Stamp Aligner™XL
No. SA-7XL
HPC’s Stamp Aligner™XL solves the problems that locksmiths
have while stamping keys and cylinders. It has one 1/4"
(6.35mm) hole to hold standard 3⁄32" (2.5mm) and 1⁄8" (3.0mm)
number and letter die stamps. Characters can be stamped on
keys and cylinders in an exact straight line with exact spacing
between figures. When the die stamps are all struck with the
same force, the end product looks like it was factory stamped.
HPC’s new Stamp Aligner™XL holds 2 keys or cylinders, and
makes stamping safer and easier. Plus, it can use the die
stamps that many locksmiths already have.
1. Depress the index block release pin and move the index
block to the load/unload position. Loosen the clamp plate
knob by turning it counterclockwise. See Fig. 1.
2. Position your key under the clamp plate and secure it by
tightening the knob clockwise. See Fig. 2.
3. Adjust the index block to desired row for stamping and
secure it with the locking knob. See Fig. 3.
012204 35T00-285-00
Fig. 3
Fig. 1
(continued)
LETTER STAMP DIE SET
HPC No. HCL-1⁄8 or HCL-3⁄32
(available separately)
FIGURE STAMP DIE SET
HPC No. HCF-1⁄8 or HCF-3⁄32
(available separately)
LOCKING
BOLT
INDEX
BLOCK
UNIVERSAL
STAMPING
PLATE
BENCH
MOUNTING
HOLES
CLAMP
PLATES
BASE
LOCKING
BOLT
Fig. 2
3/16 - INCH
HEX WRENCH SCHLAGE OR BEST I. C. PLATES
(available separately)
SCHLAGE NO. SA-PLT-SCH
BEST I.C. NO. SA-PLT-ICB
INDEX BLOCK
RELEASE PIN
LOCKING
KNOB

Stamp Aligner™XL instructions (continued)
©2004 • HPC, Inc. • Schiller Park, IL • 60176 • USA • www.hpcworld.com
4. Insert the chosen die into the index block. See Fig. 4.
5. Strike the stamp with your hammer. Continue by moving the index block after each desired character has been stamped. See Fig. 5.
6. Note the centering of the type when stamping. See Fig. 6.
7. The Stamp Aligner™XL can hold two key blanks or standard mortise cylinders at a time for stamping. See Fig. 7.
8. To stamp cylinders, remove the stamping plate to access the cylinder holes. Use the set screws to secure the cylinder in place. See
Fig. 8.
9. To use the optional Schlage or Best I. C. stamping plates, loosen the 2 locking bolts (you do not need to remove them). Remove the
universal stamping plate, replace with the Schlage or Best I. C. stamping plate, and tighten the locking bolts. See Fig. 9.
Fig. 5
Fig. 6 Fig. 7
Fig. 8
Fig. 4
FOR
SCHLAGE
STAMPING BED REMOVED
FOR STANDARD MORTISE CYLINDERS
FOR BEST
IC CORE CYLINDERS Fig. 9
LOCKING
BOLTS
SET
SCREW
SET
SCREW
