HQ CorTemp HT130003 User manual

CorTemp®
Data Recorder v4.3
9001 Series
HT130003
HT130030
HT130042
HT130043
User Manual

HT130003 / HT130042
HT130030 / HT130043
User Manual
CorTemp®
Data Recorder v4.3
9001 Series
Table of Contents
I. Overview ......................................................................................................... 1
II. Accessories and Interfacing Equipment.......................................................... 2
III. CorTemp®Data Recorder – Standard Menu................................................. 4
A. Programming the Data Recorder – Standard Menu ............................. 4
A.1. Battery Installation ....................................................................... 4
A.2. Using the Keypad – Standard Menu.......................................... 5
A.3. Turning ON the Data Recorder.................................................... 6
A.4. Exit / Standby Mode ..................................................................... 6
Accessing the Standard Programming Menus...................... 7
Accessing AUTO RUN MODE .............................................. 7
Turning OFF the Data Recorder ........................................... 7
A.5. Date and Time ............................................................................. 7
A.6. Temperature Collection Interval .................................................. 8
A.7. High / Low Temperature Alarms................................................... 8
A.8. Data Transfer............................................................................... 9
A.9. PC LINK....................................................................................... 9
A.10. Temperature Scale ...................................................................... 10
A.11. RF / Real Time Option.................................................................. 10
A.12. Initializing the Data Recorder ...................................................... 11
A.13. Clearing Data............................................................................... 11
A.14. Adding Sensors ........................................................................... 12
A.15. Changing Active Sensor .............................................................. 13
A.16. ID Number ................................................................................... 13
A.17. Sensor Test ................................................................................. 13
A.18. Resetting LBAT ........................................................................... 14
A.19. Low Battery Detector ................................................................... 15
A.20. Signal Detector ............................................................................ 16
A.21. Heart Rate Interval ...................................................................... 16
A.22. High / Low Heart Rate Alarms ...................................................... 17
A.23. Sports Mode ................................................................................ 18
A.24. Barcode ....................................................................................... 18
A.25. Time R3.X Option ........................................................................ 19
A.26. Sports Menu Option..................................................................... 20
B. Monitoring Core Body Temperature – Standard Menu ......................... 20
B.1. Administering the Sensor and Checking the Signal .................. 21
B.2. Placement of the Data Recorder ............................................... 21
B.3. Data Collection .......................................................................... 22
B.4. Use of More than One Sensor................................................... 23
B.5. Event Markers in AUTO RUN MODE........................................ 23
B.6. Signal Interference .................................................................... 23
B.7. MEM Message .......................................................................... 24
C. Monitoring Heart Rate – Standard Menu .............................................. 24
D. Downloading Data – Standard Menu .................................................... 24

HT130003 / HT130042
HT130030 / HT130043
User Manual
CorTemp®
Data Recorder v4.3
9001 Series
D.1. Connecting the Data Recorder to a PC / Laptop........................ 24
D.2. Downloading Data to CorTrack®II Software.............................. 25
IV. CorTemp®Data Recorder – Sports Menu ..................................................... 26
A. Programming the Data Recorder – Sports Menu.................................. 26
A.1. Battery Installation..................................................................... 26
A.2. Using the Keypad – Sports Menu............................................ 27
A.3. Turning ON the Data Recorder ................................................. 28
A.4. Sports Menu Screen.................................................................. 28
Accessing PC LINK............................................................... 29
Accessing SPORTS MODE .................................................. 29
Accessing the Sports Programming Menus .......................... 29
Accessing the Standard Programming Menus...................... 30
Turning OFF the Data Recorder ........................................... 30
A.5. Resetting LBAT ......................................................................... 31
A.6. Sports Menu Option .................................................................. 31
A.7. Adding Sensors ......................................................................... 32
A.8. Sensor Test ............................................................................... 32
B. Monitoring Core Body Temperature – Sports Menu ............................. 33
B.1. Administering the Sensor and Checking the Signal .................. 33
B.2. Placement of the Data Recorder ............................................... 34
B.3. Data Collection .......................................................................... 34
B.4. Use of More than One Sensor................................................... 35
B.5. Signal Interference .................................................................... 35
B.6. MEM Message .......................................................................... 35
C. Monitoring Heart Rate – Sports Menu .................................................. 35
D. Downloading Data – Sports Menu ........................................................ 36
D.1. Connecting the Data Recorder to a PC / Laptop........................ 36
D.2. Downloading Data to CorTrack®II Software.............................. 36
V. Troubleshooting .............................................................................................. 37
VI. Customer Service............................................................................................ 38
Limited Warranty..................................................................................... 38
Service .................................................................................................... 38
Calibration............................................................................................... 38
Appendix 1: Standard Menu Progression .............................................................. 39
Appendix 2: Sports Menu Progression................................................................... 42
Appendix 3: Data Interpretation Key ...................................................................... 43
Appendix 4: Default Parameters ............................................................................ 44

1
HT130003 / HT130042
HT130030 / HT130043
User Manual
CorTemp®
Data Recorder v4.3
9001 Series
I. Overview
The CorTemp®Data Recorder used in conjunction with a HQI Temperature Sensor
provides a complete electronic thermometer system that is easy to use and provides
accurate core body temperature measurements (± 0.1°C). The system uses an ingestible,
wireless sensor, which transmits a signal via a near-field magnetic link to the data recorder.
This system has obvious advantages over a "wired probe", for monitoring individuals
performing strenuous activities or working in hazardous environments.
The recorder captures the core body temperature of single or multiple subjects while
participating in sports, working in hazardous conditions, or participating in research
activities in two different modes of monitoring / data collection:
AUTO RUN MODE – CorTemp®Data Recorder is worn by the monitored subject
while data is collected at user programmable intervals.
SPORTS MODE – CorTemp®Data Recorder is held by an athletic trainer taking
individual readings of single or multiple players.

2
HT130003 / HT130042
HT130030 / HT130043
User Manual
CorTemp®
Data Recorder v4.3
9001 Series
II. Accessories and Interfacing Equipment
The following accessories may be packaged with your CorTemp®Data Recorder
(e.g. HT150001, HT150016, HT150032, or HT150033):
Accessories Part # Description
Data Recorder Pouch
HT300001
Soft pouch with belt loop for
wearing Data Recorder.
(AUTO RUN MODE)
Data Recorder Storage Case
HT300002 Molded plastic carrying case
for Data Recorder.
Data Transfer Cable
HT340004
Allows communication
between the Data Recorder
and a PC / Laptop.
CorTrack®II Software
via Downloaded file
Software interface between
Data Recorder and PC /
Laptop.
Polar®T31 (Non-Coded) HR Belt
(Heart Rate Option)
HT300005 Transmits heart rate signal.

3
HT130003 / HT130042
HT130030 / HT130043
User Manual
CorTemp®
Data Recorder v4.3
9001 Series
Interfacing Equipment Product # Description
Barcode Scanner System
HT150025
Provides faster input of Serial
& Calibration #s.
Eliminates data entry errors.
Scans Barcode via LED Beam.
Data Recorder Alarm
HT150008
Audio / Visual alarm that can
be positioned on the monitored
subject up to 3ft. from the Data
Recorder.
(AUTO RUN MODE)
RF Remote Unit
HT150009
(914Mhz)
OR
HT150014
(433Mhz)
Transmits data via a radio
frequency (RF) to a
RF Central Base Station or a
PDA–RF Base Unit.
Belt clip attachment to subject.
D TO A Temperature Converter
HT150061
Converts Real Time
temperature output of Data
Recorder to a correlated
voltage for input into analog
devices.

4
HT130003 / HT130042
HT130030 / HT130043
User Manual
CorTemp®
Data Recorder v4.3
9001 Series
III. CorTemp®Data Recorder – Standard Menu
The CorTemp®Data Recorder receives the signal from the HQI
Temperature Sensor and converts the signal frequency into
digital temperature data. This temperature data is displayed on
the recorder LCD screen with a resolution of 0.01 degree. The
recorder operates within environments between 10 and 50
degrees Celsius. The temperature / heart rate is sampled at
user programmable intervals and displayed for real time
monitoring, while simultaneously saving to memory for future
download and analysis.
The recorder can be programmed as a standalone unit with the
keypad, or it can be programmed by the CorTrack®II Software
from your PC / Laptop. The recorder can be programmed with
up to 99 sensor calibration numbers and record / store up to
25,000 readings. The recorder can be used as an ambulatory
unit (AUTO RUN MODE) to collect temperature / heart rate data
for extended periods from one subject, or as a handheld unit
(SPORTS MODE) to collect individual temperature / heart rate
readings from multiple players, easily switching back and forth
between players (active sensors). The data, when
downloaded, displays the active sensor (player) number, the date of the collection period,
and time correlated temperature / heart rate readings.
A. Programming the Data Recorder – Standard Menu
A.1. Battery Installation
The recorder operates on a 9V alkaline battery. Energizer®, Duracell®, or Ultralife®brands
of battery are recommended. The battery will provide approximately 110 hours of
continuous recording at 10 second intervals and can last up to 336 hours (14 days),
depending on the sampling interval.
To install the battery in the recorder, do the following:
1. Press down on the battery compartment release button; while pressing down, slide the
battery compartment cover towards the bottom of the detector. (Figure 1)
2. Connect the battery connector to the 9V battery. (Figure 2)
3. Insert the battery into the battery compartment. (Figure 3)
4. Attach the battery cover by aligning the cover with the housing, then slide the cover up
until it latches closed. (Figure 4)
Figure 2 Figure 3Figure 1 Figure 4
Back View
Battery Compartment
Cover
Battery Compartment
Release Button

5
HT130003 / HT130042
HT130030 / HT130043
User Manual
CorTemp®
Data Recorder v4.3
9001 Series
A.2. Using the Keypad – Standard Menu
Throughout Section III of this manual, we will refer to specific keys on the keypad. Before
continuing with Section III, take a few moments to observe the keypad and its functions in
relation to the STANDARD MENU.
Key Description
MENU From the EXIT / STBY mode, pressing MENU will gain access to
the Standard Programming Menus.
ENTER From the Standard Programming Menus, pressing ENTER
returns the recorder to the EXIT / STBY mode.
READ
From the Standard Programming Menus, pressing READ will
move to the next Standard Programming Menu screen. From
the AUTO RUN MODE, pressing READ will take a manual
reading.
RUN / STOP
From the EXIT / STBY mode, pressing RUN / STOP begins
AUTO RUN MODE. From AUTO RUN MODE, pressing RUN /
STOP ends AUTO RUN MODE. From PC LINK, pressing RUN /
STOP ends PC LINK.
F1 While in the Standard Programming Menus, pressing F1 selects
the option at the top of the screen.
F2 While in the Standard Programming Menus, pressing F2 selects
the option at the bottom of the screen.
0 – 9 Numeric input for the Standard Programming Menus. From the
AUTO RUN MODE, pressing 0 – 9 will initiate an Event Marker.

6
HT130003 / HT130042
HT130030 / HT130043
User Manual
CorTemp®
Data Recorder v4.3
9001 Series
A.3. Turning ON the Data Recorder
NOTE: If the recorder has been OFF for a week or more, turn the recorder ON for
approximately 10 minutes. This allows the internal components to recharge. After
10 minutes, turn the recorder OFF. Then, after 1 minute, turn the recorder back ON
and initialize the Data Recorder. (Refer to Section III, Part A.12.: Initializing the Data
Recorder).
To turn ON the recorder, do the following:
1. Once the battery has been installed turn the ON / OFF switch to the ON position.
2. The recorder will run a self-test. During the self-test, screens similar to the following
will display. The Firmware Revision #, Heart Rate option, and System Frequency are
noted as below. The system frequency for HT130003 / HT130042 is 262kHz and no
system frequency is displayed on the recorder LCD, while the system frequency for
HT130030 / HT130043 is 300kHz and the system frequency is displayed on the
recorder LCD.
3. On completion of the self-test, the date and time will appear briefly. The date
represents the last programmed date and the time represents the current time. Verify
that the date is not 00-00-00 and that the time is correct.
A.4. Exit / Standby Mode
EXIT / STBY mode allows the user to access the Standard Programming Menus, initiate
AUTO RUN MODE, and TURN OFF the recorder.
CorTemp®
CorTemp®
CorTemp®
CorTemp®
CorTemp®
Heart Rate RecorderNon-Heart Rate Recorder
Heart Rate DesignationFirmware Revision # System Frequency

7
HT130003 / HT130042
HT130030 / HT130043
User Manual
CorTemp®
Data Recorder v4.3
9001 Series
Accessing the Standard Programming Menus
To access the Standard Programming Menus, do the following:
1. From EXIT / STBY mode, press MENU.
2. Press READ to progress through the Standard Programming Menus.
3. Press ENTER on any of the Standard Programming Menus to return to EXIT / STBY
mode.
Accessing AUTO RUN MODE
AUTO RUN MODE allows the user to take Temperature / Heart Rate readings at a set
temperature collection interval.
To initiate AUTO RUN MODE, do the following:
1. From EXIT / STBY mode, press RUN / STOP.
2. Temperature / Heart Rate readings will display at the end of the set interval.
To terminate AUTO RUN MODE, press RUN / STOP.
Turning OFF the Data Recorder
To turn OFF the recorder, do the following:
1. From EXIT / STBY mode, press F1.
2. A TURN OFF UNIT message will display.
3. Turn the recorder ON / OFF switch to the OFF position.
A.5. Date and Time
To program the date and time, do the following:
1. From EXIT / STBY mode, press MENU.
AUTO RUN MODE
Temperature Readin
g
AUTO RUN MODE
Temperature Readin
g
with Heart Rate
CorTemp®CorTemp®
CorTemp®

8
HT130003 / HT130042
HT130030 / HT130043
User Manual
CorTemp®
Data Recorder v4.3
9001 Series
2. The DATE / TIME screen will display.
3. Press F1 to program the DATE.
4. Enter the Date (mm-dd-yy). NOTE: Default is 00-00-00.
5. Press F2 to program the TIME.
6. Enter the Time (hh:mm:ss). NOTE: Default is 00:00:00. A 24HR format is used,
for example 6:00pm would be entered and displayed as 18:00:00.
7. Press ENTER to return to EXIT / STBY mode.
NOTE: The recorder does not display a changing date, but counts hours and days
from when the date was last entered to keep an accurate elapsed-day record. The
date initially entered will display in the downloaded data as well as all changed dates
with corresponding "H" markers. To display the actual date, simply re-enter the
date. (Refer to Appendix 3: Data Interpretation Key).
A.6. Temperature Collection Interval
The temperature collection interval can be programmed anywhere between every
10 seconds to once every 24 hours (23:59:59). Data is collected at the END of the set
interval. The default interval is 10 seconds. If the heart rate option is to be used, the
required minimum temperature collection interval is 20 seconds.
To program the temperature collection interval, do the following:
1. From EXIT / STBY mode, press MENU.
2. Press READ until the INTERVAL / TEMPERATURE ALARM LIMITS screen displays:
3. Press F1 to program the INTERVAL.
4. Enter the Interval (hh:mm:ss). NOTE: Default is 00:00:10.
5. Press ENTER to return to EXIT / STBY mode.
A.7. High / Low Temperature Alarms
High and Low Temperature Alarms display on the recorder screen when collected data is
outside the programmed parameters. When using a Data Recorder Alarm, this data will
activate an audio / visual alarm, while using the recorder in the AUTO RUN MODE.
To program the high / low temperature alarms, do the following:
1. From EXIT / STBY mode, press MENU.
CorTemp®
CorTemp®

9
HT130003 / HT130042
HT130030 / HT130043
User Manual
CorTemp®
Data Recorder v4.3
9001 Series
2. Press READ until the INTERVAL / TEMPERATURE ALARM LIMITS screen displays:
3. Press F2 to program the TEMPERATURE ALARM LIMITS.
4. Enter the High Limit (HL) and the Low Limit (LL). NOTE: Default is 000.0.
5. Press ENTER to return to EXIT / STBY mode.
When the alarm limit is triggered, HALRM (High Limit Alarm) or LALRM (Low Limit Alarm)
will display on the recorder screen.
A.8. Data Transfer
DATA TRANSFER allows the user to transfer collected data to terminal programs, such as
HyperTerminal.
To initiate DATA TRANSFER, do the following:
1. From EXIT / STBY mode, press MENU.
2. Press READ until the DATA TRANSFER / PC LINK screen displays.
3. Press F1 to initiate DATA TRANSFER.
4. Press RUN / STOP to terminate DATA TRANSFER.
5. Press ENTER to return to EXIT / STBY mode.
A.9. PC LINK
PC LINK allows 2-way communication between the recorder and a PC / Laptop. The
CorTrack®II Software uses PC LINK to program the recorder and download data.
To initiate PC LINK, do the following:
1. From EXIT / STBY mode, press MENU.
Temperature Reading with High Alarm Temperature Reading with Low Alarm
CorTemp®CorTemp®
CorTemp®
CorTemp®

10
HT130003 / HT130042
HT130030 / HT130043
User Manual
CorTemp®
Data Recorder v4.3
9001 Series
2. Press READ until the DATA TRANSFER / PC LINK screen displays.
3. Press F2 to initiate PC LINK.
4. Press RUN / STOP to terminate PC LINK.
5. Press ENTER to return to EXIT / STBY mode.
A.10. Temperature Scale
The recorder can be programmed to take temperature readings in either Fahrenheit (F) or
Celsius (C). The default temperature scale is Fahrenheit (F).
To set the temperature scale, do the following:
1. From EXIT / STBY mode, press MENU.
2. Press READ until the DEGREE / RF / RT screen displays.
3. Press F1 to set the DEGREE status, DEGREE will toggle between F(Fahrenheit) and
C(Celsius). NOTE: Default is F.
4. Press ENTER to return to EXIT / STBY mode.
NOTE: Always Download Data, then Clear Data before switching between
F (Fahrenheit) and C (Celsius).
A.11. RF / Real Time Option
The recorder can transmit via a serial connection to a RF Remote Unit or a PC / Laptop for
Real Time data output. The RF / RT option can be activated for these purposes.
To set the RF / RT status, do the following:
1. From EXIT / STBY mode, press MENU.
2. Press READ until the DEGREE / RF / RT screen displays.
3. Press F2 to set the RF / RT status, RF / RT will toggle between OFF and ON. NOTE:
Default is OFF.
4. Press ENTER to return to EXIT / STBY mode.
CorTemp®
CorTemp®
CorTemp®

11
HT130003 / HT130042
HT130030 / HT130043
User Manual
CorTemp®
Data Recorder v4.3
9001 Series
A.12. Initializing the Data Recorder
Initializing will clear the recorder memory of all collected temperature / heart rate data, clear
all sensor Serial / Calibration #s, and restore all default parameters. (Refer to Appendix 4:
Default Parameters).
NOTE: Always remember to download any collected data prior to initializing. Any
data not downloaded will be permanently lost.
To initialize the recorder, do the following:
1. From EXIT / STBY mode, press MENU.
2. Press READ until the INITIALIZE / CLEAR DATA screen displays.
3. Press F1 to INITIALIZE. The following screen will display:
4. Press F1 to initialize recorder. To cancel, press F2.
5. Press ENTER to return to EXIT / STBY mode.
A.13. Clearing Data
Clearing data will clear the recorder memory of all collected temperature / heart rate data.
Clearing data will NOT clear sensor Serial / Calibration #s or programmed parameters.
NOTE: Always remember to download any collected data prior to clearing data. Any
data not downloaded will be permanently lost.
To clear data from the recorder, do the following:
1. From EXIT / STBY mode, press MENU.
2. Press READ until the INITIALIZE / CLEAR DATA screen displays.
CorTemp®
CorTemp®
CorTemp®

12
HT130003 / HT130042
HT130030 / HT130043
User Manual
CorTemp®
Data Recorder v4.3
9001 Series
3. Press F2 to CLEAR DATA. The following screen will display:
4. Press F1 to clear data from recorder. To cancel, press F2.
5. Press ENTER to return to EXIT / STBY mode.
A.14. Adding Sensors
To program the recorder with the HQI Temperature Sensors, do the following:
1. From the EXIT / STBY mode, press MENU.
2. Press READ until the ADD SENSOR / SENSOR ACT screen displays.
3. Press F1 to ADD SENSOR. The following screen will display:
4. Enter the 2-digit Sensor # (Player #, 01 – 99).
5. When the Sensor # is entered, the following screen will display:
6. Press F1 to program the Serial #.
7. Enter the 6-digit Serial # from the sensor package label.
8. Press F2 to program the Calibration #.
9. Enter the 8-digit Calibration # from the sensor package label.
10. When the sensor Serial / Calibration #s have been entered, press READ to enter the
Serial / Calibration #s for the next sequential sensor. If no other sensors require
programming, press ENTER to return to the ADD SENSOR / SENSOR ACT screen.
11. Press ENTER to return to EXIT / STBY mode.
Sensor Serial / Calibration #s may be programmed into the recorder via the CorTrack®II
Software.
NOTE: If any of the calibration numbers have been entered incorrectly, temperature
readings for that sensor will be erroneous. Generally, bad temperature readings will
be so far off as to be immediately obvious. However, there are times when they are
CorTemp®
CorTemp®
CorTemp®
CorTemp®

13
HT130003 / HT130042
HT130030 / HT130043
User Manual
CorTemp®
Data Recorder v4.3
9001 Series
not. Attention to detail during data entry is critical to ensure accurate temperature
data collection.
A.15. Changing Active Sensor
The active sensor tells the recorder to assign a specific Calibration # to the sensor signal it
is receiving.
To change the active sensor, do the following:
1. From the EXIT / STBY mode, press MENU.
2. Press READ until the ADD SENSOR / SENSOR ACT screen displays.
3. Press F2 to program the ACTIVE SENSOR.
4. Enter the 2-digit Sensor # (Player #). NOTE: Default is 01.
5. Press ENTER to return to EXIT / STBY mode.
A.16. ID Number
A 9-digit ID # can be assigned to the collected data. This ID # will appear in the
downloaded data. The recorder unit # can be used as the ID # to identify which recorder
the collected data was downloaded from.
To assign an ID #, do the following:
1. From EXIT / STBY mode, press MENU.
2. Press READ until the ID# / SENSOR TEST screen displays.
3. Press F1 to program the ID #.
4. Enter the 9-digit ID #. For example, if entering recorder #0521, enter 000000521.
NOTE: Default is 000000000.
5. Press ENTER to return to EXIT / STBY mode.
A.17. Sensor Test
The SENSOR TEST function is used to check for an active sensor signal. The recorder
does not require programming of a sensor calibration # in order to check for an active
signal. The SENSOR TEST feature is system frequency dependent, a recorder with a
262kHz system frequency will only detect a 262kHz temperature sensor or EMI in the
range of 262kHz; other system frequency recorders are the same scenario.
CorTemp®
CorTemp®

14
HT130003 / HT130042
HT130030 / HT130043
User Manual
CorTemp®
Data Recorder v4.3
9001 Series
SENSOR TEST can be used
to check sensors just received or alarming in storage due to magnet shifting,
to verify that a sensor is active before administering it to a subject (player),
to test whether or not a subject (player) may have passed the sensor from the
body, or
to detect signal interference (EMI), if no sensor is present.
To test a sensor, do the following:
1. From EXIT / STBY mode, press MENU.
2. Press READ until the ID# / SENSOR TEST screen displays.
3. Press F2 to initiate SENSOR TEST.
4. The recorder will continuously check for an active signal and will display SENSOR ON
or SENSOR OFF, depending on the actual status of the signal.
5. Press ENTER to return to the ID# / SENSOR TEST screen.
6. Press ENTER to return to EXIT / STBY mode.
A.18. Resetting LBAT
The LBAT error message will display on the recorder screen when any of the following
situations occur. The recorder has a
low battery,
loses power, or
was turned off incorrectly.
Once detected, the recorder screen will continue to display LBAT until the LBAT is reset.
To reset the LBAT error message, do the following:
1. From EXIT / STBY mode, press MENU.
2. Press READ until the SET BAT / DETECT SIG screen displays.
CorTemp®
CorTemp®
CorTemp®
CorTemp®

15
HT130003 / HT130042
HT130030 / HT130043
User Manual
CorTemp®
Data Recorder v4.3
9001 Series
3. Press F1 to access SET BAT sub-menus. The screen will display LBAT RESET.
4. Press F1 to reset LBAT. The screen will display BAT OK.
5. Press ENTER to return to the SET BAT / DETECT SIG screen.
6. Press ENTER to return to EXIT / STBY mode.
A.19. Low Battery Detector
The recorder can be set to detect low battery power and display a LBAT error message.
The recorder will end data collection when it detects low battery power and will go into
sleep mode, which disrupts extended monitoring periods. This feature may not be useful in
all situations. If the battery completely drains, the recorder will shutdown, without losing
data or programmed parameters. It is important not to let the recorder stay in this condition
for an extended period of time. If the internal components discharge completely, data and
parameters will be lost.
To set the recorder to detect low battery power, do the following:
1. From EXIT / STBY mode, press MENU.
2. Press READ until the SET BAT / DETECT SIG screen displays.
3. Press F1 to access SET BAT sub-menus. The following screen will display:
4. Press F2 to set the DETECT LBAT status, DETECT LBAT will toggle between ON and
OFF. NOTE: Default is ON.
5. Press ENTER to return to the SET BAT / DETECT SIG screen.
6. Press ENTER to return to EXIT / STBY mode.
CorTemp®
CorTemp®
CorTemp®
CorTemp®

16
HT130003 / HT130042
HT130030 / HT130043
User Manual
CorTemp®
Data Recorder v4.3
9001 Series
When the recorder detects low battery power during the EXIT / STBY or AUTO RUN MODE,
the recorder screen will display LBAT. The unit will end data collection and go into sleep
mode.
A.20. Signal Detector
The recorder can be programmed to display either an obviously incorrect temperature
reading or no temperature reading when the receiver loses the sensor signal while in AUTO
RUN MODE. The Signal Detect feature can be used to eliminate confusion and facilitate
ease of data analysis. (Refer to Appendix 3: Data Interpretation Key)
To set the detect signal feature, do the following:
1. From EXIT / STBY mode, press MENU.
2. Press READ until the SET BAT / DETECT SIG screen displays.
3. Press F2 to set the DETECT SIG status, DETECT SIG will toggle between ON and
OFF. NOTE: Default is ON.
4. Press ENTER to return to EXIT / STBY mode.
When the DETECT SIG feature is turned ON, the recorder will display T = ---.--, which
records a no-read to memory. The no-read will appear as 8888.88 in the downloaded data.
A.21. Heart Rate Interval
If your recorder is equipped with the heart rate option, the recorder will show CORTEMP
HR REV 4.3H, for example, during start up.
The heart rate programming screen allows you to select the Heart Rate Interval. The
interval can be set at 1, 2 or 3 beats. The recorder will sample the selected number of
CorTemp®
CorTemp®
CorTemp®
Heart Rate Designation
CorTemp®CorTemp®
AUTO RUN MODE SPORTS MODE

17
HT130003 / HT130042
HT130030 / HT130043
User Manual
CorTemp®
Data Recorder v4.3
9001 Series
beats and extrapolate heart rate per minute based on the time it took to sample the
programmed number of beats. It is recommended that the Heart Rate Interval is set to 3 to
ensure the greatest accuracy.
NOTE: In order to monitor heart rate, the Temperature Collection Interval must be
set at a minimum of 20 seconds.
To program the heart rate interval, do the following:
1. From EXIT / STBY mode, press MENU.
2. Press READ until the H_RATE / HEART RATE ALARM LIMITS screen displays.
3. Press F1 to program the H_RATE INTERVAL.
4. Enter 0, 1, 2, or 3. NOTE: Default is 0 (OFF).
5. Press ENTER to return to EXIT / STBY mode.
A.22. High / Low Heart Rate Alarms
High and Low Heart Rate Alarms display on the recorder screen when a reading is outside
the programmed parameters. When using a Data Recorder Alarm, this reading will activate
an audio / visual alarm, while using the recorder in the AUTO RUN MODE.
To program high / low heart rate alarms, do the following:
1. From EXIT / STBY mode, press MENU.
2. Press READ until the H_RATE / HEART RATE ALARM LIMITS screen displays.
3. Press F2 to program the HEART RATE ALARM LIMITS.
4. Enter the High Limit (HL) and the Low Limit (LL). NOTE: Default is 000.0
5. Press ENTER to return to EXIT / STBY mode.
When the alarm limit is triggered, ♥ALRM will display on the recorder screen.
NOTE: If a temperature HALRM or LALRM is present, the ♥ALRM will NOT display.
Heart Rate Reading below Low Limit Temperature & Heart Rate Readings are above
respective High Limits
CorTemp®CorTemp®
CorTemp®
CorTemp®
