HP StorageWorks 8B - FC Entry Switch User manual

user's guide
version 3.0
advanced performance monitoring
www.hp.com

Notice
© Hewlett-Packard Company, 2001. All rights reserved.
Edition: E1201
Hewlett-Packard Company makes no warranty of any kind with
regard to this material, including, but not limited to, the implied
warranties of merchantability and fitness for a particular purpose.
Hewlett-Packard shall not be liable for errors contained herein or for
incidental or consequential damages in connection with the
furnishing, performance, or use of this material.
This document contains proprietary information, which is protected
by copyright. No part of this document may be photocopied,
reproduced, or translated into another language without the prior
written consent of Hewlett-Packard. The information contained in
this document is subject to change without notice.
Use, duplication, or disclosure by government is subject to
restrictions as set forth in subdivision (c) (1) (ii) of the Rights in
Technical Data and Computer Software Clause at DFARS
252.227.7013.
Warranty
If you have any questions about the warranty for this product,
contact your dealer or local Hewlett-Packard sales representative.
Trademarks
BROCADE, the Brocade B weave logo, Brocade: the Intelligent
Platform for Networking Storage, SilkWorm, and SilkWorm
Express, are trademarks or registered trademarks of Brocade
Communications Systems, Inc. or its subsidiaries in the United
States and/or in other countries.
All other brands, product or service namesare or may be trademarks
or service marks of, and are used to identify products of services of
their respective owners.
Safety notices
Any servicing, adjustment, maintenance, or repair must be
performed only by authorized service-trained personnel.

Advanced Performance Monitoring User’s Guide iii
Contents
Preface
About This Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . v
Related Publications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . v
Getting Help . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . vii
Getting Software Updates. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . vii
Chapter 1 Introducing Advanced Performance Monitoring
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-1
Features. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-1
Administration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-1
Terminology Used in this Document . . . . . . . . . . . . . . . . . . 1-2
Performance Monitoring with Telnet Commands . . . . . . . . . . . . . . . . . 1-2
AL_PA Monitoring. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2
End-to-end Monitoring. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2
Filter-based Monitoring . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3
Performance Monitoring with Web Tools . . . . . . . . . . . . . . . . . . . . . . . 1-3
Predefined Performance Graphs. . . . . . . . . . . . . . . . . . . . . . 1-3
User-defined Graphs. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-4
Performance Graph Formats. . . . . . . . . . . . . . . . . . . . . . . . . 1-5
Performance Graph Canvas . . . . . . . . . . . . . . . . . . . . . . . . . 1-6
Chapter 2 Installing Advanced Performance Monitoring
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-1
Installing Through Telnet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-1
Installing through Web Tools . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-2

iv Advanced Performance Monitoring User’s Guide
Chapter 3 Using Advanced Performance Monitoring
Overview. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-1
Web Tools . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-1
Telnet Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-1
AL_PA Performance Monitoring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-2
Displaying the CRC Error Count . . . . . . . . . . . . . . . . . . . . . 3-2
Clearing the CRC Error Count . . . . . . . . . . . . . . . . . . . . . . . 3-2
End-to-end Performance Monitoring . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-3
Adding End-to-end Monitors . . . . . . . . . . . . . . . . . . . . . . . . 3-3
Setting a Mask for End-to-End Monitors . . . . . . . . . . . . . . . 3-4
Displaying the End-to-end Mask of a Port . . . . . . . . . . . . . . 3-6
Displaying End-to-end Monitors . . . . . . . . . . . . . . . . . . . . . 3-6
Deleting End-to-End Monitors . . . . . . . . . . . . . . . . . . . . . . . 3-7
Clearing End-to-End Monitor Counters . . . . . . . . . . . . . . . . 3-8
Filter-based Performance Monitoring. . . . . . . . . . . . . . . . . . . . . . . . . . . 3-8
Adding Standard Filter-Based Monitors. . . . . . . . . . . . . . . . 3-8
Adding User-Defined Filter-Based Monitors . . . . . . . . . . . . 3-9
Displaying Filter-Based Monitors. . . . . . . . . . . . . . . . . . . . . 3-10
Deleting Filter-Based Monitors . . . . . . . . . . . . . . . . . . . . . . 3-11
Clearing Filter-Based Monitor Counters . . . . . . . . . . . . . . . 3-12
Saving and Restoring Monitor Configuration . . . . . . . . . . . . . . . . . . . . 3-12
Glossary
Index

Advanced Performance Monitoring User’s Guide v
Preface
Advanced Performance Monitoring is a licensed option and requires a valid license key to function.
It is included and enabled in switches with the performance upgrade option. It is supported for the
HP Surestore FC 1Gb/2Gb Entry Switch 8B, FC 1Gb/2Gb Switch 8B and FC 1Gb/2Gb Switch 16B
using Fabric OS version 3.0.1b or later.
About This Guide
This guide provides the following information about Advanced Performance Monitoring:
Related Publications
Related product information can be found in the following publications.
Provided with the FC Entry Switch 8B and FC Switch 8B:
•HP Surestore FC 1Gb/2Gb Entry Switch 8B and FC 1Gb/2Gb Switch 8B Getting Started
Guide (A7346-90902)
•HP Surestore FC 1Gb/2Gb Entry Switch 8B and FC 1Gb/2Gb Switch 8B Documentation
CD (A7346-11001)
Chapter 1
Introducing Advanced Performance
Monitoring
Overview of Advanced Performance Monitoring.
Chapter 2
Installing Advanced Performance Monitoring Instructions for installing Advanced Performance Monitoring using telnet commands.
Chapter 3
Using Advanced Performance Monitoring Information about configuring and using the Advanced Performance Monitoring telnet
commands.

vi Advanced Performance Monitoring User’s Guide
Provided on the FC Entry Switch 8B and FC Switch 8B Documentation CD, and at the HP Web site
at http://www.hp.com/support/fc8B:
•HP Surestore FC 1Gb/2Gb Entry Switch 8B and FC 1Gb/2Gb Switch 8B Getting Started
Guide (A7346-90902)
•HP Surestore FC 1Gb/2Gb Entry Switch 8B and FC 1Gb/2Gb Switch 8B Installation and
Reference Guide
•Fabric OS Reference Manual, version 3.0
•Fabric OS Procedures Guide, version 3.0
•Fabric OS Version 3.0.1b Release Notes
•Fabric Watch User’s Guide, version 3.0
•QuickLoop User’s Guide, version 3.0
•Web Tools User’s Guide, version 3.0
•Distributed Fabrics User’s Guide, version 3.0
•Zoning User’s Guide, version 3.0
•MIB Reference Manual, version 3.0
•ISL Trunking User’s Guide, version 3.0
•Advanced Performance Monitoring User’s Guide, version 3.0
•Merging Heterogeneous Fabrics Instructions
Provided with the FC 16B:
•HP Surestore FC 1Gb/2Gb Switch 16B Quick Start Guide (A7340-96002)
•HP Surestore FC 1Gb/2Gb Switch 16B Documentation CD (A7340-11001)
Provided on the FC 1Gb/2Gb Switch 16B Documentation CD and at the HP Web site at
http://www.hp.com/support/fc16B:
•HP Surestore FC 1Gb/2Gb Switch 16B Quick Start Guide (A7340-96002)
•HP Surestore FC 1Gb/2Gb Switch 16B Installation and Reference Guide
•Fabric OS Reference Manual, version 3.0
•Fabric OS Procedures Guide, version 3.0
•Fabric OS Version 3.0.1 Release Notes
•Fabric Watch User’s Guide, version 3.0
•QuickLoop User’s Guide, version 3.0
•Web Tools User’s Guide, version 3.0
•Distributed Fabrics User’s Guide, version 3.0
•Zoning User’s Guide, version 3.0
•MIB Reference Manual, version 3.0
•ISL Trunking User’s Guide, version 3.0
•Advanced Performance Monitoring User’s Guide, version 3.0
•Merging Heterogeneous Fabrics Instructions
Information about Fibre Channel standards and Fibre Channel in general can be found on the Fibre
Channel Industry Association Web site, located at http://www.fibrechannel.com.

Advanced Performance Monitoring User’s Guide vii
Getting Help
For information for the FC Entry Switch 8B and FC Switch 8B, visit the HP Web site at
http://www.hp.com/support/fc8B. For the most current technical support information for the FC 16B,
visit the HP Web site at http://www.hp.com/support/fc16B. This includes hardware and software
support, all repairs, and spare components.
Be prepared to provide the following information to the support personnel:
•Switch serial number
•Switch world wide name
•Output from the supportShow telnet command
•Detailed description of the problem
•Topology configuration
•Troubleshooting steps already performed
Getting Software Updates
For information on obtaining software updates contact your HP account representative or technical
support.

viii Advanced Performance Monitoring User’s Guide

Advanced Performance Monitoring User’s Guide 1-1
Chapter
1
Introducing Advanced Performance Monitoring
This chapter provides the following information:
•Overview on page 1-1
•Performance Monitoring with Telnet Commands on page 1-2
•Performance Monitoring with Web Tools on page 1-3
Overview
Advanced Performance Monitoring provides SAN performance management through an
end-to-end monitoring system that enables you to:
•Increase end-to-end visibility into the fabric
•Enable more accurate reporting for service level agreements and charged access applications
•Improve performance tuning and resource optimization
•Shorten troubleshooting time
•Promote better capacity planning
•Simplify administration and setup
•Increase productivity with preformatted and customizable screens and reports
Features
The Advanced Performance Monitoring product:
•Measures the bandwidth consumed by individual routes (host-target pairs)
•Provides device performance measurements by port, AL_PA, and LUN
•Reports CRC error measurement statistics
•Measures Trunking performance
•Compares IP vs. SCSI traffic on each port
•Includes a wide range of predefined reports
•Allows you to create customized user-defined reports
Administration
Advanced Performance Monitoring is an optionally licensed product that runs on FC Entry Switch
8B, FC Switch 8B, and FC 16B switches.

1-2 Advanced Performance Monitoring User’s Guide
Introducing Advanced Performance Monitoring
1
If you have a fabric with HP Brocade 2400/2800, FC 6164, FC Entry Switch 8B, FC Switch 8B, or
FC 16B switches, you can take advantage of the end-to-end performance monitoring features by
installing an FC Entry Switch 8B, FC Switch 8B, or FC 16B switch anywhere in the route path
between the Source ID and the Destination ID.
You can administer performance monitoring through either telnet commands or Web Tools. If you
use Web Tools, a Web Tools license must also be installed on the switch.
Terminology Used in this Document
AL_PA Arbitrated Loop Physical Address. An 8-bit value used to uniquely identify an
individual port within a loop. A loop may have one or multiple AL_PAs.
SID 3-byte Source ID of the originator device, in the “0xDomainAreaALPA”
(0xDDAAPP) format.
DID 3-byte Destination ID of the destination device, in the “0xDomainAreaALPA”
(0xDDAAPP) format.
CRC Cyclic redundancy check; an error detection method. The CRC is 32 bits in the
frame, after the data field, and before the EOF (end of frame).
Performance Monitoring with Telnet Commands
Telnet commands provide three different types of performance monitoring:
•AL_PA monitoring
•End-to-end monitoring
•Filter-based monitoring
Refer to Chapter 3, Using Advanced Performance Monitoring, for detailed information on how to
use the telnet commands to monitor performance.
AL_PA Monitoring
AL_PA monitoring provides information regarding the number of CRC errors occurring in Fibre
Channel frames in a loop configuration. AL_PA monitoring collects CRC error counts for each
AL_PA attached to a specific port.
End-to-end Monitoring
End-to-end monitoring provides information regarding transaction performance between the
transaction source (SID) and destination (DID) on a fabric or a loop. Up to eight SID-DID pairs per
port can be specified. For each of the SID-DID pairs, the following information is available:
•CRC error count on the frames for the SID-DID pair
•Fibre channel words that have been transmitted through the port for the SID-DID pair

Advanced Performance Monitoring User’s Guide 1-3
Introducing Advanced Performance Monitoring 1
•Fibre channel words that have been received by the port for the SID-DID pair
Filter-based Monitoring
Filter-based monitoring provides information about a filter’s hit count. Any pattern of values in the
first 64 bytes of the Fibre Channel frame can be measured. The counter increases each time a frame
is filtered through the corresponding port. Examples of port filter statistics that can be measured
are:
•SCSI Read, Write, or Read/Write commands
•IP vs. SCSI traffic comparison
Performance Monitoring with Web Tools
You can monitor performance using Web Tools, if a Web Tools license is also installed. The
enhanced Advanced Performance Monitoring features in Web Tools provide:
•Pre-defined reports for AL_PA, end-to-end, and filter-based performance monitoring.
•User-definable reports
•Performance canvas for application level or fabric level views
•Configuration editor (save, copy, edit, and remove multiple configurations)
•Persistent graphs across reboots (saves parameter data across reboots)
•Print capabilities
Predefined Performance Graphs
Predefined graphs are provided to simplify performance monitoring. A wide range of end-to-end
fabric, LUN, device, and port metrics are included. Table 1-1 lists the predefined performance
graphs available with both basic and advanced performance monitoring. Figure 1-1 shows how to
access the list of predefined advanced performance monitoring graphs in Web Tools.
Table 1-1 Predefined Performance Graphs
Basic Monitoring Advanced Monitoring1
1. These graphs are available only when an Advanced Performance Monitoring license is
installed.
Port Throughput SID/DID Performance
Switch Aggregate Throughput SCSI vs. IP Traffic
Switch Throughput Utilization AL_PA Errors
Port Error SCSI Commands by port and LUN (R, W, R/W)
Switch Percent Utilization
Port Snapshot Error

1-4 Advanced Performance Monitoring User’s Guide
Introducing Advanced Performance Monitoring
1
Figure 1-1 Accessing Predefined Performance Graphs
User-defined Graphs
The predefined graphs can be modified based on parameter fields such as SID/DID, LUN, AL_PA,
and port. These new user-defined graphs can be added and saved to canvas configurations.
Figure 1-2 shows a list of user-defined graphs defined in a canvas.
Figure 1-2 User-defined Graphs

Advanced Performance Monitoring User’s Guide 1-5
Introducing Advanced Performance Monitoring 1
Performance Graph Formats
Performance graphs can be displayed as vertical bar charts, horizontal bar charts, and line charts, as
shown in Figure 1-3.
Figure 1-3 Types of Performance Graphs
In addition to the above charts, the Advanced Performance Monitoring Resource Usage Display
(shown in Figure 1-4 on page 1-6) shows which filter slots have been used for each port, and which
are available. The color-coded interface makes troubleshooting easier.
Vertical Bar Charts
Horizontal Bar Charts Line Charts

1-6 Advanced Performance Monitoring User’s Guide
Introducing Advanced Performance Monitoring
1
Figure 1-4 Advanced Performance Monitoring Resource Usage Display
Performance Graph Canvas
The enhanced performance monitoring in Web Tools enables you to set up a canvas of performance
graphs. The canvas can hold up to eight graphs per window, as shown in Figure 1-5 on page 1-7.

Advanced Performance Monitoring User’s Guide 1-7
Introducing Advanced Performance Monitoring 1
Figure 1-5 Canvas of Eight Performance Monitoring Graphs
Multiple canvasses can be created for different users or different scenarios. You can then save the
multiple configurations of graphs, edit them, and recall them. Figure 1-6 shows a list of different
canvas configurations from which you can choose to display.
Figure 1-6 Canvas Management

1-8 Advanced Performance Monitoring User’s Guide
Introducing Advanced Performance Monitoring
1

Advanced Performance Monitoring User’s Guide 2-1
Chapter
2
Installing Advanced Performance Monitoring
This chapter provides the following information:
•Overview on page 2-1
•Installing Through Telnet on page 2-1
•Installing through Web Tools on page 2-2
Overview
To enable Advanced Performance Monitoring, you must install a license on each switch that will
use this feature. For information on obtaining license keys for an FC Entry Switch 8B or FC Switch
8B, visit the HP Web site at http://www.hp.com/support/fc8B. For information on obtaining license
keys for an FC 16B, visit the HP Web site at http://www.hp.com/support/fc16B.
Note: A license may have already been installed on the switch at the factory.
You can install an Advanced Performance Monitoring license through telnet commands or through
Web Tools, if a Web Tools license is installed.
Version 3.0 of Advanced Performance Monitoring requires an FC Entry Switch 8B, FC Switch 8B,
or FC 16B switch with Fabric OS version 3.0.1b or later installed.
Installing Through Telnet
1. Log on to the switch by telnet (see the Fabric OS Procedures Guide Version 3.0 for details),
using an account that has administrative privileges.
2. Type licenseShow on the telnet command line to determine whether an Advanced
Performance Monitoring license is already installed on the switch.
A list of all the licenses currently installed on the switch displays. For example:
admin> licenseShow
1A1AaAaaaAAA1a:
Zoning license
QuickLoop license
If the Advanced Performance Monitoring license is not included in the list, continue with
step 3.
3. Enter the following on the command line:
licenseAdd “key”

2-2 Advanced Performance Monitoring User’s Guide
Installing Advanced Performance Monitoring
2
where “key” is the license key exactly as provided by your switch supplier, surrounded by
double quotes. The license key is case-sensitive and must be entered exactly as given.
4. Verify the license was successfully added by entering licenseShow on the command line:
admin> licenseShow
1A1AaAaaaAAA1a:
Zoning license
QuickLoop license
1A1AaAaaaAAA2a:
Performance Monitor license
The Advanced Performance Monitoring features are available as soon as the license is added.
Installing through Web Tools
You can install a license through Web Tools if a Web Tools license is already installed.
1. Launch a Web browser, enter the switch name or IP address in the Location/Address field of
the browser, and press Enter.
Web Tools launches, displaying the Fabric View. See Figure 2-1.
Figure 2-1 Fabric View
2. Click the Admin button on the relevant switch panel.
The logon window displays.
3. Enter a logon name and password with administrative privileges and press Enter. The
administrator account name and default password is “admin” and “password”.
The Administration View displays.
Admin Button

Advanced Performance Monitoring User’s Guide 2-3
Installing Advanced Performance Monitoring 2
4. Select the License Admin tab.
5. Enter the license key in the License Key field exactly as provided by your switch supplier, and
click Add (see Figure 2-2).
The Advanced Performance Monitoring features are available as soon as the license is added.
Figure 2-2 License Admin Tab
For more information about Web Tools, see the Web Tools User’s Guide Version 3.0.

2-4 Advanced Performance Monitoring User’s Guide
Installing Advanced Performance Monitoring
2
