Printing a photo
Application: Adobe Photoshop CS
Printer: HP Designjet 30/90/130 series
Software: HP Driver
Operating System: Mac OS X

1. First recommendations:
•See the Media type functionality & features and choose the most appropriate media.
•It is essential to have the media type correctly calibrated with the printer and print mode,
consult the Calibrate my printer document.
2. Open Adobe Photoshop CS.
3. Configure the Color Settings, Photoshop menu > Color Settings…:
•Make sure the Advanced Mode check box is ticked.
•Working Space > RGB: select profile of the scanner or camera you have used to get the
photo (source profile), if you don’t have it, select sRGB IEC61966-2.1 (1998).
•Color Management Policies: Preserve the Embedded Profiles.
•Profile Mismatches: check Ask When Opening and Ask When Pasting.
•Missing Profiles: check Ask When Opening.
•Conversion Options > Intent: Perceptual.
•Click OK
2

4. Open the image, File menu> Open…:
•If the document has an embedded color profile that does not match the current working
space, select Use the embedded profile. Otherwise, select Assign working space.
•Click OK
5. Adobe Photoshop Print with Preview… settings, File menu > Print with Preview…:
•Page Setup…:
oFormat for: Select the printer (ex. hp designjet 130).
oPaper Size: Select the paper size of the media loaded on the printer.
oOrientation: Select the orientation of your image on the paper.
oClick OK.
•Set the Position and the Scaled Print Size you need.
•Check Show More Options.
•Select the Color Management tab:
oSource Space: Document.
oPrint Space > Profile: Printer Color Management.
oPrint Space > Intent: Perceptual.
3

6. Driver Settings; Print…:
•Printer: Select the printer (ex. HP Designjet 130).
•Paper Type/Quality > Paper tab:
oPaper Type: Select the media type that is loaded on the printer.
oQuality: Best.
oColor: ColorSmart/sRGB.
•Click Print.
4

You should consider that each person has their own perception and their own subjective opinion
about the result; this is because there are various factors that can influence our opinions, such as the
type of photo (portrait, landscape…), the source color space, the media used, the environmental
conditions, the subjective perception about your own photo, etc.... This means the printing suggestion
may not completely match with your own personal opinion. We recommend that you consider the
next printing workflow and then choose the one that you prefer: Printing a Photo (Alternative
Workflow).
5

For more information on HP Designjet products
www.hp.com/go/designjet
6
