DM-III Multitest Power Quality Recorders
Features: • True RMS (TRMS) • Measures
and records broad spectrum of power quality
parameters: AC current, AC voltage to 600V
including sags and surges, harmonics (THD
and individual up to 49th), active, reactive and
apparent power and energy, peak demand,
power factor, frequency measurement and
phase sequence • Works with single and three
phase systems • Detects and records voltage
anomalies, sags and surges • Built in scope
displays waveforms • Phase sequence indication
• Records up to 64 parameters simultaneously
• Manual and programmable recording start • Line
or battery powered • Megohmmeter functions: test insulation of wires, cables,
transformers and electrical motors • Safety ratings: CAT III 600V phase to
phase, CAT III 300V phase to ground
Includes: • CTs • Voltage leads • Ground probes and leads • PC software
and download cable
705-1026-ND (DM-III MULTITEST F) .......................... $3484.20
Test Equipment (Cont.)
INSULATION
3Ø Power Quality Recorder
Ground Resistance Tester / Megohmmeter
TEST
LOW Ω
GROUND
TEST
POWER
QUALITY
F1 F2 F3 F4
SAVE
MENU
ESC
HOLD
ENTER
Start
Stop
AMPROBE
DM-III MultiTest
R
DM-4 Power Quality Recorder
Features:
• True RMS (TRMS) • Works with single (two and
three wire) and three phase systems (Y and Delta)
• Detects and records voltage spikes 100nS or slower
• Detects and records voltage sags and surges • Built
in scope displays waveforms • Records all parameters
simultaneously • Manual and programmable recording
start • Safety rating: CAT III 600V
Includes:
• Carrying case • CTs • Test leads • PC software and
download cable • Remote User Interface (PDA) with
protective hard case and interface cable
705-1024-ND (DM-4) ................ $3695.68
RS232
DM-4 Power Quality Recorder
FastBlink* - Urgent message, connect to recorder immediately!
Note:Allow 10 seconds of start-up time (Fast Blink), after unit is turned on.
IR
TM
R
ON/OFF LED
Unit-ON-AC Power
MAX
RESET
ON/OFF
RECORD
CAT III 600V/CAT II 1000V
!
COM
V1
I1 I2 I3
V2 V3
1V~
AMPROBE
Unit-ON-Battery Power Red Solid Record
Low Battery Slow Blink Low Memory
Green Solid
STATE RECORD LED
12V
Spike-E
DGC-1000A Clamp-on Ground
Resistance Tester
Features:
• Accurate ground resistance measurement from
0.025Ω ~ 1500Ω • TRMS current measurement
• Continuity beep if the resistance is lower than 40.00Ω
• Data logging capability: 116 records • Individual
data point recording • User selectable high and low
Ω audible alarms • Auto power off • Low battery
indicator • Large LCD display • Safety rating: CAT III
300V, CAT II 600V
705-1023-ND (DGC-1000A) ......... $1479.33
HOLD
OFF
FUNC REC
TMULD-300 Leak
Detector Kit
Features: • Locates arcing in an electrical
system • Transmitter “pressurizes” area
with ultrasonic sound enabling the ULD-
300 to pinpoint leaks • Applications include
air tightness of cars or houses • Useful
in finding the ends of buried PVC pipes
• Detects any pressurized gas leak regardless
of type CFC’s, HFC’s, Nitrogen, etc.
Includes: • Ultrasonic transmitter • Flexible
tubing adapter • Tubular extension • Parabola
• Headphones
705-1037-ND (TMULD-300) .................................... $422.92
RANGE
OI
ULTRASONIC
LEAK DETECTOR
Model
ULD-300
BATTERY
GREEN-OK
RED-LOW
X1
X10
X100
HIGH
LOW
10
8
6
4
2
7
6
8
HIGH
MED
LOW
POWER
ULTRASONIC
TRANSMITTER
MODEL
UT-300
MODE
OFF
ON
TH-2A Digital
Thermo Hygrometer
Features:
• Temperature readings
• Relative humidity measurement
• Max/Min with time stamp
• Data hold function
• Selectable °C and °F readout
• Dual LCD display with bargraph indication
• Auto power off
705-1033-ND (TH-2A) ..............$84.54
MX/MN
HOLD
°C/°F %RH
TEMP
Digital
i TH-2A
Thermo
Hygrometer
R
AMPROBE
0
2
0
4
0
6
0
%RH
ºF
THWD-2 Digital Sling
Psychrometer
Features:
• Temperature readings
• Relative humidity measurement
• Dew point and wet bulb readings
• Max/Min with time stamp
• Selectable °C and °F readout
• Data hold function
• Dual LCD display with bar graph indication
• Auto power off
705-1034-ND (THWD-2).............. $116.26
MX/MN
MEM
HOLD
READ
°C/°F
%RH
TEMP
DEW
WET
Digital
i
THWD-2
Sling
Psychrometer
R
AMPROBE
0
2
0
4
0
6
0
%RH
ºF
RC-120S Remcon Relay Switch
Features:
• Switches AC power ON and OFF using low voltage
control circuit • Built in transformer, no step down
transformers necessary • Single relay can be controlled
by multiple switches and multiple relays can be
controlled by a single switch • AC voltage from 105V ~
125V • AC current up to 6.5A
705-1032-ND (RC-120S)......................$42.24
REMCON
SOLID STATE
R
R
AMPROBE
R
CAT . NO: RC - 120 S
THIS DEVICE GENERATES HEAT
READ INSTALLATION INSTRUCTIONS!
LOAD HOT NEUT.
UL
IND.
CONT.
EQ.
957 B
LISTED 120 VOLTS AC 60HZ
AUnited Union Company
6.5 AMPS RESISTIVE LOAD
6.5 AMPS TUNGSTEN LOAD
6.5 AMPS BALLAST LOAD
1/4 HP MOTOR LOAD
PATENTNO.
4,751,401
OTHERS
PENDING.
PRM-3 Phase Sequence and
Motor Rotation Tester
Features:
• Use for phase sequence
testing, three phase motor
installation and maintenance
• Checks motors for rotation
direction • Identifies the
phase sequence of the three
phase electrical system
• Indicates normal or
reversed phases as well as
loss of the phase
705-1031-ND (PRM-3)........................................... $105.69
A
V
PHASE
CAT III 600V
NORMAL
LOW
ON/OFF
50Vto 600V~
!
PHASEto PHASE
REVERSE
BATTERY
(ABC)
LOSS
BC
PRM-3
Phase Sequence & Motor
Rotation Tester
R
AMPROBE
GP-2 Ground Resistance and
Resistivity Tester
Features:
• Measure earth ground resistance; 3 point or 2 point
tests • Automatically calculates resistivity; 4 point
test • Automatic voltage measurement prevents false
measurements • Automatically applies three testing
frequencies for the most accurate readings • Auto
ranging • 999 internal memory locations to store
measurements • RS-232 download to a personal
computer • Safety rating: CAT III 250V
Includes:
• Test leads • Auxiliary electrodes • Software • Carrying Case
705-1027-ND (GP-2)........................................... $1585.07
DISP
OFF
EARTH
2 WIRES
EARTH
3 WIRES
RS
232
AVG DIST
CLR
RCL SAVE
ESC
GO
AMPROBE GP - 2 GeoTest
R
AT-1000 Advanced Tracer
Features:
• Trace energized lines up to 300VAC
or VDC • Trace unenergized and open
conductors • Identifies breakers and
fuses without powering down • Locates
shorts • Identifies wires in a bundle
• Identifies control, alarm and telephone
system wiring • Traces coaxial cable
shield • Receiver range 1 to 3 feet from a
cable being traced
Includes:
• Receiver • Transmitter • Carrying case • 110V pigtail cordset • Alligator
clip cordset (2 pcs.) • CT-326 type adaptor
705-1018-ND (AT-1000)........................................ $370.04
AT-3000 PRO Underground Hawk Buried Wire
and Pipes Tracer
Features:
• Locates underground energized
and de-energized wires, cables and
pipes • Depth measurement up to 10
feet • Visual (LCD) and audible (with
loudspeaker) indicators • Rugged
durable construction • Backlight
• Real Sound Technology - the sound
is derived from the signal radiating
from the cable or pipe • Ready for use
with receiver, transmitter, connection
cable, ground stake and ground
cable • Allows user to pinpoint the
path of the underground traced object
• Weatherproof and drop resistant
705-1019-ND (AT-3000 PRO) ................................ $2638.26
R-3000 PRO
R-3000 PRO
G-3000 PRO
R
AMPROBE
BT-250 Break’r Trac’r™
Features:
• Identifies circuit breaker location
• Works on all electrical systems from
90 to 250 VAC • Automatic sensitivity
adjustment • Quick and easy to use
• Extremely accurate reading always
finds the right breaker • Safety rating:
UL approved
Includes:
• Transmitter • Carrying case • Test leads
• Socket adapter
705-1022-ND (BT-250) ........ $105.69
Made in the USA
ON
OFF
Break’r
Trac’r
BT-250R
AC circuit
breaker identifier
AUTO
SENSITIVITY
ADJUSTMENT
Madein the USA
Transmitter for
Break’r Trac’r
Use on 90-2250VAC
25/ 50/60 Hz Circuits
CUS
LISTED
CIRCUITTESTER
82X5
BT-250T
Megohmmeters
AMB-25
Features:
• Test insulation of wires, cables, transformers and
motors • Comes as a complete kit including test
leads • Internal memory
Specifications:
• Insulation resistance with 250, 500 and 1000 VDC
test voltages: 0 ~ 4.000 / 40.00 / 400.00 / 4000MΩ
• Resistance: 0 ~ 9999Ω
AMB-45
Features:
• Test insulation of wires, cables, transformers
and electrical motors • Comes as a complete
kit including test leads and PC software • Pro-
grammable timer • Internal memory • Safety rating:
CAT III 600V
Specifications:
• Insulation resistance with 250, 500 and 1000 VDC
test voltages: 0 ~ 4.000 / 40.00 / 400.00 / 4000MΩ
• Resistance: 4000Ω • AC/DC Voltage: 600.0V
AMC-2
Features:
• Test insulation of wires, cables, transformers
and electrical motors • Does not require
batteries or any external power supply, always
ready for use • Ohmmeter
Specifications:
• 500VDC Test Voltage: 0 ~ 100MΩ ±5% Rdg
@ (0.1 ~ 50MΩ) ±10% Rdg @ > 50MΩ
AMB-5KV-D
Features:
• Test insulation of wires, cables,
transformers, electrical motors and
generators • Comes as a complete kit
including test leads and PC software
• Built in automatic voltmeter up
to 5000V warns against hazardous
energized systems • Programmable
setups of test voltages and timers
Specifications:
• Voltages: 100V ~ 5000V • Resistance: 100kΩ ~ 500GΩ • Voltmeter: 0 ~
5000V ± (10% Rdg = 10 LSD) @ 0 ~ 500V ± (10% Rdg + 5 LSD) @ 500V ~
5000V • Memory: 20 programmable setup configurations
705-1014-ND (AMB-25) ........................................ $317.17
705-1015-ND (AMB-45) ........................................ $475.79
705-1017-ND (AMC-2).......................................... $687.27
705-1016-ND (AMB-5KV-D) ................................... $2379.14
VG
K
M
RE
ME
AD
Ms
AC
m:
HOLD
MegaTest 1
MEG-OHM
MEG-OHMS
OHMS
MODEL
AMC-3
AMPROBEINSTRUMENT
MΩ: 1000V.
Ω: 6V.
OHM
200
100
50
20
10
5
2
1
0.5
0.2
0
500
200
100
50
20
10
5
2
1
0.5
0
TIF300HV Tic Tracer -
AC Voltage Detector
Features:
• Use to check fuses, break panels, power outlets,
transmission lines, etc.
• Safety rating: UL, CE and MSHA Approved
705-1035-ND (TIF300HV)................ $73.97
705-1036-ND 48” Hot Stick (TIF410A).. $105.69
AT-4004/AT4005 Advanced Wire Tracers
Features:
• One universal transmitter; automatically switches to work with either
energized or non-energized systems • Receiver not position sensitive
• Traces live wires buried or hidden behind walls • Locates breakers, neutrals
and ground lines • Pinpoints shorts, ground faults and broken wires
• Clamp-on attachment injects signal for non-contact operation • Safety rating:
CAT III 600V
Includes:
• Hard carrying case • Receiver • Transmitter • 110V pigtail - banana plug
cord set • Alligator clip - banana plug cord set • Grounding test lead, 25 ft.
with alligator clip • Clamp-on transmitter accessory • Rechargeable battery
pack and battery pack recharger (AT4005CON Only)
705-1020-ND (AT-4004CON) ................................... $793.01
705-1021-ND (AT-4005CON) .................................. $951.63
CAT III 600V MAX
SIGNAL LEVEL
ON/OFF
SIGNALLEVEL
T-4000
TRANSMITTER
R
AMPROBE
R
R
MODE
SENSITIVITY
HI
MID
LOW
OPEN
LOW BATT
ON
SHORT
SIGNAL LEVEL
CON
ON/OFF
R-4000
RECEIVER
R
AMPROBE
AMPROBE
AT-4005CON
