HP V24i G5 Manual

Maintenance and Service Guide
V24i G5 model
SUMMARY
This guide provides information about spare parts, removal and replacement of parts, diagnostic tests, problem
troubleshooting, and more.

© Copyright 2022 HP Development
Company, L.P.
AMD is a trademark of Advanced Micro
Devices, Inc. Bluetooth is a trademark owned
by its proprietor and used by HP Inc. under
license. NVIDIA is a trademark and/or
registered trademark of NVIDIA Corporation
in the U.S. and other countries. USB Type-C
and USB-C are registered trademarks of USB
Implementers Forum. DisplayPort and the
DisplayPort logo are trademarks owned by the
Video Electronics Standards Association
(VESA) in the United States and other
countries.
The information contained herein is subject to
change without notice. The only warranties
for HP products and services are set forth in
the express warranty statements
accompanying such products and services.
Nothing herein should be construed as
constituting an additional warranty. HP shall
not be liable for technical or editorial errors
or omissions contained herein.
First Edition: Jun. 2022
Document Part Number: N08474-V24i G5-
MSG-V1
Assembly part number: N08474-001
Product notice
Only trained service personnel familiar with
this product should service it. Before
performing any maintenance or service, be sure
to read “Important Safety Information”.

1
Table of Contents
1Getting started........................................................................................................................................................................2
Important safety information ...........................................................................................................................................2
Important service information and precautions ................................................................................................................2
RoHS (2002/95/EC) requirements....................................................................................................................................3
General descriptions ........................................................................................................................................................3
Firmware updates.............................................................................................................................................................3
Before returning the repaired product to the customer ....................................................................................................3
2Monitor features.....................................................................................................................................................................4
Features............................................................................................................................................................................4
Front components.............................................................................................................................................................5
Rear components..............................................................................................................................................................6
Locating the serial number and product number..............................................................................................................7
3Illustrated parts catalog..........................................................................................................................................................8
How to order parts .........................................................................................................................................................10
4Removal and replacement procedures..................................................................................................................................11
Preparation for disassembly...........................................................................................................................................11
Rear Cover.....................................................................................................................................................................11
Power board...................................................................................................................................................................16
Connector repair ............................................................................................................................................................17
DP connector CN501..........................................................................................................................................19
HDMI connector CN502....................................................................................................................................20
D-SUB connector CN503...................................................................................................................................21
Function test...................................................................................................................................................................22
Function test...................................................................................................................................................................22
Support and troubleshooting..........................................................................................................................................22
Index..............................................................................................................................................................................24

2
1Getting started
Read this chapter to learn about safety information and where to find additional HP resources.
Important safety information
Carefully read the cautions and notes within this document to minimize the risk of personal injury to service
personnel. The cautions and notes are not exhaustive. Proper service methods are important to the safe, reliable
operation of equipment. Improper service methods can damage equipment.
The service procedures recommended and described in this service manual provide effective methods of
performing service operations. Service engineers should have prior repair knowledge and experience as well as
appropriate training for the product before performing service procedures.
●Be sure your working environment is dry and clean and meets all government safety requirements.
●Be sure that other persons are safe while you are servicing the product.
●Do not perform any action that can cause a hazard to the customer or make the product unsafe.
●Use proper safety devices to ensure your personal safety.
●Always use approved tools and test equipment for servicing.
●Never assume the product’s power is disconnected from the main power supply. Check that it is
disconnected before opening the product’s cabinet.
●Modules containing electrical components are sensitive to electrostatic discharge (ESD). Follow ESD
safety procedures while handling these parts.
●Some products contain more than one battery. Do not disassemble or expose a battery to high
temperatures, such as throwing into fire, or the battery may explode.
●Refer to government requirements for battery recycling or disposal.
This information provides general service information for the monitor. Adherence to the procedures and
precautions is essential for proper service.
IMPORTANT: Only trained service personnel who are familiar withthis HP product should performservice or
maintenance for it. Before performing any service or maintenance, personnel must read the important safety
information.
IMPORTANT: You must disconnect the power cord from the power source before opening the monitor to
prevent component damage.
Important service information and precautions
●Repair must be performed by professional service technicians in a repair center. End users should not
perform these procedures.
●Please note during servicing that the primary side is the high voltage area.
●This monitor meets ROHS requirements. Be sure to use lead-free solder wire when soldering.
●If you must change a capacitor, be sure to match the polarity as printed on the PCB.
●If you must replace a capacitor, make sure the specification and part number match the BOM and
location.
●If you must replace a capacitor, insert new parts carefully to avoid a short circuit caused by the near
pin.
●Do not get the board wet. Water and moisture can cause a short circuit that causes malfunctions.

3
●To avoid damage, be sure to use lead-free solder.
●When soldering, work quickly to avoid overheating the circuit board.
●Keep the soldering iron tip clean and well tinned when replacing parts.
●After repair, perform a close inspection of the circuit board to confirm it is in good condition.
●After repair, perform a function test to confirm the power supply is working properly.
ERP Lot5 requirement
1. A professional repairer must have the technical competence to repair electronic displays and comply
with the applicable regulations for repairers of electrical equipment in the Member States where the
repairer operates. Reference to an official registration system as professional repairer, where such a system
exists in the Member States, shall be accepted as proof of compliance.
2. A professional repairer must have insurance that covers liabilities resulting from repairs, regardless of
whether required by the Member State.
RoHS (2002/95/EC) requirements
Applied to all countries that require RoHS.
The RoHS (Restriction of Hazardous Substance in Electrical and Electronic Equipment Directive) is a legal
requirement by the EU (European Union) for the global electronics industry sold in the EU and other countries.
Any electrical and electronics products launched in the market after June 2006 should meet this RoHS
requirement. Products launched in the market before June 2006 are not required to be compliant with RoHS
parts. If the original parts are not RoHS complaint, the replacement parts can be non-ROHS complaint. If the
original parts are RoHS compliant, the replacement parts MUST be RoHS complaint.
If product service or maintenance requires replacing parts, confirm the RoHS requirement before replacement.
General descriptions
This manual contains general information. There are two levels of service:
Level 1: Cosmetic/appearance/alignment service
Level 2: Circuit board or standard parts replacement
Firmware updates
Firmware updates for the monitor are available at support.hp.com. If no firmware is posted, the monitor does
not need a firmware update.
Before returning the repaired product to the customer
Perform an AC leakage current check on exposed metallic parts to be sure the product is safe to operate
without the potential of electrical shock. Do not use a line isolation transformer during this check.
Measurements that are not within specified limits present a possible shock hazard. You must check and repair
the product before returning it to the customer.

4
2Monitor features
This chapter provides an overview of the monitor’s features.
Features
Depending on the model, your monitor might include the following features:
Displayfeatures
●60.45 cm (23.8 in) plus full-screen support for lower resolutions; includes custom scaling for maximum image size
while preserving original aspect ratio
●Liquid crystal display (LCD) with active matrix and in-plane switching (IPS) (select products only)
●sRGB color gamut
●Nonglare panel with an LED backlight
● Tilt capabilities
●Height adjustment capabilities (select products only)
●On-screen display (OSD) adjustments in several languages for easy setup and screen optimization
●Energy saver feature to meet requirements for reduced power consumption
●Security cable slot on the rear of the monitor for an optional security cable
●Cable management feature for placement of cables and cords
●Speakers are available on select models only
Connectors
●VGA port (select products only)
●DisplayPort™ video input (select products only)
●High-Definition Multimedia Interface™ (HDMI™) video input
●USB Type-C® port (select products only)
●Plug and Play capability, if supported by your operating system Monitor
stand
●Removable stand for flexible monitor head mounting solutions
●VESA® mounting capability (100 ×100 mm) for attaching the monitor to a swing arm mount
●Support for a mounting bracket to attach the monitor to a workstation
NOTE: For safety and regulatory information, see the Product Notices provided in your documentation kit. To access the
latest user guide, go to http://www.hp.com/support, and follow the instructions to find your product. Then select Manuals.

5
Front components
To identify the components on the front of the monitor, use this illustration and table.
Table 1-1: Front components and their descriptions
Component
Function
1
Power LED
Indicates that the monitor is powered on.
2
Power button
Turns the monitor on or off.
NOTE: Be sure that the master power switch on the
monitor is in the On position to turn on the monitor.
(Select products only.)

6
Rear components
To identify the components on the rear of the monitor, use this illustration and table.
Table 1-2: Rear components and their descriptions
Component
Function
1
Joypad OSD button
Opens the OSD settings.
2
Security cable slot
Connects an optional security cable.
3
Power connector
Connects a power cord.
4
DisplayPort connector
Connects a DisplayPort cable to a source device
such as a computer or game console.
5
HDMI port
Connects the HDMI cable to a source device
such as a computer or game console.
6
VGA port
Connects a VGA cable to a source device such as
a computer or game console.
4
Menu button
Press to open the OSD menu.
5
Security cable slot
Connects an optional security cable.
6
Power connector
Connects a power cord.

7
Locating the serial number and product number
The SPEC label (1) and Barcode label (2) are located on the rear of the monitor. The serial number and product
number are located on a Safety label. You may need these numbers when contacting HP about the monitor model.
Barcode label
Spec label

8
3Illustrated parts catalog
To identify the monitor major components, use this illustration and table.
Item
Description
Qty
1
DECO_BEZEL L238W-Fhp1-s1
1
2
LENS
1
3
LCD M238HAN03.10Y SZ AUO
1
4
MIDDLE_FRAME L238W-Fhp1-s1
1
5
INSULATING SHEET 125.7*92.9*0.5mm
1
6
ADAPTER BOARD
1
7
MAINFRAME
1
8
KEY BOARD
1
9
KEY
1
10
KEY_FUNCTION
1
11
KEY_POWER
1
12
stand ass''y NA NA
1
13
BASE_ASS’Y NA N/A
1
14
COVER_VESA L238W-Fhp1b-s1
1
15
REAR_COVER L238W-Fhp1b-s1
1

9
16
MAIN BOARD
1
17
LOGO HP other
1
S1
SCREW M3 4
13
S2
SCREW D3 6
4
S3
SCREW M4 6
1
S4
SCREW M3 6
2
S5
SCREW Q2 3
2
S6
SCREW P3 4
2
S7
SCREW M4 10
4

10
How to order parts
The HP authorized repair center can purchase the power board from HP.
Power board
Description
HP spare part number
Manufacturer part number
PSU V24i G5 1st Source
N16739-001
PLPCLC411GQB4
PSU V24i G5 2nd Source
N16740-001
PLPCLE601KQB5
PSU V24i G5 3rd Source
N16739-003
PLPCLE481AQB1
Capacitors and connectors are available for purchase from the following EU distributors:
Farnell: Farnell UK - Electronic Components Distributor
RS Component: Capacitors | RS Components (rs-online.com)
tme Component: Transfer Multisort Elektronik
Capacitors by distributor
Component description
Location
Component
distributor
Distributor part number
EC 470uF 20% 25V 10x12 5000
hr 1.7A ECR1
C916
NA
Contact HP Support
Connectors by manufacturer
Component description
Location
identifier
Component
distributor
Distributer part number
DisplayPort
CN501
Farnell
DP1RD20JQ1 (JAE)
HDMI
CN502
RS
DP1RD20JQ1 (JAE)
D-SUB
CN503
tme
HDL15-SL-B (ADAM TECH)
NOTE: Rear cover and chassis need to be modified to hold connector. Connector may need modifications to
meet functional, safety and regulatory requirements accordingly if it doesn’t match exactly.
NOTE: The connector may need to be modified to meet functionality, regulatory and safety requirements if it
is not an exact match.
You can purchase cables from the HP part store at https://partsurfer.hp.com/Search.aspx.
Internal and External Power Supplies are available for purchase from the following EU distributor: EET
https://www.eetgroup.com/en-eu/
NOTE: HP continually improves and changes product parts. For complete and current information about
supported parts for your product, go to https://partsurfer.hp.com/Search.aspx, select your country or region,
and then follow the on-screen instructions.

11
4Removal and replacement procedures
Adherence to these procedures and precautions is essential for proper service.
Preparation for disassembly
Use this information to properly prepare to disassemble and reassemble the monitor.
1) Read the “Important safety information” and “Important service information and precautions” sections in the
“Getting started” chapter of this guide.
2) Clean the room for disassembly.
3) Identify the disassembly area.
4) Check the position that the monitors are to be placed along with the number of monitors. Prepare the area for
material flow according to the disassembly layout.
5) Be sure to have the following equipment and materials:
Press fixture
Working table
Screwdriver
Knife
Gloves
Cleaning cloth
ESD protection
Scraper bar in the following dimensions:
Rear Cover
Before removing the Rear Cover, follow these steps:
▲Prepare the monitor for disassembly. See Preparation for disassembly on page 11.
Remove the Rear Cover:

12
1) Remove four screw from the rear case.
2) Use your fingers to split the left and right sides apart between the middle frame and rear case.
3) Insert the scraper bar tool into the gap between the middle frame and rear case, and then rotate. The hook
opens. Repeat the steps.

13
4) Disassemble the Rear Cover and disconnect the connectors.
5) Remove the Mylar and the screws.

14
6) Disassemble 6 screws from the boards.
7) Disassemble all the boards from housing.
8) Disconnect all the wires from the board.

15
9) Remove the screws to remove the middle frame and the panel.

16
Power board
The power board part number is PLPCLC411GQB4 (1st Source) or
PLPCLE601KQB5 (2nd Source) and PLPCLE481AQB1 (3rd Source).
Before removing the power board, follow these steps:
▲Prepare the monitor for disassembly. See Preparation for disassembly on page 11.
Remove the power board:
1) The HP V24i G5 power board connector position is as follows:
2) Locate the part number location on the board.
Warning: After unplugging the
power supply, the capacitance
is still charged, do not touch
and discharge the capacitor.
CN902
CN801

17
Connector repair
This procedure includes DisplayPort, HDMI and D-SUB connectors.
The connectors are on the main board (board part number CBPR1EBHPQ2).
The connectors identifiers are as follows:
Before repairing connectors, follow these steps:
▲Prepare the monitor for disassembly. See Preparation for disassembly on page 11.
IMPORTANT:
• Repair Condition: Connector repair is only for out of warranty.
• Repairing must operate by professional repairers (Note) in repair center, not applicable for end user.
• Electrostatic protection is required when component replacement is required.
• The monitor meets ROHS, please use Lead-free solder wire for soldering.
• If Connector need to replace, must check specification and part number whether match the BOM and
location.
• If connector need to replace, please insert new parts carefully because the near pin may cause short circuit by
inappropriate operate.
• DO NOT allow any liquid on the board. Water and moisture may cause short-circuit to the electronic
Connector
Location
DisplayPort
CN501
HDMI
CN502
D-SUB
CN503
Main Board
CN502
CN503
CN501

18
components and lead to malfunctions.
• The fusion point of Lead-Free solder is requested. Repairing with conventional lead wire may cause damage.
• Work quickly to avoid overheating the circuit board as soon as you confirm the steady soldering condition.
• Keep the soldering iron tip clean and well tinned and when replacing parts.
• A close inspection of the circuit board revealed look in good condition.
• After repaired, must connect source to each port to check Main board function is ordinary.
Note: (The requirement of professional repairers’ regulation by ERP lot5)
1) The professional repairer has the technical competence to repair electronic displays and complies with the
applicable regulations for repairers of electrical equipment in the Member States where it operates.
Reference to an official registration system as professional repairer, where such system exists in the Member
States concerned, shall be accepted as proof of compliance with this point.
2) The professional repairer is covered by insurance covering liabilities resulting from its activity, regardless of
whether this is required by the Member State.
