HP ProLiant StorageWorks NAS 1500s User manual

Installation
Guide
hp StorageWorks
NAS 1500s
Product Version: 1
First Edition (July 2004)
Part Number: 372018-001
This installation guide provides information about deploying the
HP StorageWorks NAS 1500s.

© Copyright 2004 Hewlett-Packard Development Company, L.P.
Hewlett-Packard Company makes no warranty of any kind with regard to this material,
including, but not limited to, the implied warranties of merchantability and fitness for a
particular purpose. Hewlett-Packard shall not be liable for errors contained herein or for
incidental or consequential damages in connection with the furnishing, performance, or
use of this material.
This document contains proprietary information, which is protected by copyright. No
part of this document may be photocopied, reproduced, or translated into another
language without the prior written consent of Hewlett-Packard. The information
contained in this document is subject to change without notice. The only warranties for
HP products and services are set forth in the express warranty statements
accompanying such products and services. Nothing herein should be construed as
constituting an additional warranty. HP shall not be liable for technical or editorial
errors or omissions contained herein.
Intel® and Celeron® are U.S. registered trademarks of Intel Corporation.
Microsoft®, MS Windows®, Windows®, and Windows NT® are U.S. registered
trademarks of Microsoft Corporation.
UNIX® is a registered trademark of The Open Group.
Hewlett-Packard Company shall not be liable for technical or editorial errors or
omissions contained herein. The information is provided “as is” without warranty of any
kind and is subject to change without notice. The warranties for Hewlett-Packard
Company products are set forth in the express limited warranty statements for such
products. Nothing herein should be construed as constituting an additional warranty.
Printed in the U.S.A.
NAS 1500s Installation Guide
First Edition (July 2004)
Part Number: 372018-001

Contents
3NAS 1500s Installation Guide
Contents
About this Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Intended audience. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Prerequisites . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Related documentation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
Conventions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
Document conventions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
Text symbols. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
Equipment symbols . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
Rack stability. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
Getting help. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
HP technical support. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
HP storage web site . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
HP authorized reseller. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
1 Product Overview. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
Configuration options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
Product definition and information . . . . . . . . . . . . . . . . . . . . . . . . . .14
Server hardware features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
Software features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
Managing the NAS 1500s. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
Product redundancy . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
Dependencies and requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
Storage requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
IP networking and setup requirements . . . . . . . . . . . . . . . . . . . .18
Deploying the NAS 1500s on the network . . . . . . . . . . . . . . . . . . . .18
Setup and configuration overview. . . . . . . . . . . . . . . . . . . . . . . . . . .21
Configuring the NAS 1500s . . . . . . . . . . . . . . . . . . . . . . . . . . . .21

4 NAS 1500s Installation GuideNAS 1500s Installation Guide
Storage management overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22
Storage management elements . . . . . . . . . . . . . . . . . . . . . . . . . .22
Physical storage elements . . . . . . . . . . . . . . . . . . . . . . . . . .23
Logical storage elements . . . . . . . . . . . . . . . . . . . . . . . . . . .24
File system elements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24
File-sharing elements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24
2 Configuration Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25
Preinitialization . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25
Collect information for configuration . . . . . . . . . . . . . . . . . . . . . . . .26
Configuration information . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26
WebUI configuration. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27
RapidLaunch method . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27
Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27
Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .28
Remote browser method (using hostname) . . . . . . . . . . . . . . . .31
Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .31
Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .32
Direct attach method. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .33
Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .33
Rapid Startup Wizard configuration. . . . . . . . . . . . . . . . . . . . . .34
Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .34
Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .35
Disk partitioning, RAID configuration, and failover . . . . . . . . .36
Creating file shares . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .39
Basic setup complete. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .40
Completing the system configuration. . . . . . . . . . . . . . . . . . . . .40
Replacing a failed hard drive . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .41
Detecting a hard drive failure . . . . . . . . . . . . . . . . . . . . . . . . . . .41

5NAS 1500s Installation Guide
A Regulatory Compliance Notices. . . . . . . . . . . . . . . . . . . . . . .43
Federal Communications Commission Notice . . . . . . . . . . . . . . . . .43
Class A equipment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .44
Class B equipment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .44
Modifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .45
Cables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .45
Declaration of conformity for products marked with the FCC logo
- United States only . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .45
Canadian Notice (Avis Canadien). . . . . . . . . . . . . . . . . . . . . . . . . . .46
Class A equipment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .46
Class B equipment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .46
European Union Notice. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .46
BSMI Notice . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .47
Japanese Notice. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .47
B Electrostatic Discharge . . . . . . . . . . . . . . . . . . . . . . . . . . . . .49
Grounding methods . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .50
Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .51

6 NAS 1500s Installation GuideNAS 1500s Installation Guide

About This
Guide
7NAS 1500s Installation Guide
About this Guide
About this Guide
This installation guide provides information to help you deploy
the HP StorageWorks NAS 1500s.
“About This Guide” topics include:
■Overview, page 7
■Conventions, page 8
■Rack stability, page 11
■Getting help, page 11
Overview
This section covers the following topics:
■Intended audience
■Prerequisites
■Related documentation
Intended audience
This book is intended for use by technical professionals who are
experienced with the following:
■Microsoft®administrative procedures
■File-sharing protocols
Prerequisites
Before you set up the NAS server, HP recommends that you
obtain supplemental documentation relative to the items listed
above in the section titled “Intended Audience.”

8 NAS 1500s Installation Guide
Related documentation
In addition to this guide, HP provides corresponding information:
■ HP StorageWorks NAS 1500s Administration Guide
■ HP StorageWorks NAS 1500s Rack Installation Instructions
■ HP StorageWorks NAS 1500s Release Notes
Conventions
Conventions consist of the following:
■Document conventions
■Text symbols
■Equipment symbols
Document conventions
The document conventions included in Table 1 apply in most
cases.
Table 1: Document Conventions
Element Convention
Cross-reference links Figure 1
Key and field names, menu items,
buttons, and dialog box titles Bold
File names, application names, and
text emphasis
Italics
User input, command and directory
names, and system responses
(output and messages)
Monospace font
COMMAND NAMES are uppercase
monospace font unless they are case
sensitive
Variables <monospace, italic font>
Web site addresses Underlined sans serif font text:
http://www.hp.com

9NAS 1500s Installation Guide
Text symbols
The following symbols may be found in the text of this guide.
They have the following meanings:
WARNING: Text set off in this manner indicates that failure
to follow directions in the warning could result in bodily harm
or death.
Caution: Text set off in this manner indicates that failure to
follow directions could result in damage to equipment or
data.
Note: Text set off in this manner presents commentary, sidelights, or
interesting points of information.
Equipment symbols
The following equipment symbols may be found on hardware for
which this guide pertains. They have the following meanings:
Any enclosed surface or area of the equipment
marked with these symbols indicates the presence of
electrical shock hazards. Enclosed area contains no
operator serviceable parts.
WARNING: To reduce the risk of personal injury from
electrical shock hazards, do not open this enclosure.

10 NAS 1500s Installation Guide
Any RJ-45 receptacle marked with these symbols
indicates a network interface connection.
WARNING: To reduce the risk of electrical shock, fire,
or damage to the equipment, do not plug telephone
or telecommunications connectors into this receptacle.
Any surface or area of the equipment marked with
these symbols indicates the presence of a hot surface
or hot component. Contact with this surface could
result in injury.
WARNING: To reduce the risk of personal injury from
a hot component, allow the surface to cool before
touching.
Power supplies or systems marked with these
symbols indicate the presence of multiple
sources of power.
WARNING: To reduce the risk of personal
injury from electrical shock, remove all power
cords to completely disconnect power from the
power supplies and systems.
Any product or assembly marked with these symbols
indicates that the component exceeds the
recommended weight for one individual to handle
safely.
WARNING: To reduce the risk of personal injury or
damage to the equipment, observe local occupational
health and safety requirements and guidelines for
manually handling material.

11NAS 1500s Installation Guide
Rack stability
Rack stability protects personnel and equipment.
WARNING: To reduce the risk of personal injury or damage
to the equipment, be sure that:
■The leveling jacks are extended to the floor.
■The full weight of the rack rests on the leveling jacks.
■In single rack installations, the stabilizing feet are
attached to the rack.
■In multiple rack installations, the racks are coupled.
■Only one rack component is extended at any time. A rack
may become unstable if more than one rack component
is extended for any reason.
Getting help
If you still have a question after reading this guide, contact an HP
authorized service provider or access our web site:
http://www.hp.com .

12 NAS 1500s Installation Guide
HP technical support
Telephone numbers for worldwide technical support are listed on
the following HP web site:
http://www.hp.com/support/ . From
this web site, select the country of origin.
Note: For continuous quality improvement, calls may be recorded or
monitored.
Be sure to have the following information available before
calling:
■Technical support registration number (if applicable)
■Product serial numbers
■Product model names and numbers
■Applicable error messages
■Operating system type and revision level
■Detailed, specific questions
HP storage web site
The HP web site has the latest information on this product, as
well as the latest drivers. Access storage at:
http://www.hp.com/
country/us/eng/prodserv/storage.html . From this web site, select
the appropriate product or solution.
HP authorized reseller
For the name of your nearest HP authorized reseller:
■In the United States, call 1-800-345-1518
■In Canada, call 1-800-263-5868
■Elsewhere, see the HP web site for locations and telephone
numbers:
http://www.hp.com .

13NAS 1500s Installation Guide
1
Product Overview
This chapter describes the configuration options and setup and
configuration dependencies and requirements for the HP
StorageWorks NAS 1500s.
Configuration options
The NAS 1500s is specifically designed for file serving; it offers
optimized performance for a growing environment.
The NAS 1500s is available in three models:
■320 GB
■640 GB
■1TB

14 NAS 1500s Installation Guide
Product definition and information
The NAS 1500s is a remote office or small to medium business
class NAS solution that provides reliable performance,
manageability, and fault tolerance.
Server hardware features
The following features are included in the NAS 1500s 320 GB
server:
■Intel®Celeron ®2.8 GHz, 533 MHz FSB processor
■512-MB 200 MHz PC2100 DDR SDRAM memory
■66/64-bit PCI-X slot
■33/32-bit PCI slot
■Four 80 GB 7200 rpm SATA hot-pluggable hard drives
■Τwo embedded 10/100/1000 WOL (Wake on LAN) network
interface controllers (NICs)
■Dual SCSI port controller for tape backup
■Adaptec 2410SA SATA RAID controller (in 66/64-bit slot
only)
■USB support for DVD drive
The following features are included in the NAS 1500s 640 GB
server:
■Intel Pentium 4 2.8 GHz, 800 MHz FSB processor
■1 GB 200 MHz PC2100 DDR SDRAM memory
■66/64-bit PCI-X slot
■33/32-bit PCI slot
■Four 160 GB 7200 rpm SATA hot-pluggable hard drives
■Two embedded 10/100/1000 WOL (Wake on LAN) network
interface controllers (NICs)
■Dual SCSI port controller for tape backup
■Adaptec 2410SA SATA RAID controller (in 66/64-bit slot
only)
■USB support for DVD drive

NAS 1500s Installation Guide 15
The following features are included in the NAS 1500s 1 TB
server:
■Intel Pentium 4 3.2 GHz, 800 MHz FSB processor
■1 GB 200 MHz PC2100 DDR SDRAM memory
■66/64-bit PCI-X slot
■33/32-bit PCI slot
■Four 250 GB 7200 rpm SATA hot-pluggable hard drives
■Two embedded 10/100/1000 WOL (Wake on LAN) network
interface controllers (NICs)
■Dual SCSI port controller for tape backup
■Adaptec 2410SA SATA RAID controller (in 66/64-bit slot
only)
■USB support for DVD drive
Software features
Advanced features included and supported by the NAS 1500s
include:
■Windows®Storage Server 2003
■Microsoft Services for Macintosh
■Microsoft Services for NetWare
■Microsoft Services for NFS
■NAS Web Based User Interface (WebUI)
■Shadow Copies for shared folders (VSS)
■Storage Manager 2.0 for Server Appliances
■Optional third party supported software (not included):
— Backup software
— Management software
— Quota management
— Virus protection
For specific software product recommendations, go to the HP
web site:
http://h18000.www1.hp.com/products/storageworks/nas/support
edsoftware.html

16 NAS 1500s Installation Guide
Managing the NAS 1500s
The NAS 1500s is configured at the factory with default system
settings and with the NAS operating system installed. Refer to the
“Storage management overview” section later in this chapter for
more information.
The NAS administrator uses Windows Disk Manager (DM) to
manage the logical storage.
Figure 1: NAS 1500s device
15131

NAS 1500s Installation Guide 17
Product redundancy
The NAS 1500s is specifically designed to perform file serving
tasks for networks, using industry standard components to ensure
reliability.
Other industry standard features, such as redundant array of
independent drives (RAID) implemented in the hardware and
remote manageability further enhance the overall dependability
of the NAS 1500s.
To ensure redundancy and reliability, the hard drives installed in
the NAS 1500s are configured so that a single drive failure will
not cause data loss or system failure. The NAS 1500s is
configured with dual boot capability. When powered on, the NAS
1500s can boot using a primary OS or a secondary recovery OS.
The primary OS logical drive resides on disk 0 and is mirrored on
disk 1 while the secondary OS logical drive resides on disk 2 and
is mirrored on disk 3. If a single disk failure occurs, the system
will still function off the mirrored disk. If the primary OS
becomes corrupted and un-bootable, the secondary OS is
available for data backup prior to using the Quick Restore DVD
to restore the system to the factory default state.
The data volume is configured as a hardware RAID 5 based basic
partition across all four drives. This ensures redundancy in the
event of a drive failure. The data volume is accessible by both the
primary OS and secondary OS.
Refer to the administration guide for additional information.

18 NAS 1500s Installation Guide
Dependencies and requirements
Specific conditions must be met in order for the NAS 1500s to
operate.
Storage requirements
To protect against data loss from hard drive failure, configure
storage with fault tolerance in mind. HP recommends adhering to
RAID 5 configurations.
IP networking and setup requirements
The following are IP networking and setup requirements needed
for a NAS 1500s device:
■Windows-based PC running Microsoft Internet Explorer 5.5
(or later) on the same network segment as the NAS 1500s;
this will be used to set up and administer the NAS device.
■Additional Ethernet connection ports to client subnets
(depending on network options ordered).
Deploying the NAS 1500s on the network
The default shipping configuration contains two 10/100/1000
integrated network interface controller (NIC) ports for client data
access. These data ports also allow access to the WebUI that
accompanies the product. Most management and administrative
procedures can be accomplished via the WebUI.

NAS 1500s Installation Guide 19
Figure 2: Rear panel connectors
Table 2: Rear Panel Connectors
Item Description
1Power connector
2Mouse connector (PS/2) (green)
3Keyboard connector (PS/2) (purple)
4Serial connector (teal)
5Video connector (blue)
6RJ-45 connector for NIC 1 (Eth0)
7HP SCSI Ultra 160 Dual Port connector
8HP SCSI Ultra 160 Dual Port connector
9Adaptec 2410SA HW RAID 4 Port SATA controller
(internal)
-RJ-45 connector for NIC 1 (Eth1)
;UID light and button
wUSB Connector
=USB Connector
15130
1 2 3 4 5 6 7
910111213
8

20 NAS 1500s Installation Guide
Figure 3: Front panel LEDs and buttons
Table 3: Front Panel LEDs and buttons
Item Description Color
1Reserved n/a
2Hard drive status/activity Green
3Power button n/a
4UID button n/a
5Power LED Green
6UID LED Blue
7NIC1 activity LED Green
8NIC2 activity LED Green
15155
1 3 4 6 8
2
1 2 1 2 1 2
5 7
UID
UID
UID
UID
