The latest 1P rack server, HP ProLiant DL320e Gen8 Server series, is a new entry level rack-optimized platform, ideal for single-

application IT infrastructure, web and edge-of-network applications. The ProLiant DL320e Gen8 Server is not only affordable but is

more powerful by enabling powerful quad-core processor computing performance with larger memory & storage capacity, all in a small

package.

The DL320e Gen8 supports the latest technology, such as Intel® Xeon® E3, Core i3 and Pentium processors, PCI-E Gen3, DDR3 1600MHz

memory, up to 12TB internal storage, RAID solution as well as High Efficiency Hot Plug Redundant Power Supply Kit.

HP ProLiant DL320e Gen8 Server series supports HP iLO Management Engine, a complete set of embedded management features

supporting the complete lifecycle of the server, from initial deployment, through ongoing management, to service alerting and remote

support.

Front View:

Rear View:

Access Panel

Expansion slot 2, PCIe x16

Power Supply

Expansion slot 1, PCIe x8

PCI Riser Cage

Power Supply 2

Processor

Power Supply 1

DIMMs

Dedicated iLO port

Fans

UID LED button

Optical drive

Serial Connector

2 USB Connectors

Video Connector

UID LED button

USB Connectors

10.

Health LED

10.

NIC Connector 1

11.

NIC status LED

11.

USB Connectors

12.

Power On/Standby button and LED

12.

NIC Connector 2

13.

Hard Drive Bays

QuickSpecs

HP ProLiant DL320e Generation 8 (Gen8)

Overview

DA - 14326 North America — Version 5 — November 17, 2012

Page 1

NOTE:

For the Standard Features shipped in the "Factory Integrated Models", please see the "Configuration Information - Factory

Integrated Models" section.

Processor

One of the following

depending on Model

Entry Processors

Intel® Pentium® G630 (2.7GHz/2-core/3MB/65W) Processor

NOTE:

Intel ®Pentium® G630 processor, performance for 1600MHz memory is clocked down to 1066MHz.

Intel® Pentium® G2120 (3.1GHz/2-core/3MB/55W) Processor

NOTE:

Intel® Pentium® G2120 Processor supports up to 1600MHz DDR3 memory speeds.

Intel® Pentium® G2100T (2.6GHz/2-core/3MB/35W) Processor

NOTE:

Intel® Pentium® G2100T Processor supports up to 1600MHz DDR3 memory speeds.

Base Processors

NOTE:

All support up to1600MHz DDR3 memory speeds.

Intel® Core™ i3-3220T (2.8GHz/2-core/3MB/35W, HT) Processor

Intel® Core™ i3-3240 (3.4GHz/2-core/3MB/55W, HT) Processor

Performance Processors

NOTE:

All support up to 1600MHz DDR3 memory speeds.

Intel® Xeon® E3-1220Lv2 (2.3GHz/2-core/3MB/17W, HT)

Intel® Xeon® E3-1220v2 (3.1GHz/4-core/8MB/69W, HT)

Intel® Xeon® E3-1230v2 (3.3GHz/4-core/8MB/69W, HT)

Intel® Xeon® E3-1240v2 (3.4GHz/4-core/8MB/69W, HT)

Intel® Xeon® E3-1270v2 (3.5GHz/4-core/8MB/69W, HT)

Intel® Xeon® E3-1290v2 (3.7GHz/4-core/8MB/87W, HT)

NOTE:

HT indicates that the processor model supports Intel® /Hyper-Threading Technology (Depends on

the processor).

NOTE:

DDR3 speed is the maximum memory speed of the processor. Actual memory speed may depend on

the quantity and type of DIMMs and CPU installed (options for 1600, 1333, 1066MHz).

Cache Memory

One of the following

depending on Model

8MB (1x8MB) Level 3

NOTE:

For Quad-core processors.

3MB (1x3MB) Level 3

NOTE:

For Dual-core processors.

Chipset

Intel® C204 Series Chipset

NOTE:

For more information regarding Intel® chipsets, please see the following URL:

http://www.intel.com/products/server/chipsets/

QuickSpecs

HP ProLiant DL320e Generation 8 (Gen8)

Standard Features

DA - 14326 North America — Version 5 — November 17, 2012

Page 2

Upgradeability

Up to 4 DIMM slots available for higher Memory capacity

Up to 8 SFF Hard Drive Bays; Or 4 LFF Hot plug or Non hot plug Drive Bay

1 PCIe 2.0 expansion slot

1 PCIe 3.0 I/O slot for additional communications and storage expansion (depends on processor)

Redundant Power Supply

Optical Drive Bay

On System Management

Processor

HP iLO (Firmware: HP iLO 4)

NOTE:

For more information, visit:

http://www.hp.com/go/ilo

Memory Protection

ECC

Memory

One of the following

depending on Model

Type

HP SmartMemory

Unbuffered (UDIMM)

DIMM Slots Available

4 DIMMs (2 Channels/ 2 DIMMs per channel)

Standard (Entry Model)

2GB (1 x 2GB) UDIMM PC3-12800E (1600MHz)

Standard (Base Models)

4GB (1 x 4GB) UDIMM PC3-12800E (1600MHz)

Standard ( Performance

Models)

8GB (2 x 4GB) UDIMM PC3-12800E (1600MHz)

Maximum Capacity

(UDIMM)

32GB (4 x 8GB@1600MHz)

NOTE:

HP memory from previous generation servers are not fully compatible with the HP ProLiant DL320e

Gen8 Server.

NOTE:

To realize the performance memory capabilities listed in this document, HP SmartMemory is

required. For additional information, please see the HP SmartMemory QuickSpecs at:

http://h18000.www1.hp.com/products/quickspecs/14225_na/14225_na.html

NOTE:

Depending on the memory configuration and processor model, the memory speed may run at

1600MHz, 1333MHz, or 1066MHz. Please see Memory Population Table or the Online Memory

Configuration Tool at:

www.hp.com/go/ddr3memory-configurator

Network Controller

HP Ethernet 1Gb 2-port 330i Adapter

NOTE: The HP ProLiant DL320e Gen8 server has an embedded dual-port network adapter . The server can

be further upgraded with various networking products

QuickSpecs

HP ProLiant DL320e Generation 8 (Gen8)

Standard Features

DA - 14326 North America — Version 5 — November 17, 2012

Page 3

Expansion Slots

Expansion

Slots #

Technology

Bus

Width

Connector

Width

Form Factor

Notes

PCIe 2.0

x4 x8

Low profile slot

PCIe 3.0

x16 x16

Half-length, full-

height slot

*Indicates the number of physical electrical lanes running to the connector.

NOTE:

PCIe 3.0 support with Intel Xeon E3-1200v2 family only.

HP Server ROM

HP ROM (Read Only Memory) is now digitally signed using HP's Corporate Signing Service. This signature is

verified before the flash process starts, reducing accidental programming and preventing malicious efforts

to corrupt system ROM.

HP ROM provides for essential initialization and validation of hardware components before control is

passed to the customer-installed operating system. The ROM also provides the capability of booting from

various fixed media (HDD, CD-ROM) and removable media (USB), to continue operation to the operating

system.

HP ROM performs very early configuration of the video controller, to allow monitoring of initialization

progress via an attached monitor. If configuration or hardware errors are discovered during this early

phase of hardware initialization, suitable messages are now displayed on the connected monitor.

Additionally, these configuration or hardware errors are logged to the Integrated Management Log (IML) to

assist in diagnosis.

HP's ProLiant ROM is used to configure the following:

Processor and chipset status registers

System memory, memory map, and memory initialization

System hardware configuration (Integrated PCI devices and optional PCIe cards).

Customer-specific BIOS configuration (using the HP ROM-Based Setup Utility (RBSU).

NOTE:

For further information, please refer to HP's RBSU (ROM based setup utility) user guide:

www.hp.com/support/rbsu

QuickSpecs

HP ProLiant DL320e Generation 8 (Gen8)

Standard Features

DA - 14326 North America — Version 5 — November 17, 2012

Page 4

Storage Controller

One of the following

depending on Model

Entry Models

HP Dynamic Smart Array B120i Controller

NOTE:

Supports 3.0Gb/s SATA.

NOTE:

Supports RAID 0/1/10 only. It does not have FBWC support so cannot

support advanced RAID (5 onwards). For FBWC, a standup Smart Array

Controller card must be configured.

Base Models

HP Dynamic Smart Array B120i Controller

NOTE:

Supports 3.0Gb/s SATA.

NOTE:

Supports RAID 0/1/10 only. It does not have FBWC support so cannot

support advanced RAID (5 onwards). For FBWC, a standup Smart Array

Controller card must be configured.

Performance Models

HP Smart Array P222/512MB FBWC controller

NOTE:

P222 can support RAID 0/1/10/5/50. More advanced options available

with Smart Array Advanced Pack 2.0.

NOTE: The DL320e Gen8 can support other advanced controllers as well, depending on model and

configuration

NOTE: For set up instructions for HP Smart Array B120i SATA Controller please refer to the HP ProLiant

DL300 series server user guide.

NOTE: For general information about HP Smart Array B120i SATA RAID Controller, please visit:

http://h18004.www1.hp.com/products/servers/proliantstorage/arraycontrollers

/dynamicsmartarray/index.html

Internal Storage Devices

Diskette Drive

None

Optical Drive

Optional

DVD-ROM, DVD-RW

Hard Drives

One of the following

depending on Model

None ship standard (Base Models and Performance Models)

1x NHP 500GB SATA 3.5" drive (Entry Models)

Hard Drive Bays

8 SFF drive bays or 4 LFF Non hot plug/Hot plug

NOTE:

HP ProLiant DL320e Series servers offer both SFF, and LFF versions in

CTO. The Optical Drive bay is available with both models.

NOTE:

LFF versions are not an upgradeable option from SFF models, or vice

versa, also between Non Hot Plug LFF and Hot Plug LFF.

NOTE:

All Pre-configured Models come populated with some hard drive blanks

installed. Should the customer need additional hard drive blanks, they can

order more using either P/N 666987-B21: HP SFF Gen8 Hard Drive Blank Kit or

P/N 666986-B21: HP LFF Gen8 Hard Drive Blank Kit. These part numbers for

single HDD blanks below are also provided should the customer require

replacement HDD blanks for their server.

QuickSpecs

HP ProLiant DL320e Generation 8 (Gen8)

Standard Features

DA - 14326 North America — Version 5 — November 17, 2012

Page 5

Maximum Internal

Storage

Hot Plug SFF SAS

8.0TB

8 x 1TB

Hot Plug SFF SATA

8.0TB

8 x 1TB

Hot Plug LFF SAS

12.0TB

4 x 3TB

Hot Plug LFF SATA

12.0TB

4 x 3TB

Hot Plug SFF SAS SSD

6.4TB

8 x 800GB

Hot Plug SFF SATA SSD

3.2TB

8 x 400GB

Hot Plug LFF SATA SSD

1.6 TB

4 x 400GB

Non-Hot Plug LFF SATA

12 TB

4 x 3TB

Non-Hot Plug LFF SAS

2.4TB

4 x 600GB

Interfaces

Serial

Video

1 Rear standard video

HP iLO Remote

Management Network Port

1Gb Dedicated

SD slot

1 Internal

NOTE:

The SD slot is not a hot-pluggable device. Customers should not

attempt to plug an SD card into the SD slot while the server is powered.

USB 2.0 Ports

7 total: 4 rear, 2 front, 1 internal (Optional)

Industry Standard

Compliance

ACPI 2.0b Compliant

PCIe 3.0

PXE Support

WOL Support

USB 2.0 Compliant

Server Power Cords

All Pre-configured Models servers ship with a high voltage server to PDU power cord.

NOTE:

HP ProLiant DL servers no longer ship standard with a 12-foot NEMA 5-15P to C13 power cords

(227099-001) that allow connection to 110V US wall outlets in a home or office. ProLiant DL servers are

primarily connected to PDU's in data center racks so they now ship standard with only a PDU 6-foot C-14

to C13 power cord (142258-001). If a user wishes to power a ProLiant DL server using a110V receptacle

(NEMA-15), the 12-foot NEMA 5-15 to C13 power cord must be ordered separately. See Power Cords

section for Worldwide Power Cord options.

Power Specifications

To review typical system power ratings use the HP Power Advisor which is available via the online tool

located at URL:

www.hp.com/go/proliant-energy-efficient

www.hp.com/go/hppoweradvisor

NOTE:

Power Specification and Technical Content for supported power supplies can be found at:

http://h18000.www1.hp.com/products/quickspecs/14209_div/14209_div.html

QuickSpecs

HP ProLiant DL320e Generation 8 (Gen8)

Standard Features

DA - 14326 North America — Version 5 — November 17, 2012

Page 6

Common Slot Power

Supply

NOTE:

The default power supply for DL320e Gen8 server is a 350W Non Hot Plug, Non Redundant (ATX)

power supply.

NOTE:

To choose a Redundant Common Slot Power Supply option for the DL320e Gen8 server, a Factory

Integrated Model must be chosen, beginning with a CTO server. Also, an HP DL320e Gen8 RPS Enablement

FIO Kit (675451-B21) is required.

HP's Common Slot (CS) power supplies allow for commonality of power supplies across a wide range of

ProLiant and Integrity servers, as well as HP Storage solutions, and are designed to provide the highest

power supply efficiency without degrading system performance. HP CS power supplies are tested by the

Electric Power Research Institute (EPRI) and certified through the ECOS 80 Plus power supply program.

The 460W HP CS power supply option provides an efficiency rating of up to 94%. All HP Common Slot

power sources are UL, CE Mark Compliant, hot-plug and support redundant configurations.

NOTE:

Mixing of power supplies (for instance Common Slot Platinum Plus power supplies and Common

Slot Gold power supplies) in the same server is not supported. All power supplies must be of the same

output and efficiency rating. If non-matched power supplies are inserted you will get errors and operation

will fail.

HP CS Platinum Plus power supplies are required when enabling HP's Intelligent Power Discovery (IPD)

solution. IPD is the first technology to create an automated, energy-aware network between IT systems

and facilities. This allows your company to reclaim millions of dollars in wasted power capacity and

downtime costs across data centers. For more information on HP's IPD solution, go to

www.hp.com/go/ipd

It is highly recommended that you use the HP Power Advisor in defining the "Right-Size" power supply for

your needs. HP Power Advisor can be accessed at:

www.hp.com/go/hppoweradvisor

NOTE:

The 80 PLUS program is a unique forum that unites electric utilities, the computer industry, and

consumers in an effort to bring energy efficient technology solutions to the marketplace. 80 Plus

independently tests power supply efficiency and publicly posts the results on 80Plus.org.

Redundant Power: Optional (1+1 or n+n redundant) power supplies can be purchased through power

supply option kits (see Power Supplies for part numbers).

NOTE:

Power Specification and Technical Content for supported power supplies can be found at:

http://h18000.www1.hp.com/products/quickspecs/14209_na/14209_na.html

System Fans

4 fan modules ship standard, non-redundant

Operating Systems and

Virtualization Software

Support for ProLiant

Servers

Microsoft Windows Server

Red Hat Enterprise Linux (RHEL)

SUSE Linux Enterprise Server (SLES)

VMware

NOTE:

For more information on HP's Certified and Supported ProLiant Servers for OS and Virtualization

Software and latest listing of software drivers available for your server including how to purchase from

HP, please visit our OS Support Site at:

http://www.hp.com/go/ossupport

and our driver download page:

http://www.hp.com/support/DL320eGen8

QuickSpecs

HP ProLiant DL320e Generation 8 (Gen8)

Standard Features

DA - 14326 North America — Version 5 — November 17, 2012

Page 7

Graphics

Integrated Matrox G200 video standard

1280 x 1024 (32 bpp)

1920 x 1200 (16 bpp)

Form Factor

One of the following

depending on Model

1U Rack form factor

8 SFF Drive Bay Version:

1.7" (4.32cm) Height x 17.11" (43.46cm) Width x 27.5" (69.90cm) Length

4 LFF Drive Bay Version:

1.7" (4.32cm) Height x 17.11" (43.46cm) Width x 29.5" (75.00cm) Length

On System Management

HP iLO Management

Engine

HP iLO Management Engine is a comprehensive set of embedded management

features supporting the complete lifecycle of the server, from initial

deployment, through ongoing management, to service alerting and remote

support. HP iLO Management Engine comes standard on all HP ProLiant Gen8

servers. The HP iLO Management Engine portfolio includes:

HP iLO: The HP iLO management processor is the core foundation for HP

iLO Management Engine. HP iLO for HP ProLiant servers simplify server

setup, engage health monitoring and power and thermal control, and

promote remote administration for HP ProLiant ML, DL, BL and SL

servers. Furthermore with the new HP iLO is the ability to access,

deploy, and manage your server anytime from anywhere with your

Smartphone device.

HP Agentless Management: With HP iLO Management Engine in every

HP ProLiant Gen8 server, the base hardware monitoring and alerting

capability is built into the system (running on the HP iLO chipset) and

starts working the moment that a power cord and an Ethernet cable is

connected to the server.

HP Active Health System: HP Active Health System is an essential

component of the HP iLO Management Engine. The HP Active Health

System monitors and records changes in the server hardware and

system configuration. The Active Health System assists in diagnosing

problems and delivering rapid resolution when system failures occur.

HP Intelligent Provisioning: HP Intelligent Provisioning includes

everything you need for painless system setup and deployment. All

your HP Gen8 ProLiant servers and Gen8 ProLiant server blades are

ready to set-up right out-of-the box. The firmware, drivers, and tools

that you need to quickly get your systems online are embedded on a

NAND flash chip on the server motherboard- no more SmartStart CDs or

firmware DVDs needed. Intelligent Provisioning is agentless for

improved performance, but you still have the ability to run agents if

needed.

To start Intelligent Provisioning:

Press the F10 key during the ProLiant Gen8 server boot

process (also known as power on self test or POST).

Please go to the Intelligent Provisioning website at

www.hp.com/go/intelligentprovisioning

for additional

information and to view usage videos.

QuickSpecs

HP ProLiant DL320e Generation 8 (Gen8)

Standard Features

DA - 14326 North America — Version 5 — November 17, 2012

Page 8

Use the Service Pack for ProLiant (SPP) at

www.hp.com/go/spp

to get firmware and software

updates.

NOTE:

For more information, visit:

http://www.hp.com/go/ilo

NOTE:

For information on Client System Support, please visit the HP iLO

Feature Comparison Site at:

http://www.hp.com/go/compareilo

HP Insight Management

HP Service Pack for

ProLiant (SPP)

HP Service Pack for ProLiant (SPP) and HP Smart Update Manager (HP SUM)

version 5 provide a new, comprehensive approach to firmware and system

software maintenance. Together they provide better operating stability and

ensure maximum uptime. The SPP will be updated at a predictable cadence,

typically coinciding with new HP server hardware launches. By enabling all

firmware to be updated online and integrating firmware and system software

updates in one operation HP SUM and the SPP offer faster updates of

individual servers and dramatically faster updates of entire BladeSystem

enclosures. Further improving system uptime and stability is the fact that HP

provides 12 months of support on each Service Pack for ProLiant.

The user experience around HP SUM and the SPP has been improved in several

ways, starting with the web download. A single web page provides access to a

single download containing both the latest version of HP SUM version 5 and

the latest SPP. Optional smaller subsets with only specific types of servers or

specific operating systems are offered to save on download time. The HP SUM

application has been re-written to provide a more straightforward, intuitive

user interface that guides the user through the steps of discovery, analyses

and update, providing comprehensive information on available updates,

criticality and interdependencies. This information is also available in reports.

By providing the option of multiple local or shared repositories which can be

easily updated from hp.com, HP SUM provides the tools to optimize stability

and consistency throughout the company. While HP SUM and the SPP will

recommend the combinations of firmware and system software that HP has

found to be the best practice, the application gives customers the flexibility to

set their own specific baseline.

The Service Pack for ProLiant has been rigorously tested with specific

attention for interaction between firmware, drivers and agents both within the

server as well as in interaction with the BladeSystem enclosure components

(Onboard Administrator and Virtual Connect). This testing ensures the highest

quality as well as providing the input for HP SUM to deploy updates taking into

account all interdepencies, when determining the correct updates and order of

update deployment.

NOTE:

The Service Pack for ProLiant (which includes HP SUM 5) can be

downloaded from

www.hp.com/go/spp/download

. More information can be

found: www.hp.com/go/spp and

http://www.hp.com/go/hpsum

QuickSpecs

HP ProLiant DL320e Generation 8 (Gen8)

Standard Features

DA - 14326 North America — Version 5 — November 17, 2012

Page 9

Security

Power-on password

Administrator's password

Warranty

This product is covered by a global limited warranty and supported by HP Services and a worldwide

network of HP Authorized Channel Partners resellers. Hardware diagnostic support and repair is available

for three years from date of purchase. Support for software and initial setup is available for 90 days from

date of purchase. Enhancements to warranty services are available through HP Care Pack services or

customized service agreements. Hard drives have either a one year or three year warranty; refer to the

specific hard drive QuickSpecs for details.

NOTE:

Server Warranty includes 1-Year Parts, 1-Year Labor, 1-Year Onsite support with next business day

response. Warranty repairs may be accomplished through the use of Customer Self Repair (CSR) parts.

These parts fall into two categories: 1) Mandatory CSR parts are designed for easy replacement. A travel

and labor charge will result when customers decline to replace a Mandatory CSR part; 2) Optional CSR

parts are also designed for easy replacement but may involve added complexity. Customers may choose

to have HP replace Optional CSR parts at no charge. Additional information regarding worldwide limited

warranty and technical support is available at:

http://h18004.www1.hp.com/products/servers/platforms/warranty/index.html

QuickSpecs

HP ProLiant DL320e Generation 8 (Gen8)

Standard Features

DA - 14326 North America — Version 5 — November 17, 2012

Page 10

HP Insight management

software

HP Insight Control

HP Insight Control, a product option, delivers essential infrastructure

management that can help save time and money by making it easy to deploy,

migrate, monitor, remote control, and optimize your IT infrastructure through

a single, simple management console.

Two versions of Insight Control are available, to serve environments requiring

either a Linux-based or a Windows-based central management server: HP

Insight Control for Linux, and HP Insight Control. See

www.hp.com/go/insightcontrol

HP Insight Control includes one year of 24 x 7 HP Software Technical Support

and Update Service ensuring rapid access to HP support staff and proactive

delivery of software updates. For more information about this service, please

visit:

http://www.hp.com/services/insight

HP iLO Advanced License

for ProLiant Servers

HP iLO management processors for HP ProLiant Gen8 servers virtualizes

system controls to help simplify server setup, engage health monitoring and

power and thermal control, and promote remote administration. HP iLO

functions out-of-the-box without additional software installation and

functions regardless of the servers' state of operation. Basic system board

management functions, diagnostics, and essential Lights-Out functionality

ships standard across all HP ProLiant Gen8 rack, tower and blade servers. The

HP iLO can be accessed from any location via a web browser and works hand-

in-hand with HP Systems Insight Manager, Insight Control, and Insight

Dynamics, helping customers unleash the value of the ProLiant platform and

deliver the highest possible quality of IT service to the business.

Advanced functionality, such as graphical remote console, multi-user

collaboration, and video record/playback can be activated with the optional

HP iLO Advanced or HP iLO Advanced for BladeSystem licenses. The Advanced

licensed features offer sophisticated remote administration of servers in

dynamic data center and remote locations and can help significantly reduce

cost associated with IT-related travel and unplanned downtime.

NOTE:

For more information, visit:

http://www.hp.com/go/ilo

HP Service Pack for

ProLiant
