Installation
Guide
hp StorageWorks
NAS 2000s
Product Version: 1.0
First Edition (September 2003)
Part Number: 345649-001
This installation guide provides information about how to deploy the
HP StorageWorks NAS 2000s.

© Copyright 2003 Hewlett-Packard Development Company, L.P.
Hewlett-Packard Company makes no warranty of any kind with regard to this material,
including, but not limited to, the implied warranties of merchantability and fitness for a
particular purpose. Hewlett-Packard shall not be liable for errors contained herein or for
incidental or consequential damages in connection with the furnishing, performance, or
use of this material.
This document contains proprietary information, which is protected by copyright. No
part of this document may be photocopied, reproduced, or translated into another
language without the prior written consent of Hewlett-Packard. The information
contained in this document is subject to change without notice.
Microsoft®, MS-DOS®, MS Windows®, Windows®, and Windows NT® are U.S.
registered trademarks of Microsoft Corporation.
Hewlett-Packard Company shall not be liable for technical or editorial errors or
omissions contained herein. The information is provided “as is” without warranty of any
kind and is subject to change without notice. The warranties for Hewlett-Packard
Company products are set forth in the express limited warranty statements for such
products. Nothing herein should be construed as constituting an additional warranty.
NAS 2000s Installation Guide
First Edition (September 2003)
Part Number: 345649–001

Contents
3NAS 2000s Installation Guide
Contents
About this Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
Intended Audience . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
Prerequisites . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
Related Documentation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
Conventions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
Document Conventions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
Text Symbols . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Equipment Symbols . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Rack Stability . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
Getting Help . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
HP Technical Support. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
HP Storage Website . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
HP Authorized Reseller . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
1 Product Overview. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
Product Definition and Information . . . . . . . . . . . . . . . . . . . . . . . . .11
Server Hardware Features. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
Optional Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
Rear Panel Connectors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
Software Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
2 Configuration Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
Preinitialization . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
Collect Information for Configuration . . . . . . . . . . . . . . . . . . . . . . .18
Configuration Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
WebUI Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20
RapidLaunch Method . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20
Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20
Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21

4 NAS 2000s Installation GuideNAS 2000s Installation Guide
Remote Browser Method (Using Hostname) . . . . . . . . . . . . . . .24
Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24
Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25
Direct Attach Method . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26
Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26
Rapid Startup Wizard Configuration . . . . . . . . . . . . . . . . . . . . .27
Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27
Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .28
Configure Storage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .30
Creating Disk Arrays . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .30
Creating Logical Disks. . . . . . . . . . . . . . . . . . . . . . . . . . . . .31
Verifying Logical Disks. . . . . . . . . . . . . . . . . . . . . . . . . . . .31
Creating a Volume . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .32
Creating File Shares . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .33
Basic Setup Complete . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .34
Completing the System Configuration . . . . . . . . . . . . . . . . . . . .34
Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .35

About This
Guide
5NAS 2000s Installation Guide
About this Guide
About this Guide
This installation guide provides information to help you deploy
the HP StorageWorks NAS 2000s.
“About this Guide” topics include:
■Overview, page 5
■Conventions, page 6
■Rack Stability, page 9
■Getting Help, page 9
Overview
This section covers the following topics:
■Intended Audience
■Prerequisites
■Related Documentation
Intended Audience
This book is intended for use by technical professionals who are
experienced with the following:
■Microsoft®administrative procedures
■file-sharing protocols
Prerequisites
Before you set up the NAS 2000s, HP recommends that you
obtain supplemental documentation relative to the items listed
above in the section titled “Intended Audience.”

6 NAS 2000s Installation Guide
Related Documentation
In addition to this guide, HP provides corresponding information:
■HP StorageWorks NAS 2000s Administration Guide
■HP StorageWorks NAS 2000s Quick Reference and Rack
Installation Poster
■HP StorageWorks NAS 2000s Release Notes
Conventions
Conventions consist of the following:
■Document Conventions
■Text Symbols
■Equipment Symbols
Document Conventions
The document conventions included in Table 1 apply in most
cases.
Table 1: Document Conventions
Element Convention
Cross-reference links Figure 1
Key and field names, menu items,
buttons, and dialog box titles Bold
File names, application names, and
text emphasis
Italics
User input, command and directory
names, and system responses
(output and messages)
Monospace font
COMMAND NAMES are uppercase
monospace font unless they are case
sensitive
Variables <monospace, italic font>
Website addresses Underlined sans serif font text:
http://www.hp.com

7NAS 2000s Installation Guide
Text Symbols
The following symbols may be found in the text of this guide.
They have the following meanings:
WARNING: Text set off in this manner indicates that failure
to follow directions in the warning could result in bodily harm
or death.
Caution: Text set off in this manner indicates that failure to
follow directions could result in damage to equipment or
data.
Note: Text set off in this manner presents commentary, sidelights, or
interesting points of information.
Equipment Symbols
The following equipment symbols may be found on hardware for
which this guide pertains. They have the following meanings:
Any enclosed surface or area of the equipment
marked with these symbols indicates the presence of
electrical shock hazards. Enclosed area contains no
operator serviceable parts.
WARNING: To reduce the risk of personal injury from
electrical shock hazards, do not open this enclosure.

8 NAS 2000s Installation Guide
Any RJ-45 receptacle marked with these symbols
indicates a network interface connection.
WARNING: To reduce the risk of electrical shock, fire,
or damage to the equipment, do not plug telephone
or telecommunications connectors into this receptacle.
Any surface or area of the equipment marked with
these symbols indicates the presence of a hot surface
or hot component. Contact with this surface could
result in injury.
WARNING: To reduce the risk of personal injury from
a hot component, allow the surface to cool before
touching.
Power supplies or systems marked with these
symbols indicate the presence of multiple
sources of power.
WARNING: To reduce the risk of personal
injury from electrical shock, remove all power
cords to completely disconnect power from the
power supplies and systems.
Any product or assembly marked with these symbols
indicates that the component exceeds the
recommended weight for one individual to handle
safely.
WARNING: To reduce the risk of personal injury or
damage to the equipment, observe local occupational
health and safety requirements and guidelines for
manually handling material.

9NAS 2000s Installation Guide
Rack Stability
Rack stability protects personnel and equipment.
WARNING: To reduce the risk of personal injury or damage
to the equipment, be sure that:
■The leveling jacks are extended to the floor.
■The full weight of the rack rests on the leveling jacks.
■In single rack installations, the stabilizing feet are
attached to the rack.
■In multiple rack installations, the racks are coupled.
■Only one rack component is extended at any time. A rack
may become unstable if more than one rack component
is extended for any reason.
Getting Help
If you still have a question after reading this guide, contact an HP
authorized service provider or access our website:
http://www.hp.com .

10 NAS 2000s Installation Guide
HP Technical Support
Telephone numbers for worldwide technical support are listed on
the following HP website:
http://www.hp.com/support/ . From
this website, select the country of origin.
Note: For continuous quality improvement, calls may be recorded or
monitored.
Be sure to have the following information available before
calling:
■Technical support registration number (if applicable)
■Product serial numbers
■Product model names and numbers
■Applicable error messages
■Operating system type and revision level
■Detailed, specific questions
HP Storage Website
The HP website has the latest information on this product, as well
as the latest drivers. Access storage at:
http://www.hp.com/
country/us/eng/prodserv/storage.html . From this website, select
the appropriate product or solution.
HP Authorized Reseller
For the name of your nearest HP authorized reseller:
■In the United States, call 1-800-345-1518
■In Canada, call 1-800-263-5868
■Elsewhere, see the HP website for locations and telephone
numbers:
http://www.hp.com .

11NAS 2000s Installation Guide
1
Product Overview
This chapter provides product definition, product information,
and a hardware and software overview of the HP StorageWorks
NAS 2000s. Additional information also found in the chapter
includes optional features, rear panel connector location, and
third-party support.
Product Definition and Information
The NAS 2000s is a business class NAS solution that provides
reliable performance, manageability, and fault tolerance.
Server Hardware Features
The following features are included in the NAS 2000s internal
SCSI model:
■One Intel XEON 3.06 GHz with 1 MB L3 cache and
512 K L2 cache
■1 GB (2 X 512 MB SIMMs)
■Smart Array 5i+ Embedded SCSI-3 controller with
Battery-Backed Write Cache (BBWC) Enabler
■Redundant 400-watt hot plug power supplies
■64-bit PCI-X I/O technology:
— Two hot-pluggable 100-MHz slots
— One 133-MHz slot
■Integrated Lights-Out (iLO)
■Two mirrored 36.4-GB, 10,000 rpm U320 universal drives
for OS

12 NAS 2000s Installation Guide
■Four 146.8-GB, 10,000 rpm U320 universal drives for user
data (allows for RAID 5)
■Two NC7781 10/100/1000 NICs (embedded)
■Redundant fans
Figure 1: NAS 2000s internal SCSI model
The following features are included in the NAS 2000s external
SCSI model:
■One Intel XEON 3.06 GHz with 1 MB L3 cache and
512 K L2 cache
■1 GB (2 X 512 MB SIMM)
■Smart Array 5i+ Embedded SCSI-3 controller with
Battery-Backed Write Cache (BBWC) Enabler
■Redundant 400-watt hot plug power supplies (server only)
■64-bit PCI-X I/O technology:
— Two hot-pluggable 100-MHz slots
— One 133-MHz slot with Smart Array 6404 controller
installed

NAS 2000s Installation Guide 13
■Integrated Lights-Out (iLO)
■Two mirrored 36-GB, 10,000 rpm U320 universal drives
for OS
■Two NC7781 10/100/1000 NICs (embedded)
■Redundant fans
■Four 146-GB, 10,000 rpm U320 universal drives for user
data (allows for RAID 5)
■4414 Storage Cabinet with redundant power supplies and
fans
Figure 2: NAS 2000s external SCSI model
Optional Features
The following features are optional for the NAS 2000s server:
■SA5300, SA6404 (support for multiple adapters)
■HP StorageWorks Enclosure 4314, 4414, 4354, and 4454
■Standard HP ProLiant NIC Suite including NC7770
■Alacritech NICs
■LP952 and/or LP8000 for tape support only
■Tape drive in bay 5
Server
Storage Enclosure

14 NAS 2000s Installation Guide
Rear Panel Connectors
Figure 3: Rear panel connectors
Note: * Included with NAS 2000s external SCSI only.
Table 2: Rear Panel Connectors
Item Description
1PCI expansion slots
2Serial connector (teal)
3Integrated Lights-Out (iLO Eth)
4Mouse connector (PS/2) (green)
5Power connectors
6Keyboard connector (PS/2) (purple)
7RJ-45 connector for NIC 1
8RJ-45 connector for NIC 2
9USB connectors (2) (black)
-Video connector (blue)
qVHDCI SCSI connector (SCSI port 1)
wSmart Array 6404 controller*
1 2 3 4
6711 9
3
2
10
5
812

NAS 2000s Installation Guide 15
Software Features
HP-supplied software included and supported by the NAS 2000s
includes:
■Quick Restore DVD containing the NAS OS image
■WebUI based on NAS 3.0
■Array Configuration Utility (ACU) XE Support
■HP Insight Manager (CIM) WBEM Win32
— HP Insight Manager base console
—XE
—Survey
■HP System Management Interface
■Microsoft Windows®2003 drivers, including Array
Controller driver and HBA drivers
■Insight Management agents
■UPS monitoring agent with automated shutdown via serial
port – preconfigured at factory no user interface
—HPUPS
— APC UPS
■Field diagnostics support via Integrated Lights-Out (iLO)
■SmartStart 6.4 software drivers and Insight Manager 6.4
■NIC teaming drivers
■Support for Web Based Configuration Utility
■Web based configuration utility for quick configuration
■RapidLaunch support for locating NAS devices
■Rapid Start-Up Utility for quick configuration

16 NAS 2000s Installation Guide
Third-party supplied software included and supported by the
NAS 2000s includes:
■Microsoft-supplied software components
— Windows 2003 “Embedded License”
— Microsoft Services for Network File System (NFS)
— Microsoft Services for UNIX 3.0 Retail separate CD for
user name mapping support in a domain only
— Microsoft Services for Netware 5.02 separate CD
— SAK 3.0
— Services for Macintosh
— Terminal services
— Print services
— Console for desktop services
■SW Other Third Party Components
— Tivoli Netview agents
— BMC Patrol agents

17NAS 2000s Installation Guide
2
Configuration Setup
This chapter provides information about preinitialization,
collecting information, and configuring the HP StorageWorks
NAS 2000s using the online method. Details include three
methods of system configuration and an overview of storage
configuration.
Preinitialization
Before beginning the installation process, verify that the
hardware installation is complete. Verify that the NAS 2000s is
completely installed in the rack and that all cables and cords are
connected.
Note: If you need assistance with rack installation or hardware
connections, refer to the quick reference and rack installation guide
included in the shipping carton.

18 NAS 2000s Installation Guide
Collect Information for Configuration
Choose a host name and collect general information before
initializing the NAS 2000s.
Configuration Information
Collect the general information required to initialize the NAS
device for both dynamic host configuration protocols (DHCP)
and non-DHCP configurations. You will be asked for this
information during configuration, as shown in Table 3. Become
familiar with this information before attempting to configure the
NAS device.

NAS 2000s Installation Guide 19
Table 3: Configuration Information
Part A: To Be completed for DHCP and non-DHCP
configurations
Server Host Name:
Integrated Lights-Out
Name: Integrated Lights-Out Default User: Integrated Lights-Out Password:
Note: If NIC teaming is to be implemented, determine which ports will be
teamed. Configure these Ethernet ports for DHCP protocol. For more
information, refer to the Ethernet teaming features and procedures section of
administrative procedures in the administration guide.
Part B: To be completed for non-DHCP configurations only
DNS Servers IP Address
1
2
3
NAS NIC Port* IP Address Subnet
Mask Gateway Address
NIC 1
NIC 2
Integrated Lights-Out
Eth port
* The default NAS 2000s has two Ethernet ports available for network
connectivity. Disable ports that will not be used. Each Ethernet port must be
configured with a separate subnet.
P art C: SNMP Information (optional)
Trap Destination (IP
Address) Manager
Client:
Management Traps
Community String:
System Management
Community String:

20 NAS 2000s Installation Guide
WebUI Configuration
The WebUI is designed to be a graphical, easy-to-use application
that gathers the necessary information for configuration. The
WebUI may be accessed through three methods:
■RapidLaunch method
■Remote Browser method (using hostname)
■Direct Attach method
Note: You can configure this system through the WebUI or manually
through Remote Desktop or Windows Server 2003 Desktop.
Note: The NAS 2000s is designed to be deployed without a monitor,
keyboard, and mouse. These ports are available and supported by
the NAS device, if used.
RapidLaunch Method
The NAS 2000s includes a RapidLaunch CD that can run on any
Windows-based PC using Internet Explorer 5.5 (or later).
Requirements
The following items are required to run the WebUI configuration
application:
■Windows-based PC loaded with Internet Explorer 5.5 (or
later) on the same network segment as the NAS 2000s
■RapidLaunch CD
