HP StorageWorks XP48 - Disk Array User manual

HP StorageWorks Disk Array XP
operating system configuration
guide
XP48
XP128
XP512
XP1024
XP12000
Fifth edition (November 2004)
part number: A5951-96073
SGI IRIX

2HP StorageWorks Disk Array XP Operating System Configuration Guide: SGI IRIX
Copyright © 1999 - 2004 Hewlett-Packard Development Company, L.P., all rights reserved.
Hewlett-Packard Company makes no warranty of any kind with regard to this material, including, but not limited to,
the implied warranties of merchantability and fitness for a particular purpose. Hewlett-Packard shall not be liable for
errors contained herein or for incidental or consequential damages in connection with the furnishing, performance,
or use of this material.
This document contains proprietary information, which is protected by copyright. No part of this document may be
photocopied, reproduced, or translated into another language without the prior written consent of Hewlett-Packard.
The information contained in this document is subject to change without notice.
All other product names mentioned herein may be trademarks of their respective companies.
Hewlett-Packard Company shall not be liable for technical or editorial errors or omissions contained herein. The
information is provided “as is” without warranty of any kind and is subject to change without notice. The warranties
for Hewlett-Packard Company products are set forth in the express limited warranty statements accompanying such
products. Nothing herein should be construed as constituting an additional warranty.
Printed in the U.S.A.
HP StorageWorks Disk Array XP Operating System Configuration Guide: SGI IRIX
fifth edition (November 2004)
part number: A5951-96073

Contents 3
About this guide 5
Intended audience 5
Disk arrays 5
Related documentation 5
Conventions 6
HP technical support 6
HP storage website 7
HP authorized reseller 7
Revision history 8
Warranty statement 9
1Installation 11
Features and requirements 12
Fibre Channel interface 13
Device emulation types 13
Failover 14
SNMP configuration 14
RAID Manager command devices 15
Installation procedures 16
Install and configure the disk array 17
Setting the System Option Modes 17
Configuring the Fibre Channel ports 18
Setting the Host Mode for the disk array ports 20
Install and configure the host 21
Loading the OS and software 21
Installing and configuring the HBAs 21
Clustering and fabric zoning 22
Fabric zoning and LUN security for multiple operating systems 23
Contents

4HP StorageWorks Disk Array XP Operating System Configuration Guide: SGI IRIX
Connect the disk array 24
Defining the paths 25
Verifying new device recognition 25
Configure disk array devices 26
Creating device files 26
Partitioning and labeling the devices 29
Enabling command tag queuing 32
Creating the file systems 34
Creating and verifying the mount directories 35
Registering, mounting, and verifying the file systems 36
2Troubleshooting 39
Error conditions 40
Calling the HP support center 42
AWorksheet 43
Path worksheet 44
BDisk array device emulations 45
Supported emulations 46
Device type specifications 47
Parameter values tables 49
Queue depth parameters table 61
Glossary 65
Index 69

About this guide 5
About this guide
This guide describes the requirements and procedures for connecting the
XP family of disk arrays to an SGI host system and configuring the disk
array for use with the SGI IRIX operating system.
Intended audience
This guide is intended for system administrators who have knowledge of:
• Data processing concepts
• Direct access storage device subsystems and their basic functions
• Disk arrays and RAID technology
• Operating system commands and utilities
Disk arrays
Unless otherwise noted, the term disk array refers to these disk arrays:
HP Surestore Disk Array XP512
HP Surestore Disk Array XP48
HP StorageWorks Disk Array XP128
HP StorageWorks Disk Array XP1024
HP StorageWorks XP12000 Disk Array
Related documentation
HP provides these related documents:
• HP StorageWorks Disk Array XP128: Owner’s Guide
• HP StorageWorks Disk Array XP1024: Owner’s Guide
• HP StorageWorks XP12000 Disk Array: Owner’s Guide
Refer to the manufacturer’s documentation for information about operating
system commands and third-party products.

6HP StorageWorks Disk Array XP Operating System Configuration Guide: SGI IRIX
Conventions
This guide uses these text conventions.
Figure 1 Blue text represents a cross-reference. In the online
version of this guide, the reference is linked to the
target.
www.hp.com Underlined, blue text represents a website on the
Internet. In the online version of this guide, the
reference is linked to the target.
literal Bold text represents application names, file names,
menu items, dialog box titles, buttons, key names, field
names, and literal values that you type exactly as
shown.
variable Italic type indicates that you must supply a value. Italic
type is also used for manual titles.
input/output Monospace font denotes user input and system
responses, such as output and messages.
Example The word “example” in italics denotes an example of
input or output.
[ ] Square brackets indicate an optional parameter.
{ } Braces indicate that you must specify at least one of the
listed options.
| A vertical bar separates alternatives in a list of options.
HP technical support
In North America, call technical support at 1-800-652-6672, available 24
hours a day, 7 days a week.

About this guide 7
Outside North America, call technical support at the nearest location.
Telephone numbers for worldwide technical support are listed on the HP
website under support:
http://h18006.www1.hp.com/storage/arraysystems.html
Be sure to have the following information available before calling:
• Technical support registration number (if applicable)
• Product serial numbers
• Product model names and numbers
• Applicable error messages
• Operating system type and revision level
• Detailed, specific questions
For continuous quality improvement, calls may be recorded or monitored.
HP storage website
Visit the support website for the most current information about HP
StorageWorks XP products.
http://h18006.www1.hp.com/storage/arraysystems.html
Consult your HP account representative for information about product
availability, configuration, and connectivity.
HP authorized reseller
For the name of your nearest HP authorized reseller, call:
United States 1-800-345-1518
Canada 1-800-263-5868
Or visit: www.hp.com

8HP StorageWorks Disk Array XP Operating System Configuration Guide: SGI IRIX
Revision history
May 1999 First release
November 2000 Added Fibre Channel support
April 2004 General update
August 2004 Technical and format update
November 2004 Added support for XP12000

About this guide 9
Warranty statement
HP warrants that for a period of ninety calendar days from the date of
purchase, as evidenced by a copy of the invoice, the media on which the
Software is furnished (if any) will be free of defects in materials and
workmanship under normal use.
DISCLAIMER. EXCEPT FOR THE FOREGOING AND TO THE
EXTENT ALLOWED BY LOCAL LAW, THIS SOFTWARE IS
PROVIDED TO YOU “AS IS” WITHOUT WARRANTIES OF ANY
KIND, WHETHER ORAL OR WRITTEN, EXPRESS OR IMPLIED.
HP SPECIFICALLY DISCLAIMS ANY IMPLIED WARRANTIES
OR CONDITIONS OF MERCHANTABILITY, SATISFACTORY
QUALITY, NON-INFRINGEMENT, TITLE, ACCURACY OF
INFORMATIONAL CONTENT, AND FITNESS FOR A
PARTICULAR PURPOSE. Some jurisdictions do not allow exclusions of
implied warranties or conditions, so the above exclusion may not apply to
you to the extent prohibited by such local laws. You may have other rights
that vary from country to country, state to state, or province to province.
WARNING! YOU EXPRESSLY ACKNOWLEDGE AND AGREE
THAT USE OF THE SOFTWARE IS AT YOUR SOLE RISK. HP
DOES NOT WARRANT THAT THE FUNCTIONS CONTAINED IN
THE SOFTWARE WILL MEET YOUR REQUIREMENTS, OR THAT
THE OPERATION OF THE SOFTWARE WILL BE UNINTERRUPTED,
VIRUS-FREE OR ERROR-FREE, OR THAT DEFECTS IN THE
SOFTWARE WILL BE CORRECTED. THE ENTIRE RISK AS TO THE
RESULTS AND PERFORMANCE OF THE SOFTWARE IS ASSUMED
BY YOU. HP DOES NOT WARRANT OR MAKE ANY
REPRESENTATIONS REGARDING THE USE OR THE RESULTS OF
THE USE OF THE SOFTWARE OR RELATED DOCUMENTATION IN
TERMS OF THEIR CORRECTNESS, ACCURACY, RELIABILITY,
CURRENTNESS, OR OTHERWISE. NO ORAL OR WRITTEN
INFORMATION OR ADVICE GIVEN BY HP OR HP’S AUTHORIZED
REPRESENTATIVES SHALL CREATE A WARRANTY.

10 HP StorageWorks Disk Array XP Operating System Configuration Guide: SGI IRIX
LIMITATION OF LIABILITY. EXCEPT TO THE EXTENT
PROHIBITED BY LOCAL LAW, IN NO EVENT INCLUDING
NEGLIGENCE WILL HP OR ITS SUBSIDIARIES, AFFILIATES,
DIRECTORS, OFFICERS, EMPLOYEES, AGENTS OR
SUPPLIERS BE LIABLE FOR DIRECT, INDIRECT, SPECIAL,
INCIDENTAL, CONSEQUENTIAL, PUNITIVE OR OTHER
DAMAGES (INCLUDING LOST PROFIT, LOST DATA, OR
DOWNTIME COSTS), ARISING OUT OF THE USE, INABILITY
TO USE, OR THE RESULTS OF USE OF THE SOFTWARE,
WHETHER BASED IN WARRANTY, CONTRACT, TORT OR
OTHER LEGAL THEORY, AND WHETHER OR NOT ADVISED
OF THE POSSIBILITY OF SUCH DAMAGES. Your use of the
Software is entirely at your own risk. Should the Software prove defective,
you assume the entire cost of all service, repair or correction. Some
jurisdictions do not allow the exclusion or limitation of liability for
incidental or consequential damages, so the above limitation may not apply
to you to the extent prohibited by such local laws.
NOTE.EXCEPT TO THE EXTENT ALLOWED BY LOCAL LAW,
THESE WARRANTY TERMS DO NOT EXCLUDE, RESTRICT OR
MODIFY, AND ARE IN ADDITION TO, THE MANDATORY
STATUTORY RIGHTS APPLICABLE TO THE LICENSE OF THE
SOFTWARE TO YOU; PROVIDED, HOWEVER, THAT THE
CONVENTION ON CONTRACTS FOR THE INTERNATIONAL
SALE OF GOODS IS SPECIFICALLY DISCLAIMED AND SHALL
NOT GOVERN OR APPLY TO THE SOFTWARE PROVIDED IN
CONNECTION WITH THIS WARRANTY STATEMENT.

Installation 11
1
Installation
You and your HP service representative each play a role in installation.
Your HP service representative is responsible for installing the disk array
and formatting the disk devices. You are responsible for configuring the
host server for the new devices with assistance from your HP service
representative.

12 HP StorageWorks Disk Array XP Operating System Configuration Guide: SGI IRIX
Features and requirements
The disk array has the following features:
•Storage capacity. The storage capacity for each model is listed below:
XP48: Up to 48 drives from 72 GB to 8.7 TB, 24 FC ports
XP128: From 8 to 128 drives for up to 18 TB, 48 FC ports
XP512: Up to 512 drives from 72 GB to 93 TB, 48 FC ports
XP1024: From 8 to 1024 drives for up to 149 TB, 64 FC ports
XP12000: Up to 1152 drives for up to 165 TB, 128 FC ports
•Server support. SGI ORIGIN 2000 system(s)
•Operating system support. SGI IRIX operating system 6.5 or higher
with current patches.
Before installing the disk array, ensure the environment conforms to these
requirements:
•Host Bus Adapters (HBAs). Install HBAs and all utilities and
drivers. Refer to the adapter documentation for installation details.
•(Recommended) HP StorageWorks Command View XP with LUN
management feature or Remote Control with the LUN Configuration
Manager XP option. These are used to configure disk array ports and
paths.
•(Recommended) HP StorageWorks Secure Manager XP. Allows the
host to access only authorized array devices.
•(Optional) Other available XP software (some may not be supported
by your system):
HP StorageWorks Business Copy XP
HP StorageWorks Continuous Access XP
HP StorageWorks Continuous Access Extension XP
HP StorageWorks Auto LUN XP
HP StorageWorks Data Exchange XP
HP StorageWorks Resource Manager XP
HP StorageWorks RAID Manager XP
HP StorageWorks Cache LUN XP

Installation 13
HP StorageWorks Auto Path XP
HP StorageWorks Cluster Extension XP
HP StorageWorks Performance Advisor XP
Fibre Channel interface
The XP family of disk arrays supports these Fibre Channel elements:
• Connection speed of 1 Gbps and 2 Gbps
• Short-wave non-OFC (open fiber control) optical interface
• Multimode optical cables with SC or LC connectors
• Public or private arbitrated loop (FC-AL) or direct fabric attach
• Fibre Channel switches
Even though the interface is Fibre Channel, this guide uses the term “SCSI
disk” because disk array devices are defined to the host as SCSI disks.
Device emulation types
The XP family of disk arrays supports these device emulation types:
•OPEN-xdevices: OPEN-x logical units represent disk devices.
Except for OPEN-V, these devices are based on fixed sizes. OPEN-V
is a user-defined size. Supported emulations include OPEN-3,
OPEN-8, OPEN-9, OPEN-E, OPEN-L, and OPEN-V devices.
•LUSE devices (OPEN-x*n): Logical Unit Size Expansion (LUSE)
devices combine 2 to 36 OPEN-x devices to create expanded LDEVs
larger than standard OPEN-xdisk devices. For example, an OPEN-x
LUSE volume created from ten OPEN-x volumes is designated as
OPEN-x*10.
•CVS devices (OPEN-x CVS): Volume Size Configuration (VSC)
defines custom volumes (CVS) that are smaller than normal
fixed-sized logical disk devices (volumes). (OPEN-V is a CVS-based
custom disk size that you determine. OPEN-L does not support CVS.)
• LUSE (expanded) CVS devices (OPEN-x*n CVS): LUSE CVS
combines CVS devices to create an expanded device. This is done by

14 HP StorageWorks Disk Array XP Operating System Configuration Guide: SGI IRIX
first creating CVS custom-sized devices and then using LUSE to
combine from 2 to 36 CVS devices. For example, if three OPEN-9
CVS volumes are combined to create an expanded device, this device
is designated as OPEN-9*3-CVS.
Failover
The XP family of disk arrays supports many standard software products
that provide host, application, or I/O path failover and logical volume
(storage) management.
SNMP configuration
The XP family of disk arrays supports standard Simple Network
Management Protocol (SNMP) to remotely manage the disk array from the
host. The SNMP agent on the remote console PC or Command View can
provide status and Remote Service Information Message (R-SIM) reporting
to the SNMP manager on the host for up to eight disk arrays. Refer to the
operating system documentation to configure the SNMP manager on the
host.

Installation 15
RAID Manager command devices
RAID Manager manages Business Copy (BC) and Continuous Access
(CA) operations from a host server. To use RAID Manager with BC or CA,
you use Command View or LUN Configuration Manager to designate at
least one LDEV as a command device. Refer to the Command View or
LUN Configuration Manager user guide for information about how to
designate a command device.

16 HP StorageWorks Disk Array XP Operating System Configuration Guide: SGI IRIX
Installation procedures
Perform these actions to install and configure the disk array:
1. Install and configure the disk array (page 17)
• Setting the System Option Modes
• Configuring the Fibre Channel ports
• Setting the Host Mode for the disk array ports
2. Install and configure the host (page 21)
• Loading the OS and software
• Installing and configuring the HBAs
• Clustering and fabric zoning
• Fabric zoning and LUN security for multiple operating systems
3. Connect the disk array (page 24)
• Defining the paths
• Verifying new device recognition
4. Configure disk array devices (page 26)
• Creating device files
• Partitioning and labeling the devices
• Enabling command tag queuing
• Creating the file systems
• Creating and verifying the mount directories
• Registering, mounting, and verifying the file systems

Installation 17
Install and configure the disk array
The HP service representative performs these tasks:
• Assembling hardware and installing software
• Loading the microcode updates
• Installing the channel adapters (CHAs) and cabling
• Installing and formatting devices
After these tasks are finished, you will use Command View or LUN
Configuration Manager to complete the remaining tasks listed below. If you
do not have Command View or LUN Configuration Manager, your HP
service representative can perform these tasks for you.
Setting the System Option Modes
The HP service representative sets the System Option Mode(s) based on the
operating system and software configuration of the host.

18 HP StorageWorks Disk Array XP Operating System Configuration Guide: SGI IRIX
Configuring the Fibre Channel ports
Configure the Fibre Channel ports on the disk array using Command View
(shown) or the Fibre Parameter window in LUN Configuration Manager.
Select the settings for each port based onthe device to which the port is
connected (fabric switch or point-to-point connection). Use switch zoning
if you connect different types of hosts to the array through the same switch.
Fibre Address
In fabric environments, the port addresses are assigned automatically. In
arbitrated loop environments, set the port addresses by selecting a unique
arbitrated loop physical address (AL-PA) or loop ID for each port.

Installation 19
Fabric and Connection parameter settings
Set each array port to FABRIC ON or OFF with connections of
POINT-TO-POINT or FC-AL as shown in the following table and figures.
For detailed topology information, refer to the HP StorageWorks SAN
Design Reference Guide on the
hp.com website.
Fabric
Parameter
Connection
Parameter Provides
ON FC-AL Not supported
ON Point-to-Point F-port (fabric port)
OFF FC-AL AL-port (private arbitrated loop; direct
connect without a SAN)

20 HP StorageWorks Disk Array XP Operating System Configuration Guide: SGI IRIX
Setting the Host Mode for the disk array ports
The disk array ports have Host Modes that you must set depending on the
host you use. After the disk array is installed, use Command View (shown)
or LUN Configuration Manager to set the Host Mode for each port.
The host mode setting for SGI IRIX is 00.
OFF Point-to-Point Not supported
Fabric
Parameter
Connection
Parameter Provides
