Introduction
IntroductionIntroduction
Introduction
Gain a competitive edge with our simplest and most affordable thin client! Designed for remote computing solutions in ICA and RDP
environments, you will experience desktop-like performance in task-oriented work environments such as general office, medical,
financial, educational, government, and call centers.
1. Power button 10. Secure USB compartment
2. Flash activity indicator 11. Kensington lock slot
3. Power on indicator 12. USB connectors (4)
4. Audio connector (headphone out) 13. PS/2 connectors (2)
5. Audio connector (mic in) 14. VGA connector
6. USB connectors (2) 15. Serial port connector
7. Vertical stand 16. +12V DC power input
8. Feet (4) for horizontal orientation 17. Parallel port connector
9. HP Quick Release mounting points (4) 18. 10/100 RJ-45
QuickSpecs
HP Compaq t5135 Thin Client
HP Compaq t5135 Thin ClientHP Compaq t5135 Thin Client
HP Compaq t5135 Thin Client
Overview
DA - 12660 North America — Version 14 — March 18, 2009 Page 1

At A Glance
At A GlanceAt A Glance
At A Glance
HP ThinConnect Operating System
VIA Eden 400 MHz processor
128 MB system memory (16 MB reserved for video)
64 MB Flash
Includes one parallel, one serial, two PS/2, and eight USB 2.0 ports (four in back, two in front, and two in a secure USB
compartment).
Two USB ports and audio ports in front for your convenience.
Two USB ports in a secure compartment help prevent theft with USB options hidden inside and out of your way. Great
for safeguarding USB wireless and Flash devices.
Run your HP t5135 in the familiar local mode with settings stored locally, or run it in a "stateless" (network) mode with settings
stored remotely. Take the unit out of the box, attach it to the network and it downloads settings automatically. This is our
easiest client ever to deploy and manage, and it's perfect for office environments with open seating.
HP's alliance with Altiris brings a leading management solution to the thin client market. Altiris Deployment Solution's
standards-based, advanced thin client management solution helps reduce the costs of deploying, updating, and maintaining
your thin clients. Full client license included with each HP client!
Exclusive HP ThinState Tools offers in-box, easy-to-use, scalable image deployment and recovery tools. HP ThinState Tools
allow administrators to make changes to the image or settings on one "master" client, capture the new image or settings on a
USB flash drive or the thin client itself, and then easily deploy it to "target" thin clients.
Support for selected options and peripherals.
Protected by Hewlett-Packard Services, including a limited three-year hardware warranty – certain restrictions and exclusions
apply.
QuickSpecs
HP Compaq t5135 Thin Client
HP Compaq t5135 Thin ClientHP Compaq t5135 Thin Client
HP Compaq t5135 Thin Client
Overview
DA - 12660 North America — Version 14 — March 18, 2009 Page 2

Models
ModelsModels
Models
RK271AA#ABA
RK271AA#ABARK271AA#ABA
RK271AA#ABA
RK271AT#ABA
RK271AT#ABARK271AT#ABA
RK271AT#ABA
(SmartBuy or Promo)
RM081AA#ABA
RM081AA#ABARM081AA#ABA
RM081AA#ABA
(TAA compliant)
1
Model Name
Model NameModel Name
Model Name HP Compaq t5135 Thin Client
Processor
ProcessorProcessor
Processor VIA Eden 400 MHz
Flash
FlashFlash
Flash 64 MB
System Memory
System MemorySystem Memory
System Memory 128 MB RAM (16 MB reserved for video)
Operating System
Operating SystemOperating System
Operating System HP ThinConnect
Keyboard
KeyboardKeyboard
Keyboard USB or PS/2 (both supported)
Keyboard included with every thin client. Type of included keyboard (USB or
PS/2) varies by region.
Mouse
MouseMouse
Mouse USB or PS/2 (both supported)
Mouse included with every thin client. Type of included mouse (USB or PS/2)
varies by region.
1
Product complies with U.S. Trade Agreement Act (TAA). Available in U.S only.
QuickSpecs
HP Compaq t5135 Thin Client
HP Compaq t5135 Thin ClientHP Compaq t5135 Thin Client
HP Compaq t5135 Thin Client
Standard Features - Models
DA - 12660 North America — Version 14 — March 18, 2009 Page 3

Part Number
Part NumberPart Number
Part Number
Accessories
AccessoriesAccessories
Accessories HP Integrated Work Center Stand GN783AA
HP Quick Release Kit EM870AA
HP/Kensington Cable Lock PC766A
50 Watt External Power Supply FJ851AA
Communications
CommunicationsCommunications
Communications Belkin USB Wireless 802.11b/g
1
HP4050
Input Devices
Input DevicesInput Devices
Input Devices HP PS/2 Standard Keyboard DT527A#ABA
HP USB Standard Keyboard DT528A#ABA
HP USB Smartcard Keyboard ED707AA#ABA
HP PS/2 2-Button Scroll Mouse DD440B
HP PS/2 2-Button Optical Scroll Mouse EY703AA
HP USB 2-Button Optical Scroll Mouse DC172B
Monitors
MonitorsMonitors
Monitors ELO Touch 1529L Flat Panel – USB/serial combo
1,2
E926109
ELO Touch 1515L Flat Panel – USB/serial combo
1,2
E849124
ELO Touch 1725C CRT – USB/serial combo
1,2
E248189
ELO Touch 1526C CRT – USB/serial combo
1,2
E833965
HP L5006tm LCD Touchscreen – USB/serial combo
1,2
RB146AA
Security
SecuritySecurity
Security HP USB Smartcard Keyboard ED707AA
SCM USB Smart Card Reader SCR331
1904622
Digital Privacy SCR331 USB Smart Card Reader
1904054
Envoy Data SCR331 USB Smart Card Reader
1904054
TxSystems SCR331 USB Smart Card Reader
1904054
HP/Kensington Cable Lock PC766A
Storage
StorageStorage
Storage Apacer 512 GB Disk on Key (DOK)
1
AP-HHR512HD2
Apacer 1 GB Disk on Key (DOK)
1
AP-HHR100HD2
Apacer 2 GB Disk on Key (DOK)
1
AP-HHR2009D2G
External USB 2.0 Multibay II Cradle PA509A
HDD Multibay II 80GB 5400rpm PH357A
Multibay II DVD Drive (Does not support DVD play back) PA849A
QuickSpecs
HP Compaq t5135 Thin Client
HP Compaq t5135 Thin ClientHP Compaq t5135 Thin Client
HP Compaq t5135 Thin Client
Options
DA - 12660 North America — Version 14 — March 18, 2009 Page 4

Care Packs
Care PacksCare Packs
Care Packs 9x5 Next-Business-Day
3
Advanced Exchange – 3 Years 331653-001;U4847E
4
9x5 Next-Business-Day
3
On-Site Coverage – 3 Years 331655-001;U4849E
4
1
Option available directly from third party.
2
Only serial is supported.
3
Service levels and response times for HP Care Packs may vary depending on your geographic location. Restrictions and limitations
apply. For details, visit http://www.hp.com/go/carepack .
4
4U4847E is available in all regions; U4849E is available in Americas and Asia-Pacific/Japan.
QuickSpecs
HP Compaq t5135 Thin Client
HP Compaq t5135 Thin ClientHP Compaq t5135 Thin Client
HP Compaq t5135 Thin Client
Options
DA - 12660 North America — Version 14 — March 18, 2009 Page 5

Processor
ProcessorProcessor
Processor VIA Eden 400 MHz
Chipsets
ChipsetsChipsets
Chipsets Northbridge: VIA CN700; Southbridge: VIA VT8237
Memory
MemoryMemory
Memory Flash
FlashFlash
Flash 64 MB
System Memory
System MemorySystem Memory
System Memory 128 MB RAM (16 MB reserved for video)
Graphics
GraphicsGraphics
Graphics VIA S3 graphics with support for high-resolution monitors up to 1920 x 1440, or up to 24 bit
Modes
ModesModes
Modes 800 x 600; 960 x 600
1024 x 768
1152 x 864
1280 x 720 ; 1280 x 768; 1280 x 800;1280 x 1024
1360 x 768; 1366 x 768; 1368 x 768
1400 x 1050
1600 x 1200; 1680 x 1050
1920 x 1080; 1920 x 1200; 1920 x 1440
Input/Output/
Input/Output/Input/Output/
Input/Output/
Peripheral Support
Peripheral SupportPeripheral Support
Peripheral Support
Keyboard
KeyboardKeyboard
Keyboard USB or PS/2 (both supported)
Keyboard included with every thin client. Type of included keyboard (USB or
PS/2) varies by region.
Mouse
MouseMouse
Mouse USB or PS/2 (both supported)
Mouse included with every thin client. Type of included mouse (USB or PS/2)
varies by region.
Printer
PrinterPrinter
Printer Local (ThinPrint .print TCP Client) and/or network printers (RDP, ICA, LPD)
Video
VideoVideo
Video VGA-type video output (DB-15)
Audio
AudioAudio
Audio Output
OutputOutput
Output Internal amplified speaker, 1/8-inch mini, full 16-bit stereo,
44-kHz sample rate
Security
SecuritySecurity
Security Kensington lock slot (cable lock sold separately)
Server-based Computing
Server-based ComputingServer-based Computing
Server-based Computing
Protocols and Connection
Protocols and ConnectionProtocols and Connection
Protocols and Connection
Brokers
BrokersBrokers
Brokers
Citrix ICA 10.x and rdesktop 1.5 for remote server access
Citrix Dynamic Desktop Initiative
Leostream Desktop Connection Broker
Provision Networks Virtual Access Broker
Networking
NetworkingNetworking
Networking TCP/IP with Dynamic DNS and DHCP support
10/100 BaseT Fast Ethernet, twisted pair (RJ-45)
Wake on LAN, PXE
I/O Ports and Connectors
I/O Ports and ConnectorsI/O Ports and Connectors
I/O Ports and Connectors 8 USB 2.0 ports, 1 serial, 1 parallel, 2 PS/2
Resident OS
Resident OSResident OS
Resident OS HP ThinConnect
Server OS Compatibility/
Server OS Compatibility/Server OS Compatibility/
Server OS Compatibility/
Support
SupportSupport
Support
Citrix Presentation Server (up to 4.5)
Citrix Metaframe Presentation Server 3.0, Citrix Metaframe XP Presentation Server
Citrix Metaframe 1.x
Windows 2000/2003 Server families
Windows 2000/2003 Server Terminal Services
Windows 2000 Advanced Server, Windows 2000 Advance Server Terminal Services
Microsoft® Windows® NT 4.0 Server
Windows NT 4.0 Terminal Server Edition
QuickSpecs
HP Compaq t5135 Thin Client
HP Compaq t5135 Thin ClientHP Compaq t5135 Thin Client
HP Compaq t5135 Thin Client
Technical Specifications
DA - 12660 North America — Version 14 — March 18, 2009 Page 6

Software Included
Software IncludedSoftware Included
Software Included HP ThinState Tools, Citrix ICA, rdesktop RDP client, VNC Shadow, ThinPrint .print TCP client
Full license of Altiris Deployment Solution (client agent) is preinstalled on every thin client. Altiris
Deployment Solution (management console) is available as a free download from Altiris at:
http://www.altiris.com/hptc
OS Languages
OS LanguagesOS Languages
OS Languages English
Dimensions HxWxD
Dimensions HxWxDDimensions HxWxD
Dimensions HxWxD Without stand
Without standWithout stand
Without stand 7.31 x 7.31 x 2.06 in (18.57 x 18.57 x 5.24 cm)
Stand only
Stand onlyStand only
Stand only Height: 0.75 in (1.9 cm)
Weight
WeightWeight
Weight (approximate) With stand
With standWith stand
With stand 2.9 lbs (1.3 kg)
Stand only
Stand onlyStand only
Stand only ~1 oz (30 g)
Environmental
EnvironmentalEnvironmental
Environmental Operating temperature
Operating temperatureOperating temperature
Operating temperature
range
rangerange
range
50° to 104° F (10° to 40° C)
Non-operating
Non-operatingNon-operating
Non-operating
temperature range
temperature rangetemperature range
temperature range
–22° to 140° F (–30 to 60° C)
Humidity
HumidityHumidity
Humidity 20% to 80% condensing/10% to 95% non-condensing
Power*
Power*Power*
Power* Worldwide auto-sensing 100-240 VAC, 50-60 Hz. Average power
consumption of this thin client in a typical setup is 11.4W.
* The actual power consumption at your location could vary and is dependent on many factors including
but not limited to software load on the thin client, attached peripherals, and environmental factors.
Regulatory Compliances
Regulatory CompliancesRegulatory Compliances
Regulatory Compliances Product Safety
Product SafetyProduct Safety
Product Safety International: IEC60950-1, 12:2005, with CB Certificate and all
National Deviations
US and Canada: UL 60950-1 / CAN/CSA 22.2 No. 60950-1-03,
07:2006, Bi-National Standard for ITE Safety in the US and Canada
and is published jointly by UL and CSA.
Europe: EN 60950-1, 06:2003, Information Technology Equipment
Ergonomics
ErgonomicsErgonomics
Ergonomics The product has been tested and found to comply with all applicable GS
ergonomic requirements.
RF Interference
RF InterferenceRF Interference
RF Interference FCC Class B; CE Mark; VCCI
Warranty
WarrantyWarranty
Warranty Three-year limited hardware warranty. The software is comprised of open source community code, third-
party licensed code, and HP code and is provided without warranty.
NOTE:
NOTE:NOTE:
NOTE: Certain restrictions apply. Consult the HP Customer Support Center for details.
Environment-friendly
Environment-friendlyEnvironment-friendly
Environment-friendly
Products and Approach
Products and ApproachProducts and Approach
Products and Approach
RoHS Compliance
RoHS ComplianceRoHS Compliance
RoHS Compliance Hewlett-Packard is committed to compliance with all applicable
environmental laws and regulations, including the European Union
Restriction of Hazardous Substances (RoHS) Directive. HP's goal is to exceed
compliance obligations by meeting the requirements of the RoHS Directive
on a worldwide basis. From July 1, 2006, RoHS substances will be virtually
eliminated (virtually = to levels below legal limits) for all HP electronic
products subject to the RoHS Directive, except where it is widely recognized
that there is no technically feasible alternative (as indicated by an exemption
under the EU RoHS Directive).
Material Usage
Material UsageMaterial Usage
Material Usage This product does not contain any of the following substances in excess of
regulatory limits (refer to the HP General Specification for the Environment
at: http://www.hp.com/hpinfo/globalcitizenship/environment/
supplychain/gen_specifications.html ):
Asbestos
Certain Azo Colorants
Certain Brominated Flame Retardants – may not be used as flame
QuickSpecs
HP Compaq t5135 Thin Client
HP Compaq t5135 Thin ClientHP Compaq t5135 Thin Client
HP Compaq t5135 Thin Client
Technical Specifications
DA - 12660 North America — Version 14 — March 18, 2009 Page 7

retardants in plastics
Cadmium
Chlorinated Hydrocarbons
Chlorinated Paraffins
Formaldehyde
Halogenated Diphenyl Methanes
Lead carbonates and sulfates
Lead and Lead compounds
Mercuric Oxide Batteries
Nickel – finishes must not be used on the external surface designed to
be frequently handled or carried by the user.
Ozone Depleting Substances
Polybrominated Biphenyls (PBBs)
Polybrominated Biphenyl Ethers (PBBEs)
Polybrominated Biphenyl Oxides (PBBOs)
Polychlorinated Biphenyl (PCB)
Polychlorinated Terphenyls (PCT)
Polyvinyl Chloride (PVC) – except for wires and cables, and certain
retail packaging has been voluntarily removed from most applications.
Radioactive Substances
Tributyl Tin (TBT), Triphenyl Tin (TPT), Tributyl Tin Oxide (TBTO)
Packaging
PackagingPackaging
Packaging HP follows these guidelines to decrease the environmental impact of product
packaging:
Eliminate the use of heavy metals such as lead, chromium, mercury
and cadmium in packaging materials.
Eliminate the use of ozone-depleting substances (ODS) in packaging
materials.
Design packaging materials for ease of disassembly.
Maximize the use of post-consumer recycled content materials in
packaging materials.
Use readily recyclable packaging materials such as paper and
corrugated materials.
Reduce size and weight of packages to improve transportation fuel
efficiency.
Plastic packaging materials are marked according to ISO 11469 and
DIN 6120 standards.
End-of-life Management
End-of-life ManagementEnd-of-life Management
End-of-life Management
and Recycling
and Recyclingand Recycling
and Recycling
Hewlett-Packard offers end-of-life HP product return and recycling programs
in many geographic areas. To recycle your product, please go to:
http://www.hp.com/recycle or contact your nearest HP sales office. Products
returned to HP will be recycled, recovered or disposed of in a responsible
manner.
The EU WEEE directive (2002/95/EC) requires manufacturers to provide
treatment information for each product type for use by treatment facilities.
This information (product disassembly instructions) is posted on the Hewlett
Packard web site at: http://www.hp.com/go/recyclers . These instructions may
be used by recyclers and other WEEE treatment facilities as well as HP OEM
customers who integrate and re-sell HP equipment.
Hewlett-Packard
Hewlett-PackardHewlett-Packard
Hewlett-Packard
Corporate Environmental
Corporate EnvironmentalCorporate Environmental
Corporate Environmental
For more information about HP's commitment to the environment:
[link to new HP white paper now in progress]
QuickSpecs
HP Compaq t5135 Thin Client
HP Compaq t5135 Thin ClientHP Compaq t5135 Thin Client
HP Compaq t5135 Thin Client
Technical Specifications
DA - 12660 North America — Version 14 — March 18, 2009 Page 8

Information
InformationInformation
Information Global Citizenship Report
http://www.hp.com/hpinfo/globalcitizenship/
gcreport/index.html
Eco-label certifications
http://www.hp.com/hpinfo/globalcitizenship/environment/
productdesign/ecolabels.html
ISO 14001 certificates:
http://www.hp.com/hpinfo/globalcitizenship/environment/
operations/envmanagement.html
©Copyright 2009 Hewlett-Packard Development Company, L.P.
Microsoft, Windows, and Windows NT are trademarks and/or registered trademarks of Microsoft Corporation in the United States
and other countries.
The information contained herein is subject to change without notice and is provided "as is" without warranty of any kind. The
warranties for HP products and services are set forth in the express limited warranty statements accompanying such products and
services. Nothing herein should be construed as constituting an additional warranty. HP shall not be liable for technical or editorial
errors or omissions contained herein.
QuickSpecs
HP Compaq t5135 Thin Client
HP Compaq t5135 Thin ClientHP Compaq t5135 Thin Client
HP Compaq t5135 Thin Client
Technical Specifications
DA - 12660 North America — Version 14 — March 18, 2009 Page 9
