HP D2847W User manual

1
HP D2847A, HP D2847W
21-inch Color Monitors
19.8-inch Viewable Image
User’s Guide
0.25 mm dot pitch for
excellent graphics
FD Trinitron®, anti-glare, anti-
static, multilayer screen coating
Image adjustment controls to
operate on-screen display menus Status indicator
Full scan screen that gives
an edge to edge image
On/Off switch

HP 21" Color Monitor User’s Guide
2 English
Important Safety Instructions
Important Safety Instructions
Before you plug in your new monitor, read these important safety instructions.
For your safety always connect equipment to a grounded wall outlet. Always use a
power cord with a properly grounded plug, such as the one provided with the
equipment, or one in compliance with your national safety standards. This equipment
can be disconnected from the power by removing the power cord from the power
outlet. This means the equipment must be located close to an easily accessible power
outlet.
To avoid electrical shock, do not open the monitor’s cover. There are no user-
serviceable parts inside. Only qualified service personnel should service these parts.
Make sure your PC is powered off before connecting or disconnecting a display
peripheral.
Thank you for selecting HP monitor equipment.
To optimize your comfort and productivity, it’s important that you set up your work
area correctly and use your HP equipment properly. With that in mind, we have
developed some set-up and use recommendations for you to follow based on estab-
lished ergonomic principles.
You can consult the online version of Working in Comfort preloaded on the hard disk
of HP computers, or visit HP’s Working in Comfort web site at:
http://www.hp.com/ergo/
The monitor is quite heavy (the weight is shown in the technical specifications). We
recommend you ask the assistance of a second person when lifting or moving it.
The lightning flash with arrowhead symbol, within an equilateral triangle, is intended
to alert the user to the presence of uninsulated “dangerous voltage” within the
product’s enclosure that may be of sufficient magnitude to constitute a risk of electric
shock.
The exclamation point within an equilateral triangle is intended to alert the user to the
presence of important operating and servicing instructions in the literature accompa-
nying the appliance.
WARNING
CAUTION
WORKING IN
COMFORT

HP 21" Color Monitor User’s Guide
English 3
What Your New Monitor Offers
Your HP monitor is a FD Trinitron 21-inch (19.8-inch viewable image), high resolution,
multi-synchronous color monitor. Multi-synchronous means that the monitor supports a
range of video modes. It is optimized to be used with all Hewlett-Packard computers.
Your HP color monitor has the following features:
•A 21-inch FD Trinitron tube, with a 19.8-inch viewable image, and 0.25 mm dot pitch
for excellent graphics. Anti-glare, multilayer coating to minimize reflection.
•Support of video modes up to 1600 x 1200 at 85 Hz refresh rates, and up to 1800
x 1440 using a 80 Hz refresh rate.
•Image adjustment using on-screen display menus. Includes color adjustment and
image manipulation controls to optimize the quality and position of the image.
•Improved color matching using the sRGB color temperature profile: this can
significantly improve color matching with other system devices (printer, computer
software, scanner, etc) using sRGB standard color space.
•Monitor power management system (VESA1standard) controlled from suitably
equipped HP computers to automatically reduce the power consumption of the
monitor. As an ENERGY STAR2partner, HP has determined that this product
meets the ENERGY STAR guidelines for energy efficiency
•Monitor Plug and Play capability (VESA DDC1/2Bi standard) that enables the
monitor to identify itself to suitably equipped HP computers.
•Compliance with ISO 9241-3/-7/-8 ergonomic standards.
•Complies with MPRIII, level A guidelines for upper limits of electrical and
electrostatic emissions, from the Swedish National Board for Measurement and
Testing.
•Your HP monitor complies with TCO99 requirements, refer to the last pages of
this manual for more information.
1 VESA is the Video Electronics Standards Association
2 ENERGY STAR is trademark of United States Environmental Protection Agency (EPA)
What Your New Monitor Offers

HP 21" Color Monitor User’s Guide
4 English
Setting Up Your Monitor
Where to Place the Monitor
Place your monitor on a flat sturdy surface.
Ensure the operating site is free from excessive heat, moisture, and sources of
electromagnetic fields. Sources of electromagnetic fields include transformers, motors,
and other monitors.
Connecting the Cables
1 Before you connect any cables, refer to the safety instructions at the beginning of
this manual. Make sure your computer and monitor are switched off.
2 Connect the video cable (it has a 15-pin plug) to the video outlet on your com-
puter. Tighten the thumbscrews on the plug.
3 Connect the power cord to the monitor.
4 Plug the power cord into the power outlet.
Video cable
The location of your computer’s video cable connector may be different to the one
shown. Refer to the manual that came with your computer, if necessary.
Setting Up Your Monitor
Power cords
NOTE

HP 21" Color Monitor User’s Guide
English 5
Using Your Monitor
Using Your Monitor
1 Press the power switch to turn the monitor on or off.
2 When the power is turned on, the power-on indicator will light up.
The light indicates the operating state:
• Green: The monitor is in normal operation.
• Blinking: The monitor is in the active off state.
• Off: The monitor is turned off at the power switch or disconnected from the mains
outlet.
If the power management function of your computer is working properly, you do not
need to switch the monitor off or on. This occurs automatically.
Pressing the button activates the monitor’s on-screen menu. This menu contains
the monitor’s various adjustment features.
Select a feature using the and buttons. Scroll to the adjustment feature you
require and then press to access the menu.
To adjust the required feature, use the and buttons until the desired changes are
complete.
Menu language
1 When you press the button for the first time, the Menu language menu
appears on the screen.
2 Select a language with the and buttons and press the button to activate
your choice.

HP 21" Color Monitor User’s Guide
6 English
5 Select the adjustment with the and buttons.
6 Press to confirm the selection. The menu disappears and a scale shows the
position of the adjustment. In addition to the bar, position of the adjustment is
shown as a percentage of the maximum value. The upper number shows the
current value and the lower one shows the value where the adjustment started.
SIZE & POSITION
SHAPE
SHARPNESS
COLOR
MISCELLANEOUS
CONTRAST
BRIGHTNESS
TILT
4
SIZE & POSITION
SHAPE
SHARPNESS
COLOR
MISCELLANEOUS
CONTRAST
BRIGHTNESS
HORIZONTAL CENTERING
1
2
3
Using Your Monitor
Using the menu
Menu operations are controlled with the , and buttons.
1 You can display the menu by pressing the button.
2 Select the header with the and buttons.
3 Press to confirm the selection.
4 Adjustment and settings corresponding the header appear below the header field.
CONTRAST
BRIGHTNESS
TILT
ORTHOGONALITY
TRAPEZOID
PINCUSHION
PINCUSHION BALANCE
EXIT
1280 X 1024 85 Hz
5
6

HP 21" Color Monitor User’s Guide
English 7
TILT
50 %
77 % 8
7
Using Your Monitor
7 Adjust with the and buttons.
8 When ready, press the button.
Exiting the menu
The onscreen menu disappears automatically after 20 seconds of inactivity. Alterna-
tively select EXIT and press the button to make the menu disappear immediately.
Adjusting the picture of your monitor
You should allow the monitor warm up for 20 minutes before making any adjustments
to image settings of the monitor.
Size and position
The illustrations below show the effect of each adjustment when the property is
adjusted from the extreme left to the extreme right position.
• First correct the property with largest deviation from the correct value then adjust
the width and height.
1280 x 1024 85 Hz
SIZE & POSITION
SHAPE
SHARPNESS
COLOR
MISCELLANEOUS
CONTRAST
BRIGHTNESS
HORIZONTAL CENTERING
WIDTH
VERTICAL CENTERING
HEIGHT
PRESET RECALL
EXIT
Brightness and Contrast
With brightness adjustment you may control the brightness of the whole picture.
Contrast increases or decreases the brightness difference between light and dark colors.
Adjust brightness and contrast adequately according to ambient light conditions to
obtain the best picture quality.

HP 21" Color Monitor User’s Guide
8 English
Sharpness
SIZE & POSITION
SHAPE
SHARPNESS
COLOR
MISCELLANEOUS
VERTICAL CONV
HORIZONTAL CONV
MOIRE
COLOR PURITY
DEFAULT SHARPNESS
EXIT
1280 x 1024 85 Hz
Shape
The illustrations below show the effect of each adjustment when the property is
adjusted from the extreme left to the extreme right psosition.
• When adjusting these properties, set picture width and height so that its edges are
visible. Compare the edges of the picture to those of the bezel.
• First correct the property with largest deviation from the correct value then adjust
the width and height.
SIZE & POSITION
SHAPE
SHARPNESS
COLOR
MISCELLANEOUS
CONTRAST
BRIGHTNESS
TILT
ORTHOGONALITY
TRAPEZOID
PINCUSHION
PINCUSHION BALANCE
EXIT
1280 x 1024 85 Hz
Preset Recall
This function restores the factory defaults and deletes user made settings for:
• Size and position
• Shape
Using Your Monitor

HP 21" Color Monitor User’s Guide
English 9
Vertical and horizontal convergence
A white line on the screen is made up of red, green and blue lines. If there are no
convergence errors on the picture, the lines will be exactly overlaid and the resulting
color is white. If there is a serious convergence error, separate red, green or blue lines
will be seen instead of white.
• With Horizontal conv you may minimize the error in vertical lines.
• With Vertical conv you may minimize the error in horizontal lines.
Moire
The interference on the screen can be reduced with the help of moire adjustment.
Boost the moire adjustment until the interference pattern is acceptable.
Moire adjustment slightly reduces picture sharpness. Return the adjustment to zero if
there is no risk of moire interference.
Using Your Monitorr
Color purity
These adjustments can be used to change the color temperature (tint) of the screen.
The icon of each adjustment indicates the area on the screen the adjustment affects.
COLOR PURITY
TOP AND BOTTOM
TOP RIGHT
BOTTOM RIGHT
TOP LEFT
BOTTOM LEFT
EXIT
1280 x 1024 85 Hz
You should allow the monitor to warm up for 20 minutes and demagnetize the monitor
before starting the color purity adjustment.
Color purity problems do not show up with white test picture. Always use fully red
or green test picture.
Default sharpness
This function restores the factory defaults and deletes user made settings for:
•Vertical conv, Horizontal conv, Moire, Color purity
NOTE

HP 21" Color Monitor User’s Guide
10 English
1280 x 1024 85 Hz
SIZE & POSITION
SHAPE
SHARPNESS
COLOR
MISCELLANEOUS
CONTRAST
BRIGHTNESS
COLOR TEMP 9300 K
RED
GREEN
BLUE
SAVE TO CUSTOM 1
EXIT
Color
With the Color menu the user may adjust the tint of the screen.
Color temperature
The user can choose between the following fixed color temperatures:
• 5000K, 6000K, 6500K, 7000K, 8000K, 9300K, 10000K
Alternatively, a user specified profile can be selected:
• CUSTOM1 User definable color temperature, refer to the chapter ”Save to
Custom”
• sRGB
sRGB stands for ”standardized Red, Green and Blue” colour space. Selecting
sRGB means that the monitor displays the images with the same colour balance as
other system components (scanner, printer,computer software etc) utilizing the
same sRGB color standard.
After a preset tint has been selected, the color temperature may be adjusted further as
desired.
Using Your Monitor
Red, Green, Blue
Color monitors mix red, green and blue colors to produce required tint. With Red,
Green and Blue intensity control you may finetune any preset tint.
•After adjusting Red, Green or Blue the word CUSTOM replaces the color
temperature indication.
