Redesigned from the inside out
Take a quick look at the competitively priced HP Compaq LE1901wl
and you might not notice a difference from previous 19 -inch
diagonal models, but power it on and you’ll soon realize that the
panel is a WLED (white light emitting diode; white LED) backlit
panel instead of the standard CCFL (cold cathode fluorescent lamp)
panel found in prior models. You may be familiar with these terms,
but what makes a white LED panel different from a CCFL panel?
One of the biggest differences is that a WLED panel does not
contain mercury. In contrast, a CCFL panel houses a small amount
of the element, so when the time comes to replace your monitor,
you can feel good about your recycling efforts.
Additionally, WLEDs are solid state components, which can make
them more resistant to damage caused by external shock vs. the
glass tubes within CCFL monitors. This may be useful in mobile
office environments where monitors are often re-tasked.
HP innovations help make a positive impact on business
The HP Compaq LE1901wl can help you make a positive impact as
you strive to “go green” by meeting the toughest worldwide
environmental standards on the market. These include:
ENERGY STAR®qualified
EPEAT®Silver registered*
TCO 5.0 Displays certified
Other features to help impact your workday in a positive way are:
Adjustable tilt settings let you change positions throughout
the day, helping you stay comfortable
A 16:10 aspect ratio leaves room for larger Windows®
ribbon toolbars without taking up valuable content space
170°/160° viewing angles, a 1000:1 contrast ratio,
and 5ms response times help provide clear views of work
or play**
A VGA input enables quick and simple PC connectivity so
you can get working fast
VESA compatibility corresponds with standard mounts to
provide a wide range of stand options while freeing up desk
space
Display Assistant enables color adjustments for custom
picture quality, theft deterrence for extra protection, and self
timers for power savings
A limited 3 year warranty with optional extended
care packs help cover your needs***
HP Essential Series
HP Compaq LE1901wl
19-inch WLED Backlit LCD Monitor
Introducing a competitively priced,
Mercury-free monitor from HP, with a
WLED backlit panel for improved
recyclability, durability, and productivity.

HP Compaq LE1901wl 19 -inch WLED Backlit LCD Monitor
Part number
XL877AA
Panel type
TN
Viewable image area
48,14 cm (19 in) widescreen diagonally measured
Viewing angle
Up to 170° horizontal/160° vertical (10:1 minimum contrast ratio)
Brightness**
250 nits (cd/m2)
Contrast ratio**
1000:1
Response rate**
≤5 ms (on/off)
Frequency
Horizontal: 24 to 83 kHz; Vertical: 50 to 76 Hz
Native resolution
1440 x 900 @ 60 Hz
Resolutions supported
1440 x 900 @ 60 Hz;1280 x 1024 @ 60 Hz; 1280 x 960 @ 60 Hz; 1024 x 768 @ 60 Hz Hz; 800 x 600 @ 60 Hz;
640 x 480 @ 60 Hz; 1152 x 720 @ 60 Hz; 1280 x 768 @ 60 Hz
Input signal
VGA, cable included
User controls (on-screen
display)
Brightness, Contrast, Contrast, Positioning, Color temperature (6500k, 9300k, Custom), Individual Color Control, Serial
Number, Display, Clock, Clock Phase, Monitor Management, Factory Reset, Zoom
Input power
Auto-Sensing, 90 to 265 VAC, 50/60 Hz
Power consumption
Maximum: 20 watts; Typical: 16 watts ; Power saving: <2 watts standby; 1 watt off
Dimensions (h × w × d)
Unpacked w/stand: 37 x 44,6 x 20,6 cm (14.6 x 17.6 x 8.1 in)
Unpacked w/o stand (head only): 30,1 x 44,6 x 5,9 cm (11.9 x 17.6 x 2.3 in)
Packaged: 44,6 x 51,3 x 13,2 cm (17.6 x 20.2 x 5.2 in)
Weight
Unpacked: 4,6 kg (10.1 lb); Packaged: 6,6 kg (14.5 lb); Head only: 4,0 kg (8.8 lb)
Base features
Tilt range: -5° to + 25° vertical
Environmental
Operating: 5° to 35° C (41° to 95° F); Non-operating: -34° to 60° C (-29° to 140° F )
Options (each sold
separately)
HP Single Monitor Arm - Optional; The flexible design of the HP Single Monitor Arm provides a seemingly endless range of
display adjustments with an amazing 13 inches of lift, 50 degrees of tilt, and 360 degrees of pan and rotation –all at your
fingertips -- helping you stay comfortable and productive throughout the day. Part number BT861AA.
HP Adjustable Dual Display Stand - Optional; Premium space-saving dual screen solution provides access to more monitor real
estate and makes it possible to manage multiple applications simultaneously. Weight adjustable for dual monitors from 17-24”.
Rotate displays into portrait/landscape positions. Part number AW664AA.
HP LCD Speaker Bar - Optional; powered directly by the connected PC, seamlessly attaches to the monitor's bezel to bring full
multimedia support to select HP LCD monitors; features dual speakers with full sound range and two external jacks for
headphones. Part number NQ576AA.
HP Quick Release - Optional; easy-to-use, VESA-compliant, LCD monitor mounting solution that allows quick and secure
attachment of an LCD monitor to a variety of stands, brackets, arms or wall mounts. Part number EM870AA.
HP Integrated Work Center Stand - Optional; Allows mounting of a 17-, 19-, or 22-inch diagonal HP LCD monitor and an HP
Compaq dc7800 or dc7900 Ultra-slim Desktop PC or HP t5000 series Thin Client on a single stand for the convenience of an
"all-in-one" form factor. Sold separately. Part number GN783AA.
HP USB Graphics Adapter - Optional; enables connection of up to six simultaneous displays. Use one Adapter to bridge between
a notebook or desktop PC and second monitor or use multiple Adapters to connect several displays to each other. Part number
NL571AA.
HP Business PC Security Lock Kit - Optional; Attaches to the rear of the PC with a six-foot steel cable that can be used to secure a
PC or peripherals such as mice, keyboards, monitors or USB security devices to protect them against unauthorized removal by
physically connecting the system to an anchor point. Part number PV606AA.
Certification and
compliance
TCO 5.0 Displays, ISO 9241-307, CISPR Requirements, VCCI Approvals, KC and KCC (Korean) Requirements, CSA
60950-1, UL 60950-1, EN55022 Class B, CNS 13438 Class B, IEC 60950-1, China Energy Label (CEL), China MEPS,
Korea MEPS (pending, Energy Boy), SmartWay –NA only - Energy logistics, EUP Lot 6 Tier 1 AS/NZS 3548 Class B
Approval, “GS” Mark, TUV Approvals, GEEA, CE Marking, FCC Part 15 class B Approval, ENERGY STAR® qualified,
EN55024 Class B, EN60950 -1, CUL, CCIB, CCEE, IT ECO (EDS), EPEAT® Silver (select regions)*
Limited warranty***
Protected by HP, including a 3 years parts, 3 years labor, and 3 years onsite service (3/3/3) standard limited warranty.
Certain restrictions and exclusions apply.
*EPEAT Silver where HP registers commercial display products. See www.epeat.net for registration status in your country. ** All performance specifications represent the typical
specifications provided by HP's component manufacturers; actual performance may vary either higher or lower. ***HP Care Pack Services extend service contracts beyond the standard
warranties. Service levels and response times for HP Care Packs may vary depending on your geographic location. Service starts from date of hardware purchase. To choose the right level
of service for your HP product, use the HP Care Pack Services Lookup Tool at www.hp.com/go/lookuptool. Additional HP Care Pack Services information by product is available at
www.hp.com/hps/carepack.
© 2010 Hewlett-Packard Development Company, L.P. The information contained herein is subject to change without notice. The only warranties for HP products and services are set forth in
the express warranty statements accompanying such products and services. Nothing herein should be construed as constituting an additional warranty. HP shall not be liable for technical or
editorial errors or omissions contained herein. Microsoft®, Windows® and Vista® are trademarks of the Microsoft® group of companies. ENERGY STAR®is a US registered mark owned by
the US government. To learn more, visit www.hp.com
OCTOBER 2010
