HP ProCurve J8766A User manual

Installation Guide
www.procurve.com
ProCurve Switch vl Modules
PoE
Power over Ethernet Devices

ProCurve Switch vl Modules
Installation Guide

Hewlett-Packard Company
8000 Foothills Boulevard, m/s 5552
Roseville, California 95747-5552
http://www.procurve.com
© Copyright 2005 -2007 Hewlett-Packard Development
Company, L.P.
Publication Number
5991-8602
September 2007
Applicable Products
Disclaimer
HEWLETT-PACKARD COMPANY MAKES NO WARRANTY
OF ANY KIND WITH REGARD TO THIS MATERIAL,
INCLUDING, BUT NOT LIMITED TO, THE IMPLIED
WARRANTIES OF MERCHANTABILITY AND FITNESS
FOR A PARTICULAR PURPOSE. Hewlett-Packard shall not
be liable for errors contained herein or for incidental or
consequential damages in connection with the furnishing,
performance, or use of this material.
The information contained herein is subject to change
without notice. The only warranties for HP products and
services are set forth in the express warranty statements
accompanying such products and services. Nothing herein
should be construed as constituting an additional warranty.
HP shall not be liable for technical or editorial errors or
omissions contained herein.
Hewlett-Packard assumes no responsibility for the use or
reliability of its software on equipment that is not furnished
by Hewlett-Packard.
Warranty
See the Customer Support/Warranty booklet included with
the product.
A copy of the specific warranty terms applicable to your
Hewlett-Packard product and replacement parts can be
obtained from your HP sales and service office or
HP-authorized reseller.
ProCurve Switch 100-FX MTRJ vl Module (J8763A)
ProCurve Switch Gig-T vl Module (J8764A)
ProCurve Switch 10/100-TX vl Module (J8765A)
ProCurve Switch 24-port Gig-T vl Module (J8768A)
ProCurve Switch Mini-GBIC vl Module (J8776A)
ProCurve Switch vl 20-Port Gig-T + 4-Port SFP
Module (J9033A)
ProCurve Switch 10-GbE vl Module (J8766A)

iii
Contents
ProCurve Switch vl Modules
Descriptions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
The ProCurve Switch vl Modules have the following features: . . . 4
Installing the Modules . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Installing the Module in an Unused Slot . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Installation Precautions: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Installation Procedures: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Installing or Removing the Mini-GBICs . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Install or Remove a Transceiver . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
To remove the transceiver: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Verifying the Module is Installed Correctly . . . . . . . . . . . . . . . . . . . . . . 12
Connecting the Network Cables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Connecting the 10-GbE Network cables . . . . . . . . . . . . . . . . . . . . . 16
Verifying the Network Connections Are Working . . . . . . . . . . . . . . . . 17
Default Port Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Replacing or Removing a Module . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Resetting the Switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Reasons for Resetting the Switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Methods of Resetting the Switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
LED Error Indicators: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Diagnostic Tips: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Customer Support Services . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Environmental . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Lasers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

iv
Cables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Twisted-Pair Cables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Fiber-Optic Cables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Fiber-Optic Cables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Copper 10-GbE Cables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Optical Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
ProCurve 10-GbE X2-SC SR optic . . . . . . . . . . . . . . . . . . . . . . . . . . 31
ProCurve 10-GbE X2-SC LR optic . . . . . . . . . . . . . . . . . . . . . . . . . . 31
ProCurve 10-GbE X2-SC ER optic . . . . . . . . . . . . . . . . . . . . . . . . . . 32
ProCurve 10-GbE X2-CX4 Transceiver . . . . . . . . . . . . . . . . . . . . . . 33
Mode Conditioning Patch Cord for Gigabit-LX . . . . . . . . . . . . . . . . . . . . . . 34
Installing the Patch Cord . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
EMC Regulatory Statements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
U.S.A. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Canada . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Australia/New Zealand . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Japan . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Korea . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Taiwan . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
European Community Declaration of Conformity . . . . . . . . . . . . . . . . 37
Waste Electrical and Electronic Equipment (WEEE) Statements . . . . . . . 38

1
ProCurve Switch vl Modules
Descriptions
ProCurve Switch vl Modules
For the ProCurve Series 4200vl Switches
Descriptions. The ProCurve Switch vl Modules are components that you can
add to a ProCurve vl switch to provide a variety of network connectivity
options.
The following ProCurve vl switches are available as of this printing:
■ProCurve Switch 4204vl (J8770A), a chassis with four open slots.
■ProCurve Switch 4208vl (J8773A), a chassis with eight open slots.
■ProCurve Switch 4202vl-48G (J8771A), a chassis with 48 fixed 10/100/
1000-T ports plus two open slots.
■ProCurve Switch 4202vl-72 (J8772A), a chassis with 72 fixed 10/100-TX
ports plus two open slots.
The following vl modules are available as of this printing:
Module Description
ProCurve Switch vl
24-Port 10/100-TX
Module
(J8765A)
24 twisted-pair ports with RJ-45
connectors for 10 Mbps or 100
Mbps operation over 100-ohm
unshielded(UTP)orshielded(STP)
twisted-pair cable -- all ports have
the HP Auto MDI-X feature.
ProCurve Switch vl
4-Port Mini-GBIC
Module (J8776A)
4 slots for installing any of the
supported ProCurve mini-GBICs*.
*Supported mini-GBICs: The following ProCurve mini-GBICs are supported by the mini-GBIC vl Module
(as of this printing):
• Gigabit-SX LC mini-GBIC (J4858B, J4858C)
• Gigabit-LX LC mini-GBIC (J4859B, J4859C)
• Gigabit-LH LC mini-GBIC (J4860B, J4860C)
• 1000Base-T mini-GBIC (J8177B)

2
ProCurve Switch vl Modules
Descriptions
Contact your ProCurve authorized networking reseller or your ProCurve
representative for information on availability of other products. You can also
visit the ProCurve Web site at www.procurve.com to get more information.
ProCurve Switch vl
12-Port 100-FX MTRJ
Module
(J8763A)
12 100-FX ports with MT-RJ
connectors for 100 Mbps
networking over multimode
fiber-optic cable.
ProCurve Switch vl 16-
Port Gig-T Module
(J8764A)
16 twisted-pair ports with RJ-45
connectors for 10/100/1000 Mbps
operationoverCategory5orbetter
100-ohm UTP or STP cable
(category 5e recommended for
Gigabit) -- all ports have the IEEE
802.3ab Auto MDI/MDI-X feature.
ProCurve Switch vl
24-Port Gig-T Module
(J8768A)
24 twisted-pair ports with RJ-45
connectors for 10/100/1000 Mbps
operationoverCategory5orbetter
100-ohm UTP or STP cable
(category 5e recommended for
Gigabit) -- all ports have the IEEE
802.3ab Auto MDI/MDI-X feature.
ProCurve Switch vl 20-
PortGig-T+4-PortSFP
Module (J9033A)
See page 1 for
supported mini-GBICs
and this module also
supports the J9054B
ProCurve 100-FX SFP-
LC Transceiver.
20 twisted-pair ports with RJ-45
connectors for 10/100/1000 Mbps
operationoverCategory5orbetter
100-ohm UTP or STP cable
(category 5e recommended for
Gigabit) -- all ports have the IEEE
802.3ab Auto MDI/MDI-X feature,
plus 4 mini-GBIC or SFP ports.
ProCurve Switch vl
1-Port 10-GbE Module
(J8766A)
1 port for installing any of the
supported ProCurve 10 Gig X2
transceivers.**
**Supported transceivers: The following ProCurve transceivers are supported by the J8766A vl Module (as of this
printing):
• ProCurve 10-GbE X2-SC SR Optic (J8436A)
• ProCurve 10-GbE X2-SC LR Optic (J8437A)
• ProCurve 10-GbE X2-SC ER Optic (J8438A)
• ProCurve 10-GbE X2 CX4 Xcvr (J8440B)
• ProCurve 10-GbE CX4 Optical Media Converter (J8439A)
Module Description
231 45678910 11 12
Link|Mode
100Base-FX MTRJ Po ts
123456789101112
P oCu ve
100-FX MTRJ
vl Module
J8763A
vl
Module
10/100/1000Base-T Po ts  all po ts a e HP Auto MDI-X
P oCu ve
16p Gig-T
vl Module
J8764A
vl
Module
1357 9111315
2468 10121416
P oCu ve
24p Gig-T
vl Module
J8768A
vl
Module
13 151197531 17 1 9 21 23
Link Mode Link Mode
14 161210
8642 18 20 22 24
Link Mode Link Mode
10/100/1000Base-T Po ts  all po ts a e IEEE Auto MDI/MDI-X
P oCu ve
Gig-T/SFP
vl Module
J9033A
vl
Module
13 15 11
9
7
5
3
117 19 21 23
Link Mode Link Mode
14 16 12
10
86
42 18 20 22 24
Link Mode Link Mode
10/100/1000Base-T Po ts (1 - 20)  Po ts a e IEEE Auto MDI/MDI-X
Link Mode
Link Mode
Use P oCu ve Mini-GBICs and SFPs only
!

3
ProCurve Switch vl Modules
Features
Features
The following two illustrations show the features found on the various
modules.
Figure 1. Example: ProCurve 24-Port 10/100-TX vl Module
Figure 2. Example: ProCurve Switch Mini-GBIC vl Module
network ports
Link and Mode LEDs
(one pair per port) retaining screw
Link and Mode LEDs
(one pair per port) Mini-GBIC and SFP ports

4
ProCurve Switch vl Modules
Features
Figure 3. Example: ProCurve Switch 1-port 10 Gig-X2 vl Module
The ProCurve Switch vl Modules have the following features:
■auto-enabled ports—the ports are all configured to be ready for network
operation as soon as a viable network cable is connected
■auto-configuration—a default configuration is applied to the module
when the switch is powered on and the module passes self test; this default
configuration works well for most network installations
■LEDs that provide information for each port on the link status, network
activity, connection bandwidth (speed), communication mode (half or full
duplex), and presence of specific network error packets on the port
■“hot swap modules” operation—you can add a module or replace a
module without having to shut down the switch (changing the module
type in a given slot does require a switch reset)
■“hot swap mini-GBICs” operation—you can add, replace, or change the
type of any of the mini-GBICs that you use in any of the vl Modules that
use mini-GBICs, without having to first remove the module, and without
having to shut down the switch (you must remove the network cable
before hot-swapping a mini-GBIC)
■“hot swap X2 transceiver” operation—you can add, replace, or change the
type of any of the X2 transceivers that you use in the 10-GbE vl Module,
without having to first remove the module, and without having to shut
down the switch (you must remove the network cable before hot-swap-
ping a transceiver)
port covers
Link and Mode LEDs

5
ProCurve Switch vl Modules
Installing the Modules
■the ports on the 10/100-TX vl Module have the HP Auto MDI-X feature,
and the ports on the Gig-T vl Module have the IEEE 802.3ab Auto MDI/
MDI-X feature. These features operate the same way and allow you to
use either straight-through or crossover twisted-pair cables for all the
twisted-pair network connections. Please see the note on “Automatic
Cable Sensing” on page 13.
■standards adherence:
• the 10/100-TX vl Module is compatible with the IEEE 802.3
10Base-T and IEEE 802.3u 100Base-TX standards
• the Gig-T vl Module is compatible with the IEEE 802.3 10Base-T, IEEE
802.3u 100Base-TX, and IEEE 802.3ab 1000Base-T standards
• the ports on the mini-GBICs that are installed in any of the vl Modules
that accept mini-GBICs are compatible with the IEEE 802.3z
standards
• the ports on the 100-FX MTRJ vl Module are compatible with the IEEE
802.3u 100-FX standard
• the RJ-45 ports on the 20-port Gig-T + 4 port SFP module are compat-
ible with the IEEE 802.3 10Base-T, IEEE 802.3u 100Base-TX, and IEEE
802.3ab 1000Base-T standards, and the 4 SPF ports are compatible
with the IEEE 802.3z standards
Installing the Modules
Overview
You can install any of the vl modules into any of the ProCurve vl switches. The
modules can be installed into the switch either with the switch powered on
or off. The following procedures assume the switch is powered on.
1. Install the modules in a switch slot (see page 7).
If you have installed any modules into slots that were previously occupied
by a different type module, you need to reset the switch (see page 20).
2. If you are using the mini-GBIC vl Module, or the Gig-T/SFP vl Module,
install the mini-GBICs in the module. You can install the mini-GBICs
before or after installing that module into the switch (see page 9).

6
ProCurve Switch vl Modules
Installing the Modules
Note The mini-GBICs can be “hot swapped”. That is, they can be installed or
removed after the mini-GBIC vl Module, or the Gig-T/SFP vl Module, is
installed in the switch and the module is receiving power. The network cable
must be removed from the mini-GBIC before installing or removing a mini-
GBIC. For more information, see page 9.
3. Verify the modules are installed correctly (see page 12).
4. Connect the network cabling (see page 13).
5. Verify the network connections are working properly (see page 17).
6. Optionally, customize the port configuration for each module unless the
default port configuration is satisfactory for your network application -
(see page 18).
Note You can install, exchange, or remove modules after the switch has been
powered on. Whenever a module is installed during this process, it is initialized
and tested for correct operation. During this process, the switch Self Test LED
is on. If you hot swap another module while the switch is initializing and
testing the first module, it is possible to cause the first module or the entire
switch to be reset. For more information, see page 19.
To prevent the modules or switch from being reset when you must hot swap
multiple modules, follow these precautions:
■Do not install/remove any modules from the switch while the switch Self Test
LED is lit.
■Before removing or installing any modules, make sure that all network cables
are disconnected from the module.

7
ProCurve Switch vl Modules
Installing the Modules
Installing the Module in an Unused Slot
Installation Procedures:
1. Use a Torx T-10 or flat-bladed screwdriver to unscrew the screws in the
cover plate over the slot you want to use, and remove the cover. Store the
cover plate for possible future use.
2. Hold the module by its bulkhead—taking care not to touch the metal
connectors or components on the board.
3. As shown in the illustrations on the next page, insert the module into the
slot guides and slide it into the slot until it stops. Then press near the two
screws on the module bulkhead to seat the module connector into the
switch backplane. The module bulkhead should be in contact with or very
close to contact with the front face of the switch.
4. Screw in the two retaining screws to secure the module in place. The
screws should be tightened until they are secure, but not overtightened.
Installation Precautions:
■Static electricity can severely damage the electronic components on the modules. When
handling and installing the modules in your switch, follow these procedures to avoid damage
from static electricity:
• Handle the module by its bulkhead or edges and avoid touching the components and the
circuitry on the board.
• When installing the module, equalize any static charge difference between your body and
the switch by wearing a grounding wrist strap and attaching it to the switch’s metal body,
or by frequently touching the switch’s metal body.
■The ProCurve Switch vl Modules have “low-force”, high-performance connectors. High inser-
tion forces are not necessary to install the modules, and should not be used.
■Ensure you fully insert the modules.That is, press the module into the slot until the bulkhead
on the module is contacting or is very close to contacting the front face of the switch chassis.
■Once the module is fully inserted, make sure that you screw in the two retaining screws to
secure the module in place.
■For safe operation, proper switch cooling, and reduction of electromagnetic emissions, ensure
that a slot cover is installed on any unused module slot. For safety, no more than one slot at a
time should be uncovered to install a module, when the switch is powered on.

8
ProCurve Switch vl Modules
Installing the Modules
Figure 4. Installing a Module
For best results, push
simultaneously near both
screws.
“Low-force” connector.
High insertion force is not
needed and should not be
used.
Insert module into the guides
and slide it in until it is fully
inserted.

9
ProCurve Switch vl Modules
Installing the Modules
Figure 5. Tighten module retaining screws
Installing or Removing the Mini-GBICs
Note Hot swapping mini-GBICs is supported. You can install or remove a mini-GBIC
with the switch powered on, a reset will not occur.
You can install or remove the mini-GBIC from the mini-GBIC vl Module, or the
Gig-T/SFP vl Module, without having to power off the switch. Use only
ProCurve mini-GBICs with the letter “B” (or greater) at the end of the product
number (for example, J4858B or J4860C).
WARNING The ProCurve fiber optic mini-GBICs are Class 1 laser devices. Avoid
direct eye exposure to the beam coming from the transmit port.
Then tighten the retaining screws
onthemoduleuntiltheyare secure,
but do not overtighten them.
The module is fully inserted when
the module bulkhead is contacting,
or very close to contacting
the face of the switch.

10
ProCurve Switch vl Modules
Installing the Modules
Caution Use only supported genuine ProCurve mini-GBICs with your switch. Non-
ProCurve mini-GBICs are not supported, and their use may result in product
malfunction. Should you require additional ProCurve mini-GBICs, contact
your ProCurve Networking Sales and Service Office or authorized dealer.
Installing the mini-GBICs:
Hold the mini-GBIC by its sides and gently insert it into any of the slots in the
module until the mini-GBIC clicks into place.
Figure 6. Installing/removing a mini-GBIC
Removing the mini-GBICs:
The network cable should be disconnected from the mini-GBIC before
removing it from the module.
Depending on when you purchased your ProCurve mini-GBICs, it may have
either of three different release mechanisms: a metal latch, a wire bail, or a
plastic collar around the mini-GBIC.
To remove the mini-GBICs that have the plastic collar, push inthe plastic collar
toward the switch until you see the mini-GBIC release from the switch (you
can see it move outward slightly), and then pull the mini-GBIC from the slot.
To remove the mini-GBICs that have the wire bail or metal latch, lower the
bail or latch until it is approximately horizontal, and then using the bail or
latch, pull the mini-GBIC from the slot.

11
ProCurve Switch vl Modules
Installing the Modules
Install or Remove a Transceiver
Note Hot swapping transceivers is supported. You can install or remove a trans-
ceiver with the switch powered on, a reset will not occur.
a. Slide the transceiver in until it stops.
Figure 7. Installing an X2 transceiver
b. Push firmly until the gasket seats against the bulkhead. The transceiver
should “click” into place.
Figure 8. X2 transceiver fully installed
Note If the switch is powered on when the transceiver is installed, the Link and
Mode LEDs will come on for approximately two seconds and then go off. This
is confirmation the transceiver is completely seated.
c. If your transceiver has a bail, move the bail up, if not your transceiver is
now completely installed.
Refer to page 30 for more transceiver details.
To remove the transceiver:
If your transceiver has a bail, lower the bail until it is approximately horizontal,
and then using the bail, pull the transceiver from the slot. If your transceiver
does not have a bail, pull the transceiver straight out.

12
ProCurve Switch vl Modules
Installing the Modules
Verifying the Module is Installed Correctly
Observe the Module Status LED for the slot in which the module is being
installed, and the Self Test and Fault LEDs on the switch to verify the module
is installed properly.
Figure 9. Checking LEDs for correct installation
When the module is installed properly and the switch is powered on, or the
module is installed when the switch already has power, the module undergoes
a self test that takes a few seconds. You can use the LEDs to determine that
the module is installed properly and has passed the self test, as described in
the “LED Behavior” table below.
LED Behavior
Powe
Status
Modules LED Mode
Fan
FDx Act
1 2 A B
!
Use
vl Modules
only
P oCu ve
Switch 4202v l
J8772A
CleaReset
Console Auxilia y Po t
Self Test
11
9
7
53
1
Link Mode
12642
Link Mode 108
1
Link
1
Link
35
33
31
2927
25
Link Mode
36
30
28
26
Link Mode 34
32
3
Link
3
Link
59
57
55
5351
49
Link Mode
6
Link
10/100Base-TX Po ts (1-72)  all po ts
Spd
Powe
Fault
Spd mode: off = 10 Mbps
flash = 100 Mbps
on = 1000 Mbps
ProCur ve
10/100-TX
vl Module
J8765A
vl
Module
13 15 1197
5
31 17 19 21 23
Link Mode Link Mode
14 16 12108
6
42 18 20 22 24
Link Mode Link Mode
10/100Base-TX Por ts — all ports are HP A uto MDI- X
A
Module Link and Mode
LEDs
Module Status LEDs
Self Test LED
Fault LED
LED Display for a Properly Installed Module
Module Status (for the slot in which you are installing the module) The LED goes
ON as soon as the module is installed and the switch is powered on,
and stays ON steadily.
Self Test ON briefly while the module is being tested, then OFF.
Note: If the switch was powered off while the module was installed,
when the switch is powered on, the Self Test LED will stay ON for
the duration of the whole switch self test.
Fault OFF
Link and Mode (on
the modules) For a module that is installed when the switch is already powered on (hot swap), all the Link and Mode LEDs on the module go ON for
approximately 3 to 10 seconds, then OFF for 5 to 10 seconds
depending on the module.
If the module is already installed when the switch is powered on or
reset, the process described above occurs approximately 30
seconds after the power on or reset, during which time the switch
is being tested.

13
ProCurve Switch vl Modules
Installing the Modules
Connecting the Network Cables
Note Automatic Cable Sensing on Twisted-Pair Ports:
When the ports for the 10/100-TX and the Gig-T vl Modules are in their default
configuration, Auto, both modules automatically negotiate whether the ports
operate as MDI or MDI-X, depending on the cable type and the connected
device’s operation. As a result, you can use either straight-through or
crossover twisted-pair cables for all network connections to these modules.
On the 10/100-TX vl Modules, this feature is identified as HP Auto MDI-X; on
the Gig-T vl Module, it is identified as IEEE Auto MDI/MDI-X and it is part
of the IEEE 802.3ab standard. Both features operate the same.
Operation of this feature depends on the port configurations being kept at
Auto. If the configuration is changed to one of the available fixed options (for
example, 100-Full Duplex), the port operates as an MDI-X port. In that case,
to connect the module to another switch or hub, use a crossover cable; to
connect to an end node, use a straight-through cable.

14
ProCurve Switch vl Modules
Installing the Modules
Connect the appropriate network cables to the module's ports as shown in
the table below. For more information on the cable specifications, see
“Cables” on page 28.
Supported Cable Types
Module Cable Type Maximum Length
10/100-TX, Gig-T, and Gig-T/SFP vl Modules 10 Mbps operation:
category 3, 4, or 5,
100-ohm balanced
twisted-pair cable
100 meters
(recommended)
100 Mbps operation:
category 5, 100-ohm
balanced twisted-pair
cable
100 meters
1000 Mbps (Gigabit)
operation: category
5e, 100-ohm cable is
recommended,
although category 5
cable may also work.
100 meters
Notes:
• The RJ-45 ports on this module have the HP Auto MDI-X feature. In the default configuration, Auto, either a straight-
through or crossover cable can be used to connect the port to any other 1000Base-T, 100Base-TX or 10Base-T device.
See the Note on page 13.
• Since the 10Base-T operation is through the 10/100Base-TX or 10/100/1000-T ports, if you ever want to upgrade the
ports to 100Base-TX, it would be best to cable the ports initially with category 5 cable or better.
100-FX MTRJ vl Module multimode fiber-optic
cables fitted with
MT-RJ connectors.
See “Fiber-Optic
Cables” on page 29 for
more information.
• full-duplex connec-
tions: 2 kilometers
• half-duplex connec-
tions: 412 meters
Continued on the next page.
ProCur ve
10/1 00-T
vl Module
J8765A
13 15 1197
5
31
Link Mode Link Mode
14 16 12108
6
42
Link Mode Link Mode
10/1 00Base-TX P orts — all ports are HP A uto MDI-
X
twisted-pair
cable with
RJ-45
connector
RJ-45 ports with
“HP Auto MDI-X”
2 31 4 5 6 7 8 9 10 11 12
Link|Mode
100Base-FX MTRJ P or ts
123456789101112
ProCurve
100-FX MTRJ
vl Module
J8763A
vl
Module
100-FX ports with
MT-RJ connectors
multimode fiber-optic cable
with MT-RJ connector
