HP vc4815 - Thin Client User manual

Service Reference Guide
HP Compaq vc4815 Thin Client
Document Part Number: 480421-001
January 2008

© 2008 Hewlett-Packard Development Company, L.P.
HP, Hewlett Packard, and the Hewlett-Packard logo are trademarks of
Hewlett-Packard Company in the U.S. and other countries.
Compaq, and the Compaq logo are trademarks of Hewlett-Packard Development
Company, L.P. in the U.S. and other countries.
Microsoft, Windows, and Windows NT are U.S. registered trademarks of
Microsoft Corporation.
Transmeta, the Transmeta logo, Crusoe, the Crusoe logo, and combinations
thereof are trademarks of Transmeta Corporation in the U.S.A. and other
countries.
All other product names mentioned herein may be trademarks of their respective
companies.
The information contained herein is subject to change without notice. The only
warranties for HP products and services are set forth in the express limited
warranty statements accompanying such products and services. Nothing herein
should be construed as constituting an additional warranty. HP shall not be liable
for technical or editorial errors or omissions contained herein.
This document contains proprietary information that is protected by copyright. No
part of this document may be photocopied, reproduced, or translated to another
language without the prior written consent of Hewlett-Packard Company.
WARNING: Text set off in this manner indicates that failure to follow
directions could result in bodily harm or loss of life.
CAUTION: Text set off in this manner indicates that failure to follow
directions could result in damage to equipment or loss of information.
△
Service Reference Guide
HP Compaq vc4815 Series Thin Client
First Edition (Jan 2008)
Document Part Number: 480421-001

Product Description
Network Firmware ..........................................................................................................1–1
HP Compaq Thin Client vc4815 Series ..........................................................................1–2
Serial Number Location ..................................................................................................1–6
Connecting USB Equipment ...........................................................................................1–6
Locating Additional Information ....................................................................................1–7
Spare Parts Lists
vc4815 Series Spare Parts List ........................................................................................2–1
HP vc4815 Series Setup (F10) Utility
Using HP vc4815 Series Setup (F10) Utility ..................................................................3–1
Diagnostics and Troubleshooting
Diagnostic Front Panel LEDs and Audible Codes ..........................................................4–1
Appendix A vc4815 Serial ports definition
Contents
Service Reference Guide www.hp.com iii

Contents
Upload the Flash Image and system BIOS
Upload the Flash image and BIOS ....................................................................................5–1
Thin Client vc4815 Specifications 6-1
iv www.hp.com Service Reference Guide

1
Product Description
The HP Compaq Thin Client vc4815 Series are Redflag Linux-based
terminals that connect over a network to a server where all processing
and storage occurs. Because of the nature of the products,
troubleshooting is significantly simpler than on a standard PC and
previous thin clients.
The Graphical User Interface (GUI) is Chinese on all thin clients. If
you are using a foreign language keyboard, you will need to set
localized settings to perform the localization between a server-based
application and the device, but interaction with the unit itself remains in
Chinese.
Network Firmware
PXE (Pre-boot Execution Environment) is supported on all HP
Compaq Thin Client vc4815 Series products.
PXE allows a client to boot from a server on a network prior to
booting the embedded Operating System (OS) from the local Flash
module. As long as the system is connected to AC power, the Network
Interface Controller (NIC) on a PXE-enabled client remains powered
even when the system is turned off. This allows a network
administrator to remotely wake up the unit and perform various
management tasks, including loading the operating system and other
software onto the device from a server over the network.
Service Reference Guide www.hp.com 1-1

Product Description
HP Compaq Thin Client vc4815 Series
Front view - vc4815
1 Power button 3 Flash activity LED
2 Power LED 4 USB ports (2)
Service Reference Guide www.hp.com 1-2

Product Description Product Description
HP Compaq Thin Client vc4815 Series
Rear View of the vc4815
1 PS/2 connectors (2) 5 Power connector
2 Serial connectors (4) 6 Lock Slot
3 Monitor connector 7 Ethernet RJ-45 connector
4 Universal Serial Bus (USB)
connectors (2) 8 Parallel connector
CAUTION: The vc4815 Series power cord connector is for use only
with the supplied power adaptor. Replace only with the same or equivalent
type as recommended by the manufacturer.
△
Service Reference Guide www.hp.com 1-3

Product Description
Serial Number Location
The serial number is displayed on the side of the unit.
Connecting USB Equipment
USB mouse devices and keyboards do not require special drivers and
are considered to be plug and play peripherals. Certain USB devices
such as printers and modems, however, may require special drivers.
For information on requirements for special drivers, refer to the
documentation that is included with the USB device.
Service Reference Guide www.hp.com 1-4

Product Description
Locating Additional Information
The following documentation is available to support these products:
Quick Setup
Hardware Reference Guide
Redflag Linux User manual
Customer and Service Notifications, Bulletins and Advisories
Quickspecs
✎Documentation, white papers, and drivers are subject to change. For the
latest HP thin client documentation, visit the following Web site:
http: //h18004.www1.hp.com/products/thinclients/software.html
Service Reference Guide www.hp.com 1-5

2
Spare Parts Lists
vc4815 Series Spare Parts List
The spare parts tables that follow provide a listing of the spare parts
available for the Thin Client vc4815 Series.
vc4815 Series Spare Parts Table
Description Spare Part
Number
SPS-Base, vc4815 512F/512R Linux 458813-001
SPS-Base, vc4815 1GBF/512R Linux 458814-001
SPS-Base, vc4815 2GBF/512R Linux 458815-001
SPS-KYBD USB, Basic, Vista-PRC 435382-AA1
SPS-MOUSE,OPTICAL CARBONITE 390938-001
For a full list of supported and leveraged Hewlett-Packard and third
party options, go to:
http://h18004.www1.hp.com/products/thinclients/software.html
Service Reference Guide www.hp.com 1-6

3
HP vc4815 Series Setup
(F10) Utility
Using HP vc4815 Series Setup (F10) Utility
The Setup utility can be accessed only by turning the computer on or
restarting the system. To access the Setup Utility menu, complete the
following steps:
1. Turn on or restart the computer.
2. When the F10 <BIOS Setup> message displays in the task bar
at the bottom of the screen, press the F10 key.
✎If you do not press the F10 key while the message is displayed, you
must restart the computer again to access the utility. When the F10
Post Screen display is set to zero seconds, it may be necessary to
press and hold F10 on the keyboard, then power on the computer.
3. A choice of five menu headings and five task headings appears in
the Setup Utility menu:
Menu Headings: System Information, Standard CMOS Features,
Advanced BIOS Features, Integrated Peripherals, and Power
Management Setup.
Task Headings: Load Defaults Setting, Set Supervisor
Password, Set User Password, Save Setting and Exit, and
Exit without Saving.
Service Reference Guide www.hp. com 3-1

HP vc4815 Series Setup (F10) Utility
4. Use the arrow (up and down, or left and right) keys to select the
appropriate heading, then press the Enter key. To return to the
Setup Utility menu, press the Esc key.
5. To apply and save changes, select Save Setting and Exit Setup.
✎If you have made changes that you do not want applied, select
Exit without Saving.
✎To reset to factory settings, select Load Defaults Setting. This
option will restore the original factory system defaults.
CAUTION: Do NOT turn the computer power OFF while the ROM
is saving your F10 Setup changes because the CMOS could become
corrupted. It is safe to turn off power to the computer ONLY after you exit
theF10Setupscreen.
△
vc4815 Series Setup Utility
Heading Option Description
System
Information Lists:
- Product name
- BIOS Version
- BIOS Release Date
- System Chipset Type
- Processor type
- Processor Speed
- CPU ID
- DDR Memory Size
- UUID (Universal Unique ID)
- Chassis Serial Number
- Set Asset TAG number
- Asset Tag Number
✎Support for specific Setup options may vary depending on your
hardware configuration.
Service Reference Guide www.hp.com 3-2

HP vc4815 Series Setup (F10) Utility
vc4815 Series Setup Utility (Continued)
Heading Option Description
System Date Allows you to set the date
System Time Allows you to set the time.
IDE channel 0
Master
IDE Channel 1
Master
Indicates ATA Flash settings
Standard
CMOS
Features
Halt on Allows you to select system response
when POST Error has been detected.
Quick Power
On Self Test Allows the system to skip certain tests while booting so the unit has a faster
boot.
Hard Disk Boot
Priority Allows Setting of ATA Flash Disk or Bootable Add-in Cards Boot Priority
First Boot
Device Select Boot Device Priority. The default is set to Hard Disk.
Second Boot
Device Select Boot Device Priority
Third Boot
Device Select Boot Device Priority
Boot other
Device Enable/disable boot from other device
Bootup
NumLock
Status
Select Power On state for NumLock.
Advanced
BIOS
Features
Security
Option Select whether the Password is required every time the system boots or only when
you enter Setup.
✎Support for specific Setup options may vary depending on your
hardware configuration.
Service Reference Guide www.hp.com 3-3

HP vc4815 Series Setup (F10) Utility
vc4815 Series Setup Utility (Continued)
Heading Option Description
USB Controller Enable/disable USB controller
Integrated
Audio Enable/disable onboard AC97 audio controller
Network
Controller Enable/disable onboard LAN device
Onboard Serial
port 1
Onboard Serial
port 2
Onboard Serial
port 3
Onboard Serial
port 4
Select serial port base IO port address
and IRQ
Onboard Parallel
Port Select parallel port base IO port address and IRQ
Parallel Mode Select parallel port transfer mode
Integrated
Peripherals
ECP Mode
Use DMA Select DMA channel if parallel is Operated in ECP mode.
Restore On
AC/Power Loss Allows you to set off, On, Last State
Resume on PME Enable/disable system wakeup capability
for onboard LAN device and PCI Card
Wake on Ring Enable/disable Wake on Ring
Power
Manage-
ment Setup
Resume On
Alarm Enable/disable Resume On Alarm, allow to set Date(of month), Resume
Time(hh:mm:ss)
Load Defaults
Setting Select Yes or No (Y/N)
✎Support for specific Setup options may vary depending on your
hardware configuration.
Service Reference Guide www.hp.com 3-4

HP vc4815 Series Setup (F10) Utility HP vc4815 Series Setup (F10) Utility
Heading Option Description
vc4815 Series Setup Utility (Continued)
Heading Option Description
Set
Supervisor
Password
Allows you to set and enable the
administrative password.
✎If the administrative password is set, it
is required to change the Setup options,
flash the ROM, and make changes to
certain plug and play settings under
Windows
Set User
Password Allows you to set and enable the user
password.
✎When the user password is set,
it prevents unauthorized access to the
user’s setup. User password provides
read-only access to Setup options.
Save
Setting
and Exit
Saves data to CMOS
Exit
without
Saving
Exits the Setup Utility without saving any
changes.
✎Support for specific Setup options may vary depending on your
hardware configuration.
Service Reference Guide www.hp.com 3 -5

4 Diagnostics and Troubleshooting
POST Diagnostic Front Panel LEDs and Audible
Codes
This section covers the front panel LED codes as well as the audible codes that may occur
before or during POST that do not necessarily have an error code or text message
associated with them.
✎If you see flashing LEDs on a PS/2 keyboard look for flashing LEDs on the front
panel of the computer and refer to the following table to determine the front panel
LED codes.
✎Recommended actions in the following table are listed in the order in which they
should be performed.
Diagnostic Front Panel LEDs and Audible Codes
Possible Cause Beeps &
LED blink Activity Recommended Action
Computer on. None Green Power LED On. None
Pre-video memory 5
Green Power LED flashes
five
times, once every second,
followed by a two second
pause.
Beeps stop after fifth
iteration but LEDs continue
until problem is solved.
CAUTION: To avoid damage to the DIMMs or the system
board, you must unplug the computer power cord before
attempting to reseat, install, or remove a DIMM module.
1. Reseat DIMMs.
2. Replace DIMMs one at a time
to isolate the faulty module.
3. Replace third-Party memory with HP memory.
4.Replace the system board
Service Reference Guide www.hp.com 4-1

Diagnostic Front Panel LEDs and Audible Codes
Possibl
e Cause Beeps & LED
blink
Activity Recommended Action
System
unable
to power
on.
None System does
not power on
and LEDs are
not flashing.
Press and hold the power button for less than 4
seconds.
If the hard drive LED turns green, the power button
is working correctly. Then, Replace the system
board.
OR
If the hard drive LED does not turn on green
then:
1. Check that the unit is plugged into a working AC
outlet.
2. Check that both power supply cables are properly
connected
to the system board.
3. Check to see if the 5V_aux light on the system
board is turned on. If it is turned on, then replace
the power button
harness. If the problem persists, replace the system
board.
4. If the 5V_aux light on the system board is not
turned on, remove the expansion cards one at a
time until the 5V_aux light on the system board
turns on. It the problem persists, replace the power
adapter.
✎*Replacing the system board should ONLY be the last resort.
** Replacing the power supply should ONLY be the last resort.
Service Reference Guide www.hp.com 4-2

5
Reload Flash Image and BIOS
System Requirements
To create a recovery device for the purpose of reflashing or restoring
the software image on the ROM, you will need the following:
One or more HP Compaq vc4815 Series Thin Clients
USB flash device 512MB Compatible USB flash devices (drive
keys) are available from
www.diskonkey.com.
This restore method will not work with all USB flash devices.
USB flash devices with multiple partitions generally do not
support this restore method. The range of USB flash devices
available on the market is constantly changing. Not all USB flash
devices (drive keys) have been tested with the HP Compaq Thin
Client Imaging Tool.
USB CD-ROM drive for thin client (if using the ISO Image
option)
Before using the utility, you must download the appropriate image
from http://www.hp.com/products/thinclientsoftware.
Service Reference Guide www.hp.com 5-14

Reload image and system BIOS
Hainan Image Reloading
1, Download the Image file *.gho from web.
2, Make a DOS Bootable USB flash drive(>=512M). Copy the image file and
ghost.exe (ver11.0.1) to the USB flash drive.
3, Boot from the USB device. Run ghost.exe.
System BIOS Update
1. Download the SoftPaq .EXE file to a directory on your hard drive.
2. Execute the downloaded file and follow the on-screen instructions.
3. Choose one of the following three options when presented:
- Create BIOS Flash Diskette,
- Create BIOS Flash DriveKey
4, Boot Unit with the diskette or Flash DriveKey made last in step.
Do not power off or reset the unit during flash BIOS process.
ServiceReferenceGuide www.hp.com 5-2

6
Thin Client vc4815 Specifications
Specifications - vc4815 Series
Item Description
Processor VIA C7 1GHz
Chipset VIA CN700 + 8237R
Operating System Redflag Linux (Chinese version only)
Flash Memory Apacer ADMII series 44PIN 180 degree DOM,
512 MB, 1GB, 2GB
2 slots
Memory HP 512 MB DDR2 533 SDRAM or DDR2 667 SDRAM downgraded
to 533 One slot
(NOTE: 16 MB of system RAM is reserved for graphics memory)
Graphics VIA S3 Unichromo Pro Graphic integrated
PCI Expansion No
Browser Firefox Explorer with java support
Client Management
Software Altiris Deployment Solution (client agent)
Terminal Personalities
Standard Yes, terminal emulation tool under Linux
Power adapter 65W
Keyboard USB or PS/2 (both supported)
Keyboard included with every thin client. Type of included
keyboard (USB or PS/2) varies by region
Mouse USB or PS/2 (both supported)
Keyboard included with every thin client. Type of included
keyboard (USB or PS/2) varies by region
GV665PA#AB2 vc4815
vc4815 LNX 512F/512R
PRC
GV666PA#AB2
vc4815 LNX 1GBF/512R
PRC
GV667PA#AB2
vc4815 LNX 2GBF/512R
PRC
Foot stand Yes
Service Reference Guide www.hp.com 6-1
