Hewlett Packard's MSA P2000 Family of storage arrays features P2000 G3 arrays with the latest 8 Gb Fibre Channel, 6 Gb SAS, 10GbE
iSCSI connected models, and an iSCSI model with four 1 Gb iSCSI ports per controller. The arrays are designed for entry-level customers
and feature the latest in functionality and host-connect technology while offering excellent price/performance. They are ideal for
companies with small budgets or limited IT expertise, and also larger companies with departmental or remote requirements. Each
solution is designed to be easy to deploy, to be secure, along with low management costs, while driving rapid return on investment
through efficient storage consolidation.
The MSA P2000 G3 arrays are 2U storage area network (SAN) or direct connect solutions (OS and protocol dependent) offering a choice
of five controllers - two FC, one SAS, one 10GbE iSCSI and the newest model features a four port 1 Gb iSCSI. The first Fibre Channel
controller is a high-performance, 8 Gb dual port model. The second offering is a unique dual-purpose Combo controller with two 8 Gb
Fibre Channel ports with the addition of two 1GbE iSCSI ports. The third controller choice is 6Gb SAS with four ports per controller.
There is also the addition of a two port 10 Gb iSCSI, while the latest controller introduction features four 1 Gb iSCSI ports per controller.
Whatever the situation calls for, the P2000 G3 line-up has the right solution.
The dual-protocol MSA P2000 G3 MSA FC/iSCSI Combo Controller gives exceptional flexibility. The 8 Gb FC ports support a full FC SAN
while the two 1GbE iSCSI ports can serve two purposes. With this combination you can economically share the array storage resource
with a smaller department accessing it over iSCSI or enable the new optional Remote Snap functionality over iSCSI protocol (also
available over FC).
The MSA P2000 G3 SAS is the follow-on product to the MSA2000sa G2, adding the latest 6 Gb SAS technology to the four host ports per
controller. The P2000 G3 SAS array is designed for directly attaching up to four dual-path or eight single path rack servers. SAS array
support for BladeSystems utilizes the HP 6 Gb SAS BL Switch.
The MSA P2000 G3 10GbE iSCSI brings the very latest in high-performance host connection with technology generally found only in
higher priced arrays. The bandwidth it provides in conjunction with server consolidation is highly advantageous in shared storage
configurations. Array connection to 10GbE switches that are in turn connected to 1GbE NICs is commonplace. Directly attached server
support requires the server units to have 10GbE NICs.
Rounding out the controller choices is the MSA P2000 G3 iSCSI controller featuring four 1Gb iSCSI Ethernet ports, double the number of
the G2 model. This allows an array that keeps the price of the components, particularly the interconnects, low while markedly
increasing the performance capabilities.
All MSA P2000 G3 models can be equipped with single or dual controllers, feature the same scalability, and offer 6 Gb SAS back-end
transmission speed to drives and JBODs. Significant data protection advances are delivered by the all P2000 G3 arrays. All G3 units
come STANDARD with sixty-four snapshot capability at no extra cost and there is an option for the G3 series of five hundred and twelve
snapshots. Volume Copy (clone) also comes standard. In a further move to protect the user's data, optional Remote Snap (replication)
capability is offered on the FC, FC/iSCSI, and both iSCSI versions.
All MSA P2000 G3 models support hot plug replacement of redundant controllers, fans, power supplies, and I/O modules. Hot add of
expansion enclosures is also supported.
The controller-less MSA P2000 chassis is offered in two models - one comes standard with twelve Large Form Factor (LFF) 3.5-inch
drive bays, the other can accommodate twenty-four Small Form Factor (SFF) 2.5-inch drives. Both are able to simultaneously support
enterprise-class SAS drives, SAS Midline, and archival-class SATA Midline drives. Either chassis can have one or two matching P2000 G3
controllers (same protocol) and are available with AC or DC power Supplies.
The HP modular approach to entry level SAN solutions enables incremental customer purchases, allowing the array to grow as needs
grow, thus allowing a maximum return on investment. Choose a single controller unit for low initial cost with the ability to upgrade
later; or decide on a model with dual controllers for the most demanding entry-level situations. There are no unexpected additional
charges, licenses or fees as you add enclosures or hosts and users.
QuickSpecs
HP MSA P2000 G3 Modular Smart Array Systems
Overview
DA - 13551 North America — Version 36 — December 9, 2013 Page 1

Capacity can easily be added as the need develops by attaching additional drive enclosures. Maximum capacity ranges with LFF drives
up to 57.6 TB SAS, 384 TB SAS Midline or 192 TB SATA Midline with the addition of the maximum number of drive enclosures.
Configurations utilizing the SFF drive chassis and the maximum number of drive enclosures can grow to 178 TB of SAS, 149 TB of SAS
Midline or 74.5 TB SATA Midline with a total of 96 LFF or 149 SFF drives. The P2000 G3 Arrays do not support SSDs.
What's New in the P2000 G3 array family
Introducing support for the HP MSA 1.2TB 6G SAS 10K ENT HDD
HP P2000 G3 SFF Modular Smart Array
HP P2000 G3 LFF Modular Smart Array
P2000 G3 FC Controllers, 2 installed
1. Power supplies 4. Reserved for future use
2. 8 Gb Fibre Channel ports 5. Management Ethernet port
3. CLI port (mini-USB) 6. Expansion port
QuickSpecs
HP MSA P2000 G3 Modular Smart Array Systems
Overview
DA - 13551 North America — Version 36 — December 9, 2013 Page 2

P2000 G3 FC/iSCSI Combo Controllers, 2 installed
1. Power supplies 5. Reserved for future use
2. 8 Gb Fibre Channel ports 6. Management Ethernet port
3. 1GbE iSCSI ports 7. Expansion port
4. CLI port (mini-USB)
P2000 G3 SAS controllers, 2 installed
1. Power supplies 4. Management Ethernet port
2. 6Gb SAS ports (four per
controller)
5. Expansion port
3. CLI port (mini-USB)
P2000 G3 10GbE iSCSI controllers, 2 installed
1. Power supplies 4. Management Ethernet port
2. 10GbE iSCSI ports 5. Expansion port
3. CLI port (mini-USB)
QuickSpecs
HP MSA P2000 G3 Modular Smart Array Systems
Overview
DA - 13551 North America — Version 36 — December 9, 2013 Page 3

P2000 G3 iSCSI dual controller
1. Power supplies 4. CLI port (mini-USB)
2. 1 GbE iSCSI ports (4) 5. Management Ethernet port
3. 1 GbE iSCSI ports (4) 6. Expansion port
QuickSpecs
HP MSA P2000 G3 Modular Smart Array Systems
Overview
DA - 13551 North America — Version 36 — December 9, 2013 Page 4

P2000 G3
Modular Smart Array
P2000 G3 Controllers
P2000 G3 Fibre Channel Controllers
HP P2000 G3 MSA Fibre Channel Controller
NOTE: two 8Gb FC ports per controller
AP836B
HP P2000 G3 MSA FC/iSCSI Combo Modular Smart Array Controller
NOTE: two 8Gb FC ports and two 1GbE iSCSI ports per controller
AP837B
P2000 G3 SAS Controller
HP P2000 G3 SAS MSA Array System Controller
NOTE: four 6Gb SAS ports per controller
AW592B
P2000 G3 10GbE iSCSI controller
HP P2000 G3 10GbE iSCSI MSA Array System Controller
NOTE: two 10GbE iSCSI ports per controller
AW595B
P2000 G3 iSCSI controller (1Gb Ethernet)
HP P2000 G3 iSCSI MSA Array System Controller
NOTE: four 1Gb iSCSI ports per controller
BK829B
P2000 Chassis
P2000 Controller-less Chassis (AC-powered)
HP P2000 LFF Modular Smart Array Chassis
NOTE: Will accept one or two controllers or Disk Enclosure I/O modules
AP838B
HP P2000 SFF Modular Smart Array Chassis
NOTE: Will accept one or two controllers, not I/O modules
AP839B
P2000 G3 Configured Array Systems
Configured Units, 8 Gb Fibre Channel Systems
HP P2000 G3 MSA FC Dual Controller LFF Modular Smart Array System AP845B
HP P2000 G3 MSA FC Dual Controller SFF Modular Smart Array System AP846B
HP P2000 G3 MSA FC/iSCSI Dual Combo Controller LFF Array AW567B
HP P2000 G3 MSA FC/iSCSI Dual Combo Controller SFF Array AW568B
Configured Units, 6 Gb SAS Systems
HP P2000 G3 SAS MSA Dual Controller LFF Array System AW593B
HP P2000 G3 SAS MSA Dual Controller SFF Array System AW594B
Configured Units, 10GbE iSCSI Systems
HP P2000 G3 10GbE iSCSI MSA Dual Controller LFF Array System AW596B
HP P2000 G3 10GbE iSCSI MSA Dual Controller SFF Array System AW597B
Configured Units, 1Gb iSCSI Systems
HP P2000 G3 iSCSI MSA Dual Controller LFF Array System BK830B
HP P2000 G3 iSCSI MSA Dual Controller SFF Array System BK831B
P2000 G3 FC SAN Starter Kits
HP P2000 G3 FC MSA Dual Controller Small Business SAN Starter Kit AP847B
QuickSpecs
HP MSA P2000 G3 Modular Smart Array Systems
Models
DA - 13551 North America — Version 36 — December 9, 2013 Page 5

includes (1) HP P2000G3 MSA FC Dual Controller LFF Array (AP845B) , (2) HP SN6000
12port Single Power FC Switch (BK780B) , (4) HP 81Q PCI-e FC Single Port HBA
(AK344A), (12 ) 8Gb Short Wave FC SFPs (AJ718A ), and (8 ) HP 5M OM3 FC Cables
(AJ836A ).
HP P2000 G3 FC MSA Dual Controller Virtualization SAN Starter Kit AP848B
(includes (1) HP P2000G3 MSA FC Dual Controller SFF Array (AP846B) , (2) HP 8/24 Base
16 Ports Enabled SAN Switch (AM868B) , (6) HP 81B PCI-e 8Gb FC Single Port HBA
(AP769A), (16 ) 8Gb Short Wave B Series FC SFPs (AJ716B ), and (10 ) HP 5M OM3 FC
Cables (AJ836A )
Disk Enclosures
HP P2000 Dual I/O LFF Drive Enclosure AP843B
HP P2000 LFF Drive Enclosure I/O Module AP844B
HP D2700 Disk Enclosure AJ941A
Controller-less Chassis (DC-powered)
HP P2000 DC-power LFF Chassis AP840B
(can add one or two P2000 G3 controllers or P2000 JBOD I/O modules)
HP P2000 DC-power SFF Chassis AP841B
Smart Buys HP P2000 G3 FC/iSCSI DC LFF Array/Smart-Buy- Americas
Includes: (1) HP P2000 G3 MSA FC/iSCSI DC LFF Array
(6) HP P2000 450GB 6G SAS 15K 3.5in DP HDD
BK748SB
HP P2000 G3 FC/iSCSI DC SFF Array/Smart-Buy- Americas
Includes: (1) HP P2000 G3 MSA FC/iSCSI DC SFF Array
(6) HP 300GB 6G SAS 10K 2.5 inch DP ENT HDD
BK749SB
HP P2000 G3 FC DC LFF Array/S-Buy- Americas
Includes: (1) HP P2000 G3 MSA FC Dual Controller LFF Array
(6) HP P2000 450GB 6G SAS 15K 3.5in DP HDD
BK746SB
HP P2000 G3 FC DC SFF Array/S-Buy- Americas
Includes: (1) HP P2000 G3 MSA FC Dual Controller SFF Array
(6) HP 300GB 6G SAS 10K 2.5 inch DP ENT HDD
BK747SB
HP P2000fc w/24 300GB 6GSAS-7.2TB Bundle- Americas
Includes: (1) HP P2000 G3 FC/iSCSI Dual Controller SFF MSA Array
(24) HP 300GB 6G SAS 10K 2.5in DP ENT HDD
BK816A
P2000 G3 Array Bundles
In some areas HP is offering P2000 G3 Array bundles with SFF SAS drives. These bundles can simplify the process of ordering. HP
offers these bundles with different type of P2000 G3 Array controllers for different storage capacity needs.
NOTE: These bundles are not offered worldwide so please check the availability for your region
Protocol Raw Capacity Regions
Availability
Bundle Description SKUs
Fully Populated Bundles:
FC Bundles 3.5 TB AMS
APJ
HP P2000 G3 FC DC w/24 146GB SAS
15K SFF HDD 3.5TB Bundle
BV901B
QuickSpecs
HP MSA P2000 G3 Modular Smart Array Systems
Models
DA - 13551 North America — Version 36 — December 9, 2013 Page 6

7.2 TB AMS
APJ
HP P2000 G3 FC DC w/24 300GB SAS
10K SFF HDD 7.2TB Bundle
BV902B
14.4 TB AMS
APJ
HP P2000 G3 FC DC w/24 600GB SAS
10K SFF HDD 14.4TB Bundle
BV903B
21.6 TB AMS
APJ
HP P2000 G3 FC 24x900GB SAS SFF
Bundle
QR517B
24 TB AMS
APJ
HP P2000 G3 FC 24x1TB SAS SFF
Bundle
QR521B
7.2 TB AMS AMS
APJ
HP P2000 G3 FC DC w/24 300GB SAS
15K SFF HDD 7.2TB Bundle
QW945B
FC/iSCSI Combo
Bundles
21.6 TB AMS
APJ
HP P2000 G3 FC/iSCSI MSA DC w/24
900GB SAS 10K SFF HDD 21.6TB
Bundle
QR518B
24 TB AMS
APJ
HP P2000 G3 FC/iSCSI MSA DC w/24
1TB SAS 7.2K SFF MDL HDD 24TB
Bundle
QR522B
SAS Bundles 7.2 TB AMS
APJ
HP P2000 SAS DC w/24 300GB SAS
10K SFF HDD 7.2TB Bundle
BV908B
14.4 TB AMS
APJ
HP P2000 SAS DC w/24 600GB SAS
10K SFF HDD 14.4TB Bundle
BV909B
21.6 TB AMS
APJ
HP P2000 G3 SAS MSA DC w/24 900GB
SAS 10K SFF HDD 21.6TB Bundle
QR519B
24 TB AMS
APJ
HP P2000 G3 SAS MSA DC w/24 1TB
SAS 7.2K SFF MDL HDD 24TB Bundle
QR523A
1G iSCSI
Bundles
7.2 TB AMS
APJ
HP P2000 G3 iSCSI DC w/24 300GB
SAS 10K SFF HDD 7.2TB Bundle
BV911B
21.6 TB AMS
APJ
HP P2000 G3 iSCSI MSA DC w/24
900GB SAS 10K SFF HDD 21.6TB
Bundle
QR520B
24 TB AMS
APJ
HP P2000 G3 iSCSI MSA DC w/24 1TB
SAS 7.2K SFF MDL HDD 24TB Bundle
QR524B
Half Populated Bundles:
FC Bundles 3.6 TB AMS
APJ
HP P2000 G3 FC DC w/12 300GB SAS
10K SFF HDD 3.6TB Bundle
BV913B
7.2 TB AMS
APJ
EMEA
HP P2000 G3 FC DC w/12 600GB SAS
10K SFF HDD 7.2TB Bundle
BV914B
10.8 TB AMS
APJ
HP P2000 G3 FC MSA DC w/12 900GB
SAS 10K SFF HDD 10.8TB Bundle
QR525B
12 TB AMS
APJ
HP P2000 G3 FC MSA DC w/12 1TB SAS
7.2K SFF MDL HDD 12TB Bundle
QR529B
QuickSpecs
HP MSA P2000 G3 Modular Smart Array Systems
Models
DA - 13551 North America — Version 36 — December 9, 2013 Page 7

3.6 TB AMS
APJ
HP P2000 G3 FC DC w/12 300GB SAS
15K SFF HDD 3.6TB Bundle
QW949B
FC/iSCSI Combo
Bundles
10.8 TB AMS
APJ
HP P2000 G3 FC/iSCSI MSA DC w/12
900GB SAS 10K SFF HDD 10.8TB
Bundle
QR526B
12 TB AMS
APJ
HP P2000 G3 FC/iSCSI MSA DC w/12
1TB SAS 7.2K SFF MDL HDD 12TB
Bundle
QR530B
SAS Bundles 3.6 TB AMS
APJ
HP P2000 G3 SAS DC w/12 300GB SAS
10K SFF HDD 3.6TB Bundle
BV917B
7.2 TB AMS
APJ
HP P2000 G3 SAS DC w/12 600GB SAS
10K SFF HDD 7.2TB Bundle
BV918B
10.8 TB AMS
APJ
HP P2000 G3 SAS MSA DC w/12 900GB
SAS 10K SFF HDD 10.8TB Bundle
QR527B
12 TB AMS
APJ
HP P2000 G3 SAS MSA DC w/12 1TB
SAS 7.2K SFF MDL HDD 12TB Bundle
QR531B
3.6 TB AMS
APJ
HP P2000 G3 SAS DC w/12 300GB SAS
15K SFF HDD 3.6TB Bundle
QW951B
1G iSCSI G3
Bundles
3.6 TB AMS
APJ
HP P2000 G3 iSCSI DC w/12 300GB
SAS 10K SFF HDD 3.6TB Bundle
BV919B
7.2 TB AMS
APJ
HP P2000 G3 iSCSI DC w/12 600GB
SAS 10K SFF HDD 7.2TB Bundle
BV920B
10.8 TB AMS
APJ
HP P2000 G3 iSCSI MSA DC w/12
900GB SAS 10K SFF HDD 10.8TB
Bundle
QR528B
12 TB AMS
APJ
HP P2000 G3 iSCSI MSA DC w/12 1TB
SAS 7.2K SFF MDL HDD 12TB Bundle
QR532B
3.6 TB AMS
APJ
EMEA
HP P2000 G3 iSCSI DC w/12 300GB
SAS 15K SFF HDD 3.6TB Bundle
QW952B
QuickSpecs
HP MSA P2000 G3 Modular Smart Array Systems
Models
DA - 13551 North America — Version 36 — December 9, 2013 Page 8

Key Features
The HP P2000 G3 Modular Smart Array family encompasses five controllers, each featuring different protocols or combination of
protocols to match the exact needs of the user.
P2000 G3 FC/iSCSI Combo MSA controller: this unique controller offers both 8 Gb Fibre Channel and 1 GbE iSCSI functionalities
built into a single array controller. This allows customers to enable storage needing high performance thru the FC ports while
leveraging their SAN investment by sharing the array resources with smaller departments through low-cost iSCSI. It also
enables optional Remote Snap (replication) for data protection.
P2000 G3 FC MSA controller: Dual 8 Gb Fibre Channel host ports per controller give high performance with a mature topology
and is compatible with the largest installed base of SAN users.
P2000 G3 10GbE iSCSI MSA controller: HP was the first of the major modular array manufacturers that brought a high
performance dual-ported 10GbE iSCSI solution to the entry level segment. Ideal for those who want to utilize cost-effective
Ethernet as their infrastructure without sacrificing access time to their data. Now supports Remote Snap (replication).
P2000 G3 SAS MSA controller: the P2000 G3 SAS model gives fast 6 Gb transmission rates with low cost SAS connections. Four
host ports per controller support a highly efficient direct connect configuration.
P2000 G3 iSCSI MSA controller offers four 1 Gb iSCSI ports utilizes the popular Ethernet infrastructure with its low cost and ease
of management, while the additional ports assure increased performance over the previous generation. Now supports Remote
Snap (replication).
All P2000 G3 models offer a common set of valuable features:
Ease of management featuring browser-based out-of-band access. This allows a department or small company to effectively
handle growing storage requirements, with the aid of an intuitive GUI to administer the unit with a minimum of complexity. Ideal
for local or remote installations.
All G3 models come standard with 64 controller-based snapshots and clone capability. The G3 arrays also support an optional
512 snaps.
Choose either a low-cost single controller array or start with a configured dual controller array model to fit the budget, high
availability, and performance needs.
All models feature a wide variety of drives: enterprise-class SAS, SAS Midline, and archival-class SATA Midline in either P2000
LFF 3.5-inch or HP Storage SFF 2.5-inch drives.
P2000 G3 models can have a maximum number of P2000 LFF drive enclosures (7), a maximum number of D2700 SFF enclosures
(5), or mix both sizes. The array can grow incrementally from a few drives to 178 TB SAS, 384 TB of SAS MDL or 192 TB SATA
MDL.
2 GB transportable read/write cache per controller. Battery-free cache backup with super capacitors and compact flash
Vdisks can be spanned across multiple enclosures
RAID levels 0, 1, 3, 5, 6, 10, 50
Maximums vary by RAID levels: 2 drive max for RAID level 1; max of 16 drives for RAID levels 0, 3, 5, 6, and 10; max of 32 drives
for RAID level 50
512 LUNs with LUN sizes greater than 40TB depending on the RAID configuration chosen. The maximum LUN size is 64TB
Non-disruptive on-line controller code upgrade (requires dual controllers w/ multi-pathing software)
Upgradable by design. Owners of an original MSA2000 G1 or G2 array are able to do data-in-place controller upgrades to the
P2000 G3 FC, Combo FC/iSCSI, 1 Gb or 10GbE iSCSI, or P2000 G3 SAS. Cross protocol upgrades are also supported between the
protocols. This unique ability protects the earlier investments in chassis, drives, and JBODs
Follow us on twitter and be a part of the conversation, and get the latest P2000 G3/MSA related news and information at:
http://www.twitter.com/MSAstorage
HP P2000 G3 FC MSA SAN Starter Kits
QuickSpecs
HP MSA P2000 G3 Modular Smart Array Systems
Features
DA - 13551 North America — Version 36 — December 9, 2013 Page 9

The new P2000 G3 FC MSA SAN Starter kits are offered to simplify ordering and implementation of your SAN. HP includes all the
necessary hardware components to build your own SAN solution in one package, just add the drives of your choice. These kits are
offered at very affordable prices which reflect a savings over purchasing each SAN component separately.
Virtualization SAN Starter
Kit
HP P2000 G3 FC MSA Dual Controller Virtualization SAN Starter Kit AP848B
The HP P2000 G3 FC MSA Dual Controller Virtualization SAN Starter Kit addresses the
growing need for server and storage administrators to deliver end-to-end storage,
virtualization, and management capabilities across their network infrastructure. The
hardware bundle consists of six Host Bus Adapters (HBAs), two FC switches, a P2000 G3
FC MSA Dual Controller Array (SFF Chassis), sixteen 8Gb FC SFPs , ten HP 5M FC cables
as well as two licenses per switch enabling Server Application Optimization (SAO) and
Adaptive Networking (AN). SAO is an adapter technology that offers Quality of Service
(QoS) capabilities that can be used in conjunction with fabric wide QoS and to enable a
high performing, virtualized infrastructure. With SAO deployed, administrators can
protect a VM and its application by assigning its IO flow to a specific priority level. The
QoS priorities are enforced at the hardware level, thereby providing adequate
bandwidth during periods of high congestion. Applications such as email and databases
achieve better performance when deployed in specific SAO and MSA configurations.
Small Business SAN
Starter Kit
HP P2000 G3 FC MSA Dual Controller Small Business SAN Starter Kit AP847B
The HP P2000 G3 FC MSA Dual Controller Small Business SAN Starter Kit is a unique
end-to-end 8 Gbps SAN Solution, just add disks and power. This kit includes one 8 Gbps
P2000 G3 FC MSA Dual Controller Array (LFF Chassis), four 8 Gbps FC HBAs, two HP
SN6000 Stackable 8 Gbps 8-port FC switches, twelve 8Gb FC SFPs, eight HP 5M FC
cables and HP unique Simple SAN Connection Manager (SSCM) SAN management
software, cables, rails and optics. SSCM is the only SAN management software that can
manage the FC switch, HBA and provision HP storage from a single pane of glass.
Application Solutions The HP P2000 SAN is the ideal solution for customers running Oracle, Microsoft, SAP environments and
those customers who are deploying virtual server technologies like VMware, Hyper-V, and Oracle Virtual
Machine. The HP P2000 SAN delivers enterprise functionality that enhances virtual environments,
simplifies management, and reduces costs. Easy to deploy, scale and maintain, HP P2000 SANs ensure
that crucial business data remains available.
HP has developed best-in-class expertise in Oracle, Microsoft, SAP, and Virtualization Hypervisor
technology through extensive testing with the HP P2000 SAN, HP servers, and management software;
high availability and disaster recovery solutions; and backup and recovery on the Oracle, Microsoft, and
SAP application platforms. As a result, our customers can expect a wide range of operational and business
benefits where they can:
Deploy IT assets across multiple locations.
Incrementally grow storage without interruption.
Enable high availability and disaster recovery capabilities for critical applications.
Deploy a remote disaster recovery site.
Learn more To learn more about specific HP Storage Solutions that are built with Oracle, Microsoft, SAP and
Virtualization environments in mind, visit the solution sites supporting each of these applications.
HP Storage for Oracle hyperlink to: http://www.hp.com/storage/oracle
HP Storage for Microsoft hyperlink to: http://www.hp.com/storage/microsoft
HP Storage for SAP hyperlink to: http://www.hp.com/storage/sap
HP Storage for VMware hyperlink to: http://www.hp.com/go/vmware/storage
QuickSpecs
HP MSA P2000 G3 Modular Smart Array Systems
Features
DA - 13551 North America — Version 36 — December 9, 2013 Page 10

P2000 G3 FC P2000 G3 SAS P2000 G3 10GbE iSCSI P2000 G3 iSCSI (1GbE)
Capacity
Minimum / with maximum
additional drive enclosures
LFF : 7.2 TB SAS
or 48 TB SAS MDL or 24
TB SATA MDL
w/ 7 LFF enclosures:
57.6 TB SAS,
384 TB SAS MDL or 192
TB SATA
SFF : 28 TB SAS
or 24 TB SAS MDL or 12
TB SATA MDL
w/ 5 D2700 JBODs:
178 TB SAS
or 149 TB SAS MDL or
74.5 TB SATA MDL
LFF : 7.2 TB SAS
or 48 TB SAS MDL or 24
TB SATA MDL
w/ 7 LFF enclosures:
57.6 TB SAS,
384 TB SAS MDL or 192
SATA
SFF : 28 TB SAS
or 24 TB SAS MDL or 12
TB SATA MDL
w/ 5 D2700 JBODs:
178 TB SAS
or 149 TB SAS MDL or
74.5 TB SATA MDL
LFF : 7.2 TB SAS
or 48 TB SAS MDL or 24
TB SATA MDL
w/ 7 LFF enclosures:
57.6 TB SAS,
384 TB SAS MDL or 192
TB SATA
SFF : 28 TB SAS
or 24 TB SAS MDL or 12
TB SATA MDL
w/ 5 D2700 JBODs:
178 TB SAS
or 149 TB SAS MDL or
74.5 TB SATA MDL
LFF : 7.2 TB SAS
or 48 TB SAS MDL or 24
TBSATA MDL
w/ 7 LFF enclosures:
57.6 TB SAS,
384 TB SAS MDL or 192
TB SATA
SFF : 28 TB SAS
or 24 TB SAS MDL or 12
TB SATA MDL
w/ 5 D2700 JBODs:
178TB SAS
or 149 TB SAS MDL or
74.5 TB SATA MDL
Controller Cache 2 GB per controller 2 GB per controller 2 GB per controller 2 GB per controller
Total LUNs
LUN sizes greater than
40TB depending on the
RAID configuration chosen
512
maximum LUN size: 64TB
512
maximum LUN size: 64TB
512
maximum LUN size: 64TB
512
maximum LUN size: 64TB
Host connect
P2000 & MSA2000 have 1
or 2 controllers, EVA has 2
controllers standard
Two 8 Gb
Fibre Channel ports or
Two 8Gb FC and two 1GbE
iSCSI ports
per controller
Four 6 Gb (x4)
SAS ports
per controller
Two 10 GbE iSCSI ports
per controller
Four 1 Gb
iSCSI ports
per controller
Maximum Drives
w/ expansion
96 LFF/149 SFF 96 LFF/149 SFF 96 LFF/149 SFF 96 LFF/149 SFF
Maximum host supported
(dual controller)
64 64
w/ SAS switch: 32 single
blade servers (2x c7000),
or 16 dual density blade
servers
64 64
Optional software:
Snapshot, clone,
Remote Snap
Snapshot, 64 standard
(max 512)
Clone (standard)
Remote Snap (optional)
Snapshot, 64 standard
(max 512)
Clone (standard)
Snapshot, 64 standard
(max 512)
Clone (standard)
Remote Snap (optional)
Snapshot, 64 standard
(max 512)
Clone (standard) Remote
Snap (optional)
Use for Storage Primary Storage
with SAS drives.
Secondary with SATA
Primary Storage
with SAS drives.
Secondary with SATA
Primary Storage
with SAS drives.
Secondary with SATA
Primary Storage
with SAS drives.
Secondary with SATA
NOTE: maximum available storage capacity depends on the RAID level being implemented
Product Technology
QuickSpecs
HP MSA P2000 G3 Modular Smart Array Systems
Family Information
DA - 13551 North America — Version 36 — December 9, 2013 Page 11

8Gb Fibre Channel
controller
Two host ports per FC controller shipped with SFPs. The P2000 G3 FC controller can run in either point-to-
point or FCAL (loop). The default is FCAL which is used in Direct Connect, particularly with two controllers.
The PtP (fabric) mode is used with almost all switches.
Combo controller with
FC and iSCSI ports
This ingenious dual-protocol "combo" controller supports a full FC SAN through the 8Gb FC ports, while
designating the two 1 GbE iSCSI ports to enable remote replication over iSCSI protocol and perform as an
iSCSI target. This allows economical sharing of the storage resource (the P2000 G3 array) with one
department needing the performance afforded by the 8 Gb FC ports while simultaneously supporting
another department with lesser performance needs and a budget only allowing a 1GbE iSCSI network.
6Gb SAS controller Four 4x host ports per 6Gb SAS controller.
10GbE iSCSI controller Two 10GbE ports per G3 10GbE iSCSI controller. Ports are ready for the choice of SFP (none included)
Supports the ProCurve and ISS versions of the following 10GbE parts for use in the controllers:
HP 10Gb Cables
HP SFP+ 10GbE Copper Cable
HP ProCurve 10-GbE SFP+-SFP+ Direct Attach Cable
HP SFP+ Transceivers
HP BladeSystem 10Gb SR SFP+ and HP BladeSystem 10Gb LRM SFP+
HP ProCurve 10-GbE SFP+ SR Transceiver and HP ProCurve 10-GbE SFP+ LRM Transceiver
No SFP+ LR Transceiver support
1 Gb iSCSI controller Four 1 Gb Ethernet iSCSI ports per G3 iSCSI controller
Modular Chassis 2U rack height. 12 Large Form Factor or 24 Small Form Factor drive bays, accommodating SAS and SATA.
Comes with space for one or two controllers, or P2000 3.5-inch disk Enclosure I/O modules (LFF chassis
only)
Drives available The P2000 G3 controllers support both the P2000 3.5-inch Large Form Factor (LFF) drives, and the HP
Storage 2.5-inch Small Form Factor (SFF) drives.
Serial Attached SCSI (SAS) enterprise-class drives are designed for high demand, 24x7 usage.
SAS Midline and SATA Midline are usually reserved for archival of data as they are both relatively
inexpensive and are available in very large capacities.
The HP entry-level family of arrays can accommodate both SAS and SATA drives within the same enclosure
making it ideal to have both business-critical, high activity files on SAS drives while using Snapshot, clone,
or Remote Snap capability to keep back-up or archival data on the less expensive drives.
For investment protection, the controllers will support single and dual port SAS & SATA drives in a legacy
single - or dual - domain MSA70. This support allows current owners of MSA70s to migrate their single port
drives (in their MSA70 only, not into the array head) to be attached to a P2000 G3 FC or SAS. They can only
cascade to another single I/O MSA70. This is not a data-in-place transition, and overall performance could
be impacted.
SAS drive performance can be approximately 30% greater than SATA performance on sequential host I/O.
SAS performance excels in sequential lower latency response time and random I/O per second transaction
performance due to higher rpm disk speeds yielding lower seek times. SAS drive random performance is
generally twice that of SATA drives.
NOTE: P2000 and MSA2 3.5-inch Large Form Factor (LFF) drives are for use only in the P2000 G3 or
QuickSpecs
HP MSA P2000 G3 Modular Smart Array Systems
Family Information
DA - 13551 North America — Version 36 — December 9, 2013 Page 12

MSA2000 models. The 2.5-inch Small Form Factor (SFF) drives are supported only with the P2000 G3 or the
MSA2300 G2 controllers and are Storage hot-plug 2.5-inch drives.
Optional Disk enclosures Just as the user has a choice of chassis for the array head (LFF and SFF drive bays, AC or DC powered), so
also do they have a choice of expansion disk enclosures accommodating either drive size. Both the P2000
and the D2700 disk enclosures can be hot-added to an operating array.
( NOTE: these are not supported as part of a NEBS-certified configuration with the MSA Carrier Grade
Chassis. There is a certified JBOD listed in the Carrier-grade section )
P2000 3.5-inch drive enclosure . This 2U storage enclosure (AJ941A) is designed to support twenty five
Storage 2.5-inch Universal form factor (SFF) 6Gb SAS or SATA hard drives. It ships standard with dual I/O
modules installed.
This 3.5-inch drive enclosure can be attached to either the P2000 G3 FC or SAS LFF or SFF array head.
Each configured model ships standard with two .5m mini-SAS to mini-SAS cables for cascading to
other P2000 drive enclosures
Up to seven P2000 3.5-inch enclosures can be attached to a P2000 G3 FC, FC/iSCSI Combo, or SAS
controller in the array head.
D2700 2.5-inch drive enclosure . This 2U storage enclosure (AJ941A) is designed to support twenty five
ProLiant 2.5-inch Universal form factor (SFF) 6Gb SAS or SATA hard drives. It ships standard with dual I/O
modules installed.
This 2.5-inch drive enclosure can be attached to a P2000 G3 controller (SFF or LFF) array head
The D2700 enclosure ships with a two .5m miniSAS to miniSAS cable.
Up to five D2700 may be attached to the P2000 G3 array head, given total support for 149 SFF drives.
Scalability The P2000 G3 FC, Combo FC/iSCSI, SAS, 1 Gb or 10GbE iSCSI controllers are designed to allow an installation
to begin with smaller capacity and be able to grow gradually as needed. The flexibility of SAS or SATA drive
technology, form factors, sizes, speeds, and costs per GB allows a system to easily fit in almost any budget.
Large Form Factor configurations can scale up to 7.2 TB SAS, 36TB SAS MDL or 24 TB SATA,
expandable to 57.6 TB SAS, 384 TB SAS MDL or 192 TB SATA with the addition of a maximum of seven
P2000 3.5-inch Drive Enclosures.
Small Form Factor configurations can scale from 21.6 TB SAS, 24 TB SAS MDL or 12 TB SATA MDL.
With the addition of five D2700 JBODs, the P2000 G3 can support 134 TB SAS, 149 TB SAS MDL or
74.5 TB SATA MDL.
Users may configure a 24-drive P2000 G3 SFF array head with 12-drive LFF P2000 3.5-inch disk
enclosures. This is an excellent method for a configuration that supports fast SFF enterprise-class
SAS drives in the array head, combined with economical LFF drives staged for archival purposes, all in
the same array.
Qualification of larger capacity drives is ongoing.
Vdisks Vdisks can span across multiple enclosures, where drives used in the Vdisk can be contained in different
enclosures. The maximum number of drives that can be used in RAID 1 Vdisk is 2; RAID 0, 3, 5, 6, and 10 is
16; and for RAID 50 Vdisk is 32.
LUNs The HP 2000 family of arrays supports 512 LUNs (total volumes in a dual controller system) and LUN sizes
up to 64 TB depending on the RAID configuration chosen. The array supports expansion and deletion of any
LUN.
RAID 0, 1, 3, 5, 6, 10, 50 In addition to the usual RAID levels, the P2000 G3 features several important additional levels. RAID 6 is the
highest level of RAID protection. It allocates two sets of parity data across drives and allows simultaneous
write operations. It can withstand two simultaneous drive failures without downtime or data loss. RAID 10 is
mirroring and striping without parity. It is the most popular of the multiple RAID levels, allowing large arrays
with high performance in most cases and superior fault tolerance. RAID 50 combines the block striping and
parity of RAID 5 with the straight block striping of RAID 0, yielding higher performance than RAID 5 through
QuickSpecs
HP MSA P2000 G3 Modular Smart Array Systems
Family Information
DA - 13551 North America — Version 36 — December 9, 2013 Page 13

the addition of RAID 0, particularly during writes.
Performance Performance numbers are a guideline as established by tests using RAW I/O in an Operating System
Agnostic test lab environment. 144 GB 15K SAS drives were used in a dual controller configuration of 12
vdisks consisting of twelve disks per vdisk, 1.6 TB volumes, and 3 volumes per host. 4 hosts directly
attached to the P2000 G3 array were used in this test configuration (results cannot be expected with a
single host). Results were achieved in Sequential Writes with 256K blocks; all random tests were based on
8K block sizes.
NOTE: Number and type of applications, drive type and number of drives, operating system used, and the
number of hosts will affect overall performance. This table is provided strictly as a test-lab comparison.
Note: These numbers reflect a full array configuration with the maximum number of front-end ports, disks,
and controllers. The test results shown for the P2000 G3 are designed to give a conservative reference
point for comparisons.
2000 Array
Performance
P2000 G3 FC P2000 G3
SAS
P2000 G3 10GbE
iSCSI
P2000 G3 1GbE iSCSI
Protocol (host
connect)
8 Gb
Fibre Channel
6 Gb
SAS
10Gb
Ethernet
1 Gb
Ethernet
2000 RAID 10 Performance Results
Sequential Reads
MB/s
1,650 1,650 1,600 550
Sequential Writes
MB/s
850 850 800 525
Random Mix IOPs
60/40 read/write
20,500 23,500 18,500 17,200
2000 RAID 5 Performance Results
Sequential Reads
MB/s
1,650 1,650 1,600 550
Sequential Writes
MB/s
1,300 1,350 1,000 525
Random Mix IOPs
60/40 read/write
14,000 16,000 12,500 9,400
2000 RAID 6 Performance Results
Sequential Reads
MB/s
1,650 1,650 1,600 550
Sequential Writes
MB/s
1,300 1,100 1,000 525
Random Mix IOPs
60/40 read/write
8,300 9,800 7,500 5,600
Refer to the paper titled "Upgrading the HP MSA2000 (G1 or G2) to the P2000 G3 MSA ", available in the
Resource Library at: www.hp.com/go/p2000 .
DC-power chassis HP is making the two models of controller-less chassis available with direct current (DC) power supplies.
They each have the two empty bays where users can insert one or two P2000 G3 controller(s). In addition,
the P2000 chassis with LFF drive bay can have P2000 3.5-inch I/O modules inserted to create a LFF DC-
power JBOD.
The 500 watt power supply is designed to operate over the input range of -40VDC to -75VDC.
SKU
HP P2000 DC-power LFF twelve 3.5-in Drive Bays AP840B
QuickSpecs
HP MSA P2000 G3 Modular Smart Array Systems
Family Information
DA - 13551 North America — Version 36 — December 9, 2013 Page 14

(supports up to 2 controllers or I/O modules)
HP P2000 DC-power SFF Chassis AP841B
Configuration and
Management Tools
HP Storage Management Utility (SMU). Management access, out-of-band: WEB GUI, CLI. Interface Types:
USB, 10/100 Ethernet. Protocols Supported SNMP, SMI-S, SSL, SSH, SMTP, FTP, HTTP, Telnet
P2000 Software and
Documents
Support CD
All product documentation (CD can be used on ALL supported server Operating Systems.)
MSA Device Discovery Tool (Win and Linux) - reports P2000/MSA HW devices, and supported storage
software
Host Software Bundles (Win and Linux for both ProLiant x86, ProLiant x64 and Integrity IA64servers)
CD updated quarterly on HP.com with sustaining firmware updates
The P2000 G3 contains an embedded SMI-S provider for use by SMI-S client applications. The
embedded provider is designed to support P2000 configurations with up to 24 hard drives, and up to
250 mapping paths. A mapping path is defined as a P2000 volume presented through a P2000 target
port to a Host initiator.
Hot Plug Expansion and
Replacement Support
All P2000 G3 models support hot plug expansion and replacement of redundant controllers, enclosures,
fans, power supplies, and I/O modules for simple, fast installation and maintenance. Hot add expansion of
disk enclosures is also supported.
Snapshot and Clone All G3 arrays come standard with 64 snaps, 512 snaps available. Controller based functionality. Offers
higher levels of data protection, enabling an almost instant recovery from data failure or corruption. Offers
alternative development testing of 'offline' production data and the ability to backup snapped/cloned data.
Overview The P2000 G3 arrays come integrated with web browser and CLI based software for storage and RAID
management, setup, configuration, and troubleshooting. This reduces the cost of ownership by reducing
the training and technical expertise necessary to install and maintain your HP storage solution.
The SPOCK database provides interoperability information for thousands of components and millions of
component combinations. It is available to all users at http://www.hp.com/storage/spock .
Server Compatibility
NOTE: depends on protocol
Supports most HP ProLiant, BladeSystems and Integrity servers including
HP ProLiant DL, ML
HP c-Class Blade Servers
Integrity servers, IA64 (FC and FC/iSCSI support only)
Compatibility must be confirmed at: http://www.hp.com/storage/spock
Industry Standard servers
support
Supports most multi-vendor industry standard 32-bit Intel and AMD based (x86) servers. HP
requires the Third-Party Server to be logo'd and listed on the Microsoft Windows Server Catalog.
Refer to the Microsoft website: http://www.microsoft.com/windows/catalog/server/
HP Division recommends that the Third-Party Server Vendor is an active member of TSANet. Refer
to the TSANet website for details: www.tsanet.com
Non-HP servers will generally be supported if the HP storage stack is used. This includes supported
HP branded HBAs and drivers, and supported FC switches.
OS Support
Fibre Channel ports
Refer to the HP support statements for complete current OS version support:
http://www.hp.com/storage/spock
Microsoft Windows Server 2012
Microsoft Windows Server 2008 IA32, x64, IA64 (Standard, Enterprise, Datacenter)
Microsoft Windows Server 2008 R2 x64
Microsoft Windows 2003 SP1, SP2, and R2 and 2003 R2 IA32, x64
HP-UX
Red Hat Linux (32/64)
SuSE SLES (32/64)
QuickSpecs
HP MSA P2000 G3 Modular Smart Array Systems
Family Information
DA - 13551 North America — Version 36 — December 9, 2013 Page 15

Microsoft Windows Server 2008 x64 Hyper-V
VMware
OpenVMS
Apple Mac OS X (requires ATTO Celerity 8Gb FC HBA)
Solaris 10 (x86)
OS Support
Fibre Channel Ports
(Integrity)
HP-UX
Windows
OpenVMS
Linux
OS Support
1GbE iSCSI ports
on the G3 Combo FC/iSCSI
Controller
Microsoft Windows Server 2012
Microsoft Windows Server 2008 and 2008 R2 (x64, IA64)
Microsoft Windows Server 2008 x64 Hyper-V
Microsoft Windows 2003 (SP1, SP2, and R2) and 2003 R2 (IA32, x64)
Red Hat Enterprise Linux (32/64)
SuSE Linux IA32, x64
VMware ESX
OS Support
G3 SAS Controller
Refer to the HP support statements for complete current OS version support:
http://www.hp.com/storage/spock
Microsoft Windows Server 2012
Microsoft Windows Server 2008 IA32, x64
Microsoft Windows Server 2008 R2
Microsoft Windows 2003 and 2003 R2 IA32, x64
Red Hat Linux (32/64)
SuSE SLES (32/64)
Microsoft Windows Server 2008 x64 Hyper-V
VMware
Solaris 10 (x86)
OS Support
G3 1Gb iSCSI Controller
Microsoft Windows Server 2012
Microsoft Windows Server 2008 SP1, SP2, R2
Microsoft Hyper-V (x64 only)
Microsoft Windows Server 2003 and 2003 R2, SP2
VMware
Red Hat Linux (32/64)
SuSE SLES (32/64)
OS Support
G3 10GbE iSCSI Controller
Microsoft Windows Server 2012
Microsoft Windows Server 2008 SP1, SP2, R2
Microsoft Hyper-V (x64 only)
Microsoft Windows Server 2003 and 2003 R2, SP2
Red Hat Linux (32/64)
SuSE SLES (32/64)
VMware
NOTE: the G3 10GbE array must connect to a 10GbE switch; direct connect to the G3 10GbE array must be
to a 10GbE NIC and supported by the OS.
QuickSpecs
HP MSA P2000 G3 Modular Smart Array Systems
Family Information
DA - 13551 North America — Version 36 — December 9, 2013 Page 16

Web Browser support The P2000 G3 and the older MSA2000 support target based management, and include a Web
interface and a telnet interface, and require a web browser for management.
The P2000 G3 FC requires Microsoft Internet Explorer V7.x or V8.x
The original MSA2000 and the MSA2000 G2 arrays require Microsoft Internet Explorer V6.X and V7.X
(strongly encouraged)
Mozilla Firefox 1.0.7 or later is supported
QuickSpecs
HP MSA P2000 G3 Modular Smart Array Systems
Family Information
DA - 13551 North America — Version 36 — December 9, 2013 Page 17

VMware Site Recovery
Manager (SRM)
VMware Site Recovery Manager (SRM)
VMware vCenter Site Recovery Manager (SRM) is an extension to VMware vCenter that delivers business-
continuity and disaster-recovery solution that helps you plan, test, and execute the recovery of vCenter
virtual machines. SRM can discover and manage replicated datastores, and automate migration of
inventory from one vCenter to another. Site Recovery Manager integrates with the underlying replication
product through a Storage Replication Adapter (SRA).
HP P2000 Site Recovery Adapter (SRA)
The HP P2000 SRA, a free-to-use plugin, is the program that integrates the VMware cCenter SRM with HP
P2000 G3 arrays. It enables full-featured use of the VMware SRM. It is a host-software component
installed on a Microsoft Windows Server that enables disaster recovery management (DRM) software on
the host to communicate and control certain aspects of the replication feature in storage systems
connected to the server. It allows the VMware SRM software to automatically coordinate virtual machine
failover and failback between a protected data center and a disaster recovery site by employing a disaster
recovery solution called Remote Snap. A perfect combination of the Remote Snap replication and VMware
SRM provides an unfailing automated solution for implementing and testing the disaster recovery between
sites located across geographies. It enables communication between the HP P2000 Remote Snap
replication functionality that is embedded in HP P2000 Fibre Channel, iSCSI, and Combo Fibre Channel
systems. Users are required to acquire Remote Snap license for their local and remote HP P2000 G3 arrays
to use the HP P2000 SRA.
Site Recovery Manager Requirements/Dependencies:
Requires vSphere 5.0/SRM 5.0
Not compatible with SRM 4.x
Requires HP's P2000 SRA 2.0 Plug-in (downloadable from Hp.com)
SRM works with Remote Snap functionality
Requires purchase of P2000 G3 Remote Snap licenses (one for each site)
Customers must upgrade to T240 or the latest firmware
SRM works with FC, iSCSI or Combo controllers only
HP Insight Control
Storage Module for
vCenter
HP Insight Control Storage Module for vCenter
HP Insight Control Storage Module for vCenter is a component within the HP Insight Control plug-in for
vCenter. It provides VMware administrators that are using VMware's vSphere management console
(vCenter) with the ability to see how virtual machines are mapped to datastores and individual P2000
volumes. By providing these clear relationships between VM's, datastores and storage, the VMware
administrator's productivity increases, as does the ability to ensure quality of service. Roles for
administrators can be defined on an individual basis, providing the ability to apply specific permissions for
both view and control functions.
The HP Insight Control Storage Module for vCenter supports mixed array environments including EVA,
P4000, P2000 (MSA), and the XP array series including the P9500.
When deployed with the P2000 array, provides the following:
Active Management functionality for the P2000 array:
Create/Expand/Delete a Datastore
QuickSpecs
HP MSA P2000 G3 Modular Smart Array Systems
Hardware
DA - 13551 North America — Version 36 — December 9, 2013 Page 18

Create a Virtual Machine from a template
Monitors the health and status of the P2000
Displays LUN / volume connections from VMs and ESX servers to the arrays and provides the
location and attributes of the P2000 within the SAN
Identifies what storage features are available to allow administrators to match the features
available on the P2000 to their requirements
Provide a cluster-level view of the storage
HP Insight Control Storage Module for vCenter is downloadable from Software Depot:
https://h20392.www2.hp.com/portal/swdepot/displayProductInfo.do?productNumber=HPVPR
For more information on HP Insight Control Storage Module for vCenter visit: www.hp.com/go/vmware
vStorage API for Array
Integration (VAAI)
The vStorage API for Array Integration (VAAI) is one of the storage application programming interface (API)
sets in vSphere 4.1. VAAI is an API storage partners can leverage to enhance performance of virtual
machine (VM) management operations by delegating these operations to the storage array. With hardware
offload, ESX/ESXi hosts perform certain operations faster and consume less server CPU and memory
resources, and also storage port and storage fabric bandwidth. VAAI includes high performance and
scalable VM data path primitives. HP introduced VAAI support for HP MSA P2000 Storage array products
starting with the T230 firmware release.
Storage Hardware Primitives for VAAI
In the VMware vSphere 4.1 release, the HP StorageWorks P2000 G3 MSA Array Systems offload capabilities
support the following three primitives:
Full Copy or Hardware Assisted Move
Block Zeroing or Hardware Assisted Zeroing
Hardware Assisted Locking or Atomic Test and Set (ATS)
HP Storage Management
Pack for Microsoft
System Center
The HP Management Pack for Systems Center Operations Manager provides seamless integration with
Microsoft Systems Center Operations Manager and now System Center Essentials by integrating
predefined discovery and state monitoring policies, event processing rules and tasks, and diagram and
topology views for the storage system.
For more information:
http://h18000.www1.hp.com/products/quickspecs/14249_na/14249_na.html
HP Storage Management Pack can be downloaded free from the following website:
https://h20392.www2.hp.com/portal/swdepot/displayProductInfo.do?productNumber=SCOM
Snapshot and Volume
Copy Software for the
P2000 G3
Product Features
Data Protection
Snapshots create up to 512 point-in-time pictures of data (512 snaps are exclusive to the P2000 G3)
Volume Copies create up to 128 point-in-time copies of data
Recovery is instant - revert data from any previous Snapshot or Volume Copy
Backup 'snapped' data to disk, virtual tape, or physical tape without a backup window
A 64 snapshot license and Volume Copy are included with all P2000 G3 models.
QuickSpecs
HP MSA P2000 G3 Modular Smart Array Systems
Hardware
DA - 13551 North America — Version 36 — December 9, 2013 Page 19

Support and updates are desired for bundled software functionalities (such as 64 LTU Snap and/or
Volume Copy etc in the P2000 G3 products) a combination HW + SW support care pack must be
purchased.
HP does not provide warranty assistance for software products included with our base hardware
products. This would either be SupportPlus or SupportPlus24. The hardware warranty component of
these services is accounted for in the pricing of the SP and SP24 care packs.
Data Testing
Snap or clone data to test the performance of a software application on 'offline' production data
Snap or clone data to test how a software patch or enhancement will function on 'offline; production
dat0061
P2000 G3 Snapshot and Clone :
G3 controllers/models come STANDARD with 64 snapshots and Volume Copy software
512 Snapshot option is ONLY available and supported with the G3, not the prior generation MSA2000
models
HP P2000 Array System Snapshot 512 Software LTU TA806A
HP P2000 Array System Snapshot 512 Software E-LTU TA806AAE
MSA2000 and MSA2000 G2 Snapshot and Volume Copy (clone) software:
Snapshot and Volume Copy software is optional on models other than the P2000 G3.
The following skus are designated for use by the MSA2000 G2 models. They are neither necessary nor
available for the P2000 G3 FC.
HP 2000 Modular Smart Array Volume Copy Software LTU T5514A
HP MSA Recovery Manager Software
Overview MSA Recovery Manager (RM) intelligently creates and manages application specific snapshots that
can be used to quickly restore application instances or databases. This optional software delivers a
standalone solution to augment your existing backup software strategy. It provides seamless
integration with HP P2000 G3 storage hardware.
Recovery Manager currently supports Microsoft Exchange and Microsoft SQL. Integrated with HP and
3rd party back up applications, RM provides reliable data recovery. Recovery Manager is integrated
with Microsoft Volume Shadow Copy Service (VSS) to make non-disruptive point-in-time copies of
Microsoft Exchange and Microsoft SQL databases for constant data protection. RM eases costs and
administration by providing rapid, affordable online recovery of Microsoft® SQL Server databases
from multiple, highly granular point-in-time snapshots. Quickly recover a database to a known point
in time, speeding up a variety of operations including rapid recovery of the production SQL server.
For more information please visit www.hp.com/go/recoverymanager
What's New Support for Microsoft Exchange and Microsoft SQL.
Integration with HP and 3rd party backup tool allowing backup to tape and/or disk.
Instant Recovery designed to respond to your needs for 24x7 application availability.
Support on multiple Windows platforms.
Models HP MSA Recovery Manager Software LTU TC399A
HP MSA Recovery Manager Software E-LTU TC399AAE
Licensing HP Recovery Manager Software is licensed per single array. One license is
required for each array that contains data, specific to applications being
QuickSpecs
HP MSA P2000 G3 Modular Smart Array Systems
Hardware
DA - 13551 North America — Version 36 — December 9, 2013 Page 20
