HP Tc2120 - Server - 256 MB RAM Service manual

5-8
5V PCI slot
Battery
PCI slots
Power to motherboard
indicator (green LED)
Chassis intrusion
switch
Main chassis fan
ATX 12V power
Processor/
CPU Cooler
Main ATX Power
System Board Layout
Processor fan
Memory modules
(Install in any order)
Note: Use only
Registered ECC
266 MHz DDR PC2100
DIMMs
Primary IDE channel
(ATA/100)
Secondary IDE channel
(ATA/100)
Floppy disk drive
SCSI activity LED
Switch 1 (see table)
Front panel
BIOS recovery
(Active when ON)
Hardware flash protection
(Must be ON before flashing)
Clear password
(Active when ON)
Clear CMOS
(Active when ON)
(reserved)
Switch Tables
Install/Remove Accessories
OFF
OFF
OFF
OFF
1
2
3
4
Switch Default
Position Use
CD / CD-RW / DVD
TAPE/HDD
HDD extra screws
HDD
Switch 2 (see table)
Jumper J8 (see below)
1*
1* 1*
*Indicates Pin 1
Switch 1 Table
(reserved)ON
OFF
ON
-----
1-2
3
4
5
Switch Default
Position Use
Switch 2 Table for Celeron Processors
(reserved)ON
OFF
1-2
3-4
Switch Default
Position Use
Switch 2 Table for P4 Processors
(reserved)
(reserved)
(reserved)
OFF
Please visit www.hp.com and search for 'tc2120' to find drivers,
replacement parts, specifications, and other useful information.
3V
-----
5
(reserved)
(reserved)
PCI 1
PCI 2
PCI 3
PCI 4
PCI 5
J8
Jumper J8 Setting
For Celeron Processors: J8
1 2 3
J8
1 2 3
For P4 Processors:
