Installation
and Verication
EMI Receiver Series
HP 8542E/HP 8546A
EMI Receiver
HP 85422E/HP 85462A
Receiver RF Section
ABCDE
HP Part No. 5962-0478
Printed in USA December 1996

Notice.
The information contained in this document is subject to change
without notice.
Hewlett-Packard makes no warranty of any kind with regard to this
material, including but not limited to, the implied warranties of
merchantability and tness for a particular purpose. Hewlett-Packard
shall not be liable for errors contained herein or for incidental
or consequential damages in connection with the furnishing,
performance, or use of this material.
c
 Copyright Hewlett-Packard Company 1994, 1996
All Rights Reserved. Reproduction, adaptation, or translation without
prior written permission is prohibited, except as allowed under the
copyright laws.
1400 Fountaingrove Parkway, Santa Rosa CA, 95403-1799, USA

Certication
Hewlett-P
ackard Company certies that this product met its
published specications at the time of shipment from the factory.
Hewlett-P
ackard further certies that its calibration measurements
are traceable to the United States National Institute of Standards and
T
echnology, to the extent allowed by the Institute's calibration facility,
and to the calibration facilities of other International Standards
Organization members.
Regulatory Information
Regulatory information is located in the EMI Receiver Series Reference
at the end of Chapter 1, \Specications and Characteristics."
Warranty
This Hewlett-Packard instrument product is warranted against defects
in material and workmanship for a period of one year from date of
shipment. During the warranty period, Hewlett-Packard Company
will, at its option, either repair or replace products which prove to be
defective.
F
or warranty service or repair
,this product must be returned to a
service facility designated by Hewlett-P
ackard. Buyer shall prepay
shipping charges to Hewlett-P
ackard and Hewlett-P
ackard shall pay
shipping charges to return the product to Buyer
.However
,Buyer shall
pay all shipping charges
,duties
,and taxes for products returned to
Hewlett-P
ackard from another country
.
Hewlett-P
ackard warrants that its software and rmware designated
by Hewlett-P
ackard for use with an instrument will execute
its programming instructions when properly installed on that
instrument. Hewlett-P
ackard does not warrant that the operation
of the instrument, or software, or rmware will be uninterrupted or
error-free.
Limitation of Warranty
The foregoing warranty shall not apply to defects resulting from
improper or inadequate maintenance by Buyer, Buyer-supplied
software or interfacing, unauthorized modication or misuse,
operation outside of the environmental specications for the
product, or improper site preparation or maintenance
.
NO OTHER W
ARRANTY IS EXPRESSED OR IMPLIED
.
HEWLETT-PACKARD SPECIFICALLY DISCLAIMS THE IMPLIED
WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A
PARTICULAR PURPOSE.
Exclusive Remedies
THE REMEDIES PROVIDED HEREIN ARE BUYER'S SOLE AND
EXCLUSIVE REMEDIES. HEWLETT-PACKARD SHALL NOT BE
LIABLE FOR ANY DIRECT, INDIRECT, SPECIAL, INCIDENTAL, OR
CONSEQUENTIAL DAMAGES, WHETHER BASED ON CONTRACT,
TORT, OR ANY OTHER LEGAL THEORY.
iii

Assistance
Product maintenance agreements and other customer assistance
agreements are available for Hewlett-P
ackard products.For any
assistance
,contact your nearest Hewlett-Packard Sales and Service
Oce
.
Compliance
This instrument has been designed and tested in accordance with
IEC Publication 348, Safety Requirements for Electronic Measuring
Apparatus, and has been supplied in a safe condition. The instruction
documentation contains information and warnings which must be
followed by the user to ensure safe operation and to maintain the
instrument in a safe condition.
Safety Notes
The following safety notes are used throughout this manual.
Familiarize yourself with each of the notes and its meaning before
operating this instrument.
WARNING
Warning denotes a hazard. It calls attention to a procedure
which, if not correctly performed or adhered to, could result in
injury or loss of life.Do not proceed beyond a warning note until
the indicated conditions are fully understood and met.
CA
UTION
Caution denotes ahazard. It calls attention to a procedure that, if
not correctly performed or adhered to, would result in damage to or
destruction of the instrument. Do not proceed beyond a caution sign
until the indicated conditions are fully understood and met.
iv

General Safety Considerations
WARNING
No operator serviceable parts inside. Refer servicing to
qualied personnel. To prevent electrical shock, do not remove
covers.
If this instrument is not used as specied, the protection
provided by the equipment may be impaired. This instrument
must be used in a normal condition (in which all means for
protection are intact) only.
For continued protection against re hazard, replace line fuse
only with same type and rating ([F 5A/250V]). The use of other
fuses or material is prohibited.
CAUTION
Before switching on this instrument, make sure that the line voltage
selector switch is set to the voltage of the power supply and the
correct fuse is installed.
Always use the three-prong ac power cord supplied with this
instrument. Failure to ensure adequate earth grounding by not
using this cord may cause instrument damage.
Only clean the instrument cabinet using adamp cloth.
L
The instruction documentation symbol. The product is
marked with this symbol when it is necessary for the
user to refer to the instructions in the documentation.
CE The CE mark is a registered trademark of the European
Community
.(If accompanied by a year, it is when the
design was proven.)
ISM1-A This is asymbol of an Industrial Scientic and Medical
Group 1 Class A product.
CSA The CSA mark is a registered trademark of the Canadian
Standards Association.
Manual Conventions
4
Front-Panel Key
5 This represents a key physically located on the
instrument.
NNNNNNNNNNNNNNNNNNNNNNN
Softkey This indicates a \softkey," a key whose label is
determined by the rmware of the instrument.
Screen Text This indicates text displayed on the instrument's
screen.
v

EMI Receiver Series Documentation Description
The following documents are provided with either the EMI receiver or
the receiver RF section.
Installation and Verication
provides information for installing
your instrument, verifying instrument operation, and customer
support.
User's Guide describes instrument features and how to make
measurements with your EMI receiver or receiver RF section.
Reference provides specications and characteristics, menu maps,
error messages, and key descriptions.
Programmer's Guide provides information on remote control
instrument conguration, creating programs, and parameters for
each of the programming commands available.
vi

Contents
1. Preparing for Use
Introducing the EMI Receiver . . . . . . . . . . . . . 1-1
Accessories Supplied ................. 1-2
InitialInspection ... .. .. .. .. .. .. .. .. 1-4
Electrostatic Discharge ................ 1-5
Reducing Damage Caused by ESD .. .. .. .. .. 1-6
Installation Procedures ................ 1-7
Installing the EMI Receiver ............. 1-8
Installing the Receiver RF Section . . . . . . . . . . 1-15
PowerCables..................... 1-18
2. Operation V
erication
Safety ...... .. .. .. .. .. .. .. .. .. 2-2
Before Y
ou Start .... .. .. .. . .. .. .. .. 2-2
T
est equipment you will need . . . . . . . . . . . . 2-3
Recording the test results . . . . . . . . . . . . . . 2-3
If the receiver doesn't meet specications ...... 2-3
Periodically verifying operation ...... .. .. . 2-3
1. Frequency Readout and Marker Count Accuracy . 2-7
2. Frequency Span Readout Accuracy ....... 2-12
3. EMI Receiver Absolute Amplitude Accuracy . . . 2-16
4. Input Attenuator Accuracy for Receiver RF
Section .................... 2-23
5. Input Attenuator A
ccuracy for EMI Receiver .. 2-26
6. Scale Fidelity ................. 2-31
7. EMI Receiver Reference Level Accuracy .... 2-39
8. Receiver RF Section Reference Level Accuracy . 2-45
9. Calibrator Amplitude Accuracy . . . . . . . . . 2-51
10. Calibration Repeatability and IF Bandwidth
Uncertainty.. .. .. .. .. .. .. .. .. 2-55
11. Frequency Response for the Receiver RF Section 2-59
12. EMI Receiver Overload ............ 2-68
13. Receiver RF Section Overload . . . . . . . . . 2-69
14. Displayed Average Noise Level for EMI Receiver 2-70
15. Displayed Average Noise Level for Receiver RF
Section . . . . . . . . . . . . . . . . . . . . 2-78
16. CISPR Pulse Response . . . . . . . . . . . . . 2-84
Operation Verication Test Record . . . . . . . . . . . 2-95
Contents-1

3. Customer Support
If You Have a Problem ...... .. .. .. .. .. 3-1
Calling HP Sales and Service Oces .......... 3-1
Check the Basics . . . . . . . . . . . . . . . . . . . 3-2
If Your EMI Receiver Does Not Turn On ....... 3-2
If the RF Filter Section Does Not Seem to be Working . 3-2
If the EMI Receiver Cannot Communicate Via HP-IB . 3-2
Verication of Proper Operation . . . . . . . . . . . 3-2
If the RF lter section Does Not Power O . . . . . . 3-2
ErrorMessages................... 3-2
Additional Support Services . . . . . . . . . . . . . . 3-3
CompuServe ........... .. . .. .. .. 3-3
FAX Support Line .... .. .. .. .. .. .. . 3-4
Returning the EMI Receiver for Service ........ 3-5
Package the EMI receiver for shipment ....... 3-5
4. Error Messages
Nonrecoverable System Errors ............ 4-14
Index
Contents-2

Figures
1-1. EMI Receiver . . . . . . . . . . . . . . . . . . . . 1-1
1-2. Example of a Static-Safe Work Station . . . . . . . . 1-5
2-1. Frequency Readout Accuracy Test Setup . . . . . . . 2-7
2-2. 1800 MHz Frequency Span Readout Accuracy Test
Setup...................... 2-12
2-3. 10.1 MHz to 10 kHz Frequency Span Readout Accuracy
Test Setup ................... 2-14
2-4. Input 1 Absolute Amplitude Accuracy Setup ..... 2-16
2-5. Input 2 Absolute Amplitude Accuracy Setup ..... 2-19
2-6. Input Attenuator Accuracy Test Setup . . . . . . . . 2-23
2-7. Input Attenuator Accuracy Test Setup for Frequency
Selection .......... .. .. .. .. .. 2-26
2-8. Input Attenuator A
ccuracy T
est Setup . . . . . . . . 2-27
2-9. Scale Fidelity T
est Setup .............. 2-31
2-10. Reference Level A
ccuracy T
est Setup ........ 2-39
2-11. Reference Level A
ccuracy T
est Setup ........ 2-45
2-12. LPF Characterization . . . . . . . . . . . . . . . . 2-52
2-13. Calibrator Amplitude Accuracy Test Setup ...... 2-53
2-14. Uncertainty Test Setup .... .. .. .. .. .. . 2-55
2-15. Frequency Response Test Setup,  50 MHz .. .. .. 2-59
2-16. Frequency Response Test Setup ( < 50 MHz) . . . . . . 2-62
2-17. Displayed Average Noise Level Test Setup-EMI receiver 2-70
2-18. Displayed Average Noise Level Specications  400 kHz 2-72
2-19. Displayed Average Noise Level Test Setup ...... 2-78
2-20. Input Amplitude Calibration Test Setup ....... 2-84
2-21. Isolation Check Test Setup .. .. .. .. .. .. . 2-86
Contents-3

Tables
1-1. EMI Receiver Accessories Supplied . . . . . . . . . . 1-2
1-2. Static-Safe Accessories ............... 1-6
1-3. ACPower Cables Available ............. 1-19
2-1. Operation Verication Tests .. .. .. .. .. .. . 2-1
2-2. Recommended Test Equipment ........... 2-4
2-3. Recommended Accessories ............. 2-5
2-4. Recommended Cables . . . . . . . . . . . . . . . . 2-6
2-5. Frequency Readout Accuracy for the Receiver RF
Section . . . . . . . . . . . . . . . . . . . . . 2-9
2-6. Frequency Readout Accuracy for the EMI Receiver . . 2-9
2-7. Marker Count Accuracy............... 2-11
2-8. Frequency Span Readout A
ccuracy ......... 2-15
2-9. INPUT 1Absolute Amplitude Accuracy Preamp O . . 2-17
2-10. INPUT 1 Absolute Amplitude Accuracy Preamp On . . 2-18
2-11. INPUT 2 Absolute Amplitude Accuracy Preamp O . . 2-21
2-12. INPUT 2 Absolute Amplitude Accuracy Preamp On . . 2-22
2-13. Input Attenuator Error . . . . . . . . . . . . . . . 2-25
2-14. Input 1 Maximum Amplitude Attenuator Error . . . . 2-29
2-15. Input 1 Minimum Amplitude Attenuator Error .. .. 2-29
2-16. Input 2, 50 MHz Attenuator Error . . . . . . . . . . 2-30
2-17. Cumulative and Incremental Error, Log Mode .. .. 2-33
2-18. Cumulative and Incremental Error, Log Mode, Narrow
Bandwidth ................... 2-34
2-19. Scale Fidelity
,Linear Mode ....... .. .. .. 2-36
2-20. Scale Fidelity, Linear Mode ............. 2-36
2-21. Reference Level Accuracy, Log Mode .... .. .. 2-41
2-22. Reference Level Accuracy, Linear Mode ....... 2-42
2-23. Reference Level Accuracy, Log Mode for Narrow
Bandwidths . . . . . . . . . . . . . . . . . . . 2-43
2-24. Reference Level Accuracy, Linear Mode for Narrow
Bandwidths . . . . . . . . . . . . . . . . . . . 2-44
2-25. Reference Level A
ccuracy, Log Mode .. .. .. .. 2-47
2-26. Reference Level A
ccuracy, Linear Mode ....... 2-48
2-27. Reference Level Accuracy, Log Mode for Narrow
Bandwidths . . . . . . . . . . . . . . . . . . . 2-49
2-28. Reference Level Accuracy, Linear Mode for Narrow
Bandwidths . . . . . . . . . . . . . . . . . . . 2-50
2-29. Resolution Bandwidth Switching Uncertainty . . . . . 2-57
2-30. Resolution Bandwidth Switching Uncertainty for
Narrow Bandwidths . . . . . . . . . . . . . . . 2-58
2-31. Frequency Response Band 0 (  50 MHz) ....... 2-65
2-32. Frequency Response Band 1 (For an HP 85462A only) . 2-66
2-33. Frequency Response Band 0 ( < 50 MHz) ....... 2-67
2-34. Non-CISPR Bandwidths Input #1 Preamp O/On  400
kHz .... .. .. .. .. .. .. .. .. .. 2-72
Contents-4

2-35. Non-CISPR Bandwidths Input #1 Preamp O/On  400
kHz .... .. .. .. .. .. .. .. .. .. 2-74
2-36. Non-CISPR Bandwidths Input #2 Preamp O/On .. . 2-75
2-37. Non-CISPR Bandwidths Input #2, 1 GHz to 6.5 GHz
Preamp O/On ................. 2-77
2-38. Displayed Average Noise Level Worksheet .... .. 2-83
2-39. Input Amplitude Calibration Worksheet .... .. . 2-93
2-40. Quasi-Peak Detector Reference Accuracy Worksheet . 2-93
2-41. Quasi-Peak Detector Accuracy............ 2-94
2-42. Operation Verication Test Record . . . . . . . . . . 2-95
3-1. Hewlett-Packard Sales and Service Oces .... .. 3-6
Contents-5

1
Preparing for Use
Introducing the EMI Receiver
The EMI receiver includes the receiver RF section, the RF lter
section, and all the accessories you will need to prepare the system
for use.
This chapter contains information about accessories supplied, initial
inspection, electrostatic discharge, and available power cables.
In addition, installation procedures show how to install the handles,
lock the system together, set the line voltage selector switches, check
the fuses, add the front and rear cables, and set the HP-IB address.
Figure 1-1. EMI Receiver
Preparing for Use 1-1

Accessories Supplied
Table 1-1. EMI Receiver Accessories Supplied
Accessory Description HP Part Number
Receiver RF Section
Power cable See Table 1-3
Limit line and antenna factor
library disk
5010-7721
Handles 5062-3991
Adapters, Type N (m) to BNC (f) 1250-0780
Cable, BNC (m) to BNC (m),
30 cm (12 in)
1
8120-1838
External Keyboard T
emplate 85462-80010
1 For a standalone receiver RF section only, 23 cm (9 in), HP Part Number 8120-2682.
1-2 Preparing for Use

Table 1-1. EMI Receiver Accessories Supplied (continued)
Accessory Description HP Part Number
RF Filter Section
Auxiliary interface cable 8120-6337
Two sweep exible cables 8120-8154
ALC cable 8120-6212
Three type-N semi-rigid cables 85460-20036
Two securing spacers 85460-60028
Preparing for Use 1-3

Table 1-1. EMI Receiver Accessories Supplied (continued)
Accessory Description HP Part Number
RF Filter Section (continued)
Handles 5062-3989
Power cable See Table 1-3
Initial Inspection
Inspect the shipping container for damage
. If the shipping container
or cushioning material is damaged, keep it until you have veried
that the contents are complete and you have tested the EMI receiver
mechanically and electrically.
Table 1-1 contains the accessories shipped with the EMI receiver.
If the contents are incomplete or if the EMI receiver does not pass
the operation verication tests in Chapter 2, notify the nearest
Hewlett-Packard oce. If the shipping container is damaged or the
cushioning material shows signs of stress, also notify the carrier. Keep
the shipping materials for the carrier's inspection. The HP oce
will arrange for repair or replacement without waiting for a claim
settlement.
If the shipping materials are in good condition, retain them for
possible future use.You may wish to ship the EMI receiver to another
location or return it to Hewlett-Packard for service. See \Returning
the EMI Receiver for Service," in Chapter 3, for more information
about shipping materials.
1-4 Preparing for Use

Electrostatic Discharge
Electrostatic discharge (ESD) can damage or destroy electronic
components
.All work on electronic assemblies should be performed
at astatic-safe work station. Figure 1-2 shows an example of a
static-safe work station using two types of ESD protection:
Conductive table-mat and wrist-strap combination.
Conductive oor-mat and heel-strap combination.
Both types, when used together, provide a signicant level of
ESD protection. Of the two, only the table-mat and wrist-strap
combination provides adequate ESD protection when used alone.
To ensure user safety, the static-safe accessories must provide at least
1 M of isolation from ground. Refer to Table 1-2 for information on
ordering static-safe accessories.
WARNING
Do not use either of the two types of ESD protection described
above for a static-safe work station when working on circuitry
with avoltage potential greater than 500 volts
.
Figure 1-2. Example of a Static-Safe Work Station
Preparing for Use 1-5

Reducing Damage Caused by ESD
The following suggestions may help reduce ESD damage that occurs
during testing and servicing operations.
Before connecting any coaxial cable to an EMI receiver connector
for the rst time each day, momentarily ground the center and
outer conductors of the cable.
P
ersonnel should be grounded with a resistor-isolated wrist strap
before touching the center pin of any connector and before
removing any assembly from the unit.
Be sure that all instruments are properly earth-grounded to prevent
abuildup of static charge
.
T
able 1-2 lists static-safe accessories that can be obtained from
Hewlett-P
ackard by using the HP part numbers shown.
T
able 1-2. Static-Safe Accessories
HP Part
Number
Description
9300-0797 Set includes: 3M static control mat 0.6 m 2 1.2 m (2 ft 2 4 ft) and 4.6
cm (15 ft) ground wire
.(The wrist-strap and wrist-strap cord are not
included. They must be ordered separately
.)
9300-0980 Wrist-strap cord 1.5 m (5 ft)
9300-1383 Wrist-strap
,color black, stainless steel, without cord, has four
adjustable links and a7mm post-type connection.
9300-1169 ESD heel-strap (reusable 6to 12 months).
1-6 Preparing for Use

Installation Procedures
This section provides procedures on how to prepare the EMI receiver
and receiver RF section for use. Refer to the procedure below that
applies to your instrument.
Installing the EMI receiver
Installing the receiver RF section
WARNING
Do not lift the instrument by its handles when it is congured as
an EMI receiver
,that is
, when the receiver RF section is joined
together with the RF lter section. Otherwise, personal injury
may be incurred.
CAUTION
V
entilation Requirements:
When installing the instrument in a
cabinet, the convection into and out of the instrument must not be
restricted. The ambient temperature (outside the cabinet) must be
less than the maximum operating temperature of the instrument
by 4

C for every 100 watts dissipated in the cabinet. If the total
power dissipated in the cabinet is greater than 800 watts, then forced
convection must be used.
CA
UTION
The EMI receiver and receiver RF section are designed for use in
Installation Category II and Pollution Degree 2 per IEC 1010 and 664,
respectively
.
Preparing for Use 1-7
