HP FlexFabric 12900 series User manual

HP FlexFabric 12900 Switch Series
Installation Guide
Part number: 5998-4376
Document version: 5W100-20130815

Legal and notice information
© Copyright 2013 Hewlett-Packard Development Company, L.P.
No part of this documentation may be reproduced or transmitted in any form or by any means without
prior written consent of Hewlett-Packard Development Company, L.P.
The information contained herein is subject to change without notice.
HEWLETT-PACKARD COMPANY MAKES NO WARRANTY OF ANY KIND WITH REGARD TO THIS
MATERIAL, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY
AND FITNESS FOR A PARTICULAR PURPOSE. Hewlett-Packard shall not be liable for errors contained
herein or for incidental or consequential damages in connection with the furnishing, performance, or
use of this material.
The only warranties for HP products and services are set forth in the express warranty statements
accompanying such products and services. Nothing herein should be construed as constituting an
additional warranty. HP shall not be liable for technical or editorial errors or omissions contained
herein.

i
Contents
Preparing for installation ············································································································································· 1
Safety recommendations ··················································································································································1
General safety recommendations···························································································································1
Electricity safety ························································································································································1
Handling safety ························································································································································1
ESD prevention ·························································································································································2
Laser safety································································································································································2
Examining the installation site ·········································································································································2
Weight support·························································································································································2
Temperature ······························································································································································3
Humidity ····································································································································································3
Cleanness··································································································································································3
EMI·············································································································································································4
Grounding·································································································································································4
Power·········································································································································································4
Cooling······································································································································································5
Space·········································································································································································5
Installing the switch······················································································································································ 9
Confirming installation preparations·······························································································································9
Attaching installation accessory kits to the chassis········································································································9
Accessory kits ···························································································································································9
Attaching the power cable bracket ····················································································································· 10
Attaching the plastic panel··································································································································· 11
Attaching slide rails and cage nuts to the rack··········································································································· 12
Installing slide rails················································································································································ 12
Installing cage nuts················································································································································ 16
Mounting the switch to the rack···································································································································· 17
Grounding the switch ···················································································································································· 18
Grounding the switch with a grounding strip····································································································· 18
Grounding the switch through the PE wire of an AC power supply································································ 19
Installing FRUs ····························································································································································21
Attaching an ESD-preventive wrist strap······················································································································ 21
Installing a card······························································································································································ 22
Installing an MPU/LPU·········································································································································· 23
Installing a switching fabric module···················································································································· 26
Installing a power supply ·············································································································································· 27
Installing a power supply ····································································································································· 28
Connecting an AC power cable·························································································································· 29
Installing a transceiver module ····································································································································· 30
Installing an SFP+/SFP/QSFP+ module·············································································································· 31
Connecting an SFP+/QSFP+/QSFP+ to SFP+ cable ························································································ 32
Setting up an IRF fabric ·············································································································································33
IRF fabric setup flowchart·············································································································································· 33
Planning IRF fabric setup··············································································································································· 34
Planning IRF fabric size and the installation site································································································ 34
Identifying the master switch and planning IRF member IDs ············································································ 35
Planning IRF topology and connections ·············································································································· 35

ii
Identifying physical IRF ports on the member switches ····················································································· 35
Installing IRF member switches ····································································································································· 35
Configuring basic IRF settings······································································································································· 36
Connecting the physical IRF ports ································································································································ 36
Verifying the IRF fabric configuration ·························································································································· 37
Connecting your switch to the network ····················································································································38
Accessing the switch for the first time ·························································································································· 38
Setting up the configuration environment ··········································································································· 38
Setting terminal parameters·································································································································· 39
Powering on the switch········································································································································· 42
Configuring the switch··················································································································································· 44
Configuring authentication on a user interface·································································································· 44
Configuring the basic access function ················································································································ 44
Configuration example ········································································································································· 44
Verifying the network configuration ···················································································································· 46
Connecting the switch to the network ·························································································································· 46
Testing connectivity ························································································································································ 47
Troubleshooting··························································································································································48
Troubleshooting methods··············································································································································· 48
Configuration terminal problems·································································································································· 48
No terminal display ·············································································································································· 48
Garbled terminal display······································································································································ 49
Troubleshooting the switch during the operation······························································································· 49
Power supply system failure·········································································································································· 49
Fan failure······································································································································································· 50
MPU failure····································································································································································· 51
LPU and switching fabric module failure ····················································································································· 51
Interface failure······························································································································································· 52
Replacement procedures ···········································································································································53
Replacing a power supply ············································································································································ 53
Replacing a card···························································································································································· 55
Replacing an MPU or LPU ···································································································································· 56
Replacing a switching fabric module·················································································································· 58
Replacing a fan tray ······················································································································································ 60
Removing a fan tray·············································································································································· 60
Installing a fan tray ··············································································································································· 62
Replacing a transceiver module ··································································································································· 63
Replacing an SFP+/SFP/QSFP+ module············································································································ 63
Replacing an SFP+/QSFP+/QSFP+ to SFP+ cable··························································································· 64
Appendix A Chassis views and technical specifications ························································································65
Chassis views ································································································································································· 65
Weights and dimensions··············································································································································· 67
Module power consumption and system power consumption ·················································································· 68
Card power consumption····································································································································· 68
Fan tray power consumption································································································································ 68
System power consumption·································································································································· 68
Heat dissipation ····························································································································································· 69
Environmental specifications········································································································································· 69
Noise··············································································································································································· 69
Appendix B FRUs and compatibility matrixes··········································································································70
MPUs ··············································································································································································· 70
LPUs ················································································································································································· 70

iii
Switching fabric modules ·············································································································································· 71
Power supplies································································································································································ 71
Fan trays·········································································································································································· 72
Mounting accessories ···················································································································································· 72
Transceiver modules ······················································································································································ 73
Appendix C LEDs ·······················································································································································77
Chassis LEDs ··································································································································································· 77
Power supply LED ·················································································································································· 78
Fan tray status LED ················································································································································ 78
MPU LED································································································································································· 79
Switching fabric module LED ······························································································································· 79
LPU LED··································································································································································· 79
MPU LEDs········································································································································································ 79
LPU LEDs·········································································································································································· 81
Switching fabric module LEDs······································································································································· 82
Fan tray status LEDs ······················································································································································· 82
Power supply LEDs ························································································································································· 83
Appendix D Cables ···················································································································································84
Console cable································································································································································· 84
Ethernet twisted pair cable············································································································································ 84
RJ-45 connector ····················································································································································· 85
Cable pinouts························································································································································· 85
Cable type······························································································································································ 85
Pin assignments ····················································································································································· 86
Making an Ethernet twisted pair cable··············································································································· 87
Optical fiber ··································································································································································· 88
Optical fiber··························································································································································· 88
Optical fiber cable ················································································································································ 88
Patch cord ······························································································································································ 88
Pigtail cord····························································································································································· 89
Fiber connector······················································································································································ 89
Precautions····························································································································································· 89
SFP+ cable······································································································································································ 90
QSFP+ cable··································································································································································· 90
QSFP+ to SFP+ cable ···················································································································································· 91
Appendix E Engineering labels·································································································································92
Labels for cables····························································································································································· 92
Labels for network cables ····································································································································· 92
Labels for power cables········································································································································ 92
Generic labels························································································································································ 93
Labels for devices··························································································································································· 94
Filling in labels ······························································································································································· 94
Affixing labels································································································································································· 94
Affixing a label to a network cable····················································································································· 94
Affixing a label to a power cable ······················································································································· 95
Affixing a generic label········································································································································ 96
Affixing a label to a device·································································································································· 97
Guidelines······································································································································································· 97
Examples········································································································································································· 97
Engineering labels for twisted-pair cables·········································································································· 97
Engineering labels for optical fibers···················································································································· 99
Engineering labels for AC power cables··········································································································101
Engineering labels for devices···························································································································101

iv
Appendix F Cabling recommendations················································································································· 103
General cabling requirements ····································································································································104
Prerequisites··································································································································································104
Cable management guidelines···································································································································105
Appendix G Repackaging the switch···················································································································· 108
Removing cables from the switch ·······························································································································108
Removing the power cable·································································································································108
Removing the console cable·······························································································································108
Removing the grounding cable··························································································································108
Removing the twisted pair and optical fiber ····································································································109
Repackaging the switch accessories··························································································································109
Repackaging the plastic panel···························································································································109
Repackaging the power supply ·························································································································110
Repackaging the card·········································································································································110
Repackaging the switch chassis ·································································································································110
Removing the chassis from the rack ··················································································································110
Removing the power cable bracket···················································································································111
Repackaging the switch chassis·························································································································112
Support and other resources ·································································································································· 114
Contacting HP ······························································································································································114
Subscription service ············································································································································114
Related information······················································································································································114
Documents····························································································································································114
Websites·······························································································································································114
Conventions ··································································································································································115
Index ········································································································································································ 117

1
Preparing for installation
The HP FlexFabric 12900 Switch Series includes only the HP FlexFabric 12910 Switch AC Chassis model.
Product code HP descri
p
tion Alias RMN
JG619A HP FlexFabric 12910 Switch AC Chassis 12910 AC BJNGA-AC0008
Safety recommendations
To avoid possible bodily injury and equipment damage, read Compliance and Safety Manual provided
with the switch and all safety recommendations in this chapter carefully before installation. The
recommendations do not cover every possible hazardous condition.
General safety recommendations
•Keep the chassis clean and dust-free.
•Do not place the switch on a moist area, and avoid liquid flowing into the switch.
•Make sure the ground is dry and flat and anti-slip measures are in place.
•Keep the chassis and installation tools away from walk areas.
•Do not wear loose clothing, jewelry (for example, necklace) or any other things that could get
caught in the chassis when you install and maintain the switch.
Electricity safety
•Clear the work area of possible electricity hazards, such as ungrounded power extension cables,
missing safety grounds, and wet floors.
•Locate the emergency power-off switch in the room before installation so you can quickly shut power
off when an electrical accident occurs.
•Remove all external cables, including power cords, before moving the chassis.
•Do not work alone when the switch has power.
•Never assume that power has been disconnected from a circuit. Always check.
Handling safety
CAUTION:
Do not hold the handle of the fan tray or power distribution box, or the air vents of chassis. Any attemp
t
to move the switch with these parts might cause equipment damage and even bodily injury.
When you move an HP FlexFabric 12900 switch, follow these guidelines:
•Remove all external cables, including the power cords, before moving the chassis.

2
•HP recommends that you have four persons move the chassis, and you can use a mechanical lift as
needed.
•Lift and put down the chassis slowly and never move suddenly.
•Hold the handles on both sides of the chassis.
ESD prevention
To prevent the electric component from being damaged by electrostatic discharge (ESD), follow these
guidelines:
•Ground the switch correctly. For how to ground your switch, see "Installing the switch."
•Always wear an ESD-preventive wrist strap and make sure it is well grounded when installing FRUs.
For how to use an ESD-preventive wrist strap, see "Installing FRUs."
•Hold a PCB by its edges. Do not touch any electronic components or printed circuit.
•Put cards away in ESD-preventive bags for future use.
Laser safety
W
ARNING!
Do not stare into any optical port or view directly with non-attenuating optical instruments when the switch
has power. The laser light emitted from the optical fiber may hurt your eyes.
The HP FlexFabric 12900 switches are Class 1 laser products.
Examining the installation site
The HP FlexFabric 12900 switches must be used indoors. To ensure the normal operation and long
service life of your switch, the installation site must meet the requirements in this section.
Weight support
Make sure the floor can support the total weight of the rack, chassis, cards, power supplies, and all other
components. To mount the switch to a rack, make sure the slide rails can support the total weight of the
switch and its accessories (cards, power supplies, and transceiver modules). When the switch is installed
with all accessories, its maximum weight is 200 kg (440.92 lb). HP recommends that you order the HP
X421 A-Series Chassis Universal 4-Post Rack Mounting Kit (JC665A), which supports a weight up to 300
kg ( 661. 3 8 l b ) .
Additionally, the floor and slide rail loading plan must also consider system expansion, such as adding
more cards. For more information, see "Appendix A Chassis views and technical specifications."

3
Temperature
CAUTION:
If condensation appears on the chassis when you move it to a high-temperature environment, dry the
chassis before powering it on to avoid short circuits.
To ensure the normal operation of the switch, make sure the room temperature meets the requirements
in Table 1.
Table 1 Temperature requirements
Tem
p
erature Ran
g
e
Operating temperature 0°C to 45°C (32°F to 113°F)
Storage temperature –40°C to +70°C (–40°F to +158°F)
Humidity
Maintain appropriate humidity in your equipment room, as described in Table 2.
•Lasting high relative humidity tends to cause poor insulation, electricity creepage, mechanical
property change of materials, and corrosion of metal parts.
•Lasting low relative humidity is likely to result in loose screws due to washer contraction, and even
electrostatic discharge (ESD), which causes the circuits to fail.
Table 2 Humidity requirements
Humidit
y
Ran
g
e
Operating humidity 10% to 95%, noncondensing
Storage humidity 5% to 95%, noncondensing
Cleanness
Dust buildup on the chassis may result in electrostatic adsorption, which causes poor contact of metal
components and contact points. In the worst case, electrostatic adsorption can cause communication
failure.
Table 3 Dust concentration limit in the equipment room
Substance Concentration limit (
p
articles/m3)
Dust particles ≤3 x 104
(No visible dust on desk in three days)
NOTE:
Dust particle diameter ≥5 μm
The equipment room must also meet strict limits on salts, acids, and sulfides to eliminate corrosion and
premature aging of components, as shown in Table 4.

4
Table 4 Harmful gas limits in an equipment room
Gas Max. (m
g
/m3)
SO20.2
H2S 0.006
NH30.05
Cl20.01
EMI
All EMI sources, from outside or inside of the switch and application system, adversely affect the switch
in a conduction pattern of capacitance coupling, inductance coupling, electromagnetic wave radiation,
or common impedance (including the grounding system) coupling. To prevent EMI, take the following
actions:
•Take measures against interference from the power grid.
•Use a grounding system and lighting protection system for the switch separate from those for other
electric equipment, and keep them far away as possible.
•Keep the switch far away from radio transmitting stations, radar stations, and high-frequency
devices.
•Use electromagnetic shielding, for example, shielded interface cables, when necessary.
Grounding
Using a good grounding system to protect your switch against lightning shocks, interferences, and ESD
is essential to the operating reliability of your switch.
Make sure the resistance between the chassis and the ground is less than 1 ohm.
For more information about grounding the switch, see "Installing the switch."
Power
Perform the following tasks to meet the power requirements:
1. Calculate the system power consumption.
The system power consumption varies by card type and density. For more information about
system power consumption calculation, see "Appendix A Chassis views and technical
specifications."
2. Identify the number of power supplies.
The total maximum output power of all power supplies must be higher than the system power
consumption. For more information about available power supplies, see "Appendix B FRUs and
compatibility matrixes."
3. Verify that the power system at the installation site meets the requirements of the power supplies,
including the input method and rated input voltage. For more information about power supply
specifications, see "Appendix B FRUs and compatibility matrixes."

5
Cooling
Plan the installation site for adequate ventilation:
•Leave at least 30 cm (11.81 in) of clearance at the inlet and outlet air vents.
•The rack for the switch has a good cooling system.
•The installation site has a good cooling system.
•Verify that the airflow design of the chassis meets the airflow design of the installation site.
Figure 1 Airflow through the 12910 AC chassis
(1) Power supply air intake vents (2) Power supply air exhaust vents
(3) Chassis air intake vents (4) Chassis air exhaust vents
Space
For easy maintenance, follow these guidelines:
•The equipment room is at least 3 m (9.84 ft) high.
•Reserve at least 1 m (3.28 ft) of clearance between the rack and walls or other devices.
1
2
3
4

6
•Make sure dimensions of the rack are sufficient for the chassis. To meet the clearance requirement,
HP recommends that you use a rack with a depth of 1.2 m (3.94 ft). You must reserve at least 155
mm (6.10 in) of clearance between the front rack post and the front door.
The depth of the switch is 1080 mm (42.52 in) by calculating together the depth of chassis, the
cable management bracket, and the power cable bracket. For more information, see Figure 2.

7
Figure 2 Clearances required for a 12910 AC chassis

8
(1) Width of the 12910 AC chassis
(2) Depth of the 12910 AC chassis
(3) Depth of the cable management bracket (4) Depth of the power cable bracket
(5) Clearance between the chassis and the front door (6) Clearance between the chassis and the rear
door
(7) Minimum requirement to the rack depth (8) Cool air intake direction
(9) Hot air exhaust direction (10) Front clearance required for replacing
modules
(11) Rear clearance required for replacin
g
modules

9
Installing the switch
IMPORTANT:
Keep the packages of the switch and the components for future use.
Confirming installation preparations
Before you install an HP FlexFabric 12900 switch, verify that:
•You have read "Preparing for installation" carefully and the installation site meets all the
requirements.
•A 19-inch rack is ready for use when you install the switch to a rack. For how to install a rack, see
the rack installation guide.
•The rack is sturdy and securely grounded.
•No debris exists inside or around the rack.
•Choose a correct rack mounting position for the switch. Make sure the heaviest device is placed at
the bottom of the rack.
•The total height of the switches to be installed is not higher than the available installation height of
the rack and enough clearance is reserved for cable routing.
•The switch is ready for installation and has been carried to a place near the rack and convenient for
moving.
Attaching installation accessory kits to the chassis
Accessory kits
Table 5 12910 AC accessory kits
Accessor
y
kit Descri
p
tion
Mounting bracket
Located at the two sides of the chassis to secure the chassis to the rack,
as shown in callout 1 on Figure 3. They are mounted to the chassis
when shipped.
Cable management bracket
Located at the upper part of the front panel for cabling of LPUs, as
shown in callout 2 on Figure 3. White lines on the bracket help for
cabling. The cable management bracket is mounted to the chassis
when shipped.
Power cable bracket
Install it to the lower part of the rear panel for securing power cables,
as shown in callout 2 on Figure 4. For installation of the power cable
bracket, see Attaching the power cable bracket. For connecting a
power cable, see "Installing FRUs."

10
Accessor
y
kit Descri
p
tion
Plastic panel
Install it over the air intake vents at the lower part of the front panel to
protect the power supply slots and air intake vents, as shown in callout
3 on Figure 3. Before installing the plastic panel, install power supplies
and connect power cables first. For installation of the plastic panels,
see "Attaching the plastic panel."
Figure 3 12910 AC installation accessory kits
(1) Mounting bracket (2) Cable management bracket
(3) Plastic panel (4) Power supply slot
Attaching the power cable bracket
Every 12910 AC switch provides a power cable bracket at the lower part of the rear panel to secure the
power cables.
To attach the power cable bracket:
1. Unpack the power cable bracket.
11
2
3
4

11
2. Place the power cable bracket to the chassis and align the installation holes on the bracket with
those on the chassis.
3. Fasten the screws to secure the power cable bracket.
Figure 4 Attaching the power cable bracket to the 12910 AC
(1) Screw holes (2) Power cable bracket
(3) Screw (4) Place the power cable bracket to the chassis and ali
g
n the screw holes
(5) Fasten the screws
Attaching the plastic panel
Every 12910 AC switch provides a plastic panel at the lower part of the front panel to protect the air
intake vents and power supply slots. Before installing the plastic panel, install power supplies and
connect power cables first.
To install the plastic panel:
1. Unpack the plastic panel and two clips. As shown in Figure 5, use the screws supplied with the
plastic panel to secure the clips to two sides of the air intake vents.
Skip this step if the clips have been installed to the switch.
45
1
2
3

12
Figure 5 Installing the clips
(1) Clip (2) Screw (3) Fasten the screw
2. As shown in Figure 6, press down the locking tabs on the two sides of the plastic panel, position
the plastic panel with the positioning pins on the cover, and attach it to the chassis.
Figure 6 Installing the plastic panel
Attaching slide rails and cage nuts to the rack
Installing slide rails
If the rack has slide rails, skip this section.
1
2
3

13
Before you attach slide rails to the rack, verify that:
•The slide rails can support the total weight of the switch and its accessories. For the weights of the
HP FlexFabric 12900 switches, see "Appendix A Chassis views and technical specifications."
HP recommends that you order the HP X421 A-Series Chassis Universal 4-Post Rack Mounting Kit
(JC665A). For more information about the kit, see "Appendix B FRUs and compatibility matrixes."
•The dimensions of the rack are sufficient for the chassis. To meet the clearance requirement, HP
recommends that you use a rack with a depth of 1.2 m (3.94 ft). You must reserve at least 155 mm
(6.10 in) of clearance between the front rack post and the front door.
The total depth of the switch is 1080 mm (42.52 in) by calculating together the depth of chassis,
the cable management bracket, and the power cable bracket, which are 830 mm (32.68 in), 150
mm (5.91 in), and 100 mm (3.94 in), respectively.
•To ensure stability of the rack, install the slide rails to the lowest possible position when installing a
single switch on the rack. To install multiple switches on the rack, mount the heaviest switch at the
bottom of the rack.
•Identify the rack position for the switch. For the height and other specifications of the HP FlexFabric
12900 switches, see "Appendix A Chassis views and technical specifications."
Slide rail installation varies with rack type. The following installation procedure is for your reference only.
To install a slide rail:
1. Read the signs on the slide rail (see Table 6) to avoid making a mistake.
Figure 7 Right slide rail
(1) Guide rail (2) Si
g
n (3) Installation hole
Table 6 Description of signs on the slide rails
Si
g
nMeanin
g
Remarks
F/L Front end of the left slide rail Mount this end to the front left rack post.
F/R Front end of the right slide rail Mount this end to the front right rack post.

14
2. Mark the position on the rack for installing the slide rail:
a. Make sure the bottom edge of the slide rail aligns with the middle of the narrower metal area
between holes, as shown in Figure 8.
b. Each rack post requires six screws to attach the slide rail. You only need to mark the uppermost
square hole and lowermost square hole for installation.
c. Mark the square holes at the same height on the other three rack posts.
One rack unit has three holes, the middle of which is an auxiliary installation hole, and the
other two are standard installation holes. You can distinguish them by the space between each
two holes. The space between a standard installation hole and an auxiliary installation hole is
wider than that between two adjacent standard installation holes.
Figure 8 Locating the rack position for installing slide rails
(1) Middle of the narrower metal area between holes
3. Install six cage nuts in the square holes in each rack post:
a. Insert one edge of a cage nut into the hole, as shown in callout 1 on Figure 9.
b. Compress the other edge of the cage nut to push the cage nut fully into the hole, as shown in
callout 2 on Figure 9.
c. Repeat steps a and b to install cage nuts to all the marked positions on the right rack post.
Figure 9 Installing a cage nut
1 2
