HP ProLiant DL165 User instructions

Hot Plug SAS/SATA or Non-Hot Plug SATA Models
Hot Plug SAS/SATA or Non-Hot Plug SATA ModelsHot Plug SAS/SATA or Non-Hot Plug SATA Models
Hot Plug SAS/SATA or Non-Hot Plug SATA Models
Front View:
Front View:Front View:
Front View: Rear View:
Rear View:Rear View:
Rear View:
1. Access panel 1. Power supply cable socket
2. Memory banks 2. PS/2 mouse port
3. Two (2) AMD Opteron 2300 series processors 3. PS/2 keyboard port
4. Power supply 4. Two (2) RJ45 GbE LAN ports
5. PCI-E expansion riser 5. Rear panel USB 2.0 ports
6. System fans 6. Lights-Out 100 10/100Mbps port
7. Optical drive bay 7. Video port
8. Front-panel USB 2.0 ports 8. Serial port
9. Power switch/system status LEDs 9. Low-profile slot cover (slot only accessible in G5 system)
10. Optional 3rd and 4th 3.5" hot-plug SAS/SATA or non-hot
plug SATA hard drive bays
10. Full-sized riser board assembly slot cover
11. Standard 1st and 2nd 3.5" hot-plug SAS/SATA or non-hot
plug SATA hard drive bays
12. Full height/full length PCI-Express or HTX slot
What's New
What's NewWhat's New
What's New
Support for SATA Hot Plug 3.5" Midline (MDL) Solid State Drives
Support for SAS Hot Plug 3.5" Enterprise (ENT) Hard Drives
At A Glance
At A GlanceAt A Glance
At A Glance
Introducing the HP ProLiant DL165G5p, now available with the latest high performance Opteron Quad Core processors, increased
storage by 2X and a new high efficiency power supply option.
Processors
ProcessorsProcessors
Processors :
Supports up to two AMD Opteron™ 2300 series Quad-Core processors
Supports DirectConnect Architecture
Supports Power Now
Memory
MemoryMemory
Memory :
16 DIMM slots supporting up to 64GB REG PC2-6400 DDR2-800 MHz memory with Advanced ECC
16 DIMM slots supporting up to 128GB REG PC2-5300 DDR2-667 MHz memory with Advanced ECC
Internal Drive Support
Internal Drive SupportInternal Drive Support
Internal Drive Support :
QuickSpecs
HP ProLiant DL165 Generation 5p (G5p)
HP ProLiant DL165 Generation 5p (G5p)HP ProLiant DL165 Generation 5p (G5p)
HP ProLiant DL165 Generation 5p (G5p)
Overview
DA - 13204 North America — Version 9 — November 16, 2009 Page 1

Internal storage capacity:
SATA Capacity: Support for up to 4.0TB (4 x 1TB) in Hot Plug Model. Support for up to 3.0TB (4x750GB) in Non
Hot Plug Model.
SAS Capacity: Support for up to 4.0 TB (4 x 1TB) in Hot Plug Model
NOTE:
NOTE:NOTE:
NOTE: Installation of the Hot Plug Backplane 1U 2S Kit (445985-B21) is required if ordering third or fourth
Hard Drives for Hot Plug models only.
Network Controller
Network ControllerNetwork Controller
Network Controller :
Embedded HP NC362i Integrated Dual Port Gigabit Server Adapter
Storage Controllers
Storage ControllersStorage Controllers
Storage Controllers :
Non-Hot Plug SATA Models: HP Embedded SATA Controller
Hot Plug SATA/SAS Models: HP SC40Ge SAS HBA with RAID 0,1
NOTE:
NOTE:NOTE:
NOTE: When using the SC40Ge with SATA Hard Drives, 1.5G SATA Hard Drives are required.
Expansion Slots
Expansion SlotsExpansion Slots
Expansion Slots :
Standard - PCI-Express assembly includes:
Slot 1: full-length/full height PCI-Express x16
Infrastructure Management
Infrastructure ManagementInfrastructure Management
Infrastructure Management :
HP ProLiant Lights Out 100i Remote Management support (IPMI 2.0 and SMASH support)
Virtual Media plus Virtual KVM support with LO100i Advanced license
HP Insight Control for Linux (IC-Linux), a product option, delivers essential infrastructure management that can help
save time and money by making it easy to deploy, monitor, control and optimize your IT infrastructure through a single,
simple management console. HP Insight Control for Linux supports Linux-based servers and management consoles.
USB Ports
USB PortsUSB Ports
USB Ports :
Up to five USB ports (two front & two rear standard, 1 internal option)
Optical Drive
Optical DriveOptical Drive
Optical Drive :
Support for one (optional): DVD-ROM, DVD/CD RW
Power Supply
Power SupplyPower Supply
Power Supply :
650W Power Supply standard (Non-Hot Plug, Autoswitching)
Form Factor
Form FactorForm Factor
Form Factor :
Rack (1U)
Fixed mounting rails included with all models
Deployment/Serviceability
Deployment/ServiceabilityDeployment/Serviceability
Deployment/Serviceability :
Tool-less access to all system components for easy in-rack serviceability
Customer Self Repair (CSR): HP products are designed with many CSR parts to minimize repair time and allow for
greater flexibility in performing defective parts replacement
Warranty
WarrantyWarranty
Warranty :
This product is covered by a global limited warranty and supported by HP Services and a worldwide network of HP
Authorized Channel Partners. Hardware diagnostic support and repair is available for one year from date of purchase.
Support for software and initial setup is available for 90 days from date of purchase. Enhancements to warranty services
are available through HP Care Pack services or customized service agreements. Hard drives have either a one year or
three year warranty; refer to the specific hard drive QuickSpecs for details.
NOTE:
NOTE:NOTE:
NOTE: Server Warranty includes 1 year Parts, 1 year Labor, 1-year on-site support with next business day response.
Warranty repairs may be accomplished through the use of Customer Self Repair (CSR) parts. These parts fall into two
categories: 1) Mandatory CSR parts are designed for easy replacement. A travel and labor charge will result when
customers decline to replace a Mandatory CSR part; 2) Optional CSR parts are also designed for easy replacement but
may involve added complexity. Customers may choose to have HP replace Optional CSR parts at no charge. Additional
information regarding worldwide limited warranty and technical support is available at:
http://h18004.www1.hp.com/products/servers/platforms/warranty/index.html
QuickSpecs
HP ProLiant DL165 Generation 5p (G5p)
HP ProLiant DL165 Generation 5p (G5p)HP ProLiant DL165 Generation 5p (G5p)
HP ProLiant DL165 Generation 5p (G5p)
Overview
DA - 13204 North America — Version 9 — November 16, 2009 Page 2

NOTE:
NOTE:NOTE:
NOTE: For the Standard Features shipped in the "Factory Integrated Models", please see the "Configuration Information - Factory
Integrated Models" section.
Processor
ProcessorProcessor
Processor
One of the following
depending on Model
AMD Opteron™ processor Model 2393SE (3.1GHz, 105W ACP)
AMD Opteron™ processor Model 2389 (2.9GHz, 75W ACP)
AMD Opteron™ processor Model 2384 (2.7GHz, 75W ACP)
AMD Opteron™ processor Model 2381HE (2.5GHz, 55W ACP)
AMD Opteron™ processor Model 2380 (2.5GHz, 75W ACP)
AMD Opteron™ processor Model 2377EE (2.3GHz, 50W ACP)
AMD Opteron™ processor Model 2376 HE (2.3GHz, 55W ACP)
NOTE:
NOTE:NOTE:
NOTE: Offered through Configure-To-Order only. See Factory Integrated Models section for more
details.
AMD Opteron™ processor Model 2376 (2.3GHz, 75W ACP)
AMD Opteron™ processor Model 2374 HE (2.2GHz, 55W ACP)
Upgradeability
UpgradeabilityUpgradeability
Upgradeability Upgradeable to two processors
Chipset
ChipsetChipset
Chipset ServerWorks HT2100 and HT1000
Cache Memory
Cache MemoryCache Memory
Cache Memory 6MB shared L3 cache
Memory Protection
Memory ProtectionMemory Protection
Memory Protection Advanced ECC
Memory
MemoryMemory
Memory
One of the following
depending on Model
Type REG PC2-6400 DIMMs (DDR2-667)
REG PC2-5300 DIMMs (DDR2-667)
NOTE:
NOTE:NOTE:
NOTE: DIMM banks are active only when the corresponding processor
socket is populated.
Standard
(Model 2376)
2 GB (2 x 1 GB)
Standard
(Model 2380)
4 GB (2 x 2 GB)
Standard
(Model 2384)
8 GB (4 x 2 GB)
Maximum 64 GB (16 x 4 GB)
Network Controller
Network ControllerNetwork Controller
Network Controller Embedded NC362i dual-port gigabit server adapter
QuickSpecs
HP ProLiant DL165 Generation 5p (G5p)
HP ProLiant DL165 Generation 5p (G5p)HP ProLiant DL165 Generation 5p (G5p)
HP ProLiant DL165 Generation 5p (G5p)
Standard Features
DA - 13204 North America — Version 9 — November 16, 2009 Page 3

Expansion Slots #
Expansion Slots #Expansion Slots #
Expansion Slots # Technology
TechnologyTechnology
Technology Bus Width
Bus WidthBus Width
Bus Width ** Connector
ConnectorConnector
Connector
Width
WidthWidth
Width
Bus Number
Bus NumberBus Number
Bus Number * Form Factor
Form FactorForm Factor
Form Factor Notes
NotesNotes
Notes
1 PCI Express x16 x16 3 Full Height/Full
Length
* Default bus assignment. Inserting cards with PCI bridges may alter the actual bus assignment number.
** Slots are enumerated differently based on OS. MS OS's enumerate from lowest to highest Device ID
by bus (starting with the lowest bus).
Storage Controller
Storage ControllerStorage Controller
Storage Controller Non-Hot Plug SATA HP Embedded SATA Controller
Hot Plug SATA/SAS HP SC40Ge SAS HBA with RAID 0,1
NOTE:
NOTE:NOTE:
NOTE: When using the SC40Ge with SATA Hard Drives, 1.5G SATA Hard
Drives are required.
NOTE:
NOTE:NOTE:
NOTE: A diskette drive is needed to install storage controller drivers during a Windows operating system
installation from CD.
Storage
StorageStorage
Storage Diskette Drives Via USB only
Optical Drives Optional 8x IDE (ATAPI) DVD-ROM drive, slim
Optional 24x IDE (ATAPI) DVD-ROM/CDRW drive
Hard Drives Up to 4 Non-hot plug SATA 3.5" drives
Up to 4 Hot plug SATA /SAS 3.5" drives
Maximum Internal
Maximum InternalMaximum Internal
Maximum Internal
Storage
StorageStorage
Storage
Non-Hot Plug SATA 3.0TB 4 x 750GB
Hot Plug SATA 4.0TB 4 x 1TB
Hot Plug SAS 4.0TB 4 x 1TB
Interfaces
InterfacesInterfaces
Interfaces Parallel None
Network RJ-45(Ethernet) HP NC362i Integrated Dual Port Gigabit Server Adapter
Serial 1
Pointing Device (Mouse) 1
Graphics 1
Keyboard 1
USB Up to 5 (two front & two rear standard, 1 internal option)
NOTE:
NOTE:NOTE:
NOTE: Please see the following URL for additional information regarding
USB support:
http://h18004.www1.hp.com/products/servers/platforms/usb-support.html .
Graphics
GraphicsGraphics
Graphics 32MB shared supporting 1600x1200x16M resolution
Form Factor
Form FactorForm Factor
Form Factor Rack (1U), (1.75 in/4.45 cm)
QuickSpecs
HP ProLiant DL165 Generation 5p (G5p)
HP ProLiant DL165 Generation 5p (G5p)HP ProLiant DL165 Generation 5p (G5p)
HP ProLiant DL165 Generation 5p (G5p)
Standard Features
DA - 13204 North America — Version 9 — November 16, 2009 Page 4

Remote Management
Remote ManagementRemote Management
Remote Management Lights-Out 100i HP Lights-Out 100i Remote Management delivers affordable, entry level
remote management capabilities for HP ProLiant 100 Series servers with
embedded LO100i. It allows customers or their service providers to remotely
manage ProLiant 100 Series servers remotely over a LAN or the Internet and
consists of the following:
LO100i Standard
LO100i StandardLO100i Standard
LO100i Standard is embedded remote management and provides
basic remote control via telnet, browser, and IPMI 2.0 and SMASH
and comes standard on all DL100 series servers except for the DL180
G1 and G5 and the DL120 G5 servers.
LO100i Advanced Pack
LO100i Advanced PackLO100i Advanced Pack
LO100i Advanced Pack License are upgrades for essential, secure,
remote control, serial console and virtual media plus Virtual KVM
(graphical hardware-based, remote console).
NOTE:
NOTE:NOTE:
NOTE: Flexible and volume quantity (AKA) license kits are available for the
Lights-Out 100i Advanced Pack licenses as well as Electronic License To Use
(E-LTU). AKA Tracking licenses require a 100 unit minimum forecast at initial
contract signing. For these additional part numbers, please refer to each
software products. QuickSpecs at this link for more information:
www.hp.com/go/lo100
Core Infrastructure
Core InfrastructureCore Infrastructure
Core Infrastructure
Management
ManagementManagement
Management
HP Insight Control for
Linux
HP Insight Control for Linux, as a product option, delivers essential
infrastructure management that can help save time and money by making it
easy to deploy, monitor, remote control, and optimize your IT infrastructure
through a single, simple management console. The Insight Control for Linux
suite installs and license software modules that are integrated into HP System
Insight Manager.
The HP Insight Control suite for Linux (IC-Linux) serves environments
requiring a Linux-based management consoles. See www.hp.com/go/ic-linux
HP Insight Control suites include one year of 24 x 7 HP Software Technical
Support and Update Service ensuring rapid access to HP support staff and
proactive delivery of software updates. For more information about this
service, please visit: www.hp.com/services/insight .
Insight Control server
deployment
HP Insight Control server deployment is a deployment solution for HP
ProLiant and Integrity servers hosted on a Windows CMS. It automates the
process of deploying and provisioning server software, enabling companies
to quickly and easily adapt to changing business demands. Insight Control
server deployment includes software optimizations for HP servers, including
the HP scripting toolkits, configuration jobs for leading industry-standard
operating systems, sample unattended files, and HP server support packs that
include software drivers, management agents, and important documentation.
Deploying servers can be accomplished either through imaging or through
scripting.
Insight Control server deployment is hosted on a Windows server and is
intended for heterogeneous environments deploying Windows, Linux,
VMware ESX and Microsoft Hyper-V systems.
Insight Control server deployment includes one year of 24 x 7 HP Software
QuickSpecs
HP ProLiant DL165 Generation 5p (G5p)
HP ProLiant DL165 Generation 5p (G5p)HP ProLiant DL165 Generation 5p (G5p)
HP ProLiant DL165 Generation 5p (G5p)
Standard Features
DA - 13204 North America — Version 9 — November 16, 2009 Page 5

Technical Support and Update Service ensuring rapid access to HP support
staff and proactive delivery of software updates. For more information about
this service, please visit: http://www.hp.com/services/insight .
Industry Standard
Industry StandardIndustry Standard
Industry Standard
Compliance
ComplianceCompliance
Compliance
ACPI V2.0 Compliant
PCI 2.2 Compliant
PXE Support
WOL Support
Microsoft® Logo certifications
IPMI 2.0, SMASH CLP Compliant
Manageability
ManageabilityManageability
Manageability Embedded HP ProLiant Lights-Out 100i Remote Management, with licensable upgrades to Lights-Out
100i Advanced.
Security
SecuritySecurity
Security Power-on password
Setup password
UPS and PDU Power
UPS and PDU PowerUPS and PDU Power
UPS and PDU Power
Cord Matrix
Cord MatrixCord Matrix
Cord Matrix
Please see the UPS and PDU cable matrix's on the HP Power Protection and Management page. Under
Power Cords, click on the "HP Power Cord Matrix" link. That link will list cable descriptions, requirements,
and specifications for UPS and PDU units. Please see the following link:
www.hp.com/products/powercords .
Power Supply
Power SupplyPower Supply
Power Supply 650 Watts, auto-switching, PFC (Power Factor Correcting)
System Fans
System FansSystem Fans
System Fans 6 system fans ship standard; non-hot plug, non-redundant
Operating Systems and
Operating Systems andOperating Systems and
Operating Systems and
Virtualization Software
Virtualization SoftwareVirtualization Software
Virtualization Software
Support for ProLiant
Support for ProLiantSupport for ProLiant
Support for ProLiant
Servers
ServersServers
Servers
Microsoft Windows Server
Microsoft Windows Server Hyper-V
Red Hat Enterprise Linux (RHEL)
SUSE Linux Enterprise Server (SLES)
Solaris 10 for x86/x64 based Systems
NOTE:
NOTE:NOTE:
NOTE: For more information on HP's Certified and Supported ProLiant Servers for OS and Virtualization
Software and latest listing of software drivers available for your server, please visit our Support Matrix at:
http://www.hp.com/go/supportos our driver download page http://www.hp.com/support/DL165G5p
QuickSpecs
HP ProLiant DL165 Generation 5p (G5p)
HP ProLiant DL165 Generation 5p (G5p)HP ProLiant DL165 Generation 5p (G5p)
HP ProLiant DL165 Generation 5p (G5p)
Standard Features
DA - 13204 North America — Version 9 — November 16, 2009 Page 6

Rack Airflow
Rack AirflowRack Airflow
Rack Airflow
Requirements
RequirementsRequirements
Requirements
Rack 10000 G2 series Cabinets
Rack 10000 G2 series CabinetsRack 10000 G2 series Cabinets
Rack 10000 G2 series Cabinets
The increasing power of new high-performance processor technology requires increased cooling
efficiency for rack-mounted servers. The 10000 G2 Series Racks provide enhanced airflow for maximum
cooling, allowing these racks to be fully loaded with servers using the latest processors.
CAUTION:
CAUTION:CAUTION:
CAUTION: If a third-party rack is used, observe the following additional requirements to ensure
adequate airflow and to prevent damage to the equipment:
Front and rear doors: If your 42U server rack includes closing front and rear doors, you must allow
5,350 sq cm (830 square inches) of hole evenly distributed from top to bottom to permit adequate
airflow (equivalent to the required 64 percent open area for ventilation).
Side: The clearance between the installed rack component and the side panels of the rack must be a
minimum of 7 cm (2.75 inches)
CAUTION:
CAUTION:CAUTION:
CAUTION: Always use blanking panels to fill all remaining empty front panel U-spaces in the rack. This
arrangement ensures proper airflow. Using a rack without blanking panels results in improper cooling
that can lead to thermal damage.
Rack Support
Rack SupportRack Support
Rack Support The DL Fixed Rail System supports installation in racks with square or round mounting holes (including
Compaq/HP 7000, 9000, 10000 and HP series), with an adjustment range of 24" - 36".
Telco Rack Kit
Telco Rack KitTelco Rack Kit
Telco Rack Kit Installation into Telco 2 post, and 4 post, or threaded holes racks requires a 3rd party option kit. For
additional information, please visit: www.hp.com/go/rackandpower .
HP Factory Express
HP Factory ExpressHP Factory Express
HP Factory Express
Capability
CapabilityCapability
Capability
HP Factory Express offers configuration, customization, integration and deployment services for HP
servers and storage products. Customers can choose how their factory solutions are built, tested,
integrated, shipped and deployed.
Factory Express offers service packages for simple configuration, racking, installation, complex
configuration and design services as well as individual factory services, such as image loading, asset
tagging, and custom packaging. HP products supported through Factory Express include a wide array of
servers and storage: HP Integrity, HP ProLiant, HP ProLiant Server Blades, HP BladeSystem, HP 9000
servers as well as the MSAxxxx, VA7xxx, EVA, XP, rackable tape libraries and configurable network
switches.
For more information on Factory Express services for your specific server model please contact your sales
representative or go to: http://www.hp.com/go/factory-express .
HP Enterprise
HP EnterpriseHP Enterprise
HP Enterprise
Configurator
ConfiguratorConfigurator
Configurator
The HP eConfigure Enterprise Configurator now provides factory default racking for our HP hardware
portfolio. This approach is aligned with our strategic direction to meet the needs and expectations of our
valued customers. If you require "custom" rack configuration, please contact HP's Customer Business
Center or an Authorized Partner for assistance.
QuickSpecs
HP ProLiant DL165 Generation 5p (G5p)
HP ProLiant DL165 Generation 5p (G5p)HP ProLiant DL165 Generation 5p (G5p)
HP ProLiant DL165 Generation 5p (G5p)
Standard Features
DA - 13204 North America — Version 9 — November 16, 2009 Page 7

Service and Support
Service and SupportService and Support
Service and Support HP Care Pack Services provide total care and support expertise with committed response designed to
meet your IT and business needs.
HP Care Pack services include coverage for the HP branded hardware options qualified for the server
that are purchased at the same time or afterward and internal to the enclosure. It also includes the 22"
and smaller external monitors and tower UPS options up to 3kVA. These items will be covered at the
same service level and for the same coverage period as the server. Coverage of UPS Battery is not
included and standard warranty terms & conditions apply. For servers or storage systems installed within
a rack, service also covers all HP qualified rack options installed within the same rack.
To fully capitalize on your HP ProLiant servers' capabilities requires a service partner who thoroughly
understands your server technology and systems environment. HP Services, an industry leader in
provision of multi vender support solutions provides a range of support services designed to meet the
varying needs of business. Whether an SMB or large global corporation HP has a ProLiant server support
offer to help you speedily deploy and maximize system uptime.
Recommended Service
Recommended ServiceRecommended Service
Recommended Service - Simplify ProLiant solution implementation, maintenance and management.
Support Service
Support ServiceSupport Service
Support Service -3 Year, 9x5 Next Business Day coverage, excluding HP holidays only
Deployment Service
Deployment ServiceDeployment Service
Deployment Service - Hardware Installation only
Enhanced Service
Enhanced ServiceEnhanced Service
Enhanced Service - Optimize service level to increase IT performance and availability
Support Service
Support ServiceSupport Service
Support Service - 3 Year 13x5 Same Business Day, 4-Hour response coverage
Deployment Service
Deployment ServiceDeployment Service
Deployment Service - Installation and Start-up only
Installation & Start-Up of a ProLiant server and Microsoft or Linux O/S per the Customer Description
and/or Data Sheet. To be delivered on a scheduled basis 8am-5pm, M-F, excl. HP holidays.
For a complete listing of service offerings and information visit:
http://www.hp.com/services/proliantservices
http://h20219.www2.hp.com/services/us/en/warranty/carepack-servers-proliant.html
QuickSpecs
HP ProLiant DL165 Generation 5p (G5p)
HP ProLiant DL165 Generation 5p (G5p)HP ProLiant DL165 Generation 5p (G5p)
HP ProLiant DL165 Generation 5p (G5p)
Standard Features
DA - 13204 North America — Version 9 — November 16, 2009 Page 8

NOTE:
NOTE:NOTE:
NOTE: High Performance Computing (HPC) interconnect technologies are available for the DL165 G5p under the Cluster Platform
product portfolio. These high-speed interconnects are fully supported by HP when they are part of these configure to order clusters.
Solutions can be defined with a lot of flexibility with the help of configuration tools. Please visit the following URL to configure HPC
Clusters with InfiniBand, Gigabit Ethernet or Myrinet Interconnects: http://www.hp.com/techservers/clusters/ucp/index.html
HPC Interconnects
HPC InterconnectsHPC Interconnects
HPC Interconnects InfiniBand
InfiniBandInfiniBand
InfiniBand PCI-Express adapters
Gigabit Ethernet
Gigabit EthernetGigabit Ethernet
Gigabit Ethernet Use embedded ports or optional 10GbE NICs
QuickSpecs
HP ProLiant DL165 Generation 5p (G5p)
HP ProLiant DL165 Generation 5p (G5p)HP ProLiant DL165 Generation 5p (G5p)
HP ProLiant DL165 Generation 5p (G5p)
HPC Interconnects
DA - 13204 North America — Version 9 — November 16, 2009 Page 9

Non-Hot Plug Serial ATA (SATA) Models
Non-Hot Plug Serial ATA (SATA) ModelsNon-Hot Plug Serial ATA (SATA) Models
Non-Hot Plug Serial ATA (SATA) Models
Entry Model
Entry ModelEntry Model
Entry Model
HP DL165 G5p 2376 2.3
HP DL165 G5p 2376 2.3HP DL165 G5p 2376 2.3
HP DL165 G5p 2376 2.3
GHz, 2GB, Non-Hot Plug
GHz, 2GB, Non-Hot PlugGHz, 2GB, Non-Hot Plug
GHz, 2GB, Non-Hot Plug
SATA (1P)
SATA (1P)SATA (1P)
SATA (1P)
507549-001
Efficiency Model
Efficiency ModelEfficiency Model
Efficiency Model
HP DL165 G5p 2374HE
HP DL165 G5p 2374HEHP DL165 G5p 2374HE
HP DL165 G5p 2374HE
2.2 GHz, 2GB LP, Non-
2.2 GHz, 2GB LP, Non-2.2 GHz, 2GB LP, Non-
2.2 GHz, 2GB LP, Non-
Hot Plug SATA (1P)
Hot Plug SATA (1P)Hot Plug SATA (1P)
Hot Plug SATA (1P)
507547-001
Processor(s)
Processor(s)Processor(s)
Processor(s)
One of the following
depending on model
(1) AMD Opteron™ processor Model 2376 (2.3 GHz, 75W ACP)
(1) AMD Opteron™ processor Model 2374HE (2.2 GHz, 55W ACP)
Cache Memory
Cache MemoryCache Memory
Cache Memory 6MB shared Level 3 cache
Memory
MemoryMemory
Memory
One of the following
depending on model
2GB (2 x 1GB) Registered PC2-6400 DDR2 DIMMs (800MHz) with
Advanced ECC capabilities
2GB (2 x 1GB) Low Power Registered PC2-5300 DDR2 DIMMs (667MHz)
with Advanced ECC capabilities
Network Controller
Network ControllerNetwork Controller
Network Controller HP NC362i Integrated Dual Port Gigabit Server Adapter
Storage Controller
Storage ControllerStorage Controller
Storage Controller HP Embedded SATA Controller
Hard Drive
Hard DriveHard Drive
Hard Drive (1) 160GB NHP SATA HDD
Internal Storage
Internal StorageInternal Storage
Internal Storage SATA: 3TB maximum
Optical Drive
Optical DriveOptical Drive
Optical Drive None Ships Standard (Optional DVD-ROM, DVD/CD RW)
Form Factor
Form FactorForm Factor
Form Factor Rack (1U)
Hot Plug Serial ATA (SATA)/Serial Attached SCSI (SAS) Models
Hot Plug Serial ATA (SATA)/Serial Attached SCSI (SAS) ModelsHot Plug Serial ATA (SATA)/Serial Attached SCSI (SAS) Models
Hot Plug Serial ATA (SATA)/Serial Attached SCSI (SAS) Models
Performance Model
Performance ModelPerformance Model
Performance Model
HP DL165G5p 2384 2.7
HP DL165G5p 2384 2.7HP DL165G5p 2384 2.7
HP DL165G5p 2384 2.7
GHz, 8 GB, Hot Plug (2P)
GHz, 8 GB, Hot Plug (2P)GHz, 8 GB, Hot Plug (2P)
GHz, 8 GB, Hot Plug (2P)
507551-001
Base Model
Base ModelBase Model
Base Model
HP DL165G5p 2380 2.5
HP DL165G5p 2380 2.5HP DL165G5p 2380 2.5
HP DL165G5p 2380 2.5
GHz, 4 GB, Hot Plug (1P)
GHz, 4 GB, Hot Plug (1P)GHz, 4 GB, Hot Plug (1P)
GHz, 4 GB, Hot Plug (1P)
507550-001
Processor(s)
Processor(s)Processor(s)
Processor(s)
One of the following
depending on model
(2) AMD Opteron™ processor Model 2384 (2.7 GHz, 75W ACP)
(1) AMD Opteron™ processor Model 2380 (2.5 GHz, 75W ACP)
Cache Memory
Cache MemoryCache Memory
Cache Memory 6MB shared Level 3 cache
Memory
MemoryMemory
Memory
One of the following
depending on model
4GB (4 x 2GB) Registered PC2-6400 DDR2 DIMMs (800MHz) with
Advanced ECC capabilities
4GB (2 x 2GB) Registered PC2-6400 DDR2 DIMMs (800MHz) with
Advanced ECC capabilities
Network Controller
Network ControllerNetwork Controller
Network Controller HP NC362i Integrated Dual Port Gigabit Server Adapter
Storage Controller
Storage ControllerStorage Controller
Storage Controller HP 4 Internal Port SAS HBA with RAID
Hard Drive
Hard DriveHard Drive
Hard Drive None ship standard (up to 4 Hot Plug SATA or SAS drives supported)
Internal Storage
Internal StorageInternal Storage
Internal Storage
One of the following
depending on model
SATA: 4.0TB Maximum
SAS: 4.0TB Maximum
Optical Drive
Optical DriveOptical Drive
Optical Drive None Ships Standard (Optional DVD-ROM, DVD/CD RW)
Form Factor
Form FactorForm Factor
Form Factor Rack (1U)
QuickSpecs
HP ProLiant DL165 Generation 5p (G5p)
HP ProLiant DL165 Generation 5p (G5p)HP ProLiant DL165 Generation 5p (G5p)
HP ProLiant DL165 Generation 5p (G5p)
Models
DA - 13204 North America — Version 9 — November 16, 2009 Page 10

NOTE:
NOTE:NOTE:
NOTE: This section lists some of the steps required to configure a Factory Integrated Model. To ensure only valid configurations are
ordered, HP recommends the use of an HP approved configurator. Contact your local sales representative for information on CTO
product offerings and requirements.
NOTE:
NOTE:NOTE:
NOTE: HP does not allow factory integration of options into standard models listed above. Configure-to-order servers must start
with a CTO Chassis.
NOTE:
NOTE:NOTE:
NOTE: FIO indicates that this option is only available as a Factory Installable Option.
Step 1: Base Configuration
Step 1: Base ConfigurationStep 1: Base Configuration
Step 1: Base Configuration
Non-Hot Plug SATA Model
Non-Hot Plug SATA ModelNon-Hot Plug SATA Model
Non-Hot Plug SATA Model
HP ProLiant DL165 G5p Non-Hot Plug SATA Rack Chassis 495842-B21
Factory Integrated Model ships with:
Factory Integrated Model ships with:Factory Integrated Model ships with:
Factory Integrated Model ships with:
HP NC362i Integrated Dual Port Gigabit Server Adapter
One available PCI-Express slots, including one full-length/full height slot
HP embedded SATA controller
650 Watt Power Supply
6 Fixed, Non-Redundant Fans
Rack (1U), (1.75 in / 4.45 cm)
Fixed Mounting Rails
Hot Plug SATA/SAS Model
Hot Plug SATA/SAS ModelHot Plug SATA/SAS Model
Hot Plug SATA/SAS Model
HP ProLiant DL165 G5p Hot Plug SATA/SAS Rack Chassis 495841-B21
Factory Integrated Model ships with:
Factory Integrated Model ships with:Factory Integrated Model ships with:
Factory Integrated Model ships with:
HP NC362i Integrated Dual Port Gigabit Server Adapter
One full-length/full height PCI-Express slot houses the SATA/SAS storage controller
650 Watt Power Supply
6 Fixed, Non-Redundant Fans
Rack (1U), (1.75 in / 4.45 cm)
Fixed Mounting Rails
Step 2: Choose Required Options (only one of the following from each list unless otherwise
Step 2: Choose Required Options (only one of the following from each list unless otherwiseStep 2: Choose Required Options (only one of the following from each list unless otherwise
Step 2: Choose Required Options (only one of the following from each list unless otherwise
noted)
noted)noted)
noted)
Processors
ProcessorsProcessors
Processors AMD Opteron™ processor Model 2393SE (3.1GHz, 105W ACP), FIO 500062-L21
AMD Opteron™ processor Model 2389 (2.9GHz, 75W ACP), FIO 500049-L21
AMD Opteron™ processor Model 2384 (2.7GHz, 75W ACP), FIO
NOTE:
NOTE:NOTE:
NOTE: If 2 processors are desired, select one 500064-L21 and one 500064-B21.
500064-L21
AMD Opteron™ processor Model 2381HE (2.5GHz, 55W ACP), FIO 500058-L21
AMD Opteron™ processor Model 2380 (2.5GHz, 75W ACP), FIO
NOTE:
NOTE:NOTE:
NOTE: If 2 processors are desired, select one 500060-L21 and one 500060-B21.
500060-L21
AMD Opteron™ processor Model 2377EE (2.3GHz, 50W ACP), FIO 536530-B21
AMD Opteron™ processor Model 2376 HE (2.3GHz, 55W ACP), FIO
NOTE:
NOTE:NOTE:
NOTE: If 2 processors are desired, select one 507540-L21 and one 507540-B21.
507540-L21
AMD Opteron™ processor Model 2376 (2.3GHz, 75W ACP), FIO
NOTE:
NOTE:NOTE:
NOTE: If 2 processors are desired, select one 500056-L21 and one 500056-B21.
500056-L21
QuickSpecs
HP ProLiant DL165 Generation 5p (G5p)
HP ProLiant DL165 Generation 5p (G5p)HP ProLiant DL165 Generation 5p (G5p)
HP ProLiant DL165 Generation 5p (G5p)
Configuration Information - Factory Integrated Models
DA - 13204 North America — Version 9 — November 16, 2009 Page 11

AMD Opteron™ processor Model 2374 HE (2.2GHz, 55W ACP), FIO
NOTE:
NOTE:NOTE:
NOTE: If 2 processors are desired, select one 500051-L21 and one 500051-B21.
500051-L21
Memory
MemoryMemory
Memory NOTE:
NOTE:NOTE:
NOTE: DIMM banks are active only when the corresponding processor socket is
populated.
2 GB REG PC2-6400 2 x 1 GB Kit 497763-B21
2 GB REG PC2-5300 2 x 1 GB Low Power Single Rank Kit 483399-B21
4 GB REG PC2-6400 2 x 2 GB Kit 497765-B21
4 GB REG PC2-5300 2 x 2 GB Low Power Single Rank Kit 483401-B21
8 GB REG PC2-6400 2 x 4 GB Kit 497767-B21
8 GB REG PC2-6400 2 x 4 GB Low Power Kit 504351-B21
8 GB REG PC2-5300 2 x 4 GB Low Power Dual Rank Kit 483403-B21
16 GB REG PC2-5300 2 x 8 GB Kit 408855-B21
Hard Drive
Hard DriveHard Drive
Hard Drive NOTE:
NOTE:NOTE:
NOTE: The components of a storage subsystem (e.g. the drive, the HBA/controller,
firmware, and the server backplane) should operate at the same data transfer rate or
the system bandwidth will be negotiated down to an acceptable level for all
components.
NOTE:
NOTE:NOTE:
NOTE: Hard drives have either a one year or three year warranty; refer to the specific
hard drive QuickSpecs for details.
Serial-ATA
Serial-ATASerial-ATA
Serial-ATA (SATA) Non-Hot Plug Hard Drives
Non-Hot Plug Hard DrivesNon-Hot Plug Hard Drives
Non-Hot Plug Hard Drives (Non-Hot Plug Models Only)
SATA Non-Hot Plug 3.5" Entry (ETY) Drives
SATA Non-Hot Plug 3.5" Entry (ETY) DrivesSATA Non-Hot Plug 3.5" Entry (ETY) Drives
SATA Non-Hot Plug 3.5" Entry (ETY) Drives
HP 160GB 3G SATA 7.2K NHP 3.5" ETY HDD 458947-B21
SATA Non-Hot Plug 3.5" Midline (MDL) Drives
SATA Non-Hot Plug 3.5" Midline (MDL) DrivesSATA Non-Hot Plug 3.5" Midline (MDL) Drives
SATA Non-Hot Plug 3.5" Midline (MDL) Drives
HP 750GB 3G SATA 7.2K NHP 3.5" MDL HDD 462595-B21
HP 500GB 3G SATA 7.2K NHP 3.5" MDL HDD 458941-B21
HP 250GB 3G SATA 7.2K NHP 3.5" MDL HDD 458939-B21
SATA Hot Plug 3.5" Midline (MDL) Solid State Drives
SATA Hot Plug 3.5" Midline (MDL) Solid State DrivesSATA Hot Plug 3.5" Midline (MDL) Solid State Drives
SATA Hot Plug 3.5" Midline (MDL) Solid State Drives
HP 60GB 3G SATA 3.5in MDL 1y Wty SSD 570761-B21
HP 120GB 3G SATA 3.5in MDL 1y Wty SSD 570763-B21
3.5" SATA Non-Hot Plug Drives
3.5" SATA Non-Hot Plug Drives3.5" SATA Non-Hot Plug Drives
3.5" SATA Non-Hot Plug Drives
HP 500GB 1.5G SATA 7.2K NHP 3.5" HDD, FIO 404469-B21
HP 250GB 1.5G SATA 7.2K NHP 3.5" HDD 411276-B21
HP 160GB 1.5G SATA 7.2K NHP 3.5" HDD 411275-B21
NOTE:
NOTE:NOTE:
NOTE: The previous generation of 1.5G SATA drives are still supported.
QuickSpecs
HP ProLiant DL165 Generation 5p (G5p)
HP ProLiant DL165 Generation 5p (G5p)HP ProLiant DL165 Generation 5p (G5p)
HP ProLiant DL165 Generation 5p (G5p)
Configuration Information - Factory Integrated Models
DA - 13204 North America — Version 9 — November 16, 2009 Page 12

Storage Controllers
Storage ControllersStorage Controllers
Storage Controllers NOTE:
NOTE:NOTE:
NOTE: Storage Controller only required if 445148-B21 is selected in Step 1 above.
HP Smart Array E500/256MB Controller with Battery, FIO
NOTE:
NOTE:NOTE:
NOTE: Customers can only order one Smart Array E500/256MB Controller and one
Battery-backed write cache upgrade (P/N 383280-B21) for the HP ProLiant DL165
G5p server based on battery space.
462105-B21
HP Smart Array E200/128 BBWC Controller 411508-B21
HP SC44Ge Host Bus Adapter
NOTE:
NOTE:NOTE:
NOTE: When using the SC44Ge with SATA Hard Drives, 1.5G SATA Hard Drives are
required.
416096-B21
HP SC40Ge SAS HBA, FIO
NOTE:
NOTE:NOTE:
NOTE: When using the SC40Ge with SATA Hard Drives, 1.5G SATA Hard Drives are
required.
449176-B21
HP SA-P400 and SA-E500 24 In Battery Cable Kit
NOTE:
NOTE:NOTE:
NOTE: This option kit contains a 24" battery cable and adhesive material for installing
a battery into the following servers if a Smart Array E500 is integrated outside of the
factory. For all solutions, please refer to the HP ProLiant QuickSpecs and User's
Manual for detailed installation instruction.
417836-B21
Battery-backed write cache
NOTE:
NOTE:NOTE:
NOTE: When installing a battery-backed write cache module, the HP Smart Array
E500 must be installed in the full-length PCI slot. 256MB Battery-backed write cache
upgrade for RAID 5 support.
383280-B21
Step 3: Choose Additional Factory Integratable Options
Step 3: Choose Additional Factory Integratable OptionsStep 3: Choose Additional Factory Integratable Options
Step 3: Choose Additional Factory Integratable Options
Backplane Option
Backplane OptionBackplane Option
Backplane Option Hot Plug HDD Backplane 1U 2S Kit
NOTE:
NOTE:NOTE:
NOTE: Installation of the Hot Plug Backplane 1U 2S Kit (445985-B21) is required if
ordering third or fourth Hard Drives for Hot Plug models only in Step 1 above.
445985-B21
Power Supplies
Power SuppliesPower Supplies
Power Supplies HP 1200W High Efficiency Power Supply Kit, FIO
NOTE:
NOTE:NOTE:
NOTE: Selection of the HE Power Supply Unit will remove the 650 Watt standard
power supply and requires the purchase of Power Supply Backplane (P/N 453652-
B21).
453650-B21
Power Options
Power OptionsPower Options
Power Options
Power Supply Backplane, FIO
NOTE:
NOTE:NOTE:
NOTE: This backplane must be ordered with the high efficiency power supply (P/N
453650-B21).
453652-B21
Step 4: Choose Additional Options for Factory Integration
Step 4: Choose Additional Options for Factory IntegrationStep 4: Choose Additional Options for Factory Integration
Step 4: Choose Additional Options for Factory Integration
NOTE:
NOTE:NOTE:
NOTE: For additional "Core Options" and "Additional Options", please refer to the options sections below.
QuickSpecs
HP ProLiant DL165 Generation 5p (G5p)
HP ProLiant DL165 Generation 5p (G5p)HP ProLiant DL165 Generation 5p (G5p)
HP ProLiant DL165 Generation 5p (G5p)
Configuration Information - Factory Integrated Models
DA - 13204 North America — Version 9 — November 16, 2009 Page 13

NOTE:
NOTE:NOTE:
NOTE: Some options may not be available for factory integration. Please contact an HP sales representative for additional
information.
Processor
ProcessorProcessor
Processor AMD Opteron™ processor Model 2393SE (3.1GHz, 105W ACP) 500062-B21
AMD Opteron™ processor Model 2389 (2.9GHz, 75W ACP) 500049-B21
AMD Opteron™ processor Model 2384 (2.7GHz, 75W ACP) 500064-B21
AMD Opteron™ processor Model 2381HE (2.5GHz, 55W ACP) 500058-B21
AMD Opteron™ processor Model 2380 (2.5GHz, 75W ACP) 500060-B21
AMD Opteron™ processor Model 2377EE (2.3GHz, 50W ACP) 536530-B21
AMD Opteron™ processor Model 2376 HE (2.3GHz, 55W ACP) 504540-B21
AMD Opteron™ processor Model 2376 (2.3GHz, 75W ACP) 500056-B21
AMD Opteron™ processor Model 2374 HE (2.2GHz, 55W ACP) 500051-B21
Memory (DIMMs)
Memory (DIMMs)Memory (DIMMs)
Memory (DIMMs) NOTE:
NOTE:NOTE:
NOTE: DIMM banks are active only when the corresponding processor socket is
populated.
2 GB REG PC2-6400 2 x 1 GB Kit 497763-B21
2 GB REG PC2-5300 2 x 1 GB Low Power Single Rank Kit 483399-B21
4 GB REG PC2-6400 2 x 2 GB Kit 497765-B21
4 GB REG PC2-5300 2 x 2 GB Low Power Single Rank Kit 483401-B21
8 GB REG PC2-6400 2 x 4 GB Kit 497767-B21
8 GB REG PC2-6400 2 x 4 GB Low Power Kit 504351-B21
8 GB REG PC2-5300 2 x 4 GB Low Power Dual Rank Kit 483403-B21
16 GB REG PC2-5300 2 x 8 GB Kit 408855-B21
Optical Drives
Optical DrivesOptical Drives
Optical Drives DVD-ROM Drive Optical Drive 447889-B21
DVD/CD RW Drive Optical Drive 447891-B21
Hard Drives
Hard DrivesHard Drives
Hard Drives NOTE:
NOTE:NOTE:
NOTE: The components of a storage subsystem (e.g. the drive, the HBA/controller,
firmware, and the server backplane) should operate at the same data transfer rate or
the system bandwidth will be negotiated down to an acceptable level for all
components.
NOTE:
NOTE:NOTE:
NOTE: Hard drives have either a one year or three year warranty; refer to the specific
hard drive QuickSpecs for details.
Serial-ATA
Serial-ATASerial-ATA
Serial-ATA (SATA) Non-Hot Plug Hard Drives
Non-Hot Plug Hard DrivesNon-Hot Plug Hard Drives
Non-Hot Plug Hard Drives (Non-Hot Plug Models Only)
SATA Non-Hot Plug 3.5" Midline (MDL) Drives
SATA Non-Hot Plug 3.5" Midline (MDL) DrivesSATA Non-Hot Plug 3.5" Midline (MDL) Drives
SATA Non-Hot Plug 3.5" Midline (MDL) Drives
HP 750GB 3G SATA 7.2K NHP 3.5" MDL HDD 462595-B21
HP 500GB 3G SATA 7.2K NHP 3.5" MDL HDD 458941-B21
HP 250GB 3G SATA 7.2K NHP 3.5" MDL HDD 458939-B21
SATA Non-Hot Plug 3.5" Entry (ETY) Drives
SATA Non-Hot Plug 3.5" Entry (ETY) DrivesSATA Non-Hot Plug 3.5" Entry (ETY) Drives
SATA Non-Hot Plug 3.5" Entry (ETY) Drives
HP 160GB 3G SATA 7.2K NHP 3.5" ETY HDD 458947-B21
Serial-ATA
Serial-ATASerial-ATA
Serial-ATA (SATA) Hot Plug Hard Drives
Hot Plug Hard DrivesHot Plug Hard Drives
Hot Plug Hard Drives (SATA/SAS Hot Plug Models Only)
SATA Hot Plug 3.5" Entry (ETY) Drives
SATA Hot Plug 3.5" Entry (ETY) DrivesSATA Hot Plug 3.5" Entry (ETY) Drives
SATA Hot Plug 3.5" Entry (ETY) Drives
QuickSpecs
HP ProLiant DL165 Generation 5p (G5p)
HP ProLiant DL165 Generation 5p (G5p)HP ProLiant DL165 Generation 5p (G5p)
HP ProLiant DL165 Generation 5p (G5p)
Core Options
DA - 13204 North America — Version 9 — November 16, 2009 Page 14

HP 160GB 3G SATA 7.2K 3.5" ETY HDD 458945-B21
SATA Hot Plug 3.5" Midline (MDL) Drives
SATA Hot Plug 3.5" Midline (MDL) DrivesSATA Hot Plug 3.5" Midline (MDL) Drives
SATA Hot Plug 3.5" Midline (MDL) Drives
HP 1TB 3G SATA 7.2K 3.5" MDL HDD 454146-B21
HP 750GB 3G SATA 7.2K 3.5" MDL HDD 458930-B21
HP 500GB 3G SATA 7.2K 3.5" MDL HDD 458928-B21
HP 250GB 3G SATA 7.2K 3.5" MDL HDD 458926-B21
NOTE:
NOTE:NOTE:
NOTE: Please see the QuickSpecs for Technical Specifications and additional
information:
http://h18000.www1.hp.com/products/quickspecs/13021_na/13021_na.html
3.5" SATA Hot Plug Drives
3.5" SATA Hot Plug Drives3.5" SATA Hot Plug Drives
3.5" SATA Hot Plug Drives
HP 750GB 1.5G SATA 7.2K 3.5" HDD 432341-B21
HP 500GB 1.5G SATA 7.2K 3.5" HDD 395473-B21
HP 250GB 1.5G SATA 7.2K 3.5" HDD 349239-B21
HP 160GB 1.5G SATA 7.2K 3.5" HDD 349238-B21
3.5" SATA Non-Hot Plug Drives
3.5" SATA Non-Hot Plug Drives3.5" SATA Non-Hot Plug Drives
3.5" SATA Non-Hot Plug Drives
HP 250GB 1.5G SATA 7.2K NHP 3.5" HDD 411276-B21
HP 160GB 1.5G SATA 7.2K NHP 3.5" HDD 411275-B21
NOTE:
NOTE:NOTE:
NOTE: The previous generation of 1.5G SATA drives are still supported.
NOTE:
NOTE:NOTE:
NOTE: Please see the QuickSpecs for Technical Specification and additional
information:
http://h18000.www1.hp.com/products/quickspecs/11940_na/11940_na.html
SATA Hot Plug 3.5" Midline (MDL) Solid State Drives
SATA Hot Plug 3.5" Midline (MDL) Solid State DrivesSATA Hot Plug 3.5" Midline (MDL) Solid State Drives
SATA Hot Plug 3.5" Midline (MDL) Solid State Drives
HP 60GB 3G SATA 3.5in MDL 1y Wty SSD 570761-B21
HP 120GB 3G SATA 3.5in MDL 1y Wty SSD 570763-B21
NOTE:
NOTE:NOTE:
NOTE: Please see QuickSpecs for Technical Specifications and additional
information:
http://h18000.www1.hp.com/products/quickspecs/13415_na/13415_na.html
SAS Hot Plug 3.5" Enterprise (ENT) Drives
SAS Hot Plug 3.5" Enterprise (ENT) DrivesSAS Hot Plug 3.5" Enterprise (ENT) Drives
SAS Hot Plug 3.5" Enterprise (ENT) Drives
HP 600GB 6G SAS 15K 3.5" DP ENT HDD 516828-B21
HP 450GB 6G SAS 15K 3.5" DP ENT HDD 516816-B21
HP 450GB 3G SAS 15K 3.5" DP ENT HDD 454232-B21
HP 300GB 6G SAS 15K 3.5" DP ENT HDD 516814-B21
HP 300GB 3G SAS 15K 3.5" DP ENT HDD 416127-B21
HP 146GB 3G SAS 15K 3.5" DP ENT HDD 384854-B21
SAS Hot Plug 3.5" Midline (MDL) Drives
SAS Hot Plug 3.5" Midline (MDL) DrivesSAS Hot Plug 3.5" Midline (MDL) Drives
SAS Hot Plug 3.5" Midline (MDL) Drives
HP 1TB 3G SAS 7.2K 3.5" DP MDL HDD 461137-B21
HP 750GB 3G SAS 7.2K 3.5" DP MDL HDD 461135-B21
NOTE:
NOTE:NOTE:
NOTE: The purchase of SAS HBA or array controller is required.
NOTE:
NOTE:NOTE:
NOTE: Please see the QuickSpecs for Technical Specifications and additional
information:
http://h18000.www1.hp.com/products/quickspecs/12244_na/12244_na.html
QuickSpecs
HP ProLiant DL165 Generation 5p (G5p)
HP ProLiant DL165 Generation 5p (G5p)HP ProLiant DL165 Generation 5p (G5p)
HP ProLiant DL165 Generation 5p (G5p)
Core Options
DA - 13204 North America — Version 9 — November 16, 2009 Page 15

Communications
CommunicationsCommunications
Communications Gigabit Ethernet Adapters
Gigabit Ethernet AdaptersGigabit Ethernet Adapters
Gigabit Ethernet Adapters
HP NC112T PCIe Gigabit Server Adapter 503746-B21
HP NC360T PCI Express Dual Port Gigabit Server Adapter 412648-B21
HP NC364T PCI Express Quad Port Gigabit Server Adapter 435508-B21
HP NC382T PCI Express Dual Port Multifunction Gigabit Server Adapter 458492-B21
10 Gigabit Ethernet Adapters
10 Gigabit Ethernet Adapters10 Gigabit Ethernet Adapters
10 Gigabit Ethernet Adapters
HP NC522SFP Dual Port 10GbE Server Adapter
NOTE:
NOTE:NOTE:
NOTE: A minimum of two Gigabytes (2 GB) of server memory is required per each
NC522SFP adapter.
NOTE:
NOTE:NOTE:
NOTE: Direct Attach Cable (DAC) for copper environments or fiber transceivers and
cables for fiber-optic environments must be purchased separately.
468332-B21
NOTE:
NOTE:NOTE:
NOTE: Please see the QuickSpecs for Technical Specifications and additional
information: www.hp.com/go/ProLiantNICs
QuickSpecs
HP ProLiant DL165 Generation 5p (G5p)
HP ProLiant DL165 Generation 5p (G5p)HP ProLiant DL165 Generation 5p (G5p)
HP ProLiant DL165 Generation 5p (G5p)
Core Options
DA - 13204 North America — Version 9 — November 16, 2009 Page 16

Remote Management
Remote ManagementRemote Management
Remote Management HP Lights-Out 100i Advanced Pack
HP Lights-Out 100i Advanced PackHP Lights-Out 100i Advanced Pack
HP Lights-Out 100i Advanced Pack
HP LO100i Advanced Pack, No Media 1-Server License including 1 year of 24x7
Technical Support and Updates
530521-B21
NOTE:
NOTE:NOTE:
NOTE: Flexible and volume quantity (AKA) license kits are available for the Lights-Out
100i Advanced Pack licenses as well as Electronic License To Use (E-LTU). AKA
Tracking licenses require a 100 unit minimum forecast at initial contract signing. For
these additional part numbers, please refer to QuickSpecs at this link for more
information: www.hp.com/go/lo100
HP Insight Software
HP Insight SoftwareHP Insight Software
HP Insight Software HP Insight Control for Linux
HP Insight Control for LinuxHP Insight Control for Linux
HP Insight Control for Linux
HP Insight Control for Linux, 1-server license, including one year of 24x7 Technical
Support and Updates, Electronic
T9084BAE
HP Insight Control for Linux, No Media, 1-Server license, including one year of 24x7
Technical Support and Updates
464423-B22
HP Insight Control for Linux, Media pack (DVD) - No licenses included
NOTE:
NOTE:NOTE:
NOTE: Media pack DVD contains HP Insight Control for Linux, HP Systems Insight
Manager, HP Insight Control power management, HP Insight Control virtual machine
management, and an integrated installer. Licenses must be acquired separately
NOTE:
NOTE:NOTE:
NOTE: This Media pack is optional because the latest ISO image and latest updates
may be downloaded at no cost from: http://www.hp.com/go/ic-linux (click on
Download button).
464422-B22
NOTE:
NOTE:NOTE:
NOTE: Electronic licenses can be used to purchase multiple licenses with a single
activation key, and are available in all countries except China and Japan. Customers
in China and Japan should order the physical equivalent.
NOTE:
NOTE:NOTE:
NOTE: Customer will receive a license entitlement certificate, which must be
redeemed online or via fax in order to obtain the license activation key(s). Includes
one year of 24 x 7 HP Software Technical Support Service.
NOTE:
NOTE:NOTE:
NOTE: For additional License Kits, including electronic licensing options, please see
the QuickSpecs at:
http://h18000.www1.hp.com/products/quickspecs/13019_na/13019_na.html
HP Insight Control server deployment
HP Insight Control server deploymentHP Insight Control server deployment
HP Insight Control server deployment
HP Insight Control server deployment Electronic License including 1 year 24x7
Technical Support and Updates
T9082AAE
HP Insight Control server deployment 1-Server License including 1 year 24x7
Technical Support and Updates
452151-B21
NOTE:
NOTE:NOTE:
NOTE: Licenses ship without media. The Insight Control Media Kit can be ordered
separately, or can be downloaded at: http://www.hp.com/go/insightupdates .
NOTE:
NOTE:NOTE:
NOTE: Electronic licenses can be used to purchase multiple licenses with a single
activation key, and is available in all countries except China and Japan. Customers in
China and Japan should order the physical equivalent.
NOTE:
NOTE:NOTE:
NOTE: Customer will receive a license entitlement certificate, which must be
redeemed online or via fax in order to obtain the license activation key(s). Includes
one year of 24 x 7 HP Software Technical Support Service.
NOTE:
NOTE:NOTE:
NOTE: For additional license kits please see the Insight Control QuickSpecs at:
http://h18004.www1.hp.com/products/quickspecs/12631_na/12631_na.html
QuickSpecs
HP ProLiant DL165 Generation 5p (G5p)
HP ProLiant DL165 Generation 5p (G5p)HP ProLiant DL165 Generation 5p (G5p)
HP ProLiant DL165 Generation 5p (G5p)
Additional Options
DA - 13204 North America — Version 9 — November 16, 2009 Page 17

Hot Plug HDD Backplane
Hot Plug HDD BackplaneHot Plug HDD Backplane
Hot Plug HDD Backplane
Option
OptionOption
Option
Hot Plug HDD Backplane 1U 2S Kit
NOTE:
NOTE:NOTE:
NOTE: Installation of the Hot Plug Backplane 1U 2S Kit (445985-B21) is required if
ordering third or fourth Hard Drives for Hot Plug models only.
445985-B21
Storage Controllers
Storage ControllersStorage Controllers
Storage Controllers NOTE:
NOTE:NOTE:
NOTE: The addition of storage controllers for internal hard drive use is intended for
use ONLY with the Hot Plug SATA/SAS Model Chassis (495841-B21).
SAS Controllers
SAS ControllersSAS Controllers
SAS Controllers
Smart Array E200 Controller
Smart Array E200 ControllerSmart Array E200 Controller
Smart Array E200 Controller
HP Smart Array E200/128 BBWC Controller 411508-B21
Smart Array P400 Controller
Smart Array P400 ControllerSmart Array P400 Controller
Smart Array P400 Controller
HP Smart Array P400/256MB Controller
NOTE:
NOTE:NOTE:
NOTE: Customers can only order one Smart Array P400/256MB Controller and one
Battery-backed write cache upgrade (P/N 383280-B21) for the HP ProLiant DL165
G5 server based on battery space.
405132-B21
HP Smart Array P400/512MB BBWC Controller
NOTE:
NOTE:NOTE:
NOTE: Customers can only order one Smart Array P400/512MB BBWC Controllers
for the HP ProLiant DL165 G5p server based on battery space.
411064-B21
Smart Array P800 Controller
Smart Array P800 ControllerSmart Array P800 Controller
Smart Array P800 Controller
HP Smart Array P800/512 BBWC Controller 381513-B21
NOTE:
NOTE:NOTE:
NOTE: Please see the following QuickSpecs for Technical Specifications and
additional information:
http://h18000.www1.hp.com/products/quickspecs/12460_na/12460_na.html
(Smart Array E200 Controller)
http://h18000.www1.hp.com/products/quickspecs/12400_na/12400_na.html
(Smart Array P400 Controller)
http://h18000.www1.hp.com/products/quickspecs/12616_na/12616_na.html
(Smart Array P800 Controller)
Optional Upgrades
Optional UpgradesOptional Upgrades
Optional Upgrades
512MB Battery-backed write cache upgrade
NOTE:
NOTE:NOTE:
NOTE: Contains battery and memory module. For Smart Array P400 Controller.
405148-B21
HP SA-P400 and SA-E500 24 In Battery Cable Kit
NOTE:
NOTE:NOTE:
NOTE: This option kit contains a 24" battery cable and adhesive material for installing
a battery into the following servers if a Smart Array E500 is integrated outside of the
factory. For all solutions, please refer to the HP ProLiant QuickSpecs and User's
Manual for detailed installation instruction.
417836-B21
SAS HBA
SAS HBASAS HBA
SAS HBA
HP SC44Ge Host Bus Adapter
NOTE:
NOTE:NOTE:
NOTE: When using the SC44Ge with SATA Hard Drives, 1.5G SATA Hard Drives are
required.
NOTE:
NOTE:NOTE:
NOTE: PCI-Express SAS HBA.
416096-B21
NOTE:
NOTE:NOTE:
NOTE: Please see the following QuickSpecs for Technical Specifications and
additional information:
http://h18004.www1.hp.com/products/quickspecs/12617_na/12617_na.html
(SC44Ge HBA)
SCSI HBA
SCSI HBASCSI HBA
SCSI HBA
QuickSpecs
HP ProLiant DL165 Generation 5p (G5p)
HP ProLiant DL165 Generation 5p (G5p)HP ProLiant DL165 Generation 5p (G5p)
HP ProLiant DL165 Generation 5p (G5p)
Additional Options
DA - 13204 North America — Version 9 — November 16, 2009 Page 18

HP SC11Xe Host Bus Adapter
NOTE:
NOTE:NOTE:
NOTE: Recommended HBA for SCSI tape drive connect.
412911-B21
NOTE:
NOTE:NOTE:
NOTE: Please see the following QuickSpecs for Technical Specifications additional
information:
http://h18000.www1.hp.com/products/quickspecs/12566_na/12566_na.html
(SC11Xe HBA)
HPC Specific Options
HPC Specific OptionsHPC Specific Options
HPC Specific Options HP IB 4X DDR PCI-e Dual Port HCA 448397-B21
HP10GbE PCI-e G2 Dual Port Network Adapter 516937-B21
HP 10 GbE PCI-e G2 Dual Port Adapter 516937-B21
NOTE:
NOTE:NOTE:
NOTE: For HPC interconnect adapters please see the HPC Interconnect section of this
QuickSpecs.
Tape Storage
Tape StorageTape Storage
Tape Storage NOTE:
NOTE:NOTE:
NOTE: For the complete listing of Tape Drive offerings, please see:
http://www.hp.com/products1/storage/compatibility/tapebackup/ISS/index.html
Tape Drives
Tape DrivesTape Drives
Tape Drives
USB Rack-Mount Tape Solutions
USB Rack-Mount Tape SolutionsUSB Rack-Mount Tape Solutions
USB Rack-Mount Tape Solutions
HP StorageWorks 1U USB Rack-Mount Kit with one DAT 160 USB Tape Drive
NOTE:
NOTE:NOTE:
NOTE: Pre-configured with one DAT 160 USB tape drive.
AG703A
SAS Rack-Mount Tape Solutions
SAS Rack-Mount Tape SolutionsSAS Rack-Mount Tape Solutions
SAS Rack-Mount Tape Solutions
NOTE:
NOTE:NOTE:
NOTE: HP recommends purchasing the HP SC44Ge HBA (416096-B21) for a
dedicated SAS HBA for tape.
HP StorageWorks 1U SAS Rack-Mount Kit with one LTO-4 Ultrium 1760
NOTE:
NOTE:NOTE:
NOTE: Pre-configured with one LTO-4 Ultrium 1760 SAS tape drive.
EH946A
HP StorageWorks 1U SAS Rack-Mount Kit
NOTE:
NOTE:NOTE:
NOTE: Supports up to (2) half-height SAS tape drives.
AE459A
HP StorageWorks DAT 160 SAS Internal Tape Drive
NOTE:
NOTE:NOTE:
NOTE: Mounts inside the 1U SAS Rack-Mount Kit (AE459A).
Q1587A
HP StorageWorks LTO-2 Ultrium 448 SAS Internal Tape Drive
NOTE:
NOTE:NOTE:
NOTE: Mounts inside the 1U SAS Rack-Mount Kit (AE459A).
DW085A
HP StorageWorks LTO-3 Ultrium 920 SAS Internal Tape Drive
NOTE:
NOTE:NOTE:
NOTE: Mounts inside the 1U SAS Rack-Mount Kit (AE459A).
EH847A
SCSI Rack-Mount Tape Solutions
SCSI Rack-Mount Tape SolutionsSCSI Rack-Mount Tape Solutions
SCSI Rack-Mount Tape Solutions
NOTE:
NOTE:NOTE:
NOTE: SCSI Controller required. HP recommends purchasing the HP SC11Xe HBA
(412911-B21) for a dedicated SCSI HBA for tape.
HP StorageWorks 1U SCSI Rack-mount kit with one LTO-2 Ultrium 448 SCSI Tape
Drive (Carbonite)
NOTE:
NOTE:NOTE:
NOTE: Pre-configured with one LTO-2 Ultrium 448 SCSI tape drive.
DW028B
HP StorageWorks 1U SCSI Rack-mount kit with one LTO-3 Ultrium 920
NOTE:
NOTE:NOTE:
NOTE: Pre-configured with one LTO-3 Ultrium 920 SCSI tape drive.
EH903A
HP StorageWorks 3U SCSI Rack-Mount with 1 LTO-4 Ultrium 1840 Tape Drive
NOTE:
NOTE:NOTE:
NOTE: Pre-configured with one LTO-4 Ultrium 1840 SCSI tape drive.
EH926A
NOTE:
NOTE:NOTE:
NOTE: For an up-to-date listing of the latest O/S and software support details for HP
Ultrium tape drives, please visit: http://www.hp.com/go/connect
Tape Autoloaders
Tape AutoloadersTape Autoloaders
Tape Autoloaders
QuickSpecs
HP ProLiant DL165 Generation 5p (G5p)
HP ProLiant DL165 Generation 5p (G5p)HP ProLiant DL165 Generation 5p (G5p)
HP ProLiant DL165 Generation 5p (G5p)
Additional Options
DA - 13204 North America — Version 9 — November 16, 2009 Page 19

HP StorageWorks DAT Autoloader
HP StorageWorks DAT AutoloaderHP StorageWorks DAT Autoloader
HP StorageWorks DAT Autoloader
HP StorageWorks DAT 72x10 tape autoloader AE313B
HP StorageWorks 1/8 G2 Tape Autoloader
HP StorageWorks 1/8 G2 Tape AutoloaderHP StorageWorks 1/8 G2 Tape Autoloader
HP StorageWorks 1/8 G2 Tape Autoloader
HP StorageWorks 1/8 G2 LTO-4 Ultrium 1760 SAS Tape Autoloader AK377A
HP StorageWorks 1/8 G2 LTO-3 Ultrium 920 SAS Autoloader AH558A
HP StorageWorks 1/8 G2 LTO-2 Ultrium 448 Tape Autoloader AH164A
HP StorageWorks 1/8 G2 Tape Autoloader Rack Kit
NOTE:
NOTE:NOTE:
NOTE: Required to install the 1/8 G2 Autoloaders in a standard 19-inch rack;
includes rails and rackmount instructions.
AH166A
NOTE:
NOTE:NOTE:
NOTE: Please reference the QuickSpecs for Technical Specifications and
http://www.hp.com/go/automation for additional information needed to create a
complete solution; reference current compatibility information at:
http://www.hp.com/go/ebs .
Tape Libraries
Tape LibrariesTape Libraries
Tape Libraries
HP StorageWorks MSL2024 Tape Library
HP StorageWorks MSL2024 Tape LibraryHP StorageWorks MSL2024 Tape Library
HP StorageWorks MSL2024 Tape Library
HP StorageWorks MSL2024 1 LTO-4 Ultrium 1840 SCSI Drive Library AJ033A
HP StorageWorks MSL2024 1 LTO-4 Ultrium 1760 SAS Drive Library AK378A
HP StorageWorks MSL2024 1 LTO-3 Ultrium 960 SCSI Drive Library AG115A
HP StorageWorks MSL2024 1 LTO-3 Ultrium 920 SAS Drive Library AH559A
HP StorageWorks MSL2024 1 LTO-2 Ultrium 448 SCSI Drive Library AG116A
HP StorageWorks MSL4048 Tape Library
HP StorageWorks MSL4048 Tape LibraryHP StorageWorks MSL4048 Tape Library
HP StorageWorks MSL4048 Tape Library
HP StorageWorks MSL4048 1 LTO-4 Ultrium 1840 SCSI Drive Library AJ035A
HP StorageWorks MSL4048 2 LTO-4 Ultrium 1760 SAS Drive Library AK380A
HP StorageWorks MSL4048 1 LTO-3 Ultrium 960 SCSI Drive Library AG322A
HP StorageWorks MSL4048 1 LTO-3 Ultrium 920 SAS Drive Library AH560A
Disk-Based Backup
Disk-Based BackupDisk-Based Backup
Disk-Based Backup RDX Removable Disk Backup
RDX Removable Disk BackupRDX Removable Disk Backup
RDX Removable Disk Backup
HP StorageWorks RDX160 External Removable Disk Backup System
NOTE:
NOTE:NOTE:
NOTE: 160GB of Disk Storage
AJ766A
HP StorageWorks RDX320 External Removable Disk Backup System
NOTE:
NOTE:NOTE:
NOTE: 320GB of Disk Storage
AJ768A
HP StorageWorks RDX500 External Removable Disk Backup System
NOTE:
NOTE:NOTE:
NOTE: 500GB of Disk Storage
AJ935A
NOTE:
NOTE:NOTE:
NOTE: Please see the QuickSpecs for Technical Specifications and additional
information:
http://h18000.www1.hp.com/products/quickspecs/13036_na/13036_na.html
D2D Backup
D2D BackupD2D Backup
D2D Backup
HP StorageWorks D2D2504i Backup System
NOTE:
NOTE:NOTE:
NOTE: 4 TB raw capacity/3 TB useable capacity.
EJ002A
HP StorageWorks D2D130 Backup System with LTO-3 Ultrium 920 SAS Tape Drive
NOTE:
NOTE:NOTE:
NOTE: 3TB of Disk Storage
EH952A
HP StorageWorks D2D2503i Backup System
NOTE:
NOTE:NOTE:
NOTE: 3TB of Disk Storage
EH945A
QuickSpecs
HP ProLiant DL165 Generation 5p (G5p)
HP ProLiant DL165 Generation 5p (G5p)HP ProLiant DL165 Generation 5p (G5p)
HP ProLiant DL165 Generation 5p (G5p)
Additional Options
DA - 13204 North America — Version 9 — November 16, 2009 Page 20
