HP 2910 Series User manual

HP 2910-24G al Switch
HP 2910-48G al Switch
HP 2910-48G-PoE+ al Switch
Models
HP 2910-24G al Switch J9145A
HP 2910-48G al Switch J9147A
HP 2910-24G-PoE+ al Switch J9146A
HP 2910-48G-PoE+ al Switch J9148A
Key Features
High-performance Gigabit Ethernet access switch
Four optional 10 GbE (CX4 and/or SFP+) ports
IEEE 802.3af/802.3at functionality ( PoE/PoE+)
Layer 2 and Layer 3 plus static IP and RIP routing
Lifetime warranty, sFlow, ACLs, and rate limiting
QuickSpecs
HP 2910 al Switch Series
Overview
DA - 13280 North America — Version 20 — December 12, 2013 Page 1

Product overview
The HP 2910 al Switch Series consists of four switches: the HP 2910-24G al and 2910-24G-PoE+ al Switches with 24 10/100/1000
ports, and the HP 2910-48G al and 2910-48G-PoE+ al Switches with 48 10/100/1000 ports. Each switch has four dual-personality
ports for 10/100/1000 or mini-GBIC connectivity. In addition, the 2910 al Switch Series supports up to four optional 10 Gigabit Ethernet
(CX4 and/or SFP+) ports, thereby offering the most flexible and easy-to-deploy uplinks in its class. Together with static and RIP IPv4
routing, robust security and management, enterprise-class features, free lifetime warranty, and free software updates, the 2910
series is a cost-effective, scalable solution for customers who are building high-performance networks. These switches can be
deployed at enterprise edge and remote branch offices, converged networks, and data center top of rack.
Features and Benefits
Quality of Service (QoS)
Traffic prioritization (IEEE 802.1p): allows real-time traffic classification into eight priority levels mapped to eight queues
Layer 4 prioritization : enables prioritization based on TCP/UDP port numbers
Class of Service (CoS): sets the IEEE 802.1p priority tag based on IP address, IP Type of Service (ToS), Layer 3 protocol, TCP/UDP
port number, source port, and DiffServ
Rate Limiting : per-port ingress enforced maximums
Connectivity
10 Gbps Ethernet connectivity : up to four optional and flexible 10-Gigabit ports (CX4 and/or SFP+), with optional interconnect
kit for short-distance connectivity
IPv6 :
IPv6 host : allows the switches to be managed and deployed at the edge of IPv6 networks
Dual stack (IPv4/IPv6): provides transition mechanism from IPv4 to IPv6; supports connectivity for both protocols
MLD snooping : forwards IPv6 multicast traffic to the appropriate interface; prevents IPv6 multicast traffic from flooding
the network
IEEE 802.3af Power over Ethernet (PoE): provides up to 15.4 W per port to IEEE 802.3af-compliant PoE-powered devices such
as IP phones, wireless access points, and security cameras
IEEE 802.3at Power Over Ethernet Plus : provides up to 30 W per port to IEEE 802.3 for PoE/PoE+ powered devices such as
video IP phones, IEEE 802.11n wireless access points, and advanced pan/zoom/tilt security cameras
Pre-standard PoE support : detects and provides power to pre-standard PoE devices; see list of supported devices in the
product FAQ at: www.hp.com/networking/support
Auto-MDIX : automatically adjusts for straight-through or crossover cables on all 10/100 and 10/100/1000 ports
Dual-personality functionality : includes four 10/100/1000 ports or SFP slots for optional fiber connectivity such as Gigabit-SX,
-LX, -LH, 100-FX, 100-BX, and 1000-BX
Single IP Address Management : single IP address management for a virtual stack of up to 16 switches
Performance
High-performance architecture : 128 Gbps switching fabric with up to 95 Mpps (24-port switches) and 176 Gbps switching fabric
with up to 131 Mpps (48-port switches)
Selectable queue configurations : allows for increased performance by selecting the number of queues and associated memory
buffering that best meet the requirements of the network applications
Resiliency and high availability
IEEE 802.1s Multiple Spanning Tree : provides high link availability in multiple VLAN environments by allowing multiple
spanning trees; provides legacy support for IEEE 802.1d and IEEE 802.1w
QuickSpecs
HP 2910 al Switch Series
Overview
DA - 13280 North America — Version 20 — December 12, 2013 Page 2

IEEE 802.3ad Link Aggregation Protocol (LACP) and HP port trunking : support up to 24 trunks, each with up to 8 links (ports)
per trunk
Optional redundant power supply : supplies backup power in case of power failure ( NOTE: HP 620 Redundant/External Power
Supply provides only RPS functionality )
Manageability
RMON, XRMON, and sFlow : provide advanced monitoring and reporting capabilities for statistics, history, alarms, and events
Uni-Directional Link Detection (UDLD): monitors a link between two switches and blocks the ports on both ends of the link if
the link goes down at any point between the two devices
Command authorization : leverages RADIUS to link a custom list of CLI commands to an individual network administrator's login;
also provides an audit trail
Dual flash images : provides independent primary and secondary operating system files for backup while upgrading
Multiple configuration files : allow multiple configuration files to be stored to a flash image
Friendly port names : allow assignment of descriptive names to ports
Find-Fix-Inform : finds and fixes common network problems automatically, then informs administrator
Software updates : free downloads from the Web
Troubleshooting : ingress and egress port monitoring enable network problem solving
Layer 2 switching
VLAN support and tagging : supports IEEE 802.1Q (4,094 VLAN IDs) and 256 VLANs simultaneously
GARP VLAN Registration Protocol (GVRP): allows automatic learning and dynamic assignment of VLANs
Jumbo packet support : supports up to 9220-byte frame size to improve the performance of large data transfers
IEEE 802.1v protocol VLANs : isolate select non-IPv4 protocols automatically into their own VLANs
Layer 3 routing
Static IP routing : provides manually configured routing; includes ECMP capability
Routing Information Protocol (RIP): provides RIPv1 and RIPv2 routing
Security
Multiple user authentication methods :
IEEE 802.1X : is an industry-standard method of user authentication using an IEEE 802.1X supplicant on the client in
conjunction with a RADIUS server
Web-based authentication : is similar to IEEE 802.1X and provides a browser-based environment to authenticate clients
that do not support the IEEE 802.1X supplicant
MAC-based authentication : authenticates the client with the RADIUS server based on the client's MAC address
Authentication flexibility :
Multiple IEEE 802.1X users per port : provides authentication of up to eight IEEE 802.1X users per port; prevents a user
from "piggybacking" on another user's IEEE 802.1X authentication
Concurrent IEEE 802.1X and Web or MAC authentication schemes per port : switch port will accept any IEEE 802.1X and
either Web or MAC authentications
Access control lists (ACLs): provide IP Layer 3 filtering based on source/destination IP address/subnet and source/destination
TCP/UDP port number
Identity-driven ACL : enables implementation of a highly granular and flexible access security policy and VLAN assignment
specific to each authenticated network user
Dynamic ARP protection : blocks ARP broadcasts from unauthorized hosts, preventing eavesdropping or theft of network data
DHCP protection : blocks DHCP packets from unauthorized DHCP servers, preventing denial-of-service attacks
QuickSpecs
HP 2910 al Switch Series
Overview
DA - 13280 North America — Version 20 — December 12, 2013 Page 3

Port monitoring for network threats : provides sampled port traffic using sFlow technology to the HP Network Immunity
Manager (NIM) application for Network Behavior Anomaly Detection (NBAD) analysis to detect and mitigate threats at the port
where the threat originated
Source-port filtering : allows only specified ports to communicate with each other
RADIUS/TACACS+ : eases switch management security administration by using a password authentication server
Secure shell : encrypts all transmitted data for secure remote CLI access over IP networks
Secure FTP : allows secure file transfer to and from the switch; protects against unwanted file downloads or unauthorized
copying of a switch configuration file
Secure Sockets Layer (SSL): encrypts all HTTP traffic, allowing secure access to the browser-based management GUI in the
switch
Port security : allows access only to specified MAC addresses, which can be learned or specified by the administrator
MAC address lockout : prevents particular configured MAC addresses from connecting to the network
Switch management logon security : helps secure switch CLI logon by optionally requiring either RADIUS or TACACS+
authentication
STP BPDU port protection : blocks Bridge Protocol Data Units (BPDUs) on ports that do not require BPDUs, preventing forged
BPDU attacks
USB Secure Autorun (requires HP PCM+): deploys, diagnoses, and updates a switch using a USB flash drive; works with a secure
credential to prevent tampering
STP Root Guard : protects the root bridge from malicious attacks or configuration mistakes
Custom banner : displays security policy when users log in to the switch
Per-port broadcast throttling : selectively configures broadcast control on heavy traffic port uplinks
Convergence
IP multicast snooping and data-driven IGMP : automatically prevent flooding of IP multicast traffic
LLDP-MED (Media Endpoint Discovery): is a standard extension of LLDP that stores values for parameters such as QoS and VLAN
to automatically configure network devices such as IP phones
IEEE 802.1AB Link Layer Discovery Protocol (LLDP): is an automated device discovery protocol that provides easy mapping of
network management applications
PoE and PoE+ allocations : support multiple methods (automatic, IEEE 802.3at dynamic, LLDP-MED fine-grain, IEEE 802.3af
device class, or user specified) to allocate and manage PoE/PoE+ power for more efficient energy savings
Monitor and diagnostics
Port mirroring : enables traffic on a port to be simultaneously sent to a network analyzer for monitoring
Warranty and support
Lifetime warranty : for as long as you own the product with advance replacement and next-business-day delivery (available in
most countries)†
Electronic and telephone support : limited electronic and telephone support is available from HP; to reach our support centers,
refer to www.hp.com/networking/contact-support ; for details on the duration of support provided with your product purchase,
refer to www.hp.com/networking/warrantysummary
Software releases : to find software for your product, refer to www.hp.com/networking/support ; for details on the software
releases available with your product purchase, refer to www.hp.com/networking/warrantysummary
†HP warranty includes repair or replacement of hardware for as long as you own the product, with next business day advance
replacement (available in most countries). The disk drive included with HP AllianceOne Advanced Services and Services zl Modules, HP
Threat Management Services zl Module, HP AllianceOne Extended zl Module with Riverbed Steelhead, HP MSM765zl Mobility Controller
and HP Survivable Branch Communication zl Module powered by Microsoft Lync has a five-year hardware warranty. For details, refer to
QuickSpecs
HP 2910 al Switch Series
Overview
DA - 13280 North America — Version 20 — December 12, 2013 Page 4

the Software license and hardware warranty statements at www.hp.com/networking/warranty .
QuickSpecs
HP 2910 al Switch Series
Overview
DA - 13280 North America — Version 20 — December 12, 2013 Page 5

Build To Order:
BTO is a standalone unit with no integration. BTO products ship standalone are not part of a CTO or Rack-
Shippable solution.
HP 2910-24G al Switch J9145A
20 autosensing 10/100/1000 port
4 dual-personality ports
min=0 \ max=4 SFP Transceivers
2 - Module Slots
1U - Height
See Configuration
Note:1, 2, 3
PDU Cable NA/MEX/TW/JP J9145A#B2B
C15 PDU Jumper Cord (NA/MEX/TW/JP)
PDU Cable ROW J9145A#B2C
C15 PDU Jumper Cord (ROW)
HP 2910-48G al Switch J9147A
44 autosensing 10/100/1000 port
4 dual-personality ports
min=0 \ max=4 SFP Transceivers
2 - Module Slots
1U - Height
See Configuration
Note:1, 2, 3
PDU Cable NA/MEX/TW/JP J9147A#B2B
C15 PDU Jumper Cord (NA/MEX/TW/JP)
PDU Cable ROW J9147A#B2C
C15 PDU Jumper Cord (ROW)
HP 2910-24G-PoE+ al Switch J9146A
20 autosensing 10/100/1000 port
4 dual-personality ports
min=0 \ max=4 SFP Transceivers
2 - Module Slots
1U - Height
See Configuration
Note:1, 2, 3
PDU Cable NA/MEX/TW/JP J9146A#B2B
C15 PDU Jumper Cord (NA/MEX/TW/JP)
PDU Cable ROW J9146A#B2C
C15 PDU Jumper Cord (ROW)
HP 2910-48G-PoE+ al Switch J9148A
QuickSpecs
HP 2910 al Switch Series
Configuration
DA - 13280 North America — Version 20 — December 12, 2013 Page 6

44 autosensing 10/100/1000 port
4 dual-personality ports
min=0 \ max=4 SFP Transceivers
2 - Module Slots
1U - Height
See Configuration
Note:1, 2, 3
PDU Cable NA/MEX/TW/JP J9148A#B2B
C15 PDU Jumper Cord (NA/MEX/TW/JP)
PDU Cable ROW J9148A#B2C
C15 PDU Jumper Cord (ROW)
Configuration Rules:
Note 1 The following Transceivers install into this switch:
HP X111 100M SFP LC FX Transceiver J9054C
HP X112 100M SFP LC BX-D Transceiver J9099B
HP X112 100M SFP LC BX-U Transceiver J9100B
HP X121 1G SFP LC LH Transceiver J4860C
HP X121 1G SFP LC LX Transceiver J4859C
HP X121 1G SFP LC SX Transceiver J4858C
HP X122 1G SFP LC BX-D Transceiver J9142B
HP X122 1G SFP LC BX-U Transceiver J9143B
HP X132 10G SFP+ LC SR Transceiver J9150A
HP X132 10G SFP+ LC LR Transceiver J9151A
HP X132 10G SFP+ LC LRM Transceiver J9152A
HP X242 SFP+ SFP+ 1m Direct Attach Cable J9281B
HP X242 SFP+ SFP+ 3m Direct Attach Cable J9283B
HP X242 SFP+ SFP+ 7m Direct Attach Cable J9285B
HP X244 XFP SFP+ 1m Direct Attach Cable J9300A
HP X244 XFP SFP+ 3m Direct Attach Cable J9301A
HP X244 XFP SFP+ 5m Direct Attach Cable J9302A
HP X242 SFP+ 10m DAC Cable J9286B
HP X242 SFP+ 15m DAC Cable J9287B
Note 2 Localization required. (See Localization Menu for list.)
Note 3 Localization required on orders without #B2B or #B2C options.
Remarks:
Drop down under power supply should offer the following options and results:
Switch/Router/Power Supply to PDU Power Cord - #B2B in North America, Mexico, Taiwan, and
Japan or #B2C ROW. (Watson Default B2B or B2C for Rack Level CTO)
Switch/Router/Power Supply to Wall Power Cord - Localized Option (Watson Default for BTO and
Box Level CTO)
QuickSpecs
HP 2910 al Switch Series
Configuration
DA - 13280 North America — Version 20 — December 12, 2013 Page 7

Factory Racked Models
HP 2910-24G al Switch J9145A
20 autosensing 10/100/1000 port
4 dual-personality ports
min=0 \ max=4 SFP Transceivers
2 - Module Slots
1U - Height
See Configuration
Note:1, 2
HP 2910-24G Fact Integrated al Switch J9145AZ
See Configuration
Note:1, 2
PDU Cable NA/MEX/TW/JP J9145A#B2B
C15 PDU Jumper Cord (NA/MEX/TW/JP)
PDU Cable ROW J9145A#B2C
C15 PDU Jumper Cord (ROW)
HP 2910-48G al Switch J9147A
44 autosensing 10/100/1000 port
4 dual-personality ports
min=0 \ max=4 SFP Transceivers
2 - Module Slots
1U - Height
See Configuration
Note:1, 2
HP 2910-48G Factory Integrated al Switch J9147AZ
See Configuration
Note:1, 2
PDU Cable NA/MEX/TW/JP J9147A#B2B
C15 PDU Jumper Cord (NA/MEX/TW/JP)
PDU Cable ROW J9147A#B2C
C15 PDU Jumper Cord (ROW)
HP 2910-24G-PoE+ al Switch J9146A
20 autosensing 10/100/1000 port
4 dual-personality ports
min=0 \ max=4 SFP Transceivers
2 - Module Slots
1U - Height
See Configuration
Note:1, 2
HP 2910-24G-PoE+ Fact Integ al Switch J9146AZ
See Configuration
Note:1, 2
QuickSpecs
HP 2910 al Switch Series
Configuration
DA - 13280 North America — Version 20 — December 12, 2013 Page 8

PDU Cable NA/MEX/TW/JP J9146A#B2B
C15 PDU Jumper Cord (NA/MEX/TW/JP)
PDU Cable ROW J9146A#B2C
C15 PDU Jumper Cord (ROW)
HP 2910-48G-PoE+ al Switch J9148A
44 autosensing 10/100/1000 port
4 dual-personality ports
min=0 \ max=4 SFP Transceivers
2 - Module Slots
1U - Height
See Configuration
Note:1, 2
HP 2910-48G-PoE+ Fact Integ al Switch J9148AZ
See Configuration
Note:1, 2
PDU Cable NA/MEX/TW/JP J9148A#B2B
C15 PDU Jumper Cord (NA/MEX/TW/JP)
PDU Cable ROW J9148A#B2C
C15 PDU Jumper Cord (ROW)
Configuration Rules:
Note 1 The following Transceivers install into this switch:
HP X111 100M SFP LC FX Transceiver J9054C
HP X112 100M SFP LC BX-D Transceiver J9099B
HP X112 100M SFP LC BX-U Transceiver J9100B
HP X121 1G SFP LC LH Transceiver J4860C
HP X121 1G SFP LC LX Transceiver J4859C
HP X121 1G SFP LC SX Transceiver J4858C
HP X122 1G SFP LC BX-D Transceiver J9142B
HP X122 1G SFP LC BX-U Transceiver J9143B
HP X132 10G SFP+ LC SR Transceiver J9150A
HP X132 10G SFP+ LC LR Transceiver J9151A
HP X132 10G SFP+ LC LRM Transceiver J9152A
HP X242 SFP+ SFP+ 1m Direct Attach Cable J9281B
HP X242 SFP+ SFP+ 3m Direct Attach Cable J9283B
HP X242 SFP+ SFP+ 7m Direct Attach Cable J9285B
HP X244 XFP SFP+ 1m Direct Attach Cable J9300A
HP X244 XFP SFP+ 3m Direct Attach Cable J9301A
HP X244 XFP SFP+ 5m Direct Attach Cable J9302A
HP X242 SFP+ 10m DAC Cable J9286B
HP X242 SFP+ 15m DAC Cable J9287B
QuickSpecs
HP 2910 al Switch Series
Configuration
DA - 13280 North America — Version 20 — December 12, 2013 Page 9

Note 2 If this switch is factory installed in HP Universal Racks, Then the J9583A#0D1 or J9583AZ is
required.
AMS then J9583AZ is required.
EMEA then J9583A#0D1 is required.
APD, Japan and China then J9583A#0D1 is required.
CLIC Only - Allow the J9583AZ in all regions.
Note 3 Localization required on orders without #B2B or #B2C options.
Remarks:
Drop down under power supply should offer the following options and results:
Switch/Router/Power Supply to PDU Power Cord - #B2B in North America, Mexico, Taiwan, and
Japan or #B2C ROW. (Watson Default B2B or B2C for Rack Level CTO)
Switch/Router/Power Supply to Wall Power Cord - Localized Option (Watson Default for BTO and
Box Level CTO)
Internal Power Supplies
Power supplies included in base models.
Enter the following menu selections as integrated to the CTO Model X server above if order is factory built.
Modules
System (std 0 // max=2) User Selection (min 0 / max=2) per Chassis
HP 2-port 10GbE CX4 al Module J9149A
HP 2p 10GbE CX4 Fact Integrated al Mod J9149AZ
HP 2-port 10GbE SFP+ al Module J9008A
min=0 \ max=2 SFP+ Transceivers See Configuration
Note:2
HP 2-port 10GbE SFP+ Fact Integ al Mod J9008AZ
min=0 \ max=2 SFP+ Transceivers See Configuration
Note:2
HP 10GbE al Switch Interconnect Kit J9165A
HP 10GbE Fact Intg al Switch Intrcon Kit J9165AZ
Configuration Rules:
QuickSpecs
HP 2910 al Switch Series
Configuration
DA - 13280 North America — Version 20 — December 12, 2013 Page 10

Note 2 The following Transceivers install into this Module:
HP X132 10G SFP+ LC ER Transceiver J9153A
HP X132 10G SFP+ LC LR Transceiver J9151A
HP X132 10G SFP+ LC LRM Transceiver J9152A
HP X132 10G SFP+ LC SR Transceiver J9150A
HP X242 SFP+ SFP+ 1m Direct Attach Cable J9281B
HP X242 SFP+ SFP+ 3m Direct Attach Cable J9283B
HP X242 SFP+ SFP+ 7m Direct Attach Cable J9285B
HP X244 XFP SFP+ 1m Direct Attach Cable J9300A
HP X244 XFP SFP+ 3m Direct Attach Cable J9301A
HP X244 XFP SFP+ 5m Direct Attach Cable J9302A
HP X242 SFP+ 10m DAC Cable J9286B
HP X242 SFP+ 15m DAC Cable J9287B
Transceivers
SFP Transceivers
HP X111 100M SFP LC FX Transceiver J9054C
HP X112 100M SFP LC BX-D Transceiver J9099B
HP X112 100M SFP LC BX-U Transceiver J9100B
HP X121 1G SFP LC LH Transceiver J4860C
HP X121 1G SFP LC SX Transceiver J4858C
HP X121 1G SFP LC LX Transceiver J4859C
HP X122 1G SFP LC BX-D Transceiver J9142B
HP X122 1G SFP LC BX-U Transceiver J9143B
HP X132 10G SFP+ LC SR Transceiver J9150A
HP X132 10G SFP+ LC LR Transceiver J9151A
HP X132 10G SFP+ LC LRM Transceiver J9152A
SFP+ Transceivers
HP X132 10G SFP+ LC SR Transceiver J9150A
HP X132 10G SFP+ LC LR Transceiver J9151A
HP X132 10G SFP+ LC LRM Transceiver J9152A
HP X132 10G SFP+ LC ER Transceiver J9153A
HP X242 10G SFP+ SFP+ 1m DAC Cable J9281B
HP X242 10G SFP+ SFP+ 3m DAC Cable J9283B
HP X242 10G SFP+ SFP+ 7m DAC Cable J9285B
HP X244 XFP SFP+ 1m Direct Attach Cable J9300A
HP X244 XFP SFP+ 3m Direct Attach Cable J9301A
HP X244 XFP SFP+ 5m Direct Attach Cable J9302A
HP X242 SFP+ 10m DAC Cable J9286B
QuickSpecs
HP 2910 al Switch Series
Configuration
DA - 13280 North America — Version 20 — December 12, 2013 Page 11

HP X242 SFP+ 15m DAC Cable J9287B
Cables
Multi-Mode Cables
HP .5m Multi-mode OM3 LC/LC FC Cable AJ833A
HP 1m Multi-mode OM3 LC/LC FC Cable AJ834A
HP 2 m Multimode OM3 LC/LC FC Cable AJ835A
HP 5 m Multimode OM3 LC/LC FC Cable AJ836A
HP 15 m Multimode OM3 LC/LC FC Cable AJ837A
HP 30 m Multimode OM3 LC/LC FC Cable AJ838A
HP 50 m Multimode OM3 LC/LC FC Cable AJ839A
HP Premier Flex LC/LC OM4 2f 1m Cbl QK732A
HP Premier Flex LC/LC OM4 2f 2m Cbl QK733A
HP Premier Flex LC/LC OM4 2f 5m Cbl QK734A
HP Premier Flex LC/LC OM4 2f 15m Cbl QK735A
HP Premier Flex LC/LC OM4 2f 30m Cbl QK736A
HP Premier Flex LC/LC OM4 2f 50m Cbl QK737A
Switch Enclosure Options
Rack Mount Kit
HP 10GbE al Switch Interconnect Kit J9165A
Used to connect two switches together
Rack Mount Kit
HP X410 1U Univ 4-post Rack Mnt Kit J9583A
See Configuration
Note:1
HP X410 1U Integ Univ 4-post Rck Mnt Kit J9583AZ
See Configuration
Note:1
Configuration Rules:
Note 1 If this Mounting Kit is order with #0D1 or Z then it integrates to the HP Universal Rack. (not the
switch)
Software
QuickSpecs
HP 2910 al Switch Series
Configuration
DA - 13280 North America — Version 20 — December 12, 2013 Page 12

HP IDM v3 Software w/500-user License J9438A
HP IDM v3 additional 1000-user License J9440A
HP IDM v3 Software w/Unltd-user License J9439A
External Power supplies
HP 620 Redundant/External Power Supply J8696A
Height = 1U See Configuration
Note:1, 2
HP 630 Red and/or External Power Supply J9443A
Height = 1U See Configuration
Note:1, 2
Configuration Rules:
Note 1 See HPN Rack Menu for integration details.
Note 2 Localization required. (See Localization Menu for list.)
QuickSpecs
HP 2910 al Switch Series
Configuration
DA - 13280 North America — Version 20 — December 12, 2013 Page 13

HP 2910-24G al Switch (J9145A)
Ports 20 autosensing 10/100/1000 ports (IEEE 802.3 Type 10BASE-T, IEEE 802.3u Type 100BASE-TX, IEEE
802.3ab Type 1000BASE-T); Media Type: Auto-MDIX; Duplex: 10BASE-T/100BASE-TX: half or full;
1000BASE-T: full only
4 dual-personality ports; each port can be used as either an RJ-45 10/100/1000 port (IEEE 802.3 Type
10Base-T; IEEE 802.3u Type 100Base-TX; IEEE 802.3ab 1000Base-T Gigabit Ethernet) or as a mini-GBIC
slot (for use with mini-GBIC transceivers)
1 RJ-45 serial console port
Supports a maximum of 4 10GbE ports, with optional module
Physical characteristics Dimensions 17.4(w) x 14.4(d) x 1.73(h) in (44.2 x 36.58 x 4.4 cm) (1U height)
Weight 10.92 lb (4.95 kg)
Memory and processor Processor Dual ARM1156T2S @ 515 MHz, 4 MB flash, 1 GB compact flash, 512 MB
SDRAM; packet buffer size: 6 MB
Mounting Mounts in an EIA-standard 19 in. telco rack or equipment cabinet (hardware included); horizontal surface
mounting only
Performance 1000 Mb Latency < 2.9 µs (FIFO 64-byte packets)
10 Gbps Latency < 1.3 µs (FIFO 64-byte packets)
Throughput up to 95 million pps (64-byte packets)
Switching capacity 128 Gbps
Routing table size 2000 entries (IPv4)
MAC address table size 16000 entries
Environment Operating temperature 32°F to 131°F (0°C to 55°C)
Operating relative
humidity
15% to 95% @ 104°F (40°C), noncondensing
Non-operating/
Storage temperature
-40°F to 158°F (-40°C to 70°C)
Non-operating/
Storage relative humidity
15% to 95% @ 149°F (65°C), noncondensing
Altitude up to 10,000 ft (3 km)
Acoustic Power: 53.5 dB, Pressure: 39.4 dB; DIN 45635T.19 per ISO 7779
Electrical characteristics Description The switch automatically adjusts to any voltage between 100-127 and 200-
240 volts and either 50 or 60 Hz
Maximum heat
dissipation
279 BTU/hr (295 kJ/hr)
Voltage 100-127/200-240 VAC
Current 1.7/0.9 A
Idle power 49 W
Maximum power rating 82 W
Frequency 50/60 Hz
QuickSpecs
HP 2910 al Switch Series
Technical Specifications
DA - 13280 North America — Version 20 — December 12, 2013 Page 14

Notes Idle power is the actual power consumption of the device with no ports
connected.
Maximum power rating and maximum heat dissipation are the worst-case
theoretical maximum numbers provided for planning the infrastructure with
fully loaded PoE (if equipped), 100% traffic, all ports plugged in, and all
modules populated.
Safety EN 60950/IEC 60950; CAN/CSA 22.2 No. 60950; EN 60825; UL 60950
Emissions FCC part 15 Class A; EN 55022/CISPR-22 Class A; VCCI Class A
Immunity EN EN 55024, CISPR 24
ESD IEC 61000-4-2; 4 kV CD, 8 kV AD
Radiated IEC 61000-4-3; 3 V/m
EFT/Burst IEC 61000-4-4; 1.0 kV (power line), 0.5 kV (signal line)
Surge IEC 61000-4-5; 1 kV / 2 kV AC, 1 kV signal, 0.5 kV DC
Conducted IEC 61000-4-6; 3 V
Power frequency
magnetic field
IEC 61000-4-8; 1 A/m
Voltage dips and
interruptions
IEC 61000-4-11; > 95% reductions, 0.5 period; 30% reduction, 25 periods
Harmonics IEC 61000-3-2
Flicker IEC 61000-3-3
Management HP PCM+; HP PCM; command-line interface; Web browser; out-of-band management (serial RS-232C)
Notes When using mini-GBICs with this product, mini-GBICs with revision "B" or later (product number ends with
the letter "B" or later, e.g., J4858B, J4859C) are required.
Services 3-year, 4-hour onsite, 13x5 coverage for hardware (U2855E)
3-year, 4-hour onsite, 24x7 coverage for hardware (U2856E)
3-year, 4-hour onsite, 24x7 coverage for hardware, 24x7 software phone support (U6304E)
3-year, 24x7 SW phone support, software updates (UE262E)
Installation with minimum configuration, system-based pricing (U4826E)
Installation with HP-provided configuration, system-based pricing (U4830E)
4-year, 4-hour onsite, 13x5 coverage for hardware (UR868E)
4-year, 4-hour onsite, 24x7 coverage for hardware (UR869E)
4-year, 4-hour onsite, 24x7 coverage for hardware, 24x7 software phone (UR870E)
4-year, 24x7 SW phone support, software updates (UR871E)
5-year, 4-hour onsite, 13x5 coverage for hardware (UR872E)
5-year, 4-hour onsite, 24x7 coverage for hardware (UR873E)
5-year, 4-hour onsite, 24x7 coverage for hardware, 24x7 software phone (UR874E)
5-year, 24x7 SW phone support, software updates (UR875E)
3 Yr 6 hr Call-to-Repair Onsite (UW356E)
4 Yr 6 hr Call-to-Repair Onsite (UW357E)
5 Yr 6 hr Call-to-Repair Onsite (UW358E)
1-year, 6 hour Call-To-Repair Onsite for hardware (HR893E)
1-year, 24x7 software phone support, software updates (HR892E)
1-year, 24x7 software phone support, software updates + Next Business Day Hardware Exchange
(HS610E)
1-year, 24x7 software phone support, software updates + 4 hour hardware exchange (HS611E)
3-year, 24x7 software phone support, software updates + Next Business Day Hardware Exchange
QuickSpecs
HP 2910 al Switch Series
Technical Specifications
DA - 13280 North America — Version 20 — December 12, 2013 Page 15

(HS612E)
3-year, 24x7 software phone support, software updates + 4 hour Hardware Exchange (HS613E)
4-year, 24x7 software phone support, software updates + Next Business Day Hardware Exchange
(HS614E)
4-year, 24x7 software phone support, software updates + 4 hour Hardware Exchange (HS615E)
5-year, 24x7 software phone support, software updates + Next Business Day Hardware Exchange
(HS616E)
5-year, 24x7 software phone support, software updates + 4 hour Hardware Exchange (HS617E)
Refer to the HP website at: www.hp.com/networking/services for details on the service-level descriptions
and product numbers. For details about services and response times in your area, please contact your local
HP sales office.
HP 2910-48G al Switch (J9147A)
Ports 44 autosensing 10/100/1000 ports (IEEE 802.3 Type 10BASE-T, IEEE 802.3u Type 100BASE-TX, IEEE
802.3ab Type 1000BASE-T); Media Type: Auto-MDIX; Duplex: 10BASE-T/100BASE-TX: half or full;
1000BASE-T: full only
4 dual-personality ports; each port can be used as either an RJ-45 10/100/1000 port (IEEE 802.3 Type
10Base-T; IEEE 802.3u Type 100Base-TX; IEEE 802.3ab 1000Base-T Gigabit Ethernet) or as a mini-GBIC
slot (for use with mini-GBIC transceivers)
1 RJ-45 serial console port
Supports a maximum of 4 10GbE ports, with optional module
Physical characteristics Dimensions 17.42(w) x 14.4(d) x 1.73(h) in (44.25 x 36.58 x 4.4 cm) (1U height)
Weight 11.2 lb (5.08 kg)
Memory and processor Processor Dual ARM1156T2S @ 515 MHz, 4 MB flash, 1 GB compact flash, 512 MB
SDRAM; packet buffer size: 6 MB
Mounting Mounts in an EIA-standard 19 in. telco rack or equipment cabinet (hardware included); horizontal surface
mounting only
Performance 1000 Mb Latency < 2.9 µs (FIFO 64-byte packets)
10 Gbps Latency < 1.3 µs (FIFO 64-byte packets)
Throughput up to 131 million pps
Switching capacity 176 Gbps
Routing table size 2000 entries (IPv4)
MAC address table size 16000 entries
Environment Operating temperature 32°F to 131°F (0°C to 55°C)
Operating relative
humidity
15% to 95% @ 104°F (40°C), non-condensing
Non-operating/
Storage temperature
-40°F to 158°F (-40°C to 70°C)
Non-operating/
Storage relative humidity
15% to 95% @ 149°F (65°C), non-condensing
Altitude up to 10,000 ft (3 km)
Acoustic Power: 53.5 dB, Pressure: 39.4 dB; DIN 45635T.19 per ISO 7779
Electrical characteristics Achieved Miercom Certified Green Award
QuickSpecs
HP 2910 al Switch Series
Technical Specifications
DA - 13280 North America — Version 20 — December 12, 2013 Page 16

* Products within this series have achieved sufficient scores in each of the rated criteria to achieve the
Miercom Certified Green distinction Award. See the Specifications section of this series for more
information.
Description The switch automatically adjusts to any voltage between 100-127 and 200-
240 volts and either 50 or 60 Hz
Maximum heat
dissipation
356 BTU/hr (376 kJ/hr)
Voltage 100-127/200-240 VAC
Current 2.1/1.1 A
Idle power 64 W
Maximum power rating 105 W
Frequency 50/60 Hz
Notes Idle power is the actual power consumption of the device with no ports
connected.
Maximum power rating and maximum heat dissipation are the worst-case
theoretical maximum numbers provided for planning the infrastructure with
fully loaded PoE (if equipped), 100% traffic, all ports plugged in, and all
modules populated.
Safety EN 60950/IEC 60950; CAN/CSA 22.2 No. 60950; EN 60825; UL 60950
Emissions FCC part 15 Class A; EN 55022/CISPR-22 Class A; VCCI Class A
Immunity EN EN 55024, CISPR 24
ESD IEC 61000-4-2; 4 kV CD, 8 kV AD
Radiated IEC 61000-4-3; 3 V/m
EFT/Burst IEC 61000-4-4; 1.0 kV (power line), 0.5 kV (signal line)
Surge IEC 61000-4-5; 1 kV / 2 kV AC, 1 kV signal, 0.5 kV DC
Conducted IEC 61000-4-6; 3 V
Power frequency
magnetic field
IEC 61000-4-8; 1 A/m
Voltage dips and
interruptions
IEC 61000-4-11; > 95% reductions, 0.5 period; 30% reduction, 25 periods
Harmonics IEC 61000-3-2
Flicker IEC 61000-3-3
Management HP PCM+; HP PCM; command-line interface; Web browser; out-of-band management (serial RS-232C)
Notes When using mini-GBICs with this product, mini-GBICs with revision "B" or later (product number ends with
the letter "B" or later, e.g., J4858B, J4859C) are required.
Services 3-year, 4-hour onsite, 13x5 coverage for hardware (H4496E)
3-year, 4-hour onsite, 24x7 coverage for hardware (H2893E)
3-year, 4-hour onsite, 24x7 coverage for hardware, 24x7 software phone support (U6319E)
3-year, 24x7 SW phone support, software updates (UE264E)
Installation with minimum configuration, system-based pricing (U4826E)
Installation with HP-provided configuration, system-based pricing (U4830E)
4-year, 4-hour onsite, 13x5 coverage for hardware (UR884E)
4-year, 4-hour onsite, 24x7 coverage for hardware (UR885E)
4-year, 4-hour onsite, 24x7 coverage for hardware, 24x7 software phone (UR886E)
QuickSpecs
HP 2910 al Switch Series
Technical Specifications
DA - 13280 North America — Version 20 — December 12, 2013 Page 17

4-year, 24x7 SW phone support, software updates (UR887E)
5-year, 4-hour onsite, 13x5 coverage for hardware (UR888E)
5-year, 4-hour onsite, 24x7 coverage for hardware (UR889E)
5-year, 4-hour onsite, 24x7 coverage for hardware, 24x7 software phone (UR890E)
5-year, 24x7 SW phone support, software updates (UR891E)
3 Yr 6 hr Call-to-Repair Onsite (UW365E)
4 Yr 6 hr Call-to-Repair Onsite (UW366E)
5 Yr 6 hr Call-to-Repair Onsite (UW367E)
1-year, 6 hour Call-To-Repair Onsite for hardware (HR898E)
1-year, 24x7 software phone support, software updates (HR897E)
1-year, 4-hour onsite, 24x7 coverage for hardware, 24x7 software phone support and software updates
(HR896E)
1-year, 24x7 software phone support, software updates + 4 hour hardware exchange (HS618E)
1-year, 24x7 software phone support, software updates + 4 hour hardware exchange (HS619E)
3-year, 24x7 software phone support, software updates + Next Business Day Hardware Exchange
(HS620E)
3-year, 24x7 software phone support, software updates + 4 hour Hardware Exchange (HS621E)
4-year, 24x7 software phone support, software updates + Next Business Day Hardware Exchange
(HS622E)
4-year, 24x7 software phone support, software updates + 4 hour Hardware Exchange (HS623E)
5-year, 24x7 software phone support, software updates + Next Business Day Hardware Exchange
(HS624E)
5-year, 24x7 software phone support, software updates + 4 hour Hardware Exchange (HS625E)
Refer to the HP website at: www.hp.com/networking/services for details on the service-level descriptions
and product numbers. For details about services and response times in your area, please contact your local
HP sales office.
HP 2910-24G-PoE+ al Switch (J9146A)
Ports 20 autosensing 10/100/1000 ports (IEEE 802.3 Type 10BASE-T, IEEE 802.3u Type 100BASE-TX, IEEE
802.3ab Type 1000BASE-T); Media Type: Auto-MDIX; Duplex: 10BASE-T/100BASE-TX: half or full;
1000BASE-T: full only
4 dual-personality ports; each port can be used as either an RJ-45 10/100/1000 port (IEEE 802.3 Type
10Base-T; IEEE 802.3u Type 100Base-TX; IEEE 802.3ab 1000Base-T Gigabit Ethernet) or as a mini-GBIC
slot (for use with mini-GBIC transceivers)
1 RJ-45 serial console port
Supports a maximum of 4 10GbE ports, with optional module
Physical characteristics Dimensions 17.4(w) x 14.4(d) x 1.73(h) in (44.2 x 36.58 x 4.39 cm) (1U height)
Weight 12.34 lb (5.6 kg)
Memory and processor Processor Dual ARM1156T2S @ 515 MHz, 4 MB flash, 1 GB compact flash, 512 MB
SDRAM; packet buffer size: 6 MB
Mounting Mounts in an EIA-standard 19 in. telco rack or equipment cabinet (hardware included); horizontal surface
mounting only
Performance 1000 Mb Latency < 2.9 µs (FIFO)
10 Gbps Latency < 1.3 µs (FIFO)
Throughput up to 95 million pps
QuickSpecs
HP 2910 al Switch Series
Technical Specifications
DA - 13280 North America — Version 20 — December 12, 2013 Page 18

Switching capacity 128 Gbps
Routing table size 2000 entries (IPv4)
MAC address table size 16000 entries
Environment Operating temperature 32°F to 131°F (0°C to 55°C)
Operating relative
humidity
15% to 95% @ 104°F (40°C), non-condensing
Non-operating/
Storage temperature
-40°F to 158°F (-40°C to 70°C)
Non-operating/
Storage relative humidity
15% to 95% @ 149°F (65°C), non-condensing
Altitude up to 10,000 ft (3 km)
Acoustic Power: 51.5 dB, Pressure: 38.1 dB; DIN 45635T.19 per ISO 7779
Electrical characteristics Description The switch automatically adjusts to any voltage between 100-127 and 200-
240 volts and either 50 or 60 Hz
Maximum heat
dissipation
447 BTU/hr (472 kJ/hr), max. using PoE+
Voltage 100-127/200-240 VAC
Current 6.1/3.1 A
Idle power 65 W
Maximum power rating 490 W
PoE power 382 W
Frequency 50/60 Hz
Notes Idle power is the actual power consumption of the device with no ports
connected.
Maximum power rating and maximum heat dissipation are the worst-case
theoretical maximum numbers provided for planning the infrastructure with
fully loaded PoE (if equipped), 100% traffic, all ports plugged in, and all
modules populated.
PoE Power is the power supplied by the internal power supply, it is dependent
on the type and quantity of power supplies and may be supplemented with the
use of a External Power Supply (EPS).
Safety EN 60950/IEC 60950; CAN/CSA 22.2 No. 60950; EN 60825; UL 60950
Emissions FCC part 15 Class A; EN 55022/CISPR-22 Class A; VCCI Class A
Immunity EN EN 55024, CISPR 24
ESD IEC 61000-4-2; 4 kV CD, 8 kV AD
Radiated IEC 61000-4-3; 3 V/m
EFT/Burst IEC 61000-4-4; 1.0 kV (power line), 0.5 kV (signal line)
Surge IEC 61000-4-5; 1 kV / 2 kV AC, 1 kV signal, 0.5 kV DC
Conducted IEC 61000-4-6; 3 V
Power frequency
magnetic field
IEC 61000-4-8; 1 A/m
QuickSpecs
HP 2910 al Switch Series
Technical Specifications
DA - 13280 North America — Version 20 — December 12, 2013 Page 19

Voltage dips and
interruptions
IEC 61000-4-11; > 95% reductions, 0.5 period; 30% reduction, 25 periods
Harmonics IEC 61000-3-2
Flicker IEC 61000-3-3
Management HP PCM+; HP PCM; command-line interface; Web browser; out-of-band management (serial RS-232C)
Notes When using mini-GBICs with this product, mini-GBICs with revision "B" or later (product number ends with
the letter "B" or later, e.g., J4858B, J4859C) are required.
Services 3-year, 4-hour onsite, 13x5 coverage for hardware (U2855E)
3-year, 4-hour onsite, 24x7 coverage for hardware (U2856E)
3-year, 4-hour onsite, 24x7 coverage for hardware, 24x7 software phone support (U6304E)
3-year, 24x7 SW phone support, software updates (UE262E)
Installation with minimum configuration, system-based pricing (U4826E)
Installation with HP-provided configuration, system-based pricing (U4830E)
4-year, 4-hour onsite, 13x5 coverage for hardware (UR868E)
4-year, 4-hour onsite, 24x7 coverage for hardware (UR869E)
4-year, 4-hour onsite, 24x7 coverage for hardware, 24x7 software phone (UR870E)
4-year, 24x7 SW phone support, software updates (UR871E)
5-year, 4-hour onsite, 13x5 coverage for hardware (UR872E)
5-year, 4-hour onsite, 24x7 coverage for hardware (UR873E)
5-year, 4-hour onsite, 24x7 coverage for hardware, 24x7 software phone (UR874E)
5-year, 24x7 SW phone support, software updates (UR875E)
3 Yr 6 hr Call-to-Repair Onsite (UW356E)
4 Yr 6 hr Call-to-Repair Onsite (UW357E)
5 Yr 6 hr Call-to-Repair Onsite (UW358E)
-year, 6 hour Call-To-Repair Onsite for hardware (HR893E)
1-year, 24x7 software phone support, software updates (HR892E)
1-year, 24x7 software phone support, software updates + Next Business Day Hardware Exchange
(HS610E)
1-year, 24x7 software phone support, software updates + 4 hour hardware exchange (HS611E)
3-year, 24x7 software phone support, software updates + Next Business Day Hardware Exchange
(HS612E)
3-year, 24x7 software phone support, software updates + 4 hour Hardware Exchange (HS613E)
4-year, 24x7 software phone support, software updates + Next Business Day Hardware Exchange
(HS614E)
4-year, 24x7 software phone support, software updates + 4 hour Hardware Exchange (HS615E)
5-year, 24x7 software phone support, software updates + Next Business Day Hardware Exchange
(HS616E)
5-year, 24x7 software phone support, software updates + 4 hour Hardware Exchange (HS617E)
Refer to the HP website at: www.hp.com/networking/services for details on the service-level descriptions
and product numbers. For details about services and response times in your area, please contact your local
HP sales office.
HP 2910-48G-PoE+ al Switch (J9148A)
Ports 44 autosensing 10/100/1000 ports (IEEE 802.3 Type 10BASE-T, IEEE 802.3u Type 100BASE-TX, IEEE
802.3ab Type 1000BASE-T); Media Type: Auto-MDIX; Duplex: 10BASE-T/100BASE-TX: half or full;
1000BASE-T: full only
QuickSpecs
HP 2910 al Switch Series
Technical Specifications
DA - 13280 North America — Version 20 — December 12, 2013 Page 20
