HP LTO-4 Ultrium 1760 Product manual

HP LTO Ultrium tape drives
technical reference manual
LTO 4 FC, SCSI and SAS drives
volume 5: UNIX, Linux and OpenVMS configuration guide
Edition 1, May 2007

Legal and notice information
© Copyright 2005–2007 Hewlett-Packard Development Company, L.P.
Hewlett-Packard Company makes no warranty of any kind with regard to this material, including, but not limited to, the implied
warranties of merchantability and fitness for a particular purpose. Hewlett-Packard shall not be liable for errors contained herein or
for incidental or consequential damages in connection with the furnishing, performance, or use of this material.
This document contains proprietary information, which is protected by copyright. No part of this document may be photocopied,
reproduced, or translated into another language without the prior written consent of Hewlett-Packard. The information is provided
“as is” without warranty of any kind and is subject to change without notice. The only warranties for HP products and services are
set forth in the express warranty statements accompanying such products and services. Nothing herein should be construed as
constituting an additional warranty. HP shall not be liable for technical or editorial errors or omissions contained herein.
Revision history
This document is frequently revised and updated. To find out if there is a later version, please ask your HP OEM Representative.
HP LTO Ultrium 4 drives technical reference manual, volume 5: UNIX, Linux and OpenVMS configuration
guide
Version Date Changes
Edition 1 May 2007 For LTO 4 FC, SCSI and SAS drives

HP LTO Ultrium 4 drives technical reference manual, volume 5: UNIX, Linux and OpenVMS configuration guide 1
Related documents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Documents specific to HP LTO Ultrium drives . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Documentation map. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Drives—general . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Installation and configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Cartridges . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Maintenance and troubleshooting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Dealing with errors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
LTO Ultrium features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
General documents and standardization . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
1 Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Purpose of this manual . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
LTO Ultrium drives in a library. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
SAS drives . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Backup applications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
2 HP (HP-UX) servers and workstations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Determining a suitable SCSI ID. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Adding stape and schgr (autoloader driver) to the kernel. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Add device files . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
What next? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
3 HP (OpenVMS) servers and workstations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Determining attached devices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
What next? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
4 HP (Tru64 5.1x) servers and workstations. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Determining attached devices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
What next?. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
5 Linux (kernel 2.6.x) servers and workstations . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Determining the SCSI ID . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Configuring on Linux systems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Using the seek and tell features of mt . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
What next? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
6 IBM (AIX) servers and workstations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Determining the SCSI ID . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Configuring the device files . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Contents

2
If you are using a graphics terminal running X-Windows . . . . . . . . . . . . . . . . . . . . . . . . . 27
If you are using a non-graphics terminal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Device filenames under AIX . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
7 Sun (Solaris 8, 9, 10) servers and workstations. . . . . . . . . . . . . . . . . . . . . . . . . 31
Fibre Channel drives. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Configuring the device files. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
SCSI drives . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Determining the SCSI ID . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Configuring the device files. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
HP-data values . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
8 Verifying the installation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Verifying the installation of the drive (UNIX). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
To verify the installation:. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Example . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
Glossary . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43

HP LTO Ultrium 4 drives technical reference manual, volume 5: UNIX, Linux and OpenVMS configuration guide 3
Related documents
The following documents provide additional information:
Documents specific to HP LTO Ultrium drives
•Hardware Integration Guide, volume 1 of the HP LTO Ultrium Technical Reference Manual
•Software Integration Guide, volume 2 of the HP LTO Ultrium Technical Reference Manual
•Host Interface Guide, volume 3 of the HP LTO Ultrium Technical Reference Manual
•Specifications, volume 4 of the HP LTO Ultrium Technical Reference Manual
Please contact your HP supplier for copies.
•The features and benefits of HP LTO Ultrium drives are discussed in the HP Ultrium Technology
White Paper.
•For a general background to LTO technology and licensing, go to
http://www.lto-technology.com.
Documentation map
The following will help you locate information in the Technical Reference Manual. A reference like
“1HW Integration: ch. 7” means Volume 1, Hardware Integration Guide, of the HP LTO Ultrium
Technical Reference Manual, chapter 7.
Drives—general
Installation and configuration
FC Drives SCSI Drives SAS Drives
Connectors 1HW Integration: ch. 4 1HW Integration: ch. 7
Front Panel LEDs 1HW Integration: ch. 3 1HW Integration: ch. 6
Specifications 4Specifications
FC Drives SCSI Drives SAS Drives
Connectors 1HW Integration: ch. 4 1HW Integration: ch. 7
Determining the configuration 2SW Integration: ch. 2
External drives n/a 1HW Integration: ch. 5
In Libraries 1HW Integration: ch. 1
In Servers n/a 1HW Integration: ch. 4
In Tape Arrays n/a 1HW Integration: ch. 3 n/a
Linux configuration 5UNIX, Linux, OpenVMS Configuration
Modes of Usage n/a 1HW Integration: ch. 8 n/a
OpenVMS configuration 5UNIX, Linux, OpenVMS Configuration

4
Operation
Cartridges
Interface
Optimizing performance n/a 1HW Integration: ch. 8 n/a
2SW Integration: ch. 4
UNIX configuration 5UNIX, Linux, OpenVMS Configuration
FC Drives SCSI Drives SAS Drives
FC Drives SCSI Drives SAS Drives
External drives n/a 1HW Integration: ch. 5
In Libraries 1HW Integration: ch. 1
In Servers n/a 1HW Integration: ch. 4
In Tape Arrays n/a 1HW Integration: ch. 3 n/a
FC Drives SCSI Drives SAS Drives
Cartridge Memory (LTO-CM) 2SW Integration: ch. 5
Cartridges 1HW Integration: ch. 5 1HW Integration: ch. 9
Managing the use of cartridges 2SW Integration: ch. 1
Use of cartridges 2SW Integration: ch. 3
FC Drives SCSI Drives SAS Drives
FC, SCSI and SAS host interface guide 3Host Interface
Commands 3Host Interface: ch. 5
Error codes 1HW Integration: ch. 6 1HW Integration: ch. 10
Implementation 3Host Interface: ch. 1
Interpreting sense data 2SW Integration: ch. 3
Messages 3Host Interface: ch. 2
Mode pages
—see the MODE SENSE command
3Host Interface: ch. 5
Pre-execution checks 3Host Interface: ch. 4
Responding to Sense Keys and ASC/Q 2SW Integration: ch. 6
Sense Keys and ASC/Q
—see REQUEST SENSE command
3Host Interface: ch. 5
Task management functions n/a 3Host Interface: ch. 3

HP LTO Ultrium 4 drives technical reference manual, volume 5: UNIX, Linux and OpenVMS configuration guide 5
Maintenance and troubleshooting
Dealing with errors
LTO Ultrium features
FC Drives SCSI Drives SAS Drives
Cleaning 2SW Integration: ch. 5
2SW Integration: ch. 7
External drives n/a 1HW Integration: ch. 5
In Libraries 1HW Integration: ch. 1
In Servers n/a 1HW Integration: ch. 4
In Tape Arrays n/a 1HW Integration: ch. 3 n/a
Monitoring drive and tape condition 2SW Integration: ch. 7
Software troubleshooting techniques 2SW Integration: ch. 1
FC Drives SCSI Drives SAS Drives
Error Codes 1HW Integration: ch. 6 1HW Integration: ch. 10
Handling errors 2SW Integration: ch. 5
Logs—see the LOG SENSE command 3Host Interface: ch. 4
Recovering from write and read errors 2SW Integration: ch. 7
Software response to error correction 2SW Integration: ch. 3
Software response to logs 2SW Integration: ch. 3
TapeAlert log 2SW Integration: ch. 7
FC Drives SCSI Drives SAS Drives
Autoload 1HW Integration: ch. 2
Automation Control Interface (ACI) 1HW Integration: ch. 2
Cartridge Memory (LTO-CM) 1HW Integration: ch. 2
2SW Integration: ch. 5
Data Compression, managing 2SW Integration: ch. 5
OBDR and CD-ROM emulation 2SW Integration: ch. 7
Performance optimization n/a 1HW Integration: ch. 8
2SW Integration: ch. 1
Performance, factors affecting 2SW Integration: ch. 4
Software design 2SW Integration: ch. 1
Supporting LTO Ultrium features 2SW Integration: ch. 5

6
General documents and standardization
See http://www.t10.org/t10_main.htm for INCITS SCSI Primary Commands—3 (SPC-3) and other
specifications
Copies of documents of other standards bodies can be obtained from:
INCITS 11 West 42nd Street
New York,
NY 10036-8002
USA
ISO CP 56
CH-1211 Geneva 20
Switzerland
ECMA 114 Rue du Rhône
CH-1204 Geneva
Switzerland
Tel: [phone]
Web URL: http://www.ecma.ch
Global Engineering
Documents
2805 McGaw
Irvine, CA 92714
USA
Tel: [phone] or 714 261 1455

HP LTO Ultrium 4 drives technical reference manual, volume 5: UNIX, Linux and OpenVMS configuration guide 7
1Introduction
Purpose of this manual
This manual provides basic information on configuring the drives with various operating systems.
See the top-level release notes that accompany the drive for expected functionality and features.
LTO Ultrium drives are supported on the following platforms:
•HP (HP-UX) servers and workstations (Chapter 2)
•HP (OpenVMS) servers and workstations (Chapter 3)
•HP (Tru64 5.1x) servers and workstations (Chapter 4)
•IBM (AIX) servers and workstations (Chapter 6)
•Linux (kernel 2.6.x) servers and workstations (Chapter 5)
•Sun (Solaris 8, 9, 10) servers and workstations (Chapter 7)
For platforms not mentioned here, contact HP because there may be new connectivity details
available that arrived after the release notes were published.
See Chapter 8 on page 37 for details of how to verify the installation.
LTO Ultrium drives in a library
Although LTO Ultrium drives may also be used in a library, instructions about installing device
drivers for automatic robotics are not included in this manual.
SAS drives
SAS drives are only supported on Redhat and SLES Linux.
Backup applications
For optimum performance it is important to use a backup application that supports the drive’s
features within your system’s configuration.
For details of which backup applications are supported with your tape drive and system, visit the
HP Tape Compatibility website:
http://www.hp.com/products1/storage/compatibility/tapebackup/index.html
Follow the “Software compatibility” link then click a tick in the appropriate matrix to drill down into
detailed application support information.
See the Getting Started Guide for more information about usage models.

Introduction8

HP LTO Ultrium 4 drives technical reference manual, volume 5: UNIX, Linux and OpenVMS configuration guide 9
2 HP (HP-UX) servers and workstations
This chapter covers:
•HP servers and workstations: HP-UX 11i v1 (11.11), 11i v2 (11.23)
•HP servers: HP-UX 11i v3 (11.31)
Before you install your tape drive, log on to the HP web site, www.hp.com, and download the latest
hardware enablement (HWE) patch bundle for your operating system. This ensures that you will
have the correct device driver for your tape drive.
System Administration Management (SAM) tools have evolved with ongoing HP-UX version releases.
As a result, the procedures for setting up with different HP-UX versions differ. They are described
separately in this chapter.
HP-UX11i v3 and agile addressing
HP-UX11i v3 introduces agile addressing of devices. Agile addressing uses a different format of the
device special file (dsf) to represent the tape drive—known as a persistent dsf. However
HP-UX11i v3 retains support for the legacy dsf format as used in HP-UX11i v1 and 11i v2.
For more information about HP-UX releases including HP-UX11i v3 please refer to
www.docs.hp.com.
Determining a suitable SCSI ID
The tape drive SCSI ID setting must be unique for the SCSI bus to which the drive is attached. In
many cases the drive will be the only device on a SCSI bus1in which case the default SCSI ID
setting of 3 is suitable. See the tape drive User Guide for details of how to alter the SCSI ID setting
physically (usually accessible at the rear panel of the drive).
Scan the system to list the existing devices attached. From a shell window (hpterm/xterm),
execute ioscan as follows:
For HP-UX 11i v1, 11i v2 and 11i v3 (legacy format)
Enter the command:
% /sbin/ioscan -f
The output should look similar to the following (which shows SCSI drives):
Class I H/W Path Driver S/W State H/W Type Description
=================================================================================
root 0 root CLAIMED BUS_NEXUS
ioa 0 0 sba CLAIMED BUS_NEXUS System Bus Adapter (880)
ba 0 0/0 lba CLAIMED BUS_NEXUS Local PCI-X Bus Adapter (783)
OO 0 0/0/1/0 UsbOhci CLAIMED INTERFACE PCI SerialBus (10330035)
OO 1 0/0/1/1 UsbOhci CLAIMED INTERFACE PCI SerialBus (10330035)
OO 2 0/0/1/2 UsbEhci CLAIMED INTERFACE PCI SerialBus (103300e0)
sideba 0 0/0/2/0 side_multi CLAIMED INTERFACE CMD IDE controller
ext_bus 0 0/0/2/0.0 side CLAIMED INTERFACE IDE Primary Channel
target 2 0/0/2/0.0.0 tgt CLAIMED DEVICE
disk 1 0/0/2/0.0.0.0 sdisk CLAIMED DEVICE TEAC DV-28E-N
1. Note that HP does not support disk drives and tape drives sharing the same SCSI bus.

HP (HP-UX) servers and workstations10
ext_bus 1 0/0/2/0.1 side CLAIMED INTERFACE IDE Secondary Channel
ba 1 0/1 lba CLAIMED BUS_NEXUS Local PCI-X Bus Adapter (783)
ext_bus 2 0/1/1/0 c8xx CLAIMED INTERFACE SCSI C1010 Ultra160 Wide LVD
target 0 0/1/1/0.0 tgt CLAIMED DEVICE
disk 0 0/1/1/0.0.0 sdisk CLAIMED DEVICE HP 73.4GST373454LC
ext_bus 3 0/1/1/1 c8xx CLAIMED INTERFACE SCSI C1010 Ultra160 Wide LVD
lan 0 0/1/2/0 igelan CLAIMED INTERFACE HP PCI 1000Base-T Core
ba 2 0/2 lba CLAIMED BUS_NEXUS Local PCI-X Bus Adapter (783)
ext_bus 4 0/2/1/0 mpt CLAIMED INTERFACE SCSI Ultra320 A6961-60011
ext_bus 5 0/2/1/1 mpt CLAIMED INTERFACE SCSI Ultra320 A6961-60011
target 1 0/2/1/1.3 tgt CLAIMED DEVICE
tape 1 0/2/1/1.3.0 stape CLAIMED DEVICE HP Ultrium 4-SCSI
ba 3 0/3 lba CLAIMED BUS_NEXUS Local PCI-X Bus Adapter (783)
ext_bus 6 0/3/1/0 c8xx CLAIMED INTERFACE SCSI C1010 Ultra160 Wide LVD
A6829-60001
ext_bus 7 0/3/1/1 c8xx CLAIMED INTERFACE SCSI C1010 Ultra160 Wide LVD
A6829-60001
ba 4 0/4 lba CLAIMED BUS_NEXUS Local PCI-X Bus Adapter (783)
ba 5 0/6 lba CLAIMED BUS_NEXUS Local PCI-X Bus Adapter (783)
ba 6 0/7 lba CLAIMED BUS_NEXUS Local PCI-X Bus Adapter (783)
tty 0 0/7/1/0 asio0 CLAIMED INTERFACE PCI SimpleComm (103c1290)
tty 1 0/7/1/1 asio0 CLAIMED INTERFACE PCI Serial (103c1048)
unknown -1 0/7/2/0 UNCLAIMED UNKNOWN PCI Display (10025159)
memory 0 8 memory CLAIMED MEMORY Memory
ipmi 0 16 ipmi CLAIMED INTERFACE IPMI Controller
processor 0 128 processor CLAIMED PROCESSOR Processor
processor 1 129 processor CLAIMED PROCESSOR Processor
NOTE: If you are installing a SCSI drive onto a Storage Area Network (SAN), the fibre
channel/SCSI router will also appear in the list of attached devices.
For a particular SCSI device in the ioscan listing, the SCSI bus ID and the drive’s SCSI ID and
LUN ID can be decoded from the H/W path (hardware path)/ For example:
Class I H/W Path Driver S/W State H/W Type Description
tape 1 2/0/1.5.0 stape CLAIMED DEVICE HP Ultrium 2-SCSI
The H/W path for this tape drive is “2/0/1.5.0”.
•The SCSI bus ID is “2/0/1” (including all the numbers separated by “/”).
From the remaining “.5.0” portion:
•Tape drive SCSI ID = 5
•Tape drive SCSI LUN = 0
Fibre Channel drives have a slightly different format in ioscan output, similar to the following
segment:
Class I H/W Path Driver S/W State H/W Type Description
=============================================================================
ba 4 0/4 lba CLAIMED BUS_NEXUS Local PCI-X Bus Adapter (783)
fc 2 0/4/1/0 fcd CLAIMED INTERFACE HP AB378-60001 4Gb Single Port
PCI/PCI-X Fibre Channel Adapter (FC Port 1)
fcp 1 0/4/1/0.84 fcd_fcp CLAIMED INTERFACE FCP Domain
ext_bus 6 0/4/1/0.84.3.255.0 fcd_vbus CLAIMED INTERFACE FCP Device Interface
target 3 0/4/1/0.84.3.255.0.0 tgt CLAIMED DEVICE
tape 2 0/4/1/0.84.3.255.0.0.0 stape CLAIMED DEVICE HP Ultrium 3-SCSI
fcp 0 0/4/1/0.180 fcd_fcp CLAIMED INTERFACE FCP Domain
ext_bus 10 0/4/1/0.180.2.255.0 fcd_vbus CLAIMED INTERFACE FCP Device Interface
target 7 0/4/1/0.180.2.255.0.0 tgt CLAIMED DEVICE
tape 9 0/4/1/0.180.2.255.0.0.0 stape CLAIMED DEVICE HP Ultrium 4-SCSI

HP LTO Ultrium 4 drives technical reference manual, volume 5: UNIX, Linux and OpenVMS configuration guide 11
For 11i v3 (Agile I/O tree view)
Enter the command:
% ioscan -m lun
The output should look similar to the following1(SCSI interface drives are shown in this example)
Class I Lun H/W Path Driver S/W State H/W Type Health Description
=====================================================================================
disk 2 64000/0xfa00/0x0 esdisk CLAIMED DEVICE online HP 73.4GST373454LC
0/1/1/0.0x0.0x0
/dev/disk/disk2 /dev/rdisk/disk2
disk 3 64000/0xfa00/0x3 esdisk CLAIMED DEVICE online TEAC DV-28E-N
0/0/2/0.0.0x0.0x0
/dev/disk/disk3 /dev/rdisk/disk3
tape 5 64000/0xfa00/0xa estape CLAIMED DEVICE online HP DLT VS160
0/2/1/1.0x5.0x0
/dev/rtape/tape5_BEST /dev/rtape/tape5_BESTb /dev/rtape/tape5_BESTn
/dev/rtape/tape5_BESTnb
tape 9 64000/0xfa00/0x12 estape CLAIMED DEVICE online HP C5683A
0/1/1/1.0x2.0x0
/dev/rtape/tape9_BEST /dev/rtape/tape9_BESTb /dev/rtape/tape9_BESTn
/dev/rtape/tape9_BESTnb
tape 0 64000/0xfa00/0x16 estape CLAIMED DEVICE online HP Ultrium 2-SCSI
0/3/1/1.0x3.0x0
/dev/rtape/tape0_BEST /dev/rtape/tape0_BESTb /dev/rtape/tape0_BESTn
/dev/rtape/tape0_BESTnb
tape 12 64000/0xfa00/0x1a estape CLAIMED DEVICE online HP SDLT600
0/2/1/0.0x3.0x0
/dev/rtape/tape12_BEST /dev/rtape/tape12_BESTb /dev/rtape/tape12_BESTn
/dev/rtape/tape12_BESTnb
For a particular SCSI device, you can decode the SCSI bus ID and the drive’s SCSI ID and LUN ID
from the lunpath hardware path. For example:
Class I Lun H/W Path Driver S/W State H/W Type Health Description
=====================================================================================
tape 0 64000/0xfa00/0x16 estape CLAIMED DEVICE online HP Ultrium 4-SCSI
0/3/1/1.0x3.0x0
The lunpath hardware path for the above tape drive is “0/3/1/1.0x3.0x0”.
•SCSI bus ID is “0/3/1/1” (including all the numbers separated by “/”).
From the remaining “0x3.0x0” portion:
•Tape drive SCSI ID = 3 (decimal value from hexadecimal 0x3)
•Tape drive SCSI LUN = 0 (decimal value from hexadecimal 0x0)
Fibre Channel drives have a slightly different format in ioscan output, similar to the following
segment:
Class I Lun H/W Path Driver S/W State H/W Type Health Description
======================================================================
tape 10 64000/0xfa00/0x14 estape CLAIMED DEVICE online HP Ultrium 4-SCSI
0/4/1/0.0x50060b0000b7f3c8.0x0
/dev/rtape/tape10_BEST /dev/rtape/tape10_BESTb /dev/rtape/tape10_BESTn
/dev/rtape/tape10_BESTnb
For a given FC device the FC bus ID, the World Wide Name (WWN) and the LUN ID can be
decoded from the Lun H/W Path. For example:
1. Note that device files (such as /dev/rtape/tape9_BEST) may or may not be in place initially.

HP (HP-UX) servers and workstations12
The lunpath hardware path for the above tape drive is
“0/4/1/0.0x50060b0000b7f3c8.0x0”.
•The FC bus ID is “0/4/1/0” (including all the numbers separated by “/”).
From the remaining “0x50060b0000b7f3c8.0x0” portion:
•Tape drive WWN (hexadecimal) = 0x50060b0000b7f3c8
•Tape drive SCSI LUN = 0x0 (hexadecimal SCSI-3 64-bit LUN identifier)
Adding stape and schgr (autoloader driver) to the kernel
For HP-UX 11i v1, 11i v2
If your tape drive or autoloader does not appear in ioscan listing or is listed with H/W Type
“UNKNOWN” you may need to install the appropriate drivers.
Use the ‘sam’ utility. Sam runs as a mouse driven GUI (Figure 1) on a system with full graphics
capability, or as a console text-based interface (Figure 2). If you use the text-based interface, use the
Tab and arrow keys to navigate, and the Return key to select.
Figure 1 SAM GUI

HP LTO Ultrium 4 drives technical reference manual, volume 5: UNIX, Linux and OpenVMS configuration guide 13
Figure 2 SAM text-based interface
For HP-UX 11i v1 (11.11)
1. Enter sam at the command line.
% sam
2. Select the following:
Kernel Configuration
Drivers
3. Highlight the stape driver. If the driver has not been added to the kernel, both Current State
and Pending State will read “Out”.
4. Select the following:
Actions
Add Driver to Kernel
The Pending State will now read “In”.
5. To add the new driver to the kernel, select:
Actions
Create a New Kernel
The stape driver is added to the kernel.
6. If you are going to attach an autoloader, use a similar procedure to change schgr to “static”.
7. Reboot the system.
For HP-UX 11i v2 (11.23)
1. Enter sam at the command line.
% sam
2. Select the following:
Kernel Configuration
Kernel Configuration (character mode)
Modules

HP (HP-UX) servers and workstations14
3. Highlight the stape driver. If the driver has not been added to the kernel, both Current State
and Planned State will read “unused”.
4. Type “m” to modify the stape driver and “s” to set it to “static”. The Planned State will now read
“static”.
5. The stape driver is now added to the kernel.
6. If you are going to attach an autoloader, use a similar procedure to change schgr to “static”.
7. Reboot the system.
For HP-UX 11i v3 (11.31)
1. Start up the SMH web-based interface.
% smh –w
This will attempt to launch a web browser. Mozilla browser1is the default when HP-UX 11i v3 is
installed.
2. From the SMH Tools page (see Figure 3), select Modules from the Kernel Configuration section.
Figure 3 SMH web-based interface (HP-UX11i v3)
3. In the Search box on the Kernel Configuration page, type stape and execute the search.
The search results list will include both estape and stape modules. If either of these modules is
not installed both Current State and Next Boot State will be shown as “unused”. A state of
“static” indicates that the module is installed.
1. If Mozilla is being invoked for the first time you may be asked to agree to license terms for the software.

HP LTO Ultrium 4 drives technical reference manual, volume 5: UNIX, Linux and OpenVMS configuration guide 15
4. Select the estape module1radio button. Its details will appear in a panel below the modules
list. From the right hand panel on the web page, click the Modify Module link.
5. On the Modify Kernel Module: estape page, for Next Boot State, select the “static” radio button.
Check the box entitled Backup to create a backup copy of the existing kernel (see Figure 4).
Figure 4 Adding estape driver to the kernel
6. If you wish, type in a Reason for Change, such as “Initial estape installation May
1st 2007” and then select the Modify tab.
7. Click the OK button at the Operation Successful page. Both estape and stape drivers will
now be shown with Next Boot State as “static”.
8. For autoloaders, use a similar procedure to prepare the eschgr (with schgr) module.
9. From the right-hand panel on the Kernel Configuration page, click View Pending Changes and
reboot and proceed to reboot the system as directed.
10.Following the reboot, re-run SMH and search again for the driver as in step 3 above. Current
State and Next Boot State should both be listed as “static”.
Add device files
For HP-UX 11i v1, 11i v2
Use the sam utility to create device files. sam runs as a mouse driven GUI (see Figure 1 on page 12)
on a system with full graphics capability, or as a console text-based interface (see Figure 2 on page
13). If you use the text-based interface, use the Tab and arrow keys to navigate, and the Return key
to select.
1. Enter sam at the command line:
% sam
2. Select the following:
1. The estape and stape modules are linked, so it is sufficient to select the estape module alone for installation.

HP (HP-UX) servers and workstations16
Peripheral Devices
Tape Drives
sam will then scan the system for any tape drives connected.
For example, when an HP LTO Ultrium 4 drive is found, it will be displayed as something like:
Hardware Path Driver Description
===========================================================
8/0/2/0.3.0 stape HP Ultrium 4-SCSI
3. Highlight the drive and select the following from the tool bar:
Actions
Create Device Files
Create Default Device Files
This will create default device files for the drive. To view the device files that have been created,
select:
Actions
Create Device Files
Show Device Files
4. When you have exited sam, run ioscan to see the tape drive:
%/sbin/ioscan –fnC tape
All default device files displayed have compression enabled.
NOTE: HP recommends the ‘Berkeley’ device files for most applications:
cXtYdZBESTnb = Berkeley, no rewind, best available density
cXtYdZBESTb = Berkeley, with rewind, best available density
where:
X= card number
Y= target number (drive SCSI ID)
Z= LUN number
For HP-UX 11i v3 (HP-UX 11.31)
1. Start up the SMH web-based interface:
%smh –w
This will attempt to launch a web browser. Mozilla browser1is the default when HP-UX 11i v3 is
installed.
2. From the SMH Tools page (see Figure 3 on page 14), select Manage Peripheral Devices from
the Peripheral Devices section.
1. If Mozilla is being invoked for the first time you may be asked to agree to license terms for the software.

HP LTO Ultrium 4 drives technical reference manual, volume 5: UNIX, Linux and OpenVMS configuration guide 17
3. Select tape from the Class drop down box on the HP-UX Peripheral Device Tool page. Select the
tape device (radio button) requiring device files from the resulting list. If device files are not
already present this will be indicated under the Properties header (see Figure 5)1.
Figure 5 Selecting a tape device to create its device files (Agile View)
4. From the right-hand panel on the HP-UX Peripheral Device Tool page, click on Reinstall Device
Files. At the next page, click the Reinstall button. When the browser returns to the HP-UX
Peripheral Device Tool page, click the Refresh button one or more times until the list of device
files appears under the Properties header.
What next?
Once device files have been created, you should confirm that your new tape drive is working
properly. Chapter 8 on page 37 provides instructions on backing up and restoring a sample file to
test your installation.
1. Depending on how SMH was last used the HP-UX Peripheral Device Tool page will display either the Agile View or the
Legacy View as described at the beginning of this chapter (page 9). To switch between these views use the Toggle
Global Device View link on the right hand side of the HP-UX Peripheral Device Tool page. In this chapter, the Agile View
is assumed. The process is similar for the Legacy View.

HP (HP-UX) servers and workstations18
