HP NetServer LC 3
specifications
The rock-solid workgroup server that keeps
your growing business up and running
The HP NetServer LC 3 is unmatched for manageability, availability, and
performance by any other server in its class through this unique combination
of features built into its core design:
Manageability
•Integrated HP Remote Assistant
•HP Navigator for ease of installation
•HP TopTools for Servers Web-based device management
•HP OpenView ManageX/SE (Special Edition) for NOS and application
management
Availability
•Support for Microsoft®Cluster Server
•ECC memory and memory scrubbing
•Variety of disk array controllers to meet budget and performance needs
•Hot-swap drives
•One-Button Disaster Recovery with HP SureStore DDS backup
accessories
Scalable Performance
•Support for Pentium II and Pentium III dual processing
•I
2O-ready system
•Upgrade path from HP NetServer LC II to HP NetServer LC 3
HP’s Commitment to Service
•Package fully designed by HP for easy access and quick serviceability
•Package design partitions key components to enable easy access to
processor and I/O slots
•Optional service packets for higher levels of hardware and software
support
•HP service available worldwide
As your business grows and your network
needs become more critical, you need a
server that can expand and be reliable so
that you can trust it to run your business.
HP NetServer LC 3 is engineered to
deliver superior manageability, high
availability, and performance wherever
you install your next workgroup server.

2
specifications
HP NetServer LC 3
Features
Performance
Processor Up to 2 Intel Pentium II 400MHz, 450MHz or Pentium III 500MHz, 550MHz
processors with 100MHz bus
Cache 512KB ECC L2 cache per processor
ECC Memory •64MB high-performance 100MHz ECC SDRAM standard with memory scrubbing
•1GB maximum capacity
I/O Expansion Slots 5 PCI (one occupied by preinstalled 10/100TX NIC)
1 PCI/ISA
Controllers •Integrated Ultra/Wide SCSI
Mass Storage System
Hot-Swap •3 half-height hot-swap shelves, plus 1 half-height common tray shelf
•72.8GB maximum internal capacity, 54.6GB hot-swap
•Optional external storage solutions
Video •Integrated; supports 1024x768, 256-color resolution at 72Hz
•1MB standard video memory, upgradeable to 2MB
•Super VGA drivers available with operating system
CD-ROM Drive 24x Max IDE
Flexible Disk Drive 3.5” 1.44MB flexible disk drive
Built-in I/O Ports •One 25-pin parallel port
•Two 9-pin Serial/RS-232 ports
•Video port
•Mini-DIN keyboard and mouse ports
•Management port (9-pin)
Keyboard and Mouse Localized keyboard and two-button mouse

3
specifications
HP NetServer LC 3
Features
Availability
Clustering Support for Microsoft Cluster Server
Self-Restart Capability •Automatic Server Restart (ASR) that reboots in the event of a NOS hang
•Temperature, voltage, and fan-speed monitoring
Self-Correcting Memory Manageable Error Checking and Correcting (ECC) system and cache memory
Hot-Swap Subsystem •Supports 4.2GB, 9.1GB, and 18.2GB disk drives
•Supports high-performance 10,000rpm 4.2GB and 9.1GB disk drives
•Up to 54.6GB of hot-swappable internal storage
Disk Array Controller •Optional HP NetRAID-1or HP NetRAID-3Si I2O disk array controller
•Supports RAID 0, 1, 3, 5, 10, 30, 50
IPMI Intelligent Platform Management Interface to simplify and standardize system
communication for device management
Network Interface Preinstalled 10/100TX network interface card with support for optional network
interface card to support redundancy, load balancing, and Cisco®Fast EtherChannel®
One-Button Disaster Recovery Simple and reliable data restoration with the world's first hardware-based One-Button
Disaster Recovery solution
Manageability1
Installation and Configuration •HP NetServer Navigator with automated, menu-driven system setup and
configuration
•Guided network operating system installation
•Automatic installation of monitoring tools
•IntranetWare from Novell distributed with every system (requires customer
purchase for activation)
Management Software •HP TopTools for Servers, a comprehensive server management solution with
intuitive browser-based user interface, facilitates troubleshooting, administration,
and asset information collection
•Detailed inventory information provided through standard DMI 2.0 protocol
•Award-winning HP OpenView™ ManageX/SE for complete NOS and application
management
•Easy integration with other leading network and system management products
Remote Administration •Integrated HP Remote Assistant provides emergency remote access with a single
event log and expanded inventory data collection for faster troubleshooting
•Optional HP TopTools Remote Control card for remote LAN access and increased
security
•File transfer capabilities for secure and easy remote updates
Expandability
Design Features •Mezzanine design partitions key components and to provide easy access to
memory, I/O slots, and CPU
•Vertically mounted electronics with suspension rails to improve access without
requiring disassembly
•Easy-release processor cartridge
•Ample top and side access
•Rack-friendly design
1See HP NetServer Management Web site at http://www.hp.com/go/netserver_mgmt

4
specifications
HP NetServer LC 3
Features
Flexibility
Supported Operating Systems Microsoft®Windows NT®, Novell®NetWare®and IntranetWareTM,
SCO®OpenServerTMand UnixWare®, IBM®OS/2®Warp Server and
Warp Server SMP, Banyan®VINES®, Linux
Security and Safety
System Security •Startup password
•Power switch cover and keyboard lock button
•Chassis intrusion alert
•Provision for padlock
•System lock and hot-swap hard disk drive lock
•Enable or disable serial port, parallel port, flexible disk drive, and write operations
to the flexible disk drive
Service and Support
Warranty 3-year, next-business-day, onsite limited warranty from HP or authorized resellers
(standard business hours) worldwide
HP SupportPack Options •Free telephone support for basic setup, installation, and troubleshooting in North
America, Europe, and Asia Pacific during warranty
•Optional HP SupportPack for 4-hour response during standard business hours
•Optional HP SupportPack for 24 hours a day, 7 days a week
•Optional HP SupportPack for 6-hour Hardware Call-to-Repair Commitment Service
•Optional HP SupportPack for Comprehensive Technical Support
Reseller Support Services Comprehensive reseller support framework to ensure successful support of
HP NetServers includes
•Proactive Notification e-mail service1
•Service and support Web site1
•Server management and hardware troubleshooting courses (STAR)1
•Troubleshooting Toolkit1
•24x7 telephone support for authorized resellers
•HP Business Builders blueprints for new business opportunities
1See http://www.hp.com/netserver/servsup for details

5
specifications
HP NetServer LC 3
Features
Regulatory Compliance
Electromagnetic Emissions •CFR 47 part 15, Class B: Self Declaration, C63.4 - 1992 (USA)1
•Industry Canada, ICES-003, CISPR 22, Class B (Canada)1
•EN 50081, EN 55022, Class B (EU Countries) 1
•EN 55022, Class B (Eastern Europe (ISE) Countries) 1
•M of C, Class A (Korea)
•VCCI, CISPR 22 Class B ITE (Japan)1
•AS/NZS 3548 - EN 55022B (Australia/ New Zealand)
•BCIQ, Class A (Taiwan)
•GOST 29216 (Russia)
Electromagnetic Immunity Generic Immunity (EN 50082-1, EU countries), including:
•ESD, IEC-801-2:1984, 4KV Contact, 8KV Air
•Radiated Immunity, IEC-801-3:1984:
3V/m, 80% AM Mod, 27MHz–1000MHz
•EFT, IEC-801-4:1988 1.0KV Power, 0.5KV I/O lines
Safety •UL 1950 (File E139742) (USA and Canada)
•EN 60950 (International)
•NOM (Mexico)
1Class A for Pentium III 500MHz and 550MHz processors.

6
specifications
HP NetServer LC 3
Accessories
Product Accessory1Product No.
Memory •64MB 100MHz ECC SDRAM DIMM
•128MB 100MHz ECC SDRAM DIMM
•256MB 100MHz ECC SDRAM DIMM
•1MB Video RAM
D6097A
D6098A
D6099A
D4219A
Processors •Pentium II 450MHz, 512KB L2 cache
•Pentium III 500MHz, 512KB L2 cache
•Pentium III 550MHz, 512KB L2 cache
D7032A
D7129A
D8583A
Internal Storage •4.2GB Ultra/Wide SCSI disk drive (7,200rpm)
•9.1GB Ultra/Wide SCSI disk drive (7,200rpm)
•18.26GB Ultra/Wide SCSI disk drive (7,200rpm)
•9.1GB Ultra/Wide SCSI disk drive (10,000rpm)
•4.2GB hot-swap Ultra/Wide SCSI disk drive (7,200rpm)
•4.2GB hot-swap Ultra/Wide SCSI disk drive (10,000rpm)
•9.1GB hot-swap Ultra/Wide SCSI disk drive (7,200rpm)
•9.1GB hot-swap Ultra/Wide SCSI disk drive (10,000rpm)
•18.2GB hot-swap Ultra/Wide SCSI disk drive (7,200rpm)
D4910A
D4911A
D7176A
D7049A
D3583C
D4903A
D4289A
D6019A
D5039A
Disk Controllers & SCSI Cables •HP NetRAID-1 Disk Array Controller (1 channel)
•HP NetRAID-3Si I2O Disk Array Controller (3 channels)
•HP Ultra/Wide SCSI PCI Controller
•2.5m SCSI Cable to connect from HP NetRAID Family Controller
to External Storage2
•HP NetServer LC 3 Internal SCSI Cable Kit3
D4992A
D5955A
D5025A
D6020A
D5968A
External Storage Solutions •HP NetServer Rack Storage/6
•HP NetServer Rack Storage/12 (Ultra2 SCSI)
•HP NetServer Rack Storage/12 SCSI Card
D3604B
D5989A
D6025A
Backup Devices4•Internal HP SureStore T20i Travan TR-5 tape drive
•Internal HP SureStore DAT8i DDS-2 tape drive
•Internal HP SureStore DAT24i DDS-3 tape drive
•Internal HP SureStore DLT 40i DLT 4000 tape drive
•External HP SureStore T20e Travan TR-5 tape drive
•External HP SureStore DAT8e DDS-2 tape drive
•External HP SureStore DAT24e DDS-3 tape drive
•External HP SureStore DLT 40e DLT 4000 tape drive
•External HP SureStore DAT24x6e DDS-3 Autoloader
C4394A
C1528J
C1555C
C5647A
C4395A
C1529J5
C1556C5
C5679A
C1559B
Network Interface Cards •HP NetServer 10/100TX PCI LAN adapter
•HP DeskDirect 10/100VG PCI LAN adapter D5013A J2585B

7
specifications
HP NetServer LC 3
Accessories
Product Accessory1Product No.
Remote Management •Integrated HP Remote Assistant
•HP TopTools Remote Control card
•Optional AC adapter for HP TopTools Remote Control card
Included
D6028A
D6138A
Uninterruptible Power Supply UPS devices are available from American Power Conversion (APC).
For additional information, contact your local APC reseller, or see
APC’s Web page at http://www.apcc.com.
Upgrades •HP NetServer LC II to LC 3 upgrade kit6D6135A
Monitors •HP 50 15" Color Monitor
•HP M500 15" Color Monitor
•HP 70 17" Color Monitor
•HP M700 17" Color Monitor
D2826A
D2832A
D2837A
D2838A
Disk Tray •3.5-inch hard disk drive mounting trays (3-pack, non-hot-swap)
•Tape/DAT/CD-ROM mounting trays (3-pack, no front panel)
•Hot-swap disk mounting tray (for selected third-party drives)
D2198A
D2199A
D3349B
HP NetServer Racks7•2-meter rack with side panels and rear door
•2-meter rack only
•HP NetServer LC II/LC 3 rackmount kit
J1487B
J1488A
J1456B
HP SupportPack Offering
Support can be delivered either by your local reseller or by the Hewlett-Packard Customer Support organization. For more
information, visit our Web site at www.hp.com/go/netserver.
HP SupportPack Order No.
3-year onsite support, 4-hour response (standard business hours) H5519A
3-year onsite support, 4-hour response (24 hours/day, 7 days/week) H5513A
3-year onsite support, Hardware Call-to-Repair Commitment service within a maximum of 6 hours H1820A
Onsite installation and network configuration H5751A
Comprehensive Technical Support H1847A
1 Please see the
HP NetServers Configuration Guide
for important technical information when choosing your
accessories.
22.5m SCSI Cable 68-pin male ultra-high-density offset connector to 68-pin male high-density connector.
3Use in HP NetServer LC 3 when HP NetRAID Family Controller is used with internal storage.
4 HP SureStore offers a complete range of tape backup solutions for HP NetServers. For more information on
HP SureStore tape backup products, please check the
HP NetServers Configuration Guide
or go to the HP
SureStore Web site at http://ww.hp.com/storage.
5 One-Button Disaster Recovery will be available with these backup devices May 1, 1999.
6 HP NetServer LC II to LC 3 upgrade kit includes system board and 64MB 100MHz ECC SDRAM
7 For additional rack accessories and kits, please see the
HP NetServer Rack Configuration Guide
or
http://www.hp.com/netserver/products/racks. Use HP NetServer Rack Assistant to
configure your complete rackmounted solution.

8
specifications
HP NetServer LC 3
LC 3 Hot-Swap Drive Model
8S WR  3HQWLXP ,, 0+] 0+] RU
3HQWLXP ,,, 0+] 0+] SURFHVVRUV ZLWK
.% LQWHJUDWHG ZULWHEDFN (&& FDFKH
 +DOIKHLJKW
KRWVZDS VKHOYHV
8S WR *% WRWDO (&&
6'5$0 ',00 PHPRU\

9
specifications
HP NetServer LC 3
For the latest information
HP NetServer Web site http://www.hp.com/go/netserver
HP NetServer FTP Site ftp://ftp.hp.com/pub/servers
HP Fax Response system 1-208-344-4809
(available worldwide, fax only)
Specifications
Operating Temperature 41 to 95 degrees F (5 to 35 degrees C)
Operating Humidity 20% to 80% noncondensing
Acoustic Emissions Sound pressure (LpA): <55 dB(A), bystander position
Power Supply Auto-ranging 90 to 240 VAC at 47–63Hz
Power Availability 350W maximum
Power Consumption 470W; recommended UPS 700VA and 1000VA
System Dimensions 21.7"H x 8.5"W x 20.8"D (552mm H x 217mm W x 527mm D)
System Weight 46-60lbs (21-27.5kg), depending on configuration
Choose Your HP NetServer LC 3
Model Storage Processor ECC Memory HDD Product No*
HP NetServer LC 3 PII/400 Model 1 Hot-Swap Pentium II 400MHz 64MB None D6125A
HP NetServer LC 3 PII/400 Model 4 Hot-Swap Pentium II 400MHz 64MB 4.2GB D6126T
HP NetServer LC 3 PII/450 Model 1 Hot-Swap Pentium II 450MHz 64MB None D7028A
HP NetServer LC 3 PII/450 Model 9 Hot-Swap Pentium II 450MHz 64MB 9.1GB D7030T
HP NetServer LC 3 PIII/500 Model 1 Hot-Swap Pentium III 500MHz 64MB None D7126A
HP NetServer LC 3 PIII/550 Model 1 Hot-Swap Pentium III 550MHz 64MB None D8591A
* Product availability varies from country to country. Please check with your reseller for details.
IBM and OS/2 are registered trademarks of IBM Corporation. Intel and Pentium are U.S. registered trademarksof, and Xeon is a trademark of, Intel Corporation.
Microsoft and Windows NT are registered trademarks of Microsoft Corporation. Novell and NetWare are registered trademarks of, and IntranetWare is a
trademark of, Novell, Inc. OpenView is a trademark of
Hewlett-Packard Company. SCO and UnixWare are registered trademarks of, and OpenServer is a trademark of, The Santa Cruz Operation. All other brand
names are trademarks of their respective owners.
Information in this document is subject to change without notice.
© Copyright Hewlett-Packard Company 1999. All Rights Reserved. Reproduction, adaptation, or translation without priorwritten permission is prohibited, except
as allowed under the copyright laws.
Printed in USA M0599
HP Select Express Program:
HP NetServer LC 3 is also available through
HP Select Express Program. This program
offers custom integration of HP hardware
offered at HP’s lowest price. For more
information visit our Web site at:
http://www.hp.com/netserver/products/sep.
