Front View: Rear View:
1. Cover 1. Power supply
2. Four PC2-6400 ECC DDR2 Memory Slots 2. Mouse connector
3. Processor Socket (Intel® Xeon®, Core™2, Pentium® or
Celeron®)
3. NIC 2 Port
4. USB connectors (2)
4. Power Supply (400 Watt) 5. Serial connector
5. Non Hot Plug Dual Rotor Fans 6. PCI Express expansion slot 5, low-profile, half-length
6. Optional 12.7mm DVD-ROM, or DVD-RW Drive for 2
HDD models and optional 9.5mm DVD-ROM, or DVD
combo drive for 4-HDD model
7. PCI Express expansion slot 4, (optional PCI-X, full-
length)
8. UID button/LED
9. Video connector
7. Two upfront USB connectors 10. Dedicated Integrated Lights-Out 2 (iLO 2) management
port (optional)
8. Power Button, UID Button, and Front LED Indicators
9. Support for up to four Hot Plug SATA or SAS Hard
Drives
11. NIC 1 Port / Shared iLO 2 Management Port
10. Two PCI-Express Slots (2 PCI-Express x8 connectors
standard)
12. Keyboard connector
What's New
New Quad-Core Intel Xeon processors with up to 12 MB L2 cache for 1333MHz Front Side Bus
Support for low-cost Intel Celeron 440 processor
At a Glance
The HP ProLiant DL320 G5p Server is an enterprise rack-optimized server at an entry level price. The highly manageable 1
processor, 1U server is ideal for single-application IT infrastructure, web and edge-of-network applications. The remote
console and virtual KVM offered by the embedded iLO-2, coupled with the management features of SIM and deployment
capabilities of SmartStart and other ProLiant Essentials software, give the DL320 G5p enterprise-class management
features. Optional upgrades provide support for hot-plug SAS drives and/or up to 4 SAS or SATA drives, and gives the
DL320 G5p the flexibility to meet the needs of your datacenter. Plus, you get the cost-effective solution of a single-processor
platform with the performance advantages of dual-core or quad-core.
Processor:
Quad-Core Intel® Xeon® 3300 processor sequence
QuickSpecs
HP ProLiant DL320 Generation 5p
Overview
DA - 12854 Worldwide QuickSpecs — Version 12 — 5-28-2008 Page 1

Quad-Core Intel® Xeon® 3200 processor sequence
Dual-Core Intel® Xeon® 3100 processor sequence
Dual-Core Intel® Xeon® 3000 processor sequence
Dual-Core Intel® Core™2 E4600 processor
Dual-Core Intel® Pentium® E2160 processor
Single-Core Intel® Celeron® 440 and 420 processors
Intel® 3210 Chipset with up to 1333MHz Front Side Bus (FSB)
Memory:
Supports up to 8 GB of PC2-6400 (800 MHz) Unbuffered DDR2 ECC SDRAM Memory
4 DIMM sockets
Storage Controller:
4 Port SATA Controller with RAID 0/1 support
Internal Drive Support:
Up to four 3.5" (Large Form Factor) SATA or SAS hard drives
Two drive cage standard. Optional 4 HDD cage upgrade kit
SAS drives require optional SAS Host Bus Adapter (HBA) or Smart Array Controller
Optional hot plug hard drive configuration
Internal storage capacity of up to 3.0TB (4 x 750 GB SATA hard drives) with optional 4HDD cage
Optional DVD, DVD Combo or DVD-RW drive (depending on 2 or 4 HDD model)
Network Controller:
Embedded NC326i Dual Port Gigabit Server Adapter
Expansion Slots:
Two total slots:
(1) Full length PCI Express x8 slot (x8 connector)
Can be replaced with a full-length 64-bit /133MHz PCI-X slot
(1) Half-length, low-profile PCI Express x1 slot (x8 connector)
USB 2.0 Ports:
Up to 5 Total: (2) front; (1) internal (optional); (2) rear accessible ports
Internal USB port (optional) for flexible storage, security, or USB drive key deployment
Management:
HP Insight Control Environment server management software
Integrated Lights-Out 2 featuring Integrated Remote Console with KVM over IP performance over shared network
access
HP ProLiant Essentials Foundation Pack, including HP Systems Insight Manager and SmartStart
Front Panel status LEDs including system health and UID
Form Factor:
1U (1.70" / 4.32 cm) Rack Mount Chassis
26.85" (68.20 cm) Deep
New fixed, mounting rails included with all models
Warranty:
This product is covered by a global limited warranty and supported by HP Services and a worldwide network of HP
Authorized Channel Partners. Hardware diagnostic support and parts repair is available for three years Next Business
Day, with one year on-site support from date of purchase. Support for software and initial setup is available for 90 days
QuickSpecs
HP ProLiant DL320 Generation 5p
Overview
DA - 12854 Worldwide QuickSpecs — Version 12 — 5-28-2008 Page 2

from date of purchase. Expanded support may be covered under the warranty or available for an additional fee.
Enhancements to warranty services are available through HP Care Pack services or customized service agreements.
SATA hard drives have a one-year warranty.
NOTE : Server Warranty includes three year parts, one year labor, and one year on-site support with next business day
response. Additional information regarding worldwide limited warranty and technical support is available at:
http://h18004.www1.hp.com/products/servers/platforms/warranty/index.html
QuickSpecs
HP ProLiant DL320 Generation 5p
Overview
DA - 12854 Worldwide QuickSpecs — Version 12 — 5-28-2008 Page 3

NOTE: For a brief, printer friendly data sheet that describes this product and informs you of the essential capabilities and
specifications, please visit: http://h71028.www7.hp.com/ERC/downloads/4AA1-5500ENW.pdf .
NOTE: For the Standard Features shipped in the "Factory Integrated Models", please see the "Configuration Information -
Factory Integrated Models" section.
Processor
One of the following
depending on Model
Quad-Core Intel® Xeon® processor X3360 (2.83GHz, 12MB L2 cache, 95 Watts, 1333MHz Front
Side Bus (FSB))
NOTE: Available via CTO only.
Quad-Core Intel® Xeon® processor X3350 (2.66GHz, 12MB L2 cache, 95 Watts, 1333MHz FSB)
NOTE: Available via CTO only.
Quad-Core Intel® Xeon® processor X3320 (2.50GHz, 6MB L2 cache, 95 Watts, 1333MHz FSB)
Quad-Core Intel® Xeon® processor X3220 (2.4GHz, 8MB L2 cache, 95 Watts, 1066MHz FSB)
NOTE: Available via CTO only.
Quad-Core Intel® Xeon® processor X3210 (2.13GHz, 8MB L2 Cache, 95 Watts, 1066MHz FSB)
Dual-Core Intel® Xeon® processor E3110 (3.0GHz, 6MB L2 cache, 65 Watts, 1333MHz FSB)
Dual-Core Intel® Xeon® processor 3075 (2.66GHz, 4MB L2 cache, 65 Watts, 1333MHz FSB)
Dual-Core Intel® Xeon® processor 3065 (2.33GHz, 4MB L2 Cache, 65 Watts, 1333MHz FSB)
NOTE: Available via CTO only.
Dual-Core Intel® Core™2 processor E4600 (2.4GHz, 2MB L2 cache, 800MHz FSB)
NOTE: Available via CTO only .
Dual-Core Intel® Core™2 processor E4400 (2.0GHz, 2MB L2 cache, 800MHz FSB)
NOTE: Available via CTO only.
Dual-Core Intel® Pentium® processor E2160 (1.80GHz, 1MB L2 cache, 800MHz FSB)
NOTE: Available via CTO only.
Single-Core Intel® Celeron® processor 440 (2.00GHz, 512KB L2 cache, 800MHz FSB)
NOTE: Available via CTO only.
Single-Core Intel® Celeron® processor 420 (1.60GHz, 512KB L2 cache, 800MHz FSB)
NOTE: Available via CTO only.
Cache Memory
One of the following
depending on Model
12 MB L2 Cache
NOTE: For Models with Intel® Xeon® processor X3360 and X3350.
8 MB L2 Cache
NOTE: For Models with Intel® Xeon® processor X3220 and X3210.
6 MB L2 Cache
NOTE: For Models with Intel® Xeon® processor X3320 and E3110.
4 MB L2 Cache
NOTE: For Models with the Intel® Xeon® processor 3075 and 3065.
2 MB L2 Cache
NOTE: For Models with the Intel® Core2 processor E4600 and E4400.
1 MB L2 Cache
NOTE: For Models with the Intel® Pentium processor E2160.
512 KB L2 Cache
NOTE: For Models with the Intel® Celeron processor 440 and 420.
Chipset Intel® 3210 Chipset
Memory Protection ECC
QuickSpecs
HP ProLiant DL320 Generation 5p
Standard Features
DA - 12854 Worldwide QuickSpecs — Version 12 — 5-28-2008 Page 4

Memory
One of the following
depending on Model
Type PC2-6400 (800MHz) Unbuffered ECC DDR2 SDRAM
Interleaving optional (Enabled when DIMMs populated in pairs)
DIMM Sockets 4
Standard - Xeon E3110
and Xeon 3075 Models
1 GB (1 x 1 GB)
Standard - Xeon X3320
and Xeon X3210 Models
2 GB (2 x 1 GB)
Maximum Memory 8 GB
Network Controller Embedded NC326i Dual Port Gigabit Server Adapter
Expansion Slots
Expansion
Slots #
Technology
Bus
Width
***
Connector
Width
Bus
Number *
Device No. **
Form
Factor
Notes
5
(Standard)
PCIe x1 x8 10 0
Low profile
(half length,
half height)
slot
4
(Standard)
PCIe x8 x8 21 0
Full length, full
height slot
This PCIe slot
can be
replaced with
optional PCI-X
slot below
4
(Optional)
PCI-X
(133MHz,
3.3Volt)
64-bit Not applicable 24 4
Full length, full
height slot
* Default bus assignment (in decimal). Inserting cards with PCI bridges may alter the actual bus assignment number.
** Slots are enumerated differently based on OS. MS OS's enumerate from lowest to highest Device ID by bus (starting with
the lowest bus).
*** Indicates the number of physical electrical lanes running to a PCI-e connector.
Storage Controllers Integrated Intel® 82801IR Serial ATA Host Controller with RAID 0/1 support.
Hot Plug SAS and SATA controllers available via PCI card option.
Storage Optical Drive Optional
2 HDD Models: 12.7mm DVD-ROM, or DVD-RW Drive
4 HDD Models: 9.5mm DVD-ROM, or DVD combo drive
Hard Drives
One of the following
depending on Model
Hard Drives - Hot Plug
SATA/SAS
Up to 2 or 4 hot plug SATA or SAS 3.5" drives
NOTE: Hot-plug and/or SAS support requires
optional HBA or Controller card.
QuickSpecs
HP ProLiant DL320 Generation 5p
Standard Features
DA - 12854 Worldwide QuickSpecs — Version 12 — 5-28-2008 Page 5

Maximum Internal
Storage Type
SATA (2HDD models -
standard)
1.5TB 2 x 750 GB SATA
SATA (4HDD models -
requires optional 4HDD
cage)
3.0TB 4 x 750 GB SATA
SAS (2HDD models
standard - requires
optional PCI controller)
600GB 2 x 300 GB SAS
SAS (4HDD models -
requires optional 4HDD
cage and PCI controller)
1.2TB 4 x 300 GB SAS
Interfaces Serial 1
USB 2.0 5 (2 front, 1 internal (optional), 2 rear)
NOTE: Please see the following URL for additional information
regarding USB support:
http://h18004.www1.hp.com/products/servers/platforms/usb-
support.html
Graphics 1 (rear)
Keyboard 1
Mouse 1
Network RJ-45 2 (NIC 1 shared iLO 2 port)
Dedicated iLO 2 remote
management port
1 (optional)
Graphics Integrated ATI ES1000, 32 MB video standard
16 bit color: maximum resolution of 1600 x 1200
32 bit color: maximum resolution of 1280 x 1024
NOTE: Maximum resolution available via iLO 2 remote console is 1280 x 1024.
Form Factor Rack (1U), (1.70 in/4.32 cm), 26.85" deep
QuickSpecs
HP ProLiant DL320 Generation 5p
Standard Features
DA - 12854 Worldwide QuickSpecs — Version 12 — 5-28-2008 Page 6

HP Insight Control
Management Suites
HP Insight Control Environment delivers foundation management, including remote monitoring,
hardware resource deployment, health monitoring, software version control, performance
monitoring, vulnerability scanning and patch management, and power management.
HP Insight Control Environment installs and licenses the following components by default using a
wizard-based integrated installer:
HP Systems Insight Manager
HP iLO Advanced Pack
HP Rapid Deployment Pack
HP Insight Power Manager
HP Performance Management Pack
HP Vulnerability and Patch Management Pack
Additional ProLiant Essentials software and management tools included on the Insight Control
Management kit can be installed manually
HP Server Migration Pack - Universal Edition
HP Open Service Event Manager
HP Instant Support Enterprise Edition
NOTE: Server Migration Pack - Universal Edition can be installed from the SMP Universal CD
included in the Insight Control Management media kit.
NOTE: For additional product and licensing information about HP Insight Control Environment,
visit: http://www.hp.com/go/ice .
HP Insight Control Environment for Linux (ICE-Linux) provides comprehensive discovery, imaging
& deployment, monitoring, and management for Linux-based ProLiant server platforms. Built on
the industry-leading HP Systems Insight Manager framework, this solution integrates open source
technology with experience leveraged from HP's Linux products in HP ICLE and HP XC Clusters,
while providing paths to the future with developing management technologies.
HP Insight Control management suites and most HP ProLiant Essentials include a one year of 24
x 7 HP Software Technical Support and Update Service ensuring rapid access to HP support staff
and proactive delivery of software updates. For more information about this service, please visit:
http://www.hp.com/services/insight .
Server Management
Stand Alone Software
Product - ProLiant
Essentials
HP Systems Insight
Manager
HP Systems Insight Manager (HP SIM) provides a unified, secure and
extensible standards-based environment to centrally manage servers,
storage and other infrastructure devices, (both HP and non-HP) across
multiple operating system platforms.
ProLiant Essentials
Rapid Deployment Pack
Rapid Deployment Pack (RDP) extends HP Systems Insight Manager
with a complete deployment solution for HP ProLiant servers. RDP
provides a central location to configure server hardware, deploy
Windows, Linux and VMware ESX operating environments and install
HP ProLiant Support Pack drivers using images and scripted profiles.
For more information, visit: http://www.hp.com/go/rdp .
ProLiant Essentials
Server Migration Pack -
Universal Edition
Upgrading, replacing, or virtualizing your existing server? Effortlessly
transition to new virtual or physical HP ProLiant servers or BladeSystem
with automated, accurate and affordable migration of OS, application
and data. SMP Universal automates the manual processes required for
migrating servers between physical or virtual platforms, whether
migrating to VMware or Microsoft virtual machines. SMP Universal
allows all of the following migrations:
physical to ProLiant
physical to virtual
virtual to virtual
QuickSpecs
HP ProLiant DL320 Generation 5p
Standard Features
DA - 12854 Worldwide QuickSpecs — Version 12 — 5-28-2008 Page 7

virtual to ProLiant
NOTE: For more information, visit: http://www.hp.com/go/migrate .
ProLiant Essentials
Performance
Management Pack
Performance Management Pack (offered exclusively through the Insight
Control suites) - a performance management solution that identifies and
explains hardware performance bottlenecks on ProLiant servers and
attached options enabling users to better utilize their valuable resources
Integrated Lights-Out
Advanced Pack
Upgrades the iLO 2 processor with comprehensive remote control
including Virtual KVM remote graphical console, enhanced console
sharing and replay, virtual media (floppy, CD/DVD, USB key), virtual
folders, and enterprise security (directory services and two-factor
authentication).
Integrated Lights-Out
Select Pack
Upgrades the iLO 2 processor with enhanced console sharing and
replay, virtual media (floppy, CD/DVD, USB key), virtual folders,
historical power reporting, power capping and enterprise security
(directory services and two-factor authentication) for servers managed
using remote consoles available in iLO 2 Standard and iLO 2 Standard
Blade Edition.
NOTE: Flexible and volume quantity license kits are available for ProLiant Essentials Value
Packs. Refer to: http://www.hp.com/servers/proliantessentials or the various ProLiant Essentials
Value Pack product QuickSpecs for more information.
Core Infrastructure
Management
SmartStart SmartStart is a tool that simplifies server setup, providing a rapid way to
deploy reliable and consistent server configurations. For more
information, please visit the SmartStart Web site at:
http://www.hp.com/servers/smartstart .
SmartStart version supported (minimum): SmartStart 7.90
Insight Management
Agents
The Insight Management Agents should be installed on all HP servers to
present system instrumentation, health and configuration information
into HP Systems Insight Manager and the HP System Management
Homepage. The HP System Management Homepage aggregates
systems data from Insight Management Agents and other HP
management tools, providing a consolidated browser-based interface for
managing individual servers.
Insight Management Agents and The HP System Management
Homepage are included on ProLiant Support Packs, and can also be
installed using the server profiles provided with the ProLiant Essentials
Rapid Deployment Pack.
For additional information about the Management Agents and the HP
System Management Homepage please visit the management Web site
at: http://www.hp.com/servers/manage .
Subscriber's Choice Subscriber's Choice Driver and Support Alerts/Notifications is a web-
based email subscription service that provides software and driver
change notifications for ProLiant products. Sign up at:
http://www.hp.com/go/subscriberschoice and customize your profile to
receive various new alerts as they become available, on a weekly or
monthly basis.
ProLiant Support Packs
and ROMPaq, software
The latest software, drivers, and firmware fully optimized and tested for
your ProLiant server and options, available through ProLiant Support
Packs the ProLiant Essentials Rapid Deployment Pack, SmartStart or
downloaded from software and drivers download pages website at:
http://www.hp.com/go/support .
QuickSpecs
HP ProLiant DL320 Generation 5p
Standard Features
DA - 12854 Worldwide QuickSpecs — Version 12 — 5-28-2008 Page 8

HP Serviceguard for
Linux (SGLX)
HP Serviceguard for Linux is a high availability clustering solution designed to protect applications
and services from a wide variety of software and hardware failures, monitoring the health of each
server (node) and quickly responding to failures such as those that affect system processes,
system memory, LAN media and adapters, and application processes.
The following is a quick summary of HP Serviceguard for Linux features and support. For the most
recent list of Linux distributions & kernels, servers and storage supported with Serviceguard for
Linux, see the Serviceguard for Linux Certification Matrix, available at:
http://www.hp.com/go/sglx/info .
Supported Linux Distributions:
Red Hat EL 4
Red Hat EL 5
SUSE SLES10
Supported Server Platforms
HP Integrity
HP ProLiant
Selected 3rd party x86 class servers
Physical and virtual server support
Application Integration Toolkits
Oracle Single Instance Database
Serviceguard Extension for SAP for Linux (SGeSAP/LX)
Other Application Integration Toolkits for sendmail, MySQL and more are free to
download at: http://www.hp.com/go/softwaredepot/ha
Disaster Tolerant Solutions
Serviceguard for Linux Extended Distance Cluster (XDC) extends cluster distances up
to 100 km, utilizes software RAID mirroring for data replication and is storage array
independent
HP StorageWorks XP/EVA Cluster Extension Software for Linux (CLX) works
seamlessly with HP Serviceguard for Linux, HP StorageWorks Continuous Access,
and HP Disk Arrays to automate failover and failback between sites
Software updates are distributed by HP Services to customers with support contracts
NOTE: For additional information on HP Serviceguard for Linux, visit: http://www.hp.com/go/sglx
or see the HP Serviceguard for Linux QuickSpecs.
NOTE: HP Serviceguard for Linux products for HP ProLiant and select 3rd party x86 class servers
include one year of 24 x 7 HP Software Technical Support and Update Service ensuring rapid
access to HP support staff and proactive delivery of software updates. For more information about
this service, please visit: http://www.hp.com/services/swsupport .
Industry Standard
Compliance
ACPI 2.0
PCI 3.0 Compliant
PXE Support
WOL Support
Microsoft® Logo certifications
USB 2.0
IPMI 2.0
NOTE: iLO 2 management processor monitors fans, temperature sensors, power supply sensors
and Vrms without having the System Management Driver loaded. In addition to reporting sensor
status from all iLO 2 interfaces, the management processor also reports sensor status to the
operating system through an IPMI 2.0 specified interface.
QuickSpecs
HP ProLiant DL320 Generation 5p
Standard Features
DA - 12854 Worldwide QuickSpecs — Version 12 — 5-28-2008 Page 9

Remote Management Integrated Lights Out 2 (iLO2) Standard Management:
Virtual Text Remote Console (pre-OS only)
Remote Serial Console
Virtual Power Button Control
Virtual Unit ID control
Integrated Remote Console
Dedicated & full function shared network connectivity
Embedded system health
Browser, command line and scripted access
Automatic IP Configuration via DHCP/DNS/WINS
Industry Standard 128-bit Secure Sockets Layer (SSL) and Secure Shell security (SSH)
OS independent hardware health status
IML and iLO Event Logging
Support for 12 user accounts with customizable access privilege
Intelligent
Manageability
Automatic Server Recovery (ASR)
iLO 2 Advanced Pack (optional)
HP Systems Insight Manager
Integrated Management Log
Drive Parameter Tracking (with Smart Array Controllers)
Dynamic Sector Repairing (with Smart Array Controllers)
Pre-Failure Warranty (covers processors, SAS hard drives, and memory)
BIOS Serial Console
Front and Rear Unit ID (UID) button/LED
Security Power-on password
Keyboard password
USB Port control
Removable optical drive assembly (optional)
Removable DVD-ROM Drive Assembly (optional)
Dedicated iLO2 port (optional)
Administrator's password
Server Power Cords North America One 6' Highline (IEC-IEC) power cord ships standard
Japan One 6' Highline (IEC) power cord and one 6' Lowline power cord ship
standard
ROW One 6' Highline (IEC) power cord ships standard
NOTE: HP ProLiant DL320 G5p servers hip standard worldwide with a C13 to C14 2M Highline
jumper cord. Japanese models also include a 2M Lowline power cord. If customers require a local
power cord, they can check the power cord matrix for the appropriate country specific cord.
Please see the following power cord matrix: http://www.hp.com/go/powercordmatrix .
Power Supply Auto-sensing 400-Watt PFC Power Supply, CE Mark Compliant
UPS and PDU Power
Cord Matrix
Please see the UPS and PDU cable matrix that lists cable descriptions, requirements, and
specifications for UPS and PDU units:
http://h18004.www1.hp.com/products/servers/proliantstorage/power-protection/index.html
QuickSpecs
HP ProLiant DL320 Generation 5p
Standard Features
DA - 12854 Worldwide QuickSpecs — Version 12 — 5-28-2008 Page 10

System Fans 3 dual rotor fans ship standard with X3360, X3350, X3320, and E3110 models.
4 dual rotor fans ship standard with all other models (e.g. X3220, X3210, 3075, 3065, E4600,
E4400, E2160, 440 and 420 models).
Ultra Thin Rack
Deployment Overview
For the Ultra Thin Rack Deployment Overview, including best practices for the HP ProLiant DL320
G5p, please see the following URL: www.hp.com/servers/dl320-g5 .
Required Cabling For required cabling information, refer to the Web site at: www.hp.com/servers/dl320-g5 .
OS Support Microsoft Windows Server 2003 (web, standard, and enterprise editions; standard and enterprise
editions for 64-bit extensions)
Microsoft Windows Small Business Server 2003, R2
Microsoft Windows Server 2008
Red Hat Enterprise Linux
SUSE Linux Enterprise Server
NOTE: Support differences will exist between the SATA and SAS configurations.
NOTE: For a more complete and up-to-date listing of supported OSs and versions, please visit our
OS Support Matrix at: http://www.hp.com/go/supportos .
NOTE: For an up-to-date listing of the latest software and drivers available for your server, please
select your server: http://h20000.www2.hp.com/bizsupport/TechSupport/Product.jsp?lang=
en&cc=us&taskId=135&prodTypeId=15351&prodCatId=241435 .
NOTE: For more Linux OS support & certification information, please visit our the ProLiant &
BladeSystem Server Linux matrix
http://h18004.www1.hp.com/products/servers/linux/hpLinuxcert.html
NOTE: For more complete and up-to-date information on how to buy server operating systems
from HP please visit the OS product site at:
http://h18004.www1.hp.com/products/servers/software/OEM.html
Rack Airflow
Requirements
Rack 10000 series Cabinets
The increasing power of new high-performance processor technology requires increased cooling
efficiency for rack-mounted servers. The 10000 Series Racks provide enhanced airflow for
maximum cooling, allowing these racks to be fully loaded with servers using the latest processors.
CAUTION: If a third-party rack is used, observe the following additional requirements to ensure
adequate airflow and to prevent damage to the equipment:
Front and rear doors : If your 42U server rack includes closing front and rear doors, you must
allow 5,350 sq cm (830 square inches) of hole evenly distributed from top to bottom to
permit adequate airflow (equivalent to the required 64 percent open area for ventilation).
Side : The clearance between the installed rack component and the side panels of the rack
must be a minimum of 7 cm (2.75 inches)
CAUTION: Always use blanking panels to fill all remaining empty front panel U-spaces in the rack.
This arrangement ensures proper airflow. Using a rack without blanking panels results in improper
cooling that can lead to thermal damage.
NOTE: For additional information, refer to the Setup and Installation Guide or the Documentation
CD provided with the server, or to the server documentation located in the Support section at the
following URL: http://h18004.www1.hp.com/products/servers/proliantdl320/index.html .
QuickSpecs
HP ProLiant DL320 Generation 5p
Standard Features
DA - 12854 Worldwide QuickSpecs — Version 12 — 5-28-2008 Page 11

Rack Kit The DL320 G5p Fixed Rail System supports installation in racks with square or round mounting
holes (including Compaq/HP 7000, 9000, 10000 and HP series), with an adjustment range of 24" -
36". Installation into Telco 2 post, and 4 post, or threaded holes racks requires a 3rd party option
kit. Go to: www.racksolutions.com for more information.
HP Factory Express
Capabilities
HP Factory Express offers configuration, customization, integration and deployment services for
HP servers and storage products. Customers can choose how their factory solutions are built,
tested, integrated, shipped and deployed.
Factory Express offers service packages for simple configuration, racking, installation, complex
configuration and design services as well as individual factory services, such as image loading,
asset tagging, and custom packaging. HP products supported through Factory Express include a
wide array of servers and storage: HP Integrity, HP ProLiant, HP ProLiant Server Blades, HP
BladeSystem, HP 9000 servers as well as the MSAxxxx, VA7xxx, EVA, XP, rackable tape libraries
and configurable network switches.
For more information on Factory Express services for your specific server model please contact
your sales representative or go to: http://www.hp.com/go/factory-express .
Service and Support HP Care Pack Services provide total care and support expertise with committed response times
designed to meet your IT and business needs.
HP Care Pack services include coverage for the HP branded hardware options qualified for the
server that are purchased at the same time or afterward and internal to the enclosure. It also
includes the 22-inch and smaller external monitors and tower UPS options up to 3kVA. These
items will be covered at the same service level and for the same coverage period as the server.
Coverage of UPS Battery is not included and standard warranty terms & conditions apply. For
servers or storage systems installed within a rack, service also covers all HP qualified rack
options installed within the same rack.
To fully capitalizing on your HP ProLiant servers' capabilities requires a service partner who
thoroughly understands your server technology and systems environment. HP Services, an
industry leader in provision of support solutions provides a range of support services designed to
meet the varying needs of your business. Whether an SMB, or large global corporation, HP has
ProLiant server support offers to help you speedily deploy and maximize system uptime.
Recommended Service - simplify ProLiant solution implementation, maintenance, and
management.
Support - 3 Year 9x5 Next Business Day coverage, excluding HP holidays only
Deployment Service - HW Installation only
Enhanced Service - optimize service level to increase IT performance and availability.
Support - 3 Year 13x5 Same Business Day, 4-Hour response coverage only
Deployment Service - Installation and Start up only
Refer to the information on the Installation of a ProLiant on the ProLiant Data Sheet; to be
delivered on a scheduled basis 8am-5pm, M-F, excluding HP holidays.
NOTE: For a complete listing of service offerings and information visit:
http://www.hp.com/services/proliantservices
http://www.hp.com/go/proliant/carepack
QuickSpecs
HP ProLiant DL320 Generation 5p
Standard Features
DA - 12854 Worldwide QuickSpecs — Version 12 — 5-28-2008 Page 12

NOTE: For the Standard Features shipped in the "Factory Integrated Models", please see the "Configuration Information -
Factory Integrated Models" section.
DL320 G5p X3320 2GB
445431-xx1
Processor Quad-Core Intel® Xeon® processor 3320 (2.50GHz, 6MB L2 cache, 95
Watts, 1333MHz FSB)
Cache Memory 6MB L2 Cache
Chipset Intel® 3210 Chipset
Memory 2 GB (Standard) to 8 GB (Maximum) of ECC PC2-6400 Unbuffered
DDR2 SDRAM Memory
Network Controller Embedded NC326i Dual Port Gigabit Server Adapter
Storage Controller Intel® 82801IR Integrated Serial ATA Host Controller
Hard Drives None ship standard
Internal Storage SAS: 1.2TB maximum; SATA: 3.0TB maximum
NOTE: SAS requires optional PCI Controller.
Optical Drive Optional
Power Supply Auto-sensing 400-Watt PFC Power Supply, CE Mark Compliant
Form Factor Rack (1U), (1.70 in/4.32 cm)
DL320 G5p X3210 2GB
445434-xx1
Processor(s) Quad-Core Intel® Xeon® processor 3210 (2.13GHz, 8MB L2 cache, 95
Watts, 1066MHz FSB)
Cache Memory 8MB L2 Cache
Memory 2 GB (Standard) to 8 GB (Maximum) of ECC PC2-6400 Unbuffered
DDR2 SDRAM Memory
Network Controller Embedded NC326i Dual Port Gigabit Server Adapter
Storage Controller Intel® 82801IR Integrated Serial ATA Host Controller
Hard Drives None ship standard
Internal Storage SAS: 1.2TB maximum; SATA: 3.0TB maximum
NOTE: SAS requires optional PCI Controller.
Optical Drive Optional
Power Supply Auto-sensing 400-Watt PFC Power Supply, CE Mark Compliant
Form Factor Rack (1U), (1.70 in/4.32 cm)
DL320R05p E3110 1GB
445432-xx1
Processor(s) Dual-Core Intel® Xeon® processor E3110 (3.0GHz, 6MB L2 cache, 65
Watts, 1333MHz FSB)
Cache Memory 6MB L2 Cache
Memory 1 GB (Standard) to 8 GB (Maximum) of ECC PC2-6400 Unbuffered
DDR2 SDRAM Memory
Network Controller Embedded NC326i Dual Port Gigabit Server Adapter
Storage Controller Intel® 82801IR Integrated Serial ATA Host Controller
Hard Drives None ship standard
Internal Storage SAS: 1.2TB maximum; SATA: 3.0TB maximum
NOTE: SAS requires optional PCI Controller.
Optical Drive Optional
Power Supply Auto-sensing 400-Watt PFC Power Supply, CE Mark Compliant
Form Factor Rack (1U), (1.70 in/4.32 cm)
QuickSpecs
HP ProLiant DL320 Generation 5p
Models
DA - 12854 Worldwide QuickSpecs — Version 12 — 5-28-2008 Page 13

DL320 G5p X3075 1GB
445433-xx1
Processor Dual-Core Intel® Xeon® processor 3075 (2.66GHz, 4MB L2 cache, 65
Watts, 1333MHz FSB)
Cache Memory 4 MB L2 Cache
Chipset Intel® 3210 chipset
Memory 1 GB (Standard) to 8 GB (Maximum) of ECC PC2-6400 Unbuffered
DDR2 SDRAM Memory
Network Controller Embedded NC326i Dual Port Gigabit Server Adapter
Storage Controller Intel® 82801IR Integrated Serial ATA Host Controller
Hard Drives None ship standard
Internal Storage SAS: 1.2TB maximum; SATA: 3.0TB maximum
NOTE: SAS requires optional PCI Controller.
Optical Drive Optional
Power Supply Auto-sensing 400-Watt PFC Power Supply, CE Mark Compliant
Form Factor Rack (1U), (1.70 in/4.32 cm)
Country Code Key xx=00 North America
xx=29 Japan
xx=37 APD (Asia excluding Japan)
xx=42 EURO (Europe / Middle East / Africa)
xx=AA PRC
QuickSpecs
HP ProLiant DL320 Generation 5p
Models
DA - 12854 Worldwide QuickSpecs — Version 12 — 5-28-2008 Page 14

NOTE: This section lists some of the steps required to configure a Factory Integrated Model. To ensure only valid
configurations are ordered, HP recommends the use of an HP approved configurator. Contact your local sales
representative for information on CTO product offerings and requirements.
NOTE: HP does not allow factory integration of options into standard models listed above. Configure-to-order servers must
start with a CTO Chassis.
NOTE: This product offering does not support HP Factory Express Server Configuration Level 1.
NOTE: FIO indicates that this option only available as a Factory Installable Option.
Step 1: Base Configuration (choose one of the following configurable models)
Models DL320G5p CTO (Configure-To-Order) Chassis 445436-B21
Includes :
Embedded NC326i Dual Port Gigabit Server Adapter
1 full length PCI Express x8 slot and 1 half length low profile PCI Express x8 slot
Integrated Lights-Out 2 (iLO 2) embedded (shared NIC functionality standard)
Intel® 82801IR Integrated Serial ATA Host Controller
Rack (1U) form factor, (1.70 in/4.32 cm)
Fixed, mounting rails
Step 2: Choose Required Options (only one of the following from each list unless
otherwise noted)
Processors Intel® Celeron 420 processor FIO Kit 450125-L21
Intel® Celeron 440 processor FIO Kit 468963-L21
Dual-Core Intel® Pentium E2160 Processor FIO Kit 455035-L21
Dual-Core Intel® Core E4400 processor FIO Kit 455033-L21
Dual-Core Intel® Core E4600 processor FIO Kit 482110-L21
Dual-Core Intel® Xeon® 3065 processor FIO Kit 450143-L21
Dual-Core Intel® Xeon® 3075 processor FIO Kit 450127-L21
Dual-Core Intel® Xeon® E3110 processor FIO Kit 463436-L21
Quad-Core Intel® Xeon® X3210 processor FIO Kit 455031-L21
Quad-Core Intel® Xeon® X3220 processor FIO Kit 450141-L21
Quad-Core Intel® Xeon® X3320 processor FIO Kit 463434-L21
Quad-Core Intel® Xeon® X3350 processor FIO Kit 463432-L21
Quad-Core Intel® Xeon® X3360 processor FIO Kit 489909-L21
Drive Cage DL1U 2 DRV CAGE FIO Kit 450436-B21
DL1U 4 DRV CAGE FIO Kit 450434-B21
Memory 2 GB Unbuffered PC2-6400 ECC DIMM (1 x 2 GB) 450260-B21
1 GB Unbuffered PC2-6400 ECC DIMM (1 x 1 GB) 450259-B21
512 MB Unbuffered PC2-6400 ECC DIMM (1 x 512 MB) 450258-B21
QuickSpecs
HP ProLiant DL320 Generation 5p
Configuration Information - Factory Integrated Models
DA - 12854 Worldwide QuickSpecs — Version 12 — 5-28-2008 Page 15

Step 3: Choose Additional Factory Integratable Options (only one of the following
from each list unless otherwise noted)
SAS HBAs HP SC44Ge Host Bus Adapter 416096-B21
HP 8 Internal Port SAS HBA with RAID 347786-B21
NOTE: Any SAS HBA CTO purchase automatically includes the HP HBA SAS-
SATA 4x1LN Cable Kit (452130-B21).
Controllers HP Smart Array E200/128 BBWC Controller 411508-B21
HP Smart Array P400/256MB Controller 405132-B21
HP Smart Array P400/512MB BBWC Controller 411064-B21
HP Smart Array E500/256MB Controller 435129-B21
HP Smart Array P800/512MB BBWC Controller 381513-B21
NOTE: Any Smart Array Controller CTO purchase automatically includes the HP
HBA SAS-SATA 4x1LN Cable Kit (452130-B21).
452130-B21
QuickSpecs
HP ProLiant DL320 Generation 5p
Configuration Information - Factory Integrated Models
DA - 12854 Worldwide QuickSpecs — Version 12 — 5-28-2008 Page 16

NOTE: Some options may not be factory integratable. Contact your local sales representative for additional information.
ProLiant DL320 G5p
Unique Options
DL320G5p DVD Drive 9.5mm
NOTE: Only supported on 4HDD models.
450432-B21
DL320G5p CD-RW/DVD-ROM Combo Drive 9.5mm
NOTE: Only supported on 4HDD models.
451688-B21
DL320G5p DVD-ROM Drive 12.7mm
NOTE: Only supported on 2HDD models.
449991-B21
DL320G5p DVD-RW Drive 12.7mm
NOTE: Only supported on 2HDD models.
449998-B21
DL320G5p PCI-X RISER BD 450341-B21
DL320G5p iLO2 PORT OPT KIT
NOTE: For dedicated port functionality.
450343-B21
DL1U 4 DRV CAGE KIT 450434-B21
HP Insight Control
Management Suites
NOTE: Electronic licensing options are available for Insight Control suites
software products. Please see the appropriate Insight Control QuickSpecs for
additional information.
HP Insight Control Environment
HP Insight Control Environment, No Media 1-Server License including 1 year of
24x7 Technical Support and Updates
NOTE: This part number can be purchased as a single license or as multiple
licenses with a single activation key. Customer will receive a license entitlement
certificate via e-mail. The license entitlement certificate must be redeemed
online or via fax in order to obtain the license activation key(s). Includes one
year of 24 x 7 HP Software Technical Support and Update Service. Only
available directly from HP and select resellers in the Americas region.
452148-B22
HP Insight Control Management Software Media Kit
NOTE: Insight Control Management DVD media without licenses. Contains
Insight Manager and Essentials software products and components licensed by
Insight Control Management suites. Uses an integrated installer to perform quick
and accurate software installation and updates.
436222-B21
NOTE: For additional License Kits, please see the QuickSpecs at:
http://h18000.www1.hp.com/products/quickspecs/12631_div/12631_div.html
HP Insight Control Environment for Linux
HP Insight Control Environment for Linux v2.0, Media pack (CD) - No licenses
included
NOTE: This optional Media pack CD contains the ISO image for HP Insight
Control Environment for Linux, HP System Insight Manager, and an integrated
installer. Servers must be acquired separately. This Media pack is optional
because the latest ISO image and latest updates may be downloaded at no cost
from: http://www.hp.com/go/ice-linux (click on Download button).
464422-B21
HP Insight Control Environment for Linux v2.0, No Media, 1-Server license,
including One year of 24x7 Technical Support and Updates
NOTE: This part number can be used to purchase one (1) license with a single
activation key. Customer will receive a printed license entitlement certificate via
physical shipment. The license entitlement certificate must be redeemed online
or via fax in order to obtain the license activation key(s). Includes one year of 24
x 7 HP Software Technical Support and Update Service. One certificate is
shipped for each license.
464423-B21
NOTE: For additional License Kits, please see the QuickSpecs at:
http://h18000.www1.hp.com/products/quickspecs/13019_div/13019_div.html
QuickSpecs
HP ProLiant DL320 Generation 5p
Options
DA - 12854 Worldwide QuickSpecs — Version 12 — 5-28-2008 Page 17

Server Management
Stand Alone Software
Product - ProLiant
Essentials
NOTE: Electronic licensing options are available for select ProLiant Essentials
software products. Please see the appropriate ProLiant Essentials QuickSpecs
for additional information.
Deploy
ProLiant Essentials Rapid Deployment Pack
ProLiant Essentials Rapid Deployment Pack No Media 1-Server License
including 1 year of 24x7 Technical Support and Updates
NOTE: This license allows 1 server to be deployed and managed via RDP.
Customer will receive a printed license entitlement certificate via physical
shipment. The license entitlement certificate must be redeemed online or via fax
in order to obtain the license activation key(s). Includes one year of 24 x 7 HP
Software Technical Support Service
NOTE: For additional License Kits, please see the QuickSpecs at:
http://h18000.www1.hp.com/products/quickspecs/11053_div/11053_div.html
452151-B21
HP Server Migration Pack - Universal Edition
HP Server Migration Pack - Universal Edition, No Media, Physical / Virtual to
ProLiant Single Migration License, including 1 year of 24x7 Technical Support
and Updates
NOTE: This license allows 1 physical to ProLiant or virtual to ProLiant migration.
Customer will receive a printed license entitlement certificate and documentation
via physical shipment. The license entitlement certificate must be redeemed
online or via fax in order to obtain the license activation key(s). Includes one
year of 24 x 7 HP Software Technical Support and Update Service.
460750-B21
HP Server Migration Pack - Universal Edition, No Media, Physical / Virtual to
Virtual Single Migration License, including 1 year of 24x7 Technical Support and
Updates
NOTE: This license allows 1 physical to virtual or virtual to virtual migration.
Customer will receive a printed license entitlement certificate and documentation
via physical shipment. The license entitlement certificate must be redeemed
online or via fax in order to obtain the license activation key(s). Includes one
year of 24 x 7 HP Software Technical Support and Update Service.
460753-B21
HP Server Migration Pack - Universal Edition, No Media, 1-Year Unlimited
Migration License, including 1 year of 24x7 Technical Support
NOTE: This license allows unlimited migrations (physical to ProLiant, physical to
virtual, virtual to virtual, and virtual to ProLiant) for one year. Customer will
receive a printed license entitlement certificate and documentation via physical
shipment. The license entitlement certificate must be redeemed online or via fax
in order to obtain the license activation key(s). Includes one year of 24 x 7 HP
Software Technical Support Service.
460756-B21
NOTE: For additional License Kits, please see the QuickSpecs at:
http://h18000.www1.hp.com/products/quickspecs/12855_div/12855_div.html
Control
Integrated Lights-Out Select Pack
ProLiant Essentials Integrated Lights-Out Select Pack, No Media, 1-Server
License
NOTE: For additional License Kits, please see the QuickSpecs at :
http://h18000.www1.hp.com/products/quickspecs/12362_div/12362_div.html
452158-B21
Integrated Lights-Out Advanced Pack
Integrated Lights-Out Advanced Pack, No Media ,1 Server License
NOTE: For additional License Kits, please see the QuickSpecs at:
http://h18000.www1.hp.com/products/quickspecs/10861_div/10861_div.html
452141-B21
Optimize
ProLiant Essentials Virtual Machine Management Pack
ProLiant Essentials Virtual Machine Management Pack, No Media, 1-Server 452153-B21
QuickSpecs
HP ProLiant DL320 Generation 5p
Options
DA - 12854 Worldwide QuickSpecs — Version 12 — 5-28-2008 Page 18

License, including 1 year of 24x7 Technical Support and Updates
NOTE: Customer will receive a printed license entitlement certificate via physical
shipment. The license entitlement certificate must be redeemed online or via fax
in order to obtain the license activation key(s). Includes one year of 24 x 7 HP
Software Technical Support and Update Service.
NOTE: For additional License Kits, please see the QuickSpecs at:
http://h18000.www1.hp.com/products/quickspecs/12328_div/12328_div.html
NOTE: Flexible and volume quantity license kits are available for ProLiant
Essentials Value Packs. Refer to: http://www.hp.com/servers/proliantessentials
or the various ProLiant Essentials QuickSpecs for more information.
Memory (DIMMs) 2 GB Unbuffered PC2-6400 ECC DIMM (1 x 2 GB) 450260-B21
1 GB Unbuffered PC2-6400 ECC DIMM (1 x 1 GB) 450259-B21
512 MB Unbuffered PC2-6400 ECC DIMM (1 x 512 MB) 450258-B21
Port Options Internal USB Kit 451363-B21
Serial/Parallel Port OPT KIT 401222-B21
Optical Drives DL320G5p DVD Drive 9.5mm
NOTE: Only supported on 4HDD models.
450432-B21
DL320G5p CD-RW/DVD-ROM Combo Drive 9.5mm
NOTE: Only supported on 4HDD models.
451688-B21
DL320G5p DVD-ROM Drive 12.7mm
NOTE: Only supported on 2HDD models.
449991-B21
DL320G5p DVD-RW Drive 12.7mm
NOTE: Only supported on 2HDD models.
449998-B21
Hard Drives Hot Plug SAS 3.5" Drives
HP 300GB 3G SAS 15K 3.5" SP HDD 431944-B21
HP 300GB 3G SAS 15K 3.5" DP HDD 416127-B21
HP 146GB 3G SAS 15K 3.5" SP HDD 375872-B21
HP 146GB 3G SAS 15K 3.5" DP HDD 384854-B21
HP 72GB 3G SAS 15K 3.5" SP HDD 375870-B21
HP 72GB 3G SAS 15K 3.5" DP HDD 384852-B21
NOTE: Serial Attached SCSI - SAS Hard Drives are only supported with optional
SAS HBA or RAID cards.
NOTE: Please see the Hard Drive QuickSpecs for Technical Specifications such
as capacity, height, width, interface, transfer rate, seek time, physical
configuration, and operating temperature:
http://h18000.www1.hp.com/products/quickspecs/12244_div/12244_div.html
(Worldwide)
3.5" SATA Hot Plug Drives
HP 750GB 1.5G SATA 7.2K 3.5" HDD 432341-B21
HP 500GB 1.5G SATA 7.2K 3.5" HDD 395473-B21
HP 250GB 1.5G SATA 7.2K 3.5" HDD 349239-B21
HP 160GB 1.5G SATA 7.2K 3.5" HDD 349238-B21
HP 80GB 1.5G SATA 7.2K 3.5" HDD 349237-B21
NOTE: Serial ATA hot-plug capability and drive LEDs are not supported by the
DL320 G5p embedded SATA storage controller.
QuickSpecs
HP ProLiant DL320 Generation 5p
Options
DA - 12854 Worldwide QuickSpecs — Version 12 — 5-28-2008 Page 19

NOTE: SATA drives have a 1 year warranty. Please see the QuickSpecs for
Technical Specifications such as capacity, height, width, interface, transfer rate,
seek time, physical configuration, and operating temperature:
http://h18000.www1.hp.com/products/quickspecs/11940_div/11940_div.html
(Worldwide)
Storage Controllers SAS Controllers
Smart Array E200 Controller
NOTE: The HP Smart Array E200 Controllers require the purchase of the HP
HBA SAS-SATA 4x1LN Cable Kit (PN: 452130-B21).
HP Smart Array E200/128 BBWC Controller 411508-B21
128-MB BBWC (Battery-Backed Write Cache) Enabler
NOTE: Supports the Smart Array E200 Controller, Smart Array 641 Controller,
Smart Array 642 Controller.
351580-B21
Smart Array E500 Controller
HP Smart Array E500/256MB Controller 435129-B21
Smart Array P400 Controller
NOTE: The HP Smart Array P400 Controllers require the purchase of the HP
HBA SAS-SATA 4x1LN Cable Kit (452130-B21).
HP Smart Array P400/256MB Controller 405132-B21
HP Smart Array P400/512MB BBWC Controller 411064-B21
Smart Array P400 Battery Attach Kit
NOTE: This option kit contains a 24" battery cable and adhesive material for
installing a battery into the server if a Smart Array P400 is integrated outside of
the factory. For all solutions, please refer to the server QuickSpecs and User's
Manual for detailed installation instructions.
417836-B21
Battery-backed write cache upgrade
NOTE: Battery only. For Smart Array P400 Controller only.
383280-B21
512MB Battery-backed write cache upgrade
NOTE: For Smart Array P400 Controller only.
405148-B21
HP ProLiant P800 Controller
HP Smart Array P800/512MB BBWC Controller 381513-B21
NOTE: Please see the following QuickSpecs for Technical Specifications and
additional information:
http://h18000.www1.hp.com/products/quickspecs/12460_div/12460_div.html
(Smart Array E200 Controller)
http://h18000.www1.hp.com/products/quickspecs/12700_div/12700_div.html
(Smart Array E500 Controller)
http://h18000.www1.hp.com/products/quickspecs/12400_div/12400_div.html
(Smart Array P400 Controller)
http://h18000.www1.hp.com/products/quickspecs/12616_div/12616_div.html
(Smart Array P800 Controller)
SAS HBA
HP SC44Ge Host Bus Adapter 416096-B21
HP 8 Internal Port SAS HBA with RAID
NOTE: The HP SC44Ge HBA and HP 8 Internal Port SAS HBA with RAID
require the purchase of the HP HBA SAS-SATA 4x1LN Cable Kit (452130-B21).
347786-B21
HP HBA SAS-SATA 4x1LN Cable Kit
NOTE: This option is required for any internal port HBA or controller that has a
standard 4 port SAS/SATA connector.
452130-B21
QuickSpecs
HP ProLiant DL320 Generation 5p
Options
DA - 12854 Worldwide QuickSpecs — Version 12 — 5-28-2008 Page 20
