HP ProLiant ML310 Generation 5p User instructions

Front View:
Front View:Front View:
Front View: Rear View:
Rear View:Rear View:
Rear View:
1. SATA DVD-ROM 1. Power cord connections for Power Supply 1 & 2
2. Removable Media Bays 2. Mouse connector
3. LED Indicators and Power Button 3. Keyboard connector
4. Upfront USB Ports 4. Integrated Lights-Out 2 (iLo2) connector
5. Four DIMM Sockets for up to 8GB DDR2 memory 5. Embedded Gigabit NIC
6. Processor Socket (Intel® Xeon®, Core™2, Pentium® or
Celeron®)
6. USB 2.0 (qty 2)
7. Serial Port
7. System Fan 8. Video Port
8. 410W Non-Hot Plug Non-Redundant Power Supply or 430W
Hot Plug Redundant Power Supplies
9. Up to Five Expansion Slots (Four PCI Express and One PCI-X
(Optional)
QuickSpecs
HP ProLiant ML310 Generation 5 (G5)
HP ProLiant ML310 Generation 5 (G5)HP ProLiant ML310 Generation 5 (G5)
HP ProLiant ML310 Generation 5 (G5)
Overview
DA - 12858 North America — Version 9 — January 21, 2008 Page 1

At A Glance
At A GlanceAt A Glance
At A Glance
The HP ProLiant ML310 G5 is an affordable, single processor tower server designed to provide the solid network foundation
essential to fuel thriving small offices. Processing power ranging from single-core Celeron to quad-core Xeon combines with industry-
leading management and essential data protection features for a secure, affordable platform that helps you run your business
efficiently.
Processors:
Processors:Processors:
Processors:
Quad-Core Intel® Xeon® 3200 processor sequence, or
Dual-Core Intel® Xeon® 3000 processor sequence, or
Dual-Core Intel® Core™2 E4400 processor, or
Dual-Core Intel® Pentium® E2160 processor, or
Single-Core Intel® Celeron® 420 processor
1333 MHz Front Side Bus (FSB)
Intel 3210 Chipset
Memory:
Memory:Memory:
Memory:
Up to 8GB of PC2-6400 800MHz unbuffered DDR2 SDRAM with ECC capabilities and optional interleaving
Storage Controller:
Storage Controller:Storage Controller:
Storage Controller:
SAS Models: HP SC40Ge SAS HBA with RAID 0,1 in a PCI Express slot
SATA Models: Embedded SATA with integrated SATA RAID 0,1
Internal Drive Support:
Internal Drive Support:Internal Drive Support:
Internal Drive Support:
Supports up to four hot plug SAS or SATA hard drives for up to 3TB internal storage
Models support SAS and SATA hard drives
Network Controller:
Network Controller:Network Controller:
Network Controller:
Embedded NC326i Gigabit Server Adapter
Expansion Slots:
Expansion Slots:Expansion Slots:
Expansion Slots:
Up to 5 Total: (1) PCI Express x8, (3) PCI Express x1, Optional Extender Board for (1) 64-bit/100MHz PCI-X
USB 2.0 Ports:
USB 2.0 Ports:USB 2.0 Ports:
USB 2.0 Ports:
6 Total: (2) front; (2) rear; (1) internal; (1) dedicated internal for tape
Management:
Management:Management:
Management:
HP Insight Control Environment server management software
Integrated Lights-Out 2 featuring Integrated Remote Console with KVM over IP performance over shared network
access
ROM Based Setup Utility (RBSU) and PXE support
Form Factor:
Form Factor:Form Factor:
Form Factor:
Tower
Optional Tower-to-Rack Enabling Kit available
Warranty:
Warranty:Warranty:
Warranty:
This product is covered by a global limited warranty and supported by HP Services and a worldwide network of HP
Authorized Channel Partners. Hardware diagnostic support and repair is available for one year, with 1 year Next
Business Day and year on-site support from date of purchase. Support for software and initial setup is available for 90
days from date of purchase. Expanded support may be covered under the warranty or available for an additional fee.
Enhancements to warranty services are available through HP Care Pack services or customized service agreements.
SATA hard drives have a one-year warranty. (3-1-1 warranty offered in AP only).
NOTE:
NOTE:NOTE:
NOTE: Additional information regarding worldwide limited warranty and technical support is available at:
http://h18004.www1.hp.com/products/servers/platforms/warranty/index.htm
QuickSpecs
HP ProLiant ML310 Generation 5 (G5)
HP ProLiant ML310 Generation 5 (G5)HP ProLiant ML310 Generation 5 (G5)
HP ProLiant ML310 Generation 5 (G5)
Overview
DA - 12858 North America — Version 9 — January 21, 2008 Page 2

NOTE:
NOTE:NOTE:
NOTE: For a brief, printer friendly data sheet that describes this product and informs you of the essential capabilities and
specifications, please visit: http://h71028.www7.hp.com/ERC/downloads/4AA1-5499ENW.pdf .
NOTE:
NOTE:NOTE:
NOTE: For the Standard Features shipped in the "Factory Integrated Models", please see the "Configuration Information – Factory
Integrated Models" section.
Processor
ProcessorProcessor
Processor
One of the following
depending on Model
Quad-Core Intel® Xeon® processor 3220 (2.4GHz, 8MB L2 cache, 95 Watts, 1066MHz Front Side
Bus (FSB)
Dual-Core Intel® Core™2 processor E4400 (2.0GHz, 2MB L2 cache, 800MHz FSB)
Dual-Core Intel® Pentium® processor E2160 (1.80GHz, 1MB L2 cache, 800MHz FSB)
Single-Core Intel® Celeron® processor 420 (1.60GHz, 512KB L2 cache, 800MHz FSB)
NOTE:
NOTE:NOTE:
NOTE: The processors listed above available via Configure to Order only. Please see "Configuration
Information – Factory Integrated Models" section of this QuickSpecs.
Quad-Core Intel® Xeon® processor 3210 (2.13 GHz, 8MB L2 Cache, 95 Watts, 1066MHz FSB)
Dual-Core Intel® Xeon® processor 3075 (2.66GHz, 4MB L2 cache, 65 Watts, 1333MHz FSB)
Dual-Core Intel® Xeon® processor 3065 (2.33 GHz, 4MB L2 Cache, 65 Watts, 1333MHz FSB)
Cache Memory
Cache MemoryCache Memory
Cache Memory
One of the following
depending on Model
8MB L2 Cache
NOTE:
NOTE:NOTE:
NOTE: For Models with Intel Xeon processor 3220 and 3210.
4MB L2 Cache
NOTE:
NOTE:NOTE:
NOTE: For Models with the Intel Xeon processor 3075 and 3065 .
2MB L2 Cache
NOTE:
NOTE:NOTE:
NOTE: For Models with the Intel Core2 processor E4400.
1MB L2 Cache
NOTE:
NOTE:NOTE:
NOTE: For Models with the Intel Pentium processor E2160.
512KB L2 Cache
NOTE:
NOTE:NOTE:
NOTE: For Models with the Intel Celeron processor 420.
Memory Protection
Memory ProtectionMemory Protection
Memory Protection ECC
Memory
MemoryMemory
Memory
One of the following
depending on Model
Type PC2-6400 unbuffered DDR2 SDRAM (800MHz)
Standard
(One of the following,
depending on Model)
512 MB (1 x 512 MB)
1 GB (1 x 1 GB)
Maximum 8 GB
Network Controller
Network ControllerNetwork Controller
Network Controller Embedded NC326i Gigabit Server Adapter
QuickSpecs
HP ProLiant ML310 Generation 5 (G5)
HP ProLiant ML310 Generation 5 (G5)HP ProLiant ML310 Generation 5 (G5)
HP ProLiant ML310 Generation 5 (G5)
Standard Features
DA - 12858 North America — Version 9 — January 21, 2008 Page 3

Expansion Slots
Expansion SlotsExpansion Slots
Expansion Slots Slot Number
Slot NumberSlot Number
Slot Number Bus Speed
Bus SpeedBus Speed
Bus Speed Maximum Card
Maximum CardMaximum Card
Maximum Card
Length
LengthLength
Length
Hot Plug
Hot PlugHot Plug
Hot Plug Connector Type
Connector TypeConnector Type
Connector Type
5 (optional) 64-bit/100MHz
PCI-X
12.3 No 3.3V
4 PCI Express x8 12.3 No x8
3 PCI Express x1 12.3 No x8
2 PCI Express x1 12.3 No x8
1 PCI Express x1 12.3 No x8
Storage Controllers
Storage ControllersStorage Controllers
Storage Controllers The HP ProLiant ML310 G5 supports Serial ATA (SATA) and Serial Attached SCSI (SAS) hard drives.
Models described as SAS models include an 8 port HBA that supports both SATA and SAS hard drives in
non-RAID, RAID 0, or RAID 1 configurations. Models described as SATA/SAS support SATA hard drives
standard and require the installation of an HBA or controller to support SAS.
HP SC40Ge SAS HBA with RAID (in PCIe slot) (SAS Models)
Embedded SATA with integrated SATA RAID 0,1 (SATA/SAS Models)
NOTE:
NOTE:NOTE:
NOTE: Use of the embedded SATA RAID feature with a Linux operating system requires installation of a
driver from a floppy drive. The supported floppy drive can be a USB drive key, USB floppy drive, half-
height internal floppy drive, or virtual floppy via Integrated Lights-Out 2 (iLO 2).
NOTE:
NOTE:NOTE:
NOTE: Any Smart Array Controller or SAS HBA requires the purchase of the HP SAS Cable for the
ML310 G5.
NOTE:
NOTE:NOTE:
NOTE: See the "Storage" section of these QuickSpecs for information on required to support SATA and
SAS hard drive configurations.
Storage
StorageStorage
Storage Optical Drive SATA DVD-ROM Drive
Diskette Drive Optional 1.44 MB Diskette Drive
NOTE:
NOTE:NOTE:
NOTE: Use of the embedded SATA RAID feature with a Linux operating
system requires installation of a driver from a floppy drive. The supported
floppy drive can be a USB drive key, USB floppy drive, half-height internal
floppy drive, or virtual floppy via Integrated Lights-Out 2 (iLO 2).
Maximum Internal
Maximum InternalMaximum Internal
Maximum Internal
Storage
StorageStorage
Storage
Hot Plug SAS (3.5") 1.2TB 4 x 300 GB SAS
Hot Plug SATA (3.5") 3.0TB 4 x 750 GB SATA
NOTE:
NOTE:NOTE:
NOTE: See the "Storage" section of these QuickSpecs for information on controllers required to support
SATA and SAS hard drive configurations.
QuickSpecs
HP ProLiant ML310 Generation 5 (G5)
HP ProLiant ML310 Generation 5 (G5)HP ProLiant ML310 Generation 5 (G5)
HP ProLiant ML310 Generation 5 (G5)
Standard Features
DA - 12858 North America — Version 9 — January 21, 2008 Page 4

Interfaces
InterfacesInterfaces
Interfaces Parallel 1 (Optional)
Serial 1 (Optional second serial port available)
Pointing Device (Mouse) 1
Graphics 1
Keyboard 1
USB Ports 5 (2 front; 2 rear; 1 internal)
NOTE:
NOTE:NOTE:
NOTE: Please see the following URL for additional information regarding
USB support:
http://h18004.www1.hp.com/products/servers/platforms/usb-support.html .
Dedicated USB Port 1 (available for USB tape connectivity)
Network RJ-45 (Ethernet) 1
iLO 2 Remote
Management port
1
Graphics
GraphicsGraphics
Graphics Integrated ATI ES1000, 32 MB video standard
16 bit color: maximum resolution of 1600 x 1200
32 bit color: maximum resolution of 1280 x 1024
NOTE:
NOTE:NOTE:
NOTE: Maximum resolution available via iLO 2 remote console is 1280 x 1024.
Form Factor
Form FactorForm Factor
Form Factor Tower (5U)
Optional Tower-to-Rack Enabling Kit available (system & tray occupy 6U)
HP Insight Control
HP Insight ControlHP Insight Control
HP Insight Control
Management Suites
Management SuitesManagement Suites
Management Suites
HP Insight Control Environment delivers foundation management, including remote monitoring,
hardware resource deployment, health monitoring, software version control, performance monitoring,
vulnerability scanning and patch management, and power management.
HP Insight Control Environment installs and licenses the following components by default using a wizard-
based integrated installer:
HP Systems Insight Manager
HP iLO Advanced Pack
HP Rapid Deployment Pack
HP Insight Power Manager
HP Performance Management Pack
HP Vulnerability and Patch Management Pack
Additional ProLiant Essentials software and management tools included on the Insight Control
Management kit can be installed manually
HP Server Migration Pack - Universal Edition
HP Open Service Event Manager
HP Instant Support Enterprise Edition
NOTE:
NOTE:NOTE:
NOTE: Server Migration Pack - Universal Edition can be installed from the SMP Universal CD included
in the Insight Control Management media kit.
NOTE:
NOTE:NOTE:
NOTE: For additional product and licensing information about HP Insight Control Environment, visit:
http://www.hp.com/go/ice .
QuickSpecs
HP ProLiant ML310 Generation 5 (G5)
HP ProLiant ML310 Generation 5 (G5)HP ProLiant ML310 Generation 5 (G5)
HP ProLiant ML310 Generation 5 (G5)
Standard Features
DA - 12858 North America — Version 9 — January 21, 2008 Page 5

HP Insight Control management suites and most HP ProLiant Essentials include a one year of 24 x 7 HP
Software Technical Support and Update Service ensuring rapid access to HP support staff and proactive
delivery of software updates. For more information about this service, please visit:
http://www.hp.com/services/insight .
Server Management
Server ManagementServer Management
Server Management
Stand Alone Software
Stand Alone SoftwareStand Alone Software
Stand Alone Software
Product - ProLiant
Product - ProLiantProduct - ProLiant
Product - ProLiant
Essentials
EssentialsEssentials
Essentials
HP Systems Insight
Manager
HP Systems Insight Manager (HP SIM) provides a unified, secure and
extensible standards-based environment to centrally manage servers, storage
and other infrastructure devices, (both HP and non-HP) across multiple
operating system platforms.
ProLiant Essentials Server
Migration Pack - Universal
Edition
Upgrading, replacing, or virtualizing your existing server? Effortlessly
transition to new virtual or physical HP ProLiant servers or BladeSystem with
automated, accurate and affordable migration of OS, application and data.
SMP Universal automates the manual processes required for migrating
servers between physical or virtual platforms, whether migrating to VMware
or Microsoft virtual machines. SMP Universal allows all of the following
migrations:
physical to ProLiant
physical to virtual
virtual to virtual
virtual to ProLiant
NOTE:
NOTE:NOTE:
NOTE: For more information, visit: http://www.hp.com/go/migrate .
ProLiant Essentials
Performance Management
Pack
Performance Management Pack (offered exclusively through the Insight
Control suites) - a performance management solution that identifies and
explains hardware performance bottlenecks on ProLiant servers and attached
options enabling users to better utilize their valuable resources
Integrated Lights-Out
Advanced Pack
Upgrades the iLO 2 processor with comprehensive remote control including
Virtual KVM remote graphical console, enhanced console sharing and
replay, virtual media (floppy, CD/DVD, USB key), virtual folders, and
enterprise security (directory services and two-factor authentication).
HP Insight Power Manager
(IPM)
Upgrades the single-server remote management capabilities of iLO
Select/Advanced to include centralized reporting and policy-based
management of power consumption and thermal output provided by the
Insight Power Manager. IPM unifies all of this functionality within a single
user interface - HP Systems Insight Manager.
NOTE:
NOTE:NOTE:
NOTE: Flexible and volume quantity license kits are available for ProLiant Essentials Value Packs. Refer
to: http://www.hp.com/servers/proliantessentials or the various ProLiant Essentials Value Pack product
QuickSpecs for more information.
QuickSpecs
HP ProLiant ML310 Generation 5 (G5)
HP ProLiant ML310 Generation 5 (G5)HP ProLiant ML310 Generation 5 (G5)
HP ProLiant ML310 Generation 5 (G5)
Standard Features
DA - 12858 North America — Version 9 — January 21, 2008 Page 6

Core Infrastructure
Core InfrastructureCore Infrastructure
Core Infrastructure
Management
ManagementManagement
Management
SmartStart SmartStart is a tool that simplifies server setup, providing a rapid way to
deploy reliable and consistent server configurations. For more information,
please visit the SmartStart Web site at:
http://www.hp.com/servers/smartstart .
SmartStart version supported (minimum): SmartStart 7.51.
Insight Management
Agents
The Insight Management Agents should be installed on all HP servers to
present system instrumentation, health and configuration information into HP
Systems Insight Manager and the HP System Management Homepage. The
HP System Management Homepage aggregates systems data from Insight
Management Agents and other HP management tools, providing a
consolidated browser-based interface for managing individual servers.
Insight Management Agents and The HP System Management Homepage
are included on ProLiant Support Packs, and can also be installed using the
server profiles provided with the ProLiant Essentials Rapid Deployment Pack.
For additional information about the Management Agents and the HP
System Management Homepage please visit the management Web site at:
http://www.hp.com/servers/manage .
Subscriber's Choice Subscriber's Choice Driver and Support Alerts/Notifications is a web-based
email subscription service that provides software and driver change
notifications for ProLiant products. Sign up at:
http://www.hp.com/go/subscriberschoice
and customize your profile to receive various new alerts as they become
available, on a weekly or monthly basis.
ProLiant Support Packs
and ROMPaq, software
The latest software, drivers, and firmware fully optimized and tested for your
ProLiant server and options, available through ProLiant Support Packs the
ProLiant Essentials Rapid Deployment Pack, SmartStart or downloaded from
software and drivers download pages website at:
http://www.hp.com/go/support .
Industry Standard
Industry StandardIndustry Standard
Industry Standard
Compliance
ComplianceCompliance
Compliance
ACPI V1.0b and 2.0 Compliant
PCI 3.0 Compliant
PCI-X 3.0 Compliant
PCI-Express 3.0 Compliant
PXE Support
WOL Support
Microsoft Logo certifications
Novell Logo certifications
USB 2.0
QuickSpecs
HP ProLiant ML310 Generation 5 (G5)
HP ProLiant ML310 Generation 5 (G5)HP ProLiant ML310 Generation 5 (G5)
HP ProLiant ML310 Generation 5 (G5)
Standard Features
DA - 12858 North America — Version 9 — January 21, 2008 Page 7

Remote Management
Remote ManagementRemote Management
Remote Management Integrated Lights-Out (iLO 2) Management 2
Virtual Text Remote Console (pre-OS only)
Remote Serial Console
Virtual Power Button Control
Virtual Unit ID control
Integrated Remote Console
Dedicated & full function shared network connectivity
Embedded system health
Present power consumption
Browser, command line and scripted access
Automatic IP Configuration via DHCP/DNS/WINS
Industry Standard 128-bit Secure Sockets Layer (SSL) and Secure Shell security (SSH)
Advanced Encryption Standard (AES)/Triple Data Encryption Standard (3DES)
OS independent hardware health status
IML and iLO Event Logging
Support for 12 user accounts with customizable access privilege
Manageability
ManageabilityManageability
Manageability HP Systems Insight Manager
Online ROM Flash Utility
Drive Parameter Tracking (with Smart Array Controller)
Dynamic Sector Repairing (with Smart Array Controller)
Pre-Failure Warranty (covers processors, memory and SAS hard drives)
BIOS Serial Console
Security
SecuritySecurity
Security Power-on password
Setup password
Diskette boot control
Power switch security
Server Power Cords
Server Power CordsServer Power Cords
Server Power Cords All models ship with one 1.8m (6 foot) standard low-line power cord.
NOTE:
NOTE:NOTE:
NOTE: A C13 to C14 2.8M jumper cord ships standard. If customers require a local power cord, they
can check the power cord matrix for the appropriate country specific sku. Please see the following power
cord matrix: http://www.hp.com/go/powercordmatrix .
Power Specifications
Power SpecificationsPower Specifications
Power Specifications To review typical system power ratings use the Active Answers Power Calculator at:
http://h30099.www3.hp.com/configurator/powercalcs.asp
Power Supply
Power SupplyPower Supply
Power Supply 410 Watt PFC (Power Factor Correcting) non-hot plug non-redundant power supply or 430 Watt PFC
hot plug redundant power supplies (ships with two power supplies)
UPS and PDU Power
UPS and PDU PowerUPS and PDU Power
UPS and PDU Power
Cord Matrix
Cord MatrixCord Matrix
Cord Matrix
Please see the UPS and PDU cable matrix that lists cable descriptions, requirements, and specifications
for UPS and PDU units:
http://h18004.www1.hp.com/products/servers/proliantstorage/power-protection/index.html
QuickSpecs
HP ProLiant ML310 Generation 5 (G5)
HP ProLiant ML310 Generation 5 (G5)HP ProLiant ML310 Generation 5 (G5)
HP ProLiant ML310 Generation 5 (G5)
Standard Features
DA - 12858 North America — Version 9 — January 21, 2008 Page 8

System Fans
System FansSystem Fans
System Fans 2 – Non-hot plug, Non-redundant system fans; 1 optional fan for PCI-X Extender Board
NOTE:
NOTE:NOTE:
NOTE: Does not include fan in power supply.
OS Support
OS SupportOS Support
OS Support Microsoft Windows Server 2003
Microsoft Small Business Server 2003
Novell NetWare
Red Hat Enterprise Linux
SUSE Enterprise Linux Server
SCO OpenServer
NOTE:
NOTE:NOTE:
NOTE: The ML310 Embedded SATA RAID feature is not available for use with Netware or SCO
operating systems.
NOTE:
NOTE:NOTE:
NOTE: For a more complete and up-to-date listing of supported OSs and versions, please visit our OS
Support Matrix at: http://www.hp.com/go/supportos
NOTE:
NOTE:NOTE:
NOTE: For an up-to-date listing of the latest drivers available for the HP ProLiant ML310, please see:
http://h18023.www1.hp.com/support/files/server/us/index.html .
NOTE:
NOTE:NOTE:
NOTE: For more Linux OS support & certification information, please visit our the ProLiant &
BladeSystem Server Linux matrix http://h18004.www1.hp.com/products/servers/linux/hpLinuxcert.html
NOTE:
NOTE:NOTE:
NOTE: For more complete and up-to-date information on how to buy server operating systems from HP
please visit the OS product site at: http://h18004.www1.hp.com/products/servers/software/OEM.html
Factory Express Portfolio
Factory Express PortfolioFactory Express Portfolio
Factory Express Portfolio
for Servers and Storage
for Servers and Storagefor Servers and Storage
for Servers and Storage
HP Factory Express offers configuration, customization, integration and deployment services for HP
servers and storage products. Customers can choose how their factory solutions are built, tested,
integrated, shipped and deployed.
Factory Express offers service packages for simple configuration, racking, installation, complex
configuration and design services as well as individual factory services, such as image loading, asset
tagging, and custom packaging. HP products supported through Factory Express include a wide array of
servers and storage: HP Integrity, HP ProLiant, HP ProLiant Server Blades, HP BladeSystem, HP 9000
servers as well as the MSA1000, VA7xxx, EVA, XP, rackable tape libraries and configurable network
switches.
For more information on Factory Express services for your specific server model please contact your sales
representative or go to http://www.hp.com/go/factory-express .
Rack and Rack Options
Rack and Rack OptionsRack and Rack Options
Rack and Rack Options Rack Cabinets:
Rack Cabinets:Rack Cabinets:
Rack Cabinets:
For information regarding Rack Cabinets, please see the following URL:
http://www.hp.com/go/rackandpower
KVM Switches, Serial Console Servers, Rackmount Monitors, Keyboards:
KVM Switches, Serial Console Servers, Rackmount Monitors, Keyboards:KVM Switches, Serial Console Servers, Rackmount Monitors, Keyboards:
KVM Switches, Serial Console Servers, Rackmount Monitors, Keyboards:
For additional information regarding KVM switches, Serial Console servers, rack mount monitors,
keyboards and all related options please see the following URL: http://www.hp.com/go/kvm .
QuickSpecs
HP ProLiant ML310 Generation 5 (G5)
HP ProLiant ML310 Generation 5 (G5)HP ProLiant ML310 Generation 5 (G5)
HP ProLiant ML310 Generation 5 (G5)
Standard Features
DA - 12858 North America — Version 9 — January 21, 2008 Page 9

HP Enterprise
HP EnterpriseHP Enterprise
HP Enterprise
Configurator
ConfiguratorConfigurator
Configurator
The HP eCo-Enterprise Configurator now provides factory default racking for our HP hardware portfolio.
This approach is aligned with our strategic direction to meet the needs and expectations of our valued
customers. If you require "custom" rack configuration, please contact HP's Customer Business Center or
an Authorized Partner for assistance.
http://www.hp.com/products/configurator .
Service and Support
Service and SupportService and Support
Service and Support HP Care Pack Services provide total care and support expertise with committed response times designed
to meet your IT and business needs.
HP Care Pack services include coverage for the HP branded hardware options qualified for the server
that are purchased at the same time or afterward and internal to the enclosure. It also includes the 22-
inch and smaller external monitors and tower UPS options up to 3kVA. These items will be covered at the
same service level and for the same coverage period as the server. Coverage of UPS Battery is not
included and standard warranty terms & conditions apply. For servers or storage systems installed within
a rack, service also covers all HP qualified rack options installed within the same rack.
To fully capitalizing on your HP ProLiant servers' capabilities requires a service partner who thoroughly
understands your server technology and systems environment. HP Services, an industry leader in
provision of support solutions provides a range of support services designed to meet the varying needs of
your business. Whether an SMB, or large global corporation, HP has ProLiant server support offers to
help you speedily deploy and maximize system uptime.
Recommended Service
Recommended ServiceRecommended Service
Recommended Service – simplify ProLiant solution implementation, maintenance, and management.
Support
SupportSupport
Support – 3-Year 9x5 Next Business Day coverage, excluding HP holidays only
Deployment Service
Deployment ServiceDeployment Service
Deployment Service – HW Installation only
Enhanced Service
Enhanced ServiceEnhanced Service
Enhanced Service – optimize service level to increase IT performance and availability.
Support
SupportSupport
Support – 3-Yyear 13x5 Same Business Day, 4-Hour response coverage only
Deployment Service
Deployment ServiceDeployment Service
Deployment Service – Installation and Start up only
Refer to the information on the Installation of a ProLiant on the ProLiant Data Sheet; to be delivered on a
scheduled basis 8am-5pm, M-F, excluding HP holidays. .
NOTE:
NOTE:NOTE:
NOTE: For a complete listing of service offerings and information visit:
http://www.hp.com/services/proliantservices
http://www.hp.com/go/proliant/carepack
QuickSpecs
HP ProLiant ML310 Generation 5 (G5)
HP ProLiant ML310 Generation 5 (G5)HP ProLiant ML310 Generation 5 (G5)
HP ProLiant ML310 Generation 5 (G5)
Standard Features
DA - 12858 North America — Version 9 — January 21, 2008 Page 10
