HP 22m Installation instructions

EL-MF877-00 Page 1
Template Revision B
PSG instructions for this template are available at EL-MF877-01
Product End-of-Life Disassembly Instructions
Product Category: Monitors and Displays
Marketing Name / Model
[List multiple models if applicable.]
HP 22m Display
Purpose: The document is intended for use by end-of-life recyclers or treatment facilities. It provides the basic instructions
for the disassembly of HP products to remove components and materials requiring selective treatment, as defined by EU
directive 2002/96/EC, Waste Electrical and Electronic Equipment (WEEE).
1.0 Items Requiring Selective Treatment
1.1 Items listed below are classified as requiring selective treatment.
1.2 Enter the quantity of items contained within the product which require selective treatment in the right column, as
applicable.
Item Description
Notes
Quantity
of items
included
in product
Printed Circuit Boards (PCB) or Printed Circuit
Assemblies (PCA)
With a surface greater than 10 sq cm
Main Board*1,key pad Board*1, TCON Board*1,
3
Batteries
All types including standard alkaline and lithium coin
or button style batteries
0
Mercury-containing components
For example, mercury in lamps, display backlights,
scanner lamps, switches, batteries
0
Liquid Crystal Displays (LCD) with a surface greater
than 100 sq cm
Includes background illuminated displays with gas
discharge lamps panel*1
1
Cathode Ray Tubes (CRT)
0
Capacitors / condensers (Containing PCB/PCT)
0
Electrolytic Capacitors / Condensers measuring
greater than 2.5 cm in diameter or height
external power supply
1
External electrical cables and cords
Power cord*1, HDMI cable*1
All are inside monitor carton box
2
Gas Discharge Lamps
0
Plastics containing Brominated Flame Retardants
weighing > 25 grams (not including PCBs or PCAs
already listed as a separate item above)
0
Components and parts containing toner and ink,
including liquids, semi-liquids (gel/paste) and toner
Include the cartridges, print heads, tubes, vent
chambers, and service stations.
0
Components and waste containing asbestos
0
Components, parts and materials containing
0

EL-MF877-00 Page 2
Template Revision B
PSG instructions for this template are available at EL-MF877-01
refractory ceramic fibers
Components, parts and materials containing
radioactive substances
0
2.0 Tools Required
List the type and size of the tools that would typically be used to disassemble the product to a point where components
and materials requiring selective treatment can be removed.
Tool Description
Tool Size (if
applicable)
Cross screwdriver
Hexagon screwdriver
Opening plasitc picks
3.0 Product Disassembly Process
3.1 List the basic steps that should typically be followed to remove components and materials requiring selective treatment:
1. Separate base(chassis) and neck by hand, then unlock monitor head and column by releasing button.
2. Separate front bezel and rear cover along the side gap by opening plsatic pick and separate front bezel by hand.
3. Remove all the acetate tapes from LVDS FFC, disassemble the internal wire, LVDS FFC from connector by hand
4. Release I/O port screws on PCBs by hexagon screwdriver, tear Alu tape from chassis then separate LVDS FFC and all
connector on PCBs.
5. Disassemble metal hinge with screwdriver, then release the screws to separate hinge from plastic part of neck, and
release screws to separate hinge top bracket from hinge..
6.
7.
8.
9.
10.
3.2 Optional Graphic. If the disassembly process is complex, insert a graphic illustration below to identify the items
contained in the product that require selective treatment (with descriptions and arrows identifying locations).

WEEE Report
ReportNo.:A2180169984101001Page1 of18
Applicant:K-tronics(SuZhou)TechnologyCo.,LTD
Address :No.1700,ZhongshanNorthRoad, SonglingTown, WujiangCity, JiangsuProvince, 215200, P.R. China
1. General Information
Buyer : K-tronics(SuZhou)TechnologyCo.,LTD
Supplier : /
SampleReceived Date : Sep.12, 2018
Testing period : Sep.12, 2018 toSep.20, 2018
2. Product Description
Product Name : COMPUTERTECHNOLOGYLINK
Product Part No. : L22FBFBVP5C000
ProductWeight : 3393.7g
Product Size : 49.0cm 16.9cm 39.0cm
Categoryunderthe WEEE directive : Screens, monitors,and equipment containingscreenshaving asurfacegreaterthan 100
cm 2

WEEE Report
ReportNo.:A2180169984101001Page2 of18
ProductPhoto
Conclusion Whentestedasspecified,theresultsshownon thereportmeetthe requirementsof theReuse/Recycling/RecoveryRate
of Directive2012/19/EUreleased on EUOfficialJournal(OJ)
Tested byReviewed by
Approved by Date Sep.20, 2018
LeslieChen
TechnicalManager No. R198698437
CentreTestingInternational Pinbiao(Shanghai)Co.,Ltd.No.1996,XinjinqiaoRoad,PudongNewDistrict,Shanghai,China

WEEE Report
ReportNo.:A2180169984101001Page3 of18
3.AssessmentRequirement
Asspecifiedbyclient, toassess the reuse/recycle/recoveryof thesubmitted sampleunderarticle11 andAnnexVof Directive
2012/19/EU*
*******************************************************************************************************************************************************************************
*=July24,2012,the EUOfficialJournal(OJ)released the Directive2012/19/EUwhichasanewversion ofWEEE Directive(2002/96/EC).The revised
directivehasentered intoforceon the twentiethdayafteritspublication inthe OJ.
4. ResultofReuse/Recycling/RecoveryAssessments
Reuse/Recycling/Recovery Reuse/RecyclingRate(%) RecoveryRate(%)
Reuse/Recycling/RecoveryTargetof ProductsUnderWEEE Directive 70 80
Resultof Assessment 87.9 87.9
WEEE Compliance Pass Pass

WEEE Report
ReportNo.:A2180169984101001Page4 of18
5.AppearanceoftheProduct
6. DisassemblyAssessment
6.1DisassemblyProcedure
The productisdisassembled intodifferent partsand groupedbythe type ofmaterialsharingcommon characteristic(suchasplastic,
metal, glass)based on the treatment requirementsassetoutinthe WEEE Directive, followedbythecurrent stateofthe art ofrecycling
and recoverytechnology.Inaddition,the recycling issubjecttothe economicfeasibility,disassemblytools,onlybiggerpartsthatcan be
easilyseparated areincludedintherecycling and reusecalculation.Otherparts,respectivelymaterialsthatcannotbeseparated bye.g.
standardtoolsareclassified aseitherunspecifiedmaterialsordistributed tothe relativewastefractionisexpected withrecoveryrate.

WEEE Report
ReportNo.:A2180169984101001Page5 of18
6.2DisassemblyTools
The disassemblytoolsused forthisproduct showasfollowing:
DisassemblyTool Picture
Slotted screwdriver
Cross screwdriver
Nipper

WEEE Report
ReportNo.:A2180169984101001Page6 of18
6.3ConnectionTechnique
Snap : 33 Screw: 40 Glue: 6
6.4DisassemblyTime
6minutes

WEEE Report
ReportNo.:A2180169984101001Page7 of18
6.5DisassemblyTree

WEEE Report
ReportNo.:A2180169984101001Page8 of18

WEEE Report
ReportNo.:A2180169984101001Page9 of18

WEEE Report
ReportNo.:A2180169984101001Page10 of18

WEEE Report
ReportNo.:A2180169984101001Page11 of18

WEEE Report
ReportNo.:A2180169984101001Page12 of18

WEEE Report
ReportNo.:A2180169984101001Page13 of18
7. Selective TreatmentforMaterialsandComponents
AccordingtoArticle8(2)andthe AnnexVII ofthe WEEE Directive,thisproductcontainscomponentsand materialsitemsare
described inthe followingtable.
Component/Material PhotoNo. Size/Model Quantity Weight(g)
LiquidCrystalDisplay E4 48.5cm 27.8cm 1 385.0
Print circuit board C3 14.0cm 8.0cm 1 65.9
Print circuit board E2 45.4cm 3.0cm 1 26.2
Print circuit board E3 48.6cm 0.5cm 1 6.3
Print circuit board G1 10.3cm 4.4cm 1 84.4

WEEE Report
ReportNo.:A2180169984101001Page14 of18
8. MaterialRecyclingInformation
8.1Material Reuse/RecyclingandRecoveryTable
PhotoNo. Component/Material
Composition Weight(g) PercentWeight (%)
Reuse /
Recycling
Rate(%)
EnergyRecovery
Rate(%)
Recovery
Rate(%)
B,C2,E6
PlasticParts
Plastic(others) 415.012.210.9/ 10.9
C7,E7-2,F3 ABS 432.112.711.3/ 11.3
G3 PC 44.91.31.2/ 1.2
E7-1 PC/ABS 69.82.11.8/ 1.8
A,C1,C5,E1,E5,F1,F4 MetalParts 1541.845.541.8/ 41.8
D,C6,G2 MixedParts Plastic+Metal 314.49.37.7/ 7.7
F2 Rubber 4.30.10.1/ 0.1
E4 LCD 385.011.39.0/ 9.0
C3,E2 PCBA 92.12.72.1/ 2.1
C4,E3,G1 PCBA 94.32.82.0/ 2.0
Total 3393.7100.087.9/ 87.9
Note: Plasticcontainingbrominatedflameretardantsisnot assessed inthelist.

WEEE Report
ReportNo.:A2180169984101001Page15 of18
8.2Reuse/RecyclingandRecoveryRateCalculation
CalculationMethod
Product totalweight a g）
Weightofcomponents,sub-assembliesandconsumableswhicharereusedfortheiroriginal
purposeorrecycled. bg）
Weight ofmaterialsorcomponentswhereenergyisrecovered throughincineration. c g）
Reuse/ RecyclingRate b/a*100 %）
RecoveryRate (b+c)/a*100 %）
9.ANNEX VIIofWEEE Directive (2012/19/EU)
Selectivetreatmentformaterialsandcomponentsofwasteelectrical andelectronicequipmentreferredtoinArticle8(2)
Asaminimumthe followingsubstances, mixturesand componentshavetoberemoved fromanyseparatelycollected WEEE
—polychlorinated biphenyls(PCB)containing capacitorsinaccordancewithCouncilDirective96/59/ECof16 September1996 on the
disposalof polychlorinated biphenylsandpolychlorinatedterphenyls(PCB/PCT),
—mercurycontainingcomponents, suchasswitchesorbacklighting lamps,
—batteries,
—printed circuit boardsof mobilephonesgenerally, and of otherdevicesif the

WEEE Report
ReportNo.:A2180169984101001Page16 of18
surfaceofthe printed circuit boardisgreaterthan 10 squarecentimetres,
—tonercartridges,liquidand paste, aswellascolourtoner,
—plasticcontainingbrominatedflameretardants,
—asbestoswasteand componentswhichcontainasbestos,
—cathode raytubes,
—chlorofluorocarbons(CFC), hydrochlorofluorocarbons(HCFC)orhydrofluorocarbons(HFC), hydrocarbons(HC),
—gasdischarge lamps,
—liquidcrystaldisplays(togetherwiththeircasing whereappropriate)ofa
surfacegreaterthan100 squarecentimetersand allthoseback-lighted withgasdischarge lamps,
—externalelectriccables,
—componentscontaining refractoryceramicfibresasdescribedinCommission Directive97/69/ECof 5December1997 adaptingto
technicalprogress forthe23rdtimeCouncilDirective67/548/EECon the approximation of the laws, regulationsand administrative
provisionsrelating tothe classification, packagingand labelling ofdangeroussubstances,
—componentscontaining radioactivesubstanceswiththe exception of componentsthat arebelowthe exemption thresholdssetin
Article3of andAnnexI toCouncilDirective96/29/Euratomof 13 May1996 laying downbasicsafetystandardsfortheprotection of
the healthof workersandthe generalpublicagainst the dangersarisingfromionizing radiation,

WEEE Report
ReportNo.:A2180169984101001Page17 of18
—electrolytecapacitorscontainingsubstancesof concern(height >25 mm, diameter>25 mm orproportionatelysimilarvolume).
Thesesubstances, mixturesand componentsshallbedisposedof orrecoveredincompliancewithDirective2008/98/EC.
10. RecommendationsforWEEE DirectiveCompliance
(1)Tomakethe product complywiththe reuse/recycling/recoverytarget requiredunderWEEE Directive(2012/19/EU)andotherEU
wasteregulation, theapplicant companyshouldconsiderthe product theydesigncan beeasilyreused and recycled byselecting
recyclablematerialsand components.
(2)Tomakethe product easilydismantled,lessthe disassembling time, the applicant companyshoulddesign theproduct foreasy
disassemblybychoosing easyseparatetechniques,avoiding theutilizingembedded components,designing the separableprocedure.
(3)The product shouldbesubjected totheRoHSDirective(2011/65/EU),restrictingusing hazardoussubstance. Inaddition, the
materialsselected todesign shouldconsiderthe dangeroussubstanceregulated orlist underotherenvironmentalspecifications, as
Regulation (EC)1907/2006(REACH), 67/548/EEC, etc.

WEEE Report
ReportNo.:A2180169984101001Page18 of18
(4)Incasethat aproducthavenewdesign,oremploymaterialsorcomponents, thenthe product shouldneedtobe reassessed and
retested inaccordancewiththe WEEE Directiveforreuse/recycle/recyclingtarget andRoHSforrestricted substancesrequirement.
(5)The applicant companyshouldtakeattention tothefuturepossibleupdateconcerning theWEEE Directiveandrelated
requirement.
*** End ofreport ***
