HP 100TX NightDIRECTOR/100 User manual

HP 10BT/100TX NightDIRECTOR/100
Ethernet Card
Installation Guide
HP 10BT/100TX NightDIRECTOR/100
Ethernet-Karte
Installationshandbuch
Guide d’installation de la carte
Ethernet
HP 10BT/100TX NightDIRECTOR/100
Guía de Instalación de la Tarjeta
HP 10BT/100TX NightDIRECTOR/100
Ethernet
Léase esto primero
Guida di installazione
della scheda Ethernet
HP 10BT/100TX NightDIRECTOR/100
book.bk : Frontcov.fb4 Page i Monday, October 13, 1997 6:08 PM

book.bk : Frontcov.fb4 Page ii Monday, October 13, 1997 6:08 PM

English
English . . . . . . . . . . . . . . . . . . . . . . . . . . . Chapter 1
Deutsch . . . . . . . . . . . . . . . . . . . . . . . . . . . Kapitel 2
Français. . . . . . . . . . . . . . . . . . . . . . . . . . . Chapitre 3
Español . . . . . . . . . . . . . . . . . . . . . . . . . . . Capítulo 4
Italiano . . . . . . . . . . . . . . . . . . . . . . . . . . . Capitolo 5
book.bk : glob_toc.fb Page iii Monday, October 13, 1997 6:08 PM

English
book.bk : glob_toc.fb Page iv Monday, October 13, 1997 6:08 PM

1
HP 10BT/100TX NightDIRECTOR/100
Ethernet Card Installation Guide
book.bk : title.fb Page i Monday, October 13, 1997 6:08 PM

ii EnglishFrancais
Notice
The information contained in this document is subject to change
without notice.
Hewlett-Packard makes no warranty of any kind with regard to this
material, including, but not limited to, the implied warranties of
merchantability and fitness for a particular purpose. Hewlett-Packard
shall not be liable for errors contained herein or for incidental or
consequential damages in connection with the furnishing, performance,
or use of this material.
Hewlett-Packard assumes no responsibility for the use or reliability of
its software on equipment that is not furnished by Hewlett-Packard.
This document contains proprietary information that is protected by
copyright. All rights are reserved. No part of this document may be
photocopied, reproduced, or translated to another language without the
prior written consent of Hewlett-Packard Company.
Acrobat®and Adobe®are trademarks of Adobe Systems Incorporated
and may be registered in certain jurisdictions.
CompuServeTM is a U.S. trademark of CompuServe, Inc.
Magic PacketTM and PCnetTM are U.S. trademarks of AMD Corporation.
Microsoft®, NT®, and Windows®are U.S. registered trademarks of
Microsoft Corporation.
Hewlett-Packard France
38053 Grenoble Cedex 9
France
1997 Hewlett-Packard Company
book.bk : title.fb Page ii Monday, October 13, 1997 6:08 PM

Contents
English iii
1Installing the HP LAN Card
What’s in the Service Pack? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Installation Requirements. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Overview of the Installation Procedure . . . . . . . . . . . . . . . . . . . . . . . . 5
Pre-installation Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Pre-installation on a Windows 95 System . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Pre-installation on a Windows NT 4.0 System . . . . . . . . . . . . . . . . . . . . . . 6
Installing the HP LAN Card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Updating LAN-specific Fields in the HP PC Setup Utility . . . . . . . . . 9
Post-installation Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Post-installation on a Windows 95 System . . . . . . . . . . . . . . . . . . . . . . . . 10
Post-installation on a Windows NT 4.0 System . . . . . . . . . . . . . . . . . . . . 10
Connecting to a Network . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Checking the Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Troubleshooting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
HP Support Services . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
HP LAN Card Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Physical Layout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Hardware Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Software Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Technical Specifications of the HP LAN Card . . . . . . . . . . . . . . . . . . . . . 15
book.bk : book.toc Page iii Monday, October 13, 1997 6:08 PM

iv English
Regulatory Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
FCC (for USA only). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Notice for Canada . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Hardware Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
book.bk : book.toc Page iv Monday, October 13, 1997 6:08 PM

1
Installing the HP LAN Card
book.bk : chapter.fb Page 1 Monday, October 13, 1997 6:08 PM

1 Installing the HP LAN Card
What’s in the Service Pack?
2English
What’s in the Service Pack?
The service pack contains:
•10 HP LAN cards (10BT/100TX)
•A set of diskettes:
❒one HP LAN setup diskette
❒two HP LAN driver diskettes
❒two Adobe®Acrobat®Reader diskettes (Version 2.2)
Use Acrobat Reader to read the online Network Administrator’s
guide (in English only) available on one of the HP LAN drivers
diskettes. The Network Administrator’s guide is for advanced
users only.
•10 external start cables
•This Installation Guide.
book.bk : chapter.fb Page 2 Monday, October 13, 1997 6:08 PM

English 3
1 Installing the HP LAN Card
Installation Requirements
Installation Requirements
Supported Platforms The HP LAN accessory kit is supported by HP Vectra VE4 PCs and
Kayak XA, XU and XW PC Workstations, running the following
operating systems (in English, French, German, Spanish or Italian):
•Windows 95 (all models except Kayak XW, Kayak XU 6/266
FastRAID and Kayak XU 6/300 FastRAID)
•Windows NT 4.0 (all models)
Number of Network
Cards Supported
The HP LAN card installation program supports a maximum of one LAN
card only per PC. If you want to install the HP LAN card in a PC which
already has a LAN card installed, you must install the HP LAN card
software manually. Information on how to do this is included in a
readme.txt file on one of the drivers diskettes in the kit (the PC’s
operating system determines which diskette contains the appropriate
readme.txt file).
Only one HP integrated LAN card is supported per PC. This is because
HP PCs have only one External Start connector on the system board.
Booting/Starting from
Diskette Drive
The PC must be able to boot from the diskette drive. This feature is
configured in the HP PC Setup utility, which is accessed by pressing
during the PC’s startup routine. The location of the setting in the HP PC
Setup utility is typically Security➜Boot Devices Security➜Start from
Floppy.
NT Service Pack If an NT service pack is already installed on the PC, it must be re-
installed after the HP LAN card and software is installed.
For NT4.0 systems, the HP LAN card installation program does not
work on Danish, Dutch, Italian or Norwegian systems where NT service
pack 2 (SP2) is already installed. Service pack 3 (SP3) or higher must
be installed before the HP LAN card installation program is run.
book.bk : chapter.fb Page 3 Monday, October 13, 1997 6:08 PM

1 Installing the HP LAN Card
Installation Requirements
4English
Default Configuration The LAN card installation program’s default configuration is: client for
Microsoft®Networks, IPX, NetBEUI and NDIS. If you want to obtain a
different configuration you must install the HP LAN card software
manually. Information on how to do this is included in a readme.txt file
on one of the drivers diskettes in the kit (the PC’s operating system
determines which diskette contains the appropriate readme.txt file).
HP LAN Setup Diskette The HP LAN Setup diskette must not be write protected during the HP
LAN card installation process.
Operating System
Master Diskettes
The HP LAN card installation program may need to access some of the
operating system’s files. You should have the master diskettes available.
book.bk : chapter.fb Page 4 Monday, October 13, 1997 6:08 PM

English 5
1 Installing the HP LAN Card
Overview of the Installation Procedure
Overview of the Installation Procedure
CAUTION Make sure that you read the section entitled “Installation
Requirements” on the previous two pagesbefore you install the HP LAN
card and software.
Installing the HP LAN card is a 4-stage process. You need to:
1Carry out the pre-installation steps.
2Install the HP LAN card.
3Update fields in the HP PC Setup utility.
4Carry out the post-installation steps.
Pre-installation The pre-installation stage involves:
•Running the HP LAN setup program.
•Re-starting the PC to update the BIOS. The installation program
performs this task automatically.
You must carry out the pre-installation before you physically install the
HP LAN card in the PC.
Installing the HP LAN
Card
This is when you physically install the HP LAN card in a free PCI slot in
the PC. You can install the card in a minitower or in a desktop model.
Updating LAN-Specific
Fields in the HP PC
Setup Utility
You need to check that all the LAN-specific fields in the HP PC Setup
utility are correctly set to enable the HP LAN card to function.
Post-installation During this stage, the installation program performs a number of checks
on the PC and, if necessary, updates some software components before
letting the operating system install the HP LAN drivers.
book.bk : chapter.fb Page 5 Monday, October 13, 1997 6:08 PM

1 Installing the HP LAN Card
Pre-installation Procedure
6English
Pre-installation Procedure
CAUTION Perform the pre-installation before you physically install the HP LAN
card in the PC.
Pre-installation on a Windows 95 System
1With Windows 95 running, insert the HP LAN Setup diskette into the
diskette drive.
2Click Start, and then Run.... The Run dialog box opens.
3In the command line, type a:\setup and click OK. A network
setup dialog box opens.
4Click Next. A second network setup dialog box opens.
5Click Finish. The PC reboots under DOS and displays a message
asking you whether there is another LAN card already installed.
6Type n, then remove the HP LAN Setup diskette from the diskette
drive and turn off the PC.
7Now go to “Installing the HP LAN Card” on page 8.
Pre-installation on a Windows NT 4.0 System
1With Windows NT running, insert the HP LAN Setup diskette into
the diskette drive.
2Click Start, then Run....
3In the command line, type a:\setup and click OK. An account
information dialog box opens.
4Enter the name of an account which is a member of the
administrator group, and the corresponding password. If you are
already logged on with administrator’s rights, the field for the
account name is automatically filled in with your account name.
5Click Next. A dialog box is displayed.
book.bk : chapter.fb Page 6 Monday, October 13, 1997 6:08 PM

English 7
1 Installing the HP LAN Card
Pre-installation Procedure
6Click Finish. The PC reboots under DOS and displays a message
asking you whether there is another LAN card already installed.
7Type n, then remove the HP LAN Setup diskette from the diskette
drive and turn off the PC.
8Now go to “Installing the HP LAN Card” on page 8.
book.bk : chapter.fb Page 7 Monday, October 13, 1997 6:08 PM

1 Installing the HP LAN Card
Installing the HP LAN Card
8English
Installing the HP LAN Card
For complete information on how to install an accessory card (or
board), refer to your PC User’s Guide. The following steps are given as
a guide.
1With the PC turned off, disconnect the power cord and any
connection to a telecommunications network, and then remove the
cover.
2Depending on the PC model, you may need to remove the accessory
slot’s retaining bracket, which can be found at the back of the PC.
3Remove the slot cover.
4Connect the External Start cable and, without bending it, insert the
card into the accessory slot.
5Secure the card by replacing the slot cover screw or the retaining
bracket and its screw, as appropriate for the PC.
6Replace the cover. Reconnect the power cord and any connection to
a telecommunications network.
The card may be installed in a minitower
model or in a desktop model.
Refer to “HP LAN Card Specifications”
on page 14 for the position of the
External Start connector on the HP LAN
card. Refer to the PC’s user or technical
documentation for the position of the
External Start connector on the system
board.
book.bk : chapter.fb Page 8 Monday, October 13, 1997 6:08 PM

English 9
1 Installing the HP LAN Card
Updating LAN-specific Fields in the HP PC Setup Utility
Updating LAN-specific Fields in the HP PC Setup Utility
Having physically installed the HP LAN card in the PC, you now need to
check that the BIOS is configured to use the card. To do this you need
to use the HP PC Setup utility.
Starting the HP PC
Setup Utility
1Restart the PC.
2Press when F2=Setup is displayed on the screen during the PC’s
startup routine. The opening window of the HP PC Setup utility is
displayed.
Using the HP PC Setup
Utility
Refer to the User’s Guide for the PC to find out how to navigate through
the HP PC Setup utility and how to make changes to fields.
Which Fields Need
Updating?
You need to check, and update if necessary, all the fields that are
LAN-related.
The User’s Guide supplied with the PC should contain a section
explaining how to configure a LAN interface. The bulleted list given
below should be used as a guideline. The field names used in your
version of the Setup program may be slightly different to those shown
below. Refer to the PCs User’s Guide for more information.
•Check that the integrated LAN interface is enabled
(Advanced➜Integrated Network Interface➜Integrated Ethernet
Interface [Enabled]).
•Check that the PC can be started (booted and logged on) from the
network (Security➜Boot Devices Security➜Start from Network
[Enabled]).
•Check that the PC can be woken up from the network
(Power➜Suspend Wakeup➜Integrated Network [Enabled]).
•Check that the PC can be powered on from the network
(Power➜Power-On➜Integrated Network [Enabled]).
book.bk : chapter.fb Page 9 Monday, October 13, 1997 6:08 PM

1 Installing the HP LAN Card
Post-installation Procedure
10English
Post-installation Procedure
CAUTION Make sure that you have installed the HP LAN card before you perform
the post-installation step.
Post-installation on a Windows 95 System
1Restart the PC. Windows 95 automatically detects, and installs the
software for, the HP LAN card. You may be asked to insert one of the
Windows 95 installation diskettes.
2Restart your PC when prompted to do so. Remember to remove the
HP LAN Setup diskette before you do this.
The HP LAN card is now ready to use.
Post-installation on a Windows NT 4.0 System
1Restart the PC and start Windows. You do not need to
press ++ to log on.
2When prompted to do so, insert the HP LAN Setup diskette into the
diskette drive, and click OK. The setup wizard starts, and displays a
dialog box indicating that the PC is ready to install the HP LAN card.
3Type the path to the NT master disk (C:\I386 if the operating system
files were copied to the hard disk during the installation of Windows
NT), then click Next. The installation of the HP LAN card starts
automatically. When the installation is complete, the last page of the
wizard is displayed.
4Click Finish to end the wizard.
5Restart your PC when prompted to do so. Remember to remove the
HP LAN Setup diskette before you do this.
CAUTION If a service pack was already installed on the PC before the HP LAN card
was installed, the service pack must be re-installed before the HP LAN
card will function.
The HP LAN card is now ready to use.
book.bk : chapter.fb Page 10 Monday, October 13, 1997 6:08 PM

English 11
1 Installing the HP LAN Card
Connecting to a Network
Connecting to a Network
Connect the network cable to the RJ-45 UTP (Unshielded Twisted
Pair) LAN connector. The LAN card supports both 10 Mbits/s and
100 Mbits/s operation.
Remote Wake Up
(RWU) and Remote
Power On (RPO)
The HP LAN card has the ability to power up the PC upon receipt of a
special sequence (known as a Magic PacketTM) from the network.
The RWU mode allows the PC to resume normal functioning when it is
in sleep (suspend) mode.
The RPO mode allows the PC to start when it is switched off.
Checking the Installation
Test whether the HP LAN card functions on the network by finding
another network device or performing a network operation. If it does
not work correctly, refer to “Troubleshooting” on page 12.
10BT/100TX
Connector
book.bk : chapter.fb Page 11 Monday, October 13, 1997 6:08 PM

1 Installing the HP LAN Card
Troubleshooting
12English
Troubleshooting
The HP LAN card does
not work
•Check that the installation requirements have been adhered to (refer
to page 3).
•Check that:
❒The pre-installation steps have been followed (refer to page 6).
❒The HP LAN card is correctly installed (refer to page 8).
❒The LAN-specific fields in the HP PC Setup utility are correctly
set (refer to page 9).
❒The post-installation steps have been followed (refer to page 10).
•Check the network cables. In particular, check that the network
cable connections are secure and that the cables are not damaged. If
you find any loose connections or damaged cables, fix them and then
see if your PC can communicate on the network.
•Check with the network administrator whether the network is active.
The light on the HP LAN card’s rear panel is off when there is no
autonegotiation response, for example, when the LAN cable is not
connected to the network HUB.
•Check that the PCI slot in which the HP LAN card is installed is
enabled in the HP PC Setup utility (Advanced➜PCI Configuration).
The PC cannot be
started or woken up
from the network
•Check that the external start connector cable is connected to the HP
LAN card and to the PC’s system board.
•Check that the LAN-specific fields in the HP PC Setup utility are
correctly set (refer to page 9).
book.bk : chapter.fb Page 12 Monday, October 13, 1997 6:08 PM
