HP Integrity BL860c User manual

HP Insight Management WBEM Providers for
Windows on Integrity Servers
Data Sheet
Part number 5992-5647
Third Edition September 2009

Legal notices
© Copyright 2009 Hewlett-Packard Development Company, L.P.
The information contained herein is subject to change without notice. The only warranties for HP products and services are
set forth in the express warranty statements accompanying such products and services. Nothing herein should be construed
as constituting an additional warranty. HP will not be liable for technical or editorial errors or omissions contained herein.
Confidential computer software. Valid license from HP required for possession, use or copying. Consistent with FAR 12.211
and 12.212, Commercial Computer Software, Computer Software Documentation, and Technical Data for Commercial
items are licensed to the U.S. Government under vendor’s standard commercial license.
Microsoft, Windows, and Windows Server are U.S. registered trademarks of Microsoft Corporation.

Contents 3
Contents
1Overview................................................................................................................................... 16
2Base server ................................................................................................................................ 17
2.1Overview......................................................................................................................................... 17
2.2Use cases ........................................................................................................................................ 17
2.3Class implementations ....................................................................................................................... 17
2.3.1 HP_WinComputerSystem .................................................................................................... 17
2.3.2 HP_ComputerSystemChassis ................................................................................................ 20
2.3.3 HP_ComputerSystemPackage............................................................................................... 21
2.3.4 HP_PowerManagementService............................................................................................. 22
2.3.5 HP_PowerManagementCapabilities...................................................................................... 23
2.3.6 HP_AssociatedPowerManagementService ............................................................................. 24
2.3.7 HP_PowerManagementElementCapabilities ........................................................................... 24
2.3.8 HP_HostedPowerManagementService................................................................................... 25
2.3.9 HP_SystemROMFirmware.................................................................................................... 25
2.3.10 HP_SystemROMElementFirmwareIdentity ............................................................................... 28
2.3.11 HP_SystemROMInstalledFirmwareIdentity .............................................................................. 28
2.4Supported indications........................................................................................................................ 28
2.4.1 WBEM Providers Started..................................................................................................... 29
3CPU ..........................................................................................................................................31
3.1Overview......................................................................................................................................... 31
3.2Use cases ........................................................................................................................................ 31
3.3Class implementations ....................................................................................................................... 31
3.3.1 HP_Processor..................................................................................................................... 31
3.3.2 HP_ProcessorCapabilities.................................................................................................... 33
3.3.3 HP_ProcessorCore.............................................................................................................. 34
3.3.4 HP_HardwareThread.......................................................................................................... 36
3.3.5 HP_ProcessorCacheMemory ................................................................................................ 38
3.3.6 HP_SystemProcessor ........................................................................................................... 40
3.3.7 HP_ProcessorElementCapabilities ......................................................................................... 41
3.3.8 HP_ProcessorCoreComponent.............................................................................................. 41
3.3.9 HP_HWThreadComponent .................................................................................................. 42
3.3.10 HP_AssociatedCacheMemory .............................................................................................. 42
3.3.11 HP_ProcessorCollection....................................................................................................... 43
3.3.12 HP_ProcessorGroupHostedCollection .................................................................................... 44
3.3.13 HP_PhysicalMemberOfProcessorCollection ............................................................................ 44
3.3.14 HP_ProcessorChip .............................................................................................................. 45
3.3.15 HP_RealizesProcessor ......................................................................................................... 47
3.3.16 HP_SystemPhysicalProcessor................................................................................................ 47
3.3.17 HP_ProcessorLocation ......................................................................................................... 47
3.3.18 HP_ProcessorElementLocation .............................................................................................. 49
3.4Supported indications........................................................................................................................ 49
4System Power Supply ..................................................................................................................50
4.1Overview......................................................................................................................................... 50
4.2Use cases ........................................................................................................................................ 50
4.3Class implementations ....................................................................................................................... 50
4.3.1 HP_PowerSupply................................................................................................................ 50

Contents 4
4.3.2 HP_PowerCollection ........................................................................................................... 52
4.3.3 HP_PowerRedundancySet.................................................................................................... 53
4.3.4 HP_MemberOfPowerRedundancy......................................................................................... 54
4.3.5 HP_HostedPowerRedundancySet .......................................................................................... 55
4.3.6 HP_MemberOfPowerCollection............................................................................................ 55
4.3.7 HP_HostedPowerCollection.................................................................................................. 55
4.3.8 HP_SystemPowerSupply ...................................................................................................... 56
4.3.9 HP_PowerSupplyModule ..................................................................................................... 56
4.3.10 HP_PowerSupplySlot........................................................................................................... 57
4.3.11 HP_PowerSupplyInSlot ........................................................................................................ 58
4.3.12 HP_RealizesPowerSupply .................................................................................................... 58
4.3.13 HP_SystemPhysicalPowerSupply........................................................................................... 59
4.3.14 HP_PowerMeter ................................................................................................................. 59
4.3.15 HP_AssociatedPowermeter .................................................................................................. 60
4.3.16 HP_Location ...................................................................................................................... 61
4.3.17 HP_ElementLocation............................................................................................................ 61
4.3.18 CIM_ConfigurationCapacity ................................................................................................ 61
4.3.19 CIM_ElementCapacity ........................................................................................................ 62
4.4Supported indications........................................................................................................................ 62
5System fan................................................................................................................................. 63
5.1Overview......................................................................................................................................... 63
5.2Table use cases ................................................................................................................................ 63
5.3Class implementations ....................................................................................................................... 63
5.3.1 HP_Fan............................................................................................................................. 63
5.3.2 HP_CoolingCollection......................................................................................................... 65
5.3.3 HP_CoolingRedundancySet ................................................................................................. 66
5.3.4 HP_MemberOfCoolingRedundancy ...................................................................................... 67
5.3.5 HP_HostedCoolingRedundancySet........................................................................................ 68
5.3.6 HP_MemberOfCoolingCollection ......................................................................................... 68
5.3.7 HP_HostedCoolingCollection ............................................................................................... 68
5.3.8 HP_SystemFan ................................................................................................................... 68
5.3.9 HP_FanModule .................................................................................................................. 69
5.3.10 HP_FanSlot........................................................................................................................ 70
5.3.11 HP_FanInSlot ..................................................................................................................... 71
5.3.12 HP_RealizesFan ................................................................................................................. 71
5.3.13 HP_SystemPhysicalFan........................................................................................................ 71
5.3.14 HP_Location ...................................................................................................................... 72
5.3.15 HP_ElementLocation............................................................................................................ 72
5.3.16 CIM_ConfigurationCapacity ................................................................................................ 73
5.3.17 CIM_ElementCapacity ........................................................................................................ 73
5.4Supported indications........................................................................................................................ 74
6System Temperature Sensor ......................................................................................................... 75
6.1Overview......................................................................................................................................... 75
6.2Use cases ........................................................................................................................................ 75
6.3Class implementations ....................................................................................................................... 75
6.3.1 HP_NumericSensor............................................................................................................. 75
6.3.2 HP_SensorCollection........................................................................................................... 78
6.3.3 HP_MemberOfSensorCollection ........................................................................................... 79
6.3.4 HP_HostedSensorCollection................................................................................................. 79
6.3.5 HP_SystemSensor............................................................................................................... 79
6.4Supported indications........................................................................................................................ 79
7System memory ..........................................................................................................................80

Contents 5
7.1Overview......................................................................................................................................... 80
7.2Use cases ........................................................................................................................................ 80
7.3Class implementations ....................................................................................................................... 80
7.3.1 HP_Memory ...................................................................................................................... 80
7.3.2 HP_SystemMemory............................................................................................................. 82
7.3.3 HP_MemoryModule............................................................................................................ 83
7.3.4 HP_MemoryBoard.............................................................................................................. 85
7.3.5 HP_MemoryCollection ........................................................................................................ 87
7.3.6 HP_HostedMemoryCollection............................................................................................... 89
7.3.7 HP_MemberOfMemoryCollection ......................................................................................... 89
7.3.8 HP_RealizesMemoryModule ................................................................................................ 89
7.3.9 HP_ MemoryModuleSlot...................................................................................................... 90
7.3.10 HP_MemoryBoardSlot......................................................................................................... 91
7.3.11 HP_MemoryModuleInSlot .................................................................................................... 93
7.3.12 HP_MemoryBoardInSlot ...................................................................................................... 93
7.3.13 HP_ MemoryModuleSlotOnBoard......................................................................................... 93
7.3.14 HP_MemoryModuleSlotLocation ........................................................................................... 94
7.3.15 HP_MemoryBoardSlotLocation ............................................................................................. 96
7.3.16 HP_MemoryModuleSlotElementLocation ................................................................................ 97
7.3.17 HP_MemoryBoardSlotElementLocation .................................................................................. 97
7.3.18 HP_SystemMemoryModuleSlot............................................................................................. 98
7.3.19 HP_SystemMemoryBoardSlot ............................................................................................... 98
7.4Supported indications........................................................................................................................ 98
8PCI Device.................................................................................................................................99
8.1Overview......................................................................................................................................... 99
8.2Use cases ........................................................................................................................................ 99
8.3Class implementations ....................................................................................................................... 99
8.3.1 HP_PCIDevice....................................................................................................................99
8.3.2 HP_PCIBridge .................................................................................................................. 101
8.3.3 HP_PCICard .................................................................................................................... 103
8.3.4 HP_PCISlot ......................................................................................................................105
8.3.5 HP_PCICardInSlot ............................................................................................................ 107
8.3.6 HP_RealizesPCIDevice ...................................................................................................... 108
8.3.7 HP_SystemPCISlot ............................................................................................................ 108
8.3.8 HP_SystemPCIDevice ........................................................................................................ 108
8.3.9 HP_Location .................................................................................................................... 108
8.3.10 HP_ElementLocation.......................................................................................................... 109
8.4Supported indications...................................................................................................................... 110
9Management Processor Lite........................................................................................................ 111
9.1Overview....................................................................................................................................... 111
9.2Use cases ...................................................................................................................................... 111
9.3Class implementations ..................................................................................................................... 111
9.3.1 HP_ManagementProcessor ................................................................................................ 111
9.3.2 CIM_SoftwareIdentity ....................................................................................................... 115
9.3.3 HP_MPCollection ............................................................................................................. 117
9.3.4 HP_MPHostedCollection.................................................................................................... 117
9.3.5 HP_MPComponentCS ....................................................................................................... 118
9.3.6 HP_MPMemberOfCollection .............................................................................................. 118
9.3.7 CIM_ElementSoftwareIdentity............................................................................................. 119
9.3.8 CIM_InstalledSoftwareIdentity ............................................................................................ 119
9.4Supported indications...................................................................................................................... 120
10 SEL Record Log.........................................................................................................................121

Contents 6
10.1 Overview........................................................................................................................121
10.2 Use cases........................................................................................................................ 121
10.3 Class implementations ...................................................................................................... 121
10.3.1 HP_CommonRecordLog..................................................................................................... 121
10.3.2 HP_CommonLogEntry ....................................................................................................... 123
10.3.3 HP_LogManagesRecord .................................................................................................... 126
10.3.4 HP_UseOfLog .................................................................................................................. 126
10.4 Supported indications....................................................................................................... 127
11 Platform Watchdog................................................................................................................... 128
11.1 Overview........................................................................................................................128
11.2 Use Cases.......................................................................................................................128
11.3 Class Implementations ...................................................................................................... 128
11.3.1 HP_WinPlatformWatchdogService ..................................................................................... 128
11.3.2 CIM_HostedService .......................................................................................................... 130
11.3.3 CIM_ServiceAffectsElement................................................................................................ 130
11.3.4 CIM_ServiceAvailableToElement ........................................................................................ 131
11.4 Supported Indications ....................................................................................................... 131
12 Blade System Lite......................................................................................................................132
12.1 Overview........................................................................................................................132
12.2 Use cases........................................................................................................................ 132
12.3 Class implementations ...................................................................................................... 132
12.3.1 HP_BladeEnclosureCS....................................................................................................... 132
12.3.2 HP_BladeEnclosureCollection............................................................................................. 134
12.3.3 HP_BladeSystemComponent .............................................................................................. 135
12.3.4 HP_MemberOfBladeEnclosureCollection ............................................................................. 135
12.3.5 HP_BladeEnclosureGroupHostedCollection.......................................................................... 136
12.3.6 CIM_SoftwareIdentity ....................................................................................................... 136
12.3.7 CIM_ElementSoftwareIdentity............................................................................................. 137
12.3.8 CIM_InstalledSoftwareIdentity ............................................................................................ 138
12.3.9 HP_Location .................................................................................................................... 138
12.3.10 HP_ElementLocation................................................................................................ 139
12.4 Supported indications....................................................................................................... 139
13 Ethernet Teaming...................................................................................................................... 140
13.1 Overview........................................................................................................................140
13.2 Use cases........................................................................................................................ 141
13.3 Class implementations ...................................................................................................... 141
13.3.1 HP_EthernetPort ............................................................................................................... 141
13.3.2 HP_EthernetDevice ........................................................................................................... 143
13.3.3 HP_EthernetTeam ............................................................................................................. 143
13.3.4 HP_EthernetTeamMember.................................................................................................. 145
13.3.5 HP_HostedEthernetTeam ................................................................................................... 145
13.3.6 HP_EthernetLANEndpoint .................................................................................................. 146
13.3.7 HP_EthernetPortToLANEndpoint.......................................................................................... 147
13.3.8 HP_EthernetTeamToLANEndpoint ....................................................................................... 147
13.3.9 HP_EthernetLANHostedAccessPoint .................................................................................... 147
13.3.10 HP_IPBindsToEthernetLANEndpoint ........................................................................... 148
13.3.11 HP_EthernetStatistics ............................................................................................... 148
13.3.12 HP_EthernetPortStatisticalData.................................................................................. 149
13.3.13 HP_EthernetLANEndpointStatisticalData..................................................................... 149
13.3.14 HP_EthernetCollection ............................................................................................. 150
13.3.15 HP_EthernetMemberOfCollection.............................................................................. 150
13.3.16 HP_EthernetGroupHostedCollection .......................................................................... 151

Contents 7
13.3.17 CIM_IPProtocolEndpoint .......................................................................................... 151
13.3.18 HP_EthIPHostedAccessPoint ..................................................................................... 152
13.3.19 CIM_SoftwareIdentity.............................................................................................. 152
13.3.20 CIM_ElementSoftwareIdentity................................................................................... 153
13.3.21 HP_Location .......................................................................................................... 154
13.3.22 HP_ElementLocation................................................................................................ 154
13.3.23 HP_EthEventSettings................................................................................................ 155
13.4 Supported indications....................................................................................................... 156
13.4.1 Ethernet Team Redundancy Lost ......................................................................................... 156
13.4.2 Ethernet Team Redundancy Increased ................................................................................. 158
13.4.3 Ethernet Team Redundancy Decreased................................................................................ 160
13.4.4 Ethernet Team Full Redundancy Restored............................................................................. 162
13.4.5 Network Interface Connectivity Lost .................................................................................... 163
13.4.6 Network Interface Connectivity Restored ............................................................................. 165
13.4.7 Ethernet Team Member Status Change................................................................................ 167
13.4.8 Ethernet Team Member Role Change .................................................................................. 170
13.4.9 Ethernet Team Member Dropped........................................................................................ 172
13.4.10 Ethernet Team Member Added................................................................................. 174
13.4.11 Network Interface No Longer Available .................................................................... 175
13.4.12 New Network Interface Available ............................................................................ 177
13.4.13 Ethernet Team Active Member Count Change ............................................................ 179
13.4.14 Ethernet Provider Fatal Error .................................................................................... 181
13.4.15 Ethernet Provider Cannot Access Data Source ............................................................ 183
14 Operating System Status............................................................................................................ 186
14.1 Overview........................................................................................................................186
14.2 Use Cases.......................................................................................................................186
14.3 Class Implementations ...................................................................................................... 186
14.3.1 HP_OperatingSystem........................................................................................................ 186
14.3.2 CIM_RunningOS .............................................................................................................. 188
14.3.3 CIM_InstalledOS.............................................................................................................. 188
14.4 Supported Indications ....................................................................................................... 188
15 Smart Array .............................................................................................................................189
15.1 Overview........................................................................................................................189
15.2 Use cases........................................................................................................................ 189
15.3 Class implementations ...................................................................................................... 189
15.3.1 HPSA_ArraySystem .......................................................................................................... 189
15.3.2 HPSA_ArrayController ...................................................................................................... 191
15.3.3 HPSA_StorageVolume....................................................................................................... 192
15.3.4 HPSA_DiskDrive............................................................................................................... 194
15.3.5 HPSA_StorageExtent......................................................................................................... 195
15.3.6 HPSA_DiskDriveFirmware.................................................................................................. 197
15.3.7 HPSA_PhysicalPackage..................................................................................................... 197
15.3.8 HPSA_ArrayControllerPhysicalPackage ............................................................................... 198
15.3.9 HPSA_DiskPhysicalPackage............................................................................................... 199
15.3.10 HPSA_StorageEnclosure.......................................................................................... 200
15.3.11 HPSA_StorageEnclosureProcessor............................................................................. 201
15.3.12 HPSA_PortController ............................................................................................... 202
15.3.13 HPSA_DAPort ........................................................................................................ 203
15.3.14 HPSA_SPIPort ........................................................................................................ 204
15.3.15 HPSA_Firmware ..................................................................................................... 205
15.3.16 HPSA_EnclosureFirmware........................................................................................ 205
15.3.17 HPSA_PrimordialPool.............................................................................................. 206
15.3.18 HPSA_StoragePool ................................................................................................. 207

Contents 8
15.3.19 HPSA_MediaAccessStatData ................................................................................... 207
15.3.20 HPSA_StorageSetting.............................................................................................. 208
15.3.21 HPSA_DriveCage ................................................................................................... 209
15.3.22 HPSA_SCSIProtocolEndpoint.................................................................................... 210
15.3.23 HPSA_SCSIProtocolController .................................................................................. 211
15.3.24 HPSA_RedundancySet............................................................................................. 212
15.3.25 HPSA_StorageRedundancySet.................................................................................. 213
15.3.26 HPSA_StorageSpecificCollection .............................................................................. 213
15.3.27 HPSA_DriveCageLocation ....................................................................................... 214
15.3.28 HPSA_ArraySystemLocation..................................................................................... 215
15.3.29 HPSA_DiskDriveLocation ......................................................................................... 216
15.3.30 HPSA_ArrayControllerLocation................................................................................. 216
15.3.31 HPSA_StorageCapabilities ...................................................................................... 218
15.3.32 HPSA_Product........................................................................................................ 219
15.3.33 HPSA_StorageEnclosure Location ............................................................................. 219
15.3.34 HPSA_TSASSCSIProtocolEndpoint ............................................................................ 220
15.3.35 HPSA_ISASSCSIProtocolEndpoint ............................................................................. 221
15.3.36 HPSA_TSASPort ..................................................................................................... 222
15.3.37 HPSA_ISASPort ...................................................................................................... 223
15.3.38 HPSA_ArraySystemRedundancySet (Association) ........................................................ 224
15.3.39 HPSA_StorageVolumeStorageSetting (Association) ..................................................... 224
15.3.40 HPSA_PrimordialPoolStorageCapabilities (Association) ............................................... 224
15.3.41 HPSA_StoragePoolStorageCapabilities (Association)................................................... 225
15.3.42 HPSA_ArraySystemStorageEnclosureProcessor (Association) ........................................ 225
15.3.43 HPSA_ArraySystemSCSIProtocolController (Association) .............................................. 225
15.3.44 HPSA_ArraySystemPortController (Association)........................................................... 225
15.3.45 HPSA_ArraySystemDiskDrive (Association) ................................................................ 226
15.3.46 HPSA_ArraySystemStorageVolume (Association) ........................................................ 226
15.3.47 HPSA_ArraySystemStorageExtent (Association) .......................................................... 226
15.3.48 HPSA_ArraySystemSPIPort (Association) .................................................................... 226
15.3.49 HPSA_ArraySystemDAPort (Association).................................................................... 226
15.3.50 HPSA_ArraySystemPrimordialPool (Association) ......................................................... 227
15.3.51 HPSA_ArraySystemStoragePool (Association)............................................................. 227
15.3.52 HPSA_ComputerSystemArraySystem (Association) ...................................................... 227
15.3.53 HPSA_ArraySystemArrayController (Association)........................................................ 227
15.3.54 HPSA_StorageEnclosureStorageEnclosureProcessor (Association).................................. 228
15.3.55 HPSA_ProductPhysicalPackage (Association).............................................................. 228
15.3.56 HPSA_StorageEnclosureDriveCage (Association) ........................................................ 228
15.3.57 HPSA_PhysicalPackageArrayControllerPhysicalPackage (Association) ........................... 228
15.3.58 HPSA_PhysicalPackageDiskPhysicalPackage (Association) ........................................... 228
15.3.59 HPSA_PhysicalPackageStorageEnclosure (Association)................................................ 229
15.3.60 HPSA_DriveCageDiskPhysicalPackage (Association) ................................................... 229
15.3.61 HPSA_StoragePoolStorageExtent (Association) ........................................................... 229
15.3.62 HPSA_PrimordialPoolStorageExtent (Association)........................................................ 229
15.3.63 HPSA_StorageSpecificCollectionArraySystem (Association).......................................... 230
15.3.64 HPSA_ArrayControllerRedundancySet (Association).................................................... 230
15.3.65 HPSA_StorageRedundancySetStorageExtent (Association)............................................ 230
15.3.66 HPSA_ArraySystemFirmware (Association)................................................................. 230
15.3.67 HPSA_SCSIProtocolControllerStorageVolume (Association) .......................................... 230
15.3.68 HPSA_FirmwareArraySystem (Association)................................................................. 231
15.3.69 HPSA_StorageEnclosureProcessorEnclosureFirmware (Association)................................ 231
15.3.70 HPSA_DiskDriveDiskDriveFirmware (Association)........................................................ 231
15.3.71 HPSA_DiskDriveStorageExtent (Association)............................................................... 232
15.3.72 HPSA_DiskPhysicalPackageDiskDrive (Association) ..................................................... 232

Contents 9
15.3.73 HPSA_StoragePoolStorageVolume (Association) ......................................................... 232
15.3.74 HPSA_PrimordialPoolStoragePool (Association) .......................................................... 232
15.3.75 HPSA_SpareExtentStorageExtent (Association) ........................................................... 232
15.3.76 HPSA_SpareExtentStorageRedundancySet (Association) .............................................. 233
15.3.77 HPSA_StorageExtentStorageVolume (Association)....................................................... 233
15.3.78 HPSA_DAPortSCSIProtocolEndpoint (Association) ....................................................... 233
15.3.79 HPSA_SPIPortSCSIProtocolEndpoint (Association) ....................................................... 233
15.3.80 HPSA_StorageGroupHostedCollection (Association) ................................................... 234
15.3.81 HPSA_PhysicalPackageArraySystem (Association) ...................................................... 234
15.3.82 HPSA_ArrayControllerPhysicalPackageArrayController (Association)............................. 234
15.3.83 HPSA_DiskDriveMediaAccessStatData (Association) ................................................... 234
15.3.84 HPSA_ArrayControllerPhysicalPackageArrayControllerLocation (Association) ................. 234
15.3.85 HPSA_PhysicalPackageArraySystemLocation (Association)........................................... 235
15.3.86 HPSA_DriveCageDriveCageLocation (Association) ..................................................... 235
15.3.87 HPSA_DiskPhysicalPackageDiskDriveLocation (Association) ......................................... 235
15.3.88 HPSA_SCSIProtocolEndpointSCSIProtocolController (Association) ................................. 235
15.3.89 HPSA_StorageEnclosureEnclosureLocation (Association) .............................................. 236
15.3.90 HPSA_ISASPortISASSCSIProtocolEndPoint (Association)............................................... 236
15.3.91 HPSA_ArraySystemISASSCSIProtocolEndPoint (Association) ......................................... 236
15.3.92 HPSA_ArraySystemISASPort (Association).................................................................. 236
15.3.93 HPSA_PortControllerISASPort (Association) ................................................................ 237
15.3.94 HPSA_ArraySystemTSASSCSIProtocolEndpoint (Association) ........................................ 237
15.3.95 HPSA_TSASPortISASSCSIProtocolEndpoint (Association).............................................. 237
15.3.96 HPSA_ ArraySystemTSASPort (Association)................................................................ 237
15.3.97 HPSA_ DiskDriveTSASSCSIProtocolEndpoint (Association) ........................................... 238
15.3.98 HPSA_SCSIInitiatorTargetLogicalUnitPath................................................................... 238
15.4 Supported indications....................................................................................................... 238
15.4.1 Physical Drive Status Changed to OK ................................................................................. 238
15.4.2 Physical Drive Status Changed to ERROR ............................................................................ 241
15.4.3 Physical Drive Status Changed to REBUILDING .................................................................... 243
15.4.4 Physical Drive Status Changed to PREDICTIVE FAILURE ......................................................... 245
15.4.5 Logical Drive Status Changed to OK................................................................................... 247
15.4.6 Logical drive Status Changed to ERROR .............................................................................. 249
15.4.7 Logical Drive Status Changed to DEGRADED....................................................................... 251
15.4.8 Controller Status Changed to OK ....................................................................................... 254
15.4.9 Controller Status Changed to ERROR .................................................................................. 256
15.4.10 Controller Redundancy State Has Been Set to ACTIVE ................................................. 258
15.4.11 Controller Redundancy Has Been Lost ....................................................................... 260
15.4.12 Controller Redundancy Has Been Restored ................................................................ 263
15.4.13 Controller Battery Status Changed to OK................................................................... 265
15.4.14 Controller Battery Status Changed to Not Fully Charged.............................................. 267
15.4.15 Controller Battery Status Changed to Failed ............................................................... 269
15.4.16 Controller Cache Status Changed to OK ................................................................... 271
15.4.17 Controller Cache Status – Temporarily Disabled ......................................................... 274
15.4.18 Controller Cache Status – Permanently Disabled......................................................... 276
15.4.19 Enclosure Power Supply Status Changed to Non Redundant ........................................ 278
15.4.20 Enclosure Power Supply Status Changed to OK (Redundant) ........................................ 280
15.4.21 Enclosure Power Supply Status Changed to Redundant Degraded ................................ 282
15.4.22 Enclosure Temperature Sensor Status Changed to OK ................................................. 284
15.4.23 Enclosure Temperature Sensor Status Changed to Warning ......................................... 286
15.4.24 Enclosure Temperature Sensor Status Changed to Critical ............................................ 288
15.4.25 Enclosure Fan Status Changed to OK........................................................................ 291
15.4.26 Enclosure Fan Status Changed to Degraded .............................................................. 293
15.4.27 Enclosure Fan Status Changed to Failure ................................................................... 295

Contents 10
16 FC HBA...................................................................................................................................297
16.1 Overview........................................................................................................................297
16.2 Use cases........................................................................................................................ 297
16.2.1 Getting statistics for each Fibre Channel port ....................................................................... 299
16.2.2 Discovering HBA topology and attributes ............................................................................ 299
16.3 Class implementations ...................................................................................................... 301
16.3.1 HPFCHBA_ComputerSystem .............................................................................................. 301
16.3.2 HPFCHBA_FCPort ............................................................................................................ 302
16.3.3 HPFCHBA_PortController................................................................................................... 304
16.3.4 HPFCHBA_FCPortStatistics................................................................................................. 305
16.3.5 HPFCHBA_LogicalPortGroup ............................................................................................. 306
16.3.6 HPFCHBA_PhysicalPackage .............................................................................................. 307
16.3.7 HPFCHBA_Product ........................................................................................................... 307
16.3.8 HPFCHBA_SoftwareIdentityDrv .......................................................................................... 308
16.3.9 HPFCHBA_FirmwareIdentityFW ......................................................................................... 308
16.3.10 HPFCHBA_FirmwareIdentityBIOS.............................................................................. 309
16.3.11 HPFCHBA_SCSIProtocolController ............................................................................ 310
16.3.12 HPFCHBA_SCSIProtocolEndpoint.............................................................................. 311
16.3.13 HPFCHBA_GroupSystemSpecificCollection ................................................................ 312
16.3.14 HPFCHBA_ComputerSystemFCPort ........................................................................... 312
16.3.15 HPFCHBA_ComputerSystemPortController ................................................................. 313
16.3.16 HPFCHBA_ComputerSystemSCSIProtocolController..................................................... 313
16.3.17 HPFCHBA_ComputerSystemLogicalPortGroup ............................................................ 313
16.3.18 HPFCHBA_ComputerSystemSoftwareIdentityDrv ......................................................... 314
16.3.19 HPFCHBA_SystemServiceAccessPoint........................................................................ 314
16.3.20 HPFCHBA_FCPortFCPortStatistics.............................................................................. 315
16.3.21 HPFCHBA_FCPortLogicalPortGroup .......................................................................... 315
16.3.22 HPFCHBA_FCPortSCSIProtocolEndpoint .................................................................... 315
16.3.23 HPFCHBA_SCSIProtocolControllerFCPort ................................................................... 316
16.3.24 HPFCHBA_PortControllerFCPort................................................................................ 316
16.3.25 HPFCHBA_PhysicalPackagePortController.................................................................. 316
16.3.26 HPFCHBA_SoftwareIdentityDrvPortController.............................................................. 317
16.3.27 HPFCHBA_PortControllerFirmwareIdentityFW............................................................. 317
16.3.28 HPFCHBA_PortControllerFirmwareIdentityBIOS........................................................... 317
16.3.29 HPFCHBA_ProductPhysicalComponent ...................................................................... 318
16.3.30 HPFCHBA_SystemPackaging ................................................................................... 318
16.3.31 HPFCHBA_ConcreteIdentity ..................................................................................... 319
16.3.32 HPFCHBA_GroupHostedCollection ........................................................................... 319
16.3.33 HPFCHBA_FCPortGroupSystemSpecific ..................................................................... 319
16.3.34 HPFCHBA_Location ................................................................................................ 320
16.3.35 HPFCHBA_PhysicalElementLocation .......................................................................... 320
16.4 Supported indications....................................................................................................... 320
16.4.1 Fibre Channel Port Status changed to OK............................................................................ 320
16.4.2 Fibre Channel Port Status changed to Link Down .................................................................. 322
17 SAS HBA.................................................................................................................................325
17.1 Overview........................................................................................................................325
17.2 Use cases........................................................................................................................ 325
17.3 Class implementations ...................................................................................................... 325
17.3.1 HPSAS_ArraySystem ........................................................................................................ 325
17.3.2 HPSAS_ArrayController .................................................................................................... 326
17.3.3 HPSAS_StorageVolume..................................................................................................... 327
17.3.4 HPSAS_DiskDrive............................................................................................................. 329
17.3.5 HPSAS_StorageExtent....................................................................................................... 330

Contents 11
17.3.6 HPSAS_DiskDriveFirmware................................................................................................ 331
17.3.7 HPSAS_PhysicalPackage................................................................................................... 332
17.3.8 HPSAS_DiskPhysicalPackage ............................................................................................. 332
17.3.9 HPSAS_PortController ....................................................................................................... 333
17.3.10 HPSAS_DAPort ...................................................................................................... 334
17.3.11 HPSAS_Firmware ................................................................................................... 335
17.3.12 HPSAS_PrimordialPool ............................................................................................ 335
17.3.13 HPSAS_PrimordialPoolNoRaid ................................................................................. 336
17.3.14 HPSAS_StoragePool ............................................................................................... 337
17.3.15 HPSAS_StorageSetting............................................................................................ 337
17.3.16 HPSAS_SCSIProtocolEndpoint .................................................................................. 338
17.3.17 HPSAS_SCSIProtocolController................................................................................. 339
17.3.18 HPSAS_StorageRedundancySet................................................................................ 340
17.3.19 HPSAS_StorageSpecificCollection ............................................................................ 341
17.3.20 HPSAS_ArraySystemLocation ................................................................................... 341
17.3.21 HPSAS_DiskDriveLocation ....................................................................................... 342
17.3.22 HPSAS_StorageCapabilities..................................................................................... 342
17.3.23 HPSAS_Product...................................................................................................... 344
17.3.24 HPSAS_DriveCage ................................................................................................. 344
17.3.25 HPSAS_EnclosureFirmware ...................................................................................... 345
17.3.26 HPSAS_StorageEnclosure ........................................................................................ 345
17.3.27 HPSAS_StorageEnclosureProcessor........................................................................... 346
17.3.28 HPSAS_StorageEnclosureLocation............................................................................. 347
17.3.29 HPSAS_DriveCageDiskDrive (Association) ................................................................. 348
17.3.30 HPSAS_StorageEnclosureDriveCage (Association) ...................................................... 348
17.3.31 HPSAS_StorageEnclosureEnclosureLocation (Association) ............................................ 348
17.3.32 HPSAS_ArraySystemStorageEnclosureProcessor (Association) ...................................... 349
17.3.33 HPSAS_StorageEnclosureProcessorEnclosureFirmware (Association).............................. 349
17.3.34 HPSAS_StorageEnclosureStorageEnclosureProcessor (Association)................................ 349
17.3.35 HPSAS_StorageVolumeStorageSetting (Association).................................................... 349
17.3.36 HPSAS_PrimordialPoolStorageCapabilities (Association) ............................................. 350
17.3.37 HPSAS_PrimordialPoolNoRaidStorageCapabilities (Association)................................... 350
17.3.38 HPSAS_StoragePoolStorageCapabilities (Association)................................................. 350
17.3.39 HPSAS_ArraySystemSCSIProtocolController (Association) ............................................ 350
17.3.40 HPSAS_ArraySystemPortController (Association)......................................................... 351
17.3.41 HPSAS_ArraySystemDiskDrive (Association)............................................................... 351
17.3.42 HPSAS_ArraySystemStorageVolume (Association) ...................................................... 351
17.3.43 HPSAS_ArraySystemStorageExtent (Association)......................................................... 351
17.3.44 HPSAS_ArraySystemDAPort (Association) .................................................................. 352
17.3.45 HPSAS_ArraySystemPrimordialPool (Association) ....................................................... 352
17.3.46 HPSAS_ArraySystemPrimordialPoolNoRaid (Association)............................................. 352
17.3.47 HPSAS_ArraySystemStoragePool (Association)........................................................... 352
17.3.48 HPSAS_ComputerSystemArraySystem (Association) .................................................... 352
17.3.49 HPSAS_ArraySystemArrayController (Association) ...................................................... 353
17.3.50 HPSAS_ProductPhysicalPackage (Association)............................................................ 353
17.3.51 HPSAS_StoragePoolStorageExtent (Association) ......................................................... 353
17.3.52 HPSAS_PrimordialPoolStorageExtent (Association)...................................................... 353
17.3.53 HPSAS_PrimordialPoolNoRaidStorageExtent (Association) ........................................... 354
17.3.54 HPSAS_StorageSpecificCollectionArraySystem (Association)........................................ 354
17.3.55 HPSAS_StorageRedundancySetStorageExtent (Association).......................................... 354
17.3.56 HPSAS_ArraySystemFirmware (Association)............................................................... 354
17.3.57 HPSAS_SCSIProtocolControllerStorageVolume (Association) ........................................ 355
17.3.58 HPSAS_FirmwareArraySystem (Association)............................................................... 355
17.3.59 HPSAS_DiskDriveDiskDriveFirmware (Association) ...................................................... 355

Contents 12
17.3.60 HPSAS_DiskPhysicalPackageDiskDrive (Association) ................................................... 355
17.3.61 HPSAS_StoragePoolStorageVolume (Association) ....................................................... 356
17.3.62 HPSAS_PrimordialPoolStoragePool (Association) ........................................................ 356
17.3.63 HPSAS_SpareExtentStorageRedundancySet (Association) ............................................ 356
17.3.64 HPSAS_StorageExtentStorageVolume (Association) ..................................................... 356
17.3.65 HPSAS_DAPortSCSIProtocolEndpoint (Association) ..................................................... 357
17.3.66 HPSAS_StorageGroupHostedCollection (Association).................................................. 357
17.3.67 HPSAS_PhysicalPackageArraySystem (Association)..................................................... 357
17.3.68 HPSAS_PhysicalPackageArraySystemLocation (Association) ......................................... 357
17.3.69 HPSAS_DiskPhysicalPackageDiskDriveLocation (Association)........................................ 358
17.3.70 HPSAS_SCSIProtocolEndpointSCSIProtocolController (Association) ............................... 358
17.4 Supported indications....................................................................................................... 358
17.4.1 SAS HBA Status OK ......................................................................................................... 358
17.4.2 SAS HBA in Error State..................................................................................................... 360
17.4.3 Physical Drive Status OK ................................................................................................... 362
17.4.4 Physical Drive Status ERROR .............................................................................................. 364
17.4.5 Physical Drive Status REBUILDING ...................................................................................... 366
17.4.6 Drive Status PREDICTIVE FAILURE ....................................................................................... 369
17.4.7 Logical Drive Status OK .................................................................................................... 371
17.4.8 Logical Drive Status ERROR ............................................................................................... 372
17.4.9 Logical Drive is in a Degraded State................................................................................... 374
17.4.10 Power Supply Status Changed to Non Redundant....................................................... 376
17.4.11 Enclosure Power Supply Status Changed to OK (Redundant) ........................................ 378
17.4.12 Enclosure Power Supply Status Changed to Redundant Degraded ................................ 380
17.4.13 Enclosure Temperature Sensor Status Changed to OK ................................................. 382
17.4.14 Enclosure Temperature Status Changed to Warning.................................................... 384
17.4.15 Enclosure Temperature Sensor Status Changed to Critical ............................................ 386
17.4.16 Enclosure Fan Status Changed to OK........................................................................ 388
17.4.17 Enclosure Fan Status Changed to Degraded .............................................................. 390
17.4.18 Enclosure Fan Status Changed to Failure ................................................................... 392
18 SCSI HBA................................................................................................................................394
18.1 Overview........................................................................................................................394
18.2 Use cases........................................................................................................................ 394
18.3 Class implementations ...................................................................................................... 394
18.3.1 HPSCSI_HBAComputerSystem ........................................................................................... 394
18.3.2 HPSCSI_StorageVolume.................................................................................................... 395
18.3.3 HPSCSI_DiskDrive ............................................................................................................ 397
18.3.4 HPSCSI_StorageExtent ...................................................................................................... 398
18.3.5 HPSCSI_DiskDriveFirmwareIdentity ..................................................................................... 399
18.3.6 HPSCSI_HBAPhysicalPackage............................................................................................ 399
18.3.7 HPSCSI_DiskPhysicalPackage ............................................................................................ 400
18.3.8 HPSCSI_StorageEnclosure ................................................................................................. 401
18.3.9 HPSCSI_StorageEnclosureProcessor.................................................................................... 402
18.3.10 HPSCSI_HBAPortController ...................................................................................... 403
18.3.11 HPSCSI_DAPort...................................................................................................... 404
18.3.12 HPSCSI_HBASPIPort ............................................................................................... 404
18.3.13 HPSCSI_HBAFirmwareIdentity.................................................................................. 405
18.3.14 HPSCSI_EnclosureFirmware ..................................................................................... 406
18.3.15 HPSCSI_MediaAccessStatData................................................................................. 407
18.3.16 HPSCSI_DriveCage ................................................................................................ 407
18.3.17 HPSCSI_HBASCSIProtocolEndpoint........................................................................... 408
18.3.18 HPSCSI_DASCSIProtocolEndpoint............................................................................. 409
18.3.19 HPSCSI_HBASCSIProtocolController ......................................................................... 410

Contents 13
18.3.20 HPSCSI_HBAGroupCollection .................................................................................. 411
18.3.21 HPSCSI_StorageEnclosureLocation............................................................................ 411
18.3.22 HPSCSI_DriveCageLocation..................................................................................... 412
18.3.23 HPSCSI_HBALocation ............................................................................................. 412
18.3.24 HPSCSI_DiskDriveLocation....................................................................................... 413
18.3.25 HPSCSI_HBAProduct............................................................................................... 413
18.3.26 HPSCSI_HBAComputerSystemStorageEnclosureProcessor (Association) ......................... 414
18.3.27 HPSCSI_HBAComputerSystemSCSIProtocolController (Association) ............................... 414
18.3.28 HPSCSI_HBAComputerSystemPortController (Association)............................................ 414
18.3.29 HPSCSI_HBAComputerSystemDiskDrive (Association).................................................. 414
18.3.30 HPSCSI_HBAComputerSystemStorageVolume (Association) ......................................... 414
18.3.31 HPSCSI_HBAComputerSystemStorageExtent (Association)............................................ 415
18.3.32 HPSCSI_HBAComputerSystemSPIPort (Association) ..................................................... 415
18.3.33 HPSCSI_HBAComputerSystemDAPort (Association) ..................................................... 415
18.3.34 HPSCSI_HBAComponentCS (Association).................................................................. 415
18.3.35 HPSCSI_StorageEnclosureStorageEnclosureProcessor (Association) ............................... 416
18.3.36 HPSCSI_HBAProductPhysicalComponent (Association) ................................................ 416
18.3.37 HPSCSI_StorageEnclosureDriveCage (Association) ..................................................... 416
18.3.38 HPSCSI_HBAPhysicalPackageDiskDrivePhysicalPackage (Association)........................... 416
18.3.39 HPSCSI_DriveCageDiskDrive (Association) ................................................................ 416
18.3.40 HPSCSI_HBAComputerSystemHBAFirmwareIdentity (Association) ................................. 417
18.3.41 HPSCSI_SCSIProtocolControllerStorageVolume (Association)........................................ 417
18.3.42 HPSCSI_StorageEnclosureProcessorEnclosureFirmware (Association)............................. 417
18.3.43 HPSCSI_DiskDriveDiskDriveFirmwareIdentity (Association) ........................................... 418
18.3.44 HPSCSI_DiskDriveStorageExtent (Association) ............................................................ 418
18.3.45 HPSCSI_DiskPhysicalPackageDiskDrive (Association) .................................................. 418
18.3.46 HPSCSI_StorageExtentStorageVolume (Association) .................................................... 418
18.3.47 HPSCSI_DAPortSCSIProtocolEndpoint (Association)..................................................... 418
18.3.48 HPSCSI_HBASCSIProtocolEndpointSPIPort (Association) .............................................. 419
18.3.49 HPSCSI_HBAGroupCollectionComputerSystem (Association)........................................ 419
18.3.50 HPSCSI_HBAGroupCollectionHBAComputerSystem (Association) ................................. 419
18.3.51 HPSCSI_HBASystemPackaging (Association).............................................................. 419
18.3.52 HPSCSI_HBAPhysicalPackagePortController (Association)............................................ 420
18.3.53 HPSCSI_DiskDriveMediaAccessStatData (Association)................................................. 420
18.3.54 HPSCSI_HBAPhysicalPackageLocation (Association) ................................................... 420
18.3.55 HPSCSI_StorageEnclosureEnclosureLocation (Association)............................................ 420
18.3.56 HPSCSI_DriveCageDriveCageLocation (Association)................................................... 421
18.3.57 HPSCSI_DiskPhysicalPackageDiskDriveLocation (Association)....................................... 421
18.3.58 HPSCSI_SCSIProtocolEndpointSCSIProtocolController (Association)............................... 421
18.3.59 HPSCSI_HBAPortControllerHBASPIPort (Association) ................................................... 421
18.3.60 HPSCSI_HBAComputerSystemSCSIProtocolEndpoint (Association)................................. 422
18.4 Supported indications....................................................................................................... 422
18.4.1 Physical Drive Status Set to OK .......................................................................................... 422
18.4.2 Physical Drive Status Set to ERROR ..................................................................................... 424
18.4.3 Physical Drive Status is Set to Predictive Failure .................................................................... 426
18.4.4 Physical Drive Status OFFLINE ........................................................................................... 427
18.4.5 Physical Drive Status – Missing was OK .............................................................................. 429
18.4.6 Physical Drive Status – Missing was FAILED ......................................................................... 431
18.4.7 Physical Drive Status – Missing was Predictive Failure ........................................................... 433
18.4.8 Physical Drive Status – Missing was OFFLINE....................................................................... 435
18.4.9 Controller Status Changed to Unknown............................................................................... 437
18.4.10 Controller Status OK ............................................................................................... 439
18.4.11 Controller Status ERROR .......................................................................................... 441
18.4.12 Power Supply Status NOT REDUNDANT ................................................................... 443

Contents 14
18.4.13 Power Supply Status OK.......................................................................................... 445
18.4.14 Power Supply Status DEGRADED.............................................................................. 447
18.4.15 Temperature Sensor Status Change OK..................................................................... 449
18.4.16 Temerature Sensor Status Change Warning Condition ................................................ 451
18.4.17 Temerature Sensor Status Change – Critical............................................................... 453
18.4.18 Fan Status Change – OK......................................................................................... 455
18.4.19 Fan Status Change – Degraded ............................................................................... 457
18.4.20 Fan Status Change – ERROR.................................................................................... 459
19 System software .......................................................................................................................462
19.1 Overview........................................................................................................................462
19.2 Use cases........................................................................................................................ 462
19.3 Class implementations ...................................................................................................... 462
19.3.1 CIM_SoftwareIdentity ....................................................................................................... 462
19.3.2 CIM_InstalledSoftwareIdentity ............................................................................................ 464
19.4 Supported indications....................................................................................................... 465
20 Profile registration..................................................................................................................... 466
20.1 Overview........................................................................................................................466
20.2 Use cases........................................................................................................................ 466
20.3 Class implementations ...................................................................................................... 466
20.3.1 HP_RegisteredProfile and HP_RegisteredSubProfile ............................................................... 466
20.3.2 HP_ExtendsProfile............................................................................................................. 469
20.3.3 HP_ReferencedProfile........................................................................................................ 470
20.3.4 HP_ElementConformsToProfile............................................................................................ 470
20.4 Supported indications....................................................................................................... 470
21 Standalone Tape Drive Profile ....................................................................................................471
21.1 Overview........................................................................................................................471
21.2 Use Cases.......................................................................................................................471
21.3 Class Implementations ...................................................................................................... 471
21.3.1 HPWMITape_TapeDrive.................................................................................................... 471
21.3.2 HPWMITape_TapeDriveStatData........................................................................................ 472
21.3.3 HPWMITape_TapeDriveMediaLocation............................................................................... 473
21.3.4 HPWMITape_PhysicalTape................................................................................................ 474
21.3.5 HPWMITape_TapeDriveCapabilities................................................................................... 475
21.3.6 HPWMITape_TapeDriveEnclosure ...................................................................................... 475
21.3.7 HPWMITape_Product ....................................................................................................... 476
21.3.8 HPWMITape_SCSIProtocolEndpoint.................................................................................... 477
21.3.9 HPWMITape_TapeDriveFirmware ...................................................................................... 477
21.3.10 HPWMITape_TapeDriveSPIPort ................................................................................ 478
21.3.11 HPWMITape_TapeDriveSASPort............................................................................... 479
21.3.12 HPWMITape_TapeSystemDevice (Association) ........................................................... 480
21.3.13 HPWMITape_LogicalPortSystemDevice (Association)................................................... 480
21.3.14 HPWMITape_TapeDriveToCapabilities (Association)................................................... 480
21.3.15 HPWMITape_TapeDriveToStatData (Association)........................................................ 481
21.3.16 HPWMITape_RealizeStorageMediaLocation (Association) ........................................... 481
21.3.17 HPWMITape_TapeInTapeDriveMediaLocation (Association)......................................... 481
21.3.18 HPWMITape_RealizePhysicalPackage (Association).................................................... 481
21.3.19 HPWMI_TapeProductToEnclosure (Association) .......................................................... 482
21.3.20 HPWMITape_TapeDriveToTapeDriveFirmware (Association) ........................................ 482
21.3.21 HPWMITape_InstalledDriveFirmware (Association) ..................................................... 482
21.3.22 HPWMITape_TapeDriveToProtocolEndpoint (Association) ............................................ 482
21.3.23 HPWMITape_HostedAccessPoint (Association) ........................................................... 483
21.3.24 HPWMITape_SCSIInitiatorTargetLUPath (Association).................................................. 483

Contents 15
21.3.25 HPWMITape_SCSIProtocolEndpointLogicalPort (Association)........................................ 483
21.4 Supported Indications ....................................................................................................... 483
21.4.1 Drive status changed to Unknown....................................................................................... 483
21.4.2 Drive status changed to OK............................................................................................... 485
21.4.3 Drive status changed to Degraded...................................................................................... 487
21.4.4 Drive status changed to Failed ........................................................................................... 488
21.4.5 New Tape Drive Found..................................................................................................... 490
21.4.6 Tape Drive status changed to Offline .................................................................................. 492
21.4.7 OK Tape Drive Now Missing............................................................................................. 493
21.4.8 Failed Drive Now Missing................................................................................................. 495
21.4.9 Offline Drive Now Missing ................................................................................................ 497
21.4.10 Degraded Drive Now Missing.................................................................................. 498
21.4.11 Tape Drive Cleaning Required ................................................................................. 500
21.4.12 Cleaning Tape Replacement Required....................................................................... 502
22 Host Discovered Resources (HDR) ............................................................................................... 504
22.1 Overview........................................................................................................................504
22.2 Use Cases.......................................................................................................................504
22.3 Class implementations ...................................................................................................... 504
22.3.1 HPHDR_ComputerSystem .................................................................................................. 504
22.3.2 HPHDR_SCSIProtocolEndPointInitiator ................................................................................. 505
22.3.3 HPHDR_SCSIProtocolEndPointTarget................................................................................... 505
22.3.4 HPHDR_LogicalDisk.......................................................................................................... 506
22.3.5 HPHDR_RemoteServiceAccessPoint ..................................................................................... 508
22.3.6 HPHDR_LogicalDiskRemoteServiceAccessPoint (Association) .................................................. 509
22.3.7 HPHDR_ComputerSystemRemoteServiceAccessPoint (Association)........................................... 509
22.3.8 HPHDR_ComputerSystemLogicalDisk (Association)................................................................ 509
22.3.9 HPHDR_ComputerSystemSCSIProtocolEndpointInitiator (Association)....................................... 510
22.3.10 HPHDR_ComputerSystemSCSIProtocolEndpointTarget (Association)............................... 510
23 For more information................................................................................................................. 511

Overview 16
1Overview
The HP Insight Management WBEM Providers supply system management data through the
Windows® Management Instrumentation (WMI) framework for HP Integrity server platforms and
options. These providers implement the profiles and data described in this document.
Use of the providers requires Windows Server® 2008 or Windows Server 2008 R2, and WMI.

Base server 17
2Base server
2.1 Overview
The following profiles are implemented, and files are installed by this provider.
Table 2-1 Overview
•HP Base Server Profile (P00105)
Implemented Profiles
•HP Base Server Physical Asset Profile (P00114)
•DMTF Power State Management Profile
(DSP1027)
•DMTF Software Inventory Profile (DSP1023)
•HPWmiSys.dll
Provider Installation Files
•HPWmiSysEvt.dll
•HPWmiSysEvtMsg.dll
•HPWmiSys.mof
2.2 Use cases
For use cases, see the HP Base Server profile (P00105), HP Base Server Physical Asset profile
(P00114), DMTF Power State Management Profile (DSP1027), and DMTF Software Inventory Profile
(DSP1023).
2.3 Class implementations
The following classes describe the base server implementation.
2.3.1HP_WinComputerSystem
HP_WinComputerSystem extends the class HP_ComputerSystem to model the base server. Only one
instance of HP_WinComputerSystem is instantiated on an Integrity server.
The following properties are implemented.
Table 2-2 Class: HP_WinComputerSystem Properties
Property name Property implementation
CIM_ManagedElement
Caption Computer system DNS name returned by Windows API
GetComputerSystemName()
Description Computer system DNS name returned by Windows API
GetComputerSystemName()

Base server 18
Table 2-2 Class: HP_WinComputerSystem Properties
ElementName Computer system DNS name returned by Windows API
GetComputerSystemName()
CIM_ManagedSystemElement
OperationalStatus OperationalStatus[0] contains the computer system
consolidated status and indicates the worst status of
connected subsystems. OperationalStatus[0] contains
one of the following:
•0 (Unknown)
•1 (Other)
•2 (OK)
•3 (Degraded)
•6 (Error)
StatusDescriptions StatusDescriptions[0] contains one of the following
corresponding to OperationalStatus[0]:
•One or more of the subsystems that
make up this computer system have an
OperationalStatus value of Unknown.
•One or more of the subsystems that
make up this computer system have an
OperationalStatus value of Other.
•OK
•One or more of the subsystems that
make up this computer system have an
OperationalStatus value of Degraded.
•One or more of the subsystems that
make up this computer system have an
OperationalStatus value of Error.
•0 (Unknown)
HealthState
•5 (OK)
•10 (Degraded)
•20 (Major Failure)
CIM_LogicalElement
CIM_EnabledLogicalElement
EnabledState 5 (Not Applicable)
RequestedState 12 (Not Applicable)
EnabledDefault 2 (Enabled)
CIM_System
CreationClassName HP_WinComputerSystem
Roles Computer system roles string (writable property;
persistent across reboots).
CIM_ComputerSystem

Base server 19
Table 2-2 Class: HP_WinComputerSystem Properties
•OtherIdentifyingInfo[0]:
OtherIdentifyingInfo
HPQ:ProductID_String,where
ProductID_String is
HP_ComputerSystemChassis.ProductID.
•OtherIdentifyingInfo[1]:
CIM:UUID_String,where UUID_String is the
computer system UUID string.
•OtherIdentifyingInfo[2]:
CIM:Model_String:Serial Number String,
where Model_String is the computer system
model string and Serial Number String is the
computer system serial number string.
•OtherIdentifyingInfo[3]:
CIM:Tag_String,where Tag_String is the
computer system asset tag string.
•IdentifyingDescriptions[0]:
IdentifyingDescriptions
HPQ:ProductID
•IdentifyingDescriptions[1]:
CIM:UUID
•IdentifyingDescriptions[2]:
CIM:Model:SerialNumber
•IdentifyingDescriptions[3]:
CIM:Tag
Dedicated 0 (Not Dedicated)
HP_ComputerSystem
Name Computer system DNS name returned by Windows API
GetComputerSystemName().
NameFormat DNSName
PrimaryOwnerName Computer system primary owner name string;
initialized to not set (writable property; persistent
across reboots).
PrimaryOwnerContact Computer system primary owner contact string;
initialized to not set (writable property; persistent
across reboots).
PrimaryOwnerPager Computer system primary owner pager string;
initialized to not set (writable property; persistent
across reboots).
SecondaryOwnerContact Computer system secondary owner contact string;
initialized to not set (writable property; persistent
across reboots).
SecondaryOwnerName Computer system secondary owner name string;
initialized to not set (writable property; persistent
across reboots).
SecondaryOwnerPager Computer system secondary owner pager string;
initialized to not set (writable property; persistent
across reboots).

Base server 20
Table 2-2 Class: HP_WinComputerSystem Properties
LocationIndicator State of the computer system Unit Identifier (UID) LED
(writable property):
•0 (Unknown)
•2 (On)
•3 (Off)
•4 (Unsupported)
•5 (Alternating).
Only 2 (On) and 3 (Off) are supported for writing. The
Lights Out Remote Console is active and any writes to
the property are ignored.
HP_WinComputerSystem
2.3.2 HP_ComputerSystemChassis
HP_ComputerSystemChassis extends the class CIM_ComputerSystemChassis to model the physical
system chassis. Only one instance of HP_ComputerSystemChassis is instantiated on an Integrity
server.
The following properties are implemented.
Table 2-3 Class: HP_ComputerSystemChassis
Property name Property implementation
CIM_PhysicalElement
Tag Concatenation of serial number string and product ID
string (Model:Serial Number)
CreationClassName HP_ComputerSystemChassis
ElementName Computer system product name (model) string
Manufacturer Computer manufacturer string
Model Computer system product name (model) string
SerialNumber Computer system serial number string
UserTracking Computer system asset tag string (read only property;
persistent across reboots)
VendorEquipmentType A string, indicating the system type:
•Unknown
•Other
•Cellular
•Foundation
•HPVM
•Blade
CIM_PhysicalPackage
RemovalConditions 2 (Not Applicable)
PackageType 3 (Chassis/Frame)
