Release Notes
hp StorageWorks
SAN Director 2/128
Fabric OS 4.2.x
Second Edition (April 2004)
Part Number: AV–RVUUB–TE
This document contains last-minute and supplemental information about Fabric OS version
4.2.x firmware for the HP StorageWorks SAN Director 2/128. In the event of conflicting
information between these Release Notes and other documents in this product release, the
Release Notes take precedence.
For the latest version of these Release Notes and other Fabric OS v4.2.x documentation, access
the HP Storage web site at:
http://www.hp.com/country/us/eng/prodserv/storage.html .

2 SAN Director 2/128 Fabric OS 4.2.x Release Notes
© Copyright 2004 Hewlett-Packard Development Company, L.P.
Hewlett-Packard Company makes no warranty of any kind with regard to this material, including, but not limited to,
the implied warranties of merchantability and fitness for a particular purpose. Hewlett-Packard shall not be liable for
errors contained herein or for incidental or consequential damages in connection with the furnishing, performance,
or use of this material.
This document contains proprietary information, which is protected by copyright. No part of this document may be
photocopied, reproduced, or translated into another language without the prior written consent of Hewlett-Packard.
The information contained in this document is subject to change without notice. The only warranties for HP products
and services are set forth in the express warranty statements accompanying such products and services. Nothing
herein should be construed as constituting an additional warranty. HP shall not be liable for technical or editorial
errors or omissions contained herein.
Windows® is a U.S. registered trademark of Microsoft Corporation.
UNIX® is a registered trademark of The Open Group.
JavaTM is a US trademark of Sun Microsystems, Inc.
Linux is a U.S. registered trademark of Linus Torvalds.
Hewlett-Packard Company shall not be liable for technical or editorial errors or omissions contained herein. The
information is provided “as is,” without warranty of any kind, and is subject to change without notice. The warranties
for Hewlett-Packard Company products are set forth in the express limited warranty statements for such products.
Nothing herein should be construed as constituting an additional warranty.
SAN Director 2/128
Fabric OS 4.2.x Release Notes
Second Edition (April 2004)
Part Number: AV–RVUUB–TE

About This Document
3SAN Director 2/128 Fabric OS 4.2.x Release Notes
About This Document
This section identifies the audience of these Release Notes and provides a
high-level description of the information it contains.
Release Notes Information
These Release Notes cover the following major topics:
■Overview, page 3
■Documentation, page 4
■Standards Compliance, page 5
■Important Notes, page 6
■Commands Modified in v4.2.x, page 20
■Documentation Updates, page 20
■Issues and Workarounds, page 22
Audience
These Release Notes are intended for systems administrators and technicians who
are responsible for installing, operating, and maintaining Fabric OS version 4.2.x.
Overview
HP Fabric OS 4.2.x provides the following enhancements for the
SAN Director 2/128:
■Reduced fabric configuration downtime. Extended Edge PID for mixed
fabrics eliminates host reboot for hosts that statically bind PIDs.
■Improved fabric diagnostics:
—Thepathinfo command displays path information between any two
ports of a fabric.
— The diagnostics monitor compact flash utilization and clean the file
systems during periods of high utilization.
—Thesupportshow command has improved functionality.
— Hardware watchdog failures capture a kernel trace dump prior to reset.

Documentation
4 SAN Director 2/128 Fabric OS 4.2.x Release Notes
Improvements
The following improvements have been made to the Fabric OS software since the
last HP 4.x release:
■Secure Telnet may now be connected with two LAN cards.
■Improvements have been made to the reboot code.
■Problems that caused compaqt flash full have been resolved.
■We have increased the number of HBAs that can be displayed by Web Tools.
■We have improved the reliability of firmware download on an active fabric.
■A firmwaredownload is now successful to a single CP SAN Director
2/128 chassis through Fabric Manager and Web Tools.
■Web Tools events now use adjusted timezone time, rather than coordinated
universal time (UTC).
Supported Switches
Fabric OS v4.2.x supports the HP StorageWorks SAN Switch 2/8V, 2/16N, 2/16V,
2/32, Core Switch 2/64, and SAN Director 2/128.
Technical Support
Contact Hewlett-Packard support for hardware, firmware, and software support,
including product repairs and part ordering. To assist your support representative
and to expedite your call, have the following information available when you call.
■Technical support contact number, if available
■Switch model
■Switch operating system version
■Error messages received
■Output from supportshow command
■Detailed problem description and specific questions
■Description of any troubleshooting steps already performed and results
Documentation
This section discusses documentation associated with the Fabric OS 4.2.x.

Standards Compliance
5SAN Director 2/128 Fabric OS 4.2.x Release Notes
Other Fabric OS Documentation
Additional documentation, including white papers and best practices documents,
is available at the HP web site:
http://welcome.hp.com/country/us/eng/prodserv/storage.html .
Note: HP has made every effort to provide you with the most up-to-date Web retrieval
procedures available at time of print. Note, however, that Web page links and pointers
are subject to change.
To access the technical documentation:
1. Locate the networked storage section of the Web page.
2. Under networked storage, locate the by type subsection.
3. Click SAN infrastructure. The SAN infrastructure page displays.
4. Locate the Fibre Channel Switches section.
5. Locate the B-Series Fabric subsection.
6. Click the name of the switch for which you are seeking information. The
switch overview page displays.
7. Locate the product information section.
8. Click technical documents.
9. Select the applicable documents.
For information about Fibre Channel standards, visit the Fibre Channel Industry
Association web site, located at
http://www.fibrechannel.org .
Standards Compliance
HP products conform to these standards in a manner consistent with accepted
engineering practices and procedures. In certain cases, HP may add proprietary
supplemental functions to those specified in the standards. We verify conformance
with Fibre Channel Standards by subjecting our switches to SANmark
Conformance Tests developed by the Fibre Channel Industry Association. Our
switches have earned the SANmark logo indicating such conformance. SANmark
is a limited testing program and does not test all standards or all aspects of
standards.
HP Fabric OS 4.2.x conforms to the following Fibre Channel Standards:

Important Notes
6 SAN Director 2/128 Fabric OS 4.2.x Release Notes
■FC-AL ANSI X3.272: 1996
■FC-AL-2 NCIT S 332: 1999
■FC-FLA NCIT S TR-20: 1998
■FC-GS-2 NCIT S 348-2000 Rev 7.01
■FC-FG ANSI X3.289: 1996
■FC-PH ANSI X3.230: 1994
■FC-PH-2 ANSI X3.297 X3.297: 1997
■FC-PH-3 ANSI X3.303: 1998
■FC-PLDA NCIT S TR-19: 1998
■FC-SW-2 Rev 5.3
■FC-VI Rev 1.61
■FC-MI Rev 1.92
■FC-BB Rev 4.7
■FC-FS Rev 1.7
■FC-BB-2 Rev 5.3
■IPFC RFC 2625
■FCP ANSI X3.269: 1996
■FCP-2 Rev 7
Important Notes
This section provides information you should be aware of when running Fabric
OS 4.2.x.
OS Requirements
HP recommends using the latest software release versions to get the greatest
benefit from the SAN.

Important Notes
7SAN Director 2/128 Fabric OS 4.2.x Release Notes
Mixed Fabric Environment with Different Switch Platforms
Fabric OS v2.6.2, v3.1.2, and v4.2.x introduced a new switch PID format:
Extended Edge PID (Format 2). Extended Edge PID is useful if you introduce a
Fabric OS v4.2.x switch into a fabric consisting solely of Fabric OS v2.x/v3.x
switches. Before adding a Fabric OS v4.2.x switch to such a fabric, refer to the
HP StorageWorks Fabric OS 4.2.x Procedures User Guide for information on the
Extended Edge PID format.
Note: Note that in order to use the Extended Edge PID format, Fabric OS v2.6.2,
v3.1.2, and v4.2.x must be deployed together, as applicable, to the switches.
If Extended Edge PID is set (before a downgrade from the current Fabric OS
release to an earlier Fabric OS release that does not support the Extended PID
format), PID needs to be set back to a supported format, such as Core PID (format
1) or native PID (format 0).
Advanced Web Tool Updates
When using a mixed fabric—that is, a fabric that contains v4.x, v3.x, and v2.x
switches—HP recommends that you use the most advanced switches to control
the fabric. For example, use the v4.x switches as the primary Fibre Channel
Switch (FCS), as the location to perform zoning tasks, and as the time server. HP
also recommends that you use the most recently released firmware to control the
fabric.
If you use Advanced Web Tools to change the switch name, the HP StorageWorks
SAN Director 2/128 Telnet console prompt does not update to the new name until
a new Telnet window is opened.
If a dialog box is displayed from the Switch Admin window of Advanced Web
Tools and the user selects another dialog box from Advanced Web Tools, a
window display error occurs.
Workaround: HP recommends JavaTM 1.4.1_03.
Two-Domain and Four-Domain Fabric Licensing
If your fabric includes a switch with a license for a limited number of switches in
the fabric and the fabric exceeds the limit, Advanced Web Tools allows a 45-day
grace period during which you can still monitor the switch. Advanced Web Tools
periodically displays warning messages.

Important Notes
8 SAN Director 2/128 Fabric OS 4.2.x Release Notes
These messages warn you that your fabric size exceeds the supported switch
configuration limit and tells you how long you have before Advanced Web Tools
will be disabled. After the 45-day grace period, you will no longer be able to
launch Advanced Web Tools from the switch if it still exceeds the limit.
Note: Two domain and our domain fabric licensing is applicable only to 2 Gb/sec
switches.
Browser Window Response After Failover
A browser window might stop responding after an HA failover immediately after
a zoning configuration is enabled or disabled. It is likely that the web daemon was
terminated by the HA failover before the HTTP request was returned.
Workaround: If the HA module does not respond, close the window and
relaunch the module. If the module is locked, shut down and relaunch the Web
Tools application.
Switch View Display Issue
If you frequently enable or disable a switch or perform a power cycle, the Switch
View may not display properly. Launching other Web Tools components might
then cause a browser crash.
Workaround: Upgrade your Java Plug-in to 1.4.1_06 or later, if you are
running Windows XP.
Installing Mozilla 1.4 on Solaris 8 and Solaris 9
For instructions to install Mozilla 1.4 on Solaris 8 and Solaris 9, go to the web
site:
http://ftp.mozilla.org/pub/mozilla.org/mozilla/releases/mozilla1.4/mozilla-sparc-sun
-solaris2.8_1.4.readme
Mozilla Browser Support for Switch Admin Module
The Mozilla browser does not support the Switch Admin module properly in
Fabric OS v2.6.x. In Fabric OS v2.6.2, a warning message is displayed. No
warning message is displayed in other 2.6.x versions.
Workaround: Use Netscape 4.7.7 or later.

Important Notes
9SAN Director 2/128 Fabric OS 4.2.x Release Notes
Browser, OS, and Java Plug-in Support
Advanced Web Tools browser, operating system, and Java Plug-in support is
updated for Fabric OS v4.2.x. Table 1 identifies the supported browsers, operating
systems, and Java Plug-ins for this release. Go to the
hp.com web site for the latest
list of supported operating systems.
Table 1: Browsers, OSs, and Java Plug-ins
Operating System Browser Java Plug-in
HP-UX 11.00 Mozilla 1.4 or later 1.4.2_00 or later (up to but not including 1.5)
HP-UX 11.11
(PA 32-bit & PA 64-bit) Mozilla 1.4 or later 1.4.2_00 or later (up to but not including 1.5)
HP-UX 11.23
(IA 64-Bit) Mozilla 1.4 or later 1.4.2_00 or later (up to but not including 1.5)
HP Tru64 UNIX® 5.1B Mozilla 1.4 1.4.1_02
HP Tru64 UNIX 5.1A Mozilla 1.4 1.4.1_02
HP OpenVMS 7.3-1
(64-bit) Secure Web Browser (SWB 1.4) 1.4.1_02
HP OpenVMS 7.3-2
(64-bit) Secure Web Browser (SWB 1.4) 1.4.1_02
HP Open VMS 7.3-x
(Itanium) Secure Web Browser (SWB 1.4) 1.4.1_02
AIX 5.1 Mozilla 1.4 1.4.1_01
AIX 5.2 Mozilla 1.4 1.4.1_01
AIX 5.3 Mozilla 1.4 1.4.1_01
Red Hat Linux® 7.3 Mozilla 1.4 or later 1.4.2_02 or later (up to but not including 1.5)
Red Hat Linux 8.0 Mozilla 1.4 or later 1.4.2_02 or later (up to but not including 1.5)
Red Hat Enterprise
Linux AS 2.1 (IA32 &
IA64)
Mozilla 1.4 or later 1.4.2_02 or later (up to but not including 1.5)
Red Hat Enterprise
Linux AS 3.0 (IA32 &
IA64)
Mozilla 1.4 or later 1.4.2_02 or later (up to but not including 1.5)
Red Flag Linux (32-bit) Mozilla 1.4 or later 1.4.2_02 or later (up to but not including 1.5)
United Linux 1.0
SUSE 8 (IA32) Mozilla 1.4 or later 1.4.2_02 or later (up to but not including 1.5)

Important Notes
10 SAN Director 2/128 Fabric OS 4.2.x Release Notes
The additional supported browsers, operating systems, and Java Plug-ins
introduce limitations when using mixed OS versions in Advanced Web Tools
v4.2.x. These limitations are described in Table 2.
United Linux 1.0
SUSE 8 (IA64) Mozilla 1.4 or later 1.4.2_02 or later (up to but not including 1.5)
United Linux 2.0 Mozilla 1.4 or later 1.4.2_02 or later (up to but not including 1.5)
Solaris 2.8, 2.9 Mozilla 1.2.1 (recom-
mended)
Netscape 7.0
Netscape
Communicator 4.78
1.4.2
Solaris 7, 8, 9, 10 Mozilla 1.2.1 (recom-
mended)
Netscape 7.0
Netscape
Communicator 4.78
1.4.2
Windows 2000 IE 6.0 SP1 1.3.1_04 or 1.4.1_02 (recommended)
Windows 2003 IE 6.0 SP1 1.3.1_04 or 1.4.1_02 (recommended)
Windows XP IE 6.0 SP1 1.3.1_04 or 1.4.1_02 (recommended)
Table 1: Browsers, OSs, and Java Plug-ins (Continued)
Operating System Browser Java Plug-in

Important Notes
11SAN Director 2/128 Fabric OS 4.2.x Release Notes
Table 2: Limitations Using Mixed OS Versions
Launch Switch Environment Issue and Workaround
Firmware: version earlier than Fabric OS
v2.6.2, v3.1.2, or v4.2.x
Operating System: any supported
operating system (with supported
browser)
Browser: any supported browser (on a
supported operating system)
When trying to access a switch running Fabric OS
v2.6.2, 3.1.2, or 4.2.x from the launch switch, Switch
Explorer displays a null pointer exception, and the
SwitchInfo applet does not display. Switch
Explorer does not work properly with switches
running the latest firmware.
Workaround: Use a launch switch running Fabric OS
v2.6.2, v3.1.2, or v4.2.x or later to access the switch.
Firmware: version earlier than Fabric OS
v2.6.2, v3.1.2, or v4.2.x
Operating System: any supported
operating system (with supported
browser)
Browser: any supported browser (on a
supported operating system)
When trying to perform end-to-end monitoring
(Performance Monitor) on a SAN Director 2/128,
SAN Switch 2/8V is displayed as a 16-port switch.
Workaround: Use a launch switch running Fabric OS
v4.2.x or later to perform end-to-end monitoring on
the switch.
Firmware: version prior to Fabric OS
v2.6.2, 3.1.2, or 4.2.x
Operating System: any supported
operating system (with supported
browser)
Browser: any supported browser (on a
supported operating system)
When trying to perform zoning on a SAN Director
2/128, the SAN Director 2/128 is displayed as a
16-port switch.
Workaround: If you are running Secure Fabric OS,
select a switch running Fabric OS v2.6.2, v3.1.2, or
v4.2.x or later as the primary FCS switch. If you are
not running Secure Fabric OS, use a launch switch
running Fabric OS v2.6.2, v3.1.2, or v4.2.x or later
to perform zoning on the switch.

Important Notes
12 SAN Director 2/128 Fabric OS 4.2.x Release Notes
Other Notes
Table 3, Table 4, and Table 5 list important information for Fabric OS v4.2.x.
Firmware: Fabric OS v2.6.2, v3.1.2, or
v4.2.x
Operating System: any supported
operating system (with supported
browser)
Browser: any supported browser (on a
supported operating system)
The Name Server table does not display properly for
a switch running firmware versions earlier than Fabric
OS v2.6.2, v3.1.2, or v4.2.x.
Workaround: If secure mode is enabled, select a
switch running Fabric OS v2.6.2, v3.1.2, or v4.2.x or
later as the primary FCS switch. If secure mode is not
enabled, use a launch switch running Fabric OS
v2.6.2, v3.1.2, or v4.2.x or later to access the Name
Server table on the switch.
Firmware: version earlier than Fabric OS
v2.6.2, v3.1.2, or v4.2.x
Operating System: Solaris
Browser: Netscape
Any switches running Fabric OS v2.6.2, v3.1.2, or
v4.2.x or later are not supported through Netscape.
Workaround: Netscape is not a supported browser
for switches running Fabric OS v2.6.2, v3.1.2, or
v4.2.x or later. Use Mozilla browser to manage all of
your switches from a Solaris operating system. See
Table 1 supported browsers.
Firmware: version earlier than Fabric OS
v2.6.1, v3.0.x, or v4.0.x
Operating System: Windows
Browser: Internet Explorer
When you are running Fabric View, the browser
crashes.
Workaround: Use a launch switch that runs Fabric OS
versions v2.6.1, v3.0.x, or v4.0.x or later so that you
can use Switch Explorer (instead of Fabric View).
Table 2: Limitations Using Mixed OS Versions (Continued)
Launch Switch Environment Issue and Workaround

Important Notes
13SAN Director 2/128 Fabric OS 4.2.x Release Notes
Table 3: SAN Director 2/128 Information
SAN Director 2/128 Description
CP blade The SAN Director 2/128 CP contains electronics that provide internal
routing bandwidth, and are always active on both CPs. Removal of a CP
might affect user performance and therefore should not occur until a
replacement CP is ready to be installed.
Power supplies A fully configured SAN Director 2/128 with eight port cards and two CPs is
capable of running on a single power supply. Therefore, two power
supplies provide 2N redundancy. To maintain redundancy of AC input, one
power supply must be in an even-numbered slot and one in an
odd-numbered slot. The default configuration is for the power supplies to be
in slots 1 and 2.
Card seating Follow the procedure below to ensure that Port Cards and Control Processor
(CP) cards are properly installed into your SAN Director 2/128:
1. Install the leading edge of the CP or Port Card into the appropriate slot
on the card cage.
2. Push the front surface of the card (SFP cage side) carrier near the center
with your hand until the top and bottom ejectors engage the upper and
lower ejector plates (do not hold onto the ejectors as you push).
3. Press down on both ejectors at the same time with equal force to seat the
blade.
4. Tighten the top thumb screw first.

Important Notes
14 SAN Director 2/128 Fabric OS 4.2.x Release Notes
Table 4: Small Form Factor Plugables
Part Numbers Description*
Max
Distance at
2 GB
DS-DMSHT-AA
300834-B21
221470-B21
292003-001
A6515A
500 m 2 Gb SFF-SW 300 m
DS-DMLNG-AA
300835-B21
292004-001
A6516A
10 km LD Opti Tran ALL 10 km
DS-DMEXT-AA
300836-B21
292005-001
35 km ExtRch Opti K ALL 35 km
* SFF = small form factor.
Table 5: Fabric OS Area Information
Fabric OS Area Description
Ethernet port IP
addresses When a SAN Director 2/128 fails over to its standby CP for any reason, the IP addresses for the two logical switches move to that CP blade's
Ethernet port. This might cause informational ARP address reassignment
messages to appear on other switches in the fabric. This is normal behavior,
because the association between the IP addresses and MAC addresses has
changed.
Extended links For 50-km extended links, you have a choice of configuring a port as an LD
port or an L1 port. LD ports maintain full link speeds of 103 Mbit/sec. L1
ports have link speeds of 99 Mbit/sec; you can configure all four ports of a
quad as L1 ports, but you can configure only one port in a quad as an LD
port.
Fabric configuration During fabric configuration, the countdown message that used to appear on
the console is removed starting with Fabric OS v2.6.2, v3.1.2, and v4.2.x.
The fabric reconfiguration message is now captured in the error log. For
details, refer to the diagnostic messages in the
HP StorageWorks Diagnostic
and System Error Messages 4.2.x Reference Guide
.

Important Notes
15SAN Director 2/128 Fabric OS 4.2.x Release Notes
Fabric Device
Management Interface
(FDMI)
An HBA will be allowed to register even though the originating port is not
on the HBA's registered port list. This is intended behavior, included to test
error cases.
Fabric OS: CLI
commands, failover,
and port disable
Changing port configurations during a failover might cause ports to be
disabled. Reissue the command after the failover is complete to bring the
ports online.
Fabric OS: commands Under the root account, issuing Fabric OS commands in parallel through
scripts could cause the kernel task to consume excessive memory.
Workaround: When using scripts to issue Fabric OS commands, wait for
one command to finish before issuing another.
Fabric OS: switch
beaconing Switch beaconing is not preserved across a failover. If you start beaconing, a failover causes all lights to stop flashing.
Workaround: If this occurs, reissue the command to resume switch
beaconing.
Fabric OS: switch
reboot and blade
repair
Switch reboot will fail in the SAN Director 2/128 if there are faulty port
blades.
Note: Verify that all blades are in working order before performing a
switch reboot. Switch reboot is meant to be issued after all repairs are
complete. If you perform a switch reboot and find a faulty blade, remove the
blade and reboot will continue.
Workaround: Identify and remove the faulty blade, using the slotshow
command.
Fabric routing, Fabric
Manager: domain
overlap
Issuing a configdefault command followed by reboot or switch disable
or enable can cause the fabric to segment due to possible domain overlap.
Workaround: Before rebooting the fabric, ensure that all switches are
properly configured to avoid domain overlap between the logical switches.
Fabric Watch: e-mail
alert error message If an event occurs while Fabric Watch e-mail alerts are being enabled, the message ErrLog: Error Level=3 [(null)] is captured to the
system error log. This message is from SMTP and can be ignored.
Firmware download During a firmware download, rebooting or power cycling the CPs could
corrupt the compact flash.
CAUTION: Do not attempt to power off the CP board during firmware
download, to avoid high risk of corrupting your flash.
Table 5: Fabric OS Area Information (Continued)
Fabric OS Area Description

Important Notes
16 SAN Director 2/128 Fabric OS 4.2.x Release Notes
Firmware download Fabric OS v4.1.x and v4.2.x nondisruptive firmware download allows for
firmware downgrades and upgrades; however, you might see warning
messages such as the following:
0x239 (fabos): Switch: 0, Info PDM-NOTFOUND, 4, File not
found
(/etc/fabos/mii.0.cfg)
These warnings can be ignored.
HA switch reboot
failure When a switch reboot or a failover occurs before POST is complete, the HA resynchronization is disrupted. HA does not resynchronize until POST
completes.
CAUTION: Allow POST to complete before performing a switch reboot or
failover, to avoid disruptive failover.
Invalid Gateway IP
address error message The user sees the following message on the console during startup when the Ethernet IP and Gateway IP addresses are set to the defaults:
SIOCADDRT: Invalid argument.....ip.c:311:Invalid gateway
IP address 0.0.0.0
This is a display issue only and does not affect the functionality of the
switch.
IP addresses CAUTION: Do not set a switch or CP IP address for the Ethernet interface to
0.0.0.0.
License removal When a user removes a license from the switch, the feature is not disabled
until the switch is rebooted or a switch disable or enable is performed.
LTO 2 tape drive
support When using the LTO 2 tape drive, the user must enter the following command on both Fabric OS v3.x and v4.x:
switch> portcfggport port# where drive is plugged in
This allows the tape drive to function in point-to-point mode rather than in
loop mode.
OS hardware Bringing up port blades during a failover could cause the port cards to
come up in a disabled state. This is a rare occurrence; when it happens,
bring up the port blade again, after the failover on the SAN Director
2/128.
rsh and rlogin The programs rsh and rlogin are not supported in this release. If you try
to use an rsh or rlogin client, Fabric OS rejects the login attempt;
however, because most rsh and rlogin clients continue to retry the login
for several seconds before timing out, your system appears to hang.
Security: default
password length The initial login prompt for a switch accepts a maximum password length of eight characters. Any characters beyond the eighth are ignored.
Table 5: Fabric OS Area Information (Continued)
Fabric OS Area Description

Important Notes
17SAN Director 2/128 Fabric OS 4.2.x Release Notes
Security: empty
policies CAUTION: If Telnet, API, and serial port access policies are empty, the user will not be able to communicate with the switch.
Workaround: Contact your switch provider for the recovery procedure.
Security: error counter Telnet security errors that arrive in quick succession are recorded as a single
violation by the telnet error counter. For example, a login error from a host
whose IP address is 192.168.44.247 is logged as follows:
Security violation: Login failure attempt via
TELNET/SSH/RSH. IP Addr: 192.168.44.247
If another login violation occurs immediately, the message remains the
same and only the error counter is incremented.
Security: fabric
segment When two secure fabrics are continuously joined and separated while the CPU is under heavy load, the fabric segments after approximately 30
cycles.
Security: FCS list Adding switches to the FCS list does not automatically join the switches in a
secure fabric. Add the switches to the FCS list of the new switches and the
target fabric. Reset the version stamp to 0 and either reset the E_Ports or
perform a switch disable and enable for the switches to join.
Security: HTTP policy If HTTP_Policy is empty, you will not be able to log in and will receive a
Page not found error. This is expected behavior for this policy.
Security: invalid
certificate Web Tools and Fabric OS are not consistent in how they report switch certificate status. Web Tools reports a valid certificate with extra characters
appended to it as invalid, whereas Fabric OS accepts the certificate and
allows a secmodeenable command to complete successfully.
Security: PKICERT
utility, CSR syntax Before using the PKICERT utility to prepare a certificate signing request (CSR), ensure that there are no spaces in the switch names of any switches
in the fabric. The Web site that processes the CSRs and generates the digital
certificates does not accept switch names containing spaces; CSRs that do
not conform to this requirement are rejected.
Table 5: Fabric OS Area Information (Continued)
Fabric OS Area Description

Important Notes
18 SAN Director 2/128 Fabric OS 4.2.x Release Notes
Security: PKICERT
utility, installing
certificates
PKICERT v1.0.6 is the most current version of the PKICERT utility.
When running the PKICERT utility to install switch certificates in a fabric that
did not previously contain switch certificates and now includes a SAN
Director 2/128, select the option to specify that certificates are installed on
only those switches that do not currently contain certificates. SAN Director
2/128s are delivered with switch certificates preinstalled. Switches that
were originally shipped with Fabric OS v2.5, v3.0, and v4.0 and have
never installed and enabled Secure Fabric OS do not have certificates
installed.
If you need to reinstall switch certificates in a SAN Director 2/128, follow
these guidelines:
■The host running PKICERT v1.0.6 must be connected to a proxy
switch running Fabric OS v2.6.2, v3.1.2, or v4.2.
■All switches in the fabric other than the SAN Director 2/128 can
run v2.6.1, v3.1, v4.1 or newer firmware.
Security: selectelnet If you try to log in to a switch through a sectelnet client while that switch is in
the process of either booting or shutting down, you might see the message,
Random number generation failed. The message is printed by the
sectelnet client because the switch Telnet service is not running (the service
has either already been shut down (if the switch is shutting down), or is not
yet established (if the switch is booting). If the switch is booting, wait a few
seconds and try again.
Security: secure mode If an upgrade from Fabric OS v4.0 to v4.1 or v4.2 is performed, followed
by a downgrade to Fabric OS v4.0 and upgrade back to Fabric OS v4.1 or
v4.2, the switch password state is reset and prompts the user for new secure
mode passwords.
Security: secure mode,
passwd Telnet CAUTION: Using the passwd Telnet command in secure mode to change the password results in all sessions using that password being logged out,
including the session that changed the password.
This is expected behavior. The session terminates if you change the
password in secure mode.
Security: SLAP counter The SLAP counter is designed to work when all the switches in the fabric are
in secure mode. All the switches in the fabric must be in secure mode for
accurate SLAP statistics.
Security: SSH login To properly connect SSH login, wait for secure mode to complete before
rebooting or performing HA failover on the SAN Director 2/128. If secure
mode is enabled and a reboot occurs before secure mode completes, SSH
login does not connect and goes to the wrong MAC address, because the
active CP changes after an HA failover.
Table 5: Fabric OS Area Information (Continued)
Fabric OS Area Description

Important Notes
19SAN Director 2/128 Fabric OS 4.2.x Release Notes
Single domain The SAN Director 2/128 can be configured only as a single domain, as
opposed to two logical domains in the Core Switch 2/64. In other words,
all port blades and slots are a part of that single switch.
WWN card FRU
repair If an HA failover or power cycle occurs during a FRU replacement on the WWN card, the SAN Director 2/128 becomes nonoperational.
CAUTION: When performing a FRU replacement on a WWN card,
complete the FRU procedure before attempting an HA failover or power
cycling the chassis.
Zoning: license To use zoning in a non-RCS (reliable commit service) mode fabric (that is, in
a fabric containing switches with firmware versions other than v2.6.x, v3.1,
and v4.1), HP recommends that all appropriate zoning licenses be installed
on all the switches in the fabric before attempting to bring a switch in to the
fabric.
If the zoning license is to be removed, the user must make sure it is
reinstalled properly on the affected switch before attempting the
cfgenable zoning operation.
Failure to follow these steps can cause inconsistency of zoning configuration
on the affected switches if a zoning operation is attempted from a remote
switch in the fabric. On the affected switches, an error message appears on
the console or Telnet session (or by issuing the errShow or errDump
command), indicating that the zoning license is missing.
Zoning: domain ID Domain 0 in a zoning configuration file is invalid but was not previously
enforced.
Workaround: Prior to upgrading a switch to Fabric OS v4.2.x, ensure that
the fabric's zoning configuration does not contain domain ID 0, which is
used for zoning. This is specific only to 4.x switches.
Table 5: Fabric OS Area Information (Continued)
Fabric OS Area Description

Commands Modified in v4.2.x
20 SAN Director 2/128 Fabric OS 4.2.x Release Notes
Commands Modified in v4.2.x
The portCfgLPort command now supports a mode2 option. Specify 1to
configure the L_Port as a half-duplex L_Port. Specify 0to configure the L_Port as
a full-duplex L_Port. The default value is 0.
Refer to the HP StorageWorks Fabric OS 4.2.x Command Reference Guide for
more information.
Documentation Updates
This section provides information on last-minute additions or corrections to the
documentation.
HP StorageWorks Fabric OS 4.2.x Command Reference Guide
The following commands have been modified:
■configure
■portCfgGPort
■portCfgLongDistance
■portCfgislMode
Each change is detailed in the sections that follow.
configure
Change the Domain, R_A_TOV, and E_D_TOV fields in Table 2 as follows:
portCfgLongDistance
Add a note regarding coexistence with the portCfgislMode command, as
follows:
Field Default Range
Domain 1 Varies
R_A_TOV 10000 E_D_TOV * 2 to 12000
E_D_TOV 2000 1000 to R_A_TOV / 2
