HP StorageWorks 7110 - Virtual Array User manual

HP StorageWorks
Virtual Arrays
VA 7000 Family
Edition January 2005
Part number A6183-96008
Printed in U.S.A.
User and
Service
Guide

2
Notice
© Copyright 2000-2005 Hewlett-Packard
Development Company, L.P.
Hewlett-Packard Company makes no warranty of
any kind with regard to this material, including,
but not limited to, the implied warranties of
merchantability and fitness for a particular
purpose. Hewlett-Packard shall not be liable for
errors contained herein or for incidental or
consequential damages in connection with the
furnishing, performance, or use of this material.
This document contains proprietary information,
which is protected by copyright. No part of this
document may be photocopied, reproduced, or
translated into another language without the prior
written consent of Hewlett-Packard. The
information contained in this document is subject
to change without notice.
Format Conventions
WARNING Identifies a hazard that can cause
personal injury
Caution Identifies a hazard that can cause
hardware or software damage
Note Identifies significant concepts or
operating instructions
this font - used for all text to be typed
verbatim: all commands, path names, file names,
and directory names also, text displayed on the
screen
<
this font > - used for variables used in
commands
this font - used for GUI menu options and screen
controls
Trademark Information
Red Hat is a registered trademark of Red Hat Co.
C.A. UniCenter TNG is a registered trademark of
Computer Associates International, Inc.
Microsoft, Windows NT, and Windows 2000 are
registered trademarks of Microsoft Corporation
HP, HP-UX are a registered trademarks of Hewlett-
Packard Company. CommandView, Secure
Manager, Business Copy, Auto Path are
trademarks of Hewlett-Packard Company
Adobe and Acrobat are trademarks of Adobe
Systems Inc.
Java and Java Virtual Machine are trademarks of
Sun Microsystems Inc.
NetWare is a trademark of Novell, Inc.
AIX is a registered trademark of International
Business Machines, Inc.

3
Revision History
January 2002
March 2002
April 2002
Change Page
Added new supported non-native operating systems. 16
Added Operating Tips section. 57
Clarified explanation of redundancy groups 39
Expanded the procedure for upgrading DIMMs. 135
Added procedure for reducing the amount of cache. 136
Change Page
Updated warranty information 7
Added information on new power supply model 102
Added information on new disk filler panel. 100
Added a procedure for adding a disk enclosure to a VA 7400. 132
Change Page
Added new warning LED status display for updating battery firmware. 82
Added processor model to array controller description 24
Changed part numbers of replacement array enclosure controllers. 93
Added support for DS 2405 Disk System Multiple
Added information for identifying type of disk enclosure 92
Added DS 2405 Disk System part numbers to disk enclosure
replaceable parts.
95
Added step for setting FC Loop Speed switch on DS 2405 LCCs. 127
Added note on ensuring controller firmware is HP14 or later when
adding a DS 2405 Disk System to the array.
132

4
July 2002
January 2003
September 2003
Change Page
Updated product information to include VA 7410. 13
Added VA 7410 back-end cabling. 33
Added "Data I/O Architecture" information. 52
Updated replaceable parts to include VA 7410 components 93
Updated procedure for adding a disk enclosure to include VA 7410. 132
Change Page
Updated capacity and performance tables for VA 7110. 17
Added 73 GB 15K disk module and 146 GB disk module for support
on VA 7110 and 7410.
26
Updated Data Storage Process information 38
Updated configuration drawings. 59
Added VA 7110 LED displays. 81
Added VA 7110 controller to replaceable parts. 93
Change Page
Updated VA 7110 DIMM configuration information to indicate that
512 MB is not supported.
14, 136

5
March 2004
January 2005
Change Page
Added a step to the controller installation procedure for recognizing
the new controller on HP-UX.
110
Added note regarding installing multiple disks. 132
Added information on replacing a controller in a single-controller
array.
112
Change Page
Added Japanese power cord statement. 148

6
About This Guide
This guide is intended for use by information technology (IT), service, and other personnel involved in
managing, operating, servicing, and upgrading the HP StorageWorks Virtual Array products. It is
organized into the following chapters:
Related Documents and Information
The following items contain information related to the installation, configuration, and management and
of the HP StorageWorks Virtual Array products:
—
HP StorageWorks Virtual Array 7000 Family Installation Guide - includes step-by-step instructions
for installing and configuring the hardware and software components of the HP StorageWorks
Virtual Array products.
—
HP StorageWorks Virtual Array Family Rack Installation Guide - includes step-by-step instructions
for installing the HP StorageWorks Virtual Array products into HP Rack System/E, HP System
racks, and Compaq 9000 racks.
—
HP StorageWorks CommandView SDM Installation and User Guide - describes how to install and
use the HP StorageWorks CommandView SDM software and its associated utilities to configure,
manage, and diagnose problems with the array.
Chapter 1. Product Overview Describes the features, controls, and operation of the
disk array.
Chapter 2. System Configurations Guidelines for designing array configurations for
different system requirements.
Chapter 3. Troubleshooting Instructions for isolating and solving common problems
that may occur during array operation
Chapter 4. Servicing & Upgrading Instructions for removing and replacing all field
replaceable units.
Chapter 5. Specifications & Regulatory
Statements
Product dimensions, weight, temperature and humidity
limits, shock and vibration limits, electrical and power
specifications, regulatory and safety statements, and
Declaration of Conformity.

7
Warranty Information
Standard Limited
Warranty
The HP SureStore Virtual Array Family standard warranty includes the following:
Two-year, same-day on-site warranty (parts and labor). Same-day response
equates to:
4-hour response, available normal business days (Monday-Friday) 8 am - 5 pm.
See the "Hewlett-Packard Hardware Limited Warranty" on page 8 for a complete
description of the standard warranty.
Warranty Contacts
U.S. and Canada
For hardware service and telephone support, contact:
An HP-authorized reseller or
HP Customer Support Center at 970-635-1000, 24 hours a day, 7 days a week,
including holidays
Current Support
Information
For the latest support information, visit the following web site:
http://www.hp.com/support/va7100
http://www.hp.com/support/va7400
http://www.hp.com/support/va7410
http://www.hp.com/support/va7110
Preparing for a
Support Call
If you must call for assistance, gathering the following information before placing
the call will expedite the support process:
—Product model name and number
—Product serial number
—Applicable error messages from system or diagnostics
—Operating system type and revision
—Applicable hardware driver revision levels (for example, the host
adapter driver)

8
Hewlett-Packard Hardware Limited Warranty
HP warrants to you, the end-user Customer, that HP SureStore Virtual Array Family hardware
components and supplies will be free from defects in material and workmanship under normal use after
the date of purchase for
two years . If HP or Authorized Reseller receives notice of such defects during the
warranty period, HP or Authorized Reseller will, at its option, either repair or replace products that prove
to be defective. Replacement parts may be new or equivalent in performance to new.
Should HP or Authorized Reseller be unable to repair or replace the hardware or accessory within a
reasonable amount of time, Customer's alternate remedy will be a refund of the purchase price upon
return of the HP SureStore Virtual Array Family.
Replacement Parts
Warranty
HP replacement parts assume the remaining warranty of the parts they replace.
Warranty life of a part is not extended by means of replacement.
Items Not Covered Your HP SureStore Virtual Array Family warranty does not cover the following:
—Products purchased from anyone other than HP or an authorized
HP reseller
—Non-HP products installed by unauthorized entities
—Customer-installed third-party software
—Routine cleaning, or normal cosmetic and mechanical wear
—Damage caused by misuse, abuse, or neglect
—Damage caused by parts that were not manufactured or sold by
HP
—Damage caused when warranted parts were repaired or replaced
by an organization other than HP or by a service provider not
authorized by HP

9
Warranty Information 6
Hewlett-Packard Hardware Limited Warranty 7
1Product Overview 13
Supported Operating Systems 16
Array Management Software 16
Product Features 17
Controller Enclosure Components 19
Array Controller 24
Array Controller Filler Panel 26
Disk Drives 26
Disk Drive Filler Panels 28
Power Modules 28
Disk Enclosure Components 29
Link Controller Card (VA 7110/7400/7410 Only) 30
Disk Drives 30
Disk Drive Filler Panels 30
Power Modules 34
Operating the Power/Standby Switch 35
Power-On Self-Test 36
Shutdown 36
Data Storage Process 38
Virtual Array 38
Redundancy Groups 39
Performance Path 45
RAID Levels 47
Data I/O Architecture 52
Operating Tips 57
contents

10 Contents
Automatic Hot Spare Setting Behavior 57
Install an Even Number of Disks in Each Redundancy Group 57
Auto Rebuild Behavior 58
2System Configurations 59
Lowest Entry Point, Non-HA Minimum Configuration (VA 7100
only) 59
Lowest Entry Point, Non-HA Minimum Configuration (VA 7410) 60
Entry Level Non-Cluster With Path Redundancy (All VA arrays) 61
Entry Level Cluster with Path Redundancy High Availability (VA
7410) 62
Midrange Non-Cluster (All VA arrays) 63
Midrange Non-Cluster (VA 7410) 64
Midrange Non-Cluster with Full Storage Path Redundancy (All VA
Arrays) 65
Typical Non-Clustered with Path Redundancy (VA 7410) 66
Typical Clustered Configuration (All VA models) 67
Typical Clustered Configuration (VA 7410) 68
HP-UX MC Service Guard or Windows 2000 Cluster (All VA
arrays) 69
Highly Redundant Cluster (VA 7410) 70
Typical Highly Redundant Cluster (All VA models) 71
Typical Highly Redundant Cluster (VA 7410) 72
3Troubleshooting 73
Troubleshooting Steps 74
Redundant FRUs 75
Array State & Status 76
Array Power-On Sequence 77
LED Status Indications 78
Tools for Checking Array State & Status 85
Array Controller Logs 86
Types of Array Controller Logs 86
Location of Array Controller Logs 86
Checking Array Controller Logs 87
EMS Hardware Monitors (HP-UX Only) 88

Contents 11
4Servicing & Upgrading 91
Field Replaceable Units (FRUs) 92
Identifying FRUs 92
Hot Swappable FRUs 97
Controller Enclosure Removal & Installation Procedures 98
Disk Drives 98
Disk Drive Filler Panels 100
Power Modules 102
Fiber Optic Cables 104
Gigabit Interface Converters 106
Array Controllers 107
Array Controller Filler Panels 115
Array Controller Batteries 117
Array Controller DIMMs 120
Midplane Assembly 122
Disk Enclosure Removal & Installation Procedures 125
Disk Drives 125
Disk Drive Filler Panels 125
Power Modules 125
Link Controller Cards (LCCs) 127
Midplane Assembly 131
Upgrading the Array 132
Increasing Storage Capacity 132
Upgrading Single to Dual Array Controllers 134
Upgrading Array Controller DIMMs 135
Upgrading Array Controller Firmware 137
Upgrading Link Controller Card Firmware 137
Upgrading Disk Firmware 138
5Specifications & Regulatory Statements 139
Physical, Electrical & Environmental Specifications 140
Regulatory Statements 143

12 Contents

Product Overview 13
Product Overview
The HP StorageWorks Virtual Arrays are Fibre Channel disk arrays featuring
scalability, high performance, and advanced data protection. The VA 7000
Family includes the following models:
■VA 7100 - an entry level array that includes a single controller enclosure
with up to 15 disks.
■VA 7110 - a medium-capacity array that includes a controller enclosure
with up to 15 disks, and supports up to 2 additional external disk
enclosures each capable of housing 15 disks.
■VA 7400 - a high-capacity array that includes a controller enclosure with
up to 15 disks, and supports up to 6 additional external disk enclosures
each capable of housing 15 disks.
■VA 7410 - a higher-performance model of the VA 7400 that increases the
transfer speed between the array and disk enclosures to
2 Gbits/second, increases the amount of cache to 2 Gbytes, and adds
additional host and disk Fibre Channel ports.
Table 1 lists the VA 7000 Family configurations. Figure 1 illustrates the
enclosure configuration for the VA 7400/7410 products.
Both the controller enclosure and the disk enclosure can house up to 15 disk
modules in any combination of 18 GB, 36 GB, or 73 GB disk capacities. The
VA 7410 and VA 7110 also support 146 GB disk modules. The maximum
configuration for a VA 7400/7410 includes 105 disk drives with a total
capacity of 7.67 TB. The controller enclosure includes one or two array
controllers that use advanced storage technology to automatically select the
proper RAID level for storing data.
The array can be connected to one or more hosts, hubs, or switches via fiber
optic cables. Factory-racked products are shipped pre-configured in HP Rack
1

14 Product Overview
System/E racks. Field-rackable products are supported in the racks listed in
Table 2.
Table 1 Virtual Array Product Configurations
Table 2 Virtual Array Supported Racks
1HP Computer Cabinet requires a 1U filler panel to hide the mounting rails.
2Does not include space that may be required for PDUs.
Model Enclosure/
Configurations
No. of
Enclosures
Disks
Per Encl.
Controller Cards
Per Encl.
Memory Per
Controller
(in MBytes)a
a.See Table 25 on page 136 for valid DIMM configurations.
VA 7100 Controller 1 4-15 1 or 2 array controllers
1 Gbit/s
256, 512,
or 1024
VA 7110 Controller 1 4-15 2 array controllers
1 or 2 Gbit/s
1024 or 2048
VA 7400 Controller 1 10-15 2 array controllers
1 or 2 Gbit/s
512 or 1024
VA 7410 Controller 1 10-15 2 array controllers
1 or 2 Gbit/s
1024 or 2048
VA 7110/
7400/7410
Disk 0-6 2-15 2 link controllers
7400: 1 Gbit/s
7410: 2 Gbit/s
N/A
Rack
Product No. Rack Name
Height
meters/
EIA Units
No. of
EIA Units per
Array1
No. of
Arrays
per Rack2
J1500A HP Rack System/E41 1.96 m/ 41 U 3 13
J1501A HP Rack System/E33 1.60 m/ 33 U 3 11
J1502A HP Rack System/E25 1.25 m/ 25 U 3 8
E3660B HP System Rack 1.10 m/ 21 U 4 5
E3661B HP System Rack 1.60 m/ 32 U 4 8
E3662B HP System Rack 1.96 m/ 41 U 4 10
9142 Compaq 9000 Rack 2.0 m/ 42 U 3 14
9136 Compaq 9000 Rack 1.7 m/ 36 U 3 12
9122 Compaq 9000 Rack 1.1 m/ 22 U 3 7

Product Overview 15
Product Overview
Figure 1 VA 7400/7410 Maximum Configuration
(2 Enclosures Supported on VA 7110)

16 Product Overview
Supported Operating Systems
Native Operating Systems
The arrays are supported on the following native operating systems running
CommandView SDM software:
—HP-UX 11.x
—Windows NT 4.0
—Windows 2000
—Red Hat Linux
Non-Native Operating Systems
The following non-native operating systems are only supported using a
dedicated management station running CommandView SDM on one of the
native operating systems listed above:
—Sun Solaris
—IBM AIX
—NetWare
—MPE/iX (VA 7100 only)
Array Management Software
HP StorageWorks CommandView SDM (Storage Device Manager) software,
shipped with the arrays, is used to configure, manage, diagnose, and monitor
the performance of the array. The software runs on the native operating
systems and includes the following interfaces:
—CommandView Graphical User Interface (GUI)
—Command Line User Interface (CLUI)
—CommandView User Interface (CVUI)

Product Overview 17
Product Overview
Product Features
The arrays include the following features:
■Scalability
The capacities for the different products and disk modules are listed in Table 3.
■High performance
—10K rpm & 15K rpm disk drives
—1 or 2 Gbit/s native Fibre Channel (host to controllers/controllers to
back-end)
—High performance read/write IOPS and cache hits. See Table 4
Table 4 Read/Write & Cache Performance
*RAID 1+0 only
**RAID 5DP only
Table 3 Data Storage Scalability
Product
No.
18 GB
Disk Module
36 GB
Disk Module
73 GB
Disk Module
146 GB
Disk Module
VA 7100 72 GB min
270 GB max
144 GB min
540 GB max
292 GB min
1095 GB max
Not supported
VA 7110 72 GB min
810 GB max
144 GB min
1620 GB max
292 GB min
3285 GB max
584 GB min
6570 GB max
VA 7400 180 GB min
1895 max
360 GB min
3780 GB max
730 GB min
7665 GB max
Not supported
VA 7410 180 GB min
1895 max
360 GB min
3780 GB max
730 GB min
7665 GB max
1460 GB min
15,330 GB max
Product
No.
Random
Reads
Random
Writes
Sequential
Reads
Sequential
Writes
Cache
Hits
VA 7100 3,200 IOPS*
3,000 IOPS**
1,600 IOPS*
480 IOPS**
90 MB/s 45 MB/s 14,000 IOPS
VA 7110 7150 IOPS*
7100 IOPS**
3500 IOPS*
1050 IOPS**
160 MB/s 84 MB/s 15,500 IOPS
VA 7400 8,000 IOPS*
7,500 IOPS**
4,000 IOPS*
1,200 IOPS**
160 MB/s 80 MB/s 22,500 IOPS
VA 7410 11,000 IOPS*
11,000 IOPS**
5,500 IOPS*
1,100 IOPS**
330 MB/s 250 MB/s 30,000 IOPS

18 Product Overview
■Advanced data protection
—RAID 5DP
—End-to-end data protection
—Mirrored ECC NV-SDRAM1
—Dual battery cache backup
—Dual-ported native Fibre Channel disks
—Redundant, hot swappable field replaceable components – controllers,
power supplies, cooling, Fibre Channel components
1Non-volatile synchronous dynamic random access memory/Error
Correction Code

Product Overview 19
Product Overview
Controller Enclosure Components
Figure 2 through Figure 6 show the front and rear panel components of the VA
7000 Family controller enclosures.
Figure 2 VA 7100 Factory-Racked & Field-Racked Controller Enclosure (A/AZ)
*Reference designator used in CommandView SDM
1 - Power/Standby Switch 9 - HOST FC LEDs
2 - System LEDs 10 - Array Controller LEDs
3 - Disk Drive Slot No. 1 (of 15) 11 - RS-232 Connector
4 - Disk Drive 1 (of 15) - M/D1* 12 - Array Controller 2 - M/C2*
5 - Disk Drive LEDs 13 - Power Module 1 - M/P1*
6 - ESD Ground Receptacle 14 - AC Power Connector
7 - Array Controller 1- M/C1* 15 - Power Module LEDs
8 - HOST FC Connector - M/C1.H1* 16 - Power Module 2 - M/P2*
21
3
4
789 10 11 12
16
56
14 13 15

20 Product Overview
Figure 3 VA 7100 Controller Enclosure (D)
*Reference designator used in CommandView SDM
1 - Power/Standby Switch 10 - Array Controller LEDs
2 - System LEDs 11 - RS-232 Connector
3 - Disk Drive 1 (of 15) - M/D1* 12 - Array Controller 2 - M/C2*
4 - Disk Drive LEDs 13 - AC Power Connector
5 - Disk Drive Slot No. 1 (of 15) 14 - Power Module 1 - M/P1*
6 - Front ESD Ground Receptacle 15 - Power Module LEDs
7 - Array Controller 1 - M/C1* 16 - Power Module 2 - M/P2*
8 - HOST FC Connector - M/C1.H1* 17 - Rear ESD Ground Receptacle
9 - HOST FC LEDs
1
2
5
617
7
10
9
11
12
14
13
15
16
8
4
3
