NEC iPASOLINK EX Advanced User manual

GGS-000543-01E
June 2016
NEC Corporation
7-1, Shiba 5-Chome, Minato-Ku, Tokyo 108-8001, Japan
71-76/81-86 GHz
PACKET RADIO SYSTEM
iPASOLINK EX
Advanced
INSTRUCTION MANUAL

GENERAL - 1 -
iPASOLINK EX Advanced: SAFETY INFORMATION GGS-000544-01E
iPASOLINK EX Advanced
SAFETY INFORMATION
The Safety Information provides precautions and directions to install, operate and
maintain the iPASOLINK EX Advanced (hereinafter iPASOLINK EX/A) safely. To
prevent the equipment from being damaged or causing bodily harm, please
familiarize yourself with the contents here in this document and in the instruction
manuals before installing/operating the equipment.
Following indications are used for admonishment:
GENERAL
This system should be installed, powered on, operated
and maintained only by the appropriate service personnel
who is/are skilled enough to be aware of hazards to which
the personnel may be exposed during operation, and of
measures to minimize the risks to the personnel or others.
DANGER Indicates an imminently hazardous situation, which, if not avoided, will
result in death or serious injuries.
WARNING
Indicates an imminently hazardous
situation, which, if not avoided, could
result in serious injuries or physical
damages.
CAUTION
Indicates a potentially hazardous
situation, which, if not avoided, may
result in minor or moderate injuries or
physical damages. It is also used to
alert against inappropriate practices

- 2 - LABELS
GGS-000544-01E iPASOLINK EX Advanced: SAFETY INFORMATION
LABELS
Marks of Cautions and Warnings printed on the equipment are shown below. In case
that these labels are out of sight due to the installed condition, please contact NEC.:
Risk of Electric Shock
The system uses a high voltage. Extra attention is required particularly in the
WET CONDITION in the outdoor environment.
Hot Surface. Do Not Touch
The surface of the equipment may be heated if it is in operation. Ensure
not to touch the equipment while it is in operation.
Non-Ionizing Radiation
Caution that the non-ionizing radiation from the equipment may affect
your health.
WEEE
Waste Electrical and Electronic Equipment — The electrical and
electronic products with this mark are the subjects to follow WEEE.
Disposal of NEC equipment or any part of NEC equipment with this
mark should comply with regulations implemented by the local
authorities or the agreement with NEC.
China RoHS
Equipment with this mark is the subject to compliance with China RoHS
in terms of the environmental protection applied to the electrical and
electronic equipment.
Protective Earthing (Must Be Grounded)
Any device and equipment with this label must be connected to the ground
using its Grounding Terminal.

WARNING - 3 -
iPASOLINK EX Advanced: SAFETY INFORMATION GGS-000544-01E
WARNING
(1) Risk of Electric Shock
(2) Microwave Radiation
WARNING
(1) iPASOLINK EX/A is designated to use the –48 V DC
power at the outdoor environment. Due to the risk of
electric shock, particular attention should be paid in
wet condition that decreases the electric resistance.
(2) AC Power Module is designated to convert the 100-200
V AC power to –48 V DC power at the outdoor
environment. Due to the risk of electric shock,
particular attention should be paid in wet condition
that decreases the resistance.
WARNING
Do not enter the area in front of the antenna while
transmitter is activating. Power density of microwave or
millimeter-wave is high along the antenna beam. For
details, refer to the NOTICE and SAFETY GUIDELINE in this
document.

- 4 - WARNING
GGS-000544-01E iPASOLINK EX Advanced: SAFETY INFORMATION
(3) Class1/1M Laser Product
WARNING
In a system using optical modules, do not stare at the laser
beams directly when using the optical instruments. or it
may cause damages to eyes and skin.

CAUTION - 5 -
iPASOLINK EX Advanced: SAFETY INFORMATION GGS-000544-01E
CAUTION
(1) Lift with Care
(2) To Work in High Place
(3) Supply Safety Extra Low Voltage
CAUTION: HEAVY
Use Caution when Lifting: This equipment is heavier
than you expect. Ensure not to hurt yourself or the
equipment when lifting or transporting it.
CAUTION
Take care not to drop the equipment, parts and/or tools
when working in a high place. Even a small part could
be a weapon (sometimes deadly), if it is fallen from the
high place. Ensure to take adequate measures, such as
restricting the area, to prevent an accident before
starting the high-place work.
CAUTION
Use the Safety Extra Low Voltage (SELV) to supply the
–48 VDC power to the equipment.

- 6 - CAUTION
GGS-000544-01E iPASOLINK EX Advanced: SAFETY INFORMATION
(4) Protect from Lightning
(5) Do Not Touch Power Plug While in Service
(6) Use Circuit Breaker
CAUTION
Place iPASOLINK EX/A within the area protected by
lightning rod. To avoid surge current caused by lightning,
from circulating within the equipment earth system, the
equipment earth system should be connected to the
ground of the lightning rod at the ground level.
CAUTION
While the equipment is powered on, do not even attempt
to disconnect/reconnect the power supply plug, or the
equipment and DC-DC CONV may be damaged.
CAUTION
iPASOLINK EX/A requires a circuit breaker or shut-off
function externally. The equipment does not provide a
power on/off switch. Place the equipment and a power
injector in position to shut the power of iPASOLINK EX/
A off safely just in case of emergency.

CAUTION - 7 -
iPASOLINK EX Advanced: SAFETY INFORMATION GGS-000544-01E
(7) Using PoE
(8) Use STP Cable for LAN Connection
CAUTION
When iPASOLINK EX/A is powered via the PoE
Terminal, ensure not to disconnect the LAN Cable while
in service, or the equipment may be damaged.
CAUTION
iPASOLINK EX/A provides PoE (Power over Ethernet)
Port, which can enable either –48 VDC Power Port or
PoE Port but not both at a time. See NOTICE (POWER
SUPPLY AND CIRCUIT BREAKER) also.
CAUTION
Use STP (Shielded Twisted Pair) cables for LAN
connections. Using UTP (Unshielded Twisted Pair) cables
may result in damage to the equipment, causing the
failure. To enable the shielding effect for the radio
equipment and devices to which it is connected, ground
the equipment and connecting cables securely and
properly.

- 8 - CAUTION
GGS-000544-01E iPASOLINK EX Advanced: SAFETY INFORMATION
(9) Do Not Use Cables Charged with Static Electricity
(10) Quit Operation in Case of Emergency
CAUTION
Do not use cables that are charged with static electricity.
If the charged cables are used for connecting to the
equipment, it may result in damage to the equipment.
Make sure that the cables are not charged with static
electricity before connecting them to the equipment.
CAUTION
In case of emergency, such as detecting unusual odor,
burning smells, smokes, or strange sounds, quit
operating the equipment immediately, and power it off. If
the equipment keeps operating in such condition, the
equipment may get damaged, generating an electric
shock, which should not be fixed or repaired by
customers.

CAUTION - 9 -
iPASOLINK EX Advanced: SAFETY INFORMATION GGS-000544-01E
(11) Do Not Disassemble
CAUTION
Do not attempt to disassemble, modify, overhaul, or
repair the equipment by yourself, or it may damage the
equipment or may result in giving an electric shock.

- 10 - NOTICE (PLACING EQUIPMENT)
GGS-000544-01E iPASOLINK EX Advanced: SAFETY INFORMATION
NOTICE (PLACING EQUIPMENT)
1. iPASOLINK EX/A generates non-ionizing radiation, and is designated for
the outdoor use. Installing the equipment indoors may cause bodily harm
nor inflict damage to objects, which needs to take the adequate measures, if
occurs.
2. iPASOLINK EX/A should be installed as follows:
Verify that the equipment is installed in the appropriate site. Do not
install it on an unstable spot. Improper installation raises the
temperature inside the equipment, which may damage the
equipment.
Accessing to the equipment should be limited only by the SERVICE
PERSONNEL or by USERS WHO ARE WELL TRAINED WITH
ENOUGH SKILLS AND KNOWLEDGES REGARDING THESE
RESTRICTIONS, PRECAUTIONS AND INSTALLATION SITES.
Accessing to the equipment must be protected using a tool, locks,
keys, and/or other means of security, which should be managed by
the authority who is responsible for the installed site.
The other end of the grounding cable connected to the ground
terminal should be connected to the station earth point. For details,
refer to the Installation Manual.
3. Precautions for Cables:
(a) POWER SUPPLY CABLES
Use two-core double insulated cable of 5.86 to 10.00 mm in diameter.
(b) DATA TRANSMISSION CABLES
Use shielded cables for the data transmission cables.
(c) GROUNDING
Ground Terminal should be connected to the station earth point. For
details, refer to the Grounding the Frame section in the Installation
manual.
4. Transmission quality degradation may temporarily occur due to the
electromagnetic disturbances, such as lightning or ESD.

NOTICE (POWER SUPPLY AND CIRCUIT BREAKER) - 11 -
iPASOLINK EX Advanced: SAFETY INFORMATION GGS-000544-01E
NOTICE (POWER SUPPLY AND CIRCUIT BREAKER)
Since iPASOLINK EX/A itself does not have a power on/off switch, it requires a
circuit breaker or shut-off function externally. See the following for reference:
The cable should be shielded to keep operating in conformity with EMC standards.
➀Using DC IN (Power) Port
DC –48V
➁Using LAN (PoE) Port
PoE
EX/A
EXTERNAL CIRCUIT BREAKER
EXTERNAL
POWER
INJECTOR
CIRCUIT
BREAKER
LAN CABLE
POWER CABLE
EX/A
Use STP (shielded twisted pair) cable.
DC –48V
EXTERNAL CIRCUIT BREAKER
AC POWER CABLE
AC POWER
MODULE
POWER CABLE
AC 100 V to 240 V
EX/A
➁Using AC Power Module
(2-Core Shielded Cable of
14 to 16 AWG)
(2-Core Shielded Cable of
14 to 16 AWG)

- 12 - SAFETY GUIDELINE FOR USING HAZARDOUS MICROWAVE RADIATION
GGS-000544-01E iPASOLINK EX Advanced: SAFETY INFORMATION
SAFETY GUIDELINE FOR USING HAZARDOUS MICROWAVE
RADIATION
The radiation levels of Microwave and Millimeter-Wave that iPASOLINK series deal
with are very low, and no health hazard has been reported for them so far. However,
advanced countries that care much about health hazard have started regulating the
radiation levels. For EU countries, it is specified by EN 62311 Annex A A.2. In order
to follow the regulation, operators should not work near the antenna if its transmitter
is activating. Especially, the radiation level of a specific area (Xand Yshown in the
illustration below) in front of antenna is high.
See the following illustration and Calculation Examples 1 and 2:
Power density in front of the antenna turns high along the antenna beam. Ensure not
to allow yourself radiated by beams anytime.
Radiation Hazard Area
The power density and field strength level can be obtained by the following
calculation formula:
Where
P= Output Power (W),
P’ = Output Power (dBm),
G= Antenna Gain (dBi),
(in condition of angle and range from antenna)
R= Distance between human being and antenna (m)
iPASOLINK EX/A
ANTENNA
–90 to +90
degrees
Calculation Example 1
Calculation Example 2
X
SAFETY DISTANCE: X m
SAFETY DISTANCE: Y m
Y
Power Density : S = P’+ G– 30
10

 
10
40R2
(W/m2) =
4R2(mW/cm2)
P

SAFETY GUIDELINE FOR USING HAZARDOUS MICROWAVE RADIATION - 13 -
iPASOLINK EX Advanced: SAFETY INFORMATION GGS-000544-01E
Safety distance should be calculated according to the conditions of installation site.
Following show the calculation examples:
Calculation Example 1 (Front Side of Antenna)
iPASOLINK EX = +18 dBm
Antenna Diameter = 0.6 m
Antenna Gain = 52 dBi
Distance = 9.0 m
Output Power Density : S = 0.982 mW/cm21 mW/cm2
Limit: Output Power Density S = 10 (W/m2)*= 1 (mW/cm2)
*: COUNCIL RECOMMENDATION (1999/519/EC) of 12 July 1999 on the
limitation of exposure of the general public to electromagnetic fields (0 Hz to 300 GHz)
Calculation Example 2 (Rear Side of Antenna)
iPASOLINK EX = +18 dBm
Antenna Diameter = 0.6 m
Antenna Gain = –16 dBi
Distance = 0.004 m = 4.0 mm
Output Power Density : S = 0.788 mW/cm21 mW/cm2
Limit: Output Power Density S = 10 (W/m2)*= 1 (mW/cm2)
*: COUNCIL RECOMMENDATION (1999/519/EC) of 12 July 1999 on the
limitation of exposure of the general public to electromagnetic fields (0 Hz to 300 GHz)
The safety distance that is obtained by the conditions above and is below the value
defined by COUNCIL RECOMMENDATIN (1999/519/EC) of 1 mW/cm² is:
Front Side of Antenna (X) 9.0 m
Rear Side of Antenna (Y) 0.004 m = 4.0 mm

GGS-000546-01E
June 2016
NEC Corporation
7-1, Shiba 5-Chome, Minato-Ku, Tokyo 108-8001, Japan
iPASOLINK EX
Advanced
INSTALLATION

CONTENTS – i –
iPASOLINK EX Advanced: INSTALLATION GGS-000546-01E
June 2016
iPASOLINK EX/A
INSTALLATION
CONTENTS
1. OVERVIEW 1-1
2. COMPOSITIONS 2-1
2.1 Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-1
2.2 Power Supply and Circuit Breaker . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-1
2.3 Available Systems and Components . . . . . . . . . . . . . . . . . . . . . . . . . . 2-3
2.3.1 1+0 System. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-3
2.4 Components Appearances. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-4
2.4.1 iPASOLINK EX/A Main Part . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-4
2.4.2 Power Injector . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-4
2.4.2.1 AC PSE Unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-4
2.4.2.2 DC PSE Unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-5
2.4.3 Power Cable (SELV) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-5
2.4.4 LAN Cable (Electric) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-5
2.4.5 LAN Cable (Optic). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-6
2.4.6 Grounding Cable. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-6
2.4.7 Antenna and its Mounting Brackets. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-7
3. UNPACK iPASOLINK EX/A 3-1
4. MOUNT iPASOLINK EX/A 4-1
4.1 For Placing Equipment. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-1
4.2 Mount iPASOLINK EX/A for 1+0 System. . . . . . . . . . . . . . . . . . . . . . . . 4-2
4.2.1 Set Antenna Brackets to Pole . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-2
4.2.1.1 Polarization: Vertical . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-2

– ii – CONTENTS
GGS-000546-01E iPASOLINK EX Advanced: INSTALLATION
4.2.1.2 Polarization: Horizontal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-3
4.2.2 Secure iPASOLINK EX/A to Antenna Attachment. . . . . . . . . . . . . . . . . . 4-4
4.3 Mount SFP Module . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-5
5. CONNECT CABLES 5-1
5.1 Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-1
5.2 Connecting Terminals. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-2
5.2.1 iPASOLINK EX/A (1+0 System) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-2
5.3 Grounding Cable. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-3
5.4 Power Cable. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-4
5.5 LAN Cables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-7
5.5.1 DCN (PoE) Port (RJ-45) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-7
5.5.2 P2/P3 Port (SFP+) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-10
5.6 Routing Cables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-13
5.6.1 Allowable Bending Radius of Cables . . . . . . . . . . . . . . . . . . . . . . . . . . 5-13
5.6.2 Secure Cables (for 1+0 System). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-14
5.7 Pin Assignment of Connectors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-15
5.7.1 Summary. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-15
5.7.2 Power Port (SELV) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-16
5.7.3 P1 Port . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-17
5.7.4 P2, P3 Port . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-18
5.8 Assemble Cables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-19
5.8.1 Grounding Cable. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-19
5.8.1.1 Outlines of Parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-19
5.8.1.2 Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-19
5.8.2 Power Cable (2-Core Cable). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-21
5.8.2.1 Outlines of Parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-21
5.8.2.2 Considering to Wear Waterproofing Plug Cover . . . . . . . . . . . . . 5-22
5.8.2.3 Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-23

CONTENTS – iii –
iPASOLINK EX Advanced: INSTALLATION GGS-000546-01E
6. GROUND iPASOLINK EX/A 6-1
7. START UP AND SHUT DOWN 7-1
7.1 Start Up iPASOLINK EX/A . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-1
7.2 Check Reception Level. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-1
7.3 Shut Down iPASOLINK EX/A . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-2
8. ADJUST ANTENNA ANGLE 8-1
8.1 Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-1
8.2 Adjust Equipment Angle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-1
8.3 Adjust Antenna Angle. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-5
8.4 Safety Guideline for Microwave Radiation Hazard. . . . . . . . . . . . . . . . 8-8

– iv/END – CONTENTS
GGS-000546-01E iPASOLINK EX Advanced: INSTALLATION
This page is intentionally left blank.

OVERVIEW 1-1
iPASOLINK EX Advanced: INSTALLATION GGS-000546-01E
1. OVERVIEW
The standard installation is summarized in this section. Following shows the typical
installation work flow and guides:
Figure 1-1 Installation Flow
Mount iPASOLINK EX/A
(Section: 4. MOUNT iPASOLINK EX/A)
Connect Cables
(Section: 5. CONNECT CABLES)
Adjust Equipment Angle
(Section: 8. ADJUST ANTENNA ANGLE)
Start Up iPASOLINK EX/A
(Section: 7. START UP AND SHUT DOWN)
WebLCT should be operational here.
Refer to the Set Network & System Provisioning
Unpack iPASOLINK EX/A
(Section: 3. UNPACK iPASOLINK EX/A)
Ground (Earth)
(Section: 6. GROUND iPASOLINK EX/A)
manual.
