time System in OFF Mode or
Standby
2.5 hours
System ON 3 to 5 hours (depending on system power
consumption)
4-Cell (41 WHr) Lithium-
on battery
Dimensions (H x W x L) 0.8 x 2.0 x 8.3 in (2.0 x 5.1 x 21.1 cm)
Weight 0.56 lb (0.252 kg)
Cells/Type 4-cell Lithium-Ion
Energy Watt-hour Capacity 41Wh
Temperature Operating (Charging) 32° to 113° F (0° to 45° C)
Operating (Discharging) 14° to 140° F (–10° to 60° C)
Non-operating –4° to 140° F (–20° to 60° C)
Battery Re-Charge Time System in OFF Mode or
Standby
2.5 hours
System ON 3 to 5 hours (depending on system power
consumption)
Displays
13.3-inch LED HD (1366
x 768)
anti-glare
Dimensions (W x H) 11.53 x 6.49 in (29.3 x 16.5 cm)
Diagonal Size 13.3 in (33.8 cm)
Surface Treatment Anti-glare
Contrast Ratio 300:1 (typical)
Refresh Rate 60 Hz
Brightness 200 nit (typical)
Pixel Resolution Pitch 0.215 mm
Format 1366 x 768
Configuration RGB Stripe
Backlight LED
PPI 118 ppi
Viewing Angle ±30° Horizontal, ±10° Vertical (minimum)
30/30/20/10 (Left/Right/Down/Up) (minimum) or
45/45/35/25 (Left/Right/Down/Up) (typical)
QuickSpecs
HP ProBook 5320m Notebook PC
Technical Specifications
DA - 13671 Worldwide QuickSpecs — Version 6 — 12.29.2010 Page 17

13.3-inch LED HD (1366
x 768) BrightView
Dimensions (W x H) 11.53 x 6.49 in (29.3 x 16.5 cm)
Diagonal Size 13.3 in (33.8 cm)
Surface Treatment BrightView (glossy)
Contrast Ratio 300:1 (typical)
Refresh Rate 60 Hz
Brightness 200 nit (typical)
Pixel Resolution Pitch 0.215 mm
Format 1366 x 768
Configuration RGB Stripe
Backlight LED
PPI 118 ppi
Viewing Angle ±30° Horizontal, ±10° Vertical (minimum)
30/30/20/10 (Left/Right/Down/Up) (minimum) or
45/45/35/25 (Left/Right/Down/Up) (typical)
Internal Storage
500 GB 7200 rpm SATA
Hard Drive
Drive Weight 0.25 lbs (115 g)
Capacity 500 GB
Height 0.37 in (9.5 mm)
Width 2.75 in (70 mm)
Interface ATA-8, SATA 2.6, 3.0 Gb/s, NCQ
Transfer Rate Synchronous (maximum) 150 MB/s (Drive Capability)
Seek Time
(typical reads, including
settling)
Single Track 1.5 ms
Average 11 ms
Maximum 22 ms
Rotational Speed 7200 rpm
Logical Blocks 976,773,168
Operating Temperature 32° to 140° F (0° to 60° C) [case temp]
Features ATA Security
QuickSpecs
HP ProBook 5320m Notebook PC
Technical Specifications
DA - 13671 Worldwide QuickSpecs — Version 6 — 12.29.2010 Page 18

320 GB 7200 rpm SATA
Hard Drive
Drive Weight 0.25 lbs (115 g)
Capacity 320 GB
Height 0.37 in (9.5 mm) or on some models 0.28 in (7 mm)
Width 2.75 in (70 mm)
Interface ATA-8, SATA 2.6, 3.0 Gb/s, NCQ
Transfer Rate Synchronous (maximum) 150 MB/s (Drive Capability)
Seek Time
(typical reads, including
settling)
Single Track 1.5 ms
Average 11 ms
Maximum 22 ms
Rotational Speed 7200 rpm
Logical Blocks 625,142,448
Operating Temperature 32° to 140° F (0° to 60° C) [case temp]
Features ATA Security
250 GB 7200 rpm SATA
Hard Drive
Drive Weight 0.25 lbs (115g)
Capacity 250 GB
Height 0.37 in (9.5 mm) or on some models 0.28 in (7 mm)
Width 2.75 in (70 mm)
Interface ATA-8, SATA 2.6, 3.0 Gb/s, NCQ
Transfer Rate Synchronous (maximum) 150 MB/s (Drive Capability)
Seek Time
(typical reads, including
settling)
Single Track 1.5 ms
Average 11 ms
Maximum 22 ms
Rotational Speed 7200 rpm
Logical Blocks 488,397,168
Operating Temperature 32° to 140° F (0° to 60° C) [case temp]
Features ATA Security
128 GB
2.5-inch SATA Solid State
Drive
Weight 80.1 Grams
Capacity 128 GB
Height 0.37 in (9.5 mm)
Width 2.75 in (70 mm)
Interface SATA
Performance Maximum Sequential
Read
Maximum Sequential Write
220 MB/s 200 MB/s
Logical Blocks 250,069,680
Operating Temperature 32° to 158°F (0° to 70°C) [case temp]
Features ATA Security; ATA-7 ;SATA 2.6; DIPM
QuickSpecs
HP ProBook 5320m Notebook PC
Technical Specifications
DA - 13671 Worldwide QuickSpecs — Version 6 — 12.29.2010 Page 19

80 GB
2.5-inch SATA Solid State
Drive
Weight 0.19 lbs (86 g)
Capacity 80 GB
Height 0.37 in (9.5 mm)
Width 2.75 in (70 mm)
Interface ATA-7 / SATA 2.6
Performance Maximum Sequential
Read
Maximum Sequential Write
250 MB/s 70 MB/s
Logical Blocks 156,301,488
Operating Temperature 32° to 158°F (0° to 70°C) [case temp]
Features ATA Security
Audio
Hardware Implementation IDT HD Audio
Full Duplex Yes
Integrated Dual-
Microphone Array
Yes
Combo stereo
headphone/mic jack
Device Used Operation
Stereo Headphone Headphone works.
Integrated microphone works.
External PC Microphone External microphone does not work.
Integrated microphone works.
Combo headphone / microphone
without "Answer" button
Headphone and microphone in headset
work as advertised.
Combo headphone / microphone
with "Answer" button
Headphone and microphone in headset
work initially whenever headset is
plugged in; integrated microphone in
PC is disabled. If "answer" button is
pushed, microphone in headset is
disabled, integrated microphone in PC
is enabled.
Audio Output Quality Frequency Response 20 Hz - 20 kHz
Signal to Noise Ratio >85 dB
Total Harmonic Distortion 0.01%
Noise Floor -110 dB
Play/Record Sampling
Rate (s)
8 kHz - 48kHz
DAC 16, 20 or 24-bit
ADC 16 or 20-bit
QuickSpecs
HP ProBook 5320m Notebook PC
Technical Specifications
DA - 13671 Worldwide QuickSpecs — Version 6 — 12.29.2010 Page 20
