HP Servers Troubleshooting Guide
January 2003 (Seventh Edition)
Part Number 161759-007

HP CONFIDENTIAL
Writer: Ted Weiman File Name: a-frnt.doc
Codename: Generic TSG Part Number: 161759-007 Last Saved On: 11/20/02 2:19 PM
Microsoft, Windows, and Windows NT are trademarks of Microsoft Corporation in the U.S.
and other countries.
Intel, Pentium, and Itanium are trademarks of Intel Corporation in the U.S. and other
countries.
UNIX is a trademark of The Open Group in the U.S. and other countries.
Hewlett-Packard Company shall not be liable for technical or editorial errors or omissions
contained herein. The information in this document is provided “as is” without warranty of
any kind and is subject to change without notice. The warranties for HP products are set forth
in the express limited warranty statements accompanying such products. Nothing herein
should be construed as constituting an additional warranty.
HP Servers Troubleshooting Guide
January 2003 (Seventh Edition)
Part Number 161759-007

HP Servers Troubleshooting Guide iii
HP CONFIDENTIAL
Writer: Ted Weiman File Name: a-frnt.doc
Codename: Generic TSG Part Number: 161759-007 Last Saved On: 11/20/02 2:19 PM
Contents
About This Guide
Who Should Use This Guide............................................................................................. xi
How to Use This Guide .................................................................................................... xii
Key Terms ........................................................................................................................ xii
Symbols in Text............................................................................................................... xiii
Reader’s Comments ........................................................................................................ xiii
HP Resources .................................................................................................................. xiii
Chapter 1
Diagnosing the Problem
Developing a Troubleshooting Plan ................................................................................ 1-2
Preparing to Troubleshoot the Server.............................................................................. 1-3
Preparing the Server for Diagnosis ........................................................................... 1-3
Using a Troubleshooting Methodology .................................................................... 1-3
Gathering Information..................................................................................................... 1-5
Preliminary Information............................................................................................ 1-5
When the Server Does Not Start............................................................................... 1-6
When the Self-Tests Fail......................................................................................... 1-12
When the Operating System Does Not Load .......................................................... 1-15
Locating Troubleshooting Information ......................................................................... 1-18
Contacting HP ............................................................................................................... 1-20
Contacting Technical Support or Authorized Reseller ........................................... 1-20
Server Information You Need................................................................................. 1-21
Operating System Information You Need .............................................................. 1-22

Contents
iv HP Servers Troubleshooting Guide
HP CONFIDENTIAL
Writer: Ted Weiman File Name: a-frnt.doc
Codename: Generic TSG Part Number: 161759-007 Last Saved On: 11/20/02 2:19 PM
Chapter 2
Hardware Problems
Important Safety Information ..........................................................................................2-2
Symbols on Equipment .............................................................................................2-2
Rack Stability ............................................................................................................2-4
Power Problems ...............................................................................................................2-5
Power Source.............................................................................................................2-5
Power Supply ............................................................................................................2-6
System Power Module...............................................................................................2-6
Uninterruptible Power Supply...................................................................................2-7
System Short Circuit .................................................................................................2-8
Redundant Line Cord Switch ....................................................................................2-9
General Hardware Problems ..........................................................................................2-10
Loose Connections ..................................................................................................2-10
Cabling Order..........................................................................................................2-10
New Hardware.........................................................................................................2-11
General Devices ......................................................................................................2-12
Rack Environment...................................................................................................2-13
Internal System Problems ..............................................................................................2-14
Processors................................................................................................................2-14
Processor Power Modules .......................................................................................2-16
PCI or PCI-X Hot Plug............................................................................................2-17
Memory ...................................................................................................................2-17
Fans .........................................................................................................................2-20
Drive Problems ..............................................................................................................2-22
Diskette Drives........................................................................................................2-22
CD-ROM and DVD Drives.....................................................................................2-23
Hard Drives .............................................................................................................2-24
Tape Drives .............................................................................................................2-31
External Device Problems..............................................................................................2-35
Video .......................................................................................................................2-35
Audio.......................................................................................................................2-37
Printers ....................................................................................................................2-37
Mouse and Keyboard...............................................................................................2-38
Diagnostic Adapter..................................................................................................2-39
Integrated Management Display .............................................................................2-40
Hot-Plug Management Module ...............................................................................2-40

Contents
HP Servers Troubleshooting Guide v
HP CONFIDENTIAL
Writer: Ted Weiman File Name: a-frnt.doc
Codename: Generic TSG Part Number: 161759-007 Last Saved On: 11/20/02 2:19 PM
Network and Modem Problems..................................................................................... 2-41
Network Controllers................................................................................................ 2-41
Modems .................................................................................................................. 2-43
Chapter 3
Software Problems
Operating Systems........................................................................................................... 3-2
Operating System Problems...................................................................................... 3-2
Operating System Updates........................................................................................ 3-5
Restoring to a Backed-Up Version ........................................................................... 3-5
When to Reconfigure or Reload Software ................................................................ 3-6
Application Software....................................................................................................... 3-8
Clustering Software......................................................................................................... 3-9
Remote ROM Flash Problems......................................................................................... 3-9
Maintaining Current Drivers ......................................................................................... 3-12
Erasing the System ........................................................................................................ 3-14
Chapter 4
Diagnostic Tools
Array Diagnostic Utility.................................................................................................. 4-2
Diagnostics ...................................................................................................................... 4-3
Enterprise Diagnostics LX32.................................................................................... 4-3
Diagnostics on a 32-bit System................................................................................. 4-5
Diagnostics on a 64-bit System................................................................................. 4-6
Server Management......................................................................................................... 4-8
Survey Utility ..................................................................................................................4-9
Running Survey Utility............................................................................................. 4-9
Diagnostic Adapter........................................................................................................ 4-10
Diagnostic Station ......................................................................................................... 4-10
Inspect Utility ................................................................................................................ 4-10
Running Inspect on a 32-bit System ....................................................................... 4-10
Running Inspect on a 64-bit System ....................................................................... 4-11
Integrated Administrator ............................................................................................... 4-12
Integrated Lights-Out .................................................................................................... 4-12
Integrated Management Log.......................................................................................... 4-12
List of Events .......................................................................................................... 4-13

Contents
vi HP Servers Troubleshooting Guide
HP CONFIDENTIAL
Writer: Ted Weiman File Name: a-frnt.doc
Codename: Generic TSG Part Number: 161759-007 Last Saved On: 11/20/02 2:19 PM
Power-On Self-Test .......................................................................................................4-18
BIOS Serial Console ...............................................................................................4-18
Server Blade Health Driver............................................................................................4-18
Chapter 5
Error Recovery
ROMPaq Disaster Recovery............................................................................................5-2
Redundant ROM Image Recovery ............................................................................5-4
Automatic Server Recovery-2..........................................................................................5-4
Unattended Recovery ................................................................................................5-5
Attended Recovery....................................................................................................5-6
Hardware Requirements ............................................................................................5-6
Health Driver ...................................................................................................................5-9
Initiating Diagnostics ..............................................................................................5-10
Initiating the Operating System...............................................................................5-14
ASR-2 Password Security..............................................................................................5-15
ASR-2 Integrated Management Log Messages .............................................................5-15
Automatic Revision Tracking........................................................................................5-18
Storage Fault Recovery Tracking ..................................................................................5-19
Storage Automatic Reconstruction ................................................................................5-19
Network Interface Fault Recovery Tracking .................................................................5-19
Memory Fault Recovery Tracking.................................................................................5-19
Chapter 6
Error Prevention
Preparing for Changes .....................................................................................................6-2
Minimizing the Impact of Changes by Using HP Tools..................................................6-3
Managing Updates Through Integration Servers ......................................................6-3
Installing Servers Consistently Through Replicated Install ......................................6-4
Maintaining Server Software.....................................................................................6-4
Other Ways to Minimize the Impact of Changes ......................................................6-4
Using a Methodology.......................................................................................................6-5
Visually Checking Your Server.......................................................................................6-7
Recognizing Power Problems Caused by Acts of Nature................................................6-8
Preventing Power Management Problems .......................................................................6-8
General Power Requirements....................................................................................6-9
Power Consumption Considerations .........................................................................6-9
Power Supply Considerations ...................................................................................6-9

Contents
HP Servers Troubleshooting Guide vii
HP CONFIDENTIAL
Writer: Ted Weiman File Name: a-frnt.doc
Codename: Generic TSG Part Number: 161759-007 Last Saved On: 11/20/02 2:19 PM
Power Cord Considerations ...................................................................................... 6-9
Power Redundancy Considerations ........................................................................ 6-10
Preventing Grounding Problems ................................................................................... 6-10
Preventing Temperature Problems ................................................................................ 6-10
Preventing Damage to Removable Drives .................................................................... 6-11
Preventing Electrostatic Damage .................................................................................. 6-12
Preventing Cable Damage ............................................................................................. 6-12
Preventing Tape Drive Errors........................................................................................ 6-13
Appendix A
HP Resources
Online Resources............................................................................................................ A-2
Software and Option Resources ..................................................................................... A-4
General Server Resources............................................................................................... A-9
ProLiant BL e-Class System Resources ....................................................................... A-12
Appendix B
Test Error Codes
100-199, Primary Processor Test Error Codes ................................................................B-2
200-299, Memory Test Error Codes................................................................................B-3
300-399, Keyboard Test Error Codes..............................................................................B-5
400-499, Parallel Printer Test Error Codes .....................................................................B-6
500-599, Graphics Controller Unit Test Error Codes......................................................B-7
600-699, Diskette Drive Test Error Codes ......................................................................B-8
1100-1199, Serial Test Error Codes ................................................................................B-9
1200-1299, Modem Communications Test Error Codes...............................................B-10
6000-6099, Network Interface Controllers Test Error Codes .......................................B-11
6100-6199, Array Controller Test Error Codes.............................................................B-12
6500-6599, SCSI Hard Drive Test Error Codes............................................................B-13
6600-6699, SCSI/IDE CD-ROM Drive Test Error Codes ............................................B-14
6700-6799, SCSI Tape Drive Test Error Codes............................................................B-15
8600-8699, Pointing Device Interface Test Error Codes ..............................................B-15
Appendix C
POST Error Messages
Non-Numeric POST Error Messages or Beeps Only ......................................................C-2
100 Series POST Error Messages....................................................................................C-7
200 Series POST Error Messages..................................................................................C-14

Contents
viii HP Servers Troubleshooting Guide
HP CONFIDENTIAL
Writer: Ted Weiman File Name: a-frnt.doc
Codename: Generic TSG Part Number: 161759-007 Last Saved On: 11/20/02 2:19 PM
300 Series POST Error Messages ................................................................................. C-25
400 Series POST Error Messages ................................................................................. C-27
500 Series POST Error Messages ................................................................................. C-27
600 Series POST Error Messages ................................................................................. C-28
800 Series POST Error Messages ................................................................................. C-30
900 Series POST Error Messages ................................................................................. C-36
1100 Series POST Error Messages ............................................................................... C-37
1600 Series POST Error Messages ............................................................................... C-38
1700 Series POST Error Messages ............................................................................... C-47
1800 Series POST Error Messages ............................................................................... C-70
Appendix D
ADU Error Messages
Index
List of Tables
1-1 Troubleshooting Methodology..................................................................................1-4
1-2 When the Server Does Not Start ...............................................................................1-6
1-3 When a ProLiant BL Server Does Not Start .............................................................1-9
1-4 When the Self-Tests Fail .........................................................................................1-12
1-5 When the Operating System Does Not Load ..........................................................1-15
1-6 Locating Troubleshooting Information ...................................................................1-18
2-1 Power Source Problems.............................................................................................2-5
2-2 Power Supply Problems ............................................................................................2-6
2-3 System Power Module Problems ..............................................................................2-7
2-4 UPS Problems ...........................................................................................................2-7
2-5 Processor Problems .................................................................................................2-14
2-6 Memory Problems ...................................................................................................2-18
2-7 General Fan Problems .............................................................................................2-20
2-8 Hot-Plug Fan Problems ...........................................................................................2-21
2-9 Diskette Drive Problems .........................................................................................2-22
2-10 CD-ROM and DVD Drive Problems ......................................................................2-23
2-11 Hard Drive Problems...............................................................................................2-24
2-12 Tape Drive Problems...............................................................................................2-31
2-13 DAT Drive Problems ..............................................................................................2-34
2-14 Video Problems .......................................................................................................2-35

Contents
HP Servers Troubleshooting Guide ix
HP CONFIDENTIAL
Writer: Ted Weiman File Name: a-frnt.doc
Codename: Generic TSG Part Number: 161759-007 Last Saved On: 11/20/02 2:19 PM
2-15 Audio Problems ...................................................................................................... 2-37
2-16 Printer Problems ..................................................................................................... 2-37
2-17 Mouse/Keyboard Problems..................................................................................... 2-38
2-18 Network Controller Problems ................................................................................. 2-41
2-19 Modem Problems.................................................................................................... 2-43
3-1 Operating System Problems...................................................................................... 3-2
3-2 Recovery Software.................................................................................................... 3-7
3-3 Application Software Problems ................................................................................ 3-8
3-4 Remote ROM Upgrade Errors ................................................................................ 3-10
3-5 Operating System Driver Delivery ......................................................................... 3-13
4-1 Event Messages....................................................................................................... 4-14
5-1 Automatic Server Recovery-2 (ASR-2) Features ..................................................... 5-8
5-2 System Configuration Utility Settings for Booting into Diagnostics...................... 5-11
5-3 System Configuration Utility Settings for Initiating the Operating System ........... 5-14
5-4 Automatic Server Recovery-2 (ASR-2) IML Messages ......................................... 5-16
5-5 Revision History Format......................................................................................... 5-18
A-1 Online Resources ..................................................................................................... A-2
A-2 Software and Option Resources............................................................................... A-4
A-3 General Server Resources ........................................................................................ A-9
A-4 ProLiant BL e-Class System Resources ................................................................ A-12
B-1 Test Error Codes .......................................................................................................B-1
B-2 Primary Processor Test Error Codes.........................................................................B-2
B-3 Memory Test Error Codes ........................................................................................B-3
B-4 Keyboard Test Error Codes ......................................................................................B-5
B-5 Parallel Printer Test Error Codes ..............................................................................B-6
B-6 Graphics Controller Unit Test Error Codes ..............................................................B-7
B-7 Diskette Drive Test Error Codes...............................................................................B-8
B-8 Serial Test Error Codes.............................................................................................B-9
B-9 Modem Communications Test Error Codes............................................................B-10
B-10 Network Interface Controllers Test Error Codes ....................................................B-11
B-11 Array Controller Test Error Codes .........................................................................B-12
B-12 SCSI Fixed Disk Drive Test Error Codes ...............................................................B-13
B-13 SCSI/IDE CD-ROM Drive Test Error Codes .........................................................B-14
B-14 SCSI Tape Drive Test Error Codes.........................................................................B-15
B-15 Pointing Device Interface Test Error Codes ...........................................................B-15
C-1 POST Error Messages...............................................................................................C-1
C-2 Non-Numeric Error Messages or Beeps Only ..........................................................C-2
C-3 100 Series POST Error Messages .............................................................................C-7
C-4 200 Series POST Error Messages ...........................................................................C-14

Contents
x HP Servers Troubleshooting Guide
HP CONFIDENTIAL
Writer: Ted Weiman File Name: a-frnt.doc
Codename: Generic TSG Part Number: 161759-007 Last Saved On: 11/20/02 2:19 PM
C-5 300 Series POST Error Messages .......................................................................... C-25
C-6 400 Series POST Error Messages .......................................................................... C-27
C-7 500 Series POST Error Messages .......................................................................... C-27
C-8 600 Series POST Error Messages .......................................................................... C-28
C-9 800 Series POST Error Messages .......................................................................... C-30
C-10 900 Series POST Error Messages .......................................................................... C-36
C-11 1100 Series POST Error Messages ........................................................................ C-37
C-12 1600 Series POST Error Messages ........................................................................ C-38
C-13 1700 Series POST Error Messages ........................................................................ C-47
C-14 1800 Series POST Error Messages ........................................................................ C-70
D-1 Array Diagnostic Utility (ADU) Error Messages..................................................... D-2

HP Servers Troubleshooting Guide xi
HP CONFIDENTIAL
Writer: Ted Weiman File Name: a-frnt.doc
Codename: Generic TSG Part Number: 161759-007 Last Saved On: 11/20/02 2:19 PM
About This Guide
This guide provides troubleshooting information for ProLiant and TaskSmart servers.
For convenience, this guide includes a complete list of Power-On Self-Test (POST)
error messages, Diagnostics test error codes, Integrated Management Log (IML)
event list error messages, and Array Diagnostic Utility (ADU) error messages.
IMPORTANT: The chapters in this guide provide information for multiple servers. Some of the
hardware or software information covered may not apply to your specific server. You may
need to modify some of the examples or procedures in this guide for your work environment.
Refer to your server-specific user documentation for information on procedures, hardware
options, software tools, and operating systems supported by, and specific to, your server.
WARNING: To reduce the risk of personal injury or damage to the equipment,
refer to the user documentation supplied with the server and observe the
appropriate safety precautions.
Who Should Use This Guide
This guide is for two types of users:
• The novice user interested in learning troubleshooting methods such as how to
record what happened before a problem, procedures for troubleshooting, tools to
use for problem resolution, and general information to help you avoid future
problems
• The advanced user already familiar with troubleshooting techniques who is
interested in specific information to troubleshoot server problems

About This Guide
xii HP Servers Troubleshooting Guide
HP CONFIDENTIAL
Writer: Ted Weiman File Name: a-frnt.doc
Codename: Generic TSG Part Number: 161759-007 Last Saved On: 11/20/02 2:19 PM
How to Use This Guide
To learn and use proper troubleshooting methods, follow the procedures described
throughout Chapter 1, which helps you isolate the problem and refers you to the part
of this guide containing the information necessary to solve the problem.
To immediately find help for the specific problem you are troubleshooting, refer to
“Locating Troubleshooting Information” in Chapter 1, which lists the location of
information in this guide.
Because this guide contains information covering multiple servers, refer to your
server-specific user documentation to find information about the system
specifications, switch settings, and status and LED indicators for your server.
Key Terms
• Boot—The process of initializing a server, beginning when the power switch is
pressed, including the running of self-tests, and concluding with the loading of
the operating system.
• Reboot—To restart a server by reloading the operating system.
• Power up—To apply power to the server by pressing the power switch. Powering
up a server is the first step of the boot process.
• Power down—To turn off a server by pressing the power switch or as required by
the operating system.
WARNING: Live circuits may still be present when the server is powered
down. To reduce the risk of injury or equipment damage, remove power
from the server by disconnecting all power cords from the power supplies.
• Server-specific user documentation—The set of documents that apply
specifically to a server, such as the setup and installation guide, maintenance and
service guide, and installation poster.
• Shut down—To completely remove all sources of power from a server.

About This Guide
HP Servers Troubleshooting Guide xiii
HP CONFIDENTIAL
Writer: Ted Weiman File Name: a-frnt.doc
Codename: Generic TSG Part Number: 161759-007 Last Saved On: 11/20/02 2:19 PM
• Server setup utility—a utility designed to set up and configure your server,
including ROM-Based Setup Utility (RBSU), System Configuration Utility
(SCU), and BIOS Setup Utility.
Symbols in Text
These symbols may be found in the text of this guide. They have the following
meanings.
WARNING: Text set off in this manner indicates that failure to follow directions
in the warning could result in bodily harm or loss of life.
CAUTION: Text set off in this manner indicates that failure to follow directions could
result in damage to equipment or loss of information.
IMPORTANT: Text set off in this manner presents essential information to explain a concept
or complete a task.
NOTE: Text set off in this manner presents additional information to emphasize or supplement
important points of the main text.
Reader’s Comments
HP welcomes your comments on this guide. Please send your comments and
suggestions by e-mail to [email protected].
HP Resources
For information on additional HP resources, refer to Appendix A, “HP Resources.”

HP Servers Troubleshooting Guide 1-1
HP CONFIDENTIAL
Writer: Ted Weiman File Name: b-ch1 Diagnosing the Problem.doc
Codename: Generic TSG Part Number: 161759-007 Last Saved On: 11/19/02 9:28 AM
1
Diagnosing the Problem
This chapter covers the steps that you are recommended to take when an error occurs.
Going through a structured set of tasks helps you to isolate the problem quickly.
IMPORTANT: This guide provides information for multiple servers. Some of the hardware or
software information may not apply to your specific server. You may need to modify some of
the examples or procedures in this guide for your work environment. Refer to your
server-specific user documentation for information on procedures, hardware options, software
tools, and operating systems supported by, and specific to, your server.
The following sections are outlined in this chapter:
• Developing a Troubleshooting Plan
• Preparing to Troubleshoot the Server
• Gathering Information
• Locating Troubleshooting Information
• Contacting HP
Even if you are experienced in troubleshooting, consider skimming through this
chapter before using the remainder of the book and the documentation that shipped
with your server. Otherwise refer to “Locating Troubleshooting Information” in this
chapter, which points you to the appropriate section of this guide.
WARNING: To avoid potential problems, ALWAYS read the warnings and
cautionary information in your server-specific user documentation before
removing, replacing, reseating, or modifying system components.

Diagnosing the Problem
1-2 HP Servers Troubleshooting Guide
HP CONFIDENTIAL
Writer: Ted Weiman File Name: b-ch1 Diagnosing the Problem.doc
Codename: Generic TSG Part Number: 161759-007 Last Saved On: 11/19/02 9:28 AM
Developing a Troubleshooting Plan
Evaluate all of the information and symptoms to:
• Identify the problem.
— Prepare the server for diagnosis and familiarize yourself with appropriate
troubleshooting methods using the following section, “Preparing to
Troubleshoot the Server.”
— Collect the facts related to the problem you want to troubleshoot using the
“Gathering Information” section later in this chapter.
— If the problem has not been identified after following the procedures in this
guide, refer to the “Contacting HP” section of this chapter.
• Plan your solution to each problem.
— Identify all steps necessary for implementation of each solution.
— Balance the time and cost required for implementing each solution against
the likelihood of resolving the problem.
— Gather the documentation that shipped with your server. Server-specific user
documentation is also located on the following website:
www.compaq.com/support/servers
Select your server, and then look in the Manuals section.
— Compile a master plan to be sure that you manipulate one variable at a time.
• Identify and collect all tools, such as a Torx screwdriver, electrostatic discharge
(ESD) wrist strap, and software utilities, necessary to troubleshoot the problem.
• Troubleshoot the problem using the information in this guide. Record each action
you take and list the results.
• Test your actions to be sure that the problem is truly resolved.
• Perform preventive steps to stop the problem from recurring. Refer to Chapter 6,
“Error Prevention,” for prevention information.
IMPORTANT: Familiarize yourself with the appropriate warnings for your server by referring
to your server-specific user documentation.

Diagnosing the Problem
HP Servers Troubleshooting Guide 1-3
HP CONFIDENTIAL
Writer: Ted Weiman File Name: b-ch1 Diagnosing the Problem.doc
Codename: Generic TSG Part Number: 161759-007 Last Saved On: 11/19/02 9:28 AM
Preparing to Troubleshoot the Server
Before troubleshooting, follow the steps to prepare the server for diagnosis. Also,
read the proper troubleshooting procedures to increase troubleshooting effectiveness.
Preparing the Server for Diagnosis
Before troubleshooting the server:
1. Record any error messages displayed by the system.
2. Remove all diskettes and CDs from the media drives.
3. Power down the server and peripheral devices. Always perform an orderly server
shutdown if possible. This means that you must:
a. Exit the applications.
b. Exit the operating system.
c. Power down the server.
4. Disconnect any peripheral devices not required for testing (any devices not
necessary to power up the server). Do not disconnect the printer if you want to
use it to log error messages.
At this point, you can attempt to boot the server using the steps provided in your
server-specific user documentation to determine if the server is starting as it should.
First, however, read through the proper troubleshooting procedures in the “Using a
Troubleshooting Methodology” section.
Using a Troubleshooting Methodology
As you follow the troubleshooting steps in this guide and your server-specific user
documentation, use the methods described in Table 1-1. When troubleshooting, some
results are obvious, such as error messages or significant changes in functionality.
Other changes may not be as obvious, requiring you to check system logs for new
events recorded after the change was made.
After familiarizing yourself with these troubleshooting methods, follow the steps
outlined in “Gathering Information” in this chapter to troubleshoot your server.

Diagnosing the Problem
1-4 HP Servers Troubleshooting Guide
HP CONFIDENTIAL
Writer: Ted Weiman File Name: b-ch1 Diagnosing the Problem.doc
Codename: Generic TSG Part Number: 161759-007 Last Saved On: 11/19/02 9:28 AM
Table 1-1: Troubleshooting Methodology
What to Check Troubleshooting Method
What are the results of each
troubleshooting step?
Look for and record new
symptoms, such as error
messages or informational
messages.
Were the results logical,
consistent, and expected?
Did anything change? If so, what? Check system logs. Look for any
type of change, no matter how
insignificant.
Was any functionality gained or
diminished?
Look for functionality changes to
judge the effectiveness of each
troubleshooting step.
Were any errors made in
implementing a step?
Look for and record any mistakes
made while executing a step.
Was more than one variable changed
at a time?
To be sure that the specific cause
of the problem is isolated, be sure
that during each step only one
variable is changed at a time.
Were any steps skipped or completed
out of order?
Place checkmarks against the
steps as they are executed, and
circle the steps not executed. Look
for skipped steps or steps
executed out of order.
Were any steps accidentally added?
Were any steps added intentionally to
complete or correct another step?
If steps had to be added in order
to proceed, record why, and note
the preceding step.

Diagnosing the Problem
HP Servers Troubleshooting Guide 1-5
HP CONFIDENTIAL
Writer: Ted Weiman File Name: b-ch1 Diagnosing the Problem.doc
Codename: Generic TSG Part Number: 161759-007 Last Saved On: 11/19/02 9:28 AM
Gathering Information
If you encounter a problem with your server, follow the guidelines in this section and
record your findings in a notebook. Having these details available reduces
troubleshooting time. This information also helps the authorized service provider to
diagnose and solve your problem, if their assistance is used.
Preliminary Information
Before troubleshooting your specific server problem, collect the following
information:
• What events preceded the failure? After which steps does the problem occur?
• What has been changed between the time the server was working and now?
• Did you recently add or remove hardware or software? If so, did you remember
to change the appropriate settings in the server setup utility, if necessary?
• Was the server recently installed or moved?
• Has the server exhibited problem symptoms for a period of time?
• If the problem occurs randomly, what is the duration or frequency?
To answer these questions, the following information may be useful:
• Run the Survey Utility and compare what has changed (for servers running the
Microsoft Windows NT, Linux, or Novell NetWare operating system).
• Refer to your software and hardware records for information.
After collecting this information, refer to the appropriate section in this chapter:
• When the Server Does Not Start
• When the Self-Tests Fail
• When the Operating System Does Not Load

Diagnosing the Problem
1-6 HP Servers Troubleshooting Guide
HP CONFIDENTIAL
Writer: Ted Weiman File Name: b-ch1 Diagnosing the Problem.doc
Codename: Generic TSG Part Number: 161759-007 Last Saved On: 11/19/02 9:28 AM
When the Server Does Not Start
The following visual and audio clues indicate that the server is not starting:
• The LEDs are off.
• The fans are not spinning.
• Something seems, looks, or sounds wrong or different.
• There is physical damage to the system.
• Something is cool that should be warm.
• There are frayed cables.
• The system does not follow the normal power-up sequence, as described in your
server-specific user documentation.
When a ProLiant ML, ProLiant DL, TaskSmart, or Previously Released Server
Does Not Start
Use the information in Table 1-2 to troubleshoot problems with a ProLiant ML,
ProLiant DL, TaskSmart, or previously released server.
Table 1-2: When the Server Does Not Start
What to Check What to Do
Check for connection problems:
• Is the server power cord plugged
into a working grounded
(earthed) AC outlet?
• Has the Power On/Standby
switch been firmly pressed?
• Are there unconnected or loose
plugs or cables?
• Are any connections loose or
improperly seated?
Refer to “Loose Connections” in
Chapter 2.
continued

Diagnosing the Problem
HP Servers Troubleshooting Guide 1-7
HP CONFIDENTIAL
Writer: Ted Weiman File Name: b-ch1 Diagnosing the Problem.doc
Codename: Generic TSG Part Number: 161759-007 Last Saved On: 11/19/02 9:28 AM
Table 1-2: When the Server Does Not Start continued
What to Check What to Do
Check for incorrect system settings:
• Are switches set correctly?
Refer to your server-specific user
documentation to verify switch
settings.
Check for faulty power delivery:
• Is the power cord working?
• Is the power strip working?
• Is the power outlet working, and
at the correct voltage level?
Refer to “Power Source” in
Chapter 2.
Check for power supply problems:
• Is each power supply fan
spinning?
• Are the power supplies’ LEDs
indicating that each power supply
is working?
• Have you recently added
hardware which might be
overburdening the power
supplies?
• Is the uninterruptible power
supply (UPS) starting and
working correctly?
Refer to:
• “Power Supply” in Chapter 2
• “Uninterruptible Power
Supply” in Chapter 2
• Your server-specific user
documentation for more
information on LEDs
Check for a system short circuit:
• Is the power status LED blinking
intermittently, turning amber, or
staying off?
Refer to:
• “System Short Circuit” in
Chapter 2
• Your server-specific user
documentation for more
information on LEDs
continued
